PROJECT 01

ARCHITECTURAL SYSTEMS INTEGRATION 3.3

GFRC CSI SPECIFICATION SUMMARY (SECTION 03455)

MANUFACTURERS:

• Willis Construction Co.

• Stromberg Architectural Products

• GFRC Cladding

• TerraGlas

Other Materials From “Related Sections”:

• Architectural Precast Concrete - common for similar uses for cladding and wall products

• Masonry Veneer - another material like GFRC used primarily for exterior finishes/aesthetics and not for structural reasons

• Granite - another siding material for a different aesthetic than GFRC

• Structural Steel - can be used as the primary structure in which GFRC can attach to

Choices Needed to Make and Questions:

• In order to add color to the GFRC during mixing, I first must decide what color fits with the aesthetic of the building and environment, which also brings the question of how to find a color that not only is harmless to people or the product, but also fits within the context and concept of the building?

• It is more standard providing connection from GFRC to concrete or steel, but how do the connections work for attaching to mass timber so the same structural integrity is reached as in steel or concrete?

• Is it possible to use a light wood frame stud system for fabrication and erection rather than the specified steel stud welded frame to offer a more sustainable and low energy solution?

Project 01

ARCHITECTURAL SYSTEMS INTEGRATION 3.3

SECTION 03455 - Glass Fiber Reinforced Concrete (GFRC)

1. GENERAL 1.1 DESCRIPTION

A. Section Includes

1. Structural design and detailing of panels (products).

2. Plant fabrication of glass fiber reinforced concrete (GFRC) panels.

3. Transportation of GFRC panels to job site.

4. Installation (erection) of GFRC panels.

B. Related Documents The requirements of the General Conditions, Supplementary General Conditions and applicable portions of Division 1 of these Specifications as they apply to this Section.

C. Related Sections :

1. Section 03450 - Architectural Precast Concrete

2. Section 03300 - Cast-In-Place Concrete

3. Section 04255 - Masonry Veneer

4. Section 04455 - Marble

5. Section 04465 - Granite

6. Section 05120 - Structural Steel

7. Section 05500 - Metal Fabrications

8. Section 07210 - Building Insulation

9. Section 07270 - Firestopping

10. Section 07600 - Flashing and Sheet Metal

11. Section 07920 Sealants and Caulking

12. Section 08800 - Glazing

13. Section 09300 - Tile

1.2 REFERENCES

A. Uniform Building Code, 1997 Edition.

B. PCI MNL-128-01 GFRC Recommended Practice for Glass Fiber Reinforced Concrete Panels, Fourth Edition

C. PCI MNL-130 - Manual for Quality Control For Plants and Production of Glass Fiber Reinforced Concrete Products, Second Edition

D. AWS D1.1-98 : Structural Welding Code - Steel

E. AWS D1.3-89 Structural Welding Code - Sheet Steel

F. AWS D1.4-92 Structural Welding Code - Reinforcing Steel

G. ASTM A27 Steel Castings, Carbon, for General Application

H. ASTM A36 : Structural Steel

I. ASTM A47 Ferritic Malleable Iron Castings

J. ASTM A53 : Pipe, Steel, Black and Hot-Dipped, Zinc-Coated Welded and Seamless

K. ASTM A108 : Steel Bars, Carbon, Cold-Finished, Standard Quality

L. ASTM A123 : Zinc Coatings on Iron and Steel Products

M. ASTM A153 Zinc Coating (Hot-Dip) on Iron and Steel Hardware

N. ASTM A307 : Carbon Steel Bolts and Studs, 60,000 Tensile Strength

O. ASTM A325 Structural Bolts, Heat Treated, 120/105 ksi Minimum Tensile Strength

P. ASTM A446 : Steel Sheet, Zinc-Coated (Galvanized) by the Hot-Dip Process, Structural (Physical) Quality

Q. ASTM A449 Quenched and Tempered Steel Bolts and Studs

R. ASTM A496 : Steel Wire, Deformed, for Concrete Reinforcement

S. ASTM A500 : Cold-Formed Welded and Seamless Carbon Steel Structural Tubing in Rounds and Shapes

T. ASTM A513 : Electric-Resistance-Welded Carbon and Alloy Steel Mechanical Tubing

U. ASTM A525 : Sheet Steel, Zinc-Coated (Galvanized) by the Hot-Dip Process
