THE ACOUSTIC COLLECTION

ALL THE ACOUSTIC SOLUTIONS FOR WINDOWS & WALLS YOU NEED IN ONE PLACE.

INSIDE IS A CAREFULLY CURATED COLLECTION OF REALLY USEFULS! THE PERFECT TOOL FOR DESIGNERS NEEDING ACOUSTIC PRODUCT!

usefuls.

[yoos-fuhls] adjective definition:

1. really useful, easy and convenient textile and wall covering products

2. makes specifying easy 3. perfect for use across all projects

CONTENTS

SOUND ABSORPTION RATES

• NRC explained Page 05

ACOUSTIC WINDOW COVERING

• Sheer curtain fabric Pages 06

• Sheer blind fabric Pages 08

• Curtain fabric Pages 12

• Light reduction curtain fabric Pages 14

WALLS

• Acoustic wall covering Pages 18

• WhisperArt® Pages 20

• WhisperPin® Pages 24

THE ACOUSTIC COLLECTION

Since 1980, Materialised has delivered innovative, high-performance furnishing textiles and wall covering to the Australasian contract interior design industry, with printing and warehousing taking place in the Southern Sydney suburb of Blakehurst.

Our Design Studios are located in Sydney, Melbourne, Brisbane, Perth, Adelaide, Auckland, Costa Rica and Singapore. The team is steeped in a culture of ‘making a difference by doing things differently’ - striving to make a positive difference to community, industry, clients and those occupying the spaces we furnish.

ACOUSTIC SOLUTIONS

Acoustic performance is an important, yet sometimes underrated element of building design.

Acoustics shouldn’t just be considered in building types like concert halls and theatres, but also hotels, bars, restaurants, offices, clubs and aged care facilities.

Sound that is not managed properly interferes with complex task performance, speech intelligibility, behaviour, and is a potential stress inducer. Numerous diners or staff in open-plan spaces; guests in the halls or adjacent rooms; noise from plumbing, HVAC and elevators; noise from function rooms and exterior noise from vehicles are all sounds that need to be minimised.

Materialised offers amazing acoustic solutions for windows and walls to improve comfort without compromising the design integrity.

A harmonious balance of acoustics and aesthetics.

Radium office | Hush Frequency White | Design by Honour Creative | Photography © Bonny Beattie

SOUND ABSORPTION RATES - NRC

To quantify our product as commercial acoustic solutions, each is tested and awarded an NRC (Noise Reduction Coefficient) rating.

The NRC relates to the absorption effectiveness of the material, and is calculated by averaging how absorptive a material is at different frequencies.

Hush acoustic fabric is tested at 250hz, 500hz, 1000hz and 2,000hz.

Whisper acoustic products are tested at 125hz, 250hz, 500hz, 1000hz, 2,000hz and 4,000hz.

Taking the average number, it is then applied to the NRC scale of 0 to 1. A perfectly sound absorptive material achieves a 1, whereas a 0 indicates no absorption.

ACOUSTIC SHEER CURTAIN FABRIC

You’ll hardly believe the difference that lightweight acoustic sheers will make to a space, achieving NRC results previously unavailable for modern architecture.

Watch the video on our YouTube channel.

Our acoustic sheers absorb sound and improve understandability. They are:

• Flame retardant

• Wide width

• Durable

HOW IT WORKS

Woven with a ribbon shaped Trevira CS yarn, this filament is the key to their sound absorption, managing the flow of sound waves repeatedly passing through and bouncing off a reflective surface. This changes the tone, becoming muffled, and results in the reduction of sound levels.

Soundcheck Pumice

Soundcheck White

Acousticus Bone

Acousticus Stone

Acousticus Mist

Acousticus Steel

Wavelength Pumice

Soundcheck Charcoal

SPECIFICATIONS

INSTALLATION

INSTRUCTIONS

For optimum acoustic benefit, we recommend the curtain track be positioned 15 to 20cm from the window or wall, with a minimum 2:1 fullness ratio using an S-Fold style of heading

“Acoustic Sheers absorb significantly more sound energy than any other sheer fabric that I know of. In contemporary decors where hard surfaces are preferred, these acoustic sheers are an ideal way to introduce desperately needed, unobtrusive, and highly effective sound absorption.”

David Spargo, owner of Praxis Acoustics

PAC The Terraces Paddington | Soundcheck Pumice | Design by Gilmore Interior Design | Curtain Manufacturer & Installation Reilly & Associates

ACOUSTIC SHEER BLINDS

The difference a lightweight acoustic blind makes to a room’s acoustic amenity is nothing short of ground breaking.

Watch the video on our YouTube channel.

Our sheer blinds absorb sound and improve understandability. They are:

• Flame retardant

• Wide width

• Durable

HOW IT WORKS

Woven with a ribbon shaped Trevira CS yarn, this filament is the key to their sound absorption, managing the flow of sound waves repeatedly passing through and bouncing off a reflective surface. This changes the tone, becoming muffled, and results in the reduction of sound levels.

MANUFACTURING NOTE: Our acoustic blind fabrics should not be railroaded.

Frequency Blind White

Soundcheck Blind Charcoal

Soundcheck Blind White

Soundcheck

Blind Pumice

SPECIFICATIONS

COMPOSITION

FLAMMABILITY

INSTALLATION INSTRUCTIONS

1530 pt 2

For optimum acoustic benefit, we recommend the blind be positioned 15 to 20cm from the window or wall.

“We have an open plan office with hard surface finishes everywhere, and it looks out onto the factory floor. It was very noisy and near impossible to have several conversations and phone calls at once. So we made roller blinds using Hush acoustic sheer Frequency White fabric. Not only do they perform well, reducing the echo and intensity of sound in the room dramatically, but they look great too and we often have comments from visitors.”

David Reilly, Reilly & Associates.

Orana Restaurant

Double faced Cameron Buff

ACOUSTIC CURTAIN FABRIC

In our lineup, we offer acoustic curtain fabric that mimics the appearance and texture of a soft drape. At the same time, their technology provides effective acoustic control, resulting in impressive Noise Reduction Coefficient (NRC) performance.

LIGHT REFLECTIVE DRAPERY - LOW EMISSION

The Sonic & Sun is a reflective acoustic curtain that has the potential to reduce the energy needed to cool a room in hot weather and conserve energy during winter. This classifies Sonic & Sun as an energysaving product!

SPECIFICATIONS

Sonic & Sun Pebble

Audible Ivory

Audible Steel

Sonic & Sun Pumice

Collins Street

Double faced Cameron Silver

ACOUSTIC LIGHT REDUCTION CURTAIN FABRC

Our range of light reduction curtain fabric offers an array of print designs and plain colour options to satisfy the most exacting demands in aesthetics and functionality. These fabrics have the look and feel of a soft drape, whilst their technology offers both light reduction and acoustic control, delivering an outstanding NRC.

PRINT COMPATIBILITY

Our Midnight offers print compatibility, allowing you to select designs from our extensive library, which we digitally print at our manufacturing headquarters in Sydney. Alternatively, you can opt for an unprinted option.

In The Dark Black

Cameron Buff

Tweedle Dee Buff

Cameron Oyster

Tweedle Dee Smoke

Cameron Silver

Tweedle Dee Char

SPECIFICATIONS

“To deal with an open plan bar space with multi-use requirements, a drapery solution was decided upon to provide flexibility for the client and acoustic abatement for guests. The solution needed to be both cost-effective and acoustically efficient. Materialised’s acoustic drapery fabric, Midnight, was perfect for the job and was both soft in its handle and weighted in its drape.”

Jodie

Duddington, Senior Interior Designer, EJE Architecture

Homespun Midnight Green Tea

Homespun Midnight Denim

Homespun Midnight Clover

Homespun Midnight Earth

Homespun Midnight Cotton

Homespun Midnight Kelp

Homespun Midnight Soot

Homespun Midnight Eucalyptus

Homespun Midnight Brass

Homespun Midnight Terracotta

Midnight - Print Compatible

DIGITAL PRINTS ON MIDNIGHT

Boucle Flint HOTP

Lavandou Navy HOTP

Tangled Terra Firma Patricia Braune

Boucle Moss HOTP

Japanese Panels Slate Florence Broadhurst

Boucle Plum HOTP

Marrunga Yubba Sweet Rain

Lizzy Stageman

Serenity Terrain Robyn Caughlan

Falling Star Ash Jimmy Pike

Mineral Actinolite Shibori

Cuttlefish Burnt Apricot

Grace Garrett

Odette Chartreuse HOTP

Acoustic

Club Parramatta | Custom Midnight | Design by EJE Architecture

| Photography © Alex Mcintyre

Achieve optimal sound control while maintaining design integrity with our acoustic wall coverings. Offered by the linear metre, our range is ideal for improving the acoustics of walls, screens, ceiling panels, and pinboards. Crafted from recycled polyester and inherently antimicrobial, our highperformance solutions are both sustainable and effective.

ACOUSTIC WALL COVERING SPECIFICATIONS

COMPOSITION

100% recycled polyester face (74-100% postconsumer Eco-fi polyester, remaining fibre is preconsumer polyester) / Fused polyester backing

100% recycled polyester face (74100% post-consumer Eco-fi polyester, remaining fibre is preconsumer polyester) / Fused polyester backing

100% recycled polyester face (74100% post-consumer Eco-fi polyester, remaining fibre is pre-consumer polyester) / Fused polyester backing

100% recycled polyester face (95% minimum post-consumer recycled content by weight with Eco-fi polyester, remaining fibre is preconsumer polyester

100% recycled polyester face (95% post-consumer recycled content by weight) / Fused polyester backing

Nufelt Carefree

Nufelt Pinwheel Carefree

Nufelt Bowtie Duckling

Nufelt Bowtie Library

Nufelt Hillside

Nufelt Private Jet

Mayfair Oxford

Nufelt Bowtie Feather

Mayfair Buckingham

Nufelt Pinwheel Private Jet

Nufelt Zest

Nufelt Bowtie Sailboat

Nufelt Pinwheel Dublin

Enlighten Lead

Mayfair Piccadilly

Cluster Snow

Enlighten Snow

Currents Onyx Black

Currents Midnight

Cluster Onyx

WHISPER ART

WhisperArt® is fabric-covered acoustic art perfect for areas where noise negatively affects the soundscape, while adding a visual dimension to the space.

Materialised supplies commercial trade and professional interior design markets with distinctive, thought-provoking acoustic wall art. We have put together an image library consisting of a carefully curated collection along with framing options, giving you the flexibility to find exactly what you need for your project.

HOW IT WORKS

Each acoustic art panel contains an acoustic absorber. The soundwaves pass through the outer skin of fabric, through to the infill where the sound energy is absorbed.

The panels are constructed with a patented polymer tracking system that eliminates the use of adhesives, nails, tacks, or tape while maintaining constant rigidity. This system enables tightly stretching our commercial grade fabric over the acoustic absorbers to create the acoustic art. The framework can therefore be re-used by changing the fabric ‘skin’ if a change of decoration is required.

SUSTAINABILITY

The acoustic absorber is manufactured from thermally bonded polyester fibre with up to 80% recycled fibre content from post-consumer PET packaging. It has a Global GreenTag GreenRate™ Level A certification with a Global GreenTag Platinum HealthRATE™ certification.

MADE IN SYDNEY

Materialised manufactures the acoustic art in-house. We print designs onto a flame retardant textile base cloth with a modified weave, allowing air to freely pass through, whilst maintaining printed integrity. Choose designs from our vast print library or work with our team of in-house designers to supply your own.

FRAMING & HANGING

A little different from a traditional framed print, the artwork sits within the box frame with a 5mm gap, creating a sophisticated shadow effect between the frame and the acoustic art panel. Shadow frames are 10mm thick, and 55mm deep.

Our timber frames are all supplied by local Australian-owned companies using the best of materials. All products comply with Australian standards as set by Australian agriculture and water resources, all logging due diligence is met to Australian standards and all country of origin timber declaration is met to confirm chain of custody.

Our acoustic art includes an aluminium split batten (unframed) and security fixtures (framed) that connects to the panels track profile which is compatible with Gyprock and masonry fixings.

Wiraywinhangin Marramarra WhisperArt. Image from Materialised art/frame library.

SPECIFICATIONS

PRODUCT WHISPERART

ACOUSTIC ABSORBER

• 100% polyester fibre with up to 80% recycled fibre content from postconsumer PET packaging such as empty drink bottles

• Recyclable

ABSORBER THICKNESS 25mm

ABSORBER WEIGHT 2300gsm

AS1530 pt 3, AS ISO 9705

FLAMMABILITY

Corner Burn in accordance with AS 5637.1

TRACK PROFILE PVC – 100 % recyclable, low VOC

TRACK DEPTH - SPLIT BATTEN (Z CLIP) 45mm (or 55mm with box frame)Aluminium

WHISPER ART (Unframed)

- the polymer track stretching system (bold lines)

- absorber (curved lines)

- fabric (dashed lines)

BOLD LINES: Polymer track stretching system CURVED LINES: Absorber | DASHED LINES: Fabric

Nullabor

Dhala-bu-nya - Cracks by Amanda Hinkelmann

Black, oak & white frame options

Brumlow Top

WHISPERPIN ®

WhisperPin® is a fabric-covered acoustic pinboard, perfect for areas where noise negatively affects the sound environment.

HOW IT WORKS

Each acoustic pinboard panel contains an acoustic absorber. The soundwaves pass through the outer skin of fabric, through to the infill where the sound energy is absorbed.

The panels are constructed with a patented polymer tracking system that eliminates the use of adhesives, nails, tacks, or tape while maintaining constant rigidity. This system enables tightly stretching our commercial grade fabric over the acoustic absorbers to create the acoustic pinboard. The framework can therefore be re-used by changing the fabric ‘skin’ if a change of decoration is required.

SUSTAINABILITY

100% PET (60% recycled), low VOC and has a Global GreenTag GreenRate™ Level A certification.

MADE IN SYDNEY

Materialised manufactures acoustic pinboards in-house. We print designs onto a flame retardant fabric with a modified weave, allowing air to freely pass through, whilst maintaining printed integrity. Choose designs from our vast print library or work with our team of in-house designers to supply your own.

SPECIFICATIONS

PRODUCT

WHISPERPIN

ACOUSTIC ABSORBER • 100% polyester fibre with up to 60% recycled fibre content

ABSORBER THICKNESS 12mm ( + / - )

ABSORBER WEIGHT 2400gsm ( + / - )

FLAMMABILITY AS ISO 9705 Corner Burn in accordance with AS 5637.1

TRACK PROFILE PVC – 100 % recyclable, low VOC

TRACK DEPTH - SPLIT

BATTEN (Z CLIP)

NRC (DIRECT FIX)

25mm - Aluminum

0.50

WHISPER PIN

- the polymer track stretching system (bold - absorber (curved lines) - fabric (dashed lines)

25mm 12mm

Lizzy Stageman The Journey - WhisperPin Concept
