The goods

Important

1. Do not tighten bolts / screws completely until all bolts / screws are lined up and inserted into holes.

2. Do not over tighten screws and bolts to avoid stripping.

3. Please use hand tools to assemble this product. Do not use power tools.

Step 1

Let’s begin! Attach the Bottom Frame (E) to the Right Frame Leg (C) using the M6 * 15mm Bolt (1) and the Allen Key (7). Pay close attention to the where it says “top”, make sure this is facing upwards when the chair is on its legs.

Tighten screws to 90%.

Step 2

Set the chair upright on its legs. Attach the Left Frame Leg (D) to Bottom Frame (E) using the same method from Step 1.

Tighten screws to 90%.

Step 3

Now attach the Stretcher (F) using M6 * 40mm Bolt (2) and the Allen Key (7). Make sure the text “Front | Up” is facing towards you when you are standing in front of the chair.

Tighten screws to 75%.

Front Up

Step 4

Time to attach the Seat (B). Grab the Flat Washer (5), Spring Washer (6), and M6 * 30mm Bolt (3), use these to secure the Seat (B) to the rest of the chair using the Allen Key (7).

Tighten screws to 75%.

Step 5

We’re getting closer! Attach the Back (A) to the rest of the chair using the M6 * 40mm Bolt (2) and the Allen key (7).

Tighten screws to 75%.

Secure the Seat Back (A) to the Seat Cushion (B) by closing the gap, lining up the holes and then fastening the hardware into place. You will use a Flat Washer (5), Spring Washer (6), and M6 * 25mm Bolt (4).

Once ALL bolts are aligned, go ahead and Tighten them all to 100% (including those from Step 1).

Step 7

Finishing touches! Now secure all velcro components underneath the chair.

Step 8

Lastly, tighten on the floor protecters. You did it, have a seat, and enjoy the result of your hard work!
