Executive Summary

Located in Kanyuambora, Embu, near the picturesque Kanyuambora Hill in Kenya, the proposed nursing school and hospital aims to establish a state-of-the-art educational and clinical facility on a approximately 5-acre site. This world-class institution will integrate advanced academic spaces with a fully functional hospital, providing approximately 500 nursing students with hands-on training in a serene and supportive environment. The design emphasizes functionality, sustainability, and aesthetic distinction, featuring modern classrooms, simulation labs, a comprehensive library, patient care areas, and extensive green spaces. By blending education and healthcare, the project seeks to create a seamless learning-to-practice transition, fostering excellence in nursing education and patient care.

Grannex Group Limited

Page 4

Project Goals and Vision World-Class Standard: Establish a premier facility equipped with the latest educational and clinical tools, attracting top faculty and dedicated students to create an environment of academic excellence.

Distinctive Design and Spatial Planning: Utilize the natural beauty of Kenyuambora Hill to inspire a visually unique and functionally efficient campus, enhancing student engagement and hospital workflow.

Educational-Healthcare Integration: Seamlessly combine academic and clinical spaces to provide students with realworld clinical experience, bridging the gap between theoretical knowledge and practical application.

Serene and Supportive Environment: Create a calm atmosphere with landscaped green areas, quiet study lounges, and open spaces to promote student wellness and patient comfort.

Sustainable and Future-Ready: Incorporate eco-friendly materials and energy-efficient systems, ensuring the facility is environmentally responsible and adaptable to future technological advancements.

Page 5

Grannex Group Limited

04 - 11 - 2024

Design concept.

1. Biophilic Design Principles Natural Light and Views: Natural light and views of nature reduce stress and enhance cognitive function. A study by the University of Oregon found that workers with views of nature experienced less absenteeism and greater satisfaction. Applying this to an academic setting, classrooms with large windows overlooking landscaped areas or Kenyuambora Hill can improve students’ mood and alertness.

Plants and Green Spaces: Incorporating indoor plants and outdoor gardens supports well-being. A study published in the Journal of Environmental Psychology found that plants in workspaces improved productivity and reduced stress.

For the nursing school, green study lounges and interior greenery can foster a calming, focused atmosphere for students.

Grannex Group Limited

Page 6

2. Restorative Environment Theory Nature Sounds and Water Features: A study by the Brighton and Sussex Medical School discovered that natural sounds, like flowing water or birdsong, activate parts of the brain associated with mindwandering and relaxation. Incorporating water features or audio of natural sounds in communal areas can create a restorative environment for students and patients alike.

Psychological Restoration: According to Kaplan and Kaplan’s Attention Restoration Theory (ART), exposure to nature restores mental focus by providing “soft fascination” (gentle, undemanding attention) that allows the brain to recover from fatigue. Outdoor courtyards, quiet green areas, and rooftop study decks can offer students opportunities to refresh between classes and clinical training.

3. Stress Reduction through Natural Elements Wood and Natural Materials: Studies show that natural materials, such as wood, reduce physiological stress responses. A 2010 study by the International Journal of Environmental Research and Public Health found that wooden interiors lower blood pressure and heart rate. Using wood finishes in study lounges, classrooms, and patient areas can help in creating a warm, inviting environment.

Visual Complexity and Patterns: Environments with moderate visual complexity (such as natural textures or patterns mimicking nature) stimulate curiosity and comfort without overwhelming the senses. Incorporating textures or patterns inspired by local flora, or elements from Kenyuambora Hill, can create an inviting and mentally stimulating space.

Page 7

Grannex Group Limited

04 - 11 - 2024

4. Healing Gardens and Outdoor Therapy Spaces Therapeutic Landscapes: Healing gardens are a valuable tool in healthcare design. Roger Ulrich’s study on the impact of nature views on hospital patients showed that those with views of trees had shorter postoperative stays and required less pain medication. A garden within the hospital section could serve as a therapy space for both students and patients, promoting faster healing and reduced stress.

Outdoor Classrooms and Study Spaces Outdoor classrooms support experiential learning and reduce anxiety. Research published in Frontiers in Psychology indicates that outdoor learning environments improve concentration, creativity, and reduce cortisol levels. By establishing outdoor study areas or rooftop decks, the nursing school can support varied learning experiences while connecting students to the local landscape.

5. Color Psychology in Learning and Healing Spaces Calming Color Palette: The colors used in the interior play a significant role in emotional responses.

Blues and greens, often associated with calmness and clarity, have been shown to reduce anxiety and improve focus.

Applying soft greens and blues in study areas and patient rooms can create an atmosphere conducive to both learning and relaxation.

Accent Colors for Stimulation: Warmer tones, such as yellow or light orange, can promote energy and engagement when used sparingly. Accent walls or furniture in shared areas can help balance calmness with an atmosphere of active learning and collaboration.

Grannex Group Limited

Page 8

Detailed Spatial Program.

Room and Space List:

Space Category

A comprehensive inventory of all rooms and their square meter allocations, organized Academic by function (e.g., academic, healthcare, support facilities). Spaces

Functional Zoning and Adjacencies: An overview of the major functional zones (academic, healthcare, support), with details on spatial relationships to ensure efficient movement and interaction.

Specialized Spaces and Equipment: Academic Subtotal Descriptions of specialized rooms such as simulation labs, treatment areas, and any unique equipment or infrastructure requirements.

Clinical Training (Hospital)

Circulation and Accessibility: A layout plan for hallways, elevators, and accessible pathways, ensuring compliance with safety and accessibility standards.

Accommodation and Amenities: Dormitory and shared spaces, Clinical Subtotal organized to support 500 Administration students, with facilities such and Staff as laundry rooms, shared lounges, and recreational areas for a comfortable residential experience.

Rooms/Spaces

Quantity 4

Size per Room (sqm) 120

Total Area (sqm) 480

Lecture Halls Classrooms

6

50

300

Simulation Labs

4

80

320

Computer Labs

2

60

120

Skill Labs

4

70

280

Library and Resource Center Study Lounges/ Quiet Rooms Student Lockers/ Storage

1

300

300

5

30

150

1

60

60

Outpatient Clinics

6

25

2010 150

Patient Rooms

12

30

360

Emergency and Triage Area Diagnostic Labs

1

80

80

2

40

80

Pharmacy Lab

1

40

40

Nursing Stations

2

30

60

Operating Room 1 Simulation Rehabilitation/ 1 Physical Therapy Room Consultation Rooms 4

50

50

50

50

20

80 950

Faculty Offices

Page 9

10

15

150

Grannex Group Limited

04 - 11 - 2024

Outdoor and Recreational Spaces:

Administrative 5 Offices Conference/Meet- 2 ing Rooms Staff Lounge 1

Details of any outdoor areas, therapeutic gardens, and recreational spaces designed for relaxation and educational Administration use.

Storage and Utility Areas:

Subtotal Student Support Facilities

Safety and Sustainability Features: Safety provisions like emergency exits, security, and Student Support sustainable design elements Subtotal to support a safe and ecoTechnical/Utility friendly environment.

Spaces

Waste Management

Technical Subtotal Accommodation and Amenities

Accommodation Subtotal Optional Spaces

Grannex Group Limited

75

40

80

40

40 345

Allocation for storage of medical and educational materials, as well as designated utility areas.

Dedicated waste management zones will be placed near hospital and clinical areas for medical waste, and throughout the facility for general waste.

Medical waste will be securely stored in ventilated rooms, with proper disposal methods like incineration or sterilization. General waste areas will be located near dining, accommodation, and administrative zones for easy access. All waste management areas will adhere to safety and environmental regulations, ensuring proper hygiene and contamination control.

15

Counseling and Wellness Center

1

50

50

Cafeteria/Dining Area Recreation Rooms

1

200

200

2

40

80

-

400

400

1

150

150

Outdoor Green Spaces Student Union/Activity Hall

880 IT and Server Room

1

30

30

Maintenance and Storage Rooms

2

30

60

Restrooms and 6 Changing Rooms Laundry and Sterili- 1 zation Area

25

150

50

50 290

Dormitory Rooms

125

30

3750

Common Lounges

5

50

250

Shared Bathrooms

50

12

600

Laundry Facilities Dining Hall and Kitchen Indoor Recreational Room Outdoor Recreational Area

2 1

30 500

60 500

1

100

100

1

1000

1000 6260

Auditorium/Mul- 1 ti-Purpose Hall

Page 10

300

300

Optional Subtotal Parking and Outdoor Recreation

Research Labs

2

50

100

Rooftop/Outdoor Study Decks

-

200

200 600

Parking Lots

-

1000

1000

Sports Area

-

500

500

Outdoor Subtotal Total Area

1500 12835

Page 11

Grannex Group Limited

04 - 11 - 2024

Functional Zoning and Circulation Main Entry and Reception Areas Function: Acts as the welcome center and initial control point for visitors, students, and patients.

Placement: Directly accessible from the main entrance.

Adjacent Zones: Close to administration, visitor waiting, and security, with pathways to academic and hospital areas.

Grannex Group Limited

Administration and Faculty Offices Function: Houses administrative and faculty operations.

Placement: Near the main entrance for visibility and easy access.

Adjacent Zones: Close to reception for accessibility and near academic areas for facultystudent interaction.

Page 12

Academic Zone Function: Core educational spaces for classes, lectures, and study.

Placement: Centrally located for convenient access.

Adjacent Zones: Near administration for faculty access; classrooms close to simulation labs for practical learning.

Clinical Training and Simulation Labs Function: Provides hands-on learning spaces through simulations and labs.

Placement: Near academic areas, with some isolation to control noise.

Adjacent Zones: Adjacent to classrooms for seamless transition to practical sessions, with nearby equipment storage.

Hospital Zone Function: Clinical area serving patients and supporting student training.

Placement: Located in a quieter, private section for patient comfort.

Adjacent Zones: Patient rooms near diagnostic and treatment areas to streamline patient care.

Student Accommodation Function: Residential facilities housing 500 students with shared amenities.

Placement: In a designated residential area for privacy from hospital and academic zones.

Adjacent Zones: Proximate to dining and recreation areas for easy access, with laundry facilities nearby.

Student Support Areas Function: Provides relaxation and dining spaces for students.

Placement: Near academic and clinical training areas but separate from patient zones.

Adjacent Zones: Lounges close to classrooms and clinical areas, dining accessible to both students and staff.

Outdoor and Recreational Areas Function: Offers green spaces for relaxation and mental restoration.

Placement: Near student lounges, study areas, and residential zones.

Adjacent Zones: Close to accommodation and dining for ease of access during breaks.

Storage and Utility Zones Function: Stores supplies and equipment for academic, medical, and residential needs.

Placement: Strategically located; clinical storage near hospital areas, and general storage near classrooms and residential areas.

Adjacent Zones: Conveniently accessible to labs, hospital areas, and classrooms.

Safety and Security Features Function: Provides emergency exits, surveillance, and access control to ensure a secure environment.

Placement: Distributed across all zones, with clear pathways and signage.

Adjacent Zones: Accessible from all major zones, with marked emergency exits in strategic locations.

Parking and Transportation Access Function: Dedicated parking areas for students, staff, and patients.

Placement: Near the main entrance for convenient access while separated from educational and residential areas.

Adjacent Zones: Short walking distance to entry points and main reception.

Page 13

Grannex Group Limited

04 - 11 - 2024

WORKING TOGETHER

Grannex Group Limited

Page 14

Scope.

Work-Stage 3. Begins to look more closely at material options, developing the design at a greater level of detail and rigor..

Work-Stage 4. Rigorously develop the technical details of the design, taking into account construct-ability, longevity of materials, economy of means, and environmental performance. By working through each construction detail, we’re then able to refine cost as well.

The Work-stage 4 drawing set will be provided both in PDF and DWG formats

WORK-STAGE 1. Preparation and Brief Work Stage 1 1.1

1.2 1.3 1.4

Scope of Work Preparation and Brief Engage with stakeholders to gather requirements and constraints Review existing conditions of the building Develop project budget and procurement strategy Prepare a project brief, including scope, quality, sustainability, and timeline

Deliverables

PDF Report

PDF Report PDF Report Printed Copy

WORK-STAGE 2. Concept Design Work Stage 2 2.1 2.2 2.3

2.4 2.5

Scope of Work Concept Design Explore design options and create concept sketches Integrate space, aesthetic, and functionality requirements Engage consultants for initial structural, mechanical, and electrical input Develop a cost plan and assess risk factors Present the concept design to stakeholders for feedback and approval

Deliverables

PDF Report PDF Report PDF Report

PDF Report PDF BoQ

WORK-STAGE 3. Developed Design Work Stage 3 3.1

3.2 *Please Note: Planning approval submission and requirements to be discussed with the client.

Scope of Work

Deliverables

Developed Design Refine design based on Concept Drawing Set Design feedback, including materials, structure, and construction methods Coordinate and provide PDF Report feedback on MEP drawings and costing

Page 15

Grannex Group Limited

04 - 11 - 2024

3.3 3.4

Prepare drawings for County Planning submissions Issue Work Stage 3 Developed Design Report and client presentation

PDF Report PDF Report

WORK-STAGE 4. Technical Design Work Stage 4 4.1

4.2

4.3 4.4

Scope of Work Technical Design Finalize outstanding items from Developed Design and produce construction documents Visit suppliers/manufacturers as needed, obtain client approval on materials and finishes Produce technical drawings, schedules, and room data sheets Issue Technical Design Report and client presentation Client Actions: - Attend site visit and feedback meetings - Review and approve deliverables - Approve/sign off kitchen equipment and appliances, if applicable

Deliverables

Drawing Set

PDF Report

Schedules PDF Report

WORK-STAGE 5. Construction Administration Work Stage

Scope of Work

Deliverables

During the construction (WS5), there will be site supervision.

The following number of site visits and site meetings will be the minimum required. The consultancy fee for the site visits below is included in the WS5 fee above. The hourly rates listed below will only apply if additional visits beyond the minimum number of visits are required. Should more visits be required, prior permission/approval will be sought from the client a minimum of 14 days in advance.

5 5.1

Grannex Group Limited

Construction Administration and Handover Conduct bi-weekly site visits to inspect critical fitout stages

Page 16

Drawing Set

5.2

5.3

Review contractor’s submittals, PDF Report including methodology and shop drawings Allow time for planning, subSchedules consultant meetings, and design reviews

WORK-STAGE 6. Handover Work Stage 6.2 6.2.1

6.2.2

6.3 6.3.1

6.4 6.4.1

6.4.2 6.5 6.5.1

6.5.2 6.6 6.6.1 6.6.2 6.6.3

Scope of Work

Deliverables

Testing and Commissioning Drawing Set Test and commission building PDF Report systems (e.g., HVAC, electrical, plumbing) for full operation Provide training to client and building users on system operations and maintenance Handover Documents Compile and deliver all project documentation, including asbuilt drawings, operation and maintenance manuals, warranties, and guarantees Feedback and Evaluation Gather feedback on building performance and design effectiveness Conduct post-occupancy evaluation Defects Liability Period Address defects identified within six to twelve months posthandover.

Ensure all issues are rectified to the clients satisfaction Final Handover and Closeout: Conclude any outstanding contractual obligations Formally handover the building to the client for full operational use Complete the project Closeout and final account settlement with health and safety regulations

Page 17

Grannex Group Limited

04 - 11 - 2024

Schedule The Schedule is a provisional forecast for the duration of the design and assumes no unforeseen delays or changes in scope. In particular, activities out of our control are difficult to estimate.

Work Stage/ Activity

Month 01

Mobilization

x

WS1 Preparation of Brief

Month 02

Month 04

x x

x

x

x

WS2 Concept Design

x x

WS3 Developed Design

x

x

x

x

x

x

x x

Submit permits WS4 Technical Design WS5 Construction Administration

Grannex Group Limited

Month 03

Page 18

Month 05

x

x

x

x

Month 06

x

x

x

x

Month 07

Month 08

Month 09

x x

x

x

x x

x

x

x

x

x

x

x

x

x

As a provisional forecast, based on the programme above, we are able to commence work within a 1 week mobilization period, following signing of the contract and payment of the mobilization fee.

Please note that the construction programme can be drafted upon completion of the Designs, as the design and its phasing will inform the construction strategy.

We require a client sign-off at the end of each work stage in order to start the next work stage. In this schedule we allow for the sign off to be done within one working week *Please Note: The construction administration schedule is dependent of the contractor’s Program of Works Page 19

Grannex Group Limited

04 - 11 - 2024

The Numbers.

Fee For the successful completion of the project, the fees will be allocated as follows among the various teams: Architecture: 6% of the total project fee will be allocated to the architectural team, covering design development, space planning, detailing, and project coordination.

Civil and Structural Engineering: 2% will be allocated to the civil and structural engineering team for the design, planning, and supervision of the building’s structural integrity and site development.

Quantity Surveying (QS): 1.5% of the total fee will be allocated to the quantity surveying team, covering cost estimation, budgeting, and procurement management.

Mechanical, Electrical, and Plumbing (MEP): 2% will be allocated to the MEP team for the design and integration of mechanical, electrical, and plumbing systems within the building.

Please note; 1. Our fee for the Scope and Brief described in this proposal for Work-Stages 1-4 only is a lump sum and is exclusive of disbursements which will be charged for printing as per the schedule below.

Client pre-approval will be obtained for certain disbursements in accordance with the agreed terms.

2. We advise the client to set aside an expedition fee during planning Approval submission of appx. ksh 70,000 (if required*). To be paid directly to the expedition officer or through GGL. Grannex Group Limited

Page 20

Description

Area (sqm)

Rate (Ksh per sqm)

Building Area

12835

60,000.00 KES

By Services

Mobilization of 30% Work on total lump sum fee inclusive of VAT

Architecture & Spatial Planning

12,706,650.00 KES 5,929

Civil & Structural Engineering

4,620,600.00 KES

2,156

Quantity Surveying

3,465,450.00 KES

1,617

4,620,600.00 KES 2,156 MEP (Mechanical, Electrical, Plumbing) Engineering & Fire Service 25,413,300.00 KES 11,85 GRAND TOTAL (Kes) Payment Schedule

Amount (%)

1st Payment 2nd Payment

Mobilization lump sum fee 14.00%

3rd Payment

14.00%

4th Payment

24.50%

5th Payment

17.50%

Subtotal (Ksh)

Fee 11% of total construction cost

S 770,100,000.00 KES

84,711,000.00 KES

Stage 1 Fee

Work Stage 2 Fee

Work Stage 3 Fee

9,770.00 KES

5,929,770.00 KES

10,377,097.50 KES 7,412,212.50 KES

42,355,500.00 KES

6,280.00 KES

2,156,280.00 KES

3,773,490.00 KES

2,695,350.00 KES

15,402,000.00 KES

7,210.00 KES

1,617,210.00 KES

2,830,117.50 KES

2,021,512.50 KES

11,551,500.00 KES

6,280.00 KES

2,156,280.00 KES

3,773,490.00 KES

2,695,350.00 KES

15,402,000.00 KES

59,540.00 KES

11,859,540.00 KES 20,754,195.00 KES 14,824,425.00 KES

)

Condition

n of 30% on total e inclusive of VAT

Upon Contract Signing

Work Stage 4 Fee

Total Fee by Service

84,711,000.00 KES

On completion and signed off WS1 On completion and signed off WS2 On completion and signed off WS3 On completion and signed off WS4 Page 21

Grannex Group Limited

04 - 11 - 2024

Extra Details.

Fine Print.

We have summarized the following key terms, assumptions and exclusions upon which this proposal is based.

• Charges or levies for permitting and County approvals (e.g. building permit) are not priced for in this proposal and will be payable by the Client directly to the relevant County office • The client will provide a qualified representative to manage the contract from their side for the duration of the construction • Changes to the Scope of Work (Variation) which are instructed or approved by the Client and which result in additional work will incur appropriate additional fees; The client to approve any variation prior to implementation.

• All renders and drawings will include GGL’s logo and tag line • GGL can publicize the design on the website and in promotion material. You will be informed beforehand regarding any publication.

Disbursements / Reimbursable Expenses: • Printing, postage, any required mockups, will be reimbursable cost. The client will provide approval for these costs before incurring them and invoices and receipts will be presented for reimbursement purposes.

• Travel expenses as may be necessary to any shop, factory etc must be approved by the client first.

Next.

Thank you for taking the time to review our proposal.

We are excited to work with you and make your vision a reality!

First of all, please let us know if you have any questions about our proposal or anything else. Once you are happy with everything and you have made a decision to work with us then we can proceed to formalize our engagement through a Project Contract, (FIDIC “White Book” Clients-Consultants Model Services Agreement).

Grannex Group Limited

Page 22

THANK YOU!

Linda Matte Design Director

lindam@grannexgrouplimited.com +254 721 494 749

Page 23

Grannex Group Limited
