Kaitlyn Lumel
Cal Poly Pomona Architecture
2021-2023
Contents
Mixed-Use Housing
Spring 2023 Cal Poly Pomona
Mount Wilson Scientist Retreat
Fall 2022 Cal Poly Pomona
Museum of Contemporary Japanese Art
Fall 2021 Cal Poly Pomona
Mixed-Use Housing | Scott Parker | Spring 2023
Mixed-Use Housing
Third Year Studio | Scott Parker | Spring 2023
This project encompasses designing multi-family mixed-use housing located in Santa Ana across from the Transportation Center and near the downtown district. Civic indoor and outdoor spaces were to be incorporated as well as retail space. Configuring parking was also part of this project with Pointsetta Street being the only surrounding road with vehicle access, which resulted in parking merging with a ground floor park with shading and mural walls so parking is not visible from the street. The mixed-use housing project incorporates a symmetric u-shape form that guides circulation throughout. The form pushes in and out on the exterior sides, allowing for cantilevered balconies to pop out. The facade is corrugated metal panels with the unit’s guardrails being glass and all other guardrails being perforated mesh. The windows have bi-fold perforated mesh panels for the residents to minimize or maximize natural lighting. Residents can feel a sense of community as they navigate to their unit but also experience privacy through street-facing balconies. To prevent the pathways leading to the units feeling like corridors, the pathways are widened through slight zig-zag angles that incorporate secluded areas with benches, tables, and plants as well as help break up the form’s symmetry. Stairs lead up to the third floor park that residents and the community can enjoy. Alongside those stairs are auditorium style stairs used as gathering and social spaces. Retail and event space fill the center of the ground floor, creating that u-shape circulation that is seen throughout.
Mixed-Use Housing | Scott Parker | Spring 2023
Mixed-Use Housing | Scott Parker | Spring 2023 N SANTIAGO ST POINTSETTA ST BROWN ST SITE PLAN E 6TH ST B A D C 0 10 20 40 80
Mixed-Use Housing | Scott Parker | Spring
A200 A201 A200 A201 C. 1 1 1 3 3 4 4 5 5 7 7 G G F F E E D D C C H H I I B B A A 2 2 6 6 8 8 9 9 11 11 10 10 1250 SF. 1250 SF. 1760 SF. 200 SF. MEN'S RR. 420 SF. 740 SF. GYM A400 6. 186' 10" 30' 0"� 30' 0" 8' 0" 175' 3" 20' 9" 27' 10" 0"� 27' 10" 32' 2" 126' 10" 8' 0" 29' 6" 30' 0" 27' 10" 20' 0"� 44' 0"� 28' 0" 12' 0"� 43' 5" 20' 8" 27' 10" 2. A300 1 GROUND FLOOR PLAN 0 5 10 20 40 A200 A. A201 A200 A201 C. 1 A300 1 1 3 3 4 4 5 5 7 7 G G F F E E D D C C H H I I B B A A 2 2 6 6 8 8 9 9 11 11 10 10 1 A310 A400 5. 750 SF. LW. 750 SF. LW. 0"� 0"� 0"� 223' 10" 186' 10" 30' 0"� 30' 0" 8' 0" 175' 3" 20' 9" 27' 10" 0"� 27' 10" 32' 2" 126' 10" 29' 11" 29' 6" 8' 0" A300 CPP B.Arch: 2025 Kellog Drive Pomona, CA 97168 REVISION SCHEDULE 610 N SANTIAGO ST A111 SECOND FLOOR PLAN 2 SECOND FLOOR PLAN SHEET NOTES REFER TO SHEET G101 FOR GRAPHIC SYMBOLS, ABBREVIATIONS, AND GENERAL NOTES REFER TO SHEET A105 FOR EGRESS AND CODE ANALYSIS REFER TO SHEET A400 FOR ENLARGED UNIT PLANS REFER TO SHEETS A501 & A502 FOR WALL AND FLOOR ASSEMBLIES REFER TO SHEET A503 FOR DRAINAGE REFER TO SHEET A600 FOR DOOR AND WINDOW TYPES SITE FURNISHINGS SHALL NOT BE LOCATED IN THE EXIT PATHWAYS AND SHALL NOT BLOCK EXIT DOORS OR FIRE DEPARTMENT ACCESS DIMENSIONS ARE TO CENTERLINE OF COLUMN, FACE OF STUD, FACE OF CONCRETE, OR FACE OF MASONRY, UNLESS NOTED OTHERWISE MEANS OF EGRESS AND EXIT DISCHARGE SHALL BE ILLUMINATED AT ANY TIME THE BUILDING IS OCCUPIED WITH A LIGHT INTENSITY OF NO LESS THAN 1 FOOT CANDLE AT THE WALKING SURFACE LEVEL PER GOVERNING CODE REQUIREMENTS WALKING SURFACES OF THE MEANS OF EGRESS SHALL HAVE A SLIPRESISTENT SURFACE AND BE SECURELY ATTACHED GROUND AND FLOOR SURFACES ALONG ACCESSIBLE ROUTES AND IN ACCESSIBLE ROOMS AND SPACES, INCLUDING FLOORS, WALKS, RAMPS, STAIRS, AND CURB RAMPS SHALL BE STABLE, FIRM, AND SLIP-RESISTENT ANY DISCREPANCIES NOTED SHALL BE BROUGHT TO THE ATTENTION OF THE ARCHITECT FOR CLARIFICATION PRIOR TO BEGINNING WORK ALL STRUCTURAL, PLUMBING, MECHANICAL, AND ELECTRICAL INFORMATION SHOWN ON SHEETS P101, M101, & E101 IS FOR REFERENCE ONLY. REFER TO CONSULTANTS DRAWINGS PREPARED BY THE ENGINEER & CONTRACTOR TO VERIFY ANY DISCREPANCIES WITH THE ARCHITECT PRIOR TO BEGINNING WORK APPROVED SET OF PLANS FOR BUILDING, FIRE SPRINKLER, FIRE ALARM, ETC. SHALL BE ON THE JOB SITE DURING CONSTRUCTION AND NO INSPECTIONS WILL BE MADE WITHOUT COMPLIANCE WITH THE ABOVE PROVISION ALL CIVIL AND LANDSCAPE INFORMATION SHOWN ON THIS SHEET IS FOR REFERENCE ONLY ALL FURNITURE, FIXTURES, AND FINISHES DEPICTED AT LEASING AND AMENITY AREAS ARE SHOWN FOR REFERENCE ONLY ALL EXTERIOR EXIT DOORS PROVIDE 5'0'' X 5'0'' MINIMUM LEVEL LANDING WITH 2% MAXIMUM SLOPE IN BOTH DIRECTIONS PORTABLE FIRE EXTINGUISERS SHALL BE INSTALLED IN LOCATION AS REQUIRED PER GOVERNING CODE REQUIREMENTS No. Description Date 0 5 10 20 40
2023
Mixed-Use Housing | Scott Parker | Spring 2023
Mixed-Use Housing | Scott Parker | Spring 2023
A200 A201 A200 A201 C. 1 1 I I A A 11 11 1 630 SF 1050 SF. STUDIO STUDIO 8' 0" 19' 10" 20' 0"� 44' 0"� 28' 0" 12' 0"� 44' 0" 20' 0"� 19' 10" 8' 4" 186' 11" 8' 0" 26' 5" 33' 6" 29' 0" 26' 0" 24' 10" 21' 0" 19' 5" 36' 0" 8' 4" 19' 5" 41' 5" 32' 7" 26' 0" 8' 0" 2. A300 SEAT CPP B.Arch: 2025 Kellog Drive Pomona, CA 97168 REVISION SCHEDULE 610 N SANTIAGO ST A112 THIRD FLOOR PLAN 3 THIRD FLOOR PLAN SHEET NOTES REFER TO SHEET G101 FOR GRAPHIC SYMBOLS, ABBREVIATIONS, AND GENERAL NOTES REFER TO SHEET A105 FOR EGRESS AND CODE ANALYSIS REFER TO SHEET A400 FOR ENLARGED UNIT PLANS REFER TO SHEETS A501 & A502 FOR WALL AND FLOOR ASSEMBLIES REFER TO SHEET A503 FOR DRAINAGE REFER TO SHEET A600 FOR DOOR AND WINDOW TYPES SITE FURNISHINGS SHALL NOT BE LOCATED IN THE EXIT PATHWAYS AND SHALL NOT BLOCK EXIT DOORS OR FIRE DEPARTMENT ACCESS DIMENSIONS ARE TO CENTERLINE OF COLUMN, FACE OF STUD, FACE OF CONCRETE, OR FACE OF MASONRY, UNLESS NOTED OTHERWISE MEANS OF EGRESS AND EXIT DISCHARGE SHALL BE ILLUMINATED AT ANY TIME THE BUILDING IS OCCUPIED WITH A LIGHT INTENSITY OF NO LESS THAN 1 FOOT CANDLE AT THE WALKING SURFACE LEVEL PER GOVERNING CODE REQUIREMENTS WALKING SURFACES OF THE MEANS OF EGRESS SHALL HAVE A SLIPRESISTENT SURFACE AND BE SECURELY ATTACHED GROUND AND FLOOR SURFACES ALONG ACCESSIBLE ROUTES AND IN ACCESSIBLE ROOMS AND SPACES, INCLUDING FLOORS, WALKS, RAMPS, STAIRS, AND CURB RAMPS SHALL BE STABLE, FIRM, AND SLIP-RESISTENT ANY DISCREPANCIES NOTED SHALL BE BROUGHT TO THE ATTENTION OF THE ARCHITECT FOR CLARIFICATION PRIOR TO BEGINNING WORK ALL STRUCTURAL, PLUMBING, MECHANICAL, AND ELECTRICAL INFORMATION SHOWN ON SHEETS P101, M101, & E101 IS FOR REFERENCE ONLY. REFER TO CONSULTANTS DRAWINGS PREPARED BY THE ENGINEER & CONTRACTOR TO VERIFY ANY DISCREPANCIES WITH THE ARCHITECT PRIOR TO BEGINNING WORK APPROVED SET OF PLANS FOR BUILDING, FIRE SPRINKLER, FIRE ALARM, ETC. SHALL BE ON THE JOB SITE DURING CONSTRUCTION AND NO INSPECTIONS WILL BE MADE WITHOUT COMPLIANCE WITH THE ABOVE PROVISION ALL CIVIL AND LANDSCAPE INFORMATION SHOWN ON THIS SHEET IS FOR REFERENCE ONLY ALL FURNITURE, FIXTURES, AND FINISHES DEPICTED AT LEASING AND AMENITY AREAS ARE SHOWN FOR REFERENCE ONLY ALL EXTERIOR EXIT DOORS PROVIDE 5'0'' X 5'0'' MINIMUM LEVEL LANDING WITH 2% MAXIMUM SLOPE IN BOTH DIRECTIONS PORTABLE FIRE EXTINGUISERS SHALL BE INSTALLED IN LOCATION AS REQUIRED PER GOVERNING CODE REQUIREMENTS No. Description Date 0 5 10 20 40 A200 A201 A200 A201 C. 1 1 1 I I A A 11 11 1 ONE BD. 460 SF. STUDIO 460 SF. A400 0"� 207' 10" 33' 6" 26' 6" 8' 0"� 187' 0" 29' 0" 33' 0" 26' 5" 12' 0" 19' 10" 8' 3" 19' 6" 40' 7" 26' 5" 33' 0" 8' 0" 36' 0"� 2. A300 CPP B.Arch: 2025 Kellog Drive Pomona, CA 97168 REVISION SCHEDULE 610 N SANTIAGO ST A113 FOURTH FLOOR PLAN 4 FOURTH FLOOR PLAN SHEET NOTES REFER TO SHEET G101 FOR GRAPHIC SYMBOLS, ABBREVIATIONS, AND GENERAL NOTES REFER TO SHEET A105 FOR EGRESS AND CODE ANALYSIS REFER TO SHEET A400 FOR ENLARGED UNIT PLANS REFER TO SHEETS A501 & A502 FOR WALL AND FLOOR ASSEMBLIES REFER TO SHEET A503 FOR DRAINAGE REFER TO SHEET A600 FOR DOOR AND WINDOW TYPES SITE FURNISHINGS SHALL NOT BE LOCATED IN THE EXIT PATHWAYS AND SHALL NOT BLOCK EXIT DOORS OR FIRE DEPARTMENT ACCESS DIMENSIONS ARE TO CENTERLINE OF COLUMN, FACE OF STUD, FACE OF CONCRETE, OR FACE OF MASONRY, UNLESS NOTED OTHERWISE MEANS OF EGRESS AND EXIT DISCHARGE SHALL BE ILLUMINATED AT ANY TIME THE BUILDING IS OCCUPIED WITH A LIGHT INTENSITY OF NO LESS THAN 1 FOOT CANDLE AT THE WALKING SURFACE LEVEL PER GOVERNING CODE REQUIREMENTS WALKING SURFACES OF THE MEANS OF EGRESS SHALL HAVE A SLIPRESISTENT SURFACE AND BE SECURELY ATTACHED GROUND AND FLOOR SURFACES ALONG ACCESSIBLE ROUTES AND IN ACCESSIBLE ROOMS AND SPACES, INCLUDING FLOORS, WALKS, RAMPS, STAIRS, AND CURB RAMPS SHALL BE STABLE, FIRM, AND SLIP-RESISTENT ANY DISCREPANCIES NOTED SHALL BE BROUGHT TO THE ATTENTION OF THE ARCHITECT FOR CLARIFICATION PRIOR TO BEGINNING WORK ALL STRUCTURAL, PLUMBING, MECHANICAL, AND ELECTRICAL INFORMATION SHOWN ON SHEETS P101, M101, & E101 IS FOR REFERENCE ONLY. REFER TO CONSULTANTS DRAWINGS PREPARED BY THE ENGINEER & CONTRACTOR TO VERIFY ANY DISCREPANCIES WITH THE ARCHITECT PRIOR TO BEGINNING WORK APPROVED SET OF PLANS FOR BUILDING, FIRE SPRINKLER, FIRE ALARM, ETC. SHALL BE ON THE JOB SITE DURING CONSTRUCTION AND NO INSPECTIONS WILL BE MADE WITHOUT COMPLIANCE WITH THE ABOVE PROVISION ALL CIVIL AND LANDSCAPE INFORMATION SHOWN ON THIS SHEET IS FOR REFERENCE ONLY ALL FURNITURE, FIXTURES, AND FINISHES DEPICTED AT LEASING AND AMENITY AREAS ARE SHOWN FOR REFERENCE ONLY ALL EXTERIOR EXIT DOORS PROVIDE 5'0'' X 5'0'' MINIMUM LEVEL LANDING WITH 2% MAXIMUM SLOPE IN BOTH DIRECTIONS PORTABLE FIRE EXTINGUISERS SHALL BE INSTALLED IN LOCATION AS REQUIRED PER GOVERNING CODE REQUIREMENTS No. Description Date 0 5 10 20 40
Mixed-Use Housing | Scott Parker | Spring 2023
SEAT BATHROOM KITCHEN DINING RM. BEDROOM STOR. CL. LIVING RM. PATIO CL. 8' 6" 10' - 7" 8' 6" 27' - 6" 30' 10" 2' 8" 4' 0" 8' 6" 10' - 7" 4' 0" 4' 0" 33' 6" 8' 1" 10' 8" 2' 6" 12' 3" 1 2 2 2 4 5 1 1 1 KITCHEN DINING RM. 8' - 6" 10' 7" 19' 0" 21' 3" UP BATHROOM KITCHEN / DINING PATIO RETAIL AREA 10' 7" 8' 9" 7' 9" 27' 0" 30' 0" 19' 3" 7' 9" 6' 0" 8' 0"� 22' 0"� 1 1 1 6 2 DN BATHROOM KITCHEN DINING RM. BEDROOM LIVING RM. CL. 10' 7" 16' - 6" 27' 0" 30' 0" 10' 10" 8' 6" 7' 9" 8' 0"� 10' 8" 11' 3" 4' 0" 4' 0" 1 1 5 1 1 BATHROOM BEDROOM STOR. CL. 13' - 9" 11' 3" 25' 0" 4'0" 23' 9" BEDROOM 13' - 9" 11' 3" 25' - 0" ONE BED UNIT PLAN STUDIO UNIT PLAN LIVE WORK UNIT GROUND FLOOR PLAN LIVE WORK UNIT SECOND FLOOR PLAN TWO BED UNIT GROUND FLOOR PLAN TWO BED UNIT SECOND FLOOR PLAN 0 1 5 10 0 0 1 5 10 0 1 5 10 10 SEAT BATHROOM KITCHEN DINING RM. BEDROOM STOR. CL. LIVING RM. PATIO CL. 8' - 6" 10' 7" 8' 6" 27' 6" 30' 10" 2' 8" 4' 0" 8' - 6" 10' 7" 4' 0" 4' 0" 33' 6" 8' 1" 10' 8" 2' 6" 12' 3" 1 2 2 2 4 5 1 1 1 BATHROOM KITCHEN DINING RM. BEDROOM STOR. CL. LIVING RM. CL. 8' 6" 10' 7" 19' - 0" 8' 1" 9' 0" 9' 5" 4' 0" 26' 6" 4' 9" 3' - 9" 10' 7" 21' 3" 5' 3" 4' 0" 1 1 3 3 7 1 1 UP BATHROOM KITCHEN DINING PATIO RETAIL AREA 10' - 7" 8' - 9" 7' 9" 27' 0" 30' 0" 19' 3" 7' 9" 6' 0" 8' 0"� 22' 0"� 1 1 1 6 2 DN BATHROOM KITCHEN DINING RM. BEDROOM LIVING RM. CL. 10' - 7" 16' 6" 27' 0" 30' 0" 10' - 10" 8' - 6" 7' - 9" 8' 0"� 10' 8" 11' 3" 4' 0" 4' 0" 1 1 5 1 1 UP BATHROOM KITCHEN DINING RM. BEDROOM STOR. CL. LIVING RM. CL. 13' 9" 11' 3" 25' 0" 9' 9" 7' 6" 2' 2" 10' 7" 4'0" 30' 0" 4' 3" 9' 6" 11' 3" 23' 9" 6' 3" 4' 0" 1 1 1 5 1 1 1 DN BATHROOM BEDROOM CL. PATIO 13' 9" 11' - 3" 25' 0" 9' 9" 7' 9" 4' 0" 4' 0" 11' 3" 6' 3" 12' 6" 30' 0" 12' 6" 1 1 1 3 1 ONE BED UNIT PLAN STUDIO UNIT PLAN LIVE WORK UNIT GROUND FLOOR PLAN LIVE WORK UNIT SECOND FLOOR PLAN TWO BED UNIT GROUND FLOOR PLAN TWO BED UNIT SECOND FLOOR PLAN 0 1 5 10 0 1 5 10 0 1 5 10 0 1 5 10 0 1 5 10 0 1 5 10
Mixed-Use Housing | Scott Parker | Spring 2023
A200 A201 A200 A201 C. 1 1 A A 11 11 1 700 SF. TWO BD. 700 SF. TWO BD. 700 SF. TWO BD. A400 2. 10" 30' 0"� 30' 0" 187' 0" 25' 10" 25' 10" 25' 10" 40' 2" 29' 11" 29' 6" 8' 0" 8' 0" 30' 30'� 0" 12' 0" 25' 10" 28' 2" 2' 0" 2' 4" 2. A300 700 SF. CPP B.Arch: 2025 Kellog Drive Pomona, CA 97168 REVISION SCHEDULE 610 N SANTIAGO ST A114 FIFTH FLOOR PLAN 5 FIFTH FLOOR PLAN SHEET NOTES REFER TO SHEET G101 FOR GRAPHIC SYMBOLS, ABBREVIATIONS, AND GENERAL NOTES REFER TO SHEET A105 FOR EGRESS AND CODE ANALYSIS REFER TO SHEET A400 FOR ENLARGED UNIT PLANS REFER TO SHEETS A501 & A502 FOR WALL AND FLOOR ASSEMBLIES REFER TO SHEET A503 FOR DRAINAGE REFER TO SHEET A600 FOR DOOR AND WINDOW TYPES SITE FURNISHINGS SHALL NOT BE LOCATED IN THE EXIT PATHWAYS AND SHALL NOT BLOCK EXIT DOORS OR FIRE DEPARTMENT ACCESS DIMENSIONS ARE TO CENTERLINE OF COLUMN, FACE OF STUD, FACE OF CONCRETE, OR FACE OF MASONRY, UNLESS NOTED OTHERWISE MEANS OF EGRESS AND EXIT DISCHARGE SHALL BE ILLUMINATED AT ANY TIME THE BUILDING IS OCCUPIED WITH A LIGHT INTENSITY OF NO LESS THAN 1 FOOT CANDLE AT THE WALKING SURFACE LEVEL PER GOVERNING CODE REQUIREMENTS WALKING SURFACES OF THE MEANS OF EGRESS SHALL HAVE A SLIPRESISTENT SURFACE AND BE SECURELY ATTACHED GROUND AND FLOOR SURFACES ALONG ACCESSIBLE ROUTES AND IN ACCESSIBLE ROOMS AND SPACES, INCLUDING FLOORS, WALKS, RAMPS, STAIRS, AND CURB RAMPS SHALL BE STABLE, FIRM, AND SLIP-RESISTENT ANY DISCREPANCIES NOTED SHALL BE BROUGHT TO THE ATTENTION OF THE ARCHITECT FOR CLARIFICATION PRIOR TO BEGINNING WORK ALL STRUCTURAL, PLUMBING, MECHANICAL, AND ELECTRICAL INFORMATION SHOWN ON SHEETS P101, M101, & E101 IS FOR REFERENCE ONLY. REFER TO CONSULTANTS DRAWINGS PREPARED BY THE ENGINEER & CONTRACTOR TO VERIFY ANY DISCREPANCIES WITH THE ARCHITECT PRIOR TO BEGINNING WORK APPROVED SET OF PLANS FOR BUILDING, FIRE SPRINKLER, FIRE ALARM, ETC. SHALL BE ON THE JOB SITE DURING CONSTRUCTION AND NO INSPECTIONS WILL BE MADE WITHOUT COMPLIANCE WITH THE ABOVE PROVISION ALL CIVIL AND LANDSCAPE INFORMATION SHOWN ON THIS SHEET IS FOR REFERENCE ONLY ALL FURNITURE, FIXTURES, AND FINISHES DEPICTED AT LEASING AND AMENITY AREAS ARE SHOWN FOR REFERENCE ONLY ALL EXTERIOR EXIT DOORS PROVIDE 5'0'' X 5'0'' MINIMUM LEVEL LANDING WITH 2% MAXIMUM SLOPE IN BOTH DIRECTIONS PORTABLE FIRE EXTINGUISERS SHALL BE INSTALLED IN LOCATION AS REQUIRED PER GOVERNING CODE REQUIREMENTS No. Description Date 0 5 10 20 40 A200 A. A201 A200 A201 C. 1 A300 1 1 A A 11 11 1 A310 A400 1. TWO BD. TWO BD. 390 SF. 219' 10" 186' 10" 6' 0" 37' 10" 18' 12' 18' 0"� 12' 0"� 28' 2" 25' 10" 40' 2" 18' 0"� 12' 0"� 18' 12' 8' 0" 8' 0" A300 CPP B.Arch: 2025 Kellog Drive Pomona, CA 97168 REVISION SCHEDULE 610 N SANTIAGO ST A115 SIXTH FLOOR PLAN 6 SIXTH FLOOR PLAN SHEET NOTES REFER TO SHEET G101 FOR GRAPHIC SYMBOLS, ABBREVIATIONS, AND GENERAL NOTES REFER TO SHEET A105 FOR EGRESS AND CODE ANALYSIS REFER TO SHEET A400 FOR ENLARGED UNIT PLANS REFER TO SHEETS A501 & A502 FOR WALL AND FLOOR ASSEMBLIES REFER TO SHEET A503 FOR DRAINAGE REFER TO SHEET A600 FOR DOOR AND WINDOW TYPES SITE FURNISHINGS SHALL NOT BE LOCATED IN THE EXIT PATHWAYS AND SHALL NOT BLOCK EXIT DOORS OR FIRE DEPARTMENT ACCESS DIMENSIONS ARE TO CENTERLINE OF COLUMN, FACE OF STUD, FACE OF CONCRETE, OR FACE OF MASONRY, UNLESS NOTED OTHERWISE MEANS OF EGRESS AND EXIT DISCHARGE SHALL BE ILLUMINATED AT ANY TIME THE BUILDING IS OCCUPIED WITH A LIGHT INTENSITY OF NO LESS THAN 1 FOOT CANDLE AT THE WALKING SURFACE LEVEL PER GOVERNING CODE REQUIREMENTS WALKING SURFACES OF THE MEANS OF EGRESS SHALL HAVE A SLIPRESISTENT SURFACE AND BE SECURELY ATTACHED GROUND AND FLOOR SURFACES ALONG ACCESSIBLE ROUTES AND IN ACCESSIBLE ROOMS AND SPACES, INCLUDING FLOORS, WALKS, RAMPS, STAIRS, AND CURB RAMPS SHALL BE STABLE, FIRM, AND SLIP-RESISTENT ANY DISCREPANCIES NOTED SHALL BE BROUGHT TO THE ATTENTION OF THE ARCHITECT FOR CLARIFICATION PRIOR TO BEGINNING WORK ALL STRUCTURAL, PLUMBING, MECHANICAL, AND ELECTRICAL INFORMATION SHOWN ON SHEETS P101, M101, & E101 IS FOR REFERENCE ONLY. REFER TO CONSULTANTS DRAWINGS PREPARED BY THE ENGINEER & CONTRACTOR TO VERIFY ANY DISCREPANCIES WITH THE ARCHITECT PRIOR TO BEGINNING WORK APPROVED SET OF PLANS FOR BUILDING, FIRE SPRINKLER, FIRE ALARM, ETC. SHALL BE ON THE JOB SITE DURING CONSTRUCTION AND NO INSPECTIONS WILL BE MADE WITHOUT COMPLIANCE WITH THE ABOVE PROVISION ALL CIVIL AND LANDSCAPE INFORMATION SHOWN ON THIS SHEET IS FOR REFERENCE ONLY ALL FURNITURE, FIXTURES, AND FINISHES DEPICTED AT LEASING AND AMENITY AREAS ARE SHOWN FOR REFERENCE ONLY ALL EXTERIOR EXIT DOORS PROVIDE 5'0'' X 5'0'' MINIMUM LEVEL LANDING WITH 2% MAXIMUM SLOPE IN BOTH DIRECTIONS PORTABLE FIRE EXTINGUISERS SHALL BE INSTALLED IN LOCATION AS REQUIRED PER GOVERNING CODE REQUIREMENTS No. Description Date 0 5 10 20 40
Mixed-Use Housing | Scott Parker | Spring 2023
Mixed-Use Housing | Scott Parker | Spring 2023
Mixed-Use Housing | Scott Parker | Spring 2023
Mixed-Use Housing | Scott Parker | Spring 2023
GROUND FLOOR 0' - 0" SECOND FLOOR 9' - 0" THIRD FLOOR 18' - 0" FOURTH FLOOR 27' - 0" FIFTH FLOOR 36' - 0" 45' - 0" T.O. ROOF 54' - 8" SIXTH FLOOR FOURTH FLOOR A B H I C G D E F A B H I C G D E F CORRUGATED PANEL GLASS RAILING PERFORATED MESH BI-FOLD PANEL PERFORATED MESH BI-FOLD PANEL 18'0" 18' 0"� 4' 0" 18' 8" 14'8" 14' 8" PERFORATED METAL MESH COURTYARD ELEVATION A PROMENADE VIEW ELEVATION SHEET NOTES REFER TO SYMBOLS, GENERAL REFER TO AND CODE REFER TO UNIT PLANS REFER TO WALL AND REFER TO REFER TO WINDOW SITE FURNISHINGS LOCATED SHALL NOT FIRE DEPARTMENT DIMENSIONS COLUMN, CONCRETE, UNLESS NOTED MEANS OF DISCHARGE ANY TIME WITH A LIGHT THAN 1 FOOT SURFACE CODE REQUIREMENTS WALKING EGRESS RESISTENT SECURELY GROUND ALONG ACCESSIBLE ACCESSIBLE INCLUDING STAIRS, AND STABLE, ANY DISCREPANCIES BROUGHT ARCHITECT TO BEGINNING ALL STRUCTURAL, MECHANICAL, INFORMATION P101, M101, ONLY. REFER DRAWINGS ENGINEER ANY DISCREPANCIES ARCHITECT WORK APPROVED BUILDING, ALARM, ETC. SITE DURING INSPECTIONS COMPLIANCE PROVISION ALL CIVIL INFORMATION IS FOR REFERENCE ALL FURNITURE, FINISHES AMENITY REFERENCE ALL EXTERIOR 5'0'' X 5'0'' WITH 2% DIRECTIONS PORTABLE BE INSTALLED REQUIRED REQUIREMENTS 0 5 10 20 40 GROUND FLOOR 0' - 0" SECOND FLOOR 9' - 0" THIRD FLOOR 18' - 0" FOURTH FLOOR 27' - 0" FIFTH FLOOR 36' - 0" 45' - 0" T.O. ROOF 54' - 8" SIXTH FLOOR GROUND FLOOR 0' - 0" SECOND FLOOR 9' - 0" THIRD FLOOR 18' - 0" FOURTH FLOOR 27' - 0" FIFTH FLOOR 36' - 0" 45' - 0" T.O. ROOF 54' - 8" SIXTH FLOOR A B H I C G D E F A B H I C G D E F CORRUGATED PANEL GLASS RAILING CORRUGATED PANEL GLASS RAILING PERFORATED MESH BI-FOLD PANEL PERFORATED MESH BI-FOLD PANEL 18' 0" 5' 8" 4' 0" 18' 8" 18' 0"� 4' 0" 18'8" 14' 8" 14' 8" PERFORATED METAL MESH B COURTYARD ELEVATION A PROMENADE VIEW ELEVATION SHEET NOTES REFER TO SYMBOLS, GENERAL REFER TO AND CODE REFER TO UNIT PLANS REFER TO WALL AND REFER TO REFER TO WINDOW TYPES SITE FURNISHINGS LOCATED SHALL NOT FIRE DEPARTMENT DIMENSIONS COLUMN, FACE CONCRETE, UNLESS NOTED MEANS OF DISCHARGE ANY TIME WITH A LIGHT THAN 1 FOOT SURFACE CODE REQUIREMENTS WALKING SURFACES EGRESS SHALL RESISTENT SECURELY GROUND AND ALONG ACCESSIBLE ACCESSIBLE INCLUDING STAIRS, AND STABLE, FIRM, ANY DISCREPANCIES BROUGHT ARCHITECT TO BEGINNING ALL STRUCTURAL, MECHANICAL, INFORMATION P101, M101, ONLY. REFER DRAWINGS ENGINEER ANY DISCREPANCIES ARCHITECT WORK APPROVED BUILDING, ALARM, ETC. SITE DURING INSPECTIONS COMPLIANCE PROVISION ALL CIVIL AND INFORMATION IS FOR REFERENCE ALL FURNITURE, FINISHES DEPICTED AMENITY AREAS REFERENCE ALL EXTERIOR 5'0'' X 5'0'' MINIMUM WITH 2% MAXIMUM DIRECTIONS PORTABLE BE INSTALLED REQUIRED REQUIREMENTS 0 5 10 20 40 0 5 10 20 40
PRE-FINISHED COPING
TREATED WOOD NAILER
CANT STRIP
RIGID INSULATION
3/4" PLYWOOD SHEATHING
WOOD FINISH
SOUNDPROOFING FLOOR MAT
CONCRETE
3/4" PLYWOOD SHEATHING
2 X 12 STUD
BATT INSULATION
5/8" GYPSUM BOARD RESILIENT CHANNEL
CORRUGATED PANEL BOLT
HAT CHANNEL FURRING STRIP
1" RIGID INSULATION
WEATHER BARRIER
3/4" PLYWOOD SHEATHING
BOLT
ALUMINUM SHOE
ANCHOR BOLT
GLASS WOOD FINISH
STUCCO FINISH
5/8" GYPSUM BOARD
CONCRETE WALL
C CHANNEL
1 WALL SECTION A
Mixed-Use Housing | Scott Parker | Spring 2023
5 1 0
Mixed-Use Housing | Scott Parker | Spring 2023
BEDROOM LIVING RM. PATIO RETAIL EVENT SPACE PATIO BEDROOM BEDROOM LIVING RM. RETAIL AREA RETAIL AREA GROUND FLOOR SECOND FLOOR THIRD FLOOR FOURTH FLOOR FIFTH FLOOR 45' - 0" T.O. ROOF 54' - 8" SIXTH FLOOR 4'0" 16' 8" GAME RM. OUTDOOR LOUNGE AREA KITCHEN KITCHEN LIVING RM. LIVING RM. LIVING RM. KITCHEN GROUND FLOOR 0' - 0" SECOND FLOOR 9' - 0" THIRD FLOOR 18' - 0" FOURTH FLOOR 27' - 0" FIFTH FLOOR 36' - 0" 45' - 0" T.O. ROOF 54' - 8" SIXTH FLOOR 2 SECTION B 0 5 10 20 40 BEDROOM BEDROOM BEDROOM LIVING RM. PATIO RETAIL EVENT SPACE B.O.H. PATIO BEDROOM BEDROOM BEDROOM LIVING RM. RETAIL AREA RETAIL AREA 16'8" 26' 0" 16'8" 16'8" 4' 0" 4' 0" GROUND FLOOR 0' - 0" SECOND FLOOR 9' - 0" THIRD FLOOR 18' - 0" FOURTH FLOOR 27' - 0" FIFTH FLOOR 36' - 0" 45' - 0" T.O. ROOF 54' - 8" SIXTH FLOOR 4' 0" 16' 8" GAME RM. OUTDOOR LOUNGE AREA KITCHEN KITCHEN LIVING RM. LIVING RM. LIVING RM. KITCHEN GROUND FLOOR 0' - 0" SECOND FLOOR 9' - 0" THIRD FLOOR 18' - 0" FOURTH FLOOR 27' - 0" FIFTH FLOOR 36' - 0" 45' - 0" T.O. ROOF 54' - 8" SIXTH FLOOR 1 SECTION A 2 SECTION B 0 5 10 20 40 0 5 10 20 40
Mixed-Use Housing | Scott Parker | Spring 2023
Mixed-Use Housing | Scott Parker | Spring 2023
Mixed-Use Housing | Scott Parker | Spring 2023
FLOOR ASSEMBLIES
CONCRETE PODIUM WOOD FINISH EXTERIOR INTERIOR EXTERIOR INTERIOR 5/8" GYPSUM BOARD RESILIENT CHANNEL BATT INSULATION 2 X 12 FLOOR FRAMING, 16" OC 3/4" PLYWOOD SHEATHING SOUNDPROOFING FLOOR MAT WOOD FINISH INTERIOR INTERIOR INTERIOR INTERIOR CONCRETE 5/8" GYPSUM BOARD RESILIENT CHANNEL BATT INSULATION 2 X 10 FLOOR FRAMING, 16" OC 3/4" PLYWOOD SHEATHING TAPERED RIGID INSULATION INSULATION COVER BOARD SUPPORT PEDESTAL WOOD DECKING EXTERIOR EXTERIOR EXTERIOR EXTERIOR 5/8" GYPSUM BOARD BATT INSULATION R30 2 X 12 FLOOR FRAMING, 16" OC 3/4" PLYWOOD SHEATHING 1" EXTERIOR RIGID INSULATION WEATHER BARRIER CORRUGATED METAL ROOFING EXTERIOR EXTERIOR TYP. PODIUM FLOOR ASSEMBLY TYP. DEMISING FLOOR ASSEMBLY TYP. BALCONY FLOOR ASSEMBLY TYP. ROOF ASSEMBLY CONCRETE PODIUM WOOD FINISH EXTERIOR INTERIOR EXTERIOR INTERIOR
RESILIENT
BATT
2
3/4"
SOUNDPROOFING
WOOD
INTERIOR INTERIOR INTERIOR INTERIOR CONCRETE
5/8" GYPSUM BOARD
CHANNEL
INSULATION
X 12 FLOOR FRAMING, 16" OC
PLYWOOD SHEATHING
FLOOR MAT
FINISH
BATT
2
TAPERED
INSULATION COVER BOARD SUPPORT PEDESTAL WOOD DECKING EXTERIOR EXTERIOR EXTERIOR EXTERIOR 5/8"
BATT
2 X
3/4"
SHEATHING 1" EXTERIOR
WEATHER BARRIER CORRUGATED METAL
INTERIOR EXTERIOR INTERIOR EXTERIOR
5/8" GYPSUM BOARD RESILIENT CHANNEL
INSULATION
X 10 FLOOR FRAMING, 16" OC 3/4" PLYWOOD SHEATHING
RIGID INSULATION
GYPSUM BOARD
INSULATION R30
12 FLOOR FRAMING, 16" OC
PLYWOOD
RIGID INSULATION
ROOFING
TYP. PODIUM FLOOR ASSEMBLY TYP. DEMISING FLOOR ASSEMBLY
TYP. BALCONY FLOOR ASSEMBLY TYP. ROOF ASSEMBLY
INTERIOR
INTERIOR
EXTERIOR
EXTERIOR
INTERIOR INTERIOR
BATT INSULATION
5/8"
INTERIOR
INTERIOR
INTERIOR INTERIOR
BATT INSULATION
2"
5/8" GYPSUM BOARD
TYP. INTERIOR WALL ASSEMBLY
INTERIOR
BOLT CORRUGATED METAL PANEL
FURRING STRIP
HAT CHANNEL
1" RIGID INSULATION
WEATHER BARRIER
3/4" PLYWOOD SHEATHING
BATT INSULATION R19
2" X
INTERIOR INTERIOR
WALL FRAMING, 16" O.C.
5/8" GYPSUM BOARD
TYP. EXTERIOR WALL ASSEMBLY
INTERIOR
INTERIOR INTERIOR
1" AIR GAP
BATT INSULATION
2"
5/8" GYPSUM BOARD
TYP. DEMISING WALL ASSEMBLY
Mixed-Use Housing | Scott Parker | Spring 2023
2" X 4" WALL FRAMING, 16" O.C.
GYPSUM BOARD
X 4" WALL FRAMING, 16" O.C. RESILIENT CHANNEL
X 4" WALL FRAMING, 16" O.C.
TYP. DEMISING PLUMBING WALL ASSEMBLY
6"
WALL ASSEMBLIES
Mount Wilson Scientist Retreat | Alexander Pang | Fall 2022
Mount Wilson Scientist Retreat
Third Year Studio | Alexander Pang | Fall 2022
This project consists of a scientist retreat at the Mount Wilson Observatory located in Southern California. The scientist retreat incorporates public and private spaces with living quarters for scientists and a gathering deck that overlooks the city of Los Angeles. The project explores a cantilever and bridge with the program divided through public on the upper level and private on the lower level. This is also reflected through materiality with standing seam on the upper level and curtain walls on the lower level to create a floating box appearance. A box truss system is implemented on the upper level with 6 structural support columns that connect from the ground to the upper level. Retaining walls create a u-shape to carve into the earthwork for the lower level. Outdoor circulation is prominent allowing researchers, visitors, and pedestrians to travel alongside the building from the upper and lower level. The cantilevered portion includes an amphitheater gathering space with a deck platform at the top.
Mount Wilson Scientist Retreat | Alexander Pang | Fall 2022
0 SITE PLAN SCALE 1/16” = 1’0 10 50 100
SILVERHOUSE
CABIN
PUBLIC ENTRANCE PRIVATE ENTRANCE Mount Wilson Scientist Retreat | Alexander Pang | Fall 2022
CABIN
STRUCTURE
EARTHWORK
Mount Wilson Scientist Retreat | Alexander Pang | Fall 2022 0 25 50 EXPLODED ISOMETRIC DIAGRAM
ENVELOPE
Mount Wilson Scientist Retreat | Alexander Pang | Fall 2022
B UP 1 2 4 6 3 B 0 5 10 25 Mount Wilson Scientist Retreat | Alexander Pang | Fall 2022
PUBLIC RESEARCH PRIVATE PROGRAM DIAGRAM Mount Wilson Scientist Retreat | Alexander Pang | Fall 2022
UP UP DN DN 9 7 8 LEVEL 1 FLOOR PLAN 7 GATHERING SPACE / DECK 8 ADA RESTROOM 9 LAB / OFFICE B B 0 5 10 25 Mount Wilson Scientist Retreat | Alexander Pang | Fall 2022
Mount Wilson Scientist Retreat | Alexander Pang | Fall 2022
Mount Wilson Scientist Retreat | Alexander Pang | Fall 2022
SECTION A 1 KITCHEN / DAYROOM 2 BEDROOM 4 BATHROOM 7 GATHERING SPACE / DECK 8 ADA RESTROOM 9 LAB / OFFICE 1 8 9 Mount Wilson Scientist Retreat | Alexander Pang | Fall 2022
0 5 10 25 7 2 4 2 Mount Wilson Scientist Retreat | Alexander Pang | Fall 2022
Mount Wilson Scientist Retreat | Alexander Pang | Fall 2022
SECTION B 2 BEDROOM 7 GATHERING SPACE / DECK 10 HALLWAY 0 5 10 25 7 2 10 Mount Wilson Scientist Retreat | Alexander Pang | Fall 2022
Museum of Contemporary Japanese Art | Noam Saragosti | Fall 2021
Museum of Contemporary Japanese Art
Second Year Studio | Noam Saragosti | Fall 2021
This project encompasses designing a museum for contemporary Japanese art through a given site with an infill condition of existing buildings on both sides located in Downtown Los Angeles. The museum’s facade is inspired by the New Museum in New York by utilizing rotation and shifted volumes to connect the front and back of the site.
A rotated atrium is the defining circulation as it dictates how visitors move throughout the building by wrapping around the atrium. The rotated atrium also consists of open to below spaces, connecting all the floors together and acts as a skylight, bringing natural light down the museum and through the open spaces. The shifted volumes create skylight strips that allow natural light to be brought into the lower floors and travel throughout the building.
Museum of Contemporary Japanese Art | Noam Saragosti | Fall 2021
A B A A 5 0 10 25 50 C SITE PLAN C B B SERVICE ALLEY SAN PEDRO STREET E 1ST STREET Museum of Contemporary Japanese Art | Noam Saragosti | Fall 2021
SERVICE ALLEY C C B B UP DN DN UP 1 6 8 DN UP 1 3 4 5 DN 7 2 2 8 FIRST FLOOR PLAN 1 EXHIBITION 2 STORAGE 3 LOBBY 4 RECEPTION 5 BOOKSTORE 6 CONFERENCE ROOM 7 LOADING DOCK 8 STAFF RESTROOM 0 5 10 20 Museum of Contemporary Japanese Art | Noam Saragosti | Fall 2021
Museum of Contemporary Japanese Art | Noam Saragosti | Fall 2021
SERVICE ALLEY 1 9 2 1 10 C C B B SECOND FLOOR PLAN 1 EXHIBITION 2 STORAGE 9 RESTROOM 10 CLASSROOM 5 BOOKSTORE 6 CONFERENCE ROOM 7 LOADING DOCK 8 STAFF RESTROOM 0 5 10 20 UP DN DN UP DN UP DN Museum of Contemporary Japanese Art | Noam Saragosti | Fall 2021
Museum of Contemporary Japanese Art | Noam Saragosti | Fall 2021 1 1 1 1 14 7 SECTION A 1 EXHIBITION 3 LOBBY 5 BOOKSTORE 7 LOADING DOCK 10 CLASSROOM 11 DIRECTOR’S OFICE 12 AUDITORIUM 13 OFFICE 14 CAFE
Museum of Contemporary Japanese Art | Noam Saragosti | Fall 2021 3 5 1 1 10 1 1 11 12 14 13 1 0 5 10 20
Museum of Contemporary Japanese Art | Noam Saragosti | Fall 2021
Museum of Contemporary Japanese Art | Noam Saragosti | Fall 2021 1 SECTION B 1 EXHIBITION 5 BOOKSTORE 12 AUDITORIUM SECTION C 1 EXHIBITION 14 CAFE 14 14 1 1 1 1 1 1 1 1 1 1 1 12 1 5 0 5 10 0 5 10 ELEVATION A ELEVATION B 0 5 10 0 5 10
Museum of Contemporary Japanese Art | Noam Saragosti | Fall 2021
EXTERIOR SPACES
PROGRAM DIAGRAM PUBLIC AREAS 1 LOBBY/BOOKSTORE 2 AUDITORIUM 3 CLASSROOM 4 PUBLIC RESTROOM 5 DIRECTOR’S OFFICE 6 STAFF OFFICE 7 CONFERENCE ROOM 8 STAFF ROOM 9 STAFF RESTROOM 10 MECHANICAL ROOM 11 ART STORAGE 12 LOADING DOCK 13 CAFE EXHIBITION BASEMENT FIRST FLOOR SECOND FLOOR THIRD FLOOR FOURTH FLOOR SUPPORT STAFF 1 9 13 7 2 4 10 11 3 4 4 13 13 8 5 6 1
CIRCULATION EXPLODED
Museum of Contemporary Japanese Art | Noam Saragosti | Fall 2021
