LEGEND OF THE PHOENIX

The Sweet Sounding Cry CONCEPTUALIZATION

The phoenix was a legendary bird connected with sun worship in ancient Egypt and Classical antiquity. The Egyptian phoenix was said to be the size of an eagle, with bright scarlet and gold plumage and a sweet-sounding cry. There was only one phoenix at any given period, and it lived for a very long time—no ancient source gave it a life span of less than 500 years. As its time came to pass, the phoenix built a nest of aromatic branches and spices, set it ablaze, and was consumed by the flames. After embalming its father’s ashes in an egg of myrrh, the phoenix flew with the ashes to Heliopolis (“City of the Sun”) in Egypt, where it deposited them on the altar in the temple of the Egyptian deity of the sun. According to one version of the tale, the dying phoenix flew to Heliopolis and immolated itself in the altar fire, from which the young phoenix rose. The Egyptians linked the phoenix to eternity, and this symbolism was popular in late antiquity. The phoenix was associated with eternal Rome, and it appears on late Roman Empire coinage as an emblem of the Eternal City. It was also widely understood as a metaphor of resurrection and life after death, which resonated with emergent Christianity. In Islamic mythology, the phoenix was associated with the “anqa” (Persian: smorgh), a huge mysterious bird (probably a heron) that was created by God with all perfections but later became a plague and was killed.

I will be creating a mechanism that can be attached to a source of light in order to create a reimagining of sort on the resurrection and life after death through referencing the immolated Phoenix in the altar fire, from which the young phoenix rose and began a new life. Upon completion, the mechanism would allow the user to extend or retract the “lamp shades” as they seem fit to hopefully create a unique visual experience.

Bibliography

Phoenix (no date) Encyclopædia Britannica. Encyclopædia Britannica, inc. Available at: https:// www.britannica.com/topic/ phoenix-mythological-bird (Accessed: March 22, 2023).

The curious symbolism of the Phoenix in literature and myth (2021) Interesting Literature. Available at: https://interestingliterature. com/2021/04/phoenix-symbolism-in-literature-and-myth/ (Accessed: March 22, 2023).

History of the City Bird (no date) City of Phoenix. Available at: https:// www.phoenix.gov/pio/ official-city-bird-logo/ history-of-the-city-bird#:~:text=The%20phoenix%20 bird%20symbolizes%20 immortality,associated%20 with%20the%20sun%20 god. (Accessed: March 22, 2023).

(“phoenix allegory flying over Egypt”)

(“The Egyptian phoenix the size of an eagle, with bright scarlet and gold plumage and a sweet sounding cry”)

All three images illustrate The phoenix burning itself to ashes after 500 years of living and emerges again having its youth restored.

1- [image obtained through the Manuscript of Physiologus “Bayerische Staatsbibliothek, Clm 6908 (Fürstenfelder Physiologus), folio 85r” Produced 14th century Munich, Germany].

2- The burning building could be a reference to one account of the story: A cleric at Heliopolis covers an altar with twigs in early spring. The phoenix arrives in town, sees the altar, starts a fire on it, and is consumed by it. [image obtained through the Manuscript of “Bestiaire of Guillaume le Clerc” Produced in France, end of the 13th century].

3- [image obtained through the Manuscript of “Aberdeen University Library, Univ. Lib. MS 24 (Aberdeen Bestiary), folio 56r” produced in England c 1200.

As the model is pulled upwards the double gear mechanism allows for the arms to open up and extend.

In addition to that as the model slides up, the tension created from the model being pulled away from the base allows the second part of the hand to extend due to the strings being attached to the base.

Explanation

In order to extend the arms of the model one must pull up on the handle to allow the gears to rotate and extend the arms out to its final form.

As the arms are being extended, the light in the middle of the form would begin to slowly reveal its self until it is fully exposed, releasing the light into its surroundings as a symbol of the phoenix being risen

Physical presentation of how the tension from the string allows the arm to extend when being pulled.

Once I made sure that the arms truly worked how I first imagined it I began on solidifying the design and tweaking it for a more reliable pull.

My model’s vision was created in the hopes of capturing the elegance and transformative power of fire through all of the tales told about the phoenix.

Explanation

As the model slides up and opens its arms to allow the light to escape and shine through the fabrics, it shows as if the phoenix has risen from its ashes to begin a new existence full of promise.

It represents hope and resilience in the face of adversity, as it cycles through life and transformation, teaching us to accept change, let go of the past, and have confidence in the future.

PHISICAL STILL VARIANTS (VISION)

Mechanical Outcome

The overall torque or the arms would ultimately end up breaking the handle where all the parts would connect to one another. The only work around that found works is having only one arm attached to the handle as the stress points would only occur in one spot rather than four which resulted in a working representation of how the model would work if made in a stronger material.

WORKING MODEL VARIANT (MECHANICAL)

Design Concept

Light source would create a diamond like appearance once lit resembling the burning and rebirth transformative power of fire.

As the model lifts its arms and spreads them, the light permeates through the fabrics, giving an impression of a phoenix emerging from the ashes, ready to start a new life filled with hope and potential.

The dazzling display can evoke feelings of joy, excitement, and wonder, as people are drawn to the radiant light and stunning beauty of its display. It would also allow for the people to have the sense of hope and resilience that the phoenix had once accomplished through the various iterations throughout history.

Assembly stages

Light Source

The diamond reflections creates a stunning and dazzling display of colour and brilliance. The light bounces off the multiple facets of the diamond facade, creating a unique and mesmerizing visual effect. This reflection can transform the appearance of the room it is placed in, enhancing its natural beauty and creating a stunning display of light and colour.

The design comes in two variants, variant one is a portable lamp that could be moved around and placed in any room/scenario the individual pleases. While the second variant is more of a permanent feature in a room where the design is scaled up and is placed into the ceiling to create the stunning visual effects of the product to showcase in its fullest potential.

Mechanical motor that allows for the individual to dim or lighten the room by either retracting or extending the arms to control the amount of light passes through the fabrics.

A rope of sort would be connected to the motor and is responsible for the arms to move up or down to control the dimming.

Lastly upon turning off the lights, the form would automatically close up and retract in. while on the other hand when the lights turn on the form would extend and reveal its self as it brightens the room with its dazzling display.

Electrical Components

Overall if I am being honest the starting point might have messed me up a bit, instead of creating and experimenting with different ways of creating a muscle, skin, and bone movement I ended up rushing into a final form from the very start and ended up creating the model and figure out its mechanism in a very short amount of time as I have misunderstood the assignment.

I ended up following the example posters posted up on canvas not knowing that the posters represented how our finals would look like in the end of the semester and not how they would turn out at the end of week 4. This resulted in me having very little to show for the second part of the project as I have basically showed everything there is to show in the first part due to rushing into things and misunderstanding the task at hand.

Additionally, regarding my physical model. The results of my final physical model happened to be underwhelming to say the least. Having to 3D print the model might not have been the best idea as some of the thin layers would end up being too brittle which resulted in those spots to break easily.

The overall torque or the arms would ultimately end up breaking the handle where all the parts would connect to one another, The only work around that I found works is having only one arm attached to the handle as the stress points would only occur in one spot rather than four which resulted in a working representation of how the model would work if made in a stronger material.

All things considered I have learned some valuable lessons throughout this unit, and it was nice to experience what goes through the mechanical side of design rather than only focusing on the aesthetics parts of it.
