S.W.O.T Analysis

SITE A

• The melange of modern and historic buildings can provide a unique and visually interesting streetscape, as well as preserving the historical character of the new incorporating and area developments.

• The river Taff flowing through the site can be a valuable asset, providing scenic views and enhancing the overall aesthetic appeal of the area.

• The site also has a good functional mix of live, work, visit all across the site.

(Dovey and Pafka 2018) • The site also has the rail lines running across the site which acts as a central point and easily accessible to the entire site. It can also act as a central point for transportation, facilitating accessibility to improving and different areas connectivity.

• The presence of pedestrian-only streets can be a positive factor for the site, promoting walkability, reducing vehicular traffic, and creating a pedestrian-friendly environment.

• Large blocks can restrict permeability, it is more difficult for people to walk or bike between different areas of the site. This can be a result of the large lot sizes that are characteristic of the site, which can create a more spread-out and disconnected layout, with fewer connections between different areas of the site.

• Minimal cycling lane can also limit the options of transportation for cycling enthusiasts and those who prefer to cycle as a mode of transportation.

• Minimal connectivity of bridges can also be an issue, this can create barriers to accessibility and make it more difficult for people to walk or bike across the river and railway line, which can be a major physical division of the site.

• Poor sidewalks and lack of maintenance can be a significant issue that affects the accessibility, safety, and overall walkability of the site.

• Creating urban spaces on the river can also improve the ecological balance of the river. The Urban spaces on the river can help to mitigate the effects of flooding.

The development of urban spaces along the river can also provide opportunities for residents.

• The site presents a promising opportunity to incorporate bike lanes alongside the roads, as the roads are spacious enough to accommodate pedestrians, cyclists, and cars.

• The old historic buildings in the site are still in use, which is a great example of adaptive reuse and retaining the architectural history of the place intact.

• Urban crime in the site can also be a problem for the social life, as it can create a sense of insecurity and fear among residents and visitors. It can also negatively impact the overall liveability and desirability of the area, as well as discourage investment and economic development.

• Due to the possibility of sea levels rising, the landscape alongside the river banks is vulnerable to flooding.

• Dilapidation of historic buildings is a major threat to the site and its identity, as it can lead to the loss of important cultural and architectural heritage.

• The new developments do bring in more density to the population of the area but it also includes on deteriorating the architectural context of the city.

STRATEGIC DESIGN FRAMEWORK VISION

Stimulating the flow of connectivity by increasing the porosity in the city which integrates the mental health into Urban Design, change of a city brings shape to its users.

OBJECTIVES

• Porosity in urban design refers to the degree to which a city is permeable, or open to the flow of people. Increasing porosity in a city can help to stimulate networks of connectivity by making it easier for people to move around and interact with one another.

• Integrating mental health into urban design is an important consideration, as the built environment can have a significant impact on people's mental well-being. This can be achieved by designing spaces that are safe, accessible, and welcoming to all, and by providing access to green spaces and natural light.

• Also, to promote social interaction, by designing spaces that are conducive to meeting and spending time with others, such as community gardens, playgrounds, and plazas. This can help to create a sense of community and belonging, which can have a positive act on mental health.

• A change in a city can have a significant impact on the way its residents and visitors use and interact with the urban environment. This can include changes to transportation systems, the development of new buildings or public spaces, or the introduction of new technology and services.

These changes can shape the way people move through the city, the way they access goods and services, and the way they experience and engage with their surroundings. It can also have an impact on the social and cultural dynamics of the city, influencing the way different groups of people interact and coexist.

STRATEGIC DESIGN FRAMEWORK SITE A

<<<

C

<<<

Creating new connectivity's and social spaces across large blocks in the Brains brewery site.

\

Creating pedestrian pathways and landscape across the river front .

utilising the

Activating the existing spaces across the site, to make it safer for pedestrians.

V

<<············

[

D

Enhancing existing connectivity mainly in the underpasses which is rarely used and underlit.

F The main challenge is to connect the spaces across the rail lines to make it more permeable.

Providing activity on the site with strong enclosure and frontages.

The strategic design framework creates a visual and facile understanding of the design and helps us to interrelate with the S.W.0.T analysis, the design strategies proposed are related to the S.W.0.T analysis of the site, by using these strategies the design creates and improves the existing quality of life in the site. This will create enhanced connectivity, make use of the existing landscape of the site, activate spaces, and stimulate the pedestrian flow across the site.
