Madison Rattan Modular Sofa Instruction Sheet 27263
Madison Seater Sofa
See the following configuration options: seater Page 3
2 seater Page 13
3 seater Page 26
4 seat sectional Page 43
5 seat sectional Page 60
This should be easy, just follow our instructions and you will be back to Net flix in no time.
Estimated time for assembly
What you need
• Some of your favourite bubbly or your preferred relaxant
• Use the packaging car ton as a working sur face to prevent product damage during assembly
• Phillips head screwdriver
Weight Limitation Toll-free at 1- 866 - 619 -1004
Help@nathanjames com Nathanjames.com/help 20:00
Let ’s get your home ready for movie night! Star t by at taching the Metal Bracket (1) to the side of the Seat Frame (C) using t wo Ø1/4 x 30mm Bolts (2).
Step 1 Step 2
Join the Leg + Arm SubAssembly (Left) (A) to the Seat Frame (C) by the brackets.
Step 3
Align Par t (A) and (C). Then open the zipper on Par t (A). Place a flat washer on one Ø5/16” x 60mm Thumb Screw (4) and another Flat Washer on a Ø5/16” Wing Nut (6) and twist to secure Part (A) and (C) together.
Close the zipper when complete
Remove the pre-installed metal bracket from the seat frame.
Step 4 Step 5
Tighten t wo Metal Brackets (1) on the side of the Frame using four Ø1/4” x 30mm Bolts (2), as shown below
x 2 x4
Use the wall to help stabilize the unit. Then, at tach the Leg + Arm Sub-Assembly (Right) (B) to the brackets
Step 7
Open the zipper on the Leg + Arm Sub-Assembly (Right) (B). Place a flat washer on one Ø5/16” x 60mm Thumb Screw (4) and another Flat Washer on a Ø5/16” Wing Nut (6) and twist to secure.
Your fly ’s down! Don’t forget to close the zipper
8
You made it to the last step!
Place the Backrest Pillows (F ) and Seat Cushions (E) on to your sofa
Get your popcorn ready, movie nights just got a whole lot cozier!
Madison 2-Seater Sofa
This should be easy, just follow our instructions and you will be back to Net flix in no time.
Estimated time for assembly
What you need
• Some of your favourite bubbly or your preferred relaxant
• Use the packaging car ton as a working sur face to prevent product damage during assembly
• Phillips head screwdriver
Weight Limitation
Weight per seat. 300lbs
Toll-free at 1- 866 - 619 -1004 Help@nathanjames com Nathanjames.com/help
The good s
Let ’s get your home ready for movie night! Star t by at taching the Metal Bracket (1) to the side of the Seat Frame (C) using t wo Ø1/4 x 30mm Bolts (2).
Step 1 Step 2
Join the Leg + Arm SubAssembly (Left) (A) to the Seat Frame (C) by the brackets.
Step 3
Align Par t (A) and (C). Then open the zipper on Par t (A). Place a flat washer on one Ø5/16” x 60mm Thumb Screw (4) and another Flat Washer on a Ø5/16” Wing Nut (6) and twist to secure Part (A) and (C) together.
Close the zipper when complete
Step 4
Join the other Seat Frame (C) to the bracket on the side of the Seat Frame from the previous steps
Step 5
Be sure that the t wo Frames are sit ting flush and then secure the t wo together by placing a flat washer on one Ø5/16” x 60mm Thumb Screw (4) and another Flat Washer on a Ø5/16” Wing Nut (6) and twist to secure.
Step 6 7 x4
Grab a friend because you’re going to need an extra hand for this step! At tach the Seat Frame Suppor t Leg ( J) to the bot tom of the Frame using four M4 x 20 mm Screws (7).
Tip: The suppor t leg should be aligned with the white line.
Remove the pre-installed metal bracket from the seat frame.
Step 7 Step 8
Tighten t wo Metal Brackets (1) on the side of the Frame using four Ø1/4” x 30mm Bolts (2), as shown below
Step 9
Use the wall to help stabilize the unit. Then, at tach the Leg + Arm Sub-Assembly (Right) (B) to the brackets
Step 10
Open the zipper on the Leg + Arm Sub-Assembly (Right) (B) Place a flat washer on one Ø5/16” x 60mm Thumb Screw (4) and another Flat Washer on a Ø5/16” Wing Nut (6) and twist to secure.
Your fly ’s down! Don’t forget to close the zipper
Step 11
You made it to the last step!
Place the Backrest Pillows (F ) and Seat Cushions (E) on to your sofa
Get your popcorn ready, movie nights just got a whole lot cozier!
Madison 3 -Seater Sofa
This should be easy, just follow our instructions and you will be back to Net flix in no time.
Estimated time for assembly
What you need
• Some of your favourite bubbly or your preferred relaxant
• Use the packaging carton as a working sur face to prevent product damage during assembly
• Phillips head screwdriver
Limitation
seat.
The goods
Let ’s get your home ready for movie night! Star t by at taching the Metal Bracket (1) to the side of the Seat Frame (C) using t wo Ø1/4 x 30mm Bolts (2).
Step 1 Step 2
Join the Leg + Arm SubAssembly (Left) (A) to the Seat Frame (C) by the brackets.
Step 3
Align Par t (A) and (C). Then open the zipper on Par t (A). Place a flat washer on one Ø5/16” x 60mm Thumb Screw (4) and another Flat Washer on a Ø5/16” Wing Nut (6) and twist to secure Part (A) and (C) together.
Close the zipper when complete
Step 4
Join the other Seat Frame (C) to the bracket on the side of the Seat Frame from the previous steps
Step 5
Be sure that the t wo Frames are sit ting flush and then secure the t wo together by placing a flat washer on one Ø5/16” x 60mm Thumb Screw (4) and another Flat Washer on a Ø5/16” Wing Nut (6) and twist to secure.
Step 6 7 x4
Grab a friend because you’re going to need an extra hand for this step! At tach the Seat Frame Suppor t Leg ( J) to the bot tom of the Frame using four M4 x 20 mm Screws (7).
Tip: The suppor t leg should be aligned with the white line.
Step 7
Join the third Seat Frame (C) to the bracket on the side of the Seat Frame from the previous steps
Step 8
Ensure that the t wo seat frames are aligned and sit ting flush. Then secure the t wo together by placing a flat washer on one Ø5/16” x 60mm Thumb Screw (4) and another Flat Washer on a Ø5/16” Wing Nut (6) and twist to secure.
Bring that friend back and at tach the other Seat Frame
Suppor t Leg ( J) to the bot tom of the seat frame using four M4 x 20 mm Screws (7).
Tip: The suppor t leg should be aligned with the white line
Step 10
Remove the pre-installed metal bracket from the seat frame. Remove
Tighten t wo Metal Brackets (1) on the side of the seat frame using four Ø1/4” x 30mm Bolts (2), as shown below.
Step 12
Use the wall to help stabilize the unit. Then, at tach the Leg + Arm Sub-Assembly (Right) (B) to the brackets.
Step 13
Open the zipper on the Leg + Arm Sub-Assembly (Right) (B). Place a flat washer on one Ø5/16” x 60mm Thumb Screw (4) and another Flat Washer on a Ø5/16” Wing Nut (6) and twist to secure.
Your fly ’s down! Don’t forget to close the zipper.
Step 14
You made it to the last step!
Place the Backrest Pillows (F ) and Seat Cushions (E) on to your sofa
Get your popcorn ready, movie nights just got a whole lot cozier!
Madison 4 -Seat Sectiona l
This should be easy, just follow our instructions and you will be back to Net flix in no time.
What you need
• Some of your favourite bubbly or your preferred relaxant
• Use the packaging car ton as a working sur face to prevent product damage during assembly
• Phillips head screwdriver
Weight Limitation
Weight per seat.
Toll-free at 1- 866- 619 -1004 Help@nathanjames.com Nathanjames com/help
The goods
Let ’s get your home ready for movie night! Star t by at taching the Metal Bracket (1) to the side of the Seat Frame (C) using t wo Ø1/4 x 30mm Bolts (2).
Step 1 Step 2
Join the Leg + Arm SubAssembly (Left) (A) to the Seat Frame (C) by the brackets.
Step 3
Align Par t (A) and (C). Then open the zipper on Par t (A). Place a flat washer on one Ø5/16” x 60mm Thumb Screw (4) and another Flat Washer on a Ø5/16” Wing Nut (6) and twist to secure Part (A) and (C) together.
Close the zipper when complete
Step 4
Join the other Seat Frame (C) to the bracket on the side of the Seat Frame from the previous steps
Step 5
Be sure that the t wo Frames are sit ting flush and then secure the t wo together by placing a flat washer on one Ø5/16” x 60mm Thumb Screw (4) and another Flat Washer on a Ø5/16” Wing Nut (6) and twist to secure.
Step 6 7 x4
Grab a friend because you’re going to need an extra hand for this step! At tach the Seat Frame Suppor t Leg ( J) to the bot tom of the Frame using four M4 x 20 mm Screws (7).
Tip: The suppor t leg should be aligned with the white line.
Step 7
Keep your friend close! At tach the other Seat Frame Support Leg ( J) to the bottom of the seat frame using M4 x 20 mm Screws (7).
Step 8
Remove the pre-installed metal bracket from the seat frame
Tip: The suppor t leg should be aligned with the white line.
Step 9
Tighten t wo Metal Brackets (1) on the side of the seat frame using four Ø1/4” x 30mm Bolts (2), as shown below
Step 10
Join the Leg + Arm SubAssembly (Right) (B) to the Seat Frame (C) by the brackets.
Align Part (B) and (C). Then open the zipper on Part (B). Place a flat washer on one Ø5/16” x 60mm Thumb Screw (4) and another Flat Washer on a Ø5/16” Wing Nut (6) and twist to secure Part and (C) together.
Close the zipper when complete.
Step 12
Join the Corner Seat Frame (D) to Par t (B) and (C) by the brackets.
Ensure that the t wo seat frames are aligned and sit ting flush. Then secure the t wo together by placing a flat washer on one Ø5/16” x 60mm Thumb Screw (4) and another Flat Washer on a Ø5/16” Wing Nut (6) and twist to secure, as shown below.
Step 14
Attach the Seat Frame Support Leg J) to the bottom of the seat frame using four M4 x 20 mm Screws (7).
Place a 50mm Plastic Washer (9) on to a Corner Support Leg (K) and twist to secure, as shown below.
Tip: The suppor t leg should be aligned with the white line.
Step 15
Bring the t wo assembled sofa units together and secure by the brackets, as shown below.
Step 16
You made it to the last step! Place the Backrest Pillows (F ), Corner Pillow 1 (H), Corner PIllow 2 (I), Corner Seat Cushion (G), and Seat Cushions (E) on to your sofa.
Get your popcorn ready, movie nights just got a whole lot cozier!
Let ’s build the
Madison 5 -Seat Sectiona l
Configuration 1
Configuration 2
This should be easy, just follow our instructions and you will be back to Net flix in no time.
What you need
• Some of your favourite bubbly or your preferred relaxant
• Use the packaging car ton as a working sur face to prevent product damage during assembly
• Phillips head screwdriver
Let ’s get your home ready for movie night! Star t by at taching the Metal Bracket (1) to the side of the Seat Frame (C) using t wo Ø1/4 x 30mm Bolts (2).
Step 1 Step 2
Join the Leg + Arm SubAssembly (Left) (A) to the Seat Frame (C) by the brackets.
Step 3
Align Par t (A) and (C). Then open the zipper on Par t (A). Place a flat washer on one Ø5/16” x 60mm Thumb Screw (4) and another Flat Washer on a Ø5/16” Wing Nut (6) and twist to secure Part (A) and (C) together.
Close the zipper when complete
Step 4
Join the other Seat Frame (C) to the bracket on the side of the Seat Frame from the previous steps
Step 5
Be sure that the t wo Frames are sit ting flush and then secure the t wo together by placing a flat washer on one Ø5/16” x 60mm Thumb Screw (4) and another Flat Washer on a Ø5/16” Wing Nut (6) and twist to secure.
Step 6 7 x4
Grab a friend because you’re going to need an extra hand for this step! At tach the Seat Frame Suppor t Leg ( J) to the bot tom of the Frame using four M4 x 20 mm Screws (7).
Tip: The suppor t leg should be aligned with the white line.
Skip to Page 70 if you are doing Configuration 2!
No, this isn’t Deja Vu! At tach another Suppor t Leg ( J) to the bot tom of the seat frame, this time using t wo M4 x 20 mm Screws (7 ).
Tip: The suppor t leg should be aligned with the white line.
Step 8
Tighten t wo Metal Brackets (1) on the side of the seat frame using four Ø1/4” x 30mm Bolts (2), as shown below. 1 2 x2 x4
Step 9
Join the Leg + Arm SubAssembly (Right) (B) to the Seat Frame (C) by the brackets.
Align Part (C) and (B). Then open the zipper on Part (B). Place a flat washer on one Ø5/16” x 60mm Thumb Screw (4) ) and another Flat Washer on a Ø5/16” Wing Nut (6) (C) Part secure to twist and and together.
Close the zipper when complete.
Step 11
Join a Seat Frame (C) to the bracket on the side of the Seat Frame from the previous step.
You’re killin’ it!
Ensure that the t wo Frames are aligned and sit ting flush. Then secure the t wo together by placing a flat washer on one Ø5/16” x 60mm Thumb Screw (4) and another Flat Washer on a Ø5/16” Wing Nut (6) and twist to secure, as shown below.
You know the drill by now! Bring your friend back for an extra hand for this step!
At tach the Seat Frame Suppor t Leg ( J) to the bot tom of the Frame using four M4 x 20 mm Screws (7).
Tip: The suppor t leg should be aligned with the white line.
Step 14
Join the Corner Seat Frame (D) to the previously assembled seat frames by the brackets, as shown below.
Step 15
Ensure that the t wo Frames are aligned and sit ting flush. Then secure the t wo together by placing a flat washer on one Ø5/16” x 60mm Thumb Screw (4) and another Flat Washer on a Ø5/16” Wing Nut (6) and twist to secure, as shown below.
At tach the Seat Frame Suppor t Leg ( J) to the bot tom of the seat frame using four M4 x 20 mm Screws (7).
Place a 50mm Plastic Washer (9) on to a Corner Support Leg (K) and twist to secure, as shown below.
x4 9 x1
Tip: The suppor t leg should be aligned with the white line.
Step 17
Bring the t wo assembled sofa units together and secure by the brackets, as shown below.
Step 18
You made it to the last step! Place the Backrest Pillows (F ), Corner Pillow 1 (H), Corner PIllow 2 (I), Corner Seat Cushion (G), and Seat Cushions (E) on to your sofa.
Step 7
Continue here for sofa Config. 2!
Join another Seat Frame (C) to the sofa unit by the brackets, as shown below.
Step 8
Ensure that the t wo Frames are aligned and sit ting flush. Then secure the t wo together by placing a flat washer on one Ø5/16” x 60mm Thumb Screw (4) and another Flat Washer a Ø5/16” Wing Nut (6) and twist to secure, as shown below.
You know the drill by now! Bring your friend back for an extra hand for this step! At tach the Seat Frame Suppor t Leg ( J) to the bot tom of the Frame using four M4 x 20 mm Screws (7).
Tip: The suppor t leg should be aligned with the white line.
Step 10
No, this isn’t Deja Vu! At tach another Suppor t Leg ( J) to the bot tom of the seat frame, this time using t wo M4 x 20 mm Screws (7 ).
Step 11
Remove the pre-installed metal bracket from the seat frame.
Tip: The suppor t leg should be aligned with the white line
R emove
Step 12
Tighten two Metal Brackets (1) on the side of the seat frame using four Ø1/4” x 30mm Bolts (2), as shown below.
Step 13
Join the Leg + Arm SubAssembly (Right) (B) to the Seat Frame (C) by the brackets.
x2 x4
Step 14
Align Par t (C) and (B). Then open the zipper on Par t (B). Place a flat washer on one Ø5/16” x 60mm Thumb Screw (4) ) and another Flat Washer on a Ø5/16” Wing Nut (6) and twist to secure (C) ) and Part together
Close the zipper when complete.
Step 15
Join the Corner Seat Frame (D) to Par t (B) and (C) by the brackets.
Step 16
Ensure that the two seat frames are aligned and sitting flush. Then secure the two together by placing a flat washer on one Ø5/16” x 60mm Thumb Screw (4) and another Flat Washer on a Ø5/16” Wing Nut (6) and twist to secure, as shown below.
Step 17
At tach the Seat Frame Suppor t Leg ( J) to the bot tom of the seat frame using four M4 x 20 mm Screws (7).
Place a 50mm Plastic Washer (9) on to a Corner Support Leg (K) and twist to secure, as shown below
Tip: The suppor t leg should be aligned with the white line.
Step 18
Bring the t wo assembled sofa units together and secure by the brackets, as shown below.
Step 19
You made it to the last step! Place the Backrest Pillows (F ), Corner Pillow 1 (H), Corner PIllow 2 (I), Corner Seat Cushion (G), and Seat Cushions (E) on to your sofa
Get your popcorn ready, movie nights just got a whole lot cozier!
No hear tbur n, when we ha ndle t he retur n
Give us a call 1- 866 - 619 -1004 or shoot us a message at help@nathanjames.com we will issue you a free replacement with zero hassle.
Our way Their way
Give us a call
Replacement
You
Re-package item
Schedule pick up
Track package
Replacement
You
We really don’t want you to go through the hassle of re-packaging your item and sending it back , because let ’s be honest…nobody has time for that.
Sa fet y first, f un later
We want your product to last as long as possible, so we recommend that you tighten the screws 2 weeks af ter assembly and for added safet y check the tightness of all screws ever y 2 months.
For proper care and treatment, please check our website at NathanJames.com/products
Safe use of this produc t star ts with you.
Use this product responsibly with the primar y concern for your safet y. Follow assembly instructions carefully and inspect product upon receipt and each use.
Nathan James and its parent companies cannot be held legally responsible for any injuries or death resulted from failure to follow instructions or improper use of this product
Do not modif y the struc ture of this produc t in any way.
Our products have been tested to meet specific safet y measures as they were originally intended to be sold. Any modifications will present the risk of creating significant safet y issues which NJ will not be responsible for.
DO NOT use for commercial purposes
DO NOT frolic on sofa
Proper use
DO NOT leave spilled liquid on seat
DO NOT use sofa if damaged
DO NOT make temporar y repairs
DO NOT use outdoors
We are only in business if you’re happy
For star ters, thanks for being you.
Toll-free at 1-866-619-1004 Help@nathanjames.com NathanJames.com/help
We do our best to ensure your furniture arrives without any problems, but occasionally mistakes happen as humans we are imper fect beings. In the event that a par t is damaged or missing, we will be more than happy to provide you with replacement par t(s) for free
Warrant y
This product comes with a lifetime warrant y from the date of purchase. Please use your phone to scan the QR code to register your product or visit ht tps://goo.gl/i9dk3q
Did we do alright? Please spread the love!
If you are happy with your product, tell your friends and family about us or even bet ter leave us a review online. Spreading the word gives us the oppor tunit y to make more people happy and keep our prices low for your next purchase.
