This should be easy, just follow our instructions and you will be back to Netflix in no time.
Estimated time for assembly
What you need
• Some of your favourite bubbly or your preferred relaxant
• Use the packaging carton as a working surface to prevent product damage during assembly
• Phillips head screwdriver
• Drill (not included)
• 1/4”
1. Do not tighten bolts / screws completely until all bolts / screws are lined up and inserted into holes.
2. Do not over tighten screws and bolts to avoid stripping.
3. Please use hand tools to assemble this product. Do not use power tools.
Let’s get this thing fired up! Begin by attaching the Arched Tops (A) to the Middle Side Frames (B). First, insert the Wooden Dowels (9) into the designated holes. Then, use a Hex Button Head Bolt (1) with a Spring Washer (4) and a Flat Washer (5) to secure them tightly.
1 1 4 5 6
Step 2
Attach the Open Shelves (C) to one of the Side Frames (B). First, insert the Wooden Dowels (9) into the designated holes. Then, use a Hex Button Head Bolt (1) with a Spring Washer (4) and a Flat Washer (5) to secure them tightly.
Step 3
You should be a pro by now! Repeat Step 2 with the other Side Frame (B).
Step 4
Secure the Magnetic Door Catch (13) to the Top Cabinet Panel (F) usig two M3x15mm Screws (14). Then, attach the Back Stretcher (H) to the Top Cabinet Panel (F) by inserting the Wooden Dowels (9) into the designated holes. Then, use a Hex Button Head Bolt (3) with a Spring Washer (4) and a Flat Washer (5) to secure them tightly.
No, this isn’t Deja Vu! Repeat Step 4 with the Bottom Cabinet Panel (G). Step 5
Twist four of the Cam Lock Bolts (7) into the designated holes on the Bottom Side Panel (Right)(E) and Bottom Side Panel (Left)(D). Be sure the Cam Lock Bolts are tightened all the way. Step 6
Attach the Top Cabinet Panel (F) and Bottom Cabinet Panel (G) to the Bottom Side Panel (Right) by inserting the Wooden Dowels (9) into the designated holes. Then, use a Hex Button Head Bolt (1) with a Spring Washer (4) and a Flat Washer (5) to tighten everything to 100%.
8
Insert the Back Panel (I) vertically into the groove in the side panel. Secure with two Cam Locks (8).
See the following page for a quick guide on cam locks!
Did you know?
Cam locks are used to join t wo panels together, usually the edge of one to the flat side of another.
First, your cam bolt (or cam pin) will need to be properly inser ted into the flat side of the board.
Import ant Note: Only tighten the cam bolt until it is secure. Do not over-tighten
Next, you will fit the proper hole on the edge of the associated joining panel over the cam bolt.
Import ant Note: When installed properly, the head of the cam bolt will be visible through the larger hole on the side of the joining panel.
Next, you will notice the cam lock has a “C” shaped back. Commonly, an arrow on the front of the cam lock points in the same direct ion as the open sec tion on back
Using these as your cue, insert the cam lock into the large hole so the opening of the “C” fits over the head of the cam bolt.
Using a screwdriver, you will turn the cam lock until it stops, usually between 130º or 180º. You will feel the panels pulling closer until they are secured.
Import ant Note: Only turn the cam lock until the panels are fully engaged & feel secure Turning too far may lead to hardware failure
Still having issues?
If a cam loc k seem s to be spinning in plac e or is not “catching” or pulling the panel s together as expected , first rem ove th e cam loc k & tr y agai n while mak in g sure that every thin g is properly positoned & oriented.
If you are still having issues getting things worki n g as expected, firs t re move the cam loc k then unscr ew th e cam bolt slightl y (les s than 1 complet e turn) to s ee if that helps with the alignment of the cam lock & bolt
Secure the Bottom Side Panel (Left)(D) to what you’ve assembled so far from Step 8. Be sure that the back panel is inserted in the groove in the side panel.
Secure with two Cam Locks (8).
Would you believe us if we told you you’re over halfway finished?!
Time to bring it all together! Secure the Arched Top section with the bottom section by insterting the Wooden Dowels (9) into the designated holes. Then, use a Hex Button Head Bolt (2) with a Spring Washer (4) and a Flat Washer (5) to secure them tightly. Step 11
Step 12
Insert four Shelf Pins (12) at the height you want the shelf to be. Then, place the Shelf (J) on top of the pins.
Tighten the Hinges (10) to the Left (K) and Right (L) doors using the M3.5x15mm Screws (11). Tighten to 100%. Step 13
x8pcs 10 x4pcs 11
Step 14
Attach the doors to the bookshelf by securing the Hinges with the M3.5x15mm Screws (11). After the doors are attached, fasten the Handles (22) to the doors using the 5/32” x 1” Bolts (23).
Now your bookshelf has some stylish accessories!
HELPFUL TIP: Adjust feet to balance cabinet.
Then you’ve come to the right place. Follow the illustrations below to get your cabinet door aligned and ready for action.
If you’re still having trouble lining ever yt hing up, your next step should be to tr y to adjust the feet slightly to square up the cabinet & doors. Follow the illustrations below:
If the right door appears to be hanging low, you can adjust the adjustable leveler on the front right until the door is bett er aligned.
If the lef t door appears to be hanging low, you can adjust the adjustable leveler on the front left until the door is bett er aligned
Safety first! Let’s get this bookshelf secured to the wall. Find where you want this bookshelf to live and then mount the Plastic Bracket (16) to the wall using the provided Wall Anchors (17) or (21) and Screws (20). We recommend using a 5/16” drill bit.
Non-Drywall Anchor (17) requires 1/4” Drill Bit
Drywall Anchor (21) requires 5/16” Drill Bit
Secure the other Plastic Bracket (16) to the back of the bookshelf using the M3.5*15MM Screws (18) and then secure the bookshelf to the wall by looping the Plastic Tether (19) through both brackets.
Young children (and/or pets) can be seriously injured by tipping furniture units.
You must install the provided anti-tip kit hardware solution, as instructed, to prevent the furniture unit(s) from tipping overwhich could possibly lead to injuries or damage.
The provided anti-tip kit hardware solution is intended only as an additional safety measure & deterrent; it is not a substitute for proper adult supervision.
The provided anti-tip kit hardware solution is not an earthquake restraint. If you wish to add the extra security of earthquake restraints, they must be purchased & installed separately.
5/16” Drill Bit
5/16” Hol eW
3. Begin tightening.
4. Anchor is secure when screw is tightened to 100%
Give us a call 1-866-619-1004 or shoot us a message at help@nathanjames.com we will issue you a free replacement with zero hassle.
Our way Their way
Give us a call
Replacement
You
Re-package item
Schedule pick up
Track package
Replacement
You
We really don’t want you to go through the hassle of re-packaging your item and sending it back, because let’s be honest…nobody has time for that.
We want your product to last as long as possible, so we recommend that you tighten the screws 2 weeks after assembly and for added safety check the tightness of all screws every 2 months.
For proper care and treatment, please check our website at NathanJames.com/products
Use this product responsibly with the primary concern for your safety. Follow assembly instructions carefully and inspect product upon receipt and each use.
Nathan James and its parent companies cannot be held legally responsible for any injuries or death resulted from failure to follow instructions or improper use of this product.
Do not modify the structure of this product in any way.
Our products have been tested to meet specific safety measures as they were originally intended to be sold. Any modifications will present the risk of creating significant safety issues which NJ will not be responsible for.
DO NOT use for commercial purposes
DO NOT frolic on bookshelf
DO NOT use bookshelf as foot stool
DO NOT leave spilled liquid on shelves
DO NOT use bookshelf if damaged
DO NOT make temporary repairs
DO NOT use outdoors
