Gaia Studio Designs Final Presentation

OASIS EDGE GAIA STUDIO DESIGNS

HOUSTON, TEXAS MONTROSE NEIGHBORHOOD NTS

PRINT BED

PRINT BED

ROTATION OF PRINT BEDS

PROPOSED SITE LAYOUT

SITE PLAN NTS

FAIRVIEW ST

T ST

GRAN

MONTROSE BLVD HYDE PARK BLVD

DWELLING SPACES

DWELLING SPACES

DWELLING SPACES

DWELLING SPACES

PRIVATE COURTYARDS

PRIVATE COURTYARDS

PRIVATE COURTYARDS

PRIVATE COURTYARDS

COMMUNAL COURTYARD

COMMUNAL COURTYARD

COMMUNAL COURTYARD

COMMUNAL COURTYARD

FLOOR PLANS

14'-5"

22'-9"

STORAGE 14 SF

BATHROOM 49 SF

BEDROOM 124 SF

BEDROOM 88 SF

BATHROOM 33 SF

30'-0"

27'-5"

24'-6"

KITCHEN / LIVING ROOM 140 SF

KITCHEN / LIVING ROOM 174 SF

TOTAL AREA 420 SF

BEDROOM 69 SF

15'-9"

LIVING ROOM 74 SF

KITCHEN / DINING 110 SF

TOTAL AREA 419 SF BATHROOM 43 SF

TOTAL AREA 410 SF

N

1

2

4

SCALE: 1/8” = 1’0”

8 FT

ROOF PATTERN

TRADITIONAL ROOF LINE IS TRANSLATED TO THE ROOF LINE AND TRELICE LINES OF OUR INNOVATIVE HOUSING

TRADITIONAL HOUSING

INNOVATIVE HOUSING

N

1

2

4

SCALE: 1/8” = 1’0”

8 FT

BUILDABILITY EXTERIOR GRADE SOUTHERN YELLOW PINE LATTICE

TERRACOTTA ROOF TILES

PRIVACY SCREEN LEVELS OF PRIVACY

ROOF SHEATHING

GYPSUM WALLBOARD

LAVACRETE

HIGH

CEMENTITIOUS WALL RENDER

LOW

SUSTAINABILITY

SUMMER NO SHADE

TEMP WITH NO SHADE 90°-100°

BEING EXPOSED TO THE SUN FOR EXTENDED PERIODS OF TIME IN HOT TEMPATURES IS POTENTIALLY DANGEROUS

TERRACOTTA ROOF PROVIDES HIGH QUALITY THERMAL PERFORMANCE, REDUCING THE NEED FOR IN HOUSE HEATING AND COOLING

BREEZEWAYS ALLOW FOR WIND FLOW AND EXIT OF HOT AIR

SUMMER SHADE

TEMP IN SHADE 80°

ROOF OVERHANGS SHADE THE FRONT AND BACK OF THE HOMES FOR INCREASED OUTDOOR USE DURING SUMMER MONTHS

CROSS VENTILATION

WINTER SUN

TEMP IN SUN 50°

SUN WARMS OUTTER FACE OF HOMES AND HEATS FLOORING DURING WINTER MONTHS

CONCRETE ABSORBS SUNLIGHT AND SLOWLY RELEASES ITS WARMTH SUNSET

SUNRISE

COST CALCULATIONS

MATERIALS ROOF WOOD LATTICE TERRACOTTA ROOF TILES APPLIANCES 1’ CMU WALL DOORS VINYL WINDOW WINDOW FRAMES (43(7*9* 81&' )*59- INSULATION QUOTE TOTAL

COST $18,720.00 $12,240.00 $7,800.00 $5,010.00 $2,725.65 $2096.00 $1,582.48 $900.00 $858.00 $779.00 $52,711.13

THANK YOU!
