This should be easy, just follow our instructions and you will be back to Net flix in no time.
Estimated time for assembly
What you need
• Some of your favourite bubbly or your preferred relaxant
• Use the packaging car ton as a working sur face to prevent product damage during assembly
• Phillips head screwdriver
• Drill (not included)
• 1/4” Drill bit (not included)
• 5/16” Drill bit (not included)
1. Do not tighten bolts / screws completely until all bolts / screws are lined up and inser ted into holes
2 . Do not over tighten screws and bolts to avoid stripping.
3. Please use hand tools to assemble this product.
Step 1
Let ’s get this thing fired up! Begin by at taching the Arched Tops (A) to the Middle Side Frames (B). First, inser t the Wooden Dowels (9) into the designated holes Then, use a Hex But ton Head Bolt (1) with a Spring Washer (4) and a Flat Washer (5) to secure them tightly
At tach the Open Shelves (C) to one of the Side Frames (B). First, inser t the Wooden Dowels (9) into the designated holes. Then, use a Hex But ton Head Bolt (1) with a Spring Washer (4) and a Flat Washer (5) to secure them tightly
Step 2 9
You should be a pro by now! Repeat Step 2 with the other Side Frame (B). Step 3
Secure the Magnetic Door Catch (13) to the Top Cabinet Panel (F) usig two M3 x15mm Screws (1 ). Then, attach the Back Stretcher (H) to the Top Cabinet Panel (F) by inserting the Wooden Dowels (9) into the designated holes. Then, use a Hex Button Head Bolt (3) with a Spring Washer (4) and a Flat Washer (5) to secure them tightly.
Step 5
No, this isn’t Deja Vu!
Repeat Step 4 with the Bot tom Cabinet Panel (G).
4 5 6 3
Twist four of the Cam Lock Bolts (7 ) into the designated holes on the Bot tom Side Panel (Right)(E) and Bot tom Side Panel (Lef t)(D). Be sure the Cam Lock Bolts are tightened all the way.
Step 6 x4pcs 7 x
At tach the Top Cabinet Panel (F ) and Bottom Cabinet Panel (G) to the Bottom Side Panel (Right) by inserting the Wooden Dowels (9) into the designated holes. Then, use a Hex Button Head Bolt (1) with a Spring Washer (4) and a Flat Washer (5) to tighten everything to 100%.
8 x2pcs 8
Inser t the Back Panel (I) ver tically into the groove in the side panel. Secure with t wo Cam Locks (8).
See the following page for a quick guide on cam locks!
Did you know?
Cam locks are used to join t wo panels together, usually the edge of one to the flat side of another.
First, your cam bolt (or cam pin) will need to be properly inser ted into the flat side of the board.
Import ant Note: Only tighten the cam bolt until it is secure. Do not over-tighten.
Next, you will fit the proper hole on the edge of the associated joining panel over the cam bolt.
Import ant Note: When installed properly, the head of the cam bolt will be visible through the larger hole on the side of the joining panel.
Next, you will notice the cam lock has a “C” shaped back Commonly, an arrow on the front of the cam lock points in the same direct ion as the open sec tion on back
Using these as your cue, insert the cam lock into the large hole so the opening of the “C” fits over the head of the cam bolt.
Using a screwdriver, you will turn the cam lock until it stops, usually between 130º or 180º. You will feel the panels pulling closer until they are secured.
Import ant Note: Only turn the cam lock until the panels are fully engaged & feel secure Turning too far may lead to hardware failure
Still having issues?
If a cam loc k seem s to be spinning in plac e or is not “catching” or pulling the panel s together as expected , first rem ove th e cam loc k & tr y agai n while mak in g sure that every thin g is properly positoned & oriented.
If you are still having issues getting things worki n g as expected, firs t re move the cam loc k then unscr ew th e cam bolt slightl y (les s than 1 complet e turn) to s ee if that helps with the alignment of the cam lock & bolt
Secure the Bot tom Side Panel (Lef t)(D) to what you’ve assembled so far from Step 8 Be sure that the back panel is inser ted in the groove in the side panel.
Secure with t wo Cam Locks (8).
Would you believe us if we told you you’re over half way finished?! Step 10 8 x2 x2pcs 8
Time to bring it all together! Secure the Arched Top section with the bot tom section by inster ting the Wooden Dowels (9) into the designated holes. Then, use a Hex But ton Head Bolt (2) with a Spring Washer (4) and a Flat Washer (5) to secure them tightly Step 11
Inser t four Shelf Pins (12) at the height you want the shelf to be. Then, place the Shelf ( J) on top of the pins.
HELPFUL TIP: Adjust feet to balance cabinet.
If you’re still having trouble lining ever yt hing up, your next step should be to tr y to adjust the feet slightly to square up the cabinet & doors. Follow the illustrations below:
If the right door appears to be hanging low, you can adjust the adjustable leveler on the front right until the door is better aligned.
If the lef t door appears to be hanging low, you can adjust the adjustable leveler on the front left until the door is better aligned
5/16” Drill Bit
5/16” HoleW
3 Begin tightening.
4. Anchor is secure when screw is tightened to 100%
IMPORTANT NOTE:
Non-Drywall Anchor (17) requires 1/4” Drill Bit
Secure the other Plastic Bracket (16) to the back of the bookshelf using the M3.5*15MM Screws (1 ) and then secure the bookshelf to the wall by looping the Plastic Tether (19) through both brackets.
Young children (and/or pets) can be seriously injured by tipping furniture units.
You must install the provided anti-tip kit hardware solution, as instructed, to prevent the furniture unit(s) from tipping overwhich could possibly lead to injuries or damage.
The provided anti-tip kit hardware solution is intended only as an additional safety measure & deterrent; it is not a substitute for proper adult supervision.
The provided anti-tip kit hardware solution is not an earthquake restraint. If you wish to add the extra security of earthquake restraints, they must be purchased & installed separately
Give us a call 1- 866 - 619 -1004 or shoot us a message at help@nathanjames.com we will issue you a free replacement with zero hassle.
Our way Their way
Give us a call
Replacement
You
Re-package item
Schedule pick up Track package
Replacement
You
We really don’t want you to go through the hassle of re-packaging your item and sending it back , because let ’s be honest…nobody has time for that.
We want your product to last as long as possible, so we recommend that you tighten the screws 2 weeks af ter assembly and for added safet y check the tightness of all screws ever y 2 months.
For proper care and treatment, please check our website at NathanJames.com/products
Safe use of this produc t star ts with you.
Use this product responsibly with the primar y concern for your safet y. Follow assembly instructions carefully and inspect product upon receipt and each use.
Nathan James and its parent companies cannot be held legally responsible for any injuries or death resulted from failure to follow instructions or improper use of this product
Do not modif y the struc ture of this produc t in any way.
Our products have been tested to meet specific safet y measures as they were originally intended to be sold. Any modifications will present the risk of creating significant safet y issues which NJ will not be responsible for.
DO NOT use for commercial purposes
DO NOT frolic on bookshelf
DO NOT use bookshelf as foot stool
DO NOT leave spilled liquid on shelves
DO NOT use bookshelf if damaged
DO NOT make temporar y repairs
DO NOT use outdoors
For star ters, thanks for being you.
Toll-free at 1-866-619-1004 Help@nathanjames.com NathanJames.com/help
We do our best to ensure your furniture arrives without any problems, but occasionally mistakes happen as humans we are imper fect beings. In the event that a par t is damaged or missing, we will be more than happy to provide you with replacement par t(s) for free
Warrant y
This product comes with a lifetime warrant y from the date of purchase. Please use your phone to scan the QR code to register your product or visit ht tps://goo.gl/i9dk3q
Did we do alright? Please spread the love!
If you are happy with your product, tell your friends and family about us or even bet ter leave us a review online. Spreading the word gives us the oppor tunit y to make more people happy and keep our prices low for your next purchase.
