For more ergonomic workplaces.

ErgoMove 1000 and ErgoMove 2000.

The Electric Drive Systems from Blickle.

2

we innovate mobility

www.blickle.com

Content

Blickle. A company in motion.

4–5

The ErgoMove principle of added value.

6–7

Overview: ErgoMove 1000 and ErgoMove 2000.

ErgoMove 1000

8

Overview ErgoMove 1000

Overview of ergonomic handle and flex cockpit

ErgoMove 2000

11

Ergonomic handle / Technical information

12 – 13

Flex cockpit Details / Technical information

14 – 15

Other functions

16

Order overview of fixed castors with electric drive

17

Order overview of sets and accessories

18

Order overview of matching swivel castors

19 21 – 22

Overview ErgoMove 2000

23

ErgoMove 2000 and ErgoMove 2000T with recuperative system

www.blickle.com

9 – 10

Cockpit elements and technical details

24 – 25

ErgoMove 2000T: Recuperative system and emergency release

26 – 27

Order overview of fixed castors with electric drive

28

Order overview of sets and accessories

29

Order overview of matching swivel castors

30

we innovate mobility

3

BLICKLE. A COMPANY IN MOTION.

Blickle. Your partner for mobility.

Think mobility.

We have been one of the leading manufacturers of wheels and castors for decades because of our reliability and commitment to innovation. Blickle has been manufacturing high-quality wheels and castors since 1953 and is a global leader in terms of volume, quality and its product range.

Our demands are simple: to develop the best wheel, the best castor for every application ‒ based on our good ideas, our commitment to innovation, our expertise in materials and manufacturing technology, our many years of experience and our motivated, committed employees. Blickle is known worldwide for high-quality, long-lasting and maintenance-free castors and wheels that are “Made in Germany”.

Our headquarters are in Rosenfeld, Germany. This demonstrates our commitment to quality and manufacturing products “Made in Germany”. As a family company, we value consistency. Dr. Sarah Blickle and David Blickle, M.Sc. are the third generation of the family to be involved in the company.

4

we innovate mobility

www.blickle.com

BLICKLE. A COMPANY IN MOTION.

The company headquarters in Rosenfeld

¢ More

than 900 employees worldwide, over 700 of which are based at the headquarters in Rosenfeld, Germany. ¢ 17 sales subsidiaries in Europe, North America and Asia. ¢ Exclusive agencies in 120 countries around the globe. ¢ DIN EN ISO 9001, 14001 and 50001 certified.

www.blickle.com

we innovate mobility

5

ELECTRIC DRIVE SYSTEMS.

The Electric Drive System from Blickle.

Simple. Easy. Blickle.

6

Musculoskeletal disorders are the most common causes for incapacity for work -- in particular in professions in which physically strenuous work such as pulling and pushing of loads are a part of daily activity. The latest innovation from Blickle can reduce these health risks to a minimum: The electric drive systems of the ErgoMove series.

With the integrated dead man’s brake system, the mass in motion is decelarated so that the strain on the operator’s back is reduced. The Blickle drive systems are easy to use and meet stringent safety standards. Blickle uses tried and tested components (motors, control units, operating controls, batteries) to ensure that the drive system is extremely reliable.

The physical strain on the operator is reduced significantly during internal material transport due to considerably less amount of effort required compared to manual operation. The ErgoMove modular electric drive systems from Blickle are designed for a variety of transport devices, trailer systems and special applications with an overall weight of up to 2,000 kg. The high thrust force of up to 2 x 55 daN ensures that the operator uses much less force moving transport devices and trailer systems.

Blickle’s ErgoMove series is therefore an investment that pays off quickly, since personnel and subsequent costs due to illness-related absences are reduced significantly.

we innovate mobility

www.blickle.com

ELECTRIC DRIVE SYSTEMS.

The ErgoMove Principle of Added Value.

Less Strain. More Ergonomics.

Force required to drive a trolley *

Wheels with standard polyurethane tread

Wheels with heavy duty polyurethane Blickle Besthane®

Use of a Blickle ErgoMove **

0

50

Operator's effort in Newton

100

150

200

250

300

Trolley 1,000 kg total weight Trolley 2,000 kg total weight

* Values measured on even floor with wheel Ø 200 mm. ** With ErgoMove 1000 with ergonomic handle, the maximum effort required is 28 N, and with flex cockpit 0 N.

www.blickle.com

we innovate mobility

7

Overview: ErgoMove 1000 and ErgoMove 2000.

Electric drive systems have many applications in manual as well as towing operations. Hence Blickle offers two different systems: ErgoMove 1000 is the right solution for a permissible total weight up to 1,000 kg, while ErgoMove 2000 is suitable for a total weight up to 2,000 kg.

Blickle ErgoMove 1000.

For a total weight of up to 1,000 kg

Both models meet high safety standards and feature electromechanical dead man’s brakes and an automatic brake release due to hand detection sensors on the operating handles. The emergency stop and anti-trap function prevent pressing and crushing injuries.

The Blickle ErgoMove 2000.

For a total weight of up to 2,000 kg

2,000 kg

1,000 kg

¢ ¢ ¢ ¢ ¢ ¢

For a total weight of max. 1,000 kg Power assistance up to 4 km/h Thrust force max. 2 x 30 daN High-capacity rechargeable batteries with quick charger Different cockpits available Plug & Play: Can be easily integrated into existing trolley systems with the plug-in system

More information about ErgoMove 1000 on page 9

8

we innovate mobility

¢ ¢ ¢ ¢

¢

For a total weight of max. 2,000 kg Power assistance up to 4 km/h Thrust force max. 2 x 55 daN Can also be used for towing operation up to 16 km/h; battery recharges through recuperative system (ErgoMove 2000T) Ideal solution for highest requirements

More information about ErgoMove 2000 on page 21

www.blickle.com

For a total weight of up to 1,000 kg.

ErgoMove 1000

www.blickle.com

we innovate mobility

9

The Electric Drive System ErgoMove 1000.

Power Assistance for a Total Weight up to 1,000 kg.

ErgoMove is ideally suitable for the retrofitting of existing trolleys. Both handle designs available for ErgoMove 1000 offer additional flexibility.

ErgoMove 1000 supports the use in manual operation with a maximum speed up to 4 km/h. It is permitted for a total weight of up to 1,000 kg.

Set components 1: Cockpit Different cockpit versions available for ErgoMove 1000.

1

Set components 2: Drive castors Electrically-driven fixed castors available in different versions.

4

2

Accessories: Cockpit extension Complementary for versions with ergonomic handle.

3 10

we innovate mobility

Accessories: Suitable swivel castors Different swivel castors available, also in anti-static versions. www.blickle.com

ErgoMove 1000 Overview of Ergonomic Handle and Flex Cockpit.

We provide a number of different versions of the ErgoMove 1000.

Design with ergonomic handle ·C ontrol panel with integrated operation control, two rechargeable batteries as well as two operating handles · F lexible positioning of signal horn · Two electrically-driven fixed castors The handle has an integrated sensor system for force detection.

More details starting on page 12.

Design with flex cockpit · Control panel with integrated control and two rechargeable batteries · Two separate operating handles with rotary joystick · Fully-adjustable signal horn · Two electrically-driven fixed castors The components offer high flexibility, since they can be mounted individually on the trolley. For more details see page 14.

The advantages at a glance ¢ Compact Control and rechargeable batteries are integrated in both versions. ¢ Plug & Play

Quick and uncomplicated assembly through a plug-in system for retrofitting to existing trolleys. ¢ Power assistance up to 1,000 kg The electric drive system is suitable for trailer and transport trolleys of up to 1,000 kg total weight.

(Power assistance up to 4 km/h, thrust force max. 2 x 30 daN). ¢ Operation modes Mode "Turtle": forwards 2 km/h, reverse 2 km/h.

Mode "Hare": forwards 4 km/h, reverse 2 km/h. www.blickle.com

¢ Modular concept With standard parts and optional accessories. ¢ Ready for operation at any time Rechargeable batteries can be changed quickly and easily. ¢ Safe

Emergency stop, anti-trap protection, automatic brake release with hand detection sensor, authorisation concept with key switch and horn as standard.

¢ CE Conformity Installation declaration and installation instructions for the set in line with the Machine Guideline 2006/42/EU including EU-compliance declaration in line with the EMV Guideline 2014/30/EU. we innovate mobility

11

ErgoMove 1000 The Ergonomic Handle.

RoHS conformity ďƒźCE

Protection class IP 40 ďƒźRoHS

The ergonomic handle with integrated power sensor was designed in collaboration with the Institute for Materials Handling Technology and Logistics in Stuttgart and the Heilbronn College to meet superior ergonomic demands and contains a system for measuring the operating forces on the ergonomic handle.

The motor control of the drive castors is dependent on the strength and design of the forces on the operating handle.

2

1

1

3 4 5 6

7

1 2 3 4 5 6 7

12

7

Handles with sensor and hand detection * Emergency stop On button

Key switch **

Mode "Turtle" / "Hare" Horn (110 dB volume)

* The sensor for hand detection guarantees that castors can only be driven if the operator holds operating handles with both hands. ** Key switch including two keys as standard.

Rechargeable batteries with charge level display

we innovate mobility

www.blickle.com

ErgoMove 1000 Technical Information on the Ergonomic Handle.

RoHS conformity ďƒźCE

Protection class IP 40 ďƒźRoHS

The ergonomic handle with integrated power sensor records the forces operated by the operator in three dimensions: front / back, left / right and turn: The power impulses in the ergonomic handle are converted into control signals and support the steering. This in turn provides simple and intuitive handling.

Safety function: The trolley brakes when the handle is released.

The ideal ergonomic height of the handle for an operator with average height is approx. 1.20 m. Blickle optionally offers a console extension for this height. The element is also conceptualised for an optimal ergonomic grip angle.

The scope of supply also contains a cable for the horn (1.5 m) and two pluggable cables for connecting the cockpit and drive castors (each 3Â m). For more details please refer to page 15 and 16 in Accessories.

Ergonomic handle dimensions

Ergonomic handle and console extension to the trolley

Console extension*

Top plate dimensions (bottom view)

For details on the horn, please refer to pages 15 and 16

www.blickle.com

* console extension available as accessory, see page 18

we innovate mobility

13

ErgoMove 1000 The Flex Cockpit.

RoHS conformity ďƒźCE

Protection class IP 40 ďƒźRoHS

The flex cockpit includes the following components: A control panel with integrated control and anti-trap protection (pressure-sensitive button), two separate operating handles with rotary joystick.

All elements can be installed flexibly on the trolley.

The motors are controlled separately by a different joystick (left/right). As in the case of the ergonomic handle, the brake release is also activated in the flex cockpit with a sensor for hand detection on both handles.

3 4 2 1

5

2

6 7

1

8

1 2 3 4

Handles with joystick and hand detection * Rechargeable batteries with charge level display Emergency stop On button

5 6 7 8

Key switch **

Mode "Turtle" / "Hare" Horn (110 dB volume) Anti-trap protection

* The sensor for hand detection guarantees that castors can only be driven if the operator holds operating handles with both hands. ** Key switch including two keys as standard.

14

we innovate mobility

www.blickle.com

ErgoMove 1000 Technical Dimensions of the Flex Cockpit.

RoHS conformity CE

Protection class IP 40 RoHS

Dimensions of the left and right joystick

Joystick cables for the cockpit are included in the scope of supply (each 1 m).

Dimensions for flex cockpit and horn Assembly is done with bracket clips for round pipe Ø 33-36 mm. The scope of supply contains a cable for the horn (1.5 m) and two loadable cables for connecting the cockpit and drive castors (each 3 m).

Flexible positioning of the horn, 110dB, 24V, cable length 1.5m.

www.blickle.com

we innovate mobility

15

ErgoMove 1000 Other Functions.

RoHS RoHS CE conformity CE conformity Protection class IP Protection class IP 40  RoHS RoHS 40RoHS

The ErgoMove 1000 includes the following other functions:

Emergency release

ON

If required, the key switch (position ) can be used to release the dead man's brakes. This way, the trolley can also be moved manually without any power supply.

Rechargeable battery The battery unit comprises of commercial rechargeable batteries and can be quickly changed with a simple plug mechanism. In this way the permanent operation is guaranteed through replacement batteries. At full capacity the battery can get 1000 kg loads moving up to 300 times on an even surface. .

(Li-Ion battery, 5Ah, 90Wh with 18 V. charging time approx. 45min at 8A charging current with quick charger.)

Horn

Both ergonomic handle and flex cockpit come with a horn. It can be attached on the trolley anywhere. More details on page 25.

Volume: 110 dB. Cable length: 1.5m (with cockpit connected).

Anti-trap protection

Both versions of the ErgoMove 1000 guarantee anti-trap protection for the operator:

The integrated power sensor in the ergonomic handle ensures the anti-trap protection. If the ergonomic handle is pressed against the operator, the trolley will go back in the opposite direction.

The handle already detects minor forces (max. 28N in 1,000 kg are necessary) and sends these signals to the motor.

In the flex cockpit, the pressure-sensitive button activates the anti-trap protection: The trolley travels a little in the opposite direction when the button is pressed.

16

we innovate mobility

www.blickle.com

ErgoMove 1000 Drive Castors.

RoHS RoHS RoHS conformity CE conformity Protection class IP 40RoHS Protection class IP 40 CE 

Fixed castor bracket: Made from a sturdy casting, zinc-plated, blue-passivated, Cr6-free, with integrated motor controller Wheels: Tread: Made of high-quality, reaction-injected Blickle Besthane® Soft polyurethane-elastomer, 75° hardness, Shore A, very high operational comfort due to the especially thick, elastic tread, lownoise operation, very low rolling resistance, high dynamic load capacity, good floor preservation, highly abrasion-resistant, high cut and tear propagation resistance, blue, non-marking, non-staining, very good chemical bonding with the wheel centre.

Wheel centre: Made of high-quality, shatter-proof plastic, black.

Drive: Brushless DC motor with integrated electro-mechanical brake system (dead man’s function, 4Nm static holding torque), thrust force max. 30 daN per motor.

“-L”

“-R”

Fixed castor with electric drive system

Wheel Ø

EM1000-POBS 160K-ET-L

160

50

400

202

140 x 110

105 x 75-80

11

85

105

EM1000-POBS 160K-ET-R

160

50

400

202

140 x 110

105 x 75-80

11

85

105

EM1000-POBS 190K-ET-L

190

50

480

235

140 x 110

105 x 75-80

11

85

105

EM1000-POBS 190K-ET-R

190

50

480

235

140 x 110

105 x 75-80

11

85

105

Wheel Load capacity Total height width at 4 km/h (D) [mm] (T2) [mm] [kg] (H) [mm]

Plate size (A, B) [mm]

Bolt hole spacing (a, b) [mm]

Bolt hole Ø Motor Ø (d) [mm] (M) [mm]

Motor overhang (U) [mm]

-L for "left roller" and -R "right roller".

www.blickle.com

we innovate mobility

17

ErgoMove 1000 Standard Components and Accessories.

RoHS conformity CE

Protection class IP 40 RoHS

The ErgoMove 1000 is a modular system. The possible combinations with ergonomic or flex cockpit are listed in the following overview table. Furthermore, there are also accessories and spare parts available.

“-L”

SET Order number * SET EM1000-POBS 160K-ET-EG SET EM1000-POBS 160K-ET-2FG SET EM1000-POBS 190K-ET-EG SET EM1000-POBS 190K-ET-2FG

“-R”

Fixed castors with drive and electro-mechanical dead man's brake (-ET)

Ergonomic handle (-EG) **

EM1000-POBS 160K-ET-L

Cockpit with two separate handles and rotary joysticks (-2FG) **

Use in manual operation (support up to 4 km/h)

x

EM1000-POBS 160K-ET-R

x

EM1000-POBS 160K-ET-L

x

EM1000-POBS 160K-ET-R EM1000-POBS 190K-ET-L

x

EM1000-POBS 190K-ET-R

x x

EM1000-POBS 190K-ET-L

x

EM1000-POBS 190K-ET-R

x

* The scope of supply contains a cable for the horn and two pluggable cables for connecting the cockpit and drive castors. ** With integrated control and two rechargeable batteries. Charger available as accessory.

Accessories

Foot guard and motor cover**

Charger

Spare battery**

Extension cable**

Console extension

Article no.

For wheel Ø 160mm: EM1000-GUARD-160

EM-CHARGER-18V8A

EM-BATTERY-18V5AH

EM1000-CABLE-2M

EM1000-CONSOLE

Quick charger for rechargeable batteries, charging voltage 18V; charging current 8A.

Rechargeable battery in Extension cable (2m) original manufacturer incl. for connection quality, 18V; 5Ah. between the cockpit and drive castors.

For wheel Ø 190 mm: EM1000-GUARD-190

Description

Foot guard for avoiding foot injuries due to overrunning.

Motor cover for protection against impacts and other mechanical damages.

Four-edged adapter pipe for extending the handrail under the cockpit. Total height adjustment of 435mm.

** Two pieces are required for a complete set.

18

we innovate mobility

www.blickle.com

ErgoMove 1000 Compatible Swivel Castors.

RoHS conformity CE

Protection class IP 40 RoHS

The Blickle standard program includes more than 30,000 products. This includes a number of swivel castors that can be combined with ErgoMove 1000. The following is a recommendation keeping in mind the ergonomic aspects:

Housing: L series - made of pressed steel, swivel housing with double ball bearing in swivel head, with robust centre pins and swivel head sealing. Bolted wheel axle. Coated, passivated blue, Cr6-free.

ALBS

Housing: LH/LHD series - Made of pressed strong steel, tightened and secured with really robust centre pins, with double ball bearing in swivel head, additionally reinforced with four especially moulded, hardened bearing seats. Bolted wheel axle. Coated, passivated blue, Cr6-free.

Accessories Compatible swivel castors (see below for images) LH-ALBS 160K LH-ALST 160K-AS L-ALBS 200K L-ALST 200K-AS LH-ALBS 200K * LH-ALST 200K-AS * LHD-ALBS 181K LHD-ALST 181K-AS

Wheel Ø

Wheel width

[mm]

[mm] 160 160 200 200 200 200 180 180

ALST-AS

Load capacity at 4 km/h [kg]

50 50 50 50 50 50 2 x 44 2 x 44

Designation

Illustration for LH-ALBS series*

Illustration for LHALST-...-AS series*

Technical information

Pressed steel swivel castor, see G15 p. 242

Pressed steel swivel for perfect swivel castor, antistatic, see G15 p. 227

Illustration for LHD-ALBS 181K series

Wheels: ALBS series - Tread: Made of high-quality polyurethane-elastomer Blickle Besthane® soft, 75° Shore A, blue, non-marking, non-staining.

Wheel centre: Made of aluminium die casting.

Bearing type: Two pressed-in ball bearings.

550 550 400 400 700 700 800 800

Wheels: ALST-...-AS series - Tread: Made of high-quality polyurethane-elastomer Blickle Softhane®, 75° Shore A, green, non-marking, non-staining, anti-static.Wheel centre: Made of aluminium die casting.

Bearing type: Two pressed-in ball bearings.

Total height

Plate size

Bolt hole spacing Bolt hole Ø

[mm]

[mm]

[mm]

202 202 235 235 245 245 235 235

140 x 110 140 x 110 140 x 110 140 x 110 140 x 110 140 x 110 140 x 110 140 x 110

105 x 75-80 105 x 75-80 105 x 75-80 105 x 75-80 105 x 75-80 105 x 75-80 105 x 75-80 105 x 75-80

[mm] 11 11 11 11 11 11 11 11

Illustration for Illustration for LHD-ALST 181K-AS L-ALBS 200K series

Illustration for L-ALST 200K-AS

Swivel castor with foot guard

for perfect swivel, anti-static

Pressed steel swivel castor, see G15 p. 223

Item suffix -FS, on request

Pressed steel Swivel castor

* While using the LH-ALBS 200K and LH-ALST 200K-AS, the set SET EM1000-POBS 190K... needs the adapter plate APS3-10.

www.blickle.com

we innovate mobility

19

20

we innovate mobility

www.blickle.com

For a total weight of up to 2,000 kg.

ErgoMove 2000 and ErgoMove 2000T.

www.blickle.com

we innovate mobility

21

The Electric Drive System ErgoMove 2000.

Power Support for a Total Weight up to 2,000 kg.

1

Set components 1: Cockpit comprising a control panel and two separate handles with rotary joysticks.

2

Accessories: Compatible swivel castors Addition to the ErgoMove 2000, different swivel castors also available in anti-static design.

22

we innovate mobility

4

Set components 2: Control box with integrated battery unit.

3

Set components 3: Drive castors Electrically-driven fixed castors available in different designs.

www.blickle.com

The ErgoMove 2000 for Use in Manual Mode.

The ErgoMove 2000T with Battery Recuperative System in Towing Operation.

We provide a number of different versions of the ErgoMove 2000.

We recommend the Blickle ErgoMove 2000 for loads up to 2,000 kg. The ErgoMove 2000 will be available to you as a modular kit which can be flexibly assembled comprising two electrically-driven fixed castors, a cockpit, separate handle with rotary joystick, a horn and a control box with integrated battery.

The Blickle ErgoMove 2000.

For use in manual mode.

For use in manual mode ¢ Power assistance up to 4 km/h ¢

If you will use the ErgoMove for towing, we recommend the electric drive system with recuperative system (ErgoMove 2000T). In this version, the battery will be recharged in towing mode.

The Blickle ErgoMove 2000T. With battery recuperative system in towing operation.

Also use in towing operation up to 16 km/h charges in towing operation through recuperative system ¢ Additional charging is not required if the towing route is sufficiently long. ¢

¢ Battery

Both designs offer two operating modes: Version with one joystick (-1FG): Mode I: forwards and reverse 2km/h.

Mode II: forwards 4km/h, reverse 2km/h.

Version with two joysticks (-2FG): Mode I: Both motors are controlled together (forwards 4km/h, reverse 2km/h).

Mode II: Motors are controlled separately (forwards and reverse 2km/h) with two joysticks (right/left).

The advantages at a glance ¢ Strong Drive system for trailer and transport unit up to 2,000 kg total weight with high level of thrust (max. 2 x 55 daN).

¢ Modular With standard parts and optional accessories.

¢ Energy recovery

In the ErgoMove 2000T, the battery charges through recuperative in towing operation.

Emergency stop, anti-trap protection, automatic brake release

¢ Retrofitting

Existing trailer systems can be upgraded with the drive system.

¢ CE Conformity

Installation declaration and installation instructions for the set in line with the Machine Guideline 2006/42/EC including EU-compliance declaration in line with the EMV Guideline 2014/30/EC.

www.blickle.com

¢ Safe

with hand detection sensor, authorisation concept with key switch and horn as standard.

we innovate mobility

23

ErgoMove 2000 and ErgoMove 2000T. The Cockpit.

CE conformity ďƒźRoHS

Protection class IP 44 ďƒźRoHS

1

3 4

5

6

7

8

9

2

10

1 2 3 4 5

Handle Handle with joystick and hand detection* Emergency stop Key switch On/Off button

6 7 8 9 10

Horn (110 dB volume) Mode I / II

Charge level display Charging unit port

Anti-trap protection

Delivery of cockpit and handle including cables (3m). Key switch as standard including two keys. * The sensor for hand detection guarantees that drive is possible only if a person is operating the vehicle.

24

we innovate mobility

www.blickle.com

ErgoMove 2000 and ErgoMove 2000T. Technical Details.

CE conformity RoHS

Protection class IP 44 RoHS

Cockpit dimensions.

Assembly is done with bracket clips for pipe Ø 33-36 mm. Control box cables are included in the scope of supply (each 3 m).

Handle dimensions with and without joystick. Control box cables are included in the scope of supply (each 3 m).

Control box with integrated control and battery unit The control box system can be positioned on an existing or new transport unit system to save space. It contains the battery and control unit (torque control). The cable from the cockpit to the control unit and the drive castors can be run through the frame of the unit.

Control box and horn assembly The control box and horn can be fitted using the dimensions in the diagrams.

Battery unit (integrated into control box) Cutting-edge battery technology. At full capacity the battery can get 2000 kg loads moving up to 500 times on an even surface surface.

Standard: Li-Ion battery, 22 Ah, 580 Wh at 24 V, approximately four hours to charge (for 90% capacity) at 6 A current.

Horn The horn is attached and connected to the control box. 110 db, 24 V, cable length 1.5 m, flexible positioning.

www.blickle.com

we innovate mobility

25

ErgoMove 2000T: Recuperative System and Emergency Release.

CE conformity RoHS

Protection class IP 44 RoHS

Battery recuperative system in towing operation

How does the emergency release work?

The ErgoMove 2000T version is also suitable for use in towing up to 16 km/h. Another advantage is that the battery recharges during the towing operation through a recuperative system.

Battery charging is reduced to a minimum with regular use and sufficient travel distance.

A draw-bar is lowered on the trolley while attaching it to a trailer. The movement of the plunger opens the brakes. This causes the brakes to release mechanically. The control is activated in towing mode through the electric coupling switch.

The electro-magnetic brake system must be released in towing mode in order to prevent damage to the electric drive castors.

For this purpose, ErgoMove 2000T has an emergency release for the brakes. While intalling the set the brakes need to be connected with the emergency release.

Cam (path = 12 mm) * Plunger Spring Bowden cables to the brakes * Set screws for Bowden cable cover external Ø 3 mm Electric coupling switch * Cam and Bowden cables are not part of the scope of supply. The cam needs to be installed on the drawbar in such a way that the emergency release gets activated in raised-up position.

26

we innovate mobility

www.blickle.com

ErgoMove 2000T: Recuperative System and Emergency Release.

CE conformity ďƒźRoHS

Protection class IP 44 ďƒźRoHS

Illustration 1: Raised draw-bar draw-bar

Illustration 2: Lowered draw-bar

If the draw-bar is raised-up, the Bowden cables are not pulled and brakes close mechanically.

If the draw-bar is lowered, the Bowden cables are pulled and the brakes open mechanically.

Mechanical emergency release dimensions.

Screw DIN 933-M10

www.blickle.com

we innovate mobility

27

ErgoMove 2000 Drive Castors.

CE conformity RoHS

Protection class IP 44 RoHS

Fixed castor bracket: Particularly robust welded steel construction, zinc-plated, yellow-passivated, Cr6-free.

Emergency release

Wheels: Tread: Made of high-quality, reaction-injected Blickle Besthane® Soft polyurethane-elastomer, 75° hardness, Shore A, very high operational comfort due to the especially thick, elastic tread, lownoise operation, very low rolling resistance, high dynamic load capacity, good floor preservation, highly abrasion-resistant, high cut and tear propagation resistance, blue, non-marking, non-staining, very good chemical bonding with the wheel centre.

Wheel centre: Made from robust grey cast iron, lacquered, colour silver. Wheel Ø 250 mm with grease nipple.

Bearing type: Two pressed-in ball bearings, greased with long-life grease.

Drive: Brushless DC motor with integrated electro-mechanical brake system (dead man’s function, 12 NM static holding torque) with forced unlocking on each fixed castor, level of thrust max. 55 daN per motor.

Cable outlet

“-L”

“-R”

Fixed castor with electric drive system EM2000-BS-GBS 200K-ET-L EM2000-BS-GBS 200K-ET-R EM2000-BS-GBS 252K-ET-L EM2000-BS-GBS 252K-ET-R

Wheel Ø

Wheel Load capacity Load capacity Total width at 4 km/h at 16 km/h height (D) [mm] (T2) [mm] [kg] [kg] (H) [mm] 200 200 250 250

50 50 80 80

700 700 1200 1200

280 280 480 480

245 245 305 305

-L for "left roller" and -R "right roller". Includes cables (3 metres) for brake, hall sensors and motor.

28

we innovate mobility

Plate size (A, B) [mm]

140 x 110 140 x 110 140 x 110 140 x 110

Bolt hole spacing (a, b) [mm]

105 x 75-80 105 x 75-80 105 x 75-80 105 x 75-80

Bolt hole Ø (d) [mm] 11 11 11 11

Motor Ø

Motor protrusion (M) [mm] (U) [mm] 145 145 145 145

200 200 215 215

www.blickle.com

ErgoMove 2000 Standard Components and Accessories.

CE conformity RoHS

Protection class IP 44 RoHS

The ErgoMove 2000 is a modular system. Possible combinations are listed in the overview table below.

Furthermore, there are also accessories and spare parts available.

“-L”

SET Order number * SET EM2000-BS-GBS 200K-ET-1FG SET EM2000T-BS-GBS 200K-ET-1FG SET EM2000-BS-GBS 200K-ET-2FG SET EM2000T-BS-GBS 200K-ET-2FG SET EM2000-BS-GBS 252K-ET-1FG SET EM2000T-BS-GBS 252K-ET-1FG SET EM2000-BS-GBS 252K-ET-2FG SET EM2000T-BS-GBS 252K-ET-2FG

“-R”

Standard Cockpit 1 handle with Fixed castors with drive and electro- Control box joystick (-1FG) mechanical dead man’s brake (-ET) including battery unit and horn

EM2000-BS-GBS 200K-ET-L EM2000-BS-GBS 200K-ET-R EM2000T-BS-GBS 200K-ET-L EM2000T-BS-GBS 200K-ET-R EM2000-BS-GBS 200K-ET-L EM2000-BS-GBS 200K-ET-R EM2000T-BS-GBS 200K-ET-L EM2000T-BS-GBS 200K-ET-R EM2000-BS-GBS 252K-ET-L EM2000-BS-GBS 252K-ET-R EM2000T-BS-GBS 252K-ET-L EM2000T-BS-GBS 252K-ET-R EM2000-BS-GBS 252K-ET-L EM2000-BS-GBS 252K-ET-R EM2000T-BS-GBS 252K-ET-L EM2000T-BS-GBS 252K-ET-R

and 1 handle without joystick

2 handles with joystick (-2FG)

x

x

x

x

x

x

x

x

x

x

x

x

x

x

x

x

x

x

x

x

x

x

x

x

Use only in man- Can also be ual operation up used in towing to 4 km/h operation up to 16 km/h **

x x x x x x x x

* Cables for joystick, cockpit, horn and electrically-operated fixed castor for the control box are included in the scope of supply. Charger available as accessory. ** Version ErgoMove 2000T. Supplied including mechanical emergency release (refer to page 26 and 27).

Versions and options available upon request

Description

Charger with Schuko plug Item no. EM-CHARGER-24V6A

Technical information

XLR socket (cable length 1.5 m) Charging voltage 24 V, current 6 A

www.blickle.com

we innovate mobility

29

ErgoMove 2000 Compatible Swivel Castors.

CE conformity RoHS

Protection class IP 44 RoHS

The Blickle standard program includes more than 30,000 products. This includes a number of swivel castors that can be combined with ErgoMove 2000. The following is a recommendation keeping in mind the ergonomic aspects:

Housing: LH/LHD series - Made of pressed strong steel, tightened and secured with really robust centre pins, with double ball bearing in swivel head, additionally reinforced with four especially moulded, hardened bearing seats. Bolted wheel axle. zinc-coated, passivated blue, Cr6-free.

ALBS

Housing: LS series - Particularly robust welded steel construction, swivel housing with axial grooved ball bearing DIN 711 and ball bearing DIN 720 in swivel head, dust and jet spray proof, with lubricating nipple, tightened and secured with very stable welded centre pins. Bolted wheel axle. zinc-coated, passivated yellow, Cr6-free.

Compatible swivel castors (see below for images)

Wheel Ø

Wheel width

[mm]

[mm]

LHD-ALBS 180K ** LHD-ALST 180K-AS ** LH-ALBS 200K LH-ALST 200K-AS LS-GBS 252K-03 LS-GST 252K-03-AS

180 180 200 200 250 250

2 x 44 2 x 44 50 50 80 80

Load capacity at 4 km/h [kg] 800 800 700 700 1400 1400

Designation

Illustration LH-ALBS 200K

Illustration LH-ALST 200K-AS

Technical information

Pressed steel swivel castor, see G15 p. 242

Pressed steel swivel Welded steelswivel castor, antistatic, castor see G15 p. 227

Illustration LS-GBS 252K-03

Wheels: ALBS series - Tread: Made of high-quality polyurethane-elastomer Blickle Besthane® soft, 75° Shore A, blue, non-marking, non-staining.

Wheel centre: Made of aluminium die casting.

Bearing type: Two pressed-in ball bearings.

Wheels: ALST-...-AS series - Tread: Made of high-quality polyurethane-elastomer Blickle Softhane®, 75° Shore A, green, non-marking, non-staining, anti-static.

Wheel centre: Made of aluminium die casting.

Bearing type: Two pressed-in ball bearings.

ALST-AS

Load capacity at 16 km/h [kg]

Total height

Plate size

Bolt hole spacing Bolt hole Ø

[mm]

[mm]

[mm]

420 360 280 220 560 420

235 235 245 245 305 305

140 x 110 140 x 110 140 x 110 140 x 110 140 x 110 140 x 110

105 x 75-80 105 x 75-80 105 x 75-80 105 x 75-80 105 x 75-80 105 x 75-80

[mm] 11 11 11 11 11 11

Illustration LS-GST 252K-03-AS

Illustration LHD-ALBS 180K**

Illustration LHDALST 180K-AS**

Swivel castor with foot guard

Welded steelswivel castor, see G15 p. 233

for perfect swivel

for perfect swivel, anti-static

Item suffix -FS, on request

** needs adapter plate APS3-10.

30

we innovate mobility

www.blickle.com

Safety instructions Please note that the position of the swivel and fixed castor have a significant impact on the manoeuvrability of the unit. Trolley manufacturers must attach an apron to their equipment in order to prevent potential foot injuries, however we can provide swivel castors with integrated foot guards. We also recommend fitting one end of the unit with spring-loaded swivel castors on arrangements in which the drive wheels are attached in the centre.

The customer is entirely responsible for the transport unit and its operation. The drive system is suitable for trolleys up to max. 1,000 kg (ErgoMove  1000) or up to max. 2,000 kg (ErgoMove 2000) total load with two swivel castors and two fixed castors and indoor operation on even surfaces. If the starting aid is used in different conditions, get information about the permissible total weight of the unit. We recommend using the electric drive system in an ambient temperature of between +5°C and +40°C. Please comply with the standards and regulations which has to be clarified.

www.blickle.com

we innovate mobility

31

The Blickle G15 general catalogue: More than 30,000 wheels and castors on over 500 pages.

Experience Blickle’s expertise and performance yourself: request the comprehensive G15 general catalogue by phone on +49 7428 932-0 or on the Internet at www.blickle.com.

Our Blickle product finder is also available online.

The Blickle G15.

Order

your e gu catalo now!

FREE CAD

DOWNLOAD

Castors

and Whe

els

933403 I March 2018

Your local Blickle distributor:
