Let’s build the
Jackson Floating Side Table 0
70
SEMBL
Y
A
S
M I N UT E
7
SKU 34106
Scan me! Free Lifetime Warranty 23-0815-VN
Ok, let’s get rolling
What’s included Description
Qty
1
Top Panel
1
2
Left Side Panel
1
3
Right Side Panel
1
Estimated time for assembly
4
Bottom Panel
1
70:00
5
Back Stretcher
1
6
Back Panel
1
7
French Cleat for Cabinet
2
This should be easy, just follow our instructions and you will be back to Netflix in no time.
What you need •
Some of your favourite bubbly or your preferred relaxant
8
French Cleat for Wall
2
•
Use the packaging carton as a working surface to prevent product damage during assembly
9
Drawer Front
1
•
Phillips head screwdriver
10
Drawer Left Side
1
•
Drill
•
1/4” Drill Bit OR 5/16” Drill Bit
11
Drawer Right Side
1
12
Drawer Back
1
13
Drawer Bottom
1
Weight Limitation
33
lbs for top
11
lbs for drawer
Toll-free at 1-866-619-1004 Help@nathanjames.com Nathanjames.com/help
Scan me! Free Lifetime Warranty
2
The goods 7 1
7 8 8
3 6 5
2
4
11 12
13
10 9
IMPORTANT 1. Do not tighten bolts / screws completely until all bolts / screws are lined up and inserted into holes. 2. Please use hand tools for assembly. Do not over tighten screws and bolts to avoid stripping. 3
What’s included Description
Qty
A
M6*35mm Cam Bolt
18
B
15*9.5mm Cam Lock
18
C
M6*30mm Wooden Dowel
12
D
M4*30mm Screw
8
E
M3*12mm Screw
8
F
Left Side Panel Slider (CL)
1
F
Right Side Panel Slider (CR)
1
F
Right Side Drawer Slider (DR)
1
F
Left Side Drawer Slider (DL)
1
G
M4*50mm Screw (for Non-Drywall Anchor)
4
H
M6*30mm Anchor for Non-Drywall
4
I
Drywall Anchor
4
J
M4*70mm Screw (for Drywall Anchor)
4
K
PVC Sticker
4
L
Mounting Installation Template
1
M
M4*16mm Screw (for Handle)
1
N
Handle
1
4
The goods A
B
F
CL
H
C
F
D
F
CR
I
M
K
N
5
F
DR
J
E
DL
G
L
Step 1 Let’s get this thing fired up! Lay down the packaging carton or use carpet as a working surface. To start, screw the M6*35mm Cam Bolts (A) into the Top Panel (1), Left Side Panel (2), Right Side Panel (3), and Drawer Front (9).
A
A
A
A
A
A
A A A
A
1
2
A
A A A A 9 3
6
Step 2 Attach the Drawer Left Side (10) and Drawer Right Side (11) to the Drawer Back (12) using the M4*30mm Screws (D).
Step 3 To finish up the drawer, slide in the Drawer Bottom (13). Then attach the Drawer Front (9) using the 15*9.5mm Cam Locks (B) to secure in place. Finally, attach the Handle (N) using the M4*16mm Screw (M). See the following page for instructions on how to use cam locks.
7
8
Step 4 Get those Drawer Sliders (F) out and let’s finish this drawer! Using the M3*12mm Screws (E) and the diagram below, align the DL and DR Drawer Sliders and secure in place.
Tip from a friend to a friend: Pay careful attention that your sliders are on the correct way— look for the DR and DL markers!
E E E E
F (DL)
F (DR)
9
Step 5 We know this graphic looks intense, but trust us, it’s easy! Secure the Left Side Panel Slider (F)(CL) and Right Side Panel Slider (F)(CR) to Left Side Panel (2) and Right Side Panel (3) using the M3*12mm Screws (E). Finally, add Wooden Dowels (C) to both Panels (2)(3).
E
Back
E
E E
C
Front
F (CL)
x2
E Front
E F (CR)
C Back
10
x2
Step 6 Next, insert Wooden Dowels (C) into the sides of the Back Stretcher (5). Then secure the Back Stretcher (5) to the Right Side Panel (3) and use the Cam Lock (B) to secure in place.
B
3 C
C
C 5
C
11
Step 7 Take the cabinet you’ve built so far from Step 6 and attach the Bottom Panel (4) using the Wooden Dowels (C). Once in place, secure using the Cam Locks (B), then place a PVC Sticker (K) over the top of the Cam Locks if you don’t want them to be visible.
12
Step 8 Attach the Left Side Panel (2) by repeating the process from Step 7, and continue placing the PVC Stickers (K) over the Cam Locks (B).
13
Step 9 You’re doing so well! So we decided to make this step super easy for you. Just slide in the Back Panel (6).
14
Step 10 Now attach the Top Panel (1) by aligning the holes in the Top Panel with the Wooden Dowels already placed in the cabinet sides in previous steps. Once in place, secure using the Cam Locks (B).
15
Step 11 Now turn around the cabinet and secure the French Cleat (7) pieces by lining up the Cam Bolts (A). Once in place, secure using the Cam Locks (B).
16
Step 12 Now reach into the back of the panel and secure the Back Stretcher (5) using the M4*30mm Screws (D).
17
Step 13: Using the Mounting Installation Template
18
Step 14: Non-drywall After using the Mounting Installation Template (L) to mark and pre-drill holes into your wall, press the NonDrywall Anchors (H) into the drilled holes. After the anchors are in place, secure the French Cleat for Wall (8) to the wall by inserting and tightening the M4*50mm Screws (G) through the Cleats and into the anchors.
Wall
See the next page (page 19) for more detailed instructions. If you’re mounting your table onto drywall, skip ahead to page 20 for instructions.
19
Step 14: Non-drywall (cont.)
20
Step 14: Drywall After using the Mounting Installation Template (L) to mark and pre-drill holes into your wall, press the Drywall Anchors (I) into the drilled holes. After the anchors are in place, secure the French Cleat for Wall (8) to the wall by inserting and tightening the M4*70mm Screws (J) through the Cleats and into the anchors.
Wall
See the next page (page 21) for more detailed instructions. If you’re mounting your table onto non-drywall, skip back to page 18 for instructions.
21
Step 14: Drywall (cont.)
22
Step 14: How to Use Drywall Anchors
23
Step 15 Now that the wall is prepped, line up the French Cleat for the Cabinet with the French Cleat for the Wall and set your floating side table on the wall.
Wall
24
Step 16 Before you start placing your chips and salsa on the tabletop, please finish securing the table to the wall using the M4*30mm Screws (D).
25
Step 17 You made it to the last step! We’re super proud of you, and that table is looking great! Now line up the drawer sliders and carefully push your drawer in. Okay, now your can place your chips and salsa on top!
26
No heartburn, when we handle the return Give us a call 1-866-619-1004 or shoot us a message at help@nathanjames.com we will issue you a free replacement with zero hassle.
Our way
Their way
Give us a call
Re-package item
Replacement
Schedule pick up
You
Track package Replacement You
We really don’t want you to go through the hassle of re-packaging your item and sending it back, because let’s be honest…nobody has time for that.
27
Safety first, fun later We want your product to last as long as possible, so we recommend that you tighten the screws 2 weeks after assembly and for added safety check the tightness of all screws every 2 months. For proper care and treatment, please check our website at NathanJames.com/products
Safe use of this product starts with you.
Do not modify the structure of this product in any way.
Use this product responsibly with the primary concern for your safety. Follow assembly instructions carefully and inspect product upon receipt and each use.
Our products have been tested to meet specific safety measures as they were originally intended to be sold. Any modifications will present the risk of creating significant safety issues which NJ will not be responsible for.
Nathan James and its parent companies cannot be held legally responsible for any injuries or death resulted from failure to follow instructions or improper use of this product.
Proper use
DO NOT
use for commercial purposes
DO NOT
frolic on table
DO NOT
use table as stool
DO NOT
leave spilled liquid on table
DO NOT
use table if damaged
DO NOT
make temporary repairs
DO NOT
use outdoors
28
We are only in business if you’re happy For starters, thanks for being you. Toll-free at 1-866-619-1004 Help@nathanjames.com NathanJames.com/help
We do our best to ensure your furniture arrives without any problems, but occasionally mistakes happen—as humans we are imperfect beings. In the event that a part is damaged or missing, we will be more than happy to provide you with replacement part(s) for free.
Warranty This product comes with a lifetime warranty from the date of purchase. Please use your phone to scan the QR code to register your product or visit https://goo.gl/i9dk3q
Did we do alright? Please spread the love! If you are happy with your product, tell your friends and family about us or even better leave us a review online. Spreading the word gives us the opportunity to make more people happy and keep our prices low for your next purchase.
Brooklyn Burdon Founder, Nathan James
29
