Slingback
Let’s build the 24-0214-VN Scan me! Inspiration Digital Instructions Free Lifetime Warranty 15 15 M I NUTE ASSE MBLY SKU 21501
Linus
Counter Stool
Ok, let’s get rolling
This should be easy, just follow our instructions and you will be back to Netflix in no time.
What’s included
• Some of your favourite bubbly or your preferred relaxant
• Use the packaging carton as a working surface to prevent product damage during assembly
•
Toll-free
2
What you need
Phillips Screwdriver Description Qty A Chair Back 1 B Seat Cushion 1 C Left Front Leg 1 D Right Front Leg 1 E Front Footrest 1 F Side Stretcher 2 1 ¼ x 1 ½ inch Hex Button Head Bolt 2 2 ¼ x 2 3⁄8 inch Hex Button Head Bolt 4 3 ¼ x 3 ⅛ inch Hex Button Head Bolt 4 4 ¼ inch Lock Washer 10 5 ¼ inch Flat Washer 10 6 M4 x 38 mm Screw 6 7 Allen Key 1 8 Plastic Nail-In Footpad (Extra) 4
time for assembly 300 lbs Weight Limitation
15:00 Estimated
at 1-866-619-1004
Scan me! Inspiration Digital Instructions Free Lifetime Warranty
Help@nathanjames.com Nathanjames.com/help
The goods
IMPORTANT
1. Do not tighten bolts / screws completely until all bolts / screws are lined up and inserted into holes.
2. Do not over tighten screws and bolts to avoid stripping.
3. Please use hand tools to assemble this product. Do not use power tools.
3
A B C D F F E 1 2 3 4 5 6 7 8
Step 1
Let’s get this thing fired up! Please take a moment to match the sticker on the bottom of the chair back with the sticker on the corner block.
Do NOT overt ighten hardware.
4
A B 7 1 4 5
Step 2
Let’s secure those legs in place! Consider this your workout of the day.
Do NOT overt ighten hardware.
5
B 7 3 4 5 A
Step 3
Match the sticker on the bottom of the front chair legs with the sticker on the corner blocks before tightening hardware.
IMPORTANT NOTE:
Front Legs are not interchangeable. (see following page)
6
B D C 7 2 4 5 Do NOT overt ighten hardware.
Step 4
Last, but not least, screw on the Front Footrest (E) and Side Stretchers (F). We told you this was going to be easy!
IMPORTANT NOTE:
Front Legs are not interchangeable. (see following page)
If you are having trouble getting the screws to catch, it is recommended to carefully use an electric screwdriver or drill with necessary bit for this step.
Do not over-tighten; holes may become stripped.
Do NOT overt ighten hardware.
7
F F E D C 6 6
Issues with stretchers aligning at an angle?
If the stretchers are set at an angle when you are aligning them with their respective holes on the front & back legs, you have likely assembled the front legs incorrectly.
Re-check to confirm that the proper legs are installed in their intended position on the proper side of the stool. The front legs are not interchangeable; therefore they may need to be rotated and swapped to the opposite side.
8
-OR-
Step 5
Carefully flip the stool over on a flat surf ace and make sure the legs are touching the ground evenly before tightening ever yt hing to 100% . You did it! Go tuck your bar stool into your kitchen island and celebrate with some pizza!
We want your bar stool to last as long as possible, so we recommend that you tighten the screws 2 weeks after assembly and for added safet y check the tightness of all screws every 2 months.
9
No heartburn, when we handle the return
Give us a call 1-866-619-1004 or shoot us a message at help@nathanjames.com we will issue you a free replacement with zero hassle.
Our way
Their way
Give us a call
Replacement
You
Re-package item
Schedule pick up
Track package
Replacement
You
We really don’t want you to go through the hassle of re-packaging your item and sending it back, because let’s be honest…nobody has time for that.
10
Safety first, fun later
We want your Slingback Counter Stool to last as long as possible, so we recommend that you tighten the screws 2 weeks after assembly and for added safety check the tightness of all screws every 2 months.
For proper care and treatment of wood and fabric please check our website at NathanJames.com/products
Safe use of this product starts with you.
Use this counter stool responsibly with the primary concern for your safety. Follow assembly instructions carefully and inspect product upon receipt and each use.
Nathan James and its parent companies cannot be held legally responsible for any injuries or death resulted from failure to follow instructions or improper use of this product.
Do not modify the structure of this product in any way.
Our products have been tested to meet specific safety measures as they were originally intended to be sold. Any modifications will present the risk of creating significant safety issues which NJ will not be responsible for.
DO NOT use for commercial purposes
DO NOT place on uneven floor or surface
DO NOT use as a step-stool or stand on stool
Proper use
DO NOT put hot serving liquid directly on stool
DO NOT leave spilled liquid on stool
DO NOT use if stool is damaged or broken
DO NOT make temporary repairs
DO NOT use outdoors
11
We are only in business if you’re happy
For starters, thanks for being you.
Toll-free at 1-866-619-1004
Help@nathanjames.com
NathanJames.com/help
We do our best to ensure your furniture arrives without any problems, but occasionally mistakes happen—as humans we are imperfect beings. In the event that a part is damaged or missing, we will be more than happy to provide you with replacement part(s) for free.
Warranty
This product comes with a lifetime warranty from the date of purchase. Please use your phone to scan the QR code to register your product or visit https://goo.gl/i9dk3q
