APPLICATIONS
• CARAVAN, VEHICLE, TRAILER & MOTORHOME PORTABLE WEIGHING; E.g. TW (Tow Ball Weight), ATM, GTM, GVM, GCVM & MORE.
• LOAD DISTRIBUTION AND BALANCING
• CHECK WEIGHING FOR LAW COMPLIANCE
• DETERMINATION OF WHEEL AND AXLE LOAD DISTRIBUTION FOR VEHICLE DESIGN AND MODIFICATIONS
• SUSPENSION & CENTRE OF GRAVITY TUNING FOR MOTORSPORT
• SPECIAL WEIGHING CONFIGURATIONS
FEATURES
• LIGHT-WEIGHT ALUMINIUM & STAINLESS STEEL CONSTRUCTION FOR STRENGTH & CORROSION RESISTANCE.
• HIGH CAPACITY: MAXIMUM LOAD OF 1500kg PER SCALE. CAN WEIGH SINGLE AXLE VEHICLES UP TO 3000kg CAPACITY & TWIN AXLE VEHICLES UP TO 6000kg CAPACITY (MINIMUM LOAD: 50kg).
• DISPLAYS WEIGHT IN 1kg GRADUATIONS
• STATIC OPERATION PRINCIPLE GIVES GREATER ACCURACY OVER DYNAMIC TYPE SCALES
• 19mm ULTRA-LOW PROFILE WEIGHING PLATFORM WITH RAMPS
• MULTIPLE LOAD CELLS FOR INCREASED PRECISION
• TARE FUNCTION
• LARGE 75x30mm DIGITAL READOUT WITH AUTOMATIC BACKLIGHT
• LCD AUTO POWER-OFF AFTER 3 MINUTES
• ACCURACY: ±0.5% F.S.
• BATTERIES: 2 x 3V CR2032 LITHIUM BUTTON CELL (INCLUDED)
• BATTERY LIFE: UP TO 12 HOURS (CONTINUOUS USE)
• LOW BATTERY DETECTION
• WEIGHING PLATFORM SIZE: 19mm(H) x 305mm(W) x 305mm(L)
• OVERALL SIZE: 30mm(H) x 347mm(W) x 432mm(L)
• WEIGHT: 6.2kg
• LABORATORY TESTED IN ACCORDANCE WITH AUSTRALIAN & INTERNATIONAL STANDARDS ISO/IEC 17025:2005
INCLUDES BONUS
2-WAY LEVEL TO ENSURE YOUR WEIGHING SITE & SCALE IS SET UP CORRECTLY
