digital audio + DMX
OW15Y..
PVC
OmniWire AES/EBU studio multicore n x 2 x 0.15 mm² - PVC
• 0.15 mm² conductor cross section (AWG 26) • extra fine stranded conductors (19 x 0.10 mm) • tinned copper spiral pair shields • ultra flexible
exemplarily illustrated is the 12-pair OW15Y12
2 4 8 12 16 24 pairs
OL22Y..
PVC
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/1d8ecd36a40721b9cfb06a8f687fc816.jpeg)
OmniLIVE AES/EBU multicore n x 2 x 0.22 mm² - PVC
• 0.22 mm² conductor cross section (AWG 24) • overall braid shield • very compact outer diameter
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/7907921711f4a2ce082abe22a9c6b08e.jpeg)
exemplarily illustrated is the 12-pair OL22Y12
8 12 16 24 pairs
OX22AH..
Eca FRNC
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/c3bdf7205b2324b75b87ce7822aca13d.jpeg)
OmniFIX double shielded AES/EBU multicore n x 2 x 0.22 mm² - FRNC
• 0.22 mm² conductor cross section (AWG 24) • double shielding (pair and overall Al foil) • AL/PETP foil bonded to pair jacket for fast assembly • flame retardant and non corrosive (FRNC) • CPR class Eca
exemplarily illustrated is the 12-pair OX22AH12
2 4 8 12 24 pairs
SHD..
Eca FRNC
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/13de8273d989c9a80fcead0f0e42f544.jpeg)
Sentinel high end AES/EBU multicore n x 2 x 0.57 mm - solid conductor - FRNC
• 0.26 mm² conductor cross section (AWG 23/1) • double overall shield (foil and braid) • flame retardant and non corrosive (FRNC) • CPR class Eca
exemplarily illustrated is the 10-pair SHD12
OS15CP..
PUR
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/f3d97d475faa35c6692bf88e1be41b01.jpeg)
OmniSTAR AES/EBU multicore n x 2 x 0.15 mm² - PUR
• 0.15 mm² conductor cross section (AWG 26) • extra fine stranded conductors (19 x 0.10 mm) • tinned copper spiral pair shields • pair jackets from cold-flex PVC • very dense overall copper braid • PUR overall jacket
exemplarily illustrated is the 12-pair OT15CP12
8 12 pairs
OL22P..
PUR
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/5ff5c61eef0388ec498e85746ed946ce.jpeg)
OmniLIVE AES/EBU multicore n x 2 x 0.22 mm² - PUR
• 0.22 mm² conductor cross section (AWG 24) • overall braid shield • very compact outer diameter • extra robust PUR jacket
OX22GHB..
12 pairs
Dca FRNC
OmniFIX HS high screen AES/EBU multicore n x 2 x 0.22 mm² - FRNC - Dca
• suitable for analog and digital audio • 0.22 mm² conductor cross section (AWG 24/7) • triple shielding (pair and double overall Al foil) • AL/PETP foil bonded to pair jacket for fast assembly • flame retardant and non corrosive (FRNC) • CPR class Dca - s2, d2, a1 acc. to EN50575
exemplarily illustrated is the 12-pair OX22GH12
2 4 8 12 pairs
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/ff059764026087c4cc62fe66389537a5.jpeg)
From simple parallel loudspeaker cables, to fine stranded and twisted speaker cables for the professionals and hifi enthusiasts, to multicore speaker cables and cables specially designed for prof. line array systems. All cables available for mobile or installation use.
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/69b7919c161d67a3c6712063ff2a5c99.jpeg)
speaker cables
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/a05dd6c016b6d31a5e7c93f75e23571e.jpeg)
speaker
LYP007..
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/6921be1d7df01e6e2216850fc35d1567.jpeg)
parallel speaker cable 2 x 0.75 mm² - zip cord - PVC
• cable with separable conductor pair • for banana plug speaker connections • for screw-type speaker connectors
PVC
LYP025..
PVC
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/8205aac053280db5ef613014caf12cba.jpeg)
parallel speaker cable 2 x 2.5 mm² - zip cord - PVC
• cable with separable conductor pair • for banana plug speaker connections • for screw-type speaker connectors
LY215..
PVC
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/ab22afaa7c47d36d495883196bb10620.jpeg)
twinaxial speaker cable 2 x 1.5 mm² - PVC
• fine stranded bare copper wires • improved EMC by a very short length of twist • flexible, but robust PVC jacket • ideal for winding on cable drums
LY240..
PVC
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/3cf9de1ed67115ee9709d029848b719d.jpeg)
twinaxial speaker cable 2 x 4.0 mm² - PVC
• fine stranded bare copper wires • improved EMC by a very short length of twist • flexible, but robust PVC jacket • ideal for winding on cable drums
LYP015..
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/9d83a4c416b28335e8944d8cc6234281.jpeg)
parallel speaker cable 2 x 1.5 mm² - zip cord - PVC
• cable with separable conductor pair • for banana plug speaker connections • for screw-type speaker connector
PVC
LYP060T
PVC
parallel speaker cable 2 x 6.0 mm² - zip cord - PVC
• cable with separable conductor pair • for banana plug speaker connections • for screw-type speaker connectors
LY225..
PVC
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/d86fd91d6302e8419396d6d1faff8dcb.jpeg)
twinaxial speaker cable 2 x 2.5 mm² - PVC
• fine stranded bare copper wires • improved EMC by a very short length of twist • flexible, but robust PVC jacket • ideal for winding on cable drums
speaker
LSC425YS
PVC
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/7dae5f7971c0a0045c628391b91dbeb6.jpeg)
multicore speaker cable 4 x 2.5 mm² - PVC
• fine stranded bare copper wires • flexible, but robust PVC jacket • ideal for winding on cable drums
LSC825PS
PUR
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/88c8053611ac2554dcfcd6c823bcc431.jpeg)
multicore speaker cable 8 x 2.5 mm² - PUR
• fine stranded bare copper wires • for mobile outdoor applications • low-temperature-flexible • abrasion-resistant • robust PUR jacket
LSC840PS
PUR
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/178a46d52f1743d168cd33d0c183b2ea.jpeg)
multicore speaker cable 8 x 4.0 mm² - PUR
• extra fine stranded bare copper wires • for mobile outdoor applications • low-temperature-flexible • abrasion-resistant • robust PUR jacket
LSC840XYS
PVC
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/295d450b1163b8957d7f320d197f6ad3.jpeg)
multicore speaker cable 8 x 4.0 mm² - PVC
• extremely resistant to repeated bending due to • extra fine stranded conductors acc. to VDE 0295, • class 6 (IEC 60228 cl.6) • extra thick PVC jacket
LSC440YS
PVC
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/92b55ae9d193a67467c4b0118717597b.jpeg)
multicore speaker cable 4 x 4.0 mm² - PVC
• extra fine stranded bare copper wires • flexible, but robust PVC jacket • ideal for winding on cable drums
LSC825YS
PVC
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/3aba0c5c3c9de95488d13e81fd4fd8b5.jpeg)
multicore speaker cable 8 x 2.5 mm² - PVC
• fine stranded bare copper wires • flexible, but robust PVC jacket • ideal for winding on cable drums
LSC840XYM
PVC
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/34763f88d72ab2a6649ee359bc7d956a.jpeg)
multicore speaker cable 8 x 4.0 mm² - PVC
• extremely resistant to repeated bending due to • extra fine stranded conductors acc. to VDE 0295, • class 6 (IEC 60228 cl.6) • extra tough and robust due to • extra thick PVC jacket • cold-resistant down to -40°C
LSC2440YS
PVC
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/044877c2a3a3138159e9c7745c89156a.jpeg)
multicore speaker cable 24 x 4.0 mm² - PVC
• for multi-amplifier systems • extremely resistant to repeated bending • due to extra fine stranded conductors • amd very short length of core twisting • textile braiding for increased tensile strength • low-temperature-flexible down to -40 °C
speaker
LYS425P
PUR
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/c94afd7c7cd10e9b31211797b19380b5.jpeg)
system speaker cable with sense wire 4 x 2.5 mm² + 1 x 0.5 mm² - PUR
• voltage feedback with 0.5 mm² sense wire • fine stranded bare copper wires • low-temperature-flexible and • abrasion-resistant, robust PUR jacket
SCY2025
PVC
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/459089ca0e870f85e912c2466c656e73.jpeg)
installation speaker cable - LHC 2 x 2.5 mm² - PVC
• extreme low heat of combustion (LHC) • by a tubular overall jacket • fine stranded bare copper wires
SCH2015-D
Dca
FRNC
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/655aef04efd4506abb200975a6735f0f.jpeg)
twinaxial speaker cable - LHC 2 x 1.5 mm² - FRNC - Dca
• extreme low heat of combustion (LHC) • by a tubular overall jacket • fine stranded bare copper wires • flame retardant and non corrosive (FRNC) • CPR class Dca
SCH4025-D
Dca FRNC
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/0387cf9c2ce4fff6a1ead85d6dea4c64.jpeg)
multicore speaker cable - LHC 4 x 2.5 mm² - FRNC - Dca
• extreme low heat of combustion (LHC) • by a tubular overall jacket • fine stranded bare copper wires • flame retardant and non corrosive (FRNC) • CPR class Dca
LYS440P
PUR
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/dac3abf445020e2040359d8af1442f6a.jpeg)
system speaker cable with sense wire 4 x 4.0 mm² + 1 x 0.5 mm² - PUR
• voltage feedback with 0.5 mm² sense wire • extra fine stranded bare copper wires • low-temperature-flexible and • abrasion-resistant, robust PUR jacket
SCY2040
PVC
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/3f864f4a2e1647ce74b5046749fdf583.jpeg)
installation speaker cable - LHC 2 x 4.0 mm² - PVC
• extreme low heat of combustion (LHC) • by a tubular overall jacket • fine stranded bare copper wires
SCH2025-D
Dca
FRNC
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/ae0d1960799404b8540eb660cf54899c.jpeg)
twinaxial speaker cable - LHC 2 x 2.5 mm² - FRNC - Dca
• extreme low heat of combustion (LHC) • by a tubular overall jacket • fine stranded bare copper wires • flame retardant and non corrosive (FRNC) • CPR class Dca
SCH8025-D
Dca
FRNC
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/6e73a6dcb389772a894eb5a5bb863672.jpeg)
multicore speaker cable - LHC 8 x 2.5 mm² - FRNC - Dca
• extreme low heat of combustion (LHC) • by a tubular overall jacket • fine stranded bare copper wires • flame retardant and non corrosive (FRNC) • CPR class Dca
speaker
SCH2040-D
Dca FRNC
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/4f49573b53e3aa707dfe62712a1186c8.jpeg)
twinaxial speaker cable - LHC 2 x 4.0 mm² - FRNC - Dca
• extreme low heat of combustion (LHC) • by a tubular overall jacket • fine stranded bare copper wires • flame retardant and non corrosive (FRNC) • CPR class Dca
SCH4040-D
Dca FRNC
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/1c3a30b71df9b082dfe5e3186ac34b1b.jpeg)
multicore speaker cable - LHC 4 x 4.0 mm² - FRNC - Dca
• extreme low heat of combustion (LHC) • by a tubular overall jacket • fine stranded bare copper wires • flame retardant and non corrosive (FRNC) • CPR class Dca
SCH4060-D
Dca
FRNC
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/04f40a4e0837db140b3c8d1e2a8d3dc9.jpeg)
multicore speaker cable - LHC 4 x 6.0 mm² - FRNC - Dca
• extreme low heat of combustion (LHC) • by a tubular overall jacket • fine stranded bare copper wires • flame retardant and non corrosive (FRNC) • CPR class Dca
SCFR2040
Dca
FRNC
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/99cea7b4ffe7b2b04b0a7895331d00cc.jpeg)
twinaxial speaker cable 2 x 4.0 mm² - FRNC - Dca
• round, pressure extruded jacket • extra fine stranded bare copper wires • flame retardant and non corrosive (FRNC) • CPR class Dca
SCH2060-D
Dca FRNC
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/ae3da77db5c26a11d0259957c7c64c64.jpeg)
twinaxial speaker cable - LHC 2 x 6.0 mm² - FRNC - Dca
• extreme low heat of combustion (LHC) • by a tubular overall jacket • fine stranded bare copper wires • flame retardant and non corrosive (FRNC) • CPR class Dca
SCH2100-E
Eca
FRNC
![](https://assets.isu.pub/document-structure/221102132951-9a2f579556df18e038b3c8f832b1d4b5/v1/c6bac1bf07951e7602576421fde87bd3.jpeg)
twinaxial speaker cable - LHC 2 x 10.0 mm² - FRNC - Eca
• extreme low heat of combustion (LHC) • by a tubular overall jacket • fine stranded bare copper wires • flame retardant and non corrosive (FRNC) • CPR class Eca
