POOL HOUSE AND CABANA
O F F I C E
POOL HOUSE AND CABANA
LONDON, ON
POOL HOUSE, STORAGE ROOM, CABANA SPACE WITH BUILT IN BBQ, PIZZA OVEN, SMOKE, SINK. BUILT IN KITCHEN WITH STONE VENEER AND GRANITE COUNTERTOP.
CEILING WITH POT LIGHTS AND FAN
ISLAND KITCHEN WITH 10 PERSONS SITTING AREA
STAMPED CONCERTE FLOORING
STAMPEDCONCRETE BACKWALKWAY
STAMPEDCONCRETEWALKWAY ACCESSFROMPOOL
BANASSTEPS48"X16"X7" (MATCHEXSTEP) BRUSHEDCONCRETEFLOORING STORAGEROOM
BRUSHEDCONCRETEFLOORING WASHROOM/CHANGEROOM
GABLEROOFFORCABANA ISLAND WITH STONE VENEER OVERLAY AND COUNTERTOP 4'WIDESTAMPEDCONCRETE WALKWAYACCESSFROM BACKDOORWITHBANASSTEP BUILTINBBQWITH STONEVENEERTBD
STAMPEDCONCRETEFLOORING CABANA 2"RAISEDCONCRETEPLATFORM FORPIZZAOVENANDSMOKE
MASTER PLAN
SBM02PoohouseRdgeBeam 2-175"X925"20eV
SBM052x6RAFTERS24OCTYP
5-2x6SudPos
SBM01CabanaRdgeBeam3-175"X1125"20eLV
SBM04DougasFrTmber 8X10NO1TMBERCABANASIDEBEAM
4-2x6SudPos 210-FASCATYP?
SBM8X8M umberPot DougaFTmbe
SBM03DougasFrTmber 8X10NO1TMBERTIEBEAMATCABANA
SBM8X8M umbePos DougaFTmbe
FOUNDATION DETAIL
OUTDOOR KITCHEN PLAN
OUTDOOR KITCHEN ELEVATION
ELEVATIONS
ISLAND KITCHEN
O F F I C E
BASEMENT RENOVATION
MODERN INTERIOR BASEMENT RENOVATION WITH ADDITION OF NEW PARTITION WALLS.
EXISTINGWALL
NEW2"X4"WALL
DOORSCHEDULE
SYMBOL DESCRIPTION
24"SWINGDOOR
26"SWINGDOOR
3'71/2"BI-FOLDEDDOOR
32"BARNDOORS
LONDON, ON LAYOUT
3'0"GLASSDOOR
28"POCKETDOOR
711"BI-FOLDEDDOOR
DOOR SCHEDULE
CEILING HEIGHT: FROM FLOOR FINISH = 7'6"
HOME THEATER WITH BAR, GYM, WINE CELLER, BEDROOM, STORAGE, WASHROOM, PANTRY, MECHANICAL ROOM
F R E E L A N C I N G
RECREATIONAL
PROJECT KASHMIR, INDIA
