Construction Drawings 06

Construction Drawings:

Types of Anchorage & Depths (mm)

Key Junctions:

1. 365mm THK PCC INSULATED SANDWICH PANEL WALL, AS SPECIFIED BY SPEANCOM MANUFACTURES & PQE 1.1. 1No. 12.5 mm THK INTERNAL PLASTER BOARD FINISH. 1.2. SUITABLE EXTERNAL RENDER APPLIED BY CLIENT & WEATHERING SEALANTS.

2. 20mm THK C16 TIMBER PRETREATED SKIRTING BOARD & FLOOR BUILDUP (SEE DETAIL)

3. 1200x220mm THK PCC SPEANCOM (EX22) HOLLOW CORE FLOOR SLABS, MADE TO MANUFACTURES SPECIFICATION.

4. INSITU CONCRETE/SCREED MIX

5. FLEXIBLE INSULATION MATERIAL

6. 250 x 160mm THK INSITU CONCRETE INFILL, SPECIFIED BY PQE, BACKFILLING INTO DECKING PIECE.

7. REINFORCEMENT BARS (PQE SPECIFIED) TO CONNECT WITH SANDWHICH PANELS & INSERTED INTO DECKING PIECES.

8. PLASTIC END-CAP INSERTED INTO HOLLOWED SECTIONS OF DECK.

9. 12.5mm GYPSUM PLASTER BOARD, ATTACHED TO HOLLOWCORE DECKING WITH SUITABLE FIXINGS.

10. ACOUSTIC SEALANT
