Farley Bar Cart Let’s build the 24-0403-VN Scan me! Free Lifetime Warranty 30 30 M I NUTE ASSE MBLY SKU 45500
This should be easy, just follow our instructions and you will be back to Netflix in no time.
What you need
• Some of your favourite bubbly or your preferred relaxant
• Use the packaging carton as a working surface to prevent product damage during assembly • Rubber
2
Ok, let’s get rolling What’s included
Description Qty A Back Leg Frame Sub-assembly 1 B Solid Wood Stretchers 4 C Shelf Panel 2 D Metal Stretchers / Rails 4 E Front Leg Frame Sub-assembly 1 1 1/4 × 2 inch Hex Button Head Bolt 8 2 1/4 × 1/2 inch Lock Washer 8 3 1/4 × 1/2 inch Flat Washer 8 4 Allen Key 30 x110mm 1 5 Dia 15/13 × 10mm Wood Plugs 8 6 Dia 15/13 × 10mm Wood Plugs (Extra) 4 7 Foot pads (extra) 2 30:00
60 lbs Weight Limitation Toll-free
Help@nathanjames.com Nathanjames.com/help Do not use a drill Scan me! Free Lifetime Warranty
Mallet (recommended)
Estimated time for assembly
at 1-866-619-1004
The goods
IMPORTANT
1. Do not tighten bolts / screws completely until all bolts / screws are lined up and inserted into holes.
2. Do not over tighten screws and bolts to avoid stripping.
3. Please use hand tools to assemble this product. Do not use power tools.
3
E
B C C D D D A
7
B B
B D
Step 1
Let’s get this thing fired up! Start by securing the Solid Wood Stretchers (B) to the Back Leg Frame (A) using a pair of Flat Washers (3), Lock Washers (2), and Hex Button Head Bolts (1), as pictured below. Tighten to 90% for now.
4 B A
Do NOT overtighten hardware. Tighten only to 90% for now.
2 3 x2 B
1
4
90%
Cha-cha slide the Shelf Panels (C) in to the Solid Wood Stretchers (B). Then, slide the Shelf Panels (C) to the Back Leg Frame (A). Step 2 C C A B B
5
Let’s get this thing fired up! Start by securing the Solid Wood Stretchers (B) to the Back Leg Frame (A) using a pair of Flat Washers (3), Lock Washers (2), and Hex Button Head Bolts (1), as pictured below. Tighten to 90%.
Do NOT overtighten hardware. Tighten only to 90% for now. Step 3 2 3 x2 1 4 B B
6
90%
Get those dancing shoes back on! Cha-cha slide four of the Metal Stretchers (D) into the hole of the Back Leg Frame (A).
Step 4 x4 D A A
7
Step 5
Slide the Metal Stretchers (D) into their respective holes. Secure the 2 Solid Wood Stretchers (B) to the Front Leg Frame (E) using a pair of Flat Washers (3), Lock Washers (2), and Hex Button Head Bolts (1).
Tighten to 60%.
Do NOT overtighten hardware. Tighten only to 60% for now.
3 x2 E 1 4 B B D
2
8
60%
Step 6
Two more steps until your bar cart is ready for you to make cocktails on!
Ensure that all of the Metal Stretchers (D) are aligned in their respective holes. Secure the Solid Wood Stretchers (B) to the Front Leg Frame (E) using a pair of Flat Washers (3), Lock Washers (2), and Hex Button Head Bolts (1).
Then, tighten all of the fasteners from Step 5 and Step 6 to 90%.
Do NOT overtighten hardware. Tighten only to 90% for now.
3 x4
2
1 4
9
E
B
D 90%
B
Time to secure everything to 100%.
7 x8
10
Step
Last but not least, place the Wood Plugs (5) into the holes, as pic tured below.
Cheers! Step 8 5 x8 5 5
HELPFUL TIP: It is recommended to use a Rubber Mallet or something similar to tap the Wood Plugs securely into place secured in place not secured in place
1111
No heartburn, when we handle the return
Give us a call 1-866-619-1004 or shoot us a message at help@nathanjames.com we will issue you a free replacement with zero hassle.
Our way Their way
Give us a call
Replacement
You
Re-package item
Schedule pick up
Track package
Replacement
You
We really don’t want you to go through the hassle of re-packaging your item and sending it back, because let’s be honest…nobody has time for that.
12
Safety first, fun later
We want your product to last as long as possible, so we recommend that you tighten the screws 2 weeks after assembly and for added safety check the tightness of all screws every 2 months.
For proper care and treatment, please check our website at NathanJames.com/products
Safe use of this product starts with you.
Use this product responsibly with the primary concern for your safety. Follow assembly instructions carefully and inspect product upon receipt and each use.
Nathan James and its parent companies cannot be held legally responsible for any injuries or death resulted from failure to follow instructions or improper use of this product.
Proper use
Do not modify the structure of this product in any way.
Our products have been tested to meet specific safety measures as they were originally intended to be sold. Any modifications will present the risk of creating significant safety issues which NJ will not be responsible for.
DO NOT use for commercial purposes
DO NOT frolic on bar stool
DO NOT use bar stool as foot stool
DO NOT leave spilled liquid on seat
DO NOT use bar stool if damaged
DO NOT make temporary repairs
DO NOT use outdoors
13
We are only in business if you’re happy
For starters, thanks for being you.
Toll-free at 1-866-619-1004
Help@nathanjames.com
NathanJames.com/help
We do our best to ensure your furniture arrives without any problems, but occasionally mistakes happen—as humans we are imperfect beings. In the event that a part is damaged or missing, we will be more than happy to provide you with replacement part(s) for free.
Warranty
This product comes with a lifetime warranty from the date of purchase. Please use your phone to scan the QR code to register your product or visit https://goo.gl/i9dk3q Rubber Mallet (recommended) •
