RECALIBRATING PARKS High-rise Living, Seoul 2030 / Yeouido, Seoul, S. Korea Spring 2019
02
THE SPROUT Vegan Culinary InsƟtute / Goose Island, Chicago, IL Spring 2018
03
TOWN & GOWN Urban Design Studio / Tallahassee, FL Fall 2018
04
FIELD & FRAME Chicago Downtown Library Annex / Chicago, IL Fall 2017
05
CAVE & TREE Bo-Kaap MeditaƟon Center / Cape Town, South Africa Fall 2017
06
SPIRAL CORE CollaboraƟve Workspace/ Jacksonville, FL Spring 2017
07
RENDEZVOUS
08
OTHER WORKS
Urban Architecture/ Cambridge, MA Fall 2016
Three-in-one Furniture Deployable Roof Structure
RECALIBRATING PUBLIC PARKS High-rise Living, Seoul 2030, Yeouido, Seoul, South Korea Thesis Studio / Spring 2019 Revit, Lumion, Photoshop, Illustrator This thesis proposes a high-rise residenƟal complex for 2030. A scenario planning technique is used for formulaƟng visionary concepts of a housing development within the specific context of Seoul, South Korea. The proposed design conforms to three objecƟves: 1.Ppropose a soluƟon to integrate nature with buildings while making profits, 2. Create an ecological living system that respects regional aƩributes, 3.Include programmaƟc suggesƟons responding to the future.
1
INTEGRATE NATURE IN COMPROMISE WITH PRIVATE AND PUBLIC INTEREST
HEXAGONAL GRID
MORPHOLOGY >>TO SIMULTANEOUSLY ACHIEVE MORE FLOOR AREAS AND MORE GREEN SPACES, THE HEXAGONAL ARRANGEMENT WAS APͳ PLLIED.
D = 240’
1 HEXAGONAL CELL = 1 COMMUNITY + 1 COURTYARD >>TO EQUALLY CONNECT THESE HEXAGOͳ NAL CELLS TO URBAN NODE, VORONOI DIAGRAM WAS USED.
CORE
SITE PLAN ΈFUTUREΉ
VORONOI DIAGRAM
ACCESS TO PARK
N 0
200'
2
CREATE AN ECOLOGICAL LIVING SYSTEM RESPECTING REGIONAL ATTRIBUTES
PRIVACY & A SENSE OF TOGETHERNESS
URBAN GRAIN Έ500’ RADIUSΉ
>>EACH COMMUNITY UNIT WAS CONNECTͳ ED BY ORGANICAL FORMS OF STREETS AND ALLEYS. >>THIS ALLEY, WHICH IS CALLED “GOLMOK” IN KOREAN, IS NOT JUST A WAY OF MOBILITY BUT A “CROSSͳUSE” SPACE. STREETS LEAD TO ALLEYS, AND ALLEYS LEAD TO INNER COURTS OF HOUSES. YEOUIDO ͳ EXISTING
OLD TOWN
Vehicle Pedestrian
YEOUIDO ͳ PROPOSED
"GOLMOK" CREATES SMALLER BLOCKS WITH A SENSE OF COMMUNITY
3
SUGGEST PROGRAMS FORMULATED BY FUTURE SCENARIO PLANNING
PROGRAM ZONES >>5 CHANGE FACTORS WERE EXTRACTED BY OBSERVATION OF THE CURRENT TRENDS. PROGRAMS WERE SUGGESTED TO RESPOND THEM.
GENERAL AMENITIES LIBRARY ͳ CHILDCARE ͳ PLAYGROUND ͳ GYM ͳ RETAILS
+ FUTURE PROGRAMS ENERGY HARVESTING PAVEMENT
ADAPTABLE SPACE FOR AV
SHARED WORKSPACE
LIVEͳWORK UNITS
URBAN FARMING
ROBOT TECHNOLOGY
ResidenƟal Commercial Business & Public
Retail Retail
Live-Work Units Sharable workspace
Gym
Childcare
GROUND FLOOR PLAN N 0
100'
BASEMENT FLOOR PLAN N 0
100'
OFFICE
ROAD
SECTION ResidenƟal Commercial Mixed use amenity Basement parking
ROAD
WATERFRONT PARK
THE SPROUT Vegan Culinary Institute, Goose Island, Chicago Design 6.2 Whole Building Studio / Spring 2018 Revit, Lumion, Photoshop, Illustrator The Sprout was a year-round project that developed from the interest in food and urban agriculture to programming, and realized a concrete design at the Whole Building Studio in collaboration of a lecture, New Technology of Enclosed Buildings. This new culinary institute is a place to teach culinary arts and invent new food experiences. The building is located in the old paint factory in the Goose Island neighborhood, reflecting the ongoing transformation from traditional industrial spaces to modern creative spaces.
LOCATION & CONTEXT
PARTI DEVELOPMENT
1. New bridge connection on Blackhawk St. 2. Extension of waterfront landscape 3. Potential growth and development in the area: Goose Island 2.0, Cabrini Green Redevelopment 4. Industrial characters
01 Gesture of Extension & Link
CITY
E UR
02 Public Spaces - “Stitch” Spaces Whole Foods Market Retail & Parking
Warehouse & Office
T NA
03 Movement Through Building 2
Subway(Red Line)
1
SITE Cabrini Green Redevelopment
4 Goose Island Master Plan
3
04 Continuity of Landscape
Comedy Theater
SITE PLAN N
Whole Foods Market ongoing construction (Retail + Parking)
Prevailing wind t
Summer solstice B W.
wk
ha
k lac
ee Str
Winter solstice N. gs
Kin ry
bu
Private School et
e Str
Office
Retail Parking
t
an
m ast
ee Str
E W.
Warehouse + Office
Digital Manufacturing Business
PROGRAM + CODE ANALYSIS Zoning district: C3-5 1. Setbacks: not required 2. Ground-Floor Commercial: Floor-to-floor height = min. 13 feet. Ground floor area = min. 20% of the lot area 3. Maximum Floor Area Ratio(FAR): 5.0 4. Maximum Building Height: 75 feet 5. Parking: not required
∙ Occupancy Classification Group U (Urban farm) 5,600 ft2 ÷ 300 GSF/person = 19 occupants
Group A-2 (Restaurant) 7,000 ft2 ÷ 15 NSF/person = 467 occupants
Group B (Vocational education) 29,400 ft2 ÷ 50 NSF/person = 588 occupants
∙ Type of Construction: Type IV(Heavy Timber) multi stories equipped with automatic sprinkler system ∙ Total Occupancy Load: 1,710 occupants ∙ Number of Exits per Story: Level Number of Exit 4 3 2 1
2 2 3 3
Group B (Offices) 10,600 ft2 ÷ 100 GSF/person = 106 occupants
Group B (Classrooms) 10,600 ft2 ÷ 20 NSF/person = 530 occupants
GROUND FLOOR PLAN
Whole Foods Market
W. Blackhawk Street
Chicago River
Drop-off
UP
N. Kingsbury Street
UP
UP
UP
Shuttle stop
UP
UP
2’
UP
W. Eastman Street
Warehouse & Office
STRUCTURE SYSTEM: Heavy Timber Construction
Concrete shear wall Columns: 10.5” x 13.75’ southern pine glulam post
As its core, the Vegan Culinary Institute has heavy timber structure, consisting of an exposed glulam frame (columns, beams, braces), cross-laminated timber (CLT) and concrete composite floors, and concrete shaft walls. The building’s elevated part are supported by wood-steel composite system because of the long span and the facade farming cantilevered from the south facade.
Steel beam: W 30 x 148 Primary timber beam: 8.5”x30.25” southern pine glulam beam Secondary timber beam: 6.75”x24.75”southern pine glulam beam Diagonal bracing: 6.75”x18”southern pine glulam beam
Pin
(3) Ø0.75” X 4” grade 5 hex bolt w/ Ø1.43 washer 0.75”-thick steel knife plate
(3) Ø0.75” X 4” grade 5 hex bolt w/ Ø1.43 washer (3) 0.75”-thick steel plates embedded (2) 0.75”-thick steel plates
4” HSS tube + 0.75”-thick steel plates welded (4) Ø0.75” x 12“ Anchor bolts Non-shrink grout
WALL SECTION DETAIL 1
Metal Roof + Plywood roof sheathing fastened to purlins + Custom glulam half arch
2
IPE wood decking + 1-1/2” sleepers + Waterproof membrane + 8” rigid insulation (R40) + 4” lightweight concrete topping w/ steel mesh + Permeable polyurethane lining + 7 ply CLT floor slab
3
Exhaust vent with operable glass louvers + Painted aluminum coping
4
Interior glulam - exterior aluminum curtain system + PVC pipe hydroponic system + A36 2” x 4” steel tube + Exterior glazing
5
Armstrong 15/16” Suspension system + WoodWorks Grille
6
Tile carpeting + 4” lightweight concrete topping w/ steel mesh + Permeable polyurethane lining + 7-ply(9-5/8”) CLT floor slab
7
CLT floor panel joint (6” overlap + shear fasteners) + W30x148 steel girder
8
6.75” x 18” southern pine glulam beam
9
8” x 12” Steel angle
1
2
3
5
4
6
10 Plates @ 8’ o.c. Ø0.75” X 4” grade 5 hex bolt + Welded bar grating 11 A36 hot rolled steel tee bar 12 8.5” x 30.25” southern pine glulam beam 13 10.5” x 13.75” southern pine glulam post 9
6
10
METAL ROOF
CEILING SYSTEM -OFFICE
PAC CLAD TITE LOC COLOR: ZINC
AMSTRONG WOODWORKS GRILLE COLOR: MAPLE
11 12
13 7
CURTAIN WALL
HYDROPONIC FARM
SOLAR INNOVATIONS WOOD-ALUMINUM CURTAIN WALL SYSTEM
PVC PIPE HYDROPONIC SYSTEM
8
TOWN & GOWN Suburban Retrofitting Urbanism / Tallahassee, FL Urban Design Studio / Fall 2018 Rhinoceros, AutoCAD, Photoshop, Illustrator This project proposes a networked and reinvented suburban prototypes that respond to a specific urban location, the South Monroe Corridor, Tallahassee, FL. In the first phase, collective analysis of the current state of the city and the focus area were performed extensively. Then, through the SWOT analysis and DNA sampling, the meaningful attributes that influences the future of the city were excavated and utilized for each team’s proposal. PROPOSED SITE PLAN -
PUBLIC ART STREET
MULTI-USE TRAIL
E Jennings St.
S Monroe St.
W Jennings St.
A
B
B’
S Adams St.
A’
ART + HEALTH PLAZA
ART + HEALTH PLAZA
E Palmer Ave.
W Palmer Ave.
C
D’
C’
S Adams St.
STEPPING FOREST
S Monroe St.
D
(New) Collector St.
BIOSWALE
0’ 100’ 300’
PROPOSED SITE PLAN -
600’
1000’
NEW STREETS TYPICAL SECTION
ADAMS ST. TYPICAL SECTION
SOUTH MONROE TYPICAL SECTION
PROPOSED AXONOMETRIC PROPOSED AXONOMETRIC 0’ 10’ 20’
NEW STREETS TYPICAL SECTION
SOUTH MONROE TYPICAL SECTION
40’
100’
200’
PALMETTO ST. TYPICAL SECTION
ADAMS ST. TYPICAL SECTION
ADAMS ST. SECTION
TYPICAL STREET DESIGN (TOP) ADAMS STREET (BOTTOM LEFT) PALMETTO STREET (BOTTOM RIGHT) NEW STREET
PALMETTO ST. TYPICAL SECTION
NEW STREETS TYPICAL SECTION
FIELD & FRAME Chicago Downtown Library Annex Design 6.1 Critical Thinking Studio / Fall 2017 AutoCAD, SketchUp, Lumion, Photoshop Field & Frame is a project that creates a new annex for the main downtown library in Chicago. Based on rising questions related to the “evolution of libraries,” the building suggests a new type of library in the 21st century, establishing the 3D spatial field & frame and responding to the urban context.
DESIGN ELEMENTS 01 Permeable layers on the grids
04 Arcade + Park connecting to the city
02 Grids projected onto the sky
03 Programs
LEVEL 1 (+0.0 ft)
Exhibition Hall Mechanical Room Receiving & Shipping Retail General Info & Borrowers Service 6 Cafe 1 2 3 4 5
LEVEL 2 (+30.0 ft) 1 2 3 4 5
Auditorium Mechanical Room Children’s Collection Readers Service Reading Area
PARTI: Quantum Field Theory The design process started with a question, how can architecture reflect the new era of a digitized, dematerialized world? In theoretical physics, quantum field theory is “the theoretical framework for constructing quantum mechanical models of subatomic particles.” This theory is applied when some phenomena are not able to described by classical physics, for example, when an object moves very fast like lightning or when particles are very small, in micro scale. If dematerialized materials are defined as very small particles invisible in quantum field theory, can’t we borrow the methodologies of quantum field theory to create spaces for the 21st century library?
Section
To visualize this theoretical idea, I focused on a very famous experiment in quantum field theory, “the double-slit experiment.” It showed that light has wave-particle duality by projecting light on the slit screen because it made an unexpected pattern when light was regarded only as a particle. What if slit walls are built on the site of the new library as the slit screen was in the experiment? What would happen inside and outside this permeable layer?
“ A modern library is not only a place for the storage and lending of different materials, it is also a place to stay, a place to be inspired and surprised.” - Architect Morten Schmidt
RENDEZVOUS Urban Architecture / Cambridge, MA Design 4.1 / Fall 2016 Revit, Lumion, Photoshop This project began with the selecttion of an urban district in any city in the world. The city of Cambridge, MA, is interesting and attractive, because of the duality that the city has protean vitality of a university town and classical repose of an old city. This design proposal is to suggest three urban roles corresponding to the urban fabric and offer centrality and conviviality to the Commons.
GROUND FLOOR PLAN
SECOND FLOOR PLAN
TYPICAL FLOOR PLAN
CAVE & TREE Bo-Kapp Meditation Center / Cape Town, South Africa Design 6.1 Critical Thinking Studio / Fall 2017 Revit, SketchUp, Vray, Photoshop
This project is to analyze the dichotomy of “cave” and “tree” architecture and represent the oppositional features: solid vs. void, stereotomic vs. tectonic, and light vs. shadow. The meditation center offers a spatial sequence where visitors experience various ways of meditation: yoga studio, meditation walkway, and pavilion.
LOCATION & CONTEXT
01 Landform
The site location is Bo-Kaap, Cape Town. It is a Muslim community, well known for the multicultural character, and for the unique architecture: colored buildings and cobblestone alleys.
02 Respond to Urban grids
03 Refraction of Movement
04 Meditation Loop
SECTION
LEVEL +1 LEVEL -1
SPIRAL CORE Collaborative Workspace, Jacksonville, FL Design 4.2 / Spring 2017 Revit, Rhino, Lumion, Photoshop This project is to propose a new type of office building optimizing collaborative workspace like Google and Apple. The site is located at the north bank of the St. Johns River in Jacksonville, FL. This design is a response to the new business trend of collaboration. While the adjacent buildings have a conventional, box-type form, this building has a spiral core within a rectangular enclosure as a driver of change.
GROUND FLOOR PLAN
7 - 8F
5F
3 - 4F
THREE-in-One FURNITURE Architecture Making / Fall 2017 Rhino, Photoshop The main purpose of the project is to learn how to articulate and fabricate structural connections in architecture by dealing with real-scale furniture. As Eliel Sarrinen said, “ Always design a thing by considering it in its next larger context – a chair in a room, a room in a house, a house in an environment, an environment in a city plan,” furniture is the next smaller thing in architecture.
MODULAR DESIGN All components of the grid frame are indicated in green and red below. These sixteen identical wooden members make the grid frames.
CONNECTION TYPE I. Mortise-Tenon Joint
CONNECTION TYPE II. Lap Joint
For the horizontal frame, the dowel pin on the side of one member is connected to the hole on the bottom of another member.
The table leg is connected to the horizontal frame with a lap joint.
DEPLOYABLE ROOF STRUCTURE Digital Fabrication / Spring 2017 Rhino, Photoshop This project is to design a digitally fabricated roof structure based on modular design. It is required to cover the 10 by 3 ft. space between two pin-up boards and create a form of connecting device without using glue.
MODEL STUDY Model studies were performed to prototype the module satisfying two design concepts: • •
Make a self-locking system that has no need to have connecting hardware and Apply a weaving technique to improve the stability of the entire structure.
FINAL MODEL For the final model, the 1/8” plywood panels were cut by laser cutter, coated with stain and assembled after they dried. See the pictures of the model-making process below.
SKETCHES
