KALPAK KALA Manoj Kala and Associates | Architecture Internship Portfolio | Selected Works | 2020-2022
ARHAM URBANIA- VIYAAN ANANTA - BOMBAY HEIGHTS - ABK AURIX 3 and 4 BHK apartments | 4.5 acres Masterplan | Commercial complex
20th July 2020
Alongside his interest, enthusiasm and application to the coursework I found Kalpak to be an attentive, good natured and polite student. At every stage of the year under my teaching and also with my colleagues he strove to push him self, his intellectual approach and his architectural design output to the highest level. He participated fully in various group enterprises such as our field trip to KalpakVenice
I have been asked by Mr Kalpak Kala to provide a reference in support of his application to work as an architectural assistant following completion of his Bachelor Degree at the Liverpool School of Architecture. I am a part time tutor (university teacher) at the school of architecture, teaching in the third year of the Architecture BA (Hons) course. I have been in this position for 15 years. I am also a practicing architect, being Partner at the Manchester, UK, studio of Sheppard Robson LLP.
With my colleagues, I taught Kalpak during the 2019- 20 academic year. Specifically, I was his lead studio design tutor for both semesters. He is a thoughtful, talented and hard working student who took his studies seriously, applying him self diligently in terms of design production and in intellectual striving. His work demonstrated diligent and thoughtful design and execution, which was recognised in his receipt of an upper second class honours degree.
is hard working and very careful to listen to advice and direction, taking care to understand precisely what has been asked of him before he begins a task. I have no hesitation in recommending him , confident that he has the requisite skills, aptitude, dedication, curiosity and enthusiasm to make a great success of work in architectural practice Yours
To whom it may concern, Reference for Mr Kalpak Kala
james.jones@sheppardrobson.comJ.Jones@liverpool.ac.ukJamesfaithfully,JonesRIBA
ARHAM URBANIA Spring 2021- 120 Residential Apartments Scheme Manoj Kala and Associates
13001150 4000 48003100 3000 1800 2400 4500 3350 1500 1200 2400 150018002500 D2
4000 4800 3100 3000 1800 2400 4500 3350 1500 2400 1500 250018001100
3600 36003100 4800 4000 3350 1800 4500 3100 1500 2400 3000 3600
24003500 5400
FOYERBALDONY
TOILETBEDROOM
DRESS.TOI.
36001650 705024004550 3600 2400 25001100 2400 1300
ROOMLIVING FOYERBALDONY
BALCONYFOYER
3600 360031003600 1300 2400
DRESS. LIVINGROOM
EXISTING6M WIDEROAD A BEDROOM BEDROOMBEDROOMKITCHEN LIVINGROOMFOYERDINING BALCONY UTILITY TOI. DRESS.TOI. LIVINGROOM DINING BEDROOM DRESS.TOI. TOI.FOYERBALCONY SITOUTBEDROOM TOILETBEDROOM UTILITY BALCONY 36001650 705024004550 1150 3600 2400 25001100 1300 3600 36003100 4800 4000 3350 1800 4500 3100 1200 1500 2400 3000 3600 1650 24003500 5400 1150 3600 3600310036001150 1300 1150 4000 4800 3100 3000 1800 2400 4500 3350 1500 1200 2400 1500 250018001100 BEDROOMBEDROOMBEDROOMKITCHEN ROOMLIVING DININGFOYERBALCONY UTILITY TOI. DRESS.TOI. LIVINGROOM DINING BEDROOM DRESS.TOI.TOI.BEDROOMSITOUT BEDROOMTOILET UTILITY BALCONY 3600 1650 7050 2400455011503600 24002500 1300 360036003100 4800 4000 3350 18004500 31001200 1500 2400 3000 3600 1650 350024005400 11503600 36003100 3600 1150 WING BEDROOM BEDROOMBEDROOMKITDHEN LIVINGROOMFOYER BALDONY UTILITY TOI. TOI. TOI. DRESS. LIVINGROOM KITDHENDINING BEDROOM TOI. SITOUTBEDROOM UTILITY BALDONY 1150 1150 1650 1150 1150 BEDROOMBEDROOMBEDROOMKITDHENUTILITY TOI. TOI. KITDHEN
3900 3300 3900 3300 2950 2950 1650LOBBY2800275450 1588 275158819251500 1500 1500 34503450450 2800 3450 UP DN 3100
DINING BEDROOM DRESS.TOI.TOI. BALDONYFOYERBEDROOMSITOUT BEDROOMTOILET UTILITY BALDONY 3600 1650 7050 240045503600 24002500 2400 1300 11501150 360036003100 4800 4000 3350 18004500 3100 1500 2400 3000 3600 1650 350024005400 11503600 36003100 3600 130024001150 4000 48003100 3000 1800 2400 4500 3350 1500 2400 150018002500 LOBBY1550450275 1588 275158819251500 34503450 2800 3450 1500 450 UPDN D1 WING 3900 3300 3900 2950 2950 3100 1650 2800 BEDROOM BEDROOMBEDROOMKITCHENLIVINGROOMDININGFOYER BALCONYUTILITYTOI. TOI. TOI. DRESS. LIVINGROOM KITCHEN DINING BEDROOM DRESS. TOI. TOI. BALCONY FOYER BEDROOMSITOUT TOILET BEDROOM UTILITY BALCONY 3600 1650 70504550 2400 1150 3600 2400 2500 1100 2400 1300 1150 1150 3600 3100 3600 4800 4000 3400 1800 45003100 1200 1500 2400 3000 3600 1650 3500 2400 5400 1150 3600 3600 3100 3600 1150 1300 2400 1150 4000 4800 3100 300018002400 4500 3400 1500 1200 24001500 1800 1100 2500 BEDROOM BEDROOMBEDROOMKITCHEN LIVINGROOMDINING FOYER BALCONY UTILITY TOI. TOI. TOI. KITCHENDRESS.LIVINGROOM DINING BEDROOM TOI.DRESS. TOI. BALCONYBEDROOMSITOUTFOYER TOILETBEDROOM3600UTILITYBALCONY 16507050 4550 2400 1150 3600 24002500 1100 2400 1300 1150 1150 3600 3100 3600 4800 4000 3400 1800 4500 3100 1200 1500 2400 3000 3600 16503500 2400 5400 1150 3600 3600 3100 3600 1150 1300 2400 1150 4000 4800 3100 3000 1800 2400 4500 3400 1500 1200 2400 1500 1800 1100 2500 3900 3300 3900 3300 2950 2950C1WING BEDROOM BEDROOM KITCHENBEDROOM DINING TOI. TOI. TOI. LIVING FOYER TOI./DRESS.BEDROOM DRESS. BALCONY UTILITYBALCONY 3500 1800 3750 3500 41501500 1800 2400 1500 4500 3400 31002550 5000 4800 3600 2950 3600 3600 1150 36005250 16502750 2400 16502400 1500 115011501150 240036501100 1600 1500 4501500LIFT LIFTLOBBY16502800 1550 2375 1200 1588 2751588 1500 3450 1925 UP DN 1950 BEDROOM BEDROOMBEDROOMTOI. TOI. TOI. DINING LIVINGKITCHEN FOYER 27501650DRESS.2400 52503600 1150 3600 2400 3600 295036001100 15002400 1150 1150 5000 1800 2400 4500 1800 3400 1500 3100 4800 2550 BEDROOM1200 BEDROOMBEDROOM TOI. TOI. DININGTOI. KITCHEN LIVING FOYER 2750DRESS.1650 2400 3600 5250 1150 36002400 3600 2950 3600 110024001500 1150 1150 180050002400 4500 1800 3400 15003100 4800 25501200 UTILITY UTILITY BALCONY BALCONY C2WING 1550LOBBY 275 450 1588 27515881500 34501925 3450 2800 3450 1500 1500450 DN 3100 28001650LIFT B B LIFT THIS DRAWING IS COPYRIGHT, IT IS THE PROPERTY OF MANOJ KALA AND ASSOCIATES AND IT IS NOT TO BE USED FOR ANY PURPOSE / PROJECT OTHER THAN THAT FOR WHICH IT HAS BEEN ISSUED. CLIENT FOR STUDY MANOJARCHITECT:KALA AND ASSOCIATES ALTIUS - B - 301, 3RD FLOOR, SPACE OLYMPIA, GARKHEDA, AURANGABAD. PH. 0240-2983780, 2983781. e-mail: manojkala@auracreators.inMUGDIYAFOR- GROUP DRAWN KALPAKBY:KALACHECKEDBY:SHIVANIJ. NRESIDENTIAL APPARTMENT , GARKHEDA PARISAR, AURANGABAD.CHECKED BY: MK TYPICAL FLOOR PLAN ARHAM URBANIA Status- Under Construction Grand Public Launch on 15 October 2021, 16 October 2021- 44/120 Apartments Sold Out
TOI.
ARHAM URBANIA
Indian temples are a marvellous feat of rock-cut architecture with a prominent feature of rhythmic patterns rising from the earth towards the sky in temple architecture. This physical and metaphorical aura was the drawing inspiration for the elevation of the project. The colonnade rise from the ground later bends and blend with the beam bands wrapping up the complete building.
The beam bands further extend inwards and completely wrap up the building
Beams of the balcony are merged and extended towards the edges
Arham Urbania is a 120-apartments residential scheme with about 300,000 sq ft area. It is located in the heart of Aurangabad near Gajanan Maharaj Mandir (Temple). I was responsible for developing form-giving elevations for the project with a strict condition, not making changes in the floor plan and structural detailing. Therefore, the task was to produce the best form within a limited frame. I was also closely involved in developing brochures, choosing appropriate viewpoints for marketing renders and landscape designing for creating an impactful synergy.
The colonnade rise from the ground before shops, bend before gym on the first floor and merge with the beam bands
VIYAAN ANANTA Spring 2020- 4.5 Acres Group Housing Masterplan Manoj Kala and Associates | Under Construction
GOVT POLICIES ECONOMICFACTORSTAXEXEMPTION SITEEXISITINGCONDITIONS SOCIAL AND CULTURAL REASONS 4.5 AFFORDABLEACRESHOUSINGDEVELOPMENT2BHK and 3BHK Row Houses demand according to market survey 30m Control Line from Railway BoundryMHADAHousingandAreaDevelopmentAct ApproachRoadWidth Removalof‘NotsoNecessary’architecturalfeaturesandHousesRowMaximum apartmentsbybreakthroughArea Phasedevelopmentdependinguponmarketresponse Tax Bene�its for units below 90 sq m area TaxBene�itsforplotarea/unit below60sqm1%GoodsandServicesTaxforunitsizebelow90sqm MerginingInternalRoadwithexistingroadfabricofthecity DPRoadCuttingDevelpomentofwells,borewellsSTPandTransformer VaastuShastraComplientHouses Integrationofdifferentpeoplethroughamenityandopenspacedevelopment (PradhaanBene�itofRs1.5lakhunderPMAYMantriAawazYojna) VISION AND CHALLENGES Viyaan Ananta is a 4.5 acres Masterplan visioned to serve quality life for roughly 1200 people! It has 89-row houses and 168 apartments masterplan. It provides amenities like a temple, two clubhouses with an indoor gymnasium, basketball court, turf, skating rink, lawn tennis court, volleyball court and vegetated recreational areas. Alongside adding multifunction spaces; consideration of Government Policies, Economic Factors, Tax Exemption Schemes and Socio-cultural factors played a critical role in the development of the scheme. I chose an integrated approach towards factors influencing the design is crucial to achieving a highly desirable product that is developed in the best interest of all parties; customers, developers, architects and other members involved.
Idiosyncratic nature of people expressing their favourite colours on their terrace house while respecting the neighbours (Left)
IDIOSYNCRATIC ARCHITECTURE
After World War 2, the UK had faced a massive housing crisis. The government had to incentivise huge housing developments for its citizen. Similarly, the Indian government today is incentivising developers for developing housing schemes. For the housing development proposal of Carnatic Halls, I was able to analyse how people responded to such developments collectively and individually over some time. Interestingly, people expressed beautifully by decorating their houses to their favourite colours whilst respecting their neighbours dwelling architectural elements like the roof and windows stayed intact over some time. This observation throughout the time helped me imagine future possibilities of changes to our proposal and the form of the structure. I proposed to emphasise elements that don’t change like roof and sharing wall as the boundary; dividing and defining the shape of each row house. The form is such that celebrates the transition and repetitiveness of row houses. By this approach, the architectural form of this group housing is intact in the long run while owners are flexible to beautify their dwelling as per their convenience and interests.
FOR STUDY
VIYAAN ANANTA Status- Under Construction 19 bookings for G block apartments before public release
BOMBAY HEIGHTS Spring 2021- Commercial Complex Manoj Kala and Associates | Under Submission
BOMBAY TOWER Status- Under Construction Front Facing showrooms and offices Sold out on renders
Bombay Heights is an 80,000 sq ft commercial complex developed by Shashwat group on Beed ByPass, Aurangabad. It is an nine-storey high, proposed to target middle-income group investors.
Contrast is one of the most striking observations humans experience. The perforations in Jali don’t only create fascinating daylight patterns but also protect building users from harsh afternoon southern sunlight. Till this age, perforated pattern’s were only characteristic of the day but today, through modern technology, they can be reimagined differently.
The light glowing through Jali Pattern in the evening can become a unique characteristic to the form of the building.
The texture, colours and rhythms of feathers were drawing inspiration for the facade. Image Source- Google
BOMBAY HEIGHTS
Variations and intricate detailing of Jali inspired by the feathers
ABK AURIX Spring 2022- Mixed Used Development Manoj Kala and Associates | Under Construction
ABK AURIX Status- Under Construction Front Facing showrooms and offices Sold out on renders
