SUPPLY CATALOGUE

table of contents

marine/awning/industrial fabrics - 6 marine vinyl fr awning vinyl pvc cover/tarp clear roll & sheet plastics mesh polyester nylon low temp vinyl treated & untreated cotton canvas sunbrella fabrics

8 9 10 12 14 16 17 18 21 22

performance upholstery fabrics - 25 plains & textures - 26 pu / bonded - 33 pvc - 36

marine/awning/upholstery supplies - 39 padding & decking webbing hook & loop fasteners zippers awning hardware marine hardware grommets industrial & bag hardware tools needles & thread binding & cordage tape trimming tacks & nails buttons cleaners, protectants & adhesives

40 41 44 50 56 64 66 80 82 89 105 113 122 126 134 137 141

terms & conditions - 163 indices - 170

numerical index - 171 alphanumerical index - 182 alphabetical index - 193

intro HEAD OFFICE 6111 â&#x20AC;&#x201C; 91 Street NW Edmonton, AB T6E 6V6

INTERNATIONAL HEAD OFFICE 1st Floor Hastings House Balmoral GAP Hastings Christ Church, Barbados

SHOWROOM & DISTRIBUTION CENTERS CANADA

EDMONTON (showroom) 6111 - 91 Street NW Edmonton, AB T6E 6V6 VANCOUVER (showroom & distribution) 13911 Bridgeport Road Richmond, BC V6V 1J6 TORONTO (showroom & distribution) 6300 Kenway Drive Mississauga, ON L5T 2N3

TOLL FREE ENGLISH FRENCH FAX

2 | introduction

800-663-6647 888-663-6647 888-274-2910

USA

INDIANAPOLIS (distibution) 853 S. Columbia Road Suite 125 Plainfield, IN 46168

TOLL FREE PHONE FAX

CHINA

WEB

orders@ennisfabrics.com ennisfabrics.com @ennisfabrics @ennisFabrics

877-953-6647 888-274-2910

NINGBO Bao Shui Xi Qu Gang Xi Da Dao #23 Beilun, Ningbo, 315800

@EnnisFabrics

ABOUT ENNIS FABRICS

A market leader for over 45 years. Prior to establishing Ennis Fabrics, James C. Ennis spent 22 years with LaFrance textiles. In 1958, James was transferred to Edmonton as their Western Canadian Regional Manager. During that time he learned all about textiles and the needs of his customers. On June 1, 1972, James and Lois Ennis opened their original warehouse, a 2,500ft 2 bay, in Edmonton to distribute fabrics and supplies throughout Northern Alberta.

MAJOR BRANDS

ENNIS 1974

Since that time, thanks to the continued support of our valued customers, Ennis Fabrics has experienced steady growth. Today, over 10,000 stocked products are distributed throughout North America from three extensive, full-service distribution centers in Toronto, Vancouver, and Indianapolis. Additionally, we have a wholly owned 40,000ft 2 quality control and consolidation warehouse in China capable of domestic Asian trading, and an international head office in Barbados. Each day, we strive to surpass the expectations of our customers and employees. We achieve this by being passionate about ways to contribute to our customersâ&#x20AC;&#x2122; successâ&#x20AC;&#x201D;being their partner, understanding their needs, being exceptionally reliable, and delivering the right products when needed.

CORDURA

introduction | 3

QUALITY CONTROL: Standards & Guidelines

Ennis Fabrics maintains the highest standards possible in the textiles and supplies we present to our customers. Our inventory is managed with a piece based system allowing for the highest quality control. We sell both cuts and rolls and have the ability to match dye lots. The following are the standards we use for shipping to our customers. These standards are based on those set by the American Home Funishings Alliance (AHFA), the residential furniture industry’s recognized leader in the development of product and technical standards; the Asssociation for Contract Textiles (ACT); and the Chemical Fabrics and Film Association’s (CFFA’s) paper on Standard Test Methods for Chemical Coated Fabrics and Films. These are sources subscribed to by most North American manufacturers. These resources specify test methods, practices and minimum voluntary acceptance guidelines for various types of upholstery fabrics and standards for vinyls and coated fabrics. In no case would we supply items as first quality that could not meet these guidelines. Clearouts or seconds are of a lower standard and are priced accordingly.

ALLOWANCES The following allowances will be made for fabric flaws (excluding Sunbrella) FLAW SIZE

ALLOWANCE

Less than 1 ⁄ 8 yd

1 ⁄ 8 yd

More than 1 ⁄ 8 yd

Length of flaw

Two flaws (measured as 1 long

Length of flaw

flaw)

MARKING OF FLAWS

Factory flaws are marked with either a red or yellow plastic “swiftach” type of marker or a length of colored thread or string in the selvage of material. When marked with a red tag, the flaw is considered a “spot” or filling (weft) direction flaw. It usually will be less than 1 ⁄ 8 yard and is marked with a red tag for identification and numbering of flaws per roll. When a yellow tag is used, this represents a warp direction flaw, where there are tags to mark both the start and end of each flaw. In most cases a flaw of this type would not be included in your shipment, but in case of a full roll order, the exact yardage between tags is deducted from the gross yardage on the roll. In full roll orders, there will be no more than two pieces per roll.

FLAW DENSITY

This refers to the acceptable number of flaws in a given cut. For cuts that are equal to or less than 5 yards, each cut must be free from flaws. MAXIMUM FLAWS FOR FIRSTS:

BREAKS IN ROLLS

Pile Fabrics

1 flaw per 7 yards up to a maximum of 7 flaws per 50 yard roll

Woven Fabrics

1 flaw per 9 yards up to a maximum of 5 flaws per 50 yard roll

Vinyls and Industrial Fabrics

2 flaws per 39 yards, 3 flaws per 49 yards, 4 flaws per 59 yards

A break in a roll is considered to be a flaw and the allowance given is usually 1 ⁄ 8 yard. All orders 10 yards or less must be filled with a single piece of fabric. If this is not possible then the customer must approve shipment ahead of time. If the length of the cut is greater than 10 yards, a break is acceptable provided there is a suitable allowance. No single piece will be less than 2 flaw free yards. If more than 2 pieces are required to fill an order, the customer must approve this prior to shipping, regardless of length.

SHADE & DYE LOT

For decorative and woven fabrics, a match is 3/4 to 5.0 on the Greyscale ASTM D2616-12. This is true also for industrial and

CROCKING

Crocking is the transfer of color from a fabric to fabric through the process of rubbing. On some fabrics, free dye or fibers

recreational fabrics. may remain on the surface possibly causing crocking to occur. For suedes, dry crocking is 4 to 5, wet crocking is 3/4 to 5. Both are measured against the AATCC 8 Color Transference Scale. This rating is most prevalent for very dark or rich colors (i.e. black, navy, red).

ROLL ORDER SIZE CLEAROUTS

4 | introduction

Roll lengths vary. Please confirm when placing orders for full rolls. Clearouts or seconds may contain flaws and have been priced accordingly.

FREQUENTLY ASKED QUESTIONS: How to use this catalogue

How are the supplies grouped? The catalogue is grouped by market (Marine, Awning, Upholstery, Drapery, etc.). Market/section is found at the bottom of each page next to the page number. How do I quickly navigate to supply groupings? Main table of contents at the front of the catalogue, smaller table of contents at the start of each section. For more specific searching use one of our three indexes found at the back of the book. How to search by alphabetical index (product name)? Go to page 193. In alphabetical order search by general names of products (eg. shears, scissors, etc.) How to search by alphanumeric index (alpha-numeric product code)? Go to page 182. In alphabetical order search by product codes (eg. SHEST7032) How to search by numbered index (numeric product code)? Go to page 168. In ascending order, starting at 1001, search by numeric product code (eg. 7032) Is there a digital version of the supply catalogue? Yes. You can find it on the website on the resources page for each market.

Supply Details Where do I find stock on hand? ennisfabrics.com, call into our Customer Experience team or consult your sales representative. Where can I find additional specifications if they are not described in the catalogue? ennisfabrics.com. On our website, every product page displays the full item specifications, you can even print them or save them as a PDF. How do I find how to use/install a product? Installation tips are found throughout the catalogue, additionally if you search the product on the website you can find videos explaining how to use the product – our library of videos is expanding so if you can’t initially find what you are looking for, the video may still be in production. Check back regularly to see new videos. Does the website show the catalogue page number for every product in the catalogue? Yes, look at the row labelled CATALOGUE in the product specifications – found on every product page. Do these products have a warranty? Yes. Refer to page 168 for our terms and conditions, including warranty information. Are these all the fabrics offered by Ennis Fabrics? No. We stock over 6,700 fabrics, our full range of fabrics can be found on our website ennisfabrics.com.

introduction | 5

marine / awning / industrial fabrics We are here to make your marine, awning and industrial projects easier. With thousands of supply products available, weâ&#x20AC;&#x2122;ve got you covered! marine vinyl fr awning vinyl pvc cover/tarp clear roll & sheet plastics mesh polyester nylon low temp vinyl treated & untreated cotton canvas sunbrella fabrics

8 9 10 12 14 16 17 18 21 22

This colorful selection of woven vinyl-coated polyester fabrics is rugged enough to handle outdoor applications – cushion patio furniture, umbrellas and heat-filtering awnings – in any weather, with a durability and long life expectancy for limitless applications. Phifertex Standard Mesh fabrics are also ideal for office furniture, orthopedic equipment, upholstery and safety vests and are resistant to mildew, stains and fading. Phifertex is infused with Microban® antimicrobial product protection, helping to provide an additional level of cleanliness protection that won’t wash off or wear away for the lifetime of the fabric. Microban protection inhibits the growth of stain and odor-causing bacteria, mold and mildew and works continuously, keeping fabrics cleaner for longer.

marine vinyl 1 Red

17 Burgundy

222 Hunter Green

3 Royal Blue

33 Navy Blue

333 Azure

34 Teal Green

6 White

6003 Ivory

6009 Oyster White

61 Mystic White

649 Almond

66 Off White

67 Mushroom

696 Bright White

8 Chocolate

805 Spice

84 Rust

87 Brown

8884 Rawhide

MIDSHIP

9006 Light Grey

Midship was developed to withstand harsh temperatures. In addition to being resistant to seasonal extremes, Midship can also stand up against chemical and UV exposure. Midship is a superior vinyl product with proven marine performance.

9009 Black

Abrasion: 50,000+ double rubs

905 Seagull

969 Dark Grey

Content: 100% Polyvinyl chloride (PVC) coating with a polyester knit backing Cold Crack: -28°C (-18°F) Fire Retardancy*: CALTB117-2013; NFPA 260 Class 1; UFAC Class 1.

97 Steel

98 Medium Grey

UV Resistance: ≥ 1500 hours Width: 54” (137 cm) | Roll Size: 50 yd (45.7 m)

99 Mid Grey

MIDSHIP GIMP & WELT We now carry Hydem Gimp and Welt in all matching Midship colors. See p.115–116 for more details.

MIDSHIP HEAT SEALED Utilizing a top-quality Midship face, Midship Heat-Sealed is a great accent for boat seating. It features quilted heat-sealed channels every 1½” across the roll in top neutral colors for the Marine market.

6003 Ivory

61 Mystic White

66 Oﬀ White

969 Bright White

9009 Black

905 Seagull

Face Content: 100% Polyvinyl chloride (PVC) Fill Content: 100% Polyester Knit Cold Crack: -28°C (-18°F) Fire Retardancy*: CALTB117-2013; NFPA 260 Class 1; UFAC Class 1. UV Resistance: ≥ 1500 hours Width: 54” (137 cm) | Roll Size: 50 yd (45.7 m) * This information is offered for general guidance only. It is accurate to the best of our knowledge and is not intended to relieve the user from its responsibility to investigate and understand other pertinent sources of information and to comply with all laws and procedures applicable to the safe handling and use of this material. Please note: The fabric and supply images displayed may not represent the actual product in its entirety.

8 | marine - awning - industrial fabrics

fr awning vinyl ENNIS 1974 Ennis 1974 is a pre-contraint PVC-coated Polyester fabric with a PVDF/Acrylic fi nish—a choice material for awnings, tents, canopies, gazebos, infl atable structures and light frame supported structures. This is an easy to clean outdoor fabric. The material undergoes a lacquering treatment (Rotofl uo W) of surface coatings to protect and insulate the PVC layer. Treated with a thin acrylic/ fl uorinated PVDF blend on one side and an acrylic lacquer coating on the other, Ennis 1974 provides easycleanability, thermal insulation, sound proofi ng, superior

Content: 100% Polyvinyl choloride (PVC) Coating | Finish: 100% PVC | PVDF/Acrylic Cold Crack: -30°C (-22°F) Fire Retardancy*: NFPA 701, CAN/ULC S109, Italy: Classe 2 France: M2, Germany: DIN 4102 B1, Scandinavia: SIS 650082, Europa: B s1 d0 UV Resistance: ≥ 1000 hours

radiation stability, and exceptional properties in tension

Warranty: 10-year limited manufacturer’s warranty. 6-year manufacturer’s limited warranty when used in rental tents.

and defl ection.

Width: 74” (188 cm) Roll Size: 50 yd (45.7 m)

chemical aging resistance, fi re resistance, UV and Gamma

422 Red

509 Terra Cotta

116 Burgundy

418 Dark Brown

415 Cocoa

417 Dark Grey

416 Grey

413 Bright Blue

425 Sapphire

431 Navy

426 Green

432 Forest Green

438 Spruce

427 Black

420 Lemon

419 Tan

410 White

* This information is offered for general guidance only. It is accurate to the best of our knowledge and is not intended to relieve the user from its responsibility to investigate and understand other pertinent sources of information and to comply with all laws and procedures applicable to the safe handling and use of this material. Please note: The fabric and supply images displayed may not represent the actual product in its entirety.

marine - awning - industrial fabrics | 9

pvc cover / tarp 1 Red

111 Burgundy

2009 Forest Green

55 Yellow

6 White

68 Beige

Apollo 81” Mercury 61 “ (50yd/100yd) Sampson FR 61”

Mercury 61 “ (50yd/100yd) Sampson FR 61”

Apollo 81” Mercury 61 “ (50yd/100yd)

Apollo 81” Mercury 61 “ (50yd/100yd) Sampson FR 61”

8006 Brown

9 Grey

7 Black

205 Medium Green

3 Blue

308 Navy

Mercury 61 “ (50yd/100yd) Sampson FR 61”

Apollo 81” Mercury 61 “ (50yd/100yd) Sampson FR 61”

Mercury 61 “ (50yd/100yd) Sampson FR 61”

Apollo 81” Mercury 61 “ (50yd/100yd) Sampson FR 61”

Mercury 61 “ (50yd/100yd)

44 Orange

994 Fluor. Orange

18OZ. COATED PVC

Mercury 61 “ (50yd/100yd) Sampson FR 61”

Apollo 81” Mercury 61 “ (50yd/100yd) Sampson FR 61”

Our 18.oz Coated PVC collection highlights our top three PVC products. The vinyl products featured in this collection include Apollo (81”), Mercury (61”), and Sampson (61”, FR). Each vinyl shares comparable specifications, so decisions are often based on the colors available. APOLLO

CONTENT COLORS FIRE RETARDANCY*

MERCURY (50YD/100YD)

SAMPSON FR

100% Polyvinyl Chloride 9 EN 1176-10: 2008—Playground EN 1021-1: 2006 Cigarette Test EN 1021-2: 2006 Match Test

THREAD COUNT

EN 1176-10: 2008—Playground EN 1021-1: 2006 Cigarette Test EN 1021-2: 2006 Match Test

CPAI-84; NFPA 701; MVSS 302

17 x 18 threads/inch²

YARN SIZE

1000 x 1300 denier

SCRIM

Woven polyester

THICKNESS

0.55 mm

COLD CRACK

-40˚C (-40˚F)

MILDEW RESISTANT

Yes

UV / LIGHT FASTNESS

1000 hours

WIDTH

81” (206 cm)

ROLL SIZE

50 yd

CLEANING INSTRUCTIONS CAUTIONS

61” (155 cm)

50 yd or 100 yd

50 yd

Clean with Mild Soap and Water Do not use bleach, citrus based cleaners, or vinegar. Will degrade fabric over time, causing discoloration and a shorter lifespan.

ATLAS: 10OZ. COATED PVC Content: 100% Polyvinyl Chloride (PVC)

33 Blue

44 Fluorescent

77 Black

66 White

69 Beige

99 Grey

Yarn size: 500 denier Scrim: Woven Polyester Cold Crack: ≥ -20°C (-4°F) Fire Retardancy*: MVSS302 Thread Count: 18 x 12 threads/inch2 UV Resistance: ≥ 300 hours Width: 60” (152 cm) | Roll Size: 50 yd (45.7 m) * This information is offered for general guidance only. It is accurate to the best of our knowledge and is not intended to relieve the user from its responsibility to investigate and understand other pertinent sources of information and to comply with all laws and procedures applicable to the safe handling and use of this material. Please note: The fabric and supply images displayed may not represent the actual product in its entirety.

10 | marine - awning - industrial fabrics

HERCULES: 14OZ. COATED PVC

1 Red

3 Blue

6 White

68 Beige

7 Black

9 Grey

Content: 100% Polyvinyl Chloride (PVC) Yarn Size: 1000 denier Scrim: Woven Polyester Cold Crack: ≥ -40°C (-40°F) Thread Count: 12 x 12 threads/inch2 UV Resistance: ≥ 1000 hours

Width: 61” (156 cm) | Roll Size: 30 yd (27.4 m)

CHALLENGER Challenger has the soft feel of leather and demonstrates both durability and strength. Challenger performs well across numerous markets and testing parameters ensuring that it will become your go to vinyl in almost any application.

Abrasion: 1,500,000+ Double Rubs Content: 100% Polyvinyl Chloride (PVC) Backing Content: 100% Polyester Cold Crack: -55°C (-67°F) Fi re Retardancy: CALTB117-2013, IMO FTP Code 2010 - Part 8, MVSS302, NFPA 260 Class 1, UFAC Class 1

ACT PERFORMANCE INFORMATION:

UV Resistance: AATCC 16.3 - Grade 4.0 (1,500 hours) Width: 55” (140 cm) | Roll Size: 30 yd (27 m)

61 White Cap

602 Mystic White

91 Dove

63 Vanilla

605 Cream

903 Fog

609 Taupe

802 Mocha

805 Bark

86 Earth

87 Chestunut

809 Chocolate

902 Seagull

905 Steel

97 Slate

908 Chincilla

909 Raven

37 Smokey Blue

303 Denim Blue

35 Royal

306 Naval Blue

308 Midnight Blue

31 Lagoon

54 Citron

21 Meadow

205 Spring

24 Deep Teal

44 Pumpkin Spice

14 Cherry Red

17 Garnet

108 Wine

109 Plum

66 Diamond

64 Pearl

102 Champagne

34 Spa

83 Tan

804 Amber

88 Tobacco

98 Charcoal

marine - awning - industrial fabrics | 11

clear plastic | roll & sheet Ennis Fabrics carries an extensive range of quality marine plastics to suit any budget. Our high quality Pressed Polish Sheets include STRATAGLASS and Oâ&#x20AC;&#x2122;SEA, brands that offer plastics with great optical clarity and durability. These products are formulated for maximum UV stability and feature scratch and chemical resistance. For marine and automotive windows that require more economical alternatives, we carry SUPER CLEAR, OKAMOTO and our own in-house line of plastic, ULTRA CLEAR, with or without paper. The variety in gauges provide convenient options for light to heavier-duty project needs.

Optically Clear Easy To C l e a n

Scratch Resistant

Sunscreen, Bug S p ray a n d J e t Fu e l Resistant Highly Durable

* T his information is offered for general guidance only. It is accurate to the best of our knowledge and is not intended to relieve the user from its responsibility to investigate and understand other pertinent sources of information and to comply with all laws and procedures applicable to the safe handling and use of this material. Please note: T he fabric and supply images displayed may not represent the actual product in its entirety.

12 | marine - awning - industrial fabrics

Contact your Sales Representative for more information.

DON’T LET POOR QUALITY

SINK YOUR SHIP. O’Sea® clear, smoke and green flexible window glass is optically clear, durable, and made start-tofinish in the USA. And did we mention our O’Sea® press polished sheets are sunscreen, bug spray, and jet fuel resistant? Install worry free windows by switching to O’Sea®.

SUNSCREEN, BUG SPRAY AND JET FUEL RESISTANT

OPTICALLY CLEAR WITH NO DISTORTION

DURABLE AND LONG LASTING

SCRATCH RESISTANT COATING ON BOTH SIDES

LIGHTFAST AND NO COLOR CHANGE

EASY TO CLEAN-JUST A MICROFIBER CLOTH AND WATER

ASK YOUR DISTRIBUTOR ABOUT O’SEA® and REGALITE® TODAY.

mesh SCREENING HEAVY MESH Content: 100% Polyvinyl Chloride (PVC) Yarn: 100% Polyester Cold Crack: -28°C (-18.4°F) Tear Strength: ASTM: Warp=67 lb, Weft=65 lb

White

Orange

Blue

Black

4 Florescent Orange

3 Blue

2 Green

7 Black

Red

Tensile Strength: ASTM: Warp=335 lb, Weft=335 lb Thread count: 9x9 threads/inch2 Width: 60” (152.4 cm) | Roll Size: 100 yd (91.44 m)

911 MESH 911 Mesh is a PVC extruded mesh with fi nished selvages. This product is recognized for both construction and quality. Field tested and approved for the highest satisfaction, 911 Mesh is ideal for outdoor usage.

Content: 100% Polyvinyl Chloride (PVC)

6 White

Yarn: 100% Polyester Cold Crack: -28°C (-18.4°F) Tear Strength: ASTM D5733: Warp=60 lb, Fill=60 lb Tensile Strength: ASTM D751: Warp=160 lb, Fill=140 lb Thread count: 11x11 threads/inch2 Width: 61” (155 cm) | Roll Size: 100 yd (91.4 m)

WE ALSO CARRY SCREENING BRAND

14 | marine - awning - industrial fabrics

polyester

DEFENDER

Abrasion: ISO 12927-2: 20,000 double rubs Content: 100% Polyester Construction: 600 denier Backing Content: 100% Polyurethane Water Repellent: AATCC 127 (Suter) - Average 600 mm. Thread count: 44 x 30 threads/inch2 Width: 59” (150 cm) | Roll Size: 50 yd (45.7 m)

108 Maroon

308 Navy

14 Red

46 Bright Orange (60”)

2009 Forest Green

27 Army Green

3006 Royal

505 Yellow

61 White

8003 Tan

TONTO

305 Med Blue

9003 Med Grey

9009 Black

108 Maroon

14 Red

2009 Forest

3006 Royal

308 Navy

505 Yellow

61 White

9009 Black

98 Smoke

Abrasion: 100,000+ double rubs Content: 100% Polyester Backing Content: 100% Polyvinyl chloride (PVC) Fire Retardancy*: CALTB117-2013 Thread count: 34 x 29 threads/inch2 UV Resistance: AATCC 16 Class 3.5 Width: 58” (147 cm) | Roll Size: 50 yd (45.7 m)

ALSO AVAILABLE FOR YOUR OUTDOOR APPLICATIONS 1S

marine - awning - industrial fabrics | 15

nylon 1 Red

111 Maroon

3 Royal

305 Medium Blue 32 Teal

333 Navy

4 Orange

44 Sport Gold

46 Blaze Orange Fluor.

5 Gold

699 Smoke

7 Black

6 White

69 Silver

2 Forest Green

28 Army Green

CORDURA Content: 100% Nylon

Construction: 1000 denier Backing content: 100% Polyurethane Water Repellent: AATCC 127 (Suter) - Average 350 mm.

787 Woodland

Thread Count: 34 x 26 threads/inch2 Width: 59” (150 cm) | Roll Size: 50 yd (45.7 m)

SPORTLIGHT

11 Red

2222 Forest

305 Blue

309 Midnight

33 Royal

55 Yellow

66 White

699 Silver

77 Black

994 Fluor. Orange

9009 Black FR

3 Royal Blue

OXFORD

Content: 100% Nylon

Construction: 420 denier Backing content: 100% Polyvinyl Chloride (PVC) Cold Crack: ≥ -20°C (-4°F) Thread Count: 48 x 34 threads/inch2 Width: 58” (147 cm) | Roll Size: 50 yd (45.7 m)

1 Red

2222 Forest

27 Olive Drab

Content: 100% Nylon

305 Medium Blue

308 Olympiad Blue

33 Canadiens Blue

55 Sport Yellow

Construction: 420 denier Backing content: 100% Polyurethane Water Repellent: AATCC 127 (Suter) - Average 800 mm.

66 White Opaque

7 Black

905 Platinum

9911 Light Grey

Width: 58” (147 cm) | Roll Size: 50 yd (45.7 m)

FR 9009 Black

16 | marine - awning - industrial fabrics

low temp vinyls LOW TEMPERATURE PERFORMANCE VINYLS Specifications for the following products can be found on the page numbers indicated below: TALLADEGA p.18 & p.144 SEALSKIN p.143 MIDSHIP p.8

BACKING CONTENT

COLD CRACK

MILDEW RESISTANT

TEAR STRENGTH

TENSILE STRENGTH

UV/ LIGHTFASTNESS

FIRE RETARDANCY*

WEIGHT

ROLL SIZE

ALLSPORT

100% Nylon

-50°C (-58°F)

≥ 1000 hours

CALTB117-2013; UFAC Class 1; MVSS 302; BIFMA Class 1

36oz./lin. yd 24.01oz/yd2

40 yd

ARCTIC -40

65% Polyester; 35% Cotton

-40°C (-40°F)

Yes

191A-5136: Warp=6lb Fill=9lb

ASTM D751: Warp=12lb Fill=8lb

≥ 500 hours

CALTB117-2013 MVSS 302

28.5oz./lin. yd 19.2oz./yd2

30 yd

BLIZZARD

100% Polyester

-30°C (-22°F)

ASTM D2261: Warp=6lb Fill=9lb

ASTM D751: Warp=43lb Fill=7lb

CALTB117-2013 MVSS 302

GAUCHO

100% Polyester

-40°C (-40°F)

ASTM D1117: Warp=16lb Fill=14lb

ASTM D751: Warp=80lb Fill=55lb

CALTB117-2013; UFAC Class 1; MVSS 302; BIFMA Class 1

26.5oz./lin. yd 17.7oz./yd2

50 yd

-20°C (-4°F)

MVSS 302

29.2oz./lin. yd 19.5oz./yd2

30 yd

-20°C (-4°F)

Yes

191A-5136: Warp=6lb Fill=9lb

ASTM D751: Warp=12lb Fill=8lb

≥ 500 hours

MVSS 302

28.0oz./lin. yd 18.7oz./yd2

30 yd

POLARIS

-40°C (-40°F)

Yes

≥ 300 hours

36.0oz./lin. yd 24.0oz./yd2

50 yd

SIERRA

-18°C (-0.4°F)

ASTM D573: Warp=22lb Fill=22lb

ASTM D751: Warp=80lb Fill=68lb

≥ 1000 hours

25.0oz./lin. yd 16.7oz./yd2

40 yd

-18°C (-0.4°F)

Yes

ASTM D1117: Warp=20lb Fill=18lb

ASTM D751: Warp=98lb Fill=80lb

CALTB117-2013; UFAC Class 1; MVSS 302; BIFMA Class 1

36.0oz./lin. yd 24.0oz./yd2

40 yd

-40°C (-40°F)

Yes

MVSS 302

38.5oz./lin. yd 25.7oz./yd2

30 yd

MADRID OXEN

WALLABY

WINTERZONE

65% Polyester; 35% Cotton

100% Polyester

≥ 1000 hours

30 yd

* T his information is offered for general guidance only. It is accurate to the best of our knowledge and is not intended to relieve the user from its responsibility to investigate and understand other pertinent sources of information and to comply with all laws and procedures applicable to the safe handling and use of this material. Please note: T he fabric and supply images displayed may not represent the actual product in its entirety.

marine - awning - industrial fabrics | 17

TALLADEGA

108 Wine

1111 Burgundy

14 Red

3006 Royal

302 Copen

3333 Indigo

47 Cinnamon

6 Brown

61 White

68 Buttermilk

808 Espresso

81 Camel

9003 Grey Mist

9009 Black

905 Grey

908 Charcoal

ACT PERFORMANCE INFORMATION:

Abrasion: 100,000+ double rubs Backing Content: 100% Polyester Breaking: Procedure A, CFFA 17—2012: Warp=74, Fill=52 Cold Crack: -30°C (-22°F) Content: 100% Polyvinyl Chloride (PVC) Elongation: ASTM D751: Warp: 31%, Weft: 144% Fi re Retardancy*: CALTB117-2013; MVSS302; Class 1; UFAC Class 1

NFPA260

UV Resistance: AATCC16 Class 4 Width: 54” (137 cm) | Roll Size: 30 yd (27.4 m)

18 | marine - awning - industrial fabrics

treated & untreated cotton canvas 4 Orange

MALLARD 2ND EDITION

5 Yellow

Mallard is a piece-dyed 10oz. 100% cotton duck fabric with a canvas construction that is manufactured in North America and is USMCA friendly.

111 Burgundy

Content: 100% Cotton

333 Navy

Construction: Canvas Fire Retardancy*: CALTB117-2013. UV resistance: AATCC 16 Class 4

7 Black

Thread Count: 76x28 threads/inch2 Water Repellent: Yes Weight: 10oz./yd2 Width: 54” (137 cm) | Roll Size: 50 yd (45.7 m)

UNTREATED CANVAS Content: 100% Cotton Construction: Canvas

CANU7072W 7 oz, 72” (183 cm)

CANU1260W 12 oz, 60” (152 cm)

CANU1036W 10 oz, 36” (91 cm)

CANU1860W 18 oz, 60” (152 cm)

CANU2160W 21 oz, 60” (152 cm)

CANU1060W 10 oz, 60” (152 cm)

CANU1272W 12 oz, 72” (183 cm)

CANU1560W 15 oz, 60” (152 cm)

CANUARMY60 10 oz, 60” (152 cm)

CANU2460W 24 oz, 60” (152 cm)

TREATED VS. UNTREATED CANVAS The term canvas refers to a heavy-duty

is an ideal material for the creation of

woven cotton fabric that is more than

tarps, bags and outerwear.

8oz./yd . Heavy-duty cotton canvas is 2

available treated or untreated.

Untreated canvas fabric is better suited for non-industrial indoor uses,

Canvas can be “waxed” using a

such as furniture slip covers, painter

product called CANVAK (#7199, p.118),

overalls, aprons, table coverings,

an oily substance that provides the

pillows, art canvases and theater or

material a certain degree of water

staging uses.

and mildew resistance. Treated canvas

marine - awning - industrial fabrics | 19

Sunbrella® Fabrics Beautiful

The Sunbrella Brand.

Durable Beautiful Bleach Cleanable Durable UV Resistant Bleach Cleanable Worry Free UV Resistant Worry Free Fade-resistant.

Sunbrella® is the most recognized and trusted name in performance fabrics for the Casual Furniture, Residential Furniture, Shade, Marine and Automotive markets for over fifty years. The Sunbrella Brand. Sunbrella® is the most recognized and trusted

Colorfastness. name in performance fabrics for the Casual

Furniture,fiResidential Furniture, Shade, and Sunbrella bers are saturated with highlyMarine UV stable Automotive markets for overmethods, fifty years.such as pigments. Traditional dyeing yarn or piece dyeing, only add color to the fiber exterior. All Sunbrella fabrics, including shade and Colorfastness. marine fabrics, offer performance characteristics Sunbrella fibers are saturated with highly UV stable that are an integral part of the fabric, not an pigments. Traditional dyeing methods, such as applied finish that would wash off over time. So yarn or piece dyeing, only add color to the fiber they will hold up to even the harshest outdoor exterior. All Sunbrella fabrics, including shade and environments, both on land and on the water. marine fabrics, offer performance characteristics Think of a carrot versus a radish. that are an integral part of the fabric, not an applied finish that would wash off over time. So they will hold up to even the harshest outdoor environments, both on land and on the water. Think of a carrot versus a radish.

1961

Mid 70’s

Revolutionary new Sunbrella® Sunbrella marine fabrics awning fabrics dramatically outlast begin protecting boats and cotton canvas. boaters worldwide.

1961

Mid 70’s

Sunbrella shade and marine fabrics are unmatched in resistance to fading and the degrading effects of sunlight.

Fade-resistant. Cleanable. Sunbrella shade and marine fabrics are unmatched in resistance to fading and the degrading effects Mild soap cleans most common stains. Using of sunlight. bleach or solvents for tough stains will not affect Sunbrella fabrics, but don’t try this with other fabrics. Cleanable. Mild soap cleans most common stains. Using

Durable. bleach or solvents for tough stains will not affect Sunbrellashade fabrics, butmarine don’t try this with Sunbrella and fabrics retainother their fabrics. after years of cleaning and weathering. strength

Durable. Sunbrella shade and marine fabrics retain their strength after years of cleaning and weathering.

Early 80’s

2002

2011

Sunbrella casual furniture fabrics turn patios into outdoor rooms.

Beautiful Sunbrella residential fabrics mean indoor furniture is now stress-free.

Sunbrella Contract launches for commercial upholstery applications

Early 80’s

2002

2011

turn patios into outdoor rooms.

fabrics mean indoor furniture is now stress-free.

for commercial upholstery applications

* T his information is offered for general guidance only. It is accurate to the best of our knowledge and is not intended to relieve the user from its responsibility to investigate and understand other pertinent sources ofRevolutionary information and to comply with®all laws and procedures applicable and use of this material. new Sunbrella Sunbrella marine fabrics to the safe handling Sunbrella casual furniture fabrics Beautiful Sunbrella residential Sunbrella Contract launches

awning fabrics dramatically outlast begin protecting boats and cotton canvas. boaters worldwide.

Please note: T he fabric and supply images displayed may not represent the actual product in its entirety.

20 | marine - awning - industrial fabrics

Specifying FIRESISTÂŽ fabric at the beginning of development is a solid decision.

Drawings are for visual representation only.

California State Fire Marshal Title 19 NFPA 701-99, test method II CPAI-84; Tent walls and roof FMVSS 302 FAA 25.853 (Aviation) UFAC Upholstered Furniture, Class 1

Specify FIRESIST for an up-to-code fire-resistant awning fabric that looks as good as it performs. Improved strength, colorfastness, and weather-resistance make fabrication with FIRESIST easier than ever. There has never been a smarter decision when it comes to quality, assurance and safety. For more information, contact Glen Raven customer service at 336.221.2211 or visit www.glenraven.com/firesist.

Endurepel™ is Ennis Fabrics’ exclusive range of performance finishes, that are applied to woven fabrics and PU textiles, with applications across a wide range of markets. The protective film forms an invisible, stain-resistant coating around the textile fibers or on top of the PU skin. Endurepel makes furniture easier to clean and features anti-microbial and anti-bacterial properties. Shop our extensive range of Endurepel™ finished products; Endurepel™ Fundamentals, Stability II, Stability III, Premier, and all other future collections at ennisfabrics.com.

EASY CLEANABILITY | REPELS LIQUID | STAIN RESISTANT

performance upholstery fabrics Our decorative fabrics feature beautiful colors, patterns, and textures. Ennis Fabrics offers an always increasing line of high quality products that will suit your every need. plains & textures - 26 pu/bonded - 33 pvc - 36

plains & textures STABILITY II - COHESION

6009 Aspen

908 Charcoal

308 Midnight

97 Graphite

44 Tangerine

27 Olive

ACT PERFORMANCE INFORMATION:

Abrasion: 160,000+ Double Rubs Content: 100% Polyester Fi re Retardancy: CALTB117-2013; NFPA 260 Class 1, UFAC Class 1, MVSS 302

17 Boreaux

Pilling: ASTM D3511 – Class 5 UV Resistance: AATCC 16 Class 4.5 Width: 55” (140 cm) | Roll Size: 55 yd (50.2 m)

205 Lime

34 Spa

405 Flame

STABILITY II - DIGNITY ACT PERFORMANCE INFORMATION:

87 Chocolate

9009 Black

94 Aluminum

Abrasion: 160,000+ Double Rubs Content: 100% Polyester Fi re Retardancy: CALTB117-2013; NFPA 260 Class 1, UFAC Class 1, MVSS 302

Pilling:

ASTM D3511 – Class 5

UV Resistance: AATCC 16 Class 4.5 Width: 55” (140 cm) | Roll Size: 55 yd (50.2 m)

26 | performance upholstery fabrics

STABILITY II - FORTITUDE

17 Bordeux

27 Olive

308 Midnight

44 Tangerine

6009 Aspen

908 Charcoal

ACT PERFORMANCE INFORMATION:

Abrasion: 160,000+ Double Rubs Content: 100% Polyester Fi re Retardancy: CALTB117-2013; NFPA 260 Class 1, UFAC Class 1, MVSS 302

97 Graphite

Pilling: ASTM D3511 – Class 5 UV Resistance: AATCC 16 Class 4.5 Width: 55” (140 cm) | Roll Size: 55 yd (50.2 m)

34 Spa

87 Chocolate

STABILITY II - STAMINA

94 Aluminum

ACT PERFORMANCE INFORMATION: 9009 Black

Abrasion: 160,000+ Double Rubs Content: 100% Polyester Fi re Retardancy: CALTB117-2013; NFPA 260 Class 1, UFAC Class 1, MVSS 302

Pilling:

ASTM D3511 – Class 5

UV Resistance: AATCC 16 Class 4.5 Width: 55” (140 cm) | Roll Size: 55 yd (50.2 m)

STABILITY II - SYMMETRY

37 Tidal

7009 Quarry

8009 Cocoa

ACT PERFORMANCE INFORMATION:

Abrasion: 160,000+ Double Rubs

9009 Black

Content: 100% Polyester Fi re Retardancy: CALTB117-2013; NFPA 260 Class 1, UFAC Class 1, MVSS 302

PIlling: ASTM D3511 – Class 5 UV Resistance: AATCC 16 Class 4.5 Width: 55” (140 cm) | Roll Size: 55 yd (50.2 m)

performance uphosltery fabrics | 27

STABILITY II - TENACITY

7003 Bluesteel

7009 Evening

702 Moss

708 Cliff

74 Harvest

77 Claret

ACT PERFORMANCE INFORMATION:

Abrasion: 52,000+ Double Rubs Content: 100% Polyester Fi re Retardancy: CALTB117-2013; NFPA 260 Class 1, MVSS 302

Pilling:

ASTM D3512 – Class 4.5

UV Resistance: AATCC 16 Class 4.5 Width: 55” (140 cm) | Roll Size: 55 yd (50.2 m)

17 Bordeaux

27 Olive

STABILITY II - UNITY

308 Midnight

ACT PERFORMANCE INFORMATION: 405 Flame

44 Tangerine

6009 Aspen

Abrasion: 160,000+ Double Rubs Content: 100% Polyester

9009 Black

Fi re Retardancy: CALTB117-2013; NFPA 260 Class 1,

908 Charcoal

UFAC Class 1, MVSS 302

Pilling:

ASTM D3511 – Class 5

UV Resistance: AATCC 16 Class 4.5 Width: 55” (140 cm) | Roll Size: 55 yd (50.2 m)

STABILITY II - VALOUR

205 Lime

34 Spa

87 Chocolate

94 Aluminum

97 Graphite

9009 Black

ACT PERFORMANCE INFORMATION:

Abrasion: 160,000+ Double Rubs Content: 100% Polyester Fi re Retardancy: CALTB117-2013; NFPA 260 Class 1, UFAC Class 1, MVSS 302

Pilling: ASTM D3511 – Class 5 UV Resistance: AATCC 16 Class 4.5 Width: 55” (140 cm) | Roll Size: 55 yd (50.2 m)

28 | performance upholstery fabrics

STABILITY III - AMBITION

102 Quartz

308 Midnight

37 Tidal

44 Tangerine

508 Maize

87 Brown

ACT PERFORMANCE INFORMATION:

Abrasion: 100,000 Double Rubs Content: 100% Polyester Fi re Retardancy: CALTB117-2013; NFPA 260 Class 1, UFAC Class 1, MVSS 302

709 Onyx

Pilling: ASTM D4970 – Class 4 UV Resistance: AATCC 16.3 Grade 4.5 Width: 57” (144 cm) | Roll Size: 50 yd (46 m)

17 Bordeaux

27 Olive

308 Midnight

STABILITY III - ASCEND

405 Flame

44 Tangerine

6009 Aspen

Abrasion: 75,000 Double Rubs

ACT PERFORMANCE INFORMATION:

Content: 100% Polyester 9009 Black

908 Charcoal

Fi re Retardancy: CALTB117-2013; NFPA 260 Class 1,

908 Charcoal

UFAC Class 1, MVSS 302

Pilling: ASTM D4970 – Class 3.5 UV Resistance: AATCC 16.3 Grade 4.5

9009 Black

STABILITY III - AXIS

Width: 57” (144 cm) | Roll Size: 50 yd (46 m)

37 Tidal

44 Tangerine

508 Maize

93 Smoke

76 Chili

809 Brindle

ACT PERFORMANCE INFORMATION:

Abrasion: 50,000 Double Rubs Content: 100% Polyester Fi re Retardancy: CALTB117-2013; NFPA 260 Class 1, UFAC Class 1, MVSS 302

709 Onyx

Pilling: ASTM D4970 – Class 3.5 UV Resistance: AATCC 16.3 Grade 4.5 Width: 57” (144 cm) | Roll Size: 50 yd (46 m)

performance uphosltery fabrics | 29

STABILITY III - BRAVERY

703 Nightshadow

902 Birch

ACT PERFORMANCE INFORMATION:

Abrasion: 105,000 Double Rubs Content: 100% Polyester Fi re Retardancy: CALTB117-2013; NFPA 260 Class 1, UFAC Class 1, MVSS 302

Pilling: ASTM D3511 – Class 5 UV Resistance: AATCC 16.3 Grade 4 Width: 59” (149 cm) | Roll Size: 50 yd (46 m)

703 Nightshadow

78 Tango

STABILITY III - PURSUIT

87 Chocolate

ACT PERFORMANCE INFORMATION: 97 Graphite

Abrasion: 105,000 Double Rubs Content: 100% Polyester Fi re Retardancy: CALTB117-2013; NFPA 260 Class 1, UFAC Class 1, MVSS 302

Pilling: ASTM D3511 – Class 5 UV Resistance: AATCC 16.3 Grade 4 Width: 59” (149 cm) | Roll Size: 50 yd (46 m)

STABILITY III - RESILIENT

102 Quartz

87 Chocolate

902 Birch

ACT PERFORMANCE INFORMATION:

Abrasion: 105,000 Double Rubs Content: 100% Polyester Fi re Retardancy: CALTB117-2013; NFPA 260 Class 1, UFAC Class 1, MVSS 302

Pilling: ASTM D3511 – Class 5 UV Resistance: AATCC 16.3 Grade 4 Width: 59” (149 cm) | Roll Size: 50 yd (46 m)

30 | performance upholstery fabrics

STABILITY III - SUMMIT

308 Midnight

39 Shade

508 Maize

602 Oatmeal

77 Canyon

82 Nutmeg

86 Walnut

908 Charcoal

94 Slate

ACT PERFORMANCE INFORMATION:

Abrasion: 90,000 Double Rubs Content: 100% Polyester Fi re Retardancy: CALTB117-2013; NFPA 260 Class 1, UFAC Class 1, MVSS 302

Pilling: ASTM D3511 – Class 5 UV Resistance: AATCC 16.3 Grade 3.5 Width: 57” (144 cm) | Roll Size: 50 yd (46 m)

27 Olive

306 Storm

96 Ash

STABILITY III - VALIANT

35 Coastal

ACT PERFORMANCE INFORMATION: 74 Fiesta

77 Canyon

84 Earth

Abrasion: 100,000 Double Rubs Content: 100% Polyester Fi re Retardancy: CALTB117-2013; NFPA 260 Class 1,

94 Slate

UFAC Class 1, MVSS 302

Pilling: ASTM D4970 – Class 4 UV Resistance: AATCC 16.3 Grade 4.5 Width: 57” (144 cm) | Roll Size: 50 yd (46 m)

STABILITY III - VITALITY ACT PERFORMANCE INFORMATION:

902 Birch

91 Dove

Abrasion: 105,000 Double Rubs Content: 100% Polyester Fi re Retardancy: CALTB117-2013; NFPA 260 Class 1, UFAC Class 1, MVSS 302

Pilling: ASTM D3511 – Class 5 UV Resistance: AATCC 16.3 Grade 4 Width: 59” (149 cm) | Roll Size: 50 yd (46 m)

performance uphosltery fabrics | 31

STABILITY III - ENDUREPEL MONROE

8009 Sable

81 Quartz

84 Hemp

9003 Pewter

902 Mica

91 Granite

14 Chipotle

308 Naval

86 Mineral

87 Trufﬂe

9006 Steel

9009 Black

ACT PERFORMANCE INFORMATION:

Abrasion: 165,000 Double Rubs Content: 100% Polyester Fi re Retardancy: CALTB117-2013; NFPA 260 Class 1, UFAC Class 1

Pilling: ASTM D3512 – Class 4 UV Resistance: N/A Width: 56” (142 cm) | Roll Size: 55 yd (50 m)

32 | performance upholstery fabrics

pu/bonded CLARO Claro is a soft PU with a sandstone grain, giving it a unique textural look.

ACT PERFORMANCE INFORMATION:

600 Bone

902 Alabaster

602 Cream

6003 Beige

606 Tan

8009 Amber

6009 Taupe

67 Slate

9003 Ash

89 Tobacco

87 Beaver

9006 Gunmetal

905 Smoke

908 Graphite

909 Charcoal

Abrasion: 100,000+ Double Rubs Content: 100% Polyurethane (PU) Backing Content: 85% Polyester, 15% Cotton Fi re Retardancy: CALTB117-2013; MVSS302; NFPA260 Class 1

Hydrolysis: ASTMD3690-02

Sect.6.11,ISO 1419 Method C (Accelerated Ageing) (Jungle Test) 10 weeks

UV Resistance: AATCC16 Class 5 Width: 58â&#x20AC;? (147 cm) | Roll Size: ~40 yd (36 m)

9009 Dusk

performance uphosltery fabrics | 33

PREMIER Premier is an eco-friendly, high performance polyurethane. It features the Endurepel Armour easy-clean performance finish and is a nti bacterial.

ACT PERFORMANCE INFORMATION:

3822 White

61 Vanilla

6003 Cream

9003 Grey

605 Parchment

95 Quicksilver

3948 Taupe

608 Sandstone

905 Steel

808 Mocha

6009 Chinchilla

9009 Black

8020 Chocolate

87 Chestunut

805 Bisque

84 Earth

802 Tan

108 Wine

11 Brick

44 Pumpkin Spice

14 Rust

17 Garnet

24 Deep Teal

1009 Plum

3006 Navy

3003 Pacific Blue

37 Lagoon

54 Citron

21 Meadow

205 Sprig

Abrasion: 500,000+ Double Rubs Content: 100% Polyurethane (PU) Backing Content: 85% Polyester, 15% Cotton Cold Crack: -30°C (-22°F) Fi re Retardancy: CALTB117-2013; NFPA260 Class 1; UFAC Class 1

Hydrolysis: ASTMD3690-02

Sect.6.11,ISO 1419 Method C (Accelerated Ageing) (Jungle Test) 10 weeks

UV Resistance: AATCC16 Class 4.5 Width: 54” (137 cm) | Roll Size: ~40 yd (36 m)

34 | performance upholstery fabrics

TURNER Turner brings an incredibly soft hand tp contract seating and upholstery. Made of 100% polyurethane, Tuner is designed for a soft touch but with strength and durability for high usage areas. Available in 27 versatile colors.

ACT PERFORMANCE INFORMATION: Abrasion: 500,000+ Double Rubs Content: 100% Polyurethane (PU)

3822 White

61 Vanilla

6003 Cream

605 Parchment

3948 Taupe

608 Sandstone

37 Lagoon

3003 Pacific blue

3006 Navy

54 Citron

205 Sprig

1009 plum

14 Rust

17 Garnet

108 Wine

84 Earth

87 Chestnut

805 Bisque

802 Tan

808 Mocha

8020 Chocolate

9003 Grey

6009 Chinchilla

11 Brick

905 Steel

9009 Black

95 Quicksilver

Backing Content: 70% Polyester, 30% Cotton Cold Crack: -40°C (-40°F) Fi re Retardancy: CAL117 – Section E; MVSS 302; UFAC Class 1; NFPA 260

UV Resistance: AATCC16 Class 4.5 Width: 54” (137 cm) | Roll Size: 30 yd (27.4 m)

performance uphosltery fabrics | 35

pvc

61 White Cap

602 Mystic White

91 Dove

63 Vanilla

605 Cream

903 Fog

Challenger has the soft feel of leather and demonstrates both durability and strength. Challenger performs well across numerous markets and testing parameters ensuring that it will become your go to vinyl in almost any application.

609 Taupe

802 Mocha

805 Bark

ACT PERFORMANCE INFORMATION:

86 Earth

87 Chestunut

809 Chocolate

902 Seagull

905 Steel

97 Slate

908 Chincilla

909 Raven

37 Smokey Blue

303 Denim Blue

35 Royal

306 Naval Blue

308 Midnight Blue

31 Lagoon

54 Citron

21 Meadow

205 Spring

24 Deep Teal

44 Pumpkin Spice

14 Cherry Red

17 Garnet

108 Wine

109 Plum

66 Diamond

64 Pearl

102 Champagne

34 Spa

804 Amber

88 Tobacco

98 Charcoal

CHALLENGER

Abrasion: 1,500,000+ Double Rubs Content: 100% Polyvinyl Chloride (PVC) Backing Content: 100% Polyester Cold Crack: -55°C (-67°F) Fi re Retardancy: CALTB117-2013, IMO FTP Code

2010 - Part 8, MVSS302, NFPA 260 Class 1, UFAC Class 1

UV Resistance: AATCC 16.3 - Grade 4.0 (1,500 hours) Width: 55” (140 cm) | Roll Size: 30 yd (27 m)

83 Tan

36 | performance upholstery fabrics

SEALSKIN Sealskin is an upholstery vinyl with superb abrasion, high cold crack and fi re resistance. It also features great elongation. Sealskin comes in 37 popular solids for all your upholstery needs.

61 Mystic White

66 Adobe White

68 Parchment

67 Bone

81 Bisque

6009 Taupe

905 Seagull

99 Dove

21 Moss

202 Sage

22 Dusty Jade

8009 Bronze

84 Oak

8006 Cinnamon

808 Mocha

405 Rust

111 Claret

1111 Burgundy

16 Mauve

161 Tea Rose

108 Plum

11 American Beauty

505 Sun Yellow

23 Grotto

34 Turquoise

222 Forest

24 Dark Aqua

31 Baltic Mist

37 Slate Blue

393 Blue Ridge

3 Royal

333 Regimental Blue

3333 Imperial Blue

97 Slate

1009 Amethyst

2009 Yew Green

ACT PERFORMANCE INFORMATION:

Abrasion: 500,000+ Double Rubs Content: 100% Polyvinyl Chloride (PVC) Backing Content: 100% Polyester Cold Crack: -28°C (-18°F) Fi re Retardancy: CALTB117-2013; MVSS302; NFPA260 Class 1; UFAC Class 1

UV Resistance: AATCC16 Class 4.5. Width: 54” (137 cm) | Roll Size: 30 yd (27 m)

77 Black

performance uphosltery fabrics | 37

marine / awning / upholstery supplies No matter what project you are working on, we carry every supply needed. With over 5,000 items at your fingertips, the possibilities are endless! padding & decking webbing hook & loop fasteners zippers awning hardware marine hardware grommets industrial & bag hardware tools needles & thread binding & cordage tape trimming tacks & nails buttons cleaners, protectants & adhesives

40 41 44 50 56 64 66 80 82 89 105 113 122 126 134 137 141

padding & decking Closed Cell Foam

¹/₈” ¼” ³/₈” ½”

DIMENSIONS PART #

PRICE BREAKS

FOACC4499

Cut (Yd), Roll 280 yd

FOACC4500

Cut (Yd), Roll 140 yd

FOACC4501

Cut (Yd), Roll 93 yd

FOACC4502

Cut (Yd), Roll 70 yd

DESCRIPTION Closed cell foam on a continuous roll with a 60” width. This foam is non-absorbent and resilient. Can be used for backpacking, mats, exercise mats, padding for athletic equipment, costumes, mascots, underpad for landau tops or anything where moisture is of concern.

SEW FOAM Our Ennis Fabrics Sew Foam is a regular roll foam with a Cerex backing applied. This is suitable for quilting applications without using a separate backing material. A real time-saver on stitched seat panels.

Constructed from 100% Polyurethane for a pliable pink foam. Great also for molding and shaping. This product is sold by the roll.

B B

FOARE4365 FOARE4371

½” x 58” x 60’—Pink ¼” x 58” x 60’—Pink Price Breaks: Roll (60’)

PADDING: FIBER, JAY FLEX & FELT

OUTDOOR CUSHION FIBER

Specialized fiber for outdoor cushions, prevents moisture from being caught within the cushion, maintaining cushion quality. Available at all distribution centers.

PADFI8261

C C

PADFI8265

Cushion Fiber—4”x22”x28” Price Breaks: Each | Case (8)

PADFI8267

Cushion Fiber—4”x22”x48” Cushion Fiber—4”x22”x78” Price Breaks: Roll | Box (4 Rolls) | Case (8 Rolls)

BURLAP*

Burlap is eco-friendly as it is made of renewable Jute fibers. It can be used for deckings, pull cloths and packaging. Available in: Cut length Pieces | Sizes vary from 80 –120yd Bales | 1900yd

LINBU2219

40” Burlap 10 oz. Price Breaks: Yard | 100 yd | Bale (1900 yd) * Minimum order of 10 yards. For more info, contact Sales Rep.

40 | marine - awning - upholstery supplies

Webbing can be combined with buckles, hooks, sliders and other fasteners to create a variety of sport bags, cases and specialty items. Specialty Webbing is woven from various materials such as cotton, nylons, polypropylene and polyester. Also available is the Sunbrella ® -brand webbing made from a blend of acrylic and polyester.

webbing

SUNBRELLA® WEBBING

The Sunbrella ® -brand webbing is constructed from 78% solution-dyed acrylic and 22% polyester. It is UV-resistant at a minimum grade 4 at 2200 hours when tested against AATCC 169-2003. The product also passes lightfast test SAE 1960J with a minimum grade 4 at 1500 hours.

A B C D E

D E

WEBSU13127 WEBSU13128 WEBSU13126 WEBSU13129 WEBSU13125

Sunbrella® is a registered trademark of Glen Raven, Inc.

Sunbrella ® Webbing—Jet Black 6608 Sunbrella ® Webbing—Cadet Grey 6630 Sunbrella ® Webbing—White 6604 Sunbrella ® Webbing—Burgundy 6631 Sunbrella ® Webbing—Pacific Blue 6601

Price Break: Roll (25 yd), Case (22 Rolls)

POLYESTER WEBBING Used for backpacks, bags, boat tops, boat covers, outdoors and outerwear. UV-resistant.

WEBPO13130

1” Polyester Webbing—White Tensile Strength: 5000 lb (2268 kg)

WEBPO13131

1” Polyester Webbing—Black Tensile Strength: 4000 lb (1814 kg)

F H G

Price Breaks: Roll (50 yd) | Case (10 Rolls)

POLYESTER TIE-DOWN WEBBING Thick, heavy, all-weather tie-down webbing used on truck beds and cargo straps. These goods will work well with tie-down ratchets and hooks. Used to create custom tie-downs for any configuration required.

WEBPO9701

1” Polyester Tie-Down Webbing—10 yd Roll

Break Strength: 3500 lb (1588 kg)

H H

WEBPO9703

3” Polyester Tie-Down Webbing—10 yd Roll

WEBPO9707

3” Polyester Tie-Down Webbing—100 yd Roll

Break Strength: 15,000 lb (6804 kg)

H H

WEBPO9702

2” Polyester Tie-Down Webbing—10 yd Roll

WEBPO9706

2” Polyester Tie-Down Webbing—100 yd Roll

H H

WEBPO9704

4” Polyester Tie-Down Webbing—10 yd Roll

WEBPO9708

4” Polyester Tie-Down Webbing—100 yd Roll

Break Strength: 10,000 lb (4536 kg)

Break Strength: 20,000 lb (9072 kg)

9 Tufting Twine (#8125) is recommended for sewing tie-downs. Note: # Price Breaks (10 yd rolls): Roll (10 yd) | Box (5 rolls) | Case (10 rolls) Price Break (100 yd rolls): Roll (100 yd) | Box (5 rolls) | Case (10 rolls) I

COTTON WEBBING I J K

WEBCO9831 WEBCO9832 WEBCO9550

1” Cotton Webbing—Natural 1½” Cotton Webbing—Natural 2” Heavy Cotton Webbing—Natural

Price Breaks: Roll (50 yd) | Case (10 Rolls)

marine - awning - upholstery supplies | 41

NYLON WEBBING

REGULAR

Break Strength: 1” - 1005 lb (456 kg) 1½” - 1750 lb (793.8 kg)

2” - 2015 lb (914 kg)

Price Breaks: Roll (100 yd) | Box (5 rolls) | Case (10 rolls)

HEAVY-DUTY

Break Strength: ¾” - 1980 lb (898 kg)

Black Royal Olive Drab Red White Yellow

A Black B Royal D Red

1” - 2390 lb (1084 kg) 1½” - 3620 lb (1642 kg) 2” - 6920 lb (3139 kg)

A B C D E F

1”

1½”

2”

WEBNY9851

WEBNY9822

WEBNY 9824

WEBNY9844

WEBNY9821

WEBNY9846

WEBNY9850

WEBNY9892

¾”

1”

1½”

2”

WEBNY9782

WEBNY9791

WEBNY9792

WEBNY9793

WEBNY9794

WEBNY9797

Price Breaks: Roll (50 yd) | Box (5 rolls) | Case (10 Rolls)

POLYPROPYLENE WEBBING

REGULAR

H I

A general purpose webbing for garment applications.

Price Breaks: Roll (50yd) | Case (10)

K L M N O P

HEAVY-DUTY

The heavy-duty polypropylene webbing can be used for loadbearing purposes on garment and bag applications.

R S

Price Breaks: Roll (50yd) | Case (10)

¾” G H I J K L M N O P Q R S

Olive Dark Grey Navy Red Tan Yellow White Silver Orange Green Royal Burgundy Black

WEBPP9720

1”

1½”

2”

WEBPP9716

WEBPP9717

WEBPP9718

WEBPP9864

WEBPP9863

WEBPP9859

WEBPP9858

WEBPP9868

WEBPP9852

WEBPP9856

WEBPP9866

WEBPP9769

WEBPP9770

WEBPP9771

WEBPP9893

WEBPP9894

WEBPP9895

WEBPP9780

WEBPP9874

WEBPP9855

WEBPP9865

WEBPP9861

WEBPP9862

WEBPP9878

WEBPP9766

WEBPP9767

WEBPP9768

WEBPP9905

WEBPP9903

WEBPP9904

WEBPP9853

WEBPP9857

WEBPP9867

WEBPP9898

WEBPP9899

WEBPP9900

WEBPP9781

WEBPP9869

WEBPP9860

WEBPP9870

¾” Heavy-Duty Polypropylene Webbing—Black Break Strength: 515 lb (234kg)

M S

WEBPP9734 WEBPP9733

1” Heavy-Duty Polypropylene Webbing—White 1” Heavy-Duty Polypropylene Webbing—Black Break Strength: 702 lb (318kg)

4-PANEL POLYPROPYLENE WEBBING

A general purpose polypropylene webbing with great aesthetics and shine for bag and apparel applications.

WEBPP9570

1” 4-Panel Polypropylene Webbing— Black

Break Strength: 596lb (270kg) Pr ice Breaks: Roll (50yd) | Case (10)

42 | marine - awning - upholstery supplies

M S

WEBPP9736 WEBPP9735

1½” Heavy-Duty Polypropylene Webbing—White 1½” Heavy-Duty Polypropylene Webbing—Black Break Strength: 1086 lb (493kg)

M S

WEBPP9738 WEBPP9737

2” Heavy-Duty Polypropylene Webbing—White 2” Heavy-Duty Polypropylene Webbing—Black Break Strength: 1428 lb (648kg)

FURNITURE WEBBING A

Over 90% of all furniture sold in Europe uses a webbing suspension system. Webbing is more economical than springs, easy to install (can be applied to wooden frames with standard staples), comfortable and gives a greater freedom of frame design than with traditional sinuous springs. #5 is firmer webbing than #3; however, both can be used on seating. #1 Soft is recommended for backs. Approximately 15% stretch is recommended as a cutting length guide. Price Breaks: Roll (54yd) | Box (5 Rolls) | Case (10 Rolls)

A B C D

D C

PROPEX WEBBING

WEBFU9712

2” Furniture Webbing—#1 Soft

WEBFU9710

2” Furniture Webbing—#3 Medium

WEBFU9714

2¾” Furniture Webbing—#3 Medium

WEBFU9715

2” Furniture Webbing—#5 Firm

100% polyolefin webbing. A tightly woven webbing in a 3½” width that resists rot and mildew. All synthetic fibers are strong and sanitary. Roll sizes vary from 100 m–140 m. Price Breaks: Roll (~229m) | Case (500)

WEBPR9699

3½” Propex Webbing

JUTE WEBBING

Traditional upholstery jute webbing weighs 9 lb (4 kg). Used for decades as the base for coil spring units, seat strapping, etc. Price Breaks: Roll (72yd) | Box (12 Rolls) | Case (24 Rolls)

WEBJU9709

3¼” Jute Webbing

SEAT BELT WEBBING

NON-RETRACTABLE LAP BELT

2”-width seat belt webbing material meets MVSS302 automotive fi re code. Extremely strong, with a fi ne weave and soft hand. It is easy to sew and fl exible.

Replacements for recreational vehicles, vans, trucks and wheelchairs. Comes in 74” or 90” length, positivelocking seat belts with sturdy mounting. Available in black to coordinate with interiors. H

WEBSE9875

Seat Belt Webbing—Black

Break Strength: 4,000lb (1,814kg)

H H

Price Breaks: Roll (100yd) |

BASVA9696

74” Non Retractable Lap Belt

BASVA9686

90” Non Retractable Lap Belt

Box (5 ea) |Case (15 ea)

KNIT ELASTIC

¾” Knit Elastic—White Roll Size: 136.7 yd

J K -

ELAKN4241

1” Knit Elastic—White

ELAKN4243

1” Knit Elastic—Black

ELAKN4246

1½” Knit Elastic—Black

I J

ROPE TIE-DOWN RATCHET

Rope tie-down ratchet with rubber-tipped hooks for use with ¼” rope. It is compact and easy to use. This ratchet is made specifi cally for outdoor marine use, but can be used in many other settings as well. Just tug on the rope until it is tight. To release, pull on the rope the same way as when tightening and release the trigger. Replacement Hooks (#9479) available separately.

TIEHO13003

¼” Rope Tie Down Ratchet

Price Breaks: Bag (2 ea) | Box (25 bags) | Case (50 bags)

WOVEN ELASTIC Stronger elastic for heavy-duty applications such as suspenders, sports equipment, equestrian applications (horse boots), bag straps for packs, wrist bands, orthotics (splints and supports) and more. Use wherever a strong memory elastic is required. Constructed from 84% polyester and 16% rubber. Shrinkage: 3% Stretch: 80% Price Breaks: Roll (54 yd) | Box (5 rolls) | Case (10 rolls)

L M -

Roll Size: 54 yd

Constructed from 62% polyester and 38% rubber. Knit elastics are lighter than woven elastics but still strong enough to be used for waistbands, slipcovers, drapery tire covers, boat covers or to hold cushions on furniture and for a variety of apparel applications.

ELAKN4249

Price Breaks: Each |

Box (5 rolls) | Case (10 rolls)

ELAWO4253

1” Woven Elastic—White

ELAWO4254

1” Woven Elastic—Black

ELAWO4256

1½” Woven Elastic—Black

ELAWO4258

2” Woven Elastic—Black

TRUCK TARP REINFORCEMENTS

Seat belt seconds are webbing products that have been rejected for seatbelt use as they do not meet the stringent automotive safety requirements. However, their high load strength make them ideal for truck tarp reinforcements.

WEBSE9872

Seat Belt Seconds—Black or Grey (dependent on availability)

Roll Size: ~220 yd Break Strength: 4000 lb Price Break: Full Rolls Only

marine - awning - upholstery supplies | 43

hook & loop VELCRO® SEW-ON This nylon fastener is a two-part system; one part consisting of rows of hooks and the other part a mass of loops. When pressed together, they form a highly secure closure, yet can be easily re-opened with a simple peeling action. Velcro ® Hook and Loop fastening system retains 50% fastening strength in water, then returns back to 100% when dried. Completely washable and dry cleanable, these jam-proof fasteners are adjustable and increase strength with pressure. They are available in sew-on or pressure-sensitive adhesive back forms. All Velcro ® Hook and Loop can be sterilized or autoclaved.

A Black Hook Black Loop White Hook White Loop

¾”

1”

1½”

2”

4”

VELSE9129

VELSE9058

VELSE9060

VELSE9062

VELSE9133

VELSE9130

VELSE9059

VELSE9061

VELSE9063

VELSE9134

VELSE9131

VELSE9052

VELSE9054

VELSE9056

VELSE9135

VELSE9132

VELSE9053

VELSE9055

VELSE9057

VELSE9136

Max Ironing Temperature: 163°C (325°F)

Melting Temperature: 204°C (399°F)

VELCRO® PRESSURE-SENSITIVE Velcro® Brand Tempo pressure-sensitive hook and loop fastener has a superior grade of adhesive backing that is suitable for most applications—indoor and out. This product has superior bond strength to high energy surfaces. The pressure-sensitive adhesives have a high temperature resistance and a high resistance to plasticizer migration. Designed for use in applications requiring fast turnaround under production conditions such as in packaging, medical, toys and other markets.

¾” Black Hook Black Loop White Hook White Loop

1”

1½”

2”

VELPS9121

VELPS9108

VELPS9125

VELPS9110

VELPS9122

VELPS9109

VELPS9126

VELPS9111

VELPS9123

VELPS9113

VELPS9127

VELSE9142

VELPS9124

VELPS9114

VELPS9128

VELSE9143

Price Breaks: Roll (25 yd) | Box (5 rolls) | Case (10 rolls)

VELCRO® POLYESTER

NEW!

Velcro ® Brand polyester hook and loop fastener made for use outdoors. Ideal for use with boat covers and even outerwear. Available in black and white.

1” B

B C D E

Black Hook White Hook Black Loop White Loop

2”

VELPO13045

VELPO13202

VELPO13043

VELPO13200

VELPO13044

VELPO13203

VELPO13042

VELPO13201

Price Breaks: Roll (25 yd) | Box (10 rolls) | Case (20 rolls) D

VELCRO® FR

NEW!

Durable and sewable, this prodcut is best used for fi refi ghting equipment, aerospace interiors automotive interiors, protective clothing, and insulation wraps. E

Black Hook Black Loop

1”

2”

VELSE13078

VELSE13080

VELSE13079

VELSE13081

Price Breaks: Roll (50 yd) | Box (10 rolls) | Case (20 rolls)

44 | marine - awning - upholstery supplies

VELSTICK HOOK & LOOP & DISPLAY DOTS A semi-rigid, flat vinyl extrusion with a protective beading along both side edges. The face has a permanently attached Velcro ® -brand woven nylon or polyester hook or loop, or molded hook fastening component. Staple, screw, nail, rivet or slide into a special metal extrusion to attach. Ideal for use on tents, camping trailers, stationary and patio awning ties, and many marine uses. A

VELSTICK HOOK & LOOP—BLACK A A

VELST9067

1” Velstick Black Hook

VELST9066

1” Velstick Black Loop

Size: 1” x 48” Price Breaks: Each | Box (5 ea) | Case (10 ea)

VELSTICK HOOK & LOOP—WHITE B B

VELST9064

1” Velstick White Hook

VELST9065

1” Velstick White Loop

Size: 1” x 48” Price Breaks: Each | Box (5 ea) | Case (10 ea)

DISPLAY DOTS These Display Dot “coins” feature top-quality, high-tack adhesives. They come on a peel-off roll and are ideal for trade shows, demonstrations, displays, etc. Made of a display-grade hook component, these dots will stick to any loop-style backing but is best used with Ennis Fabrics’ line of Display Fabric.

VELPS9120

¾” Display Dots White Hook

Price Breaks: Box (200 ea) | 5 boxes (200 ea) | Case (10 boxes)

ALFA-LOK NEW! VELCRO brand Alfa-Lok is a self-engaging tape that provides a strong and reliable connection. This robust fastening system is suitable for a wide range of environments and substrates encompassing Industrial, Transportation, Marine and Construction applications.

VELAL9068

1” Alfa-Lok Black

Price Breaks: Roll (25 yd) | Box (5 rolls) | Case (10 rolls)

REPURPOSING YOUR SCRAPS:

Hook & Loop Use scraps to hang lightweight photo frames on a wall. Keep seat cushions from sliding off a chair. Use the hook side of the tape to remove pills from your upholstered seats or clothes.

marine - awning - upholstery supplies | 45

Velcro Industries offers a portfolio of products that incorporate our hook and loop technology into materials and components that help companies be more innovative and competitive. Whether itâ&#x20AC;&#x2122;s a standard product or a solution customized to your design and manufacturing specifications, Velcro Industries puts more than 50 years of expertise in design, process, and logistics into our productsâ&#x20AC;&#x201D;and your success. For more information contact your local Ennis Sales Representative.

46 | marine - awning - upholstery supplies

S I LV ERT EX ®

orders and inquiries: 1-800-333-0955

South corporate offices Pelham, Alabama

fax: 1-205-985-2354 / 1-205-985-9176

West La Mirada, California

e-mail: sales@spradlingvinyl.com

East Westampton, New Jersey

url: www.spradlingvinyl.com

International Barcelona, Spain / Lüneburg, Germany

Made exclusively for Spradling International, Inc. by Proquinal S.A., Colombia, and Proquinal Costa Rica S.A. - An ISO 9001, TS 16949 company

WHIS PE R

SPR ADLI NGVI N Y L.CO M

HOOK & LOOP: 3M® PRESSURE-SENSITIVE 3M ®’s Premium Performance 70 series Scotchmate Hook and Loop is designed for static load applications where temperatures may reach 93°C (200°F) as in automotive, aircraft, electronics and business equipment. This product is usable under stringent wet, dry, hot and cold cycling conditions. Operating temperature range is -29°C to 93°C (-20°F to 200°F). Recommended on base metals, painted metals, polystyrene, acrylic polycarbonate, rigid vinyl and glass.

3M ® PRESSURE-SENSITIVE PREMIUM PERFORMANCE HOOK & LOOP—BLACK A B

VELPS9106

1” Hook—Black

VELPS9107

1” Loop—Black

Price Break: Roll (50 yd) | Box (3 rolls) | Case (6 rolls)

JEF HOOK & LOOP: PRESSURE-SENSITIVE This nylon fastener is a two-part system—one part consisting of rows of hooks and the other part a mass of loops. When pressed together, they form a highly secure closure, yet can be easily peeled apart. The JEF-brand of Pressure Sensitive hook and loop tape is an economical alternative to competitor brands. They are recommended for lighter duty applications and should not be used for all-weather outdoor applications such as attaching tonneau covers, etc.

PRESSURE SENSITIVE HOOK C

C D E

White Black Beige

1”

2”

VELPS9090

VELPS9092

VELPS9080

VELPS9082

VELPS9070

Price Breaks: 1” : Roll (27.3 yd) | Box (10 rolls) | Case (40 rolls) 2” : Roll (27.3 yd) | Box (10 rolls) | Case (40 rolls)

PRESSURE SENSITIVE LOOP -

White Black Beige

1”

2”

VELPS9091

VELPS9093

VELPS9081

VELPS9083

VELPS9071

Price Breaks: 1” : Roll (27.3 yd) | Box (10 rolls) | Case (40 rolls) 2” : Roll (27.3 yd) | Box (10 rolls) | Case (40 rolls)

48 | marine - awning - upholstery supplies

JEF HOOK & LOOP: SEW-ON This nylon fastener is a two-part system. One part that has rows of hooks and the other part has a mass of loops. When pressed together, they form a highly secure closure, yet can be easily peeled apart. This is a widely popular product for garments, bags, footwear, tents and furniture. Completely washable and dry cleanable, these jam-proof elements are adjustable and increase strength with pressure. They are available in sew-on or pressure sensitive adhesive back forms.

JEF SEW ON HOOK A B C D E F

Black Beige White Grey Royal Red

(546 yd roll)

1”

1½”

2”

4”

VELSE9002

VELSE9004

VELSE9026

VELSE9008

VELSE9006

VELSE9024

VELSE9028

VELSE9038

VELSE9044

VELSE9048

VELSE8984

VELSE9012

VELSE9014

VELSE9030

VELSE9010

VELSE9016

VELSE9018

VELSE8996

VELSE8998

VELSE9000

¾”: Roll (27.3yd) | Box

VELSE8992

VELSE8994

(10 rolls) | Case (48 rolls)

VELSE8980

VELSE8982

¾”

VELSE8986 -

1”

PRICE BREAKS

(27.3 yd roll)

⁵⁄₈”

⁵⁄₈”: Roll (27.3yd) | Box (10 rolls) | Case (60 rolls)

1”: Roll (27.3yd) | Box (10 rolls) | Case (40 rolls)

JEF SEW ON LOOP A B C D E F

Black Beige White Grey Royal Red

(27.3 yd roll)

1”

(546 yd roll)

1½”

2”

4”

VELSE9005

VELSE9027

VELSE9009

VELSE9007

VELSE9025

VELSE9029

VELSE9039

VELSE9045

VELSE9049

VELSE8985

VELSE9013

VELSE9015

VELSE9031

VELSE9011

VELSE9017

VELSE9019

VELSE8997

VELSE8999

VELSE9001

VELSE8993

VELSE8995

VELSE8981

VELSE8983

⁵⁄₈”

¾”

VELSE8987

VELSE9003

1”

JEF SEW ON HOOK/LOOP The tape features hook on one side and loop on the other. A A

VELSE9032

1” Hook/Loop—Black

VELSE9034

2” Hook/Loop—Black

Price Breaks 1”: Roll (27.3 yd) | Box (10 rolls) | Case (40 rolls) Price Breaks 2”: Roll (27.3 yd) | Box (10 rolls) | Case (20 rolls)

marine - awning - upholstery supplies | 49

fasteners

DURA SNAP: NICKEL-PLATED BRASS A heavy-duty button-style fastener. Socket construction assures a firm grip which is maintained throughout use. Used in automotive, industrial and marine trades. A

DURA SNAP POSTS H

J K

FASDB3995

Dura Snap Post—Long

FASDB4007

Dura Snap Post—Standard Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

DURA SNAP PLASTIC CAPS

SELF-TAPPING SCREW STUD—STAINLESS STEEL

Solid nylon top will not chip or fade. Ideal for color-matching to

Nickel-plated brass stud with a stainless steel Phillips head.

Sunbrella ® products.

A B C D

FASDS4008

⅜” Dura Snap Screw Stud—Stainless Steel

Dura Snap Plastic Cap—Black

FASDB3968

Dura Snap Plastic Cap—Grey

FASDB3964

Dura Snap Plastic Cap—White

FASDB3976

Dura Snap Plastic Cap—Navy Blue

STIK-A-STUD FASTENER

Price Breaks: Bag (100 ea) | Box (5 bags) |

A Delrin-molded stud with an extremely aggressive 3M adhesive

Case (10 bags)

tape backing. Can be applied to any clean, non-porous

DURA SNAP CAPS Use with socket #4003. Diameter of cap is ⁹⁄₁₆”.

E F G

FASDB3960

FASDB4002

Dura Snap Cap—Black

FASDB4001

Dura Snap Standard Cap

FASDB4000

Dura Snap Long Barrel Cap

Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

surface indoors or out. Remove without damage by applying an alcohol solution to the edge of the stud. To be used with Dot ® Dura Snap and Dot ® Durable fasteners.

M N

FASST4099

Stik-A-Stud Fastener—Black

FASST4098

Stik-A-Stud Fastener—White Price Breaks: Bag (10 ea) | Box (5 bags) |

Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

DURA SNAP SOCKET Standard socket for use with all Dura Snap Caps.

FASDB4003

Dura Snap Socket Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

DURA SNAP STUD

Case (10 bags)

YKK® SNAD ® DOME

A low-profile socket to be used wherever a snap is required, without the hassle of drilling. YKK® SNAD ® Dome features 3M’s high-quality adhesive to ensure great hold on Marine Carpeting and Canvas for decks, bulkheads or panels, upholstery cushions, seating and console covers.

O P

FASST4095

YKK SNAD® Dome—White

FASST4097

YKK SNAD® Dome—Black

For use with Dura Snap Posts (#FASDB4007 or #FASDB3995), or with

Price Breaks: Bag (10 ea) | Box (5 bags) |

#6 Head Screw.

Case (10 bags)

FASDB4004

Dura Snap Stud Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

50 | marine - awning - upholstery supplies

BABY DURA SNAP: NICKEL-PLATED BRASS BABY DURA SNAP CAPS & POST

BABY DURA SNAP SOCKET

Use with socket #FASBB3997. Diameter of cap is ½”.

A B C

FASBB3992

Baby Dura Snap Cap—Black Brass

FASBB3996

Baby Dura Snap Cap—Nickel

FASBB3999

Baby Dura Snap Post—Nickel Brass

FASBB3997

Baby Dura Snap Socket Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

BABY DURA SNAP STUD D

FASBB3998

Baby Dura Snap Stud—Nickel Brass

Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

DURA SNAP: NICKEL-PLATED STEEL Nickel-plated steel Dura Snap fasteners are very strong and durable. They are ideal for garment, luggage, sports bags and apparel, as well as applications on indoor automotive and aircraft projects. Due to their steel content, we do not recommend these fasteners for marine applications. Use the nickel-plated brass or stainless steel fasteners on p. 39. H G

SCREW STUDS Screw the stud into the side of your boat and snap your boat tip straight onto the stud.

K L

H I

FASDB4020 FASDB4021

Nickel-Plated Steel Screw Stud—³⁄₈”

Nickel-Plated Steel Screw Stud—⁵⁄₈” Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

DURA SNAP STEEL STUD

DURA SNAP STEEL POST

For use with Dura Snap Steel Post (#FASDS11011) or #6 Head Screw.

For use with Dura Snap Steel Stud (#FASDS11009).

FASDS11009

Dura Snap Steel Stud

FASDS11011

Dura Snap Steel Post

Price Breaks: Bag (100 ea) | Box (5 bags) |

Case (10 bags)

DURA SNAP STEEL SOCKET

DURA SNAP STEEL CAPS

Nickel-plated steel Dura Snap fasteners are very strong and

Caps used with Dura Snap Steel Socket (#FASDS11007).

durable. Polished to a bright finish.

FASDS11007

Dura Snap Steel Socket

K L

FASDS11001

Dura Snap Steel Cap—Nickel

FASDS11003

Dura Snap Steel Cap—Black

Price Breaks: Bag (100 ea) | Box (5 bags) |

Case (10 bags)

marine - awning - upholstery supplies | 51

DOT® DURABLE: NICKEL-PLATED BRASS

Quality Dot brand Durable™ Heavy-duty fasteners. The Dot ® brand is self-piercing and can be attached without prepunching. Button diameter is ⁹∕₁₆”, compatible with all Dura Snap parts and tools. A reliable, rustproof fastener of nickel-plated brass from a name you can trust. ®

Standard Durable™ caps with ¹¹⁄₆₄” (0.45 cm) barrel length. Self-piercing and requires no punching in most applications. Diameter of cap is ⁹⁄₁₆” (1.43 cm). Colored fasteners are topped with Delrin caps that will not fade. FASDO4070

Nickel-Plated

FASDO4068

Navy Blue

FASDO4062

Black

D E F

FASDO4064

Burgundy

FASDO4066

Pacific Blue

FASDO4060

White

Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

DOT® DURABLE SCREW STUDS—STAINLESS STEEL/ NICKEL-PLATED

Dot® Self-Drilling Screw Studs—7/16” Stainless Steel/ Nickel-Plated

FASDO4080

Dot Self-Drilling Screw Stud—⅝” Stainless Steel/ ®

Nickel-Plated

K L

FASDO4084

Dot® Durable Fastener Eyelet—5/16”

FASDO4082

Dot® Durable Fastener Eyelet—¼” Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

DOT® DURABLE MOLDING FASTENER For use with boat windshields.

M N

FASDO4086

Dot® Durable Molding Fastener—¾”

FASDO4088

Dot® Durable Molding Fastener—⅞” Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

DOT® GYPSY STUD

A nickel-plated brass fastener. Used when attaching stud to screw stud for stacking or double-layering material.

FASGY11012

Gypsy Studs—Nickel-Plated Brass

Price Breaks: Bag (100 ea) | Box (5 bags) | Case

Price Breaks: Bag (100 ea) | Box

(10 bags)

(5 bags) | Case (10 bags)

DOT® DURABLE SOCKETS I J

DOT® DURABLE EYELETS

Screw the stud into the side of your boat and snap your boat top straight onto the stud. FASDO4078

DOT® DURABLE FASTENER CAPS

K D

A B C

FASDO4072

Dot Durable Fastener Socket

FASDO4073

Dot® Durable Hard Action Socket

Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

DOT® DURABLE STUDS P Q R

FASDO4074

Dot® Durable Fastener Stud—Reg

FASDO4076

Dot® Durable Fastener Stud—Low

FASDO4077

Dot® Durable Flangeless Stud Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

Please see p.91 for Dot® Durable Punch and Dies, and for Dot® Durable Machines and Dies. 52 | marine - awning - upholstery supplies

DOT® DURABLE: STAINLESS STEEL

DURA SNAP CAP—STAINLESS STEEL

Caps for sockets to create one-half of the Dura Snap system. Diameter of the button or cap is ⁹∕₁₆”, barrel length is ¹¹∕₆₄”. 316 Marine Grade Stainless steel, rust-resistant and corrosion resistant.

FASDS4010

9/16” Dura Snap Cap—Stainless Steel Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

DURA SNAP SOCKET—STAINLESS STEEL

DURA SNAP POST—STAINLESS STEEL

316 Marine Grade Stainless steel standard socket for the Dura Snap system. Use with the stainless steel cap #4010 and attach to stud #4014. Outside diameter is ⁹∕₁₆” while inside diameter is ¹¹∕₆₄”.

FASDS4012

Stainless steel standard height Dura Snap post.

Dura Snap Socket—Stainless Steel

DOT® DURABLE SCREW STUDS—STAINLESS STEEL Screw the stud into the side of your boat and snap your boat top straight onto the stud.

DURA SNAP STUD—STAINLESS STEEL

E F G

Use with the Dura Snap Cap (#FASDS4010) and Socket (#FASDS4012). FASDS4014

Dura Snap Post—Stainless Steel Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

FASDS4015

9/16” Dura Snap Stud—Stainless Steel

FASST13002

Stainless Steel Self-Drilling Screw Stud—3/16”

FASST13000

Stainless Steel Self-Drilling Screw Stud—½”

FASST13001

Stainless Steel Self-Tapping Screw Stud—⅝” Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

DOT® COMMON SENSE: METAL

A premium line of Common Sense Fasteners from a name you know and trust. Sturdy nickelplated brass construction for durability. Reliable, rustproof fasteners for boats, truck fronts, convertible tops, tents and awning applications.

DOT® COMMON SENSE CLINCH PLATE & WASHER For use with boat windshields. H I

FASCO4058

Dot® Common Sense Washer

FASCO4054

Dot® Common Sense Clinch Plate

M H I

Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

DOT® COMMON SENSE EYELETS J

FASCO4056

Dot® Common Sense Eyelet Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

DOT® COMMON SENSE STUDS K L M

FASCO4050

Dot® Common Sense Single Stud (H:17mm)

FASCO3109

Dot® Common Sense Double Stud (H:20mm)

FASCO4052

Dot® Common Sense Prong Stud Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

Please see p.90 for Common Sense Cutters and Punches. marine - awning - upholstery supplies | 53

PULL-THE-DOT

The Pull-the-Dot fastener is a carefully engineered, three-sided locking snap fastener. Due to the unique built-in locking feature, this fastener will withstand extreme pressure on three sides without unlocking, yet release instantly on the fourth side if you pull the dot embossed on the surface of the cap. Made of nickel-plated brass. Can be set with any standard Dot ® Durable or Dura Snap setting tool.

PULL-THE-DOT SCREW STUD

FASPU4096

PULL-THE-DOT SOCKET C

Pull-the-Dot Screw Stud

FASPU4092

Pull-the-Dot Socket

Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

PULL-THE-DOT STUD CLINCH

FASPU4094

Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

PULL-THE-DOT FASTENER CAP

Pull-the-Dot Screw Stud Clinch

FASPU4090

Pull-the-Dot Fastener Cap

Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

LIFT-THE-DOT R

Lift-the Dot is a heavy-duty fastener from the Dot ® family. Like Pull-the-Dot, it locks on three sides and is easily released from the fourth. Frequently found in automotive and marine applications, it is suitable for use anywhere that a secure fastener is required. Content is also nickel-plated brass. It has its own set of tools and dies for installing. E

LIFT-THE-DOT SOCKET E

FASLI4011

Lift-the-Dot Socket

Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

FASLI4019

LIFT-THE-DOT STUD WASHER F

Lift-the-Dot Stud Washer Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

LIFT-THE-DOT CLINCH PLATE G

FASLI4013

Lift-the-Dot Clinch Plate Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

LIFT-THE-DOT STUD H

FASLI4018

Lift-the-Dot Stud—Two-Prong Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

LIFT-THE-DOT SCREW STUDS I J

FASLI4017

Lift-the-Dot Screw Stud Stainless Steel/Brass—⅝”

FASLI4069

Lift-the-Dot Screw Stud Brass—⅝” Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

FASLI4059

Screw Stud 7153-1—11/16”

Fastener stud with nut and bolt for mounting. ⅛” hole required to mount into hard surfaces. Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

54 | marine - awning - upholstery supplies

FASTENERS: NYLON Impervious and strong plastic compound fasteners, in Delrin (nylon) acetyl resin compound. Unaffected by moisture or humidity, will withstand extreme temperatures. These products have a proven track record in the winter front industry.

C D

NYLON TURN STUDS

Two-hole mounting nylon stud fastener. Can be riveted or

screwed into place or mount onto fabric with nylon Back Plates

(#FASCO3122 or #FASCO3123).

A B

FASCO3120

Nylon Turn Stud—Black

FASCO3121

Nylon Turn Stud—White

H I

Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

NYLON TURN EYELETS Nylon eyelet plate has serrated pins that extend into the nylon Washer Plates (#FASCO3126 or #FASCO3127).

C D

FASCO3124

Nylon Turn Eyelet—Black

FASCO3125

Nylon Turn Eyelet—White Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

NYLON WASHER PLATES

SLIDE-IN TARP CLIP Slide-in two-piece design allows you to place a clip for tying or hooking anywhere on a tarp. The tapered design means the more pressure you apply, the tighter it holds. A great versatile tool that allows the use of one tarp for many purposes. The clip can be applied where it is needed to simplify securing the tarp.

FASIN6070

Self-locking plate for the eyelets; simply push and the pins are

Price Breaks: B ag (25 ea) | Box (4 bags) | Case (20 bags)

locked into the plate.

E F

FASCO3126

Nylon Washer Plate—Black

FASCO3127

Nylon Washer Plate—White Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

NYLON BACK PLATE FOR STUD Backing plate for nylon Turn Studs (#FASCO3120 or #FASCO3121). Use to attach a stud where rivets or screws would pull through. Can be riveted or attached with two Dura Snap posts.

G H

FASCO3122

Nylon Back Plate for Stud—Black

FASCO3123

Nylon Back Plate for Stud—White

Slide-In Tarp Clip

#40 1” NYLON HOOK BUTTONS

#40 1” Nylon Buttons are perfect for outdoor applications such as lawn furniture. One-piece molded design with hook backs for use with twine or pre-tied strings. Design on hooks prevents twine from pulling out after insertion.

K -

BUTUP2072

#40 Nylon Hook Button—White

BUTUP2074

#40 Nylon Hook Button—Ivory Price Breaks: B ag (144 ea) | Box (5 bags) | Case (25 bags)

Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

MARINE TOP CLIP

Temporary clip constructed of nylon, that holds fabric or canvas to frames and tubes during the fitting process. Applied and removed easily. Will not tear or puncture fabric. No spring clamps to squeeze as the clip will just snap on and off.

FASIN2460

Marine Top Clip for 1” and ⅞” Tubes Price Breaks: Bag (10 ea) | Box (5 bags) | Case (10 bags)

marine - awning - upholstery supplies | 55

zippers A

COIL ZIPPERS: JEF ZIP COIL ZIPPER CHAIN

#4.5 COIL CHAIN ZIPPER

Price Break: Roll |Box (5 rolls) | Case (10 rolls)

#5 A Off-White B White C Black

Price Breaks: Roll (300yd) | Box (4 Rolls) | Case (12 Rolls)

#10

ZIPCC11660

ZIPCC9890

ZIPCC9999

ZIPCC9880

ZIPCC9885

ZIPCC9888

L M N

D E F

ZIPCC9891

#5 Non-Locking Coil Zipper Slider—White

ZIPCC9879

#5 Non-Locking Coil Zipper Slider—Black

ZIPCC10001

#5 Non-Locking 2-Tab Coil Zipper Slider—Black

G H

ZIPCC11670

#5 Locking Coil Zipper Slider—Black

ZIPCC11682

#5 Locking Coil Zipper Slider—Off-White

O P Q

ZIPCC9970

#4.5 Coil Chain Zipper—Beige

R S

ZIPCC10003

#8 Non-Locking 2-Tab Coil Zipper Slider—Black

T U

#10 ZIPPER SLIDERS (SOLD BY THE YARD) Price Breaks: Bag (25 ea) | Box (10 bags) | Case (40 bags) ZIPCC9889

#10 Non-Locking Coil Zipper Slider—Black

ZIPCC10004

#10 Non-Locking 2-Tab Coil Zipper Slider—Black

ZIPCC10000

#10 Non-Locking 2-Tab Coil Zipper Slider—White

#5 Coil 20” Open End Autolock—Black

#4.5 Coil Slide Non-Lock—Black

ZIPCC9917

#4.5 Coil Slide Non-Lock—White

ZIPCC9887

#4.5 Coil Slide Non-Lock—Black

ZIPCC9910

#4.5 Coil Slide Non-Lock—White

EZ-XTEND BOAT ZIPPERS NEW! Our New EZ-Extend Boat Zippers help to add 1” instantly where needed! With no sewing required; this is a great option to make your boat enclosure operational again.

Price Breaks: Bag (10 ea) | Box (5 bags) | Case (10 bags)

ZIPCF11502

ZIPCC9914

Black

#5 FINISHED COIL—OPEN END AUTOLOCK

#5 Coil 18” Open End Autolock—Black

#4.5 Coil Slide Pin Lock—Beige

Price Breaks: Bag (100) | Box (10 Bags) | Case (50 Bags)

#8 Non-Locking Coil Zipper Slider—Black

ZIPCF11501

#4.5 Coil Slide Pin Lock—White

ZIPCC9971

#4.5 COIL SLIDE NON-LOCK—LONG TAB

ZIPCC9886

#5 Coil 16” Open End Autolock—Black

#4.5 Coil Slide Pin Lock—Black

ZIPCC9906

Price Breaks: Bag (100) | Box (10 Bags) | Case (50 Bags)

Price Breaks: Bag (25 ea) | Box (10 bags) | Case (40 bags)

ZIPCF11500

ZIPCC9929

#4.5 COIL SLIDE NON-LOCK

#8 ZIPPER SLIDERS (SOLD BY THE YARD)

J -

#4.5 Coil Chain Zipper—White

Price Breaks: Bag (100) | Box (10 Bags) | Case (50 Bags)

Price Breaks: Bag (100 ea) | Box (10 bags) | Case (50 bags)

#4.5 Coil Chain Zipper—Black

ZIPCC9909

#4.5 COIL SLIDE PIN LOCK

#5 ZIPPER SLIDERS

ZIPCC9912

#5 FINISHED COIL—CLOSED END AUTOLOCK

White

ZIPEZ11016

#8 EZ-Xtend 35

ZIPEZ11017

#8 EZ-Xtend 59

ZIPEZ11018

#8 EZ-Xtend 95

ZIPEZ11019

#10 EZ-Xtend 35

ZIPEZ11020

#10 EZ-Xtend 59

ZIPEZ11021

#10 EZ-Xtend 95

ZIPEZ11025

#8 EZ-Xtend 35

ZIPEZ11026

#8 EZ-Xtend 59

ZIPEZ11027

#8 EZ-Xtend 95

ZIPEZ11028

#10 EZ-Xtend 35

ZIPEZ11029

#10 EZ-Xtend 59

ZIPEZ11030

#10 EZ-Xtend 95

Price Breaks: Bag (10 ea) | Box (5 bags) | Case (10 bags)

K D

ZIPCF11609

#5 Coil 6” Closed End Autolock—Black

ZIPCF11610

#5 Coil 7” Closed End Autolock—Black

ZIPCF11612

#5 Coil 9” Closed End Autolock—Black

ZIPCF11613

#5 Coil 10” Closed End Autolock—Black

T I F

56 | marine - awning - upholstery supplies

PRODUCT TIPS 1

Zippers come in three basic systemsâ&#x20AC;&#x201D;coil (or spiral), injection-molded profile (Delrin or Vislon) and metal. FI GURE 1: COIL ZIPPERS Uses the toothed elements of helical coils of polyester, nylon or, in some cases, metal wire as the fastening system. Coils can be formed and woven directly into the supporting tapes or preformed and sewn onto specially pre-manufactured tapes. Widely used due to their inconspicuous appearance when incorporated into the finished product. FI GURE 2: INJECTION-MOLDED ZIPPERS (DELRIN OR VISLON) These zippers have teeth of individually coupled members that interlock and are injection-molded onto pre-woven dyed tape. They have a degree of selflubrication and tend to be somewhat sturdier than an equivalent size of coil zipper. They also handle water and impurities better than coil zippers. In the larger size they are ideal for outdoor topping applications such as boats and other marine applications. FI GURE 3: METAL ZIPPERS Feature teeth of stamped or die-cast interlocking design fastened to the beaded edge of a dyed supporting tape. They have long life and tend to be very sturdy and strong in all directions. Brass zippers are used in marine and tent applications as they do not rust like steel. Also used in applications such as garment and upholstering due to the desired brass or metal finish.

CHOOSING A FINISHED ZIPPER If strength is not a particular concern, go with whichever zipper will provide the desired finished appearance. However, if strength is required, select the largest size that would fit your project. Metal and Delrin are stronger, although the larger coil zippers are strong enough for bags and other applications.

marine - awning - upholstery supplies | 57

Please see p.104 for Zipper tools.

DELRIN ZIPPERS: JEFZIP JEFZIP #5 DELRIN CHAIN ZIPPER A B

JEFZIP #5 DELRIN LOCKING ZIPPER SLIDERS

ZIPDC11400

#5 Delrin Chain Zipper—Black

ZIPDC11412

#5 Delrin Chain Zipper—Off-White

C D

ZIPDC11420

#5 Delrin Locking Zipper Slider—Black

ZIPDC11432

#5 Delrin Locking Zipper Slider—Off-White

Price Breaks: Roll (100yd) | Box (5 rolls) |

Price Breaks: Bag (100 ea) | Box (10 bags) |

Case (10 rolls)

Case (50 bags)

JEFZIP #5 DELRIN OPEN-END AUTOLOCK ZIPPERS

Pre-made #5 Delrin zippers, open-end with autolock sliders. Used in garments and bag applications. Available only in black.

E E E E

ZIPDF11300

16”

ZIPDF11301

18”

ZIPDF11302

20”

ZIPDF11306

24”

E E E E

ZIPDF11308

26”

ZIPDF11310

28”

ZIPDF11312

30”

ZIPDF11448

40”

Price Breaks: Bag (10 ea) | Box (5 bags) | Case (10 bags)

JEFZIP #10 DELRIN CHAIN

Nylon tooth zippers are strong and lightweight. They operate smoothly despite the presence of sand, mud, or other contaminants. Ideal for topping and other outdoor applications including garments and bags.

F G

ZIPJE10170

#10 Delrin Chain—Black

ZIPJE10166

#10 Delrin Chain—White

Price Breaks: Yard | Roll (109yd), Box (5 rolls) (Minimum order quantity: 10 yards)

JEF ZIP #10 DELRIN TWO-TAB SLIDERS—NON-LOCKING Coordinates with JEFZip’s #10 Delrin Chains (#ZIPJE10170 and #ZIPJE10166).

H I

ZIPJE10168

#10 Delrin Non-Locking Two-Tab Slider—White

ZIPJE10172

#10 Delrin Non-Locking Two-Tab Slider—Black Price Breaks: Bag (25 ea) | Box (10 bags) | Case (40 bags) G

58 | marine - awning - upholstery supplies

YKK® VISLON: FINISHED ZIPPERS YKK® #8 LOCKING VISLON ZIPPERS

#8 locking zipper with double pull-tab sliders made from enamelcoated zinc. A heavy zipper used in marine convertible tops and tenting applications. Price Breaks: Each | Bag (10 ea) | Case (25 bags)

White

Black 24”

ZIPVF10086

ZIPVF10014

36”

ZIPVF10015

ZIPVF10018

48”

ZIPVF10016

ZIPVF10019

54”

ZIPVF10087

ZIPVF10021

60”

ZIPVF10017

ZIPVF10020

72”

ZIPVF10088

ZIPVF10022

84”

ZIPVF10089

ZIPVF10023

96”

ZIPVF10099

ZIPVF11031

WHITE

BEIGE

BURGUNDY

BLUE

BLACK

GREY

YKK® #10 LOCKING VISLON ZIPPERS

YKK® #10 NON-LOCKING VISLON ZIPPERS

Price Breaks: Each | Bag (10 ea) | Case (25 bags)

#10 locking zipper with double pull-tab sliders made from enamel-coated zinc. A heavy zipper used in marine convertible tops and tenting applications.

Colour

Black Locking

White

#10 non-locking zipper with double pull-tab sliders made from enamel-coated zinc. A heavy zipper used in marine convertible tops and tenting applications.

Beige

Non Locking

Locking

Non Locking

Locking

Non Locking

Burgundy

Blue

Grey

Locking Only

18”

ZIPVF10024

ZIPVF9470

ZIPVF10039

ZIPVF9450

ZIPVF10045

ZIPVF10060

24”

ZIPVF10005

ZIPVF9991

ZIPVF9977

ZIPVF9959

ZIPVF10046

ZIPVF10061

ZIPVF10090

ZIPVF9950

ZIPVF10030

30”

ZIPVF10006

ZIPVF9989

ZIPVF9978

ZIPVF9969

ZIPVF10047

ZIPVF10062

ZIPVF10091

ZIPVF9951

ZIPVF10031

36”

ZIPVF10007

ZIPVF9992

ZIPVF9979

ZIPVF9960

ZIPVF10048

ZIPVF10063

ZIPVF10092

ZIPVF9952

ZIPVF10032

42”

ZIPVF10025

ZIPVF9471

ZIPVF10040

ZIPVF9451

ZIPVF10049

ZIPVF10064

48”

ZIPVF10008

ZIPVF9993

ZIPVF9981

ZIPVF9961

ZIPVF10050

ZIPVF10065

ZIPVF10093

ZIPVF9953

ZIPVF10033

54”

ZIPVF10026

ZIPVF9472

ZIPVF10041

ZIPVF9452

ZIPVF10051

ZIPVF10066

60”

ZIPVF10009

ZIPVF9994

ZIPVF9983

ZIPVF9962

ZIPVF10052

ZIPVF10067

ZIPVF10094

ZIPVF9954

ZIPVF10034

66”

ZIPVF10027

ZIPVF9473

ZIPVF10042

ZIPVF9453

ZIPVF10053

ZIPVF10068

72”

ZIPVF10010

ZIPVF9995

ZIPVF9985

ZIPVF9963

ZIPVF10054

ZIPVF10069

ZIPVF10095

ZIPVF9955

ZIPVF10035

78”

ZIPVF10028

ZIPVF9474

ZIPVF10043

ZIPVF9454

ZIPVF10055

ZIPVF10070

84”

ZIPVF10011

ZIPVF9996

ZIPVF9986

ZIPVF9964

ZIPVF10056

ZIPVF10071

ZIPVF10096

ZIPVF9956

ZIPVF10036 ZIPVF10037

96”

ZIPVF10012

ZIPVF9997

ZIPVF9987

ZIPVF9967

ZIPVF10057

ZIPVF10072

ZIPVF10097

ZIPVF9957

108”

ZIPVF10029

ZIPVF9475

ZIPVF10044

ZIPVF9455

ZIPVF10058

ZIPVF10073

120”

ZIPVF10013

ZIPVF9998

ZIPVF9988

ZIPVF9968

ZIPVF10059

ZIPVF10074

ZIPVF10098

ZIPVF9958

ZIPVF10038

marine - awning - upholstery supplies | 59

YKK® VISLON: UNFINISHED ZIPPERS YKK® Vislon zippers are extremely strong and lightweight. The “teeth” are made from Vislon nylon and the tape is polyester. Due to the unique properties of Vislon, the fastener has a wide variety of industrial, consumer and military applications where environmental conditions can reduce the effectiveness of metal zippers. YKK® is corrosion-resistant and is self-lubricating to a degree. This ensures smooth operation despite sand, mud or other contaminants. The color is cast into the molding, so there is no finish to rub off, peel or chip. Vislon has excellent heat resistance (up to 182°C / 360°F) and resists cold down to -51°C (-60°F). Melting point is at 249°C (480°F), which is well beyond normal laundering or exposure temperatures. Resistance to chemicals further extends the use of Vislon beyond the scope of conventional metal zippers, which are prone to accelerated corrosion with exposure to chemicals.

YKK® #5

This product is available in cut lengths or in full rolls of 220 yd. The #5 tape is ½” in width.

WHITE Zipper Chain Non-Locking Zipper Slider Non-Locking Two-Tab Slider Top Stop Bottom Stop

BLACK Zipper Chain Non-Locking Zipper Slider Non-Locking Two-Tab Slider Top Stop Bottom Stop

BEIGE Zipper Chain Non-Locking Zipper Slider Top Stop Bottom Stop

A -

ZIPVC9975

Yard | Roll (220 yd) | 3 Rolls (660 yd)

ZIPVC9990

Bag (100 ea) | Box (5 bags) | Case (10 bags)

ZIPVC9980

Bag (100 ea) | Box (5 bags) | Case (10 bags)

ZIPVC9982

Bag (100 ea) | Box (5 bags) | Case (10 bags)

ZIPVC9984

Bag (100 ea) | Box (5 bags) | Case (10 bags)

B -

ZIPVC9935

Yard | Roll (220 yd) | 3 Rolls (660 yd)

ZIPVC9936

Bag (100 ea) | Box (5 bags) | Case (10 bags)

ZIPVC9930

Bag (100 ea) | Box (5 bags) | Case (10 bags)

ZIPVC9937

Bag (100 ea) | Box (5 bags) | Case (10 bags)

ZIPVC9938

Bag (100 ea) | Box (5 bags) | Case (10 bags)

C -

ZIPVC10082

Yard | Roll (220 yd) | 3 Rolls (660 yd)

ZIPVC10083

Bag (100 ea) | Box (5 bags) | Case (10 bags)

ZIPVC10084

Bag (100 ea) | Box (5 bags) | Case (10 bags)

ZIPVC10085

Bag (100 ea) | Box (5 bags) | Case (10 bags)

D -

ZIPCC10120

Yard | Roll (150 yd) | 3 Rolls (450 yd)

ZIPCC10122

Bag (25 ea) | Box (10 bags) | Case (40 bags)

ZIPCC10121

Bag (25 ea) | Box (10 bags) | Case (40 bags)

YKK® #8 Zipper Chain Non-Locking Two-Tab Slider Non-Locking One-Tab Slider

60 | marine - awning - upholstery supplies

YKK® #10 VISLON ZIPPERS

This product is available in cut lengths or in full rolls of 110 yd. The #10 tape is ⁵⁄₈” in width.

BLACK

Zipper Chain Non-Locking Zipper Slider Non-Locking Two-Tab Slider Non-Locking Two-Tab Slider (Plastic) Locking Two-Tab Slider Top Stop Bottom Stop

WHITE

Zipper Chain Non-Locking Zipper Slider Non-Locking Two-Tab Slider Non-Locking Two-Tab Slider (Plastic) Locking Two-Tab Slider Top Stop Bottom Stop

BEIGE

Zipper Chain Non-Locking Zipper Slider Non-Locking Two-Tab Slider Locking Two-Tab Slider Top Stop Bottom Stop

ZIPVC9939

Price Breaks: Yard | Roll (110 yd) | 3 Rolls (330 yd)

ZIPVC9947

Price Breaks: Bag (25 ea) | Box (10 bags) | Case (40 bags)

ZIPVC9942

Price Breaks: Bag (25 ea) | Box (10 bags) | Case (40 bags)

ZIPVC9945

Price Breaks: Bag (25 ea) | Box (10 bags) | Case (40 bags)

ZIPVC9974

Price Breaks: Bag (25 ea) | Box (10 bags) | Case (40 bags)

ZIPVC9965

Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

ZIPVC9966

Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

B -

ZIPVC9940

Price Breaks: Yard | Roll (110 yd) | 3 Rolls (330 yd)

ZIPVC9941

Price Breaks: Bag (25 ea) | Box (10 bags) | Case (40 bags)

ZIPVC9946

Price Breaks: Bag (25 ea) | Box (10 bags) | Case (40 bags)

ZIPVC9976

Price Breaks: Bag (25 ea) | Box (10 bags) | Case (40 bags)

ZIPVC9972

Price Breaks: Bag (25 ea) | Box (10 bags) | Case (40 bags)

ZIPVC9948

Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

ZIPVC9949

Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

C -

ZIPVC10075

Price Breaks: Yard | Roll (110 yd) | 3 Rolls (330 yd)

ZIPVC10078

Price Breaks: Bag (25 ea) | Box (10 bags) | Case (40 bags)

ZIPVC10079

Price Breaks: Bag (25 ea) | Box (10 bags) | Case (40 bags)

ZIPVC10076

Price Breaks: Bag (25 ea) | Box (10 bags) | Case (40 bags)

ZIPVC10081

Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

ZIPVC10080

Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

D -

ZIPVC9943

Price Breaks: Yard | Roll (110 yd) | 3 Rolls (330 yd)

ZIPVC9944

Price Breaks: Bag (25 ea) | Box (10 bags) | Case (40 bags)

ZIPST11013

Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

OTHER

Zipper Chain—Blue Non-Locking Two-Tab Slider—Blue “V” Zipper Stop—Stainless Steel

Proudly representing… Proudly representing… ®

American & Efird Canada, Inc. marine - awning - upholstery supplies | 61 ®

American & Efird Canada, Inc.

YKK® ALUMINUM ZIPPERS YKK® #10 ALUMINUM ZIPPER TAPE A

ZIPAL9931

#10 96” Aluminum Two-Tab Finished Zipper A separable aluminum zipper, the #10 two-tab zipper is ideal for boat top and tent applications—anywhere that a separable zipper is needed. It can be shortened by trimming the free ends. Tape color is a light beige. Price Breaks: Each | Bag (10 ea) | Case (25 bags)

ZIPAL9921

H C

#10 Aluminum Heavy Zipper Tape Heavy #10 aluminum zipper on beige tape. A common size in marine, boat top and tent applications. The tape has a width of ¾”. Tape color is a light beige. Price Breaks: Yard | Roll (109 yd) | 3 Rolls (327 yd)

YKK® #10 ALUMINUM ZIPPER SLIDERS C

ZIPAL9922

#10 Aluminum Two-Tab Slider

YKK® #5 ALUMINUM ZIPPER TAPE G

ZIPAL9918

#5 aluminum zipper tape in a continuous roll. This is a slightly larger and stronger version of the #4 zipper. It is intended for more strenuous applications, such as bags and other places where a slightly heavier load is expected. Tape color is a light beige.

Price Breaks: Bag (25 ea) | Box (10 bags) | Case (40 bags)

YKK® #10 ALUMINUM ZIPPER STOPS D E

ZIPAL9923

#10 Aluminum Top Stop

ZIPAL9924

#10 Aluminum Bottom Stop Price Breaks: Bag (100 ea) | Box (5 bags) |

Price Breaks: Roll (109 yd) | Box (4 Rolls) | Case (8 Rolls)

ZIPAL9919

YKK® #4 ALUMINUM ZIPPER TAPE ZIPAL9913

#5 Aluminum Single-Tab Slider Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

Case (10 bags)

#5 Aluminum Heavy Zipper Tape

YKK® #4 Aluminum Zipper Tape— Natural

YKK® #4 ALUMINUM ZIPPER SLIDER I

ZIPAL9916

YKK® #4 Aluminum Zipper Slider

Price Breaks: Bag (100) | Box (5 Bags) | Case (10 Bags)

Price Breaks: Roll (273yd) | Box (4 Rolls) | Case (8 Rolls)

I F

YKK® BRASS ZIPPERS

YKK® #10 BRASS ZIPPER TAPE L

YKK® #4 BRASS ZIPPER TAPE

The brass finish is a more decorative alternative to aluminum for those applications where you want to stay with the traditional look and feel of metal zippers. The brass is strong, attractive, weatherproof and easy to use. ZIPBR9911

#10 Brass Heavy Zipper Tape Price Breaks: Yard | Roll (109 yd) | 3 Rolls (327 yd)

M M M

ZIPBR9925

YKK® #4 Brass Zipper Tape— Beige

Price Breaks: Yard | 50 yd | 400 yd

ZIPBR9932

#10 36” Brass Two-Tab Finished Zipper

ZIPBR9933

#10 60” Brass Two-Tab Finished Zipper

ZIPBR9934

#10 96” Brass Two-Tab Finished Zipper Price Breaks: Each | Bag (10 ea) | Case (25 bags)

YKK® #10 BRASS TWO-TAB ZIPPER SLIDER N

ZIPBR9926

#10 Brass Two-Tab Slider

Price Breaks: Bag (25 ea) | Box (10 bags) | Case (40 bags)

YKK® #10 BRASS ZIPPER STOPS O P

ZIPBR9927

#10 Brass Top Stop

ZIPBR9928

#10 Brass Bottom Stop Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

YKK #4 BRASS ZIPPER SLIDER ®

ZIPBR9915

YKK® #4 Brass Zipper Slider

Price Breaks: Bag (100) | Box (5 Bags) | Case (10 Bags) 62 | marine - awning - upholstery supplies

Optically Clear

Easy To Clean

Low Stretch

High Impact Cold Crack

Highly Durable

Visit ennisfabrics.com for more detailed specification and up-to-date pricing.

* Due to the nature of numerous different computer display settings, the digital fabric & supply images displayed on your screen may not represent the actual product in its entirety. All supplied fabric & supply images in their printed form are to be used for reference only and may not look exactly as shown. â&#x20AC; This information is offered for your general guidance only. Itâ&#x20AC;&#x2122;s accurate to the best of our knowledge and is not intended to relieve the user from its responsibility to investigate and understand other pertinent sources of information and to comply with all laws and procedures applicable to the safe handling and use of this material.

awning hardware *ID = Inside Diameter

AWNING FITTINGS: ALUMINUM The aluminum fittings listed here have a primary application in the construction of awnings. While many of the parts appear similar to their counterparts in the boat top trade, they tend to be larger castings and in many cases are not as well fi nished as the equivalent marine parts. All parts have a smooth surface with a bright fi nish. Set screws, hinge screws, bolts and nuts are made of stainless steel unless otherwise indicated. I K D G E F L A H J C B

Q R

CLEAT A

FITAL2410

6” Cleat Price Breaks: Each | Bag (10 ea) | Case (25 ea)

CAMEL BACK HINGES

Camel back hinges that move the pivot point out from the surface to allow full range of movement of eye ends. Projection distance given is from the mounting surface.

B C

FITAL2404

Camel Back Hinge—¾” Projection

FITAL2406

Camel Back Hinge—1” Projection Price Breaks: Each | Bag (10 ea) | Case (25 ea)

ROD CLAMPS D E F

FITAL2372

Hookless Head Rod Clamp—½”

FITAL2370

Head Rod Clamp—½”

FITAL2368

Head Rod Clamp—⅜” Price Breaks: Each | Bag (10 ea) | Case (25 ea)

COMBINATION RAFTER/SLIP TEE

Combination rafter tee and upright tee with offset that allows for individual or dual use.

FITAL2360

1” Combination Rafter/Slip Tee—ID* 1⅜” Price Breaks: Each | Bag (10 ea) | Case (25 ea)

SLIPFIT EYE END H I J K

FITAL2361

¼” Slipfit Eye End—ID* ½”

FITAL2420

½” Slipfit Eye End—ID* ⅞”

FITAL2364

¾” Slipfit Heavy-Duty Eye End—ID* 1⅛”

FITAL2366

1” Slipfit Eye End—ID* 1⅜”

SLIPFIT FRONT BAR CLAMP

Fit tubing into the bar clamp and tighten the stainless steel setscrew.

M N

FITAL2378

Aluminum Front Bar Clamp—¾” x ¾”

FITAL2380

Aluminum Front Bar Clamp—1” x 1” Price Breaks: Each | Bag (10 ea) | Case (25 ea)

POST SOCKETS FOR WOOD O P

FITAL2424 FITAL2422

FITAL2427

POST SOCKETS FOR BRICK

For mounting pipes securely into brick or stone surfaces. Mounts using lag bolts or cement/brick anchors.

FITAL2425

Price Breaks: Each | Bag (10 ea) | Case (25 ea)

64 | marine - awning - upholstery supplies

1” Post Socket for Brick—ID* 1⅜” Price Breaks: Each | Bag (10 ea) | Case (25 ea)

Z-SHAPED AWNING MOUNTING BRACKET

Z-bracket with two equally spaced holes for lagging into mortar and securing to the wall. The ³⁄₁₆” hole on the other end accommodates a tek screw for fastening the awning frame to the bracket.

FITAW11014

Z-Shaped Awning Bracket—1” The 1” square design will accommodate both 1” round and square awning frame tubing.

S ½” Slipfit 90° Elbow—ID* ⅞”

1” Post Socket for Wood—ID* 1⅜” Price Breaks: Each | Bag (10 ea) | Case (25 ea)

Price Breaks: Each | Bag (10 ea) | Case (25 ea)

SLIPFIT ELBOW

¾” Post Socket for Wood—ID* 1⅛”

FITAW11015

Z-Shaped Awning Bracket—3” Price Breaks: Bag (25 ea) | Box (4 bags) | Case (20 bags)

AWNING RAIL ALUMINUM AWNING RAIL

Mill fi nish aluminum awning rail in 16’ lengths. Can be used with keder welt or vinyl extruded welt to hold covers in place. Ideal for truck tonneau covers.

FITAW2771

16’ Aluminum Awning Rail Price Breaks: Each | Bag (10 ea) | Case (25 ea)

PLASTIC AWNING RAIL B

FITAW2774

10’ Plastic Awning Rail Plastic awning rail in white Delrin in 10’ lengths and 9∕16” diameter. Price Breaks: Each | Bag (10 ea) | Case (25 ea)

FITAW2777

7’6” Center Awning Rail Smooth, white, PVC rigid extrusion. Non-corrosive. Can be run around tight corners with the use of heat. Price Breaks: Each | Bag (10 ea) | Case (25 ea)

AWNING WELT VINYL EXTRUDED WELT

Use in place of rope headers to eliminate binding and tearing of threads and fabric during use. Can be easily stitched to the cover fabric and fits cleanly into the awning rails above. Fast and easy, moves the stitching away from friction. ⁵∕₁₆” diameter.

D -

FITAW2773

Vinyl Extruded Welt—White

FITAW2781

Vinyl Extruded Welt—Black Price Breaks: Roll (100’) | Box (5 Rolls) | Case (10 rolls)

KEDER WELT WITH WELDED FLAP

Heavy-duty polyester welded to a cord of solid PVC material. Hard, but fl exible with slippery track welting that slides easily, and effortlessly bends around curves. Awning welt with a welded fl ap for sewn applications. Available in standard weave in black or white.

E -

FITAW9422

9/32” Keder Welt with Welded Flap—White

FITAW9423

9/32” Keder Welt with Welded Flap—Black

FITAW9424

5/16” Keder Welt with Welded Flap—White

FITAW9425

5/16” Keder Welt with Welded Flap—Black Price Break: Roll (110yd) | Box (5 Rolls) | Case (10 rolls)

E D

KEDER WELT WITH TWO-FLAP

For sewn or heat-sealed applications. Available in standard weave. Keder welting is designed specifi cally for use in outdoor tensile structures where strength and resistance to the elements are critical. A unique construction of heavyduty polyester fabric welded to a cord of solid PVC material, resulting in a hard, but fl exible and slippery track welting. Effortlessly bends around curves.

FITAW9420

5/16” Keder Welt with Two-Flap—White

FITAW9421

5/16” Keder Welt with Two-Flap—Black Price Break: Roll (110yd) | Box (5 Rolls) | Case (10 rolls)

AWNING COVER WELT

100% PVC awning cover welt cord. Welt for sewing in the edging of awning covers. Holds the cover in place once installed in awning roller tube and front valance.

FITAW9426

Awning Cover Welt—¼” Diameter Price Breaks: Roll (250yd) | Box (5 Rolls) | Case (10 rolls)

XTREME AWNING SEAL

Closed-cell fl exible awning sealer with 3M adhesive on the backing. Use awning seal for the best seal and ease of installation of awnings. With the self-adhesive 3M back, it stays in place.

TRIED2805

Xtreme Awning Seal Price Breaks: Foot | Package (125’) | Case (250’)

F H

marine - awning - upholstery supplies | 65

marine hardware

minimum tubing order is 3 lengths *OD = Outer Diameter

ALUMINUM TUBING Square Tube #8376 used in conjunction with Jaw Slide #2579.

BRIGHT ANODIZED ROUND ALUMINUM TUBING: 0.058” WALL THICKNESS Drawn aluminum tubing with a polished bright-dip finish. Lightweight and easy to work with, the ¾” tubing will slide easily into ⅞” tubing to form cockpit poles (see p.68). FITTU8362

OD* ¾” x Length 20’ Price Breaks: Per foot (20’ lengths) | 240’ | 1080’

FITTU8372

OD* ⅞” x Length 20’

CLEAR ANODIZED SQUARE ALUMINUM TUBING: 0.058” WALL THICKNESS

Square tubing to be used with the following Jaw Slides, #2579, #2705, and #2706 (see inset photo above.) FITTU8368

Price Breaks: Per foot (20’ lengths) | 200’ | 760’ FITTU11231

OD* ⅞” x Length 24’ 24’ tubes must be shipped by truck. Ennis Fabrics can cut tube in half if this product is shipped by courier.

OD* 1” x Length 24’ Price Breaks: Per foot (24’ lengths) | 240’ | 1200’

FITTU8376

OD* 1¼” x Length 24’ Price Breaks: Per foot (24’ lengths) | 240’ | 1200’

Price Breaks: Per foot (20’ lengths) | 240’ | 912’

JAW SLIDE Meant to be used with the 1¼” Tube (#8376).

FITTU2579

FITBL2705

Price Breaks: Each | Bag (5 ea) | Case (10 ea) 1” Square Jaw Slide Black

FITWH2706

Price Breaks: Each | Bag (5 ea) | Case (10 ea) 1” Square Jaw Slide White

FITBL2708

Price Breaks: Each | Bag (5 ea) | Case (10 ea) 1” Square Inside Eye End Black

Jaw Slide for 1¼” Square Tube *Bolt not included

Price Breaks: Each | Bag (5 ea) | Case (10 ea)

66 | marine - awning - upholstery supplies

STAINLESS STEEL TUBING SUPER BUFFED STAINLESS STEEL ROUND TUBING

Bright finished 304 stainless steel tubing. Extra strength makes for a stronger frame. Ideal for railings. Sold in complete lengths of 20’. FITTU8374

OD* ⅞” x 0.049” Wall Thickness x Length 20’

FITTU8365

OD* 1” x 0.065” Wall Thickness x Length 20’ Price Breaks: Per foot (20’ lengths) | 200’ | 1400’

FITTU8373

OD* ⅞” x 0.065” Wall Thickness x Length 24’ Price Breaks: Per foot (24’ lengths) | 240’| 1680'

FITTU8364

OD* 1” x 0.065” Wall Thickness x Length 24’ Price Breaks: Per foot (24’ lengths) | 240’| 1200'

FITTU8367

OD* 1¼” x 0.065” Wall Thickness x Length 24’ Price Breaks: Per foot (24’ lengths) | 240’ | 720'

STAINLESS STEEL: GEMINI FITTINGS The Gemini Fittings are made of 316 stainless steel and include a Sliding Side Mount, Split Jaw Side Mount fitting in ⅞”, 1”, and 1¼”. Also available are Gemini hinges in ⅞” and 1”. The Sliding Side Mount and Split Jaw Side Mount feature a beefed-up body style with a stand-off style that allows hand room between the grab rail and the fabric which makes them ideal for mounting struts, grab and hand rails in marine frames. The Gemini Hinges fit standard tubing for use in collapsible support struts, dinettes, folding tables and folding seating.

SLIDING SIDE MOUNTS

Compatible with standard marine end fittings. Heavy duty construction with two set screws. Phillips head bolt and nylon washer. Easy installation, requires no modification of existing frames.

A B C

FITST11062

Gemini Sliding Side Mount—1¼”

FITST11061

Gemini Sliding Side Mount—1”

FITST11060

Gemini Sliding Side Mount—⅞”

Price Breaks: Each | Bag (5 ea) | Case (10 ea)

SPLIT JAW SLIDE MOUNT

Split-style mounts can be mounted anywhere on a frame, which creates a greater range of applications.

D E F

FITST11063

Gemini Split Jaw Slide Mount—⅞”

FITST11064

Gemini Split Jaw Slide Mount—1”

FITST11065

Gemini Split Jaw Slide Mount—1¼”

Price Breaks: Each | Bag (5 ea) | Case (10 ea)

HINGES

Solid body construction with two Buna O-rings to compensate for tubing wall thickness variation. Relief areas are provided for attachment to tubing via either roll pins or set screws.

G H

FITST11066

Gemini Hinge—⅞”

FITST11067

Gemini Hinge—1”

Price Breaks: Each | Bag (5 ea) | Case (10 ea)

marine - awning - upholstery supplies | 67

STAINLESS STEEL: RAIL FITTINGS A wide range of fittings to be used along with ⅞” and 1” stainless steel tubing to create handrails and guides. The range of angles on the bases and stanchions will allow you to fit most contours and shapes. Use 1” to create a heavier, more sturdy rail. Made with 316 Stainless Steel.

60° BASE A B

CORNER FITTING

FITST2855

60° Rectangular Base—1”

FITST2854

60° Rectangular Base—⅞”

C D

60° Round Base—1”

FITST2862

60° Round Base—⅞” Price Breaks: Each | Bag (5 ea) | Case (10 ea)

60° UNIVERSAL TEE FITTINGS E F

FITST2874

60° Universal Tee Fitting—⅞”

FITST2875

60° Universal Tee Fitting—1”

ELBOWS N O P

FITST2879

90° Elbow—1”

FITST2878

90° Elbow—⅞”

FITST2892

Elbow and Anchor Eye—⅞” Price Breaks: Each | Bag (5 ea) | Case (10 ea)

BOW FORM Q

FITST2882

STANCHION

90° BASE FITST2851

90° Rectangular Base—1”

FITST2850

90° Rectangular Base—⅞”

R S

FITST2905

60° Aft Stanchion—1”

FITST2904

60° Aft Stanchion—⅞” Price Breaks: Each | Bag (5 ea) | Case (10 ea)

Price Breaks: Each | Bag (5 ea) | Case (10 ea)

I J

FITST2859

90° Round Base—1”

FITST2858

90° Round Base—⅞”

T U

FITST2901

60° Center Stanchion—1”

FITST2900

60° Center Stanchion—⅞” Price Breaks: Each | Bag (5 ea) | Case (10 ea)

Price Breaks: Each | Bag (5 ea) | Case (10 ea)

RAIL END

90° TEE FITTINGS K L

110° Bow Form Price Breaks: Each | Bag (5 ea) | Case (10 ea)

Price Breaks: Each | Bag (5 ea) | Case (10 ea)

G H

Three-Way Corner Fitting—⅞” Price Breaks: Each | Bag (5 ea) | Case (10 ea)

Price Breaks: Each | Bag (5 ea) | Case (10 ea) FITST2863

FITST2888

FITST2871

90° Tee Fitting—1”

FITST2870

90° Tee Fitting—⅞”

V W

FITST2885

5½” Rail End (End Out)

FITST2886

5½” Rail End (End In) Price Breaks: Each | Bag (5 ea) | Case (10 ea)

Price Breaks: Each | Bag (5 ea) | Case (10 ea)

R W C

M K

S O L

68 | marine - awning - upholstery supplies

P Q

STAINLESS STEEL: TOP FITTINGS High quality die cast 316 stainless steel fittings, highly polished for a brilliant finish. Used in the construction of bimini top frames. Extremely strong and durable. They are drilled to accept either one of the ⅜” Quick Release Pins listed on p.94 or a machine screw with ¼–20 threads; in some cases a headless screw of this size is included. Those with mounting screws are pre-drilled to accommodate the use of #10 screws, which will mount flush in the countersunk holes.

BALL AND SOCKET FITTINGS A B

FITST2563

Ball and Socket Deck Hinge w/ Pin + Lanyard Price Breaks: Each | Bag (5 ea) | Case (10 ea)

B C

FITST2565

Ball and Socket Outside Top Cap—1”

FITST2564

Ball and Socket Outside Top Cap—⅞”

Price Breaks: Each | Bag (5 ea) | Case (10 ea)

D E

FITST

FITST2567

Ball and Socket Jaw Slide—1”

FITST2566

Ball and Socket Jaw Slide—⅞” Price Breaks: Each | Bag (5 ea) | Case (10 ea)

FITST2562

Ball and Socket 90o Eye End—⅞” Price Breaks: Each | Bag (5 ea) | Case (10 ea)

F G

G H

FITST2569

Ball and Socket Concave Hinge W/P—⅞”

FITST2568

Ball and Socket Deck Hinge W/P—⅞” Price Breaks: Each | Bag (5 ea) | Case (10 ea)

I J

FITST2571

Hinge with D-Ring—Port Side

FITST2573

Hinge with D-Ring—Starboard Side Price Breaks:Each | Bag (5 ea) | Case (10 ea)

FITST2574

Pull Pin with Pull Knob Lanyard Price Breaks: Each | Bag (5 ea) | Case (10 ea)

N S M L

R Q

U T

JAW SLIDES L M

FITST2665

Jaw Slide with Rubber Gasket—1”

FITST2667

Jaw Slide with Rubber Gasket—⅞” Price Breaks: Each | Bag (5 ea) | Case (10 ea)

FITST2697

FITST2698

Split Jaw Slide—⅞”

FITST2699

Split Jaw Slide—1”

FITST11043

Split Jaw Slide—1¼” Price Breaks: Each | Bag (5 ea) | Case (10 ea)

Double-Side Jaw Slide—1” Price Breaks: Each | Bag (5 ea) | Case (10 ea)

O P

Q R S

FITST2704

Jaw Slide with Bolt—⅞”

FITST2694

Jaw Slide with Bolt—1” Price Breaks: Each | Bag (5 ea) | Case (10 ea)

T U

FITST2668

Two-Screw Jaw Slide—1”

FITST2721

Two-Screw Jaw Slide—1¼” Price Breaks: Each | Bag (5 ea) | Case (10 ea)

FITST2696

Heavy Top Jaw Slide—1” Price Breaks: Each | Bag (5 ea) | Case (10 ea)

marine - awning - upholstery supplies | 69

E G

EYE SLIDE

EYE END

Drilled to accept either the ³⁄₈” Quick Release pins or a machine screw with ¼–20 threads.

A B C D E F

FITST2688

Eye Slide—1” Price Breaks: Each | Case (10)

FITST2692

Top Cap Eye End—1”

FITST2693

Top Cap Eye End—⅞”

FITST2666

Two-Screw Eye End—1”

FITST2720

Two-Screw Eye End—1¼”

FITST2689

Heavy Top Cap Eye End—1”

Replacement set screws for Eye Ends and

Price Breaks: Each | Bag (5 ea) | Case (10 ea)

Jaw Slides.

Quick-Release Side Mount/Eye End—⅞”

Price Breaks: Bag (25) | Box (4 bags) | Case (20 bags)

FITST2581

MISCELLANEOUS H

Two-hole side mount with Quick Release End. Eye end fits ⅞” tubing, then fits vertically into mount and locks when pivoted off center. Base size approximately ⅞”x2”. Pre-drilled to accommodate ¼”–20 screws.

FITST2687

Stainless Steel Set Screw

FOR MORE MISCELLANEOUS MARINE FITTINGS SEE PAGE 78

Price Breaks: Each | Bag (5 ea) | Case (10 ea) K

J I

U S O L

DECK HINGES I J K L M N O

FITST2584

Angle Base Deck Hinge

FITST2582

90° Deck Hinge

FITST2587

Heavy-Duty Deck Hinge

FITST2585

Quick-Release Angle Deck Hinge w/ Quick-Release Pin

FITST2586

Quick-Release Concave Hinge w/ Quick-Release Pin

FITST2583

Quick-Release 90° Deck Hinge w/ Quick-Release Pin

FITST2588

180° Universal Deck Hinge Price Breaks: Each | Bag (5 ea) | Case (10 ea)

SIDE MOUNTS P Q

FITST2664

Heavy-Duty Four-Hole Side Mount Plate

FITST2663

Two-Hole Side Mount Price Breaks: Each | Bag (5 ea) | Case (10 ea)

70 | marine - awning - upholstery supplies

PINS R

FITST2908

3/16” Toggle Pin Price Breaks: Each | Bag (5 ea) | Case (10 ea)

S T

FITST2702

3/16” Quick-Release Pin

FITST2703

3/16” Quick-Release Pin w/

FITST130004

7” Steel Lanyard ¼” Quick-Release Pin w/ Nylon-Coated 6” Lanyard Price Breaks: Each | Bag (5 ea) | Case (10 ea)

BIMINI HINGES & FITTING

C A

FITST2576

Quick-Release Bimini Top Hinge Easily removes or installs without having to keep track of screws. Installs with two #10 screws (not included). Price Breaks: Each | Bag (5 ea) | Case (10 ea)

FITST2578

Quick-Release Bimini Strap Hinge Installs with two #10 screws (not included). Price Breaks: Each | Bag (5 ea) | Case (10 ea)

FITST2577

Quick-Release Round Surface Bimini Top Fit Round design fits with the shape of the boat. Adapter can be inserted four different ways, 90° apart. Price Breaks: Each | Bag (5 ea) | Case (10 ea)

CHROME DIE-CAST FITTINGS Zinc die-cast fittings with chrome plating. Though not as strong as stainless steel, these fittings give you the look of stainless steel without the cost. These fittings are made for boats on fresh water lakes, and are not recommended for salt water. D

G H

HINGES D E

EYE ENDS

FITCH2715

10° Large Deck Hinge

FITCH2713

Large Deck Hinge

I J

FITCH2545

Insert Eye End—¾”

FITCH2525

Insert Eye End—⅞”

Price Breaks: Bag (10 ea) | Box (5 bags) | Case (10 bags)

MOUNTING PLATE F

FITCH2659

Mounting Plate Price Breaks: Bag (10 ea) | Box (5 bags) | Case (10 bags)

ag (10 ea) | Price Breaks: B Box (5 bags) | Case (10 bags) K L

FITCH2546

Outside Eye End—¾”

FITCH2547

Outside Eye End—⅞”

ag (10 ea) | Price Breaks: B Box (5 bags) | Case (10 bags)

END CAP G

FITCH2685

Track Slide End Cap Price Breaks: Bag (10 ea) | Box (5 bags) | Case (10 bags)

BOW SOCKET H

FITCH2695

Bow Socket—Chrome-Plated

JAW SLIDES M N

FITCH2625

Jaw Slide—¾”

FITCH2605

Jaw Slide—⅞” Price Breaks: Bag (10 ea) | Box (5 bags) | Case (10 bags)

Price Breaks: Bag (10 ea) | Box (5 bags) | Case (10 bags)

marine - awning - upholstery supplies | 71

DELRIN: TOP FITTINGS A full range of boat fittings in Delrin Acetyl resin compound. Delrin nylon is ideal for sport and recreational crafts due to its excellent resistance to corrosion of any kind. Color is cast in, not coated on, which means that it hides scratches well. Self-lubricating to a degree, Delrin Jaw Slides are unaffected by water exposures and tough enough that it can be tapped for set screws.

DECK HINGES

JAW SLIDES A A

FITBL2705

1” Square Jaw Slide—Black

FITWH2706

1” Square Jaw Slide—White

H H

FITBL2767

Small Black Deck Hinge—Lock Left

FITBL2766

Small Black Deck Hinge—Lock Right

ag (10 ea) | Box (5 bags) | Price Breaks: B Case (10 bags)

Price Breaks: Bag (10 ea) | Box (5 bags) | Case (10 bags)

B B

FITBL2600

⅞” Jaw Slide—Black

FITWH2590

⅞” Jaw Slide—White

C C

¾” Jaw Slide—Black

FITWH2610

¾” Jaw Slide—White

J J

K K

INSIDE EYE ENDS D D

1” Square Inside Eye End—Black

FITWH2709

1” Square Inside Eye End—White

FITBL2510

⅞” Inside Eye End—Black

FITWH2500

⅞” Inside Eye End—White

L L

FITBL2520

¾” Inside Eye End—Black

FITWH2530

¾” Inside Eye End—White

M M

N N

OUTSIDE EYE END FITBL2541

⅞” Outside Eye End—Black

FITWH2540

⅞” Outside Eye End—White

O O

FITWH2560

Large Deck Hinge—White

FITBL2651

Deck Hinge/Slide—Black

FITWH2650

Deck Hinge/Slide—White

FITBL2661

Two-Hole Side Mount Plate—Black

FITWH2660

Two-Hole Side Mount Plate—White

FITBL2701

Side Mount/Slide Track—Black

FITWH2700

Side Mount/Slide Track—White

FITBL2570

Small Deck Hinge—Black

FITWH2550

Small Deck Hinge—White Price Breaks: Bag (10 ea) | Box (5 bags) | Case (10 bags)

Large Deck Hinge—Black

FITBL2580

ag (10 ea) | Box (5 bags) | Price Breaks: B Case (10 bags)

Price Breaks: Bag (10 ea) | Box (5 bags) | Case (10 bags)

Angle Base Deck Hinge—White

ag (10 ea) | Box (5 bags) | Price Breaks: B Case (10 bags)

Price Breaks: Bag (10 ea) | Box (5 bags) | Case (10 bags)

G G

FITWH2710

ag (10 ea) | Box (5 bags) | Price Breaks: B Case (10 bags)

Price Breaks: Bag (10 ea) | Box (5 bags) | Case (10 bags)

F F

Angle Base Deck Hinge—Black

ag (10 ea) | Box (5 bags) | Price Breaks: B Case (10 bags)

Price Breaks: Bag (10 ea) | Box (5 bags) | Case (10 bags)

E E

FITBL2711

ag (10 ea) | Box (5 bags) | Price Breaks: B Case (10 bags)

FITBL2708

Angle Deck Hinge Large Hole—Black Price Breaks: Bag (10 ea) | Box (5 bags) | Case (10 bags)

Price Breaks: Bag (10 ea) | Box (5 bags) | Case (10 bags) FITBL2620

FITBL2712

72 | marine - awning - upholstery supplies

G N

SOCKETS

FITWH11042

Bow Rail Socket—White Price Breaks: B ag (10 ea) | Box (5 bags) | Case (10 bags)

G G

FITBL2769

Batton Socket—Black Nylon

FITWH2768

Batton Socket—White Nylon

ag (10 ea) | Box (5 bags) | Price Breaks: B Case (10 bags) J

SLIDES H H

Track Slide—Black

FITWH2680

Track Slide—White

ag (10 ea) | Box (5 bags) | Price Breaks: B Case (10 bags)

WEDGE A A

FITBL2681

FITBL2652

Angle Wedge for Deck Hinge—Black

FITWH2561

Angle Wedge for Deck Hinge—White

I I

FITBL2657

Slide Lock with Screw—Black

FITWH2655

Slide Lock with Screw—White Price Breaks: Bag (10 ea) | Box (5 bags) | Case (10 bags)

Price Breaks: Bag (10 ea) | Box (5 bags) | Case (10 bags)

TUBE CONNECTORS

SCREWS B B

FITBL2654

Nylon Head Screw—Black

FITWH2653

Nylon Head Screw—White

ag (10 ea) | Box (5 bags) | Price Breaks: B Case (10 bags)

LASH HOOKS C C

FITBL2671

Two-Hole Lash Hook—Black

FITWH2670

Two-Hole Lash Hook—White

ag (25 ea) | Box (4 bags) | Price Breaks: B Case (20 bags)

CHANNELS D E

FITBL2683

Channel Trim End Insert—Black

FITBL2691

Channel End Cap—Black

J J

FITBL2612

¾” Tube Connector—Black

FITWH2611

¾” Tube Connector—White Price Breaks: Bag (10 ea) | Box (5 bags) | Case (10 bags)

K K

FITBL2614

⅞” Tube Connector—Black

FITWH2613

⅞” Tube Connector—White Price Breaks: Bag (10 ea) | Box (5 bags) | Case (10 bags)

EYE STRAPS L L

FITBL2640

Eye Straps—Black

FITWH2630

Eye Straps—White Price Breaks: Bag (25 ea) | Box (4 bags) | Case (20 bags)

Price Breaks: Bag (10 ea) | Box (5 bags) | Case (10 bags) M

SUN PROTECTOR CLIPS

Two or three sun protector clips will extend the life of clear plastic windows on boats by holding the windows clear of the frame and preventing “heat branding” and abrasion along the frame. This can cause whitening of the clear plastic and weakening of the window.

O P Q

FITCL2450

Sun Protector Clip—⅞”

FITCL2451

Sun Protector Clip—1”

FITCL2452

Double Sun Protector Clip—⅞”

ag (25 ea) | Box (4 bags) | Price Breaks: B Case (20 bags) O

VADNEY WINDSHIELD CLIPS M N

FITCL2453

Windshield Clip—Square Boat Top Fitting

FITCL2454

Windshield Clip—Round Price Breaks: Bag (25 ea) | Box (4 bags) | Case (20 bags)

marine - awning - upholstery supplies | 73

STAYPUT The StayPut fasteners’ unique design provides a superior and reliable fastening system without the need for springs or pressure to remain closed. They are made from the highest quality UV-stable nylon composite. Resistant to corrosion and will provide many years of trouble-free operation, particularly in a marine environment. Also used for tents, awnings and covers, etc.

HOOK A

FASST1707

KNOBS I J

1” Inflatable Cover Hook Price Breaks: Bag (10 ea) | Box (5 bags) | Case (10 bags)

FASST1701

StayPut Shock Cord Clip—Black

FASST1700

StayPut Shock Cord Clip—White

StayPut Knob—Black

FASST1706

StayPut Knob—White Price Breaks: Bag (10 ea) | Box (5 bags) | Case (10 bags)

SHOCK CORD CLIPS B C

FASST1703

KEDER BULLET K

FASST1713

Price Breaks: Bag (10 ea) | Box (5 bags) | Case (10 bags)

TENT WALL HOOK

SHOCK CORD PULLS D E

StayPut Keder Bullet—White

FASST1719

StayPut Shock Cord Pull—Black

FASST1718

StayPut Shock Cord Pull—White

FASST1704

StayPut Tent Wall Hook—White Price Breaks: Bag (10 ea) | Box (5 bags) | Case (10 bags)

Price Breaks: Bag (10 ea) | Box (5 bags) | Case (10 bags)

SINGLE STUDS F G

FASST1708

StayPut Vertical Single Stud

FASST1709

StayPut Horizontal Single Stud Price Breaks: Bag (10 ea) | Box (5 bags) | Case (10 bags)

CURVED BASE INSERT H

FASST1710

StayPut Curved Base Insert

Price Breaks: Bag (10 ea) | Box (5 bags) | Case (10 bags)

D E

F I G

74 | marine - awning - upholstery supplies

K L

MARINE WELT

XTREME EDGE SEAL

Exclusive to Ennis Fabrics. A unique, fl exible edge seal. Can be sewn or glued to most materials and surfaces and creates a three-point contact seal.

A B

FITWE2787

XtremeEdge Seal—Black

FITWE2789

XtremeEdge Seal—White

Price Breaks: Foot | Box (50’) | Case (100’)

MARINE V SEAL

V-Seal is the right choice for all cut-outs and tight corners, especially bow covers and radar arch cut-outs.

FITWE2788

Marine V Seal—Black Price Breaks: Foot | Box (50’) | Case (100’)

MARINE ULTRA SEAL

Ultra Seal can be glued or sewn to most materials and surfaces. Works well with Common Sense fasteners and gives a fl atter fi nished profi le.

FITWE2786

Marine Ultra Seal Price Breaks: Foot | Box (50’) | Case (100’)

MARINE WINDSHIELD WELT

STOP-LEAK TRIM

Welt-style PVC over ⅜” foam, with ½” seam allowance.

Bulb seal PVC extrusion for boat tops.

FITMI2778

Marine Windshield Welt

FITMI2779

Stop-Leak Trim—Black Price Breaks: Roll (100’) | Box (5 Rolls ) | Case (10 Rolls)

Price Breaks: Foot | Box (50’) | Case (100’)

MARINE VENTING G

AIR VENT

NEW!

Designed to help prevent dry rot, condensation, mildew and rust due to improper ventilation. Vinyl vents can be stitched, heat sealed or glued using HH-66 Adhesives (see p.144) to tarps, canvas or vinyl covers. Made of tough, extremely pliable vinyl that can be bent, folded, or fl attened without damage. Will not rot or discolor and are impervious to sun and weather. Special hood design will spring back to the original shape and remain open regardless of how it may have folded. Sew nylon netting or fi berglass screening to fabric under the vent to prevent insect access.

G H

FITVE2797

Air Vent for Vinyl Tops—White

FITVE11023

Air Vent for Vinyl Tops—Black Price Breaks: Bag (10) | Box (5 bags) | Case (10 bags)

BOAT VENT III

NEW!

An improved version of Boat Vent II, helps to prevent the growth of mold and mildew in covered boats. Made from high UV-inhibited plastic, improvements include 40% more venting, 30 washer teeth for better grip, and an overhanging top to deter moisture.

FITVE2804

Boat Vent III Price Breaks: Each | Box (5 ea) | Case (10 ea)

HOLE CUTTER FOR BOAT VENT II & III

Simple and effi cient cutter for producing clean holes for mounting Boat Vent II (#FITVE2798) into covers. Crank action cutter creates a precisely-sized hole in seconds.

FITVE2799

Hole Cutter for Boat Vent II & III Price Break: Each | 3 ea | 5 ea

BOAT VENT II

A plastic cover support and venting device for use with ¾” or ⅞” support poles.

FITVE2798

Boat Vent II Price Breaks: Each | Box (5 ea) | Case (10 ea)

marine - awning - upholstery supplies | 75

POLE FITTINGS A

DURA SNAP POLE END FOR COCKPIT POLE

Smooth Delrin fitting that has a standard Dura Snap stud. Fits fi rmly into the end of ¾” tubing. Snap is nickel-plated brass for long life.

FITTE2780

H F

Dura Snap Pole End for Cockpit Pole Price Breaks: Bag (25 ea) | Box (4 bags) | Case (20 bags)

GROMMET POLE END FOR COCKPIT POLE

The Delrin unit fits into ¾” tubing and is tapered to accept self center grommets with an interior fi nished diameter of ⅜” or greater. Round edges will not tear or snag canvas or tops.

D E

FITTE2775

Grommet Pole End for Cockpit Pole—Black Price Breaks: Bag (25 ea) | Box (4 bags) | Case (20 bags)

JOINT SECTION FOR COCKPIT POLE

Tough Delrin fitting with nylon head screw for locking extension of the ¾” tubing. Fits securely onto the ⅞” tubing. J

FITTE2785

Joint Section for Cockpit Pole Price Breaks: Bag (25 ea) | Box (4 bags) | Case (20 bags)

POLE CLIP I

VINYL FOOT FOR COCKPIT POLE

Non-slip, non-marring vinyl feet for aluminum or steel tubing in two sizes. Finish off any exposed or open tubing end with these pieces.

A B

FITTE2790

¾” Vinyl Foot for Cockpit Pole—Black

FITTE2795

⅞” Vinyl Foot for Cockpit Pole—Black Price Breaks: Bag (25 ea) | Box (4 bags) | Case (20 bags)

SUPPORT POLES

Pre-assembled telescoping support for water craft with a combo end, meaning that the one end is a snap and the other is a grommet pole end for cockpit pole.

C D E

FITTE2802

Support Pole 38⅜” to 70” Combo End

FITTE2801

Support Pole 27¼” to 47” Combo End

FITTE2800

Support Pole 18¼” to 28” Combo End Price Breaks: Each | Box (5 ea) | Case (10 ea)

76 | marine - awning - upholstery supplies

FITCL2591

1” Pole Clip—Grey Price Breaks: Bag (10 ea) | Box (5 bags) | Case (10 bags)

SWIVEL PAD FOR SUPPORT POLES

NEW!

Features a large base to protect fl oors from damage caused by standard crutch tips. The Swivel Pad disperses pole weight and uses thermoplastic rubber for a fi rmer grip. Use with Support Poles #FITTE2800, #FITTE2801, and #FITTE2802.

FITTE2803

Swivel Pad for Support Poles Price Breaks: Each | Box (5 ea) | Case (10 ea)

BOAT TOP FRAME KITS BTK-1 BOAT TOP FRAME KIT

A kit featuring a complete, ready-made boat top frame. Frames are made of ⅞” bright anodized tubing and easily fitted to boats with beams from 40”–80”. Each kit contains:

• Frame (x1)

• ⁷/₈” Inside Eye Ends (x4)

• ⁷/₈” Jaw Slides (x2)

• 1” Nickel Brass Slides (x4)

• Large Deck Hinges (x2)

• 1” Nickel Brass Snaps (x2)

• Eye Straps (x2) All fittings are white Delrin

FITKI2763

BTK-1 Boat Top Frame Kits Price Break: Each | 3 ea | 5 ea

BIMINI BOAT TOP FRAME KIT

Three-bow frame kit fabricated from ⅞”. Bright dip aluminum tubing. Joints are attached clean and flush through the use of insert sleeves. Packed one per box, complete with hardware. All fittings are black Delrin.

FITKI2761

Bimini Boat Top Frame Kits

90” (2.3m) Max

42” (1.07m) Max

Price Break: Each | 3 ea | 5 ea

PONTOON BOAT TOP FRAME KIT

OD* 1” x Length 1” x Wall Thickness 0.062” extruded satin anodized square tubing. Packed one per box, complete with

FITKI2462

Pontoon Boat Top Frame Kits

C 66 ”

66 ”

Price Break:Each | 3 ea | 5 ea

LARGE BOAT TOP FRAME KIT

96 ”

Two-bow frame. Packed one per box, complete with hardware.

96 ”

black Delrin nylon fittings.

FOR PONTOON BOAT

OD* ⁷/₈” x Wall Thickness 0.058” drawn aluminum bright anodized tubing with black Delrin nylon fittings.

FITKI2764

108” Wide

Large Boat Top Frame Kits Price Break: Each | 3 ea | 5 ea D 50 ” 60

”

96” Wide

*OD = Outer Diameter

marine - awning - upholstery supplies | 77

MISCELLANEOUS FITTINGS ALUMINUM BOAT SEAT HINGES A

FITHI2776

W3” x L6’ Flat Continuous Boat Seat Hinge A flat-style continuous boat seat hinge in mill-finish aluminum. 3” wide with ³⁄₁₆” holes drilled on 4” centers.

Price Breaks: Each | 25 ea | 50 ea

FITHI2772

W4½” x L6’ “W” Continuous Boat Seat Hinge A W-shaped hinge in a mill finish aluminum, drilled on 2” centers, staggered at ½”. Hinge lies open to a width of 4½”; aluminum is 0.060” thick. Price Breaks: Each | 25 ea | 50 ea

ALUMINUM TRACK

Bright anodized aluminum alloy channel to use with white and black Delrin marine fittings. Aluminum alloy provides excellent corrosion resistance and is easily extruded. It can be readily welded and brazed.

FITMI2740

12’ Aluminum Slide Track Channel Price Breaks: Each | Case (20 ea)

MISCELLANEOUS C

D E F

FITST2575

Snap Hook—1”

FITST2535

Pad Eye/Eye Strap

FITST2572

Adjuster Slide—1”

ag (25) | Box (4 bags) | Case (20 bags) Price Breaks: B F

VENTS AND WASHERS D

Brass ¾” vents and washers for use in mattresses, upholstery and any other application where airflow is a concern. Requires #9022 Vent Die to set the ventilators.

GROMI9021

#1 Vents and Washers

Price Breaks: Bag (144) | Box (5 Bags) | Case (10 Bags) G

VENT DIE

This die quickly sets the #9021 ventilators. Merely punch your hole, set the ventilator with the neck up on the base, slip the fabric in place then put the washer on top. A few even taps with a mallet will set the vent.

TOOGR9022

#621 Vent Die

Price Break: Each | 3 ea | 6 ea

DOWEL PINS

Used to strengthen frames. Spiral grooves help distribute glue along the dowels.

I J

FRADO4031

⅜”x 2” Birch Dowel Pins

FRADO4033

½”x 2” Birch Dowel Pins

Price Breaks: Bag (50) | Box (10 Bags) | Case (50 Bags) J

78 | marine - awning - upholstery supplies

INTRODUCING OUR

FULL LINE OF GROMMETS AND WASHERS. Scovill.

Your only source for everything fasteners.

scovill.com/grommetswashers

grommets A

R P

C1 B1

I J

D1 L

N M G1 H1

ALL GROMMETS COME WITH WASHERS.

GROMMETS The main factor in choosing a line of grommets relates to the dies that you may already have. Osborneâ&#x20AC;&#x2122;s spur grommets have a protective rolled rim on the grommet, which the Cruiser line does not have. However, either brand gives excellent resistance to pulling out. Cruiser brand grommets are popular for its European Metric sizing system. However, the sizes are very close to the Standard system normally used in North America. For comparison purposes, we list these grommets in Standard sizes.

80 | marine - awning - upholstery supplies

STIMPSON SELF-PIERCING—BRASS

Save time and cutter costs. Grommets with a special selfpiercing finish on the grommet top. No pre-cutting of holes required, simply line up grommets and press with one of the machines listed on p.91. System works with heavy industrial materials. Sizes given are the finished inside hole sizes, and is comparable to Osborne grommet sizes.

A B C D E

GROSP5045

¼” Self-Piercing Grommet & Washer—Brass

GROSP5046

5/16” Self-Piercing Grommet & Washer—Brass

GROSP5047

⅜” Self-Piercing Grommet & Washer—Brass

GROSP5048

½” Self-Piercing Grommet & Washer—Brass

GROSP5049

9/16” Self-Piercing Grommet & Washer—Brass

F G H

GROSP5041

5/16” Self-Piercing Grommet—Nickel-Plated

GROSP5042

⅜” Self-Piercing Grommet—Nickel-Plated

GROSP5043

½” Self-Piercing Grommet—Nickel-Plated Pr ice Breaks: Bag (100 ea) | Box (5 Bags) | Case (10 Bags)

OSBORNE/STIMPSON ROLLED-RIM SPUR—BRASS Rolled rim spur grommets have an extra lip on the rim of the grommet that accepts the spurs of the washer to give the ultimate pull-out resistance. Use with Osborne dies (p.91). Will not work with Cruiser brand dies.

GROOS6080

GROOS6081

GROOS6082

D1 E1 F1 G1 H1

GROOS6064

#0 Spur Grommet & Washer—Brass

GROOS6066

#1 Spur Grommet & Washer—Brass

GROOS6065

#2 Spur Grommet & Washer—Brass

GROOS6061

#3 Spur Grommet & Washer—Brass

GROOS6062

#4 Spur Grommet & Washer—Brass

Plated/Brass

GROCR6117

#3 Plain Grommet & Tooth Washer—Brass

GROCR6115

#2 Plain Grommet & Washer—Brass

GROCR6113

#1 Plain Grommet & Washer—Brass

L M N

GROCR6127

#3 Spur Grommet & Washer—Brass

GROCR6125

#2 Spur Grommet & Washer—Brass

GROCR6123

#1 Spur Grommet & Washer—Brass

#2 Spur Grommet & Washer—NickelPlated/Brass #3 Spur Grommet & Washer—NickelPlated/Brass

Pr ice Breaks: Bag (144 ea) | Box (5 Bags) | Case (25 Bags)

CRUISER PLAIN & SPUR—BRASS I J K

#1 Spur Grommet & Washer—Nickel-

Pr ice Breaks: Bag (100 ea) | Box (5 Bags) | Case (10 Bags)

SEWABLE BLACK GROMMET

Heavy-duty, sewable black grommet can be sewn into seams. Has a cold crack of -20°C (-4°F). Some uses include sporting bags and duffel bags, as well as tents.

GROMI5075

Sewable Grommet—Black Pr ice Breaks: Bag (25 ea) | Box (5 Bags) | Case (40 Bags)

DOT/OSBORNE/STIMPSON PLAIN—BRASS

NEW LONG NECK BRASS GROMMET Perfect for all automatic feeding grommet machines. GROOS6083

#2 Long Neck Grommet—Brass Pr ice Breaks: Bag (144 ea) | Box (5 Bags) | Case (25 Bags)

Osborne quality grommets and washers. Use with Osborne dies (p.91). Will not work with Cruiser brand dies.

P Q R S T U V

GROOS5017

#00 3/16” Plain Grommet & Washer—Brass

GROOS5014

#0 ¼” Plain Grommet & Washer—Brass

GROOS5011

#1 9/32” Plain Grommet & Washer—Brass

GROOS5012

#2 ⅜” Plain Grommet & Washer—Brass

GROOS5013

#3 7/16” Plain Grommet & Washer—Brass

GROOS5015

#4 ½” Plain Grommet & Washer—Brass

GROOS5016

#5 ⅝” Plain Grommet & Washer—Brass

GROOS5039

#0 ¼” Plain Grommet & Washer—Black

X Y Z

GROOS5040

#0 ¼” Plain Grommet & Washer—Nickel-Plated

GROOS6075

#1 9/32” Plain Grommet & Washer—Nickel-Plated

GROOS6076

#2 ⅜” Plain Grommet & Washer—Nickel-Plated Pr ice Breaks: Bag (144 ea) | Box (5 Bags) | Case (25 Bags)

Please see p.91 for grommet tools

marine - awning - upholstery supplies | 81

industrial & bag hardware DELRIN WEBBING BUCKLES All of our nylon hardware is made of tough, weather-resistant Delrin. Waterproof, long-lasting and versatile. All dimensions refer to the size of webbing that fits cleanly through the opening on the fitting to attach to your product. Unless otherwise stated, the Delrin hardware is black.

BAGBU2201

Break Strengths: #BAGBU2226: 165 lb (75 kg) | #BAGBU2225: 143 lb (65 kg)

F G

CONTOURED BUCKLE BAGBU2202

BAGBU2226

2” Dual Adjustable Side Release Buckle

BAGBU2225

1½” Dual Adjustable Side Release Buckle Price Breaks: Bag (25 ea) | Box (4 bags) | Case (20 bags)

1” Contoured Buckle Break Strength: 121 lb (55 kg)

CENTER RELEASE BUCKLE

Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

BAGBU2248

BAGBU2236

2” Heavy-Duty Cam Buckle Extra heavy-duty cam action buckle for use with wider webbing. 2” tends to be used in heavier applications and should have a heavier buckle. Firm positive lock with toothed cam lobe.

HOT TUB BUCKLE & LOCK N

BAGBU2206

Case (20 bags)

BAGBU2233

1½” Cam Release Buckle

BAGBU2232

1” Cam Release Buckle

BAGBU2205

Price Breaks: Bag (25 ea) | Box (4 bags) | Case (20 bags)

SIDE RELEASE BUCKLES

One end is fixed, the other end is adjustable. Break Strengths: #BAGBU2240: 165 lb (75 kg) | #BAGBU2235: 143 lb (65 kg) #BAGBU2230: 121 lb (55 kg) | #BAGBU2229: 88 lb (40 kg) #BAGBU2228 (White): 121 lb (55 kg)

1”

1½”

2”

Black

BAGBU2229 (H)

BAGBU2230 (I)

BAGBU2235 (K)

BAGBU2240 (L)

White

BAGBU2228 (J)

Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

82 | marine - awning - upholstery supplies

Key for Hot Tub Buckle A separate key is not necessary for each hot tub lock as any key will work with any lock. Works together with the Lockable Hot Tub Buckle (#BAGBU2206), but each are sold separately.

Price Breaks: Bag (25 ea) | Box (5 bags) | Case (10 bags)

¾”

Lockable Hot Tub Buckle Price Breaks: Bag (25) | Box (4 bags) | Case (20 bags)

Price Breaks: Bag (25 ea) | Box (4 bags) |

¾” Low Profile Center Release Buckle Break Strength: 143 lb (65 kg) Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

CAM BUCKLES C

Both ends are adjustable.

1” Detail Buckle Break Strength: 176 lb (80 kg) Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

DUAL ADJUSTABLE SIDE RELEASE BUCKLES

DETAIL BUCKLE A

METAL WEBBING BUCKLES All metal buckles are for heavy-duty applications. Brass, zinc and nickel are preferred for moisture exposure as they will not rust. Steel is the best for ultimate strength. A

D E

STEEL WEB BUCKLES

Thumb grip release buckle. One end fixed by sewing, the other adjustable through serrated spring-loaded thumb grip.

A B

BAGBU2224

1” Steel Web Buckle—Black

BAGBU2227

1” Steel Web Buckle—Nickel-Plated

STEEL ADJUSTER BUCKLE Threaded type adjuster in nickel-plated steel.

BAGBU2278

Curved thumb and finger release buckle. One end is sewn and fixed, the other end is threaded and adjustable. Perfect for rounded surfaces or corner locations. BAGBU2222

2” Web Strap Buckle—Nickel-Plated Steel

BAGBU2221

1½” Web Strap Buckle—Nickel-Plated Steel Break Strength: 121 lb (55 kg)

1” Adjuster Buckle—Nickel-Plated Break Strength: 139 lb (63 kg) Price Breaks: Bag (25 ea) | Box (4 bags) Case (20 bags)

Price Breaks: Bag (25 ea) | Box (4 bags) | Case (20 bags)

WEB STRAP BUCKLES—NICKEL-PLATED STEEL

C D

DOUBLE-BAR BUCKLE Double-bar buckle in nickel-plated zinc.

BAGBU2283

1” Double-Bar Buckle—Nickel-Plated Break Strength: 705 lb (320 kg) Price Breaks: Bag (25 ea) | Box (4 bags) Case (20 bags)

Price Breaks: Bag (25 ea) | Box (4 bags) | Case (20 bags)

SURCINGLE HOOK & CLASPS H G

SURCINGLE HOOK AND CLASP— NICKEL-PLATED STEEL

Traditional equestrian hook and clasp fastener. Quick fitting and simple enough to join when wearing gloves. Twist to join or open. Comes either in a Nickel or Brass-plated finish. Both parts are included in one unit.

G H

BAGSU6845

2” Surcingle Hook and Clasp—Nickel-Plated Steel

BAGSU6841

2” Surcingle Hook and Clasp—Brass-Plated Steel Price Break: Bag (25 ea) | Box (4 Bags) | Case (20 Bags)

marine - awning - upholstery supplies | 83

WEBBING SLIDES

B A

E C

WEB SLIDES—METAL A -

1” Nickel-Plated Steel Web Slide

BAGSL6830

1½” Nickel-Plated Steel Web Slide

Straplock slides for fixing and adjusting webbing. One end fixed by sewing, the other is adjustable through the locking bar. Also available in a heavy-duty version for heavier use.

Price Breaks: Bag (100 ea) | Box (5 bags) |

Pr ice Breaks (unless otherwise specified): Bag (100 ea) | Box (5 bags) |

Case (10 bags)

BAGSL6835

2” Nickel-Plated Steel Web Slide Price Breaks: Bag (100 ea) | Box (4 bags) | Case (20 bags)

BAGSL6840

Break Strength: 445 lb (200 kg) Price Breaks: Bag (25 ea) | Box (4 bags) | FITMI2000

Case (10 bags)

BAGSL2279

I J

BAGSL2280

Break Strength: 110 lb (55 kg)

BAGSL2282

Break Strength: 154 lb (70 kg)

BAGSL2286

1” Adjuster Slide—Nickel-Plated Steel

DUAL LOCK STRAPLOCK BUCKLE—DELRIN M

BAGSL2287

1” Dual Lock Strap Lock Buckle Slider for connecting and adjusting two free ends of webbing.

WEB SLIDES—DELRIN

BAGSL2285 BAGSL2294

2” Heavy-Duty Strap Lock Buckle Break Strength: 660 lb (300 kg)

Case (20 bags)

F D

1½” Strap Lock Buckle

Price Break: Bag (25 ea) | Box (4 Bags) | Case (10 Bags)

Price Breaks: Bag (25 ea) | Box (4 bags) |

BAGSL2284

1” Strap Lock Buckle

Case (20 bags)

Compact 1” slide for use in any application with 1” webbing.

¾” Strap Lock Buckle Break Strength: 99 lb (45 kg)

2” Nickel-Plated Steel Heavy Web Slide Extra-heavy adjuster slides for high stress applications.

STRAPLOCK BUCKLES—DELRIN

BAGSL6825

¾” Slide—Black

Break Strength: 143 lb (65 kg)

Break Strength: 66 lb (30 kg)

Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

1” Slide—Black 1” Slide—White Break Strength: 88 lb (40 kg)

BAGSL2290

1½” Slide—Black J

Break Strength: 110 lb (50 kg)

BAGSL2295

2” Slide—Black

Break Strength: 143 lb (65 kg) Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

WIDE MOUTH WEB SLIDES—DELRIN H

BAGSL2291

¾” Wide Mouth Slide—Black Wide mouth slide for thicker and heavier webbing or multiple threading. Break Strength: 88 lb (40 kg) Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

84 | marine - awning - upholstery supplies

L M

WEBBING LOOPS LOOPS—DELRIN

Two-way webbing connector fixed by stitching. Used in bags and backpacks.

A B C

BAGLO2274

¾” Loop—Black Delrin

BAGLO2275

1” Loop—Black Delrin

BAGLO2276

1½” Loop—Black Delrin

Break Strength: 99 lb (45 kg)

BAGLO2277

2” Loop—Black Delrin

Break Strength: 110 lb (55 kg) Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

REDUCING LOOP—DELRIN

A loop to connect 1” and 2” webbing by stitching. Best used for bags, backpacks and sports equipment.

BAGLO2267

Reducing Loop—Black Delrin

ag (100 ea) | Box (5 bags) | Price Breaks: B Case (10 bags)

WEBBING CONNECTORS

K F J

RECTANGLE—DELRIN

Two-way webbing connector with rounded edges.

BAGTR2320

TRIANGLES—DELRIN

Three-way sewn webbing connector.

1” Plastic Rectangle—Black Delrin Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

J K

BAGTR2305

1” Nylon Triangle—Black Delrin

BAGTR2307

1½” Nylon Triangle—Black Delrin Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

BAG ACCESSORIES SHOULDER PADS

Rubber shoulder pads fit webbing widths from 1½” to 2”. Shoulder pads give professional finished appearance and add practicality to bags, totes and any carrying strap.

G H

BAGPA2302

1½” Shoulder Pad—Black

BAGPA2304

2” Shoulder Pad—Black

H G

Price Breaks: Bag (25 ea) | Box (4 bags) | Case (20 bags)

LUGGAGE STUD

Delrin stud for the base of bags, cases, etc. Prevents premature wear on these surfaces. Attach with nail stud and Delrin washer to prevent pull-through. All three pieces included in one unit.

BAGMI2325

#4 Luggage Stud Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

marine - awning - upholstery supplies | 85

WEBBING D-RINGS SNAPHOOK D-RING

D-ring with built-in eyelet for clipping.

BAGDR2262

B A

1½” Snap D-Ring—Black Delrin Price Breaks: B ag (100 ea) | Box (5 bags) | Case (10 bags)

BAGDR2253

DELRIN D-RINGS B

1” D-Ring—White Delrin

ag (100 ea) | Box (5 bags) | Case (10 bags) Price Breaks: B C D E F

BAGDR2259

¾” D-Ring—Black Delrin

BAGDR2260

1” D-Ring—Black Delrin

BAGDR2265

1½” D-Ring—Black Delrin

BAGDR2270

2” D-Ring—Black Delrin

G H

Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

STAINLESS STEEL WELDED D-RING G

BAGDR3902

1” Stainless Steel Welded D-Ring Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

BRASS-PLATED HEAVY WELDED STEEL D-RING Heavy-duty welded D-ring for high-strength applications requiring a brass finish.

BAGDR3892

1” Heavy D-Ring—Brass-Plated Break Strength: 1,210 lb (550 kg)

Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

NICKEL-PLATED HEAVY WELDED STEEL D-RINGS

D-rings in nickel-plated steel with a welded seam. Will not pull apart under heavy stresses.

BAGDR3903

¾” Nickel-Plated Heavy D-Ring

R S

Break strength: 1056 lb (480 kg)

BAGDR3904

1” Nickel-Plated Heavy Welded D-Ring Break strength: 1,210 lb (550 kg)

BAGDR3905

1¼” Nickel-Plated Heavy Welded D-Ring Break strength: 1,430 lb (650 kg)

BAGDR3906

BAGDR3907

2” Nickel-Plated Heavy Welded D-Ring Break strength: 1,870 lb (850 kg) Pr ice Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

NICKEL-PLATED UNWELDED STEEL D-RING M N O

BAGDR3901

BAGDR3890

¾” Nickel-Plated Unwelded Steel D-Ring

BAGDR3900

1” Nickel-Plated Unwelded Steel D-Ring

BAGDR3910

1½” Nickel-Plated Unwelded Steel D-Ring Price Breaks: Bag (100 ea) | Box (5 Bags) Case (10 Bags)

86 | marine - awning - upholstery supplies

1” Nickel-Plated Welded D-Ring Price Breaks: Bag (100 ea) | Box (5 Bags) Case (10 Bags)

1½” Nickel-Plated Heavy Welded D-Ring Break strength: 1,496 lb (680 kg)

NICKEL-PLATED WELDED D-RING

SEWABLE D-RING Q

BAGDR2254

¾” Sewable D-Ring—Black Delrin Price Breaks: Bag (100 ea) | Box (5 bags) Case (10 bags)

WELDED O-RING Break strength: 880 lb (400 kg)

R S

BAGOR2297

1½” Brass-Plated Welded O-Ring

BAGOR2296

1½” Nickel-Plated Welded O-Ring Price Breaks: Bag (25 ea ) | Box (4 Bags) | Case (20 bags)

WEBBING SNAP HOOKS

Pl ease Note: Measurements preceding product descriptions refer to the webbing that will fit.

PRE-ASSEMBLED SNAP HOOK—DELRIN

Fully assembled snap hook.

A B C

BAGHO2251

1” Preassembled Snap Hook—White

BAGHO2237

¾” Preassembled Snap Hook—Black

BAGHO2238

1” Preassembled Snap Hook—Black

D B

Break Strength: 99 lb (45 kg)

BAGHO2239

1½” Preassembled Snap Hook—Black Break Strength: 110 lb (50 kg)

BAGHO2241

2” Preassembled Snap Hook—Black

Break Strength: 121 lb (55 kg)

Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

UNIVERSAL SNAP HOOKS—DELRIN

Universal snap hooks swivels to accommodate angles.

BAGHO2244

¾” Universal Snap Hook—Black Break Strength: Unavailable

BAGHO2245

1” Universal Snap Hook—Black Break Strength: 77 lb (35 kg)

BAGHO2250

1½” Universal Snap Hook—Black

SNAP HOOK—NICKEL-PLATED BRASS

Nickel-plated brass snap hook for marine and other salt and moisture-exposed applications.

FITHO7700

1” Snap Hook—Nickel-Plated Brass Break Strength: 143 lb (65 kg) Price Breaks: Bag (25 ea) | Box (4 bags) | Case (20 bags)

Break Strength: 88 lb (40 kg) Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

SNAP HOOK—BRASS-PLATED STEEL I

BAGHO6822

1” Snap Hook—Brass-Plated

BAGHO6798

1” Heavy Snap Hook—Brass-Plated

I J

Price Breaks: Bag (25 ea) | Box (4 bags) | Case (20 bags)

SNAP HOOKS—NICKEL-PLATED STEEL K L M N

BAGHO6790

¾” Snap Hook—Nickel-Plated Steel

BAGHO6800

1” Snap Hook—Nickel-Plated Steel

BAGHO6810

1½” Snap Hook—Nickel-Plated Steel

BAGHO6820

2” Snap Hook—Nickel-Plated Steel

N M L

Price Break: Bag (25 ea) | Box (4 bags) | Case (20 bags)

MISCELLANEOUS O

FITST2575

Snap Hook—1” Price Breaks: Bag (25 ea) | Box (4 bags) | Case (20 bags)

SPRING SNAP HOOKS—NICKEL-PLATED STEEL The lightweight Spring Hook with Strap Eye is ideal for apparel and other non-critical applications.

BAGHO6788

¾” Spring Snap Hook—Nickel-Plated Steel Price Breaks: Bag (100 ea) | Box (5 bags) | Case (10 bags)

marine - awning - upholstery supplies | 87

SPRING SNAP HOOKS—NICKEL-PLATED STEEL

The Heavy Spring Snap Hook uses a heavier snap spring action for more positive closing, which means less chance of accidental opening. Features a pivoting head.

BAGHO6799

1” Heavy Spring Snap Hook—Nickel-Plated Steel

Break Strength: 598 lb (272 kg)

BAGHO6802

1” Heavy Spring Snap Hook—Nickel-Plated Steel A

Break Strength: 616 lb (280 kg) Price Breaks: Bag (25 ea) | Box (4 bags) | Case (20 bags)

HEAVY SNAP HOOKS—NICKEL-PLATED STEEL

Heavy snap hooks are used in tents, tacks, bags, and other applications requiring a very high strength hook. The webbing bar and hook are cast together for greatest strength.

C D

BAGHO6795

¾” Heavy Spring Snap Hook—Nickel-Plated Steel

BAGHO6797

1” Heavy Spring Snap Hook—Nickel-Plated Steel Break Strength: 300 lb (140 kg)

Price Breaks: Bag (25 ea) | Box (4 bags) | Case (20 bags)

BOLT SNAPS—BRASS-PLATED STEEL E

BAGHO6806

1” Bolt Snap—Brass-Plated Steel

Break Strength: 598 lb (272 kg) Price Breaks: Bag (25 ea) | Box (4 bags) | Case (20 bags)

BOLT SNAPS—NICKEL-PLATED STEEL

Bolt-style closing. Spring-loaded for one-hand operation. Used in tent, bag and other applications requiring a positive closing snap with a pivoting head.

F G

BAGHO6803

¾” Bolt Snap—Nickel-Plated Steel

BAGHO6805

1” Bolt Snap—Nickel-Plated Steel Break Strength: 598 lb (272 kg)

Price Breaks: Bag (25 ea) | Box (4 bags) | Case (20 bags)

E G F

88 | marine - awning - upholstery supplies

FASTENER TOOLS

tools F

I B

G D

PRES-N-SNAP HAND TOOL

Lightweight aluminum tool set snaps into place with a simple squeeze. Ideal for tarping, convertible top, tents, boat covers and canvas jobs. Each unit comes with setting dies for regular Dot ® Durable and Dura Snap type fasteners. A rubber ring (#TOOFA4028) holds one part of the fastener for one-handed operation.

TOOFA4029

Pres-N-Snap Hand Tool Price Break: Each | 3 ea | 6 ea

DURA SNAP PUNCH & ANVIL DIES

To set Dura Snap and Dot Durable fasteners into any material. Set snaps anywhere you can reach. ®

B C D E

TOOFA4023

Anvil Die for Eyelet

TOOFA4024

Anvil Die for Button

TOOFA4025

⅛” Dura Snap Hole Punch

TOOFA4022

Dura Snap Setting Punch

PRES-N-SNAP DIES F G

TOOFA4028

Rubber Ring for Pres-N-Snap

TOOFA4032

Pull-the-Dot Die—Pres-N-Snap Price Break: Each

H H I H H J K

#00 Osborne Die TOOFA4121

#0 Osborne Die

TOOFA4122

#1 Osborne Die

TOOFA4123

#2 Osborne Die

TOOFA4124

#0 Spur Osborne Die

TOOFA4125

#1 Spur Osborne Die

TOOFA4027

Replacement Dies for Pres-N-Snap Tool

TOOFA4034

Baby Dies for Pres-N-Snap Tool Price Break: Each | 3 ea | 6 ea

Price Break: Each | 3 ea | 6 ea

NOTES ON DOT®/OSBORNE/STIMPSON HAND SETTING DIES

Each set of the hand setting tools consists of two parts—the punch and the die. Note that the spur and plain are not interchangeable— you must have the specified die for each type.

TOP-SNAPPER

Ergonomic grip to provide you improved leverage and strength in placing or opening the snap. This tool has two stainless steel blades, a long blade that is suitable for use from inside, and a short blade that works well on the outside. The notch fits over the snap and enables you to open or close it easily. Reduces the chance of canvas tears and eases the fastening of your boat canvas or tonneaus.

TOOFA4038

Top-Snapper Tool Price Breaks: Each | 3 ea | 6 ea

marine - awning - upholstery supplies | 89

STAYPUT SPINCUTTERS

The StayPut Spincut is designed to simplify making holes in fabrics and webbings. Simply insert the StayPut Spincut tool into a power drill and hold a cutting board behind the fabric (#TOOGR6120, p.77). Activate the drill and gently push into the fabric. The tool does all the work in creating a clean, neat hole.

A B C

QUICK-FIT RELEASE TOOL

Simple tool releases Quick-Fit temporary snaps. With a twist of the wrist, they are ready to use again and again.

TOOQU3935

Quick-Fit Release Tool Price Break: Each | 3 ea | 6 ea

TOOFA1702

StayPut Spincut ¼”

TOOFA1716

StayPut Spincut ⅜”

TOOFA1717

StayPut Spincut 7/16”

CUTTERS

Price Break: Each | 3 ea | 6 ea

TOOFA3113

#171—Common Sense Hand Cutter

TOOFA3115

Lift-A-Dot EZ Hand Cutter

Two-prong, all-steel cutter for the standard metal Common Sense Clinch Plate Fastener (#FASCO4054, p.39). A mallet is recommended for striking the punch to avoid mushrooming the end. Hole-Cutting Pad (#TOOGR6120, p.77) is strongly recommended to maximize the life of the punch.

TOOFA3117

Common Sense E-Z Hand Cutter

Price Break: Each | 3 ea | 6 ea

LIFT-A-DOT EZ HAND CUTTER

NEW!

Price Break: Each | 3 ea | 6 ea

TOOFA3111

Punch designed to cut the oval hole and prong openings required for setting the standard metal common sense eyelet into fabric. A soft surface must be underneath the fabric being punched as the steel pins can scratch the casting. See fasteners on p.36-41.

HOLE PUNCHES F

TOOFA4016

#450—Common Sense Hand Cutter

Hole Punch for Lift-a-Dot Eyelet Price Break: Each | 3 ea | 6 ea

Price Break: Each | 3 ea | 6 ea

C D F

90 | marine - awning - upholstery supplies

GROMMET TOOLS A

HOLE CUTTING PAD F

Extend the life of your cutters by using this pad under the material you are punching. The surface absorbs the impact and prevents damage to the bench underneath. For maximum life of your cutters and die-setting equipment, always use a rubber mallet and not a steel hammer to set fasteners, grommets or to hole punch.

TOOGR6120

Hole Cutting Pad Size: W10”x D10” x H⁵⁄₁₆” Price Break: Each | 3 ea | 6 ea

VENT DIE G

This special die quickly sets #GROMI9021 Ventilators. Merely punch your hole, set the ventilator with the neck up on the base, and then slip the fabric in place. A few even taps with a mallet will set the vent. H

This tool is to be used as you would any punch. A mallet is recommended for striking the punch and a soft surface under the material will prevent the hardened steel cutter from damage and premature dulling. #TOOGR6120 Hole Cutting Pad is strongly recommended and will maximize the life of the punch. TOOGR50820

Grommet Fabric Hole Cutter Hole Size: 1⁹⁄₁₆” Price Break: Each | 3 ea | 6 ea

CRUISER, DOT®, SIMPSON &OSBORNE GROMMET HOLE CUTTERS B B B B

TOOOS5059

#00-A 3/16”

TOOOS5024

#0-A ¼”

TOOOS5031

#1-A 9/32”

TOOOS5032

#2-A ⅜”

B B B

#621 Vent Die Price Break: Each | 3 ea | 6 ea

GROMMET FABRIC HOLE CUTTER

TOOGR9022

TOOOS5033

#3-A 7/16”

TOOOS5037

#4-A ½”

TOOOS5038

#5-A ⅝”

Price Break: Each | 3 ea | 6 ea

CRUISER SPUR GROMMET HAND-SETTING DIE

Hand-setting tools for the Cruiser brand plain grommets (p.67). Each set consists of the punch and the die. Spur and Plain dies are not interchangeable.

E E E

TOOCR6145

#1 Plain Grommet Hand-Setting Die

TOOCR6147

#2 Plain Grommet Hand-Setting Die

TOOCR6149

#3 Plain Grommet Hand-Setting Die

F F F

TOOCR6155

#1 Spur Grommet Hand-Setting Die

TOOCR6157

#2 Spur Grommet Hand-Setting Die

TOOCR6159

#3 Spur Grommet Hand-Setting Die Price Break: Each | 3 ea | 6 ea

OSBORNE GROMMET HAND SETTING DIE— PLAIN & SPUR G G G G

TOOOS5020

#00 Plain Die

TOOOS5034

#0 Plain Die

TOOOS5021

#1 Plain Die

TOOOS5022

#2 Plain Die

H H H

TOOOS5019

#0 Spur Die

TOOOS5055

#1 Spur Die

TOOOS5028

#2 Spur Die

G G G

TOOOS5023

#3 Plain Die

TOOOS5025

#4 Plain Die

TOOOS5026

#5 Plain Die

H H

TOOOS5027

#3 Spur Die

TOOOS5029

#4 Spur Die

Price Break: Each | 3 ea | 6 ea

PM1 DURA SNAP MACHINE

For high production with less fatigue, we offer the PM1 Dura Snap bench mounted press. Sturdy unit sets snaps quickly and easily with a single stroke. Includes a complete set of dies for Dot ® Durable and Dura Snap fasteners (p.36). Replacement dies available (#TOOFA4026 or #TOOFA4036). This machine must be bolted to the workbench. It is not portable and has a tendency to crack if not solidly mounted.

TOOFA4030

PM1 Dura Snap Machine Price Break: Each | 3 ea | 6 ea

Please see p.81 for Cruiser & Osborne Grommets marine - awning - upholstery supplies | 91

PM5 SNAP/GROMMET MACHINE & DIES A

TOOSP5030

PM5 Bench Snap & Grommet Machine

This sturdy machine will set self-piercing grommets and will also accommodate snap fasteners with a separate set of dies. It has a deeper throat and longer padded handle. Approximate height once bolted to the workbench is 12”. Dies sold separate. This machine must be bolted to the bench, it is not portable. If you require a portable machine, use #TOOSP5057.

Price Break: Each | 3 ea | 6 ea

TOOSP5057

Portable Aluminum PM5 Machine A lightweight aluminum version of the PM5 machine listed above. Will work with all the same dies for snaps or our full line of self-piercing grommets. Suitable for portable use when mounted on a small plywood platform for stability. Dies sold separately. Price Break: Each | 3 ea | 6 ea

B B B B B

TOOSP5052

¼” Self-Piercing Grommet Die for PM5 Machine

TOOSP5054

5/16” Self-Piercing Grommet Die for PM5 Machine

TOOSP5056

⅜” Self-Piercing Grommet Die for PM5 Machine

TOOSP5058

½” Self-Piercing Grommet Die for PM5 Machine

TOOSP5060

9/16” Self-Piercing Grommet Die for PM5 Machine

PM1/PM5 SNAP DIE SETS C D

TOOFA4026

Dura Snap Die Set—PM1/PM5 Machine

TOOFA4036

Baby Snap Die Set—PM1 Machine Price Break: Each | 3 ea | 6 ea

Price Break: Each | 3 ea | 6 ea

KNIVES

COMBINATION KNIFE

This combination knife is made from the fi nest steel with both hook and pointed blade. It can be used for ripping seams, cutting auto carpeting, vinyl, plastic and rubber. Features a contoured Beechwood handle.

TOOKN8440

#1020 Combination Knife Price Break: Each | 3 ea | 6 ea

HEAVY DUTY OLFA KNIFE

A heavy-duty knife with a ratchet-lock mechanism for unlimited blade positions. The knife has a double-honed blade for superior sharpness and edge retention.

TOOKN8052

Heavy Duty Olfa Knife Price Break: Each | 3 ea | 6 ea

TOOKN8058

Heavy Duty 0.5mm Olfa Blades—Package of 50 blades Price Breaks: Each | 5 ea | 10 ea

OLFA REPLACEMENT BLADES H

TOOKN8038

Ultra Max Heavy Duty Olfa Blades—Pack-

age of 50 blades Price Break: Each | 5 ea | 10 ea

#14 MOUNT TRIMMING KNIFE

This is a tough, straight edged blade that is sharp enough to cut vinyls, carpet or other materials, and can be re-sharpened to last many years of service.

TOOKN8051

#14 Mount Trimming Knife Price Breaks: Each | 3 ea | 6 ea

92 | marine - awning - upholstery supplies

CUTTERS & DIE SETS: BUTTON

All the cutters and dies listed here are for the #1 Jr. Button Machine only (#BUTMI2121). Any other cutters or dies are special order items requiring approximately 3 weeks delivery. Cutters and dies are stocked for all common button sizes. The button machine and dies work best when the covers for the button mold are the correct size and shape and to ensure this we offer the cutters below.

JR. BUTTON MACHINE

Versatile bench mounted manual press type machine cuts, covers and makes firm solid buttons. It is designed to work with 2 piece dies and the short cutter. It includes a wood block for use in cutting covers and is capable of approximately 90 buttons per hour.

BUTMI2121

#1 Junior Button Machine Height: 22” Shipping weight: 13lb (5.89kg) Price Breaks: Each | 3 ea | 5 ea

CUTTERS & DIE SETS—MEDIUM FABRIC

This medium die is recommended for the majority of fabrics. One set is required for each size of button.

B C D E

BUTDI2141

#22 Cutter and Die Set—Medium

BUTD2143

#30 Cutter and Die Set—Medium

BUTD2145

#36 Cutter and Die Set—Medium

BUTD2147

#45 Cutter and Die Set—Medium

Price Breaks: Each | 3 ea | 5 ea A

CUTTERS & DIE SETS—HEAVY FABRIC

The wider throat makes this set ideal for heavier fabrics and vinyls. It adapts for material thickness for quick and proper assembly of the button.

F G

BUTD2133

#22 Cutter and Die Set—Heavy

BUTD2135

#30 Cutter and Die Set—Heavy Price Breaks: Each | 3ea | 5 ea

CUTTERS ONLY

The cutters do wear with time and the best way to ensure clean round covers for use in the button machine is to keep the cutter current. Make sure that there is always a soft wooden block or Hole Cutting Pad (#TOOGR6120, p.91) used to extend cutter life.

H I J

BUTCU2151

#22 Cutter

BUTCU2153

#30 Cutter

BUTCU2155

#36 Cutter Price Breaks: Each | 3ea | 5 ea

F G

H I

marine - awning - upholstery supplies | 93

SHEARS: KAI

KAI SCISSORS

Blades made of high-carbon Molybdenum Vanadium stainless steel for extra-long edge life and high cutting effi ciency. Ergonomically styled and padded grip made of Elastomer soft plastic for maximum ease of handling. Right hand use only.

A B C D E

SHEST7035

10” KAI Micro-Serrate Edge Shear

SHEST7034

8” KAI Regular Edge Shear

SHEST7036

10” KAI Regular Edge Shear

SHEST7037

12” KAI Regular Edge Shear

SHEST7038

6” KAI Regular Edge Shear NEW!

Price Break: Each | 6 ea | 12 ea E

SHEARS: MUNDIAL Mundial is a world renowned quality shear, manufactured to the highest standards using only the best materials and processes. Adjust the ride once with a screw driver and you are done. The Stay-Set™ is uniquely engineered to stay true to its name. Once set, it stays set for comfortable cutting power under the most demanding commercial conditions. Hot drop-forged and fully nickel-plated with black enamel handles.

STRAIGHT MUNDIAL SHEARS

These high quality shears have a solid feel, a sturdy blade and come in a variety of sizes. All shears are designed for the right hand except the 9” Cushion Soft. The Cushion Soft shear has enlarged fi nger bows and a padded soft touch lining, designed for both the right and left hand use.

F G -

SHEST7002

8” Mundial Shear

SHEST7001

9” Cushion Soft Shear

SHEST7004

10” Mundial Shear

SHEST7007

12” Mundial Shear

SHEST7003

9” Mundial Shear

Price Breaks: Each | 6 ea | 12 ea

HEAVY DUTY MUNDIAL SHEARS

Thicker, heavy duty blades cut through multiple layers and tough materials. Extra weight gives extra control and smoothness when cutting. Right hand use only.

H -

SHEST7013

10” Mundial Heavy Duty Shear

SHEST7014

12” Mundial Heavy Duty Shear

Price Breaks: Each | 6 ea | 12 ea

MUNDIAL QUICK CLIP CUTTER

Ideal for snipping threads. This tool is small, easy-to-use in a natural motion in corners of covers and other hard-to-reach areas.

SHEQI7023

Mundial Quick Clip Cutter Price Breaks: Each | 6 ea | 12 ea I

94 | marine - awning - upholstery supplies

SHEARS: WISS® Wiss ® Shears are made of the finest quality cutlery steel with drop-forged polished blades with a patented Set-Easy pivot. The superior combination of hardened, ground, edged and adjustable blades combine to provide outstanding cutting ability and durability.

WISS® APPAREL SHEARS

Bent apparel sheers with “inlaid” blades and black handles for professional dress maker and industrial use.

SHEST7020

9” Wiss® Apparel shears Price Breaks: Each | 6 ea | 12 ea

WISS® BENT TRIMMER SHEARS

Industrial sheers with “inlaid” blades and black handles. The 10” comes in both a right and left handed design.

B C D

SHEST7025

10” #20 Wiss® Bent Trimmer

SHEST7027

10” #20 Wiss® Bent Trimmer—Left-Hand

SHEST7026

12” #22N Wiss® Bent Trimmer Price Breaks: Each | 6 ea | 12 ea

WISS® HEAVY DUTY BENT TRIMMER SHEARS

Heavy duty bent shears with “inlaid” blades and black handles. Thicker, heavy duty blades cut through multiple layers and tough materials. Extra weight gives extra control and smoothness when cutting. Right hand use.

E E

SHEST7030

10” Wiss® Heavy Duty Bent Trimmer

SHEST7031

12” Wiss® Heavy Duty Bent Trimmer Price Breaks: Each | 6 ea | 12 ea

WISS® QUICK CLIP CUTTER WISS® X-SHARP KNIFE BENT TRIMMER

All the quality of Wiss® in a shear with a feature Knife Edge ground blade for faster, cleaner easier cutting of synthetic fibers. Fine cutlery grade steel, with Hot Drop-Forged polished blades and the patented Set-Easy pivot.

H I

SHEST7032

10” Wiss® X-Sharp Knife Bent Trimmer

SHEST7033

12” Wiss® X-Sharp Knife Bent Trimmer

Heavy duty contour design with positive spring action re-opens blades for fast cutting. PVC plastic handle with stainless steel sharp point blades. Replacement blades are available in a set with 4 blade screws.

SHEQI7021

Wiss® Quick Clip Sharp Point Cutter Price Breaks: Each | 5 ea | 10 ea

SHEQI7022

Wiss® Quick Clip Replacement Blades Price Breaks: Each | 6 ea | 12 ea

Price Breaks: Each | 6 ea | 12 ea

marine - awning - upholstery supplies | 95

CUTTERS: HOT KNIFE

HEAVY DUTY HOT KNIFE

Hot knife cutter for use on vinyls, plastic, tarp materials, etc. Can also be used for cutting and sealing webbings. Runs on normal house AC current (60W). This unit heats up to 565°C (1050°F). It is hot enough for heavy-duty work. Use the Dial-Temp Controller (#TOOCU2817) to lower the temperature of the knife for applications that require a lower heat setting.

A B C

B C

TOOCU2810

Heavy Duty Hot Knife

TOOCU2815

Hot Knife Tip

TOOCU2817

Dial Temperature Controller Price Break: Price Breaks: Each | 3 ea | 6 ea

HSGO HOT KNIFE

The small point Type HSGO is primarily used in separating thin materials and for cutting round or irregular shapes. The blade takes 6–8 seconds to heat up. The heat can be controlled using the on/off switch. This small, convenient cutter is suited for pattern-making, cutting out awnings, filter cloths, sail materials and other fabrics, as well as cutting synthetic cords and ropes.

TOOCU2830

HSGO Hot Knife—Body Only Weight: 2.2 lb (1 kg)

Price Break: Each | 3 ea | 6 ea

TOOCU2835

Standard Cutting Blade for HSGO Knife Use on a heat-proof surface. Price Break: Each | 3 ea | 6 ea

TOOCU2837

RS Curved Cutting Blade for HSGO Knife Used for cutting and sealing synthetic materials. Use on heat-proof surface.

HSGO HOT KNIFE: CAUTIONS HSGO is designed for intermittent use and should not be used for periods longer than 20 minutes without a pause for cooling. 70W capacity heater runs on standard household current.

Price Break: Each | 3 ea | 6 ea

TOOCU2839

SF Cutting Foot for RS Curved Cutting Blade Use with the RS cutting blade to allow cutting and sealing without a cutting base. Price Break: Each | 3 ea | 6 ea

HOT CUTTERS H

J K L I

COMPACT HOT CUTTER

Compact portable hot cutter heats quickly for use in cutting and sealing edges on any synthetic webbing or cord. Perfect for drawstrings, laces, tapes, cords and ropes. Actual size is H3” x L5”. This versatile unit will add a professional edge to all the cut webbings and synthetic ropes you use. Replacement blades are available.

H I

TOOCU9876

Compact Hot Cutter

TOOCU9816

Replacement Blade for Compact Hot Cutter Price Break: Each | 3 ea | 6 ea

PRODUCTION HOT CUTTER

This unit was designed for custom hand-cutting or high-speed production use. Lever-type action is fast, and neatly cuts and seals all synthetic materials such as webbings, cords, etc. No further processing needed. It can be used to trim narrow fabric strips. It has a 3½” maximum cut width and is variable heat controlled. The standard model runs on normal 110 household current, but 220V models are available on special order. The blade can be replaced separately.

J K L

TOOCU9877

Production Hot Cutter

TOOCU9814

Replacement Element for Production Hot Cutter

TOOCU9813

4” Replacement Blade for Production Hot Cutter Price Break: Each | 3 ea | 6 ea

96 | marine - awning - upholstery supplies

CUTTERS: WIRE 337 WIRE CUTTERS

A versatile tool with a non-slip handle and a hardened cutting surface. The fastest way to get rid of the original hog rings. This tool will cut through hog rings easily and is useful for all lighter gauges of wire.

TOOCU8014

337 Wire Cutters Price Breaks: Each | 3 ea | 6 ea

CUTTERS: ROUND KNIFE 1⅞” AS100 KNIFE CUTTER

MISTEE 3½” ROUND KNIFE CUTTER

A powerful, light weight hand cutter, this small cutter has more power than most cutters its size, allowing you to cut heavier materials with ease. Uses a hexagonal blade (#TOOCU3171) that rotates with a scissor action that prevents fabric from slipping. Also ensures continuous sharpness and clean cuts on fabrics. Watt capacity: 55W

B C

This lightweight 4 lb (1.8 kg) cutter has a strong motor that pulls 80W capacity. It cuts all types of fabrics single or in multiple plies. Built-in sharpener and finger guard keep this machine efficient and safe. It has smooth rollers on the base for effortless gliding while cutting. It will cut up to ¾” of fabric at one time. Perfect for the smaller shop doing repetitive contract work. Replacement blades available.

Cutting capacity: ⁵⁄₁₆”

TOOCU3170

1⅞” AS100 Knife Cutter

TOOCU3171

Hex Blade for AS100 Knife Cutter

Watt capacity: 80W

D E F

Price Break: Each | 3 ea | 6 ea

Cutting capacity: ¾”

TOOCU3162

Mistee 3½” Round Knife Cutter

TOOCU3163

Replacement Blade for Mistee 3½”

TOOCU3168

Worm Gear for Mistee 3½” Cutter Price Break: Each | 3 ea | 6 ea

D C

CUTTERS: FOAM ACU-CUTTER QUEEN*

Ideal foam cutter for the smaller shop, affordable and efficient. Cuts with two blades: one oscillating and one stationary. It has a 8½” stanchion as standard. Blade and glide included. The heavy duty free standing base is 4” wide and 6¾” long and mounted on glide bearings to reduce drag.

G H

TOOCU4338

8½” Acu-Cutter Queen

TOOCU4336

9” Replacement Blade

G H

Price Breaks: Each | 3 ea | 6 ea

*N ot intended for a production line where foam cutting is the only job.

U-CUT FOAM CUTTER

Fast and flexible, this versatile large sheet foam cutter will cut as fine as ¼” to a max. Thickness of 9” and up to a width of 36” with unlimited length.

I J

TOOCU4341

410 U-Cut Foam Cutter

TOOCU4342

410 U-Cut Replacement Blade

Price Breaks: Each | 3 ea | 6 ea marine - awning - upholstery supplies | 97

STAPLES & TACKERS 1400 SERIES STAPLES

1400 Series Staples fit standard tackers, Fasco 1400 series, Haubold Staplers and JEFast 1416. Made from galvanized steel to help prevent rusting.

STA147254

1400/6—¼”

STA147255

1400/8—5/16”

STA147256

1400/10—⅜”

STA147257

1400/12—½”

STA147258

1400/14—9/16”

B C D E

71 STAINLESS STEEL STAPLES

Staple Width: ⅜” Price Breaks: Box (10,000) | Box (20 Boxes) |

71 Series Staples fits standard tackers, Fasco 71 series, Senco Stapler.

Case (40 Boxes)

STAST7261

71 SERIES STAPLES

Staple Width: ⅜”

71 Series Staples fit standard tackers, Fasco 71 series Senco Staplers and JEFast 7116. To help prevent rusting, the staples are made from galvanized steel.

B -

STA147278

71/6—¼”

STA147279

71/8—5/16”

STA147280

71/10—⅜”

STA147282

71/12 —½”

Price Breaks: Box (10,000) | Box (20 Boxes) | Case (40 Boxes)

DUO-FAST STAPLES - HE 5018 SERIES

Fit the HE 5018 series standard electric tacker. To help prevent rusting these Duo-Fast Staples are made from galvanized steel.

Staple Width: ⅜”

STADU7244

Case (40 Boxes)

1400 STAINLESS STEEL STAPLES

Stainless steel staples for the air tackers are carried in one size only. Other sizes are available through special order based on quantity. More expensive than standard staples, but stronger and more rust resistant. Compatible with Fasco 1400 Series, Haubold Stapler and JEFast (#TOOTA1416). STAST7260

5012 ⅜” Staples Staple Width: ½”XF Price Breaks: Box (10,000) | Box (20 Boxes) |

Price Breaks: Box (10,000) | Box (20 Boxes) |

71/10—⅜” Stainless Steel Staples

1400/10—⅜” Stainless Steel Staples

DUO-FAST STAPLES - EIC 3118 SERIES

These staples fit the standard EIC 3118 Duo-Fast electric tacker. Made from galvanized steel to help prevent rusting.

E -

STADU7237

3112 ⅜” Staples

STADU7239

3116 ½” Staples Staple Width: ⅜”

Staple Width: ⅜”

Price Breaks: Box (10,000) | Box (20 Boxes) |

Price Breaks: Box (10,000) | Box (20 Boxes) | Case (40 Boxes)

Case (40 Boxes)

FASCO TACKERS

High quality pneumatic tacker has the advantage of having very few moving parts and those that do are easily replaceable. Piston/driver assembly available. F

F G H

TOOTA7211

Fasco 1400 Series Tacker

TOOTA7210

Fasco 71 Series Tacker

TOOTA7214

Piston/Driver Assembly Head Width: ⅜” Price Break: Each | 3 ea | 6 ea

JEFAST AIR TACKERS

These air tacker alternatives provide a lighter duty and more economical choice.

I J

TOOTA7216

JEFast 1416 Air Tacker

TOOTA7217

JEFast 7116 Air Tacker Price Break: Each | 3 ea | 6 ea

I J

98 | marine - awning - upholstery supplies

FASCO TACKER REPLACEMENT PARTS

These replacement parts are for both JEFast 1416 and JEFast 7116. Piston/Driver Assemblies differ.

A B

TOOTA7225

Piston/Driver Assembly—For #7216

TOOTA7230

Piston/Driver Assembly—For #7217

Price Breaks: Each | 3 ea | 6 ea

STAPLE REMOVERS STAPLE REMOVERS

These staple removers each have a distinct look and feel, they provide slightly different functions. The Berry-style staple remover has 2 grooves, one in each prong, enabling you to grab staples or just lift the corner edges of the tacks, #402 ½” Staple Remover can get under the most stubborn staple with its chiseled blade. #121 Comb Type Staple Remover is a versatile tool, the comb edge allows for removal of multiple staples.

C D E

TOOTA8041

#124 Berry-Style Staple Remover

TOOTA8046

#402 ½” Staple Remover

TOOTA8047

#121 Comb Type Staple Remover Price Break: Each | 3 ea | 6 ea

STAPLE LIFTER & CHISEL

You can use the #402 Ripping Chisel for the toughest staples and tacks. It can also be used to remove unwanted wood sections or to split wood joints. The #120 ½” Staple Lifter has the correct angle for removing staples if damaging the wood would be a problem.

F G

TOOTA8034

#402 Ripping Chisel

TOOTA8048

#120 ½” Staple Lifter Price Break: Each | 3 ea | 6 ea

PNEUMATIC RIPPING TOOL

A Pneumatic tool that takes the strain out of removing tacks, staples and other fasteners from furniture frames. This air tool can be adjusted by regulating the air pressure to compensate for hard or soft woods. Also effective in lifting shredded fabric that has “glued” itself to the frame over time. Comes with all attachments.

H I J

TOOTA8045

Pneumatic Ripping Tool

TOOTA8042

Replacement Staple Remover Attachment

TOOTA8049

Replacement Puller Attachment Price Break: Each | 3 ea | 6 ea

marine - awning - upholstery supplies | 99

TACKERS AND GLUE GUN INDUSTRIAL HOT MELT GLUE GUN

This unit is slim, efficient, and economically priced and will deliver up to 2.2 lb/hr of glue in continuous use. Operating temperature is 205°C (400°F). Our 10” Glue Sticks (#1153) will work with any glue gun that accepts ½” round glue sticks. Approximately 20 sticks/lb. A

TOOMI1151

ADHMI1153

Pro 90 Glue Gun Price Breaks: Each | Box (6 ea) | Case (12 ea) 10” Glue Sticks Price Breaks: Per lb | Box (5 ea) | Case (22 ea)

HOT GLUE GUN TIPS Hot gluing large areas at a time can cause some of the glue to set before bonding. To get a longer tack time for your adhesive, it is sometimes possible to pre-heat the surface with a heat gun before applying the glue. Of course, good judgment must be used to ensure the preheating does not damage to materials.

Because of the high speed of bonding that hot glue sticks have, it is often practical to use a hot melt glue gun to position pieces for more secure bonding with nails, screws or bolts.

BENDING TOOLS Bend tubing without marring or kinking using the Bendarc ® Tool. Mounts solidly to a workbench or wall and is constructed of steel boiler plate and the toughest polymers available. It comes with a graduated scale generated by a computer that eliminates the guesswork and results in no wasted materials. Merely mark your bends, insert and clamp the piece into the Bendarc ® for precise control. This machine is strong enough to bend either aluminum or stainless steel tubing.

BENDARC® B B B B

TOOTU8378

6” Radius for ⅞” Round Tube

TOOTU8388

8” Radius for ⅞” Round Tube

TOOTU8382

8” Radius for 1” Round Tube

TOOTU8392

10” Radius for 1” Round Tube Price Break: Each | 3 ea | 6 ea

CROWNARC®

The CrownArc ® Device gives beautiful smooth consistent crowns, with no sharp edges or awkward kinks, to round stainless steel or aluminum tubing in sizes from ¾” up to 1”. The 1” rollers work properly with smaller sizes as well. Both the lower rollers on the CrownArc ® Turn providing better control over the feed and curve imparted. It also allows a bigger bite to give more crown per pass.

TOOTU8380

CrownArc® Price Break: Each | 3 ea | 6 ea

HOW TO USE THE CROWNARC® Insert the bow and tighten the knurled knob about ¾ of a turn, then crank it through. If a bigger arc is needed, tighten the knob more and crank the bow through again. 100 | marine - awning - upholstery supplies

DRILLING TOOLS

Please see p.8-11 for Automotive Vinyls, and p.126-128 for Automotive Trim.

DRILL STEADY

Small clamp-on drill guide used for drilling stainless tubing and pipe. Swing-off design allows tool to be used without disassembly of the frame. Cast bronze body with knurled bronze thumbscrews and tool steel drill brushing. Accepts tubing from ¾”–1¼”. Standard drill size is ⁹⁄₆₄”.

TOOTU11072

Drill Steady Price Break: Each | 3 ea | 6 ea

TRIMMING TOOLS TUCKING TOOL

A sturdy tool with a slightly curved blade and rounded corners for tucking headlining and upholstery around windows, doors and other interior automotive trim. Comfortable wooden handle with eyelet gives you excellent leverage.

TOOAU8420

#746 Flexible Tucking Tool Price Breaks: Each | 3 ea | 6 ea

TRIM PAD TOOL

A tool designed to remove trim pad plastic and metal fasteners without damage to the car finish. This tool reaches under the trim pad backing. It is long enough to reach the most recessed fastener and pries only against hidden surfaces to eliminate the danger of scratching the paint. Carefully beveled and deburred and it is manufactured from high-carbon steel. While specially designed to allow the re-use of plastic fasteners on GM cars, it works well with all metal fasteners.

TOOAU8450

Trim Pad Tool Price Break: Each | 3 ea | 6 ea

HOT AIR HEAT GUN

E C

NOTES ON REPLACEMENT ELEMENT #TOOGU5154 There have been slight model changes to the hot air heat gun over the years. Please quote your model number when ordering a replacement element to ensure that you receive the correct one.

Hot air guns makes it easy to work with vinyls and to create complex shapes often found in automotive trimming. For softening vinyls to impart stretch, softening floor tiles, carpet backing, etc. Weighs only 2.75 lb (1.2 kg), including stand, and generates temperatures between 232–345°C (450–650°F). Draws 12.5 amps of regular household 110V current. Adjustable air intake regulators provides variable temperatures. Double-jacketed nozzle and shield keeps external temperatures down. Unique suspended quick-change heating element for easy replacement, and replaceable brushes to extend the life of the unit. Housing, stand and handle are G.E. Lexan ® for superior electrical insulation and impact resistance. Toggle style switch has three settings—hot, cold and off, allowing the unit to be used as blower and heater. Nozzle air opening: 1³⁄₁₆” diameter.

D E

TOOGU5151

Hot Air Heat Gun

TOOGU5154

Replacement Element for Hot Air Heat Gun Price Break: Each | 3 ea | 6 ea

marine - awning - upholstery supplies | 101

PVC WELDER TOOLS

EAGLE HOT AIR WELDER

Hand-held hot air welder. Lap welds soft thermoplastics without any additional materials other than the use of a silicone roller to provide the necessary pressure. Particularly suited to welding of tarpaulins and single-ply roofing material. Air temperature is adjustable from ambient up to 625°C (1157°F). Element is a quick-change type with no tools required. Runs on a standard house current, although a 220V model is available on special order. Heating element will also fit the Leister brand and is a simple pull-out, plug-in operation. Features a recessed temperature control knob, a booted power switch and screened air inlet to protect against damage. Air flow is adjustable up to 15 CFM. Built-in over-temperature protection, protects the heating elements and electronics.

A D

A B

TOOWE2840

Eagle Hot Air Welder

TOOWE2841

Replacement Element for Eagle Welder Price Break: Each | 3 ea | 6 ea

SILICONE ROLLER FOR TARP WELDER

Tough silicone roller mounted on a sturdy handle for pressure-rolling tarps while being heat-welded. Also very useful for flattening out any surface for being glued or fit to complex shapes, such as carpeting to automotive floors or vinyl onto complex shapes. It is also used for working with heat, such as hot air guns or lamps to soften the vinyl. Silicone roller does not absorb glues or materials and can be easily cleaned after use.

TOOWE2845

Silicone Roller for Tarp Welder Price Break: Each | 3 ea | 6 ea

ANGLE SLIT NOZZLE

This product is ideal for welding seams or applying heat into corners. For use with Steinel gun only.

TOOWE2846

2” Angle Slit Nozzle Price Break: Each | 3 ea | 6 ea

Please see p.36-37 for our PVC options.

BINDING: FOLDER E

Stitch bindings into place faster and straighter with these adapters. Simply screw the binding folder into place on your sewing machine, then guide the material and binding through the machine. Makes a difficult job easier and faster. Gives uniform, factory-quality seams for that professional fitted appearance.

FOLDER FOR BINDING E F

TOOFO4890

Folder for ¾” Binding

TOOFO4892

Folder for ⅞” Binding

G H

TOOFO4897

Folder for 1” Binding

TOOFO4895

Folder for 1¼” Binding

Price Break: Each | 3 ea | 6 ea

Please see p.113-117 for binding options. 102 | marine - awning - upholstery supplies

SPRAY GUN

E F

G H

118 SPRAY GUN

The 118 Spray Gun is a blow-over siphon type and produces a coneshaped spray. Adjustment of volume is made by screwing the fluid nozzle up into the air stream until the right flow is obtained. This product is particularly recommended for glues and other sticky liquids that tend to gum up painting equipment. Also usable for touch-up work and ideal for production painting of small articles. Light-weight and easy to use.

TOOMI1158

118 Spray Gun

TOOMI1159

118 Spray Gun - Jar Only

Weight: 2 lb (0.9 kg) Price Break: Each | 3 ea | 6 ea

EZE SPRAY GUN

A lightweight, durable alternative to the more expensive sprayers. Tube height is adjustable by loosening the adjustment nut and then sliding tube to achieve desired spray density. To clean, loosen the adjustment nut and slide the vacuum tube out. Dip tube in solvent to blow out with spray gun. Features a plastic glue pot.

TOOMI1165

118 SPRAY GUN REPLACEMENT PARTS B D E F G H I J G–K

TOOMI1159

Jar Only

TOOMI1162

Stainless Steel Tube

TOOMI1160

Aluminum Tube

TOOMI1170

Air Valve Spring

TOOMI1172

Air Nozzle

TOOMI1175

Locknut

TOOMI1174

Nozzle Spring

TOOMI1161

Fluid Nozzle

TOOMI1163

Stainless Steel Repair Kit Price Break: Each | 3 ea | 6 ea

EZE Spray Gun Price Break: Each | 3 ea | 6 ea

HAMMERS & MALLETS #6 RUBBER MALLET

Tough composite rubber head. 2” face diameter, 3¼” head length on a 12” white hickory handle and, weighs 11 oz. (312 g). Use it for setting decorative nails or dowels and other frame elements without damage. Will prolong the life of punches when used for driving them.

TOOMA5317

#6 Rubber Mallet

Price Breaks: Each | 3 ea | 6 ea

160 OR 33 MAGNET HAMMER

A specially-balanced tack hammer with solid head of bright bronze on a hickory handle. One end with a permanent magnet for picking up tacks, the other tipped with steel for driving the tacks home. The head is 5½” long, and the magnetic face is ¼”, while the steel-tipped end is ½” in diameter. The weight of the head is 7 oz. (198 g).

TOOHA5101

160 or 33 Magnet Hammer Price Breaks: Each | 3 ea | 6 ea

#4 HICKORY MALLET

A mallet formed from tough growth hickory.

TOOMA5313

#4 Hickory Mallet

JEWELED NAIL HAMMER

QUICK NAILER

This nylon tip decorative nail hammer is specifi cally made to prevent damage to nails during installation. The handles are designed for comfort and durability. Use with the Jewelled Nails on p.180.

TOOHA8210

Use the Quick Nailer to evenly space out your decorative nail projects. It’s quick and easy to use.

TOOMI5999

#777 Quick Nailer Price Break: Each | 3 ea | 6 ea

Jeweled Nail Hammer

Size: Head L6½” | Handle 11¹/₈” Weight: 13.6oz.

Price Break: Each | 3 ea | 6 ea

HOLE PUNCH TOOLS REVOLVING PUNCH

This product is a heavy duty punch with replaceable anvil and cutters. Strong metal construction. Useful for everything from punching holes for setting fasteners, to holes at the ends of cuts in vinyls to minimize chances of tearing (this process is recommended by Naugahyde® and is a good idea for any material that has a tendency to rip).

H I

TOOPU8017

#155 Revolving Hole Punch Price Break: Each | 3 ea | 6 ea

REVOLVING PUNCH REPLACEMENTS

Order only the cutters you need, or just the anvil if it wears out first. These cutters just thread into place on the punch. A pair of pliers is all that is needed for installation. The anvil must be tapped out and the stem of the new one tapped in with a hammer.

D E F G H I J

TOOPU8015

#1 Cutting Tube

TOOPU8016

#2 Cutting Tube

TOOPU8018

#3 Cutting Tube

TOOPU8019

#4 Cutting Tube

TOOPU8020

#5 Cutting Tube

TOOPU8012

#6 Cutting Tube

TOOPU8011

Anvil Price Break: Each | 3 ea | 6 ea

ZIPPER TOOL ZIPPER STOP PLIERS

Enables you to shorten zippers or make zippers of any length when working with continuous zipper tape. Helps to eliminate slippage and rotation of the zipper stops. Has a special groove that fi rmly holds the zipper stop in place. High quality forged steel with vinyl handle.

TOOZI11010

Zipper Stop Pliers Price Breaks: Each | 3 ea | 6 ea

Please see p.56-62 for Zippers. 104 | marine - awning - upholstery supplies

needles & thread

H I

PATTERN MAKING CARDBOARD

Sturdy cardboard sheeting in three thicknesses. This material can be used for making patterns or laminated together to make panels, stiffeners, etc. #3249 is often used as door panels in automotive and van customizing.

PATCA3219

28”x 40” 0.04gge—Standard Brown

PATCA3229

40”x 60” 0.057gge—Standard Brown

PATCA3249

37”x 60” 0.1gge (2 ply)—Matte Black

HEAD PINS

2½” long pins for holding covers in place for fitting. The bright heads make them easy to see and remove.

G H I

Easily sharpened markers for intricate design. Leaves a clean white mark. Designed to washout from most fabrics with water.

Dustless Sanigene blackboard chalk. PATCH3003

Sanigene® Chalk—Yellow

TAILOR'S CHALK

Tailor's style crayon chalk can be easily resharpened and is non-permanent on most surfaces. Unlike some inks, the wax base will not bleed through surfaces. The white chalk can be removed from dark surfaces with the quick touch of an iron or steamer. Tailor's Chalk—White

PATCH3007

Tailor's Chalk—Yellow

PATCH3008

Tailor's Chalk—Black

3” Steel Skewers

PATPI6251

Crystal Knobby Twist Pin

Price Break: Bag (500 pieces) | Box (5 Bags) | Case (10 bags)

Price Breaks: Box (144 pieces) | 12 boxes | 24 boxes

PATCH3005

PATPI6255

This curling pin with plastic “crystal” head is ideal for holding doilies and arm covers in place

D E F

3” 16gge steel skewers with a large eye end for gripping, threading and pinning covers while fitting.

TWIST PIN

SANIGENE CHALK

Sanigene® Chalk—White

Plastic Head Pin—Yellow

Price Breaks: Bag (36 pieces) | Box (4 Bags) | Case (8 Bags)

PATCH3001

Plastic Head Pin—Blue

PATPI6259

Case (10 bags)

Wash-Out Marker—White

Price Breaks: Box (12) | 6 boxes | 12 boxes

B C

PATPI6258

SKEWERS

WASH-OUT MARKER

PATPE3004

Plastic Head Pin—Red

Price Breaks: Bag (100 pieces) | Box (5 Bags) |

Price Breaks: Bag (5) | Box (5 Bags) | Case (10 Bags)

PATPI6257

RULERS

These aluminum rulers are light and versatile, they double as a measuring stick and a straight edge. The numbers are printed on, not stamped into the ruler, giving a smooth nonsnagging surface when used as a straightedge. Comes in two widths and are both 60” in length.

L M

PATRU6608

1½”x 60” Aluminum Ruler

PATRU6609

2”x 60” Aluminum Ruler

Price Break: Each | 6 ea | 12 ea

Price Breaks: Box (48 pieces) | 24 boxes | 48 boxes L

F K

marine - awning - upholstery supplies | 105

NEEDLES: TUFTING There are two basic classes of needles; the round point and the bayonet point. The bayonet (or cutting) point is recommended for heavier materials that are not prone to splitting, such as leathers and other heavy fabrics.

DOUBLE DOUBLE STRAIGHT STRAIGHT ROUND BAYONET

SINGLE

BAYONET

18”

ROUND

16”

12”

10”

8”

Double Straight Round Point

NEEST6236

NEEST6235

NEEST6234

NEEST6233

Double Straight Bayonet Point

NEEST6247

NEEST6246

NEEST6245

Single Straight Round Point

NEEST6228

NEEST6227

NEEST6226

NEEST6225

NEEST6223

Price Breaks: Each | 4 ea | 12 ea

TUFTING

Specially made clips are used with the Tufting Needle. They set into the needle near the point, and after inserting, the clip is ejected by the spring loaded handle and the button is set fi rmly in place. Needles and clips are sold separately.

A B

NEETU6261

Tufting Needle Price Break: Each | 4 ea | 12 ea

NEETU6262

Tufting Clips Price Breaks: Bag (100) | Box (5 Bags) | Case (10 Bags)

NEEDLES: HAND SEWING C

5”

4”

3”

Curved Round Point

NEECU6208

NEECU6207

NEECU6205

NEECU6204

Curved Bayonet Point

NEECU6218

NEECU6217

NEECU6215

NEECU6214

Price Breaks: Each | 4 ea | 12 ea

REGULATORS

Regulators are used for adjusting stuffi ng behind covers.

D E

6NEERE601

9” Plastic Handle Regulator

NEEREE6606

10” Steel Regulator Price Breaks: Each | 4 ea | 12 ea

NEEDLE KIT c

NEECU6201

F1 Assorted Needle Kit The F1 needle kit consists of 4 common sizes of curved round needle points. One each of the following: 6” 15gge 5” 16gge 4” 17gge 3” 18gge Price Breaks: Each | 4 ea | 12 ea

106 | marine - awning - upholstery supplies

2½”

THREADS: GORE TENARA® Remarkable thread manufactured from 100% expanded PTFE fi ber (commonly known as Tefl on ®). PTFE is one of the most chemically resistant substances known to man. This ensures it will not rot or develop mildew and prevents deterioration due to cleaning solutions, motor oils and other destructive substances. Gore Tenara ® threads are not affected by ultraviolet radiation and will not degrade from continuous sun exposure. Other threads lose up to 35% of their strength in a 3-year period. It is unaffected by saltwater, temperature extremes and acid rain. Colors will not fade. Ideal choice for outdoor fabric products such as awning and marine canvas. Pre-lubricated for a cooler running needle enabling sewing at higher speeds.

GORE TENARA® 1400 (92) THREADS A B C D

THRTE8418

Gore Tenara® Thread (92)—Clear

THRTE8417

Gore Tenara® Thread (92)—Black

THRTE8416

Gore Tenara® Thread (92)—White

THRTE8419

Gore Tenara® Thread (92)—Navy Blue NEW!

A B

Break Strength: 8 lb (3.6 kg) Price Break: Each (1,900 yd Spool) | 6 ea | 12 ea

GORE TENARA® 2500 (138) THREADS A B C

THRTE138418

Gore Tenara® Thread (138)—Clear

THRTE138417

Gore Tenara® Thread (138)—Black

THRTE138416

Gore Tenara® Thread (138)—White Break Strength: 14–19 lb (6.4–8.6 kg). Price Break: Each (1,150 yd Spool) | 6 ea | 12 ea

THREADS: POLYESTER

SUNGUARD B92 “G” BOBBINS

Prewound bobbins of Sunguard B92 UVR bonded polyester thread. Fits G-type bobbin holders as found on heavy-duty and industrial sewing machines.

E F

THRSU922011

Natural/White

THRSU922241

Black

G E

Bobbin Size: 25 yd Price Break: Box (144 bobbins) | 3 Boxes | 6 Boxes

SUNGUARD B92 “M” BOBBINS G H

THRSU922012

Natural/White

THRSU922242

Black

SUNGUARD B138 “G” BOBBINS K L

THRSU1382011

Natural/White

THRSU1382241

Black Bobbin Size: 17 yd Price Break: Box (144 bobbins) | 3 Boxes | 6 Boxes

Bobbin size: 36 yd Price Break: Box (144 bobbins) | 3 Boxes | 6 Boxes

SUNGUARD B138 “M” BOBBINS I J

THRSU1382012

Natural/White

THRSU1382242

Black Bobbin Size: 24 yd Price Breaks: Box (144 bobbins) | 3 Boxes | 6 Boxes

SUNGUARD UVR B92 1 LB

Sunguard B92 is a 4-ply twisted, high-quality UVR bonded polyester thread. Color-matched to the most popular shades of acrylic fabrics and OEM automotive vinyls. These are the closest color match to Sunbrella ® canvas colors. Sunguard is UV resistant, anti-wick, mildew resistant with colorfast dyes and a breaking strength of 14 lb (6.2 kg). Specifi cally designed for use in boat tops, automotive and awnings.

M N

THRSU9222416

Black

THRSU9222916

Beaver

O -

THRSU9220116

White

THRSU922916

Sand

Price Break: Spool (1 lb or ~4,600 yd) | Box (10 spools) Case (20 spools)

marine - awning - upholstery supplies | 107

SUNGUARD UVR B92 BONDED POLYESTER—½ LB

A Sunguard B92 4-ply, twisted high-quality B UVR bonded polyester thread in colors C matched to the most popular shades D of acrylic fabrics and OEM automotive vinyls. These are the closest color E match to Sunbrella ® canvas colors. F Sunguard is UV resistant, anti-wick, mildew resistant with colorfast dyes. G Break Strength: 14 lb (6.2 kg) H Price Break: Spool (½ lb or ~1,500 yd) | I Box (10 spools) | Case (20 spools) J K SUNGUARD UVR B92 BONDED L M POLYESTER—1 LB N Break Strength: 14 lb (6.2 kg) O Price Break: Spool (1 lb or ~4,600 yd) | Box (10 spools) | Case (20 spools) P Q R SUNGUARD UVR B138 BONDED S POLYESTER—½ LB T Sunguard B138 4-ply, twisted high-quality UVR bonded polyester thread in colors U matched to the most popular shades V of acrylic fabrics and OEM automotive W vinyls. These are the closest color match to Sunbrella ® canvas colors. UV X resistant, anti-wick and mildew resistant Y with colorfast dyes. Z Break Strength: 21 lb (9.5 kg) Price Breaks: Spool (½ lb or ~1,500 yd) | Box (10 spools) | Case (20 spools) A1 SUNGUARD UVR B138 BONDED POLYESTER—1 LB B1 Break Strength: 21 lb (9.5 kg) Price Breaks: Spool (1 lb or ~3,000 yd) | Box (10 spools) | Case (20 spools)

108 | marine - awning - upholstery supplies

B92 Bonded B138 Bonded B92 Bonded Polyester—½ lb Polyester—½ lb Polyester—1 lb

B138 Bonded Polyester—1 lb

Oyster

THRSU92202

Sand

THRSU92203

THRSU138203

THRSU922916

Beaver

THRSU92229

THRSU138229

THRSU9222916

Mocha

THRSU92230

Beige

THRSU92204

THRSU138204

Saddle

THRSU92231

THRSU138231

Taupe

THRSU92227

Bay Brown

THRSU92205

THRSU138205

Sunglow

THRSU92206

Cardinal

THRSU92207

THRSU138207

Burgundy

THRSU92208

THRSU138208

Black Cherry

THRSU92209

Sunflower

THRSU92212

Concord

THRSU92255

Blue Wave

THRSU92213

Pacific Blue

THRSU92214

THRSU138214

Mediterranean

THRSU92225

Adriatic Blue

THRSU92232

Dusk Blue

THRSU92215

THRSU138215

Navy

THRSU92216

THRSU138216

Dark Teal

THRSU92217

Ocean Green

THRSU92218

THRSU138218

Shamrock

THRSU92219

Forest Green

THRSU92220

THRSU138220

Charcoal

THRSU92223

THRSU138223

Shark Grey

THRSU92222

THRSU138222

Pearl Grey

THRSU92221

Black

THRSU92224

THRSU138224

THRSU9222416

Medium Titanium

THRSU92234

Medium Opal

THRSU92235

Graphite

THRSU92236

White

THRSU92201

THRSU138201

THRSU9220116

THRSU13820116

NEW! SUNSTOP UVR T90 BONDED POLYESTER — 1,350 YARDS

The T135 Sunstop thread is Twisted UVR Multifi lament Bonded Polyester. Price Break: Spool (~1,350 yd) | Box (10 spools) | Case (20 spools)

NEW! SUNSTOP UVR T135 BONDED POLYESTER — 2,100 YARDS

The T90 Sunstop thread is Twisted UVR Multifilament Bonded Polyester. Weight of spool is approximate 8 ounces. Price Break: Spool (~2,100 yd) | Box (10 spools) | Case (20 spools)

A B C D E F G H I J K L M N O P

T90 Bonded Polyester

T135 Bonded Polyester

White

THRSUS9066500

THRSUS13566500

Sol-Jet Black

THRSUS9066501

THRSUS13566501

Natural

THRSUS9066502

THRSUS13566502

Beige

THRSUS9066503

THRSUS13566503

Burgundy

THRSUS9066504

THRSUS13566504

Forest Green

THRSUS9066506

THRSUS13566506

Jockey Red

THRSUS9066507

THRSUS13566507

Navy

THRSUS9066508

THRSUS13566508

Silver

THRSUS9066509

THRSUS13566509

True Brown

THRSUS9066510

THRSUS13566510

Cadet Grey

THRSUS9066511

THRSUS13566511

Toast

THRSUS9066512

THRSUS13566512

Pacific Blue

THRSUS9066513

THRSUS13566513

Linen

THRSUS9066517

THRSUS13566517

Captain Navy

THRSUS9066518

THRSUS13566518

Logo Red

THRSUS9066519

THRSUS13566519

marine - awning - upholstery supplies | 109

THREADS: NYLON 69 NYLON

Known for its excellent sewability, high strength, resistance to abrasion and wear with its controlled stretch and recovery properties. It is unaffected by mildew and rot. Finished with a combination of waxes, silicones and oils specially designed to provide consistent machine tensions and loop formation. Protects from needle heat to ensure good sewability and prevents fusing of thread and fabric yarns. Our 69 Nylon thread is UV-treated and has a good resistance to strength loss, although prolonged exposure to sunlight could cause some deterioration.

American & Efird Canada, Inc.

Break Strength: 11.5 lb Price Breaks: Spool (1 lb, or ~6,000 yd) | Box (10 spools) | Case (40 spools)

THR69134129

Sta White

THR69136081

Fire Rd 2580

THR69135520

Navy #3

THR69130001

Natural

THR69135000

Scarlet

THR69167011

Midnight

THR69135553

Cream

THR69135048

Red

THR69134230

Salmon

THR69134099

Beige

THR69136241

Scarlet

THR69167069

Chinese Rust

THR69134215

Natural

THR69156037

OO Lala Pink

THR69134117

Rust

THR69135070

Ashes

THR69136343

Wine

THR69167061

Sienna

THR69167054

Ficelle

THR69136184

Burgundy

THR69134170

Maple

THR69167057

Beige

THR69136279

Purple 7007

THR69135538

Marron Glace

THR69167059

Deer

THR69135312

Purple

THR69134297

Sable

THR69135417

Platinum

THR69134444

Seafoam

THR69167067

Toast Brown

THR69167058

Pebble Beige

THR69136179

Dk Green

THR69135551

Chestnut

THR69136030

Beige

THR69134067

Green Olive

THR69135557

Brown

THR69136220

String 5005

THR69167021

Green Pepper

THR69134136

Wood

THR69167063

Marron Glace

THR69134811

Class Green

THR69135561

Brown

THR69167060

French Beige

THR69167025

Evergreen

THR69135472

Dk Mahogany

THR69134086

Sand

THR69167047

Mist

THR69167073

Dk Mahogany

THR69135103

Mastic Beige

THR69134144

Silver

THR69135100

Seal

THR69134664

Lt Beaver

THR69167048

Nickel

THR69167075

Walnut

THR69134609

Sand #2

THR69135670

Steel

THR69136048

Chocolate

THR69136188

Sand

THR69135631

Steel

THR69167071

Gold Brown

THR69134140

Shade 1600

THR69167050

Cub

THR69136135

Tonka Toast

THR69135477

Saba Sand

THR69163120

Foliage GN 504

THR69163114

Coyote

THR69163233

Tan 499

THR69136195

New GRY90782

THR69167074

Chestnut

THR69134257

Silver

THR69136139

Dark Silver

THR69167015

Coyote Tan

THR69135634

Beaver

THR69167053

Graphite

THR69135020

Chestnut

THR69167029

Forsythia

THR69156033

Black

THR69136111

Taupe

THR69167028

Lemon

THR69134974

DB Teal

THR69135495

ODS-1

THR69134913

Gold

THR69136911

Teal

THR69135500

Smoke

THR69135497

Gold

THR69134252

Copen

THR69135486

Rocky Brown

THR69135385

Beach Tan

THR69135210

Pro Blue

THR69136341

Neon Pink 102

THR69134370

Orange

THR69134466

Blue

THR69136999

FL Cerise

THR69134081

Orange

THR69134072

Blue

THR69136245

Neon ORG 105

THR69167034

Toboggan

THR69136099

Royal Blue

THR69136731

Neon Yellow

THR69167037

Pink #3

THR69167007

Yale Blue

THR69136289

Neon GRN 101

THR69134794

Bright Red

THR69135434

College Blue

THR69134050

Scarlet

THR69134177

Navy

THR69134212

Old Glory Red

THR69135516

Navy #1

110 | marine - awning - upholstery supplies

marine - awning - upholstery supplies | 111

CSB138 NYLON THREADS

100% continuous fi lament nylon with a bonded fi nish.

A B

THRNY8403

CSB138 Nylon—White

THRNY8404

CSB138 Nylon—Black

B C

Price Breaks: Spool (1 lb or ~3,000 yd) | Box (10 spools) | Case (20 spools)

NEW!

PERMA CORE

A high performance, stretch resistant thread. The poly wrapped core construction allows forsuperior sewability on maual and automatic sewing machines. It also has excellent frictional characteristics for a more consistent stitch appearance.

THRPC248439

Tex 24—White

THRPC248441

Tex 24—Antique Crea

THRPC408445

Tex 40—Black

THRPC408446

Tex 40—White

D-CORE

Cotton wrapped, poly-core sewing thread. A high performance, stretch resistant thread wiht excellent thread lubricant. The cotton wrapper provides great needle-heat resistance.

Price Breaks: Spool (1 lb or ~3,000 yd) | Box (10 spools) | Case (20 spools)

C -

PERMA SPUN NEW! -

THRPS278432

Perma Spun Tex 27 Black

THRPS278433

Perma Spun Tex 27 White

THRPS278434

Perma Spun Tex 27 Off White

THRPS278436

Perma Spun Tex 27 Tan

THRPS278437

Perma Spun Tex 27 Beige

THRPS458442

Perma Spun Tex 45 Black

THRPS458443

Perma Spun Tex 45 White

THRPS458444

Perma Spun Tex 45 Off White

Price Breaks: Spool (1 lb or ~3,000 yd) | Box (10 spools) | Case (20 spools)

THRDC248430

Tex 24—Natural

THRDC248431

Tex 24—Black

THRDC1208421

Tex 120—White

THRDC1208423

Tex 120—Natural

THRDC1208422

Tex 120—Black

THRDC1208427

Tex 120—Grey

THRDC1208425

Tex 120— Light Grey

THRDC1208426

Tex 120—Navy

THRDC1208428

Tex 120—Red

THRDC1208429

Tex 120—Light Brown

THRDC1208424

Tex 120—Olive Green

Price Breaks: Spool (1 lb or ~3,000 yd) | Box (10 spools) | Case (20 spools)

HAND-SEWING This is a 100% nylon hand-sewing thread. Hand stitching is often used to fi nish seams of blind stitch and places heavy demands on a thread. This thread has both the strength and abrasion resistance required for hand sewing. It is very heavy to allow strong pulls and can be used with confi dence. This thread will not break under the strain of hand stitching.

TEX210 HAND SEWING THREADS -

THRHA8504

TEX210 Hand Sewing Thread—Black

THRHA8505

TEX210 Hand Sewing Thread—White Break Strength: 35 lb. Price Breaks: Spool (546 yd) | Box (10 Spools) | Case (20 Spools)

THREADS: MONOFILAMENT

This transparent thread is made from a single extruded fi lament of nylon (fi shing line) to a specifi c diameter. Being transparent, there is no need to color match as the job changes.

At Ennis Fabrics, we carry this thread in two sizes. It is intended for high production use. It will not absorb lubrication, although, being nylon, it has a degree of self-lubrication. It is often run through a foam pad with silicone or some similar lubricant.

MONOFILAMENT THREAD E

THRMO8106

Monofilament Size 9 (#40) Break Strength: 5.7 lb

Diameter: 0.0009”

THRMO8107

Monofilament Size 10 (#52) Break Strength: 5.8 lb

Diameter: 0.001”

Price Breaks: Spool (12,635 yd) |

Price Breaks: Spool (10,252 yd) | Box (10

Box (10 Spools) | Case (50 Spools)

Spools) | Case (50 Spools)

112 | marine - awning - upholstery supplies

binding & cordage SUNBRELLA® BINDING SUNBRELLA® DOUBLE FOLD BIAS BINDING

100% solution-dyed acrylic bindings made with Sunbrella ® yarns in double-fold form. Both ¾” and 1” binding are available in a range of the most popular colors to coordinate and finish your Sunbrella ® creations. Binding is cut on the bias for easier tailoring around corners. Will not fade or weaken from normal exposure conditions including sunlight, mildew, rot and atmospheric chemicals. All the features of Sunbrella products apply directly to this binding. Please refer to p.160 for Sunbrella’s care and cleaning instructions. Roll Size: 100 yd

A B C D E F G H I J K L M N O P Q R S T U V W X Y Z A1 B1 C1 D1 E1 F1 G1 H1 I1 J1 K1 L1

Price Break: Spool | Box (5 spools) | Case (10 spools)

¾”

1”

BINSUTRI4779

Beige

BINSUNBB4742

BINSUNBB4749

Black

BINSUTRI4989

Brass

BINSUTR4743

BINSUNBP4757

Burgundy

BINSUTR4962

BINSUTRI4773

Cadet Grey

BINSUTRI4974

Capri

BINSUTR4738

BINSUNBB4754

Captain Navy

BINSUTRI4777

Charcoal Grey

BINSUTRI4778

Charcoal Tweed

BINSUTRI4998

Cocoa

BINSUTR4957

Dubonnet Tweed

BINSUTR4970

BINSUTRI4982

Fern

BINSUTR4961

BINSUNBB4755

Forest Green

BINSUTR4971

BINSUTRI4979

Heather Beige

BINSUTR4965

BINSUTRI4760

Hemlock

BINSUTR4966

BINSUTRI4775

Linen

BINSUTR4741

BINSUNBB4758

Linen Tweed

BINSUTRP4955

Logo Red

BINSUTR4976

BINSUTRI4999

Marine Blue

BINSUTRI4762

Mediterranean Blue

BINSUTR4959

BINSUTRI4981

Mediterranean Blue Tweed

BINSUTR4740

BINSUNBB4747

Natural

BINSUTR4751

BINSUNBB4748

Navy

BINSUTR4977

Ocean Blue

BINSUTRI4960

BINSUTRI4761

Oyster

BINSUTR4739

BINSUNBB4746

Pacific Blue

BINSUTR4958

BINSUTRI4985

Persian Green

BINSUTRA12012

BINSUTRP4953

Jockey Red

BINSUTR12013

BINSUTRI4771

Royal Blue

BINSUTR4956

Sapphire Blue

BINSUTR4968

BINSUTRI4774

Silver

BINSUTR4972

BINSUTRI4980

Spa

BINSUTR4954

Sunflower Yellow

BINSUTRI4767

Taupe

BINSUTR4963

BINSUTRI4765

Toast

BINSUTR4964

BINSUTRI12011

Toast Tweed

BINSUTRI12014

BINSUTRI4776

True Brown

BINSUTR4973

BINSUTRI4503

Wheat

marine - awning - upholstery supplies | 113

A B

The Industry Leader In Polyester Thread

NYLON TUFTING TWINE

Suitable for tying and tufting buttons. Excellent strength and resistant characteristics in a fi ner twine. Only available in White.

Added nanotechnology allows for 15% more strength compared to standard polyester threads

CORTW8125

#9 Nylon Tufting Twine (CSB346) Break Strength: 60 lb

UV and mildew resistant

Price Breaks: Spool (½ lb or ~600 yd) | Box (10 spools) | Case (20 spools)

Chlorine and bromine resistant Anti-wick finish

TWO SPOOL THREAD STAND

36 outstanding marine acrylic and automotive OEM vinyl color matches

This high quality dual spool thread stand is similar to many OEM designs. Mounts securely to the deck of the machine or table. The height is adjustable so that you can set it at a point where vibration from the machine does not cause thread to roll off the spool down to the base of the cone. Two eyes above the spools keep the thread feeding neatly off the cones as designed.

TOOMI11800

Two Spool Thread Stand Price Break: Each | 3 ea | 6 ea

SUNBRELLA® ⅞” CENTERFOLD BINDING

100% solution-dyed acrylic binding with a natural fold in the center tape to allow for a smooth and effi cient fit. The woven fold prevents the binding from necking down when under tension. The blind side behaves the same as the front. Can be used with or without guides. All exposure and mildew resistant features of Sunbrella ® products are built into this binding. Please refer to p.160 for Sunbrella ®’s care and cleaning instructions. Price Breaks: Spool (200 yd) | | Box (5 spools) | Case (10 spools) C

BINCE4936

Beige

BINCE4937

Burgundy

BINCE4935

Cadet Grey

BINCE4926

Captain Navy

BINCE4947

Concord

BINCE4932

Forest Green

BINCE4931

Jet Black

BINCE4930

Linen

BINCE4938

Mediterranean Blue

BINCE4939

Natural

BINCE4934

Navy

BINCE4978

Oyster

BINCE4927

Pacific Blue

BINCE4946

Red

BINCE4952

Taupe

BINCE4950

True Brown

BINCE4942

Turquoise

Sunbrella® is a registered trademark of Glen Raven, Inc. 114 | marine - awning - upholstery supplies

CENTERFOLD vs. ORDINARY BINDING 1

Centerfold binding has a natural fold woven into itself (Figure 1). Unlike ordinary binding, centerfold binding will not pull and pucker as displayed in Figure 2.

SUNBRELLA® BRAID SUNBRELLA® 13/16” EUROPEAN-STYLE ACRYLIC BRAID

Sunbrella ®’s European-style acrylic braid is constructed from 100% solution-dyed acrylic yarn. This ensures that all the features of Sunbrella products apply directly to this binding. It features excellent exposure resistance to sun and atmospheric conditions. This binding has a fi ne, soft hand and is available in a range of 33 colors. Please refer to p.205 for Sunbrella ®’s care and cleaning instructions. Price Break: Spool (100 yd) | Box (5 spools) | Case (10 spools)

A B C D E F G H I J K L M N O P Q

BRASU503038 BRASU503032 BRASU503020 BRASU503037 BRASU503046 BRASU503009 BRASU503090 BRASU503025 BRASU503036 BRASU503040 BRASU503097 BRASU503096 BRASU503027 BRASU503023 BRASU503021 BRASU503045 BRASU503041

Alpine Green Aqua Marine Beige Black Blended Brown Blended Gold Brass Burgundy Buttercup Captain Navy Charcoal Grey Concord Forest Green Green Grey Ivory Linen

R S T U V W X Y Z A1 B1 C1 D1 E1 F1 G1

BRASU503039 BRASU503094 BRASU503016 BRASU503029 BRASU503022 BRASU503024 BRASU503034 BRASU503030 BRASU503033 BRASU503035 BRASU503092 BRASU503028 BRASU503091 BRASU503093 BRASU503026 BRASU503042

Logo Red Mediterranean Blue Natural Navy Blue Pacific Blue Persian Green Plum Red Sapphire Sky Blue Taupe Terra Cotta Toast Turquoise Vanilla Yellow

Sunbrella® is a registered trademark of Glen Raven, Inc.

TOP GUN BINDING: DOUBLE FOLD

Double-folded binding made from Top Gun polyester fabric for fi nishing projects. This material is saturated with an acrylic coating which makes it the ultimate in marine cover fabrics. Long-lasting color, high strength and breathability. Other features of this product include stain, mildew, abrasion and ultraviolet resistance. The coating of Top Gun will not peel, chip, fl ake or crack even at temperatures as low as -18°C (0°F).

1” TOP GUN DOUBLE FOLD BINDING H1 I1 J1 K1

BINTGP4907

Burgundy

BINTG4901

Caribbean Blue

BINTG4903

Forest Green

BINTG4908

Hemp Beige

L1 M1 N1 O1

BINTG4904

Navy Blue

BINTG4905

Onyx Black

BINTG4902

Turquoise

BINTG4906

White

J1 K1

Price Breaks: Spool (100 yd) | Box (5 spools) | Case (10 spools) L1

TOP GUN CLEANING TIPS Top Gun Binding can be cleaned with a mixture of 4 oz. (118 ml) of Clorox ® And 2 oz. (59 ml) of soap in 1 gallon (3.8L) of water. If necessary, the cleaning can be followed with retreatment using Aqua-tite ® Protectant (#AERPR7166 and #AERPR7165, p.153) to ensure your product’s longevity.

M1 N1 O1

marine - awning - upholstery supplies | 115

STAMOID ® BINDING: TWO-FOLD STAMOID ® TWO-FOLD BIAS BINDING

A vinyl binding made from high-quality Stamoid ® products, featuring all the specifications familiar to the Stamoid ® brand. The two-fold binding has outstanding UV resistance, dirt repellency and mildew resistance. The bindings are ideal as trim or bind for cushions, canopies, dodgers and biminis. Colors are a perfect match with Stamoid ® fabrics. Available in ¾” or 1” widths.

A B

¾”

BINST10309

Snow White

BINST10310

White

BINST10314

Navy

A B

1”

BINST10312

Snow White

BINST10311

White

BINST10313

Navy

Price Breaks: Spool (100 yd) | Box (5 spools) | Case (10 spools)

AUTOMOTIVE/MARINE BINDING: TOPLINE Topline bindings are ideal for convertible tops, simcons, tonneau covers, door panels, spare tire covers, floor mats, seats, convertible boots, boat tops, marine accessories or any outdoor applications. C

Constructed of 7.6 gauge vinyl, coated on a ²⁄₂₅” drill with a 17 oz. (482 g) finished weight in a Crush (Sierra) or Pinpoint grain. Mildew treated for outdoor use. Tear strength, cold flexibility and bond specifications meet OEM standards. Available in one edge turned, or two edge turned styles in the colors and grains listed here.

1¼” TOPLINE ONE EDGE TURNED BINDING -

BINTO4770

GM White Pinpoint

BINTO4772

Black Pinpoint

BINTO4784

White Crush

BINTO4786

Black Crush

BINTO4788

Off White

¾” TOPLINE TWO EDGE TURNED BINDING C D

BINTO4766

Black Crush

BINTO4752

Black Pinpoint

Roll Size: 100 yd Price Breaks: Each | Case (5 ea)

Roll Size: 100 yd Price Breaks: Spool | Box (5 spools) | Case (10 spools)

116 | marine - awning - upholstery supplies

ONE EDGE VS. TWO EDGE TURNED BINDING 1

1¼” (3.2cm) One Edge Turned Binding

¾” (1.9cm) Two Edge Turned Binding

VINYL BINDING C

D E

H I

1¼” VINYL BIAS BINDING

Vinyl bias binding for automotive trimming. 100% polyvinyl chloride (PVC) face with a poly-cotton backing (65% polyester and 35% cotton). Cut on the bias for maximum strength. One edge folded under to give a width of 1¼”. Ideal for the finishing touch on auto carpets, interior trim pieces, etc. To speed installation, see the Trim Folders on p.102.

A B C D E F G H I

BINVI5009

Almond

BINVI5004

Black

BINVI4944

Blue

BINVI4943

Camel

BINVI5010

Charcoal

BINVI4940

White

BINVI4948

Off-White

BINVI4945

Maroon

BINVI5008

Grey

Roll Size: 100 yd

Please see p.102 for Binding tools

Price Breaks: Spool | Box (5 spools) | Case (10 spools)

FELT BINDING: SOLARGUARD

SOLARGUARD 1” FELT BINDING

An automotive and marine binding used for dash covers, car-bras and floor mats. 100% solution-dyed polyester. Non-woven flat needle construction with a thermobonded finish. Weight: 6 oz./yd2 Guauge: 0.040”

BINFE4792

1” SolarGuard Felt Binding—Black Price Breaks: Roll (50 yd) | Box (5 rolls) | Case (10 rolls)

NYLON BINDING: GROSGRAIN GROSGRAIN NYLON BINDING

Grosgrain black nylon binding in two widths for trimming bags, apparel and other nylon or leather products. Can be used anywhere twill tape is used for binding seams. Woven to each width with finished edges, not cut.

K K

BINGR11161

¾” Grosgrain Nylon Binding—Black

BINGR11163

1” Grosgrain Nylon Binding—Black Price Breaks: Roll (100 yd) | Box (5 rolls) | Case (10 rolls)

marine - awning - upholstery supplies | 117

BINDING: POLYESTER TWILL Polyester twill tape is used for binding and edging.

A B -

BINTW9845

¾” Polyester Twill Tape—White

BINTW9840

¾” Polyester Twill Tape—Black

BINTW9841

1” Polyester Twill Tape—White

BINTW9842

1” Polyester Twill Tape—Black

Price Breaks: Roll (109 yd) | Box (5 Rolls) | Case (10 Rolls)

WIRE ON BINDING Traditional style binding that is stitched in place on the edge of the cover, then used to wire in place on the frame with hog rings or other fasteners. C BINWI5002 ¾” Repp Wire On Binding—Black Price Breaks: Roll (25 yd) | Box (5 Rolls) | Case (10 Rolls)

POLYPROPYLENE ROPE Monofilament “polyprop” is the lightest, most widely used, economical rope on the market. The Polyprop rope strength exceeds that of Manila ropes, while also providing reliable specifications, such as long life, flexibility in cold temperatures and excellent resistance to most acids and alkalines. It also features good impact loading and will float on water. Suitable for a wide variety of applications including commercial fishing lines, towing and mooring lines, electrical line stringing, utility rope, scaffolding rope and more. The product is rated at medium for elongation and stretch; rated excellent for mildew, acid and alkali resistance; fair resistance to sunlight and organic solvents. Critical temperature: 392.4°C (250°F)

3/16” POLYPROPYLENE ROPE D E

CORRO6675

3/16” Polypropylene Rope—Yellow

CORRO6676

3/16” Polypropylene Rope—White

Price Break: Roll (2125’) Box (5 Rolls) | Case (10 Rolls)

¼” POLYPROPYLENE ROPE -

CORRO6673

¼” Polypropylene Rope—Yellow

CORRO6674

¼” Polypropylene Rope—White

Price Break: Roll (2125’) Box (5 Rolls) | Case (10 Rolls)

118 | marine - awning - upholstery supplies

AWNING CORDS NYLON AWNING CORDS Price Break: Roll (1000’) | Box (5 Rolls) | Case (10 Rolls)

CORAW6701

#4 ⅛” Nylon Diamond Braid Cord—White Break Strength: Roll (660 lb / 300 kg)

CORAW6704

#5 5/32” Nylon Diamond Braid Cord—White Break Strength: 700 lb (318 kg)

CORAW6705

#6 3/16” Nylon Diamond Braid Cord—White

Break Strength: 1000 lb (453 kg) Price Break: Roll (1000’) | Box (5 Rolls) | Case (10 Rolls)

DRAWSTRING CORDS NYLON DRAWSTRING CORDS—DIAMOND BRAID For bag and apparel applications.

CORDR6695

#3.5 7/64” Nylon Cord—White Break Strength: 440 lb (200 kg) Price Breaks: Roll (250’) | Box (6 Rolls) | Case (32 Rolls)

POLYPROPYLENE DRAWSTRING CORDS For bag and apparel applications.

E F

CORDR11190

5/32” Polypropylene Drawstring—Black

CORDR11194

5/32” Polypropylene Drawstring—White

Roll Size: 250 yd Price Breaks: Each | Box (5 Rolls) | Case (25 Rolls)

CORD LOCKS JACKET CORD LOCKS

Delrin jacket string locks for use in various garment applications.

G H

CORLO2210

Jacket Cord Lock—Black

CORLO2214

Flat Top Jacket Cord Lock—Black Price Breaks: Bag (100) | Box (5 bags) | Case (10 bags)

SQUARE CORD LOCKS I

CORLO2211

Square Cord Lock—Black Price Break: Bag (100) | Box (5 bags) | Case (10 bags)

BALL CORD LOCK Sliding ball cord lock in black.

CORLO2213

Ball Cord Lock—Black

WHEEL LOCK Sliding and locking cord adjuster in black.

CORLO2216

Wheel Lock—Black Price Breaks: Bag (100) | Box (5 bags) | Case (10 bags)

DRAW CORD BELL END L

CORLO2215

Draw Cord Bell End—Antique Price Breaks: Bag (100) | Box (5 bags) | Case (10 bags)

Price Breaks: Bag (100) | Box (5 bags) | Case (10 bags)

marine - awning - upholstery supplies | 119

CORDAGE: TWINE BARBOURS TWINE—LINEN

Recommended for stitching edges, button tufting and general upholstering. Comes in a natural linen color. Weight: 9 oz. (250 g)/Spool Price Breaks: Each | Box (6 ea) | Case (12 ea)

#2 Barbour Twine—Linen

CORTW8121

LUDLOW POLYESTER TWINE 100% polyester twine for tying springs. Tuff twine is twice as strong and will not rot like hemp. With reliable, known retention, tuff twine holds springs firmer. Weight: 5 lb. (2.3 kg)/Spool Price Break: Each | Box (10 ea) | Case (12 ea)

#6 Ludlow Polyester Twine—White

CORTW8122

NYLON TUFTING TWINE

Very strong and suitable for tying and tufting buttons. Great strength and resistance characteristics in a finer twine. Weight: 0.5 lb (227 g)/Spool Price Breaks: Each | Box (10 ea) | Case (12 ea)

CORTW8125

#9 Nylon Tufting Twine— White

SHOCK CORDS D

NYLON SHOCK CORDS D

CORSH6679

⅛” Nylon Shock Cord—Black Used as drawstrings in apparel items. Price Breaks: Roll (166 yd) | Box (5 Rolls) | Case (10 Rolls)

CORSH6680

3/16” Nylon Shock Cord—White Light nylon bungee cord. Cord length is customizable using the hooks on p.165. Price Breaks: Roll (144 yd) | Box (5 Rolls) | Case (10 Rolls)

F G H

CORSH6685

¼” Nylon Shock Cord—White/Black

CORSH6690

5/16” Nylon Shock Cord—White/Black (Break

CORSH6692

Strength: 75 lbs) ⅜” Nylon Shock Cord—White/Black (Break Strength: 115 lbs) White nylon bungee cord. Create custom lengths using clamps and hooks listed on p.74. Price Breaks: Roll (83 yd) | Box (5 Rolls) | Case (10 Rolls)

120 | marine - awning - upholstery supplies

POLYPROPYLENE SHOCK CORD

Bungee cord in polypropylene material, which has all the characteristics of polypropylene and is available in bulk for use in apparel, bag and other projects. Be sure to also see the Delrin Shock Cord Hooks #2722 and #2723.

CORSH6683

3/16” Polypropylene Shock Cord—Black Price Breaks: Roll (167yd) | Box (5 Rolls) | Case (10 Rolls)

SHOCK CORD HOOKS SHOCK CORD HOOK—DELRIN

2-part hook for use with ¼” shock cord.

BAGHO2723

¼” Shock Cord Hook—Black

Price Breaks: Bag (100) | Box (5 Bags) | Case (10 Bags)

ADJUSTABLE SHOCK CORD HOOK—DELRIN Adjustable hook accepts cords up to ⁵⁄₁₆”.

BAGHO2722

Adjustable Shock Cord Hook

Price Break: Bag (100) | Box (5 Bags) | Case (10 Bags)

STAINLESS STEEL CLAMPS

Secure the shock cord with these stainless steel clamps. Excellent resistance to environmental elements.

C D E

CORSH7801

⅛”–3/16”Stainless Steel Clamp

CORSH7806

7/32”–¼” Stainless Steel Clamp

CORSH7811

¼”–5/16” Stainless Steel Clamp

D F

ag (100) | Box (5 Bags) | Case (10 Bags) Price Break: B

STEEL S-HOOKS

Steel S-hook for forming cord and strap ends. Size denotes the shock cord or rope that will pass cleanly through the small end of the hook.

F G

CORSH7821

⅛” Steel S-Hook

CORSH7841

¼” Steel S-Hook

Price Breaks: Bag (100) | Box (5 Bags) | Case (10 Bags)

METAL SHOCK CORD HOOKS

Metal shock cord hooks painted in black for longer life. Plastic tips prevent marking of adjacent surfaces.

H I J

CORSH7843

¼” Metal Shock Cord Hook—Black

CORSH7844

5/16” Metal Shock Cord Hook—Black

CORSH7845

⅜” Metal Shock Cord Hook—Black

Price Breaks: Bag (25) | Box (4 Bags) Case (20 Bags)

K L

STAINLESS STEEL CONE HOOK

Stainless steel cone hooks for superior resistance and a neat finished appearance. Cord is meant to fit inside the cone.

K L

CORSH7800

3/16” Stainless Steel Cone Hook

CORSH7810

5/16” Stainless Steel Cone Hook

ag (25) | Box (4 Bags) Case (20 Bags) Price Break: B

STAINLESS STEEL S-HOOKS

Stainless steel S-hooks for superior resistance to environmental exposure.

M N

CORSH7820

⅛” Stainless Steel S-Hook

CORSH7840

¼” Stainless Steel S-Hook

M N

Price Breaks: Bag (25) | Box (4 Bags) Case (20 Bags)

marine - awning - upholstery supplies | 121

tape PRODUCT INFO SCOTCHLITE™ FLUORESCENT FIRE-RETARDANT TAPE A highly reflective fabric consisting of exposed wide-angle lenses bonded to durable cloth backing composed of 94% polyester and 6% cotton. It is lightweight and flexible, and has an enhanced daytime appearance. This provides high attention value when the visibility decreases, particularly at dawn or dusk. The nighttime appearance is a brilliant orange or yellow and provides reflectivity based on a wide range of light source angles. This material can be attached to a broad range of medium and heavy-weight fabrics. It has been tested for flame-resistance according to the Federal Test Method Standard 191A, Method 5903. Average char length is less than 6” (15.2 cm).

APPLICATION TO FABRIC: Sew in place using a lock-stitch with no more than 12 stitches per 1” and placed at least ⁵⁄₁₆” from the edge of the reflective fabric.

CAU TION: Use of a Teflon-coated needle may extend needle life. Do not apply this product to highly elastic materials.

CUT TING: The material can be hand-cut, die-cut or guillotined.

CARE INSTRUCTIONS (These are guidelines for the care of the product, please test application first): • Professionally dry clean, solvent temperature <30°C (85°F). Tumble dry warm 48°C (120°F). • Damp wipe using warm water and mild detergent. Rinse thoroughly, dry with a soft cloth or allow to air dry. • Machine wash warm (40°C, 104°F), tumble dry low.

NOT E: Maximum shrinkage is 3%. Recommended shelf life is two years and should be stored in a cool, dry area. Rolls should be stored on a rod or pipe through core.

122 | marine - awning - upholstery supplies

SCOTCHLITE™ TAPES

Ennis Fabrics is an authorized distributor of the 3M™ lineup of reflective tapes, films and materials. While these products are primarily products used in garments, they have many applications. Reflective Tapes are often incorporated into sports bags, runners, and accessories for athletes and joggers as well as clothing. Please remember that the items that are stocked represent the most popular items in this line. There are many other products available. We can provide immediate service on the stocked items. Other items are readily available on a special order basis.

PL EASE NOTE: While use of Scotchlite™ reflective material does greatly

enhance visibility, no reflective material can assure absolute visibility, particularly in adverse weather.

SCOTCHLITE™ HIGH GLOSS TAPES

This reflective material has a glossy vinyl coating that gives it a shimmering, almost wet look. This item consists of retroreflective microprisms formed on flexible, glossy and UV-stabilized polymeric film.

TAPRE11150

6187 2” High Gloss—Lime-Yellow Roll Size: 109 yd Price Breaks: Yard | Box (25 yd) | Roll (109 yd)

SCOTCHLITE™ FLUORESCENT FIRE RETARDANT TAPES

This is a highly reflective fabric consisting of exposed wide-angle lenses bonded to durable cloth backing composed of 94% Polyester and 6% Cotton. Lightweight and flexible, this material can be attached to a broad range of medium and heavyweight fabrics. FR tested according to Federal Test Method Standard 191A, Method 5903.

B1 B2

TAPRE11141

1” 8987 Fluorescent Lime/Yellow

TAPRE11143

2” 8987 Fluorescent Lime/Yellow

SCOTCHLITE™ REFLECTIVE FABRIC TRIM TAPES

Scotchlite™’s Reflective Tapes can be attached to a wide range of light and medium-weight fabrics, but is not recommended for attachment to highly elastic materials. Uses include accessories, uniforms, rain wear, jackets, active wear, head wear, backpacks, armbands, straps, belts, cutout letters and numbers, patches, and crests.

C -

TAPRE11132

8910 ½” Silver Fabric Trim

TAPRE11133

8910 1” Silver Fabric Trim Roll Size: 218 yd Price Breaks: Yard | Box (25 yd) | Roll (218 yd)

TAPRE11135

Roll Size: 218 yd Price Breaks: Yard | Box (25 yd) | Roll (218 yd)

Roll Size: 109 yd Price Breaks: Yard | Box (25 yd) | Roll (109 yd)

SCOTCHLITE™ SILVER FABRIC

Scotchlite™ Silver Fabric is composed of wide-angle, exposed retroreflective lenses bonded to a durable poly-cotton cloth backing. This fabric contains an aluminum layer as part of its construction. Blemishing of this aluminum layer can occur in prolonged exposure to temperatures greater than 26°C (80°F), or humid conditions greater than 70% relative humidity. These blemishes do not affect the performance of the product.

TAPRE11160

8925 2” Silver Fabric

SCOTCHLITE™ IRON-ON TRANSFER FILM

A highly reflective material with a wide angle reflectivity designed to enhance night visibility of the wearer. A removable plastic liner protects the heat-activated (ironon) dry adhesive on the back of the film. The transfer film is suitable for light to medium-weight fabrics and have very good stretch properties.

TAPRE11120

Scotchlite™ Vest Trim is designed to enhance 24-hour visibility. It combines a bright fluorescent element with a highly reflective silver stripe. The fluorescent is especially noticeable in conditions of poor visibility, particularly at dusk and dawn. This material can be attached to a wide range of light and medium-weight fabrics, but is not recommended for attachment to highly elastic materials.

G1 G2

TAPRE11130

8471 1½” Lime/Silver Vest Trim

TAPRE11131

8471 2” Lime/Silver Vest Trim Price Breaks: Yard | Box (100 yd) | Roll (327 yd)

8710 ½” Silver Transfer Film Roll Size: 200 yd Price Breaks: Yard | Box (25 yd) | Roll (200 yd)

Roll Size: 109 yd Price Breaks: Yard | Box (25 yd) | Roll (109 yd)

SCOTCHLITE™ VEST TRIM

8910 2” Silver Fabric Trim

D D

TAPRE11121

8710 ¾” Silver Transfer Film

TAPRE11122

8710 1” Silver Transfer Trim Roll Size: 218 yd Price Breaks: Yard | Box (25 yd) | Roll (200 yd)

TAPRE11158

8787 2” Lime-Yellow Transfer Film Roll Size: 218 yd Price Breaks: Yard | Box (50 yd) | Roll (218 yd)

marine - awning - upholstery supplies | 123

SCOTCHLITE™ PRESSURE-SENSITIVE REFLECTIVE TAPE

SCOTCHLITE™ SOLAS (SAFETY OF LIFE AT SEA)

Scotchlite™ SOLAS-grade products are intended for reflectorizing SOLAS life support equipment such as life vests, jackets, and rafts. It conforms to Marine Equipment Directive 96/98/EC and International Maritime Organization (IMO) Resolution A.658 (16) Annex 2. Approved by the US Coast Guard to meet 46 CFR part 164, subpart 164.018 for Type I and II retroflectible material used to enhance visibility of life-saving equipment in nighttime or low-light conditions. SOLAS-grade products have an European mark of conformance. All products are silver in color under daytime viewing conditions and reflect a bright white.

TAPRE11159

Scotchlite™ Pressure-Sensitive Tape offers the enhanced daytime/nighttime visibility of the wearer. Meets flame-resistant test 191A, Method 5903. A highly aggressive product with 3M™ adhesive, it is applicable for hard surfaces such as helmets, in-line skates, sports active protective pads, bicycles, etc.

TAPRE11123

8830 1” Silver Pressure Sensitive Tape Roll Size: 109 yd Price Breaks: Yard | Box (25 yd) | Roll (109 yd) C

6755 2” SOLAS Silver Sew-On Roll Size: 54 yd Price Breaks: Yard | Box (25 yd) | Roll (54 yd)

SCOTCHLITE™ INDUSTRIAL WASH B

TAPRE11153

9920 2” Silver Industrial Wash Sew-On

Roll Size: 218 yd Price Breaks: Yard | Box (50 yd) | Roll (218 yd)

TAPRE11156

9187 2” Industrial Wash Lime/Yellow With Silver 9187 contains an aluminum layer as part of its construction. Blemishing of this aluminum layer can occur if the front surface of the product has direct contact from hands during application, then exposed to hot and humid conditions greater than 26°C (80°F) and greater than 70% relative humidity, for a period of weeks. These blemishes do not affect the performance of the product. Roll Size: 109 yd Price Breaks: Yard | Box (50 yd) | Roll (109 yd)

SCOTCHLITE™ FIRE-RETARDANT INDUSTRIAL WASH SEW-ON

8940 Silver Industrial Wash Flame Resistant fabric is composed of wide-angle, exposed retroreflective lenses bonded with a special polymer layer to an aramid backing. 8940 meets or exceeds the following tests as specified in NFPA 1971 Standard, 2000 Edition, ANSI/ISEA 107-1999 and EN471 Class 2 retroreflective performance specifications.

B B

TAPRE11162

8940 1” Silver FR Industrial Wash Sew-On

TAPRE11157

8940 2” Silver FR Industrial Wash Sew-On Roll Size: 218 yd Price Breaks: Yard | Box (50 yd) | Roll (218 yd)

SCOTCHLITE™ INDUSTRIAL WASH

9920 Silver Industrial Wash fabric is composed of wide-angle, exposed retroreflective lenses bonded with a special polymer layer to a durable 100% polyester cloth backing. Certified to meet ANSI/ISEA 107-1999 Level 2 retroreflective performance and EN 471 Class 2 retroreflective performance.

APPLICATION TO FABRIC: Sew in place using a lock stitch with no more than 12 stitches per 1” and placed at least ⁵⁄₆ ₄” from the edge of the reflective fabric. THREAD RECOMMENDATION: 100% polyester or appropriate thread for flame-resistant applications. Whenever two or more pieces of 9920 Industrial Wash fabrics are used together on a single surface or as a set, they should be matched to ensure uniform daytime color and nighttime or low-light reflectivity. CUTTING: The material can be hand-cut, die-cut or guillotined. CARE INSTRUCTIONS: Stain treatment wash may reduce the life of 9920. Use low-medium alkaline, high surfactant detergents. Do not use solvenated surfactants. Do not use chlorine bleach. Maximum wash temperature: 75°C (165°F) Break/Suds Cycle: <20 minutes total Tunnel Dry: ≤160°C (300°F) Tumble Dry: Maximum 90°C (195°F) Drying Time: ≤7 minutes Pressing: ≤150°C (300°F) Note: Recommended shelf life is two years and should be stored in a cool, dry area. Rolls should be stored on a rod or pipe through core.

124 | marine - awning - upholstery supplies

MARINE TRANSFER TAPE This product is a high-tack acrylic double-coated tape, designed to provide high initial adhesion and excellent bond to most canvas and acrylic fabrics. Simply roll tape on the fabric where the seam is to be made. The tape holds firmly to prevent slippage during sewing and helps to prevent seam leakage.

A B

TAPETR7991

¼” Marine Transfer Tape

TAPETR7992

½” Marine Transfer Tape

Price Breaks: Roll (36 yd) | Box (12 Rolls) | Case (72 Rolls)

PACKING PRODUCTS HAND STRETCH FILM

This product features increased puncture resistance, elevated tear resistance, superior optics and maximum load retention for a secure cling. Reduced neckdown lower packaging costs and reduces the initial film’s width. Quiet unwind eliminates the distracting noise generated by many films. Roll is 492 yd.

TAPMI7987

12.8” Hand Stretch Film Price Breaks: Roll | Box (4 rolls) | Case (8 rolls)

CARTON SEALING TAPE & DISPENSER

The 2” Carton Sealing Tape is an all-around polypropylene packaging tape with good moisture and impact resistance. Use with the sturdy and durable dispenser for tapes from 1½”–2” wide.

TAPMI7990

2” Carton Sealing Tape Price Breaks: Package (6 rolls) | Box (6 packages) | Case (12 packages)

TAPMI7985

2” Hand Tape Dispenser Price Breaks: Each | Box (12 ea)| Case (24 ea)

marine - awning - upholstery supplies | 125

trimming E-Z LACE SUPREME A patented grommet-free lacing system to securely attach awnings, canopies, boat covers, tents and other outdoor applications. E-Z Lace is a product introduced to avoid the need for expensive installation, special equipment and additional manufacturing steps associated with traditional grommet installation. E-Z Lace provides long-term strength while also offering mildew and UV resistance.

A B C D

TRIEZ296604

Natural

TRIEZ296608

Black

TRIEZ296630

Cadet Grey

TRIEZ296633

Linen

E F G H

TRIEZ296637

Forest Green

TRIEZ296601

Pacific Blue

TRIEZ296631

Burgundy

TRIEZ296003

Jockey Red

Price Break: Roll (50 yd) | Box (4 Rolls) | Case (8 Rolls)

USING E-Z LACE

A 1” reinforced side hole makes lacing easy and quick, while the 3” spacing between holes increases manufacturing design flexibility. Lace awning cords through the slits and secure to the awning frame.

WELT 100% PVC welting cord with slit flanges for easy tailoring of corners. ⅛” diameter welting designed specifically for the sport bag and accessory industry. J

WELT—PREMIER I

TRIWE9719

J WELT

Premier Welt—Black Price Breaks: Roll (250 yd) | Box (5 Rolls) | Case (10 Rolls)

WELT—EMBOSSED J K L M N

Used to repair truck and tractor seats. The welt is sewn to the bottom of the cover, then snapped over the lower edge of the seat pan frame. Can be used anywhere there is a lip for the welt to hook over. Soft pliable plastic can be sewn by industrial machines.

TRIWE8435

J Welt

TRIWE9834

Navy

TRIWE9836

White

Pr ice Breaks: Spool (100’) | Box

TRIWE9838

Bright Red

(5 Spools) | Case (10 Spools)

TRIWE9849

Black

TRIWE9897

Buckskin

Price Breaks: Roll (100 yd) | Box (5 Rolls) | Case (10 Rolls)

I O

126 | marine - awning - upholstery supplies

POLY WELT

Softer, single fi lament plastic welting cord in various diameters. They do not support mold or mildew and are more suited for many automotive, marine and outdoor applications.

TWIN FIBER FLEX WELT

Two T-braid welt cords form decorative twin welt. Price Breaks: Each (250 yd) | Box (4 Rolls) | Case (8 Rolls)

Price Breaks: Roll | Box (5 Rolls) | Case (10 Rolls)

A A A

TRIWE9825

⅛” Poly Welt—1000 yd

TRIWE9830

5/32” Poly Welt—500 yd

TRIWE9827

3/16” Poly Welt—500 yd

TRIWE9752

5/32” Twin Fiber Flex Welt

FIBERFLEX WELT Cellulose welting cord in various sizes. ⁵/₃₂” is standard in furniture manufacturing. The smaller size is very common in automotive and RV applications. This welt features a wrapping of strong, tight thread that makes it very stable and consistent over time.

B B

TRIWE9739

4/32” Fiber Flex Welt—1600 yd

TRIWE9749

5/32” Fiber Flex Welt—1000 yd

Price Breaks: Roll | Case (8)

TRIWE9762

12/32” Fiber Flex Welt—225 yd Price Breaks: Roll | Case (4)

TRIWE9750

5/32” Fiber Flex Welt—500 yd Price Breaks: Roll | Box (5 Rolls) | Case (10 Rolls)

HYDEM GIMP: MIDSHIP The Midship Hydem Gimp is center-split, a unique feature created by the two fl aps that open up to a center well where staples or tacks are applied. The fl aps will then close back over the well to hide the nail heads and staples for a clean, fi nished double-welt appearance. Available to match all 27 colors of our Midship fabric (p.8). Price Break: Roll (50 yd) | Box (5 Rolls) | Case (10 Rolls) D

TRIHYMID

9009 Black

TRIHYMID

98 Medium Grey

TRIHYMID

8 Chocolate

TRIHYMID

6 White

TRIHYMID

333 Azure

TRIHYMID

805 Spice

17 Burgundy

TRIHYMID

84 Rust

TRIHYMID

222 Hunter Green

TRIHYMID

3 Royal Blue

TRIHYMID

6003 Ivory

TRIHYMID

8884 Rawhide

TRIHYMID

33 Navy

TRIHYMID

6009 Oyster White

TRIHYMID

9006 Light Grey

TRIHYMID

34 Teal Green

TRIHYMID

61 Mystic White

TRIHYMID

905 Seagull

TRIHYMID

67 Mushroom

TRIHYMID

649 Almond

TRIHYMID

969 Dark Grey

TRIHYMID

87 Brown

TRIHYMID

66 Off White

TRIHYMID

97 Steel

TRIHYMID

1 Red

TRIHYMID

696 Bright White

TRIHYMID

99 Mid Grey

marine - awning - upholstery supplies | 127

SNAP-ON TRIM A flexible plastic wind lace with a metal core and leather grain surface. For snap-on installation on pinch-welded seams. Suitable for import or domestic autos, interior, or exterior use.

TRIMI8400

Snap-On Trim—Black Price Breaks: Roll (100’) | Box (5 Rolls) | Case (10 Rolls)

SPONGE ROD Sponge rod is used for shimming and bolstering worn and shrunken weather stripping around car doors and trunks.

TRIWE7579

½” Sponge Rod Price Breaks: Roll (30yd) | Box (5 Rolls) | Case (10 Rolls)

EDGEROLL SPUNBONDED EDGEROLL

An edge roll padding with an attaching flange, used for padding corners, arms, etc. Firm material avoids packing down. Can be attached by stapling, tacks or tacking strips.

Price Breaks: Roll (50’) | Box (5 Rolls) | Case (10 Rolls)

C -

TRIED4200

¾” Spunbonded Edgeroll

TRIED4205

1¼” Spunbonded Edgeroll

PERFLEX CLIP EDGEROLL

Perflex features an all synthetic filler and tough spunbonded cover. It has built-in positioning stakes spaced at 1½” intervals, or can be sewn, stapled or tacked on for hard edge designs.

Price Breaks: Roll (50’) | Box (5 Rolls) | Case (10 Rolls)

TRIED4208

1¼” Clip-on-Edge

128 | marine - awning - upholstery supplies

⅝” WELT: MIDSHIP A

Similar to the Midship Hydem Gimp, the Midship Welt cord is meant to be used to dress up and finish seams. Midship Welt is available to match all 27 colors of our Midship fabric (p.8).

D E F G H I

R S T U V W

L M N

Z A1

Price Break: Roll (50 yd) | Box (5 Rolls) | Case (10 Rolls)

TRIWEMID

9009 Black

TRIWEMID

6 White

TRIWEMID

222 Hunter Green

TRIWEMID

3 Royal Blue

TRIWEMID

33 Navy

TRIWEMID

34 Teal Green

TRIWEMID

67 Mushroom

TRIWEMID

87 Brown

TRIWEMID

1 Red

TRIWEMID

98 Medium Grey

TRIWEMID

333 Azure

TRIWEMID

17 Burgundy

TRIWEMID

6003 Ivory

TRIWEMID

6009 Oyster White

TRIWEMID

61 Mystic White

TRIWEMID

649 Almond

TRIWEMID

66 Off White

TRIWEMID

696 Bright White

TRIWEMID

8 Chocolate

TRIWEMID

805 Spice

TRIWEMID

84 Rust

TRIWEMID

8884 Rawhide

TRIWEMID

9006 Light Grey

TRIWEMID

905 Seagull

TRIWEMID

969 Dark Grey

TRIWEMID

97 Steel

TRIWEMID

99 Mid Grey

marine - awning - upholstery supplies | 129

NO SAG SPRING TOOLS SPRING STRETCHER

This simple metal and wood tool allows a secure grip on the spring so it can be stretched into place in an existing clip. Useful for awkward spots where the lever type will not fit.

TOOSI7903

#297 Pull Type Spring Stretcher

Price Break: Each | 3 ea | 6 ea

LEVER TYPE SPRING STRETCHER

The wooden handled lever speeds up the installation and is especially useful with heavy seating springs.

TOOSI7904

Price Break: Each | 3 ea | 6 ea

SPRING BENDER

Chrome plated sleeves are slotted to fit loops and can be used to alter bends precisely. Designed to allow exact manipulation of the angles of the arcs on the spring. High impact handles.

#268 Lever Type Pull Type Spring Stretcher

TOOSI7907

#401 1” Spring Bender (Pair)

SPRING END FORMER

A lever action tool that can be used as a vice when mounted to the edge of a workbench. Simplifies the crimping of spring ends (both coil and sinuous). A cleanly crimped spring end will not slide out of clips, and can provide a spot for hog rings or clips. Instructions and mounting bolts included.

TOOSI7905

Price Break: Each | 3 ea | 6 ea

#404 Spring End Former Price Break: Each | 3 ea | 6 ea

SPRING CLIPS TOOLS

#445 PLIERS FOR 3 PRONG CLIPS

When crimping onto curved spring surfaces, use these pliers and the 3 prong clips to get the best connection on curves and arcs. The double pivot action ensures tight and complete crimping.

TOOSI8013

#445 3 Prong Clip Pliers Price Break: Each | 3 ea | 6 ea

HOW TO USE SPRING TOOLS

#522 PLIERS FOR BW CLIPS

The special round contact surface on the jaws of this plier ensure a good solid clamping of BW Edgewire clips; recommended for joining edgewire to sinuous springs or other straight spring sections.

TOOSI8026

#522 BW Clip Pliers Price Break: Each | 3 ea | 6 ea

SAMPLING ACCESSORIES

SAMPLE BOOK RING

Bright chrome finished rings with locking threaded closure for use in sample books and other applications. Available in 6” or 3” diameters. Use handle #6520 to create a portable sample ring book.

E F

FASSA6510

6” Chrome Sample Book Ring

FASSA6500

3” Chrome Sample Book Ring

Price Breaks: Bag (25 ea) |Box (4 bags) | Case (10 bags)

SAMPLE BOOK HANDLE

Sturdy chrome handle to go with rings listed above. 10” spacing.

FASSA6520

10” Chrome Sample Book Handle Price Breaks: Each | Case (175)

HANGER WITH METAL HOOK

Sturdy plastic hangers with metal hooks and clips.

FASSA6514

8” Hanger with Metal Hook—Black Price Breaks: Each | Case (175)

130 | upholstery supplies

PLIERS: ZIPPER & HOG RING

ZIPPER STOP PLIERS

TOOZI11010

#1012 Zipper Stop Pliers Price Breaks: Each | 3 ea | 6 ea

HOG RING PLIERS

All pliers have a non-slip handle and will apply hog rings up to 1” in size. Price Break: Each | 3 ea | 6 ea

B C D E F

TOOHO8002

XX Straight—Hog Ring Pliers

TOOHO8003

XXL Angle—Hog Ring Pliers

TOOHO8004

L Right Angle—Hog Ring Pliers

TOOHO8005

#23 Straight—Hog Ring Pliers

TOOHO8006

#2360 Angle—Hog Ring Pliers

STEAMERS HAND HELD STEAMER

This portable, versatile steamer is for removing wrinkles and puckers in fabrics, especially velvets. Not an industrial all day use steamer, but perfect for on site adjustments to upholstery or draperies. Easy to fi ll and has a visible water level indicator. Starts producing steam in 15 seconds and has a large steam vent for a continuous fl ow of steam. Features a built in thermostat and an on/off indicator light.

TOOST7288

Esteam Hand Held Steamer Price Break: Each | 3 ea | 6 ea

J-2 JIFFY STEAMER L

J-2 standard steamer from Jiffy operates with ordinary tap water and is easy and safe to use. Has a 5½’ hose and sectional rod set, removable for storage. Comes with an assembly wrench for easy, convenient setup. Heavy duty wiring. Die cast aluminum housing with 1 gallon (4.5L) checkvalve water bottle that prevents spilling. New improved heating element produces steam quickly and is specially designed to control “spitting”. Easily disassembles to remove mineral deposits. Has a shipping weight of 10lb. The heating element can be replaced.

H I

TOOST7283

J-2 Jiffy Steamer

TOOST7285

J-2 Heating Element Replacement Price Break: Each | 3 ea | 6 ea

J-4000 JIFFY STEAMER

REPLACEMENT HOSE FOR J-2 & J-4000 L

TOOST7287

Hose Replacement Length: 5½’

Price Break: Each | 3 ea | 6 ea

The J-4000 professional duty model has dual thermostats for steam in seconds after preheating. Features built in boiler tank made from strong rust proof #304 stainless steel. Contains a sight gauge allowing you to quickly keep a visual check on the water level within the steamer. A 1500W heating element is designed for long life. This unit features heavy duty colorcoded high temperature wiring and a three-position switch with automatic shut off. UL, CSA and CE approved. Shipping weight for this unit is 29lb. The heating element can be replaced.

J K

TOOST7284

J-4000 Jiffy Steamer

TOOST7289

J-4000 Heating Element Replacement Price Break: Each | 3 ea | 6 ea

upholstery supplies | 131

UPHOLSTERY KIT B1 UPHOLSTERY REPAIR KIT

This upholstery kit is intended for the beginner. It is ideal as a starting point for upholstery classes or as a retail item on the counter top of your shop or store. It includes an instruction book to cover the basics of a beginner’s project. Each kit contains: 1 magnetic hammer, 1 webbing stretcher, 1 claw type tack/staple lifter, 1 straight needle, 1 instruction booklet, 1 box of 12oz. tacks, 1 box of 4oz. tacks, 2 curved needles.

TOOKI8061

B1 Upholstery Repair Kit Price Break: Each | 3 ea | 6 ea

WEBBING TOOLS JAW WEBBING STRETCHER

GOOSE NECK WEBBING STRETCHER

Made with a hammer jaw that acts as a lever. Excellent tool for stretching webbing, as well as leather and canvas.

TOOWB8022

Goose Neck Stretcher gets your hands away from the steel teeth and provides great leverage on the webbing. Hard wood with corrugated rubber on the butt of the stretcher. Polished steel pins grip the webbing with minimum ripping.

3½” Jaw Webbing Stretcher

Price Break: Each | 3 ea | 6 ea

TOOWB8024

#403 Goose Neck Webbing Stretcher Price Break: Each | 3 ea | 6 ea

WOODEN WEBBING STRETCHER A wooden stretcher with a corrugated rubber grip on one end and a row of six steel teeth on the other.

TOOWB8023

#8 Wooden Webbing Stretcher Price Break: Each | 3 ea | 6 ea

C B

132 | upholstery supplies

Touch the Future

™

Ennis Fabrics + ULTRAFABRICS Ultimate softness and unbeatable strength. Sensorial grains and innovative textures. Naturally animal-free and easy to tailor in any application. Born in the cross-section of Japanese craftsmanship and technological pioneering, Ultrafabrics is function and beauty in perfect harmony. Ultraleather® | Brisa® | Ultratech™

ultrafabricsinc.com Red Swatch = Ultratech™ | Cove Cherry Red

upholstery supplies | 133

DECORATIVE NAILS

tacks & nails

Decorative nails are used to complement, show woods and gimps on furniture as well as to anchor nail strips and trims. A large assortment of colors and designs are available. Decorative nails should be set lightly in place with a tack hammer, then gently set with a mallet to avoid damaging the decorative face.

STANDARD— 7/16” NAIL HEAD A B C D E F G H I J

OX NAILS—1” NAIL HEAD N O P

TACNA6049

#9 Nail—French Natural ½” Post

TACNA6050

#9 Nail—French Natural ¾” Post

TACNA6047

#9 Nail—Antique Brass ½” Post

TACNA6048

#9 Nail—Antique Brass ¾” Post

TACNA6041

#9 Nail—Bright Brass ½” Post

TACNA6045

#9 Nail—Nickel-Plated ½” Post

TACNA6046

#9 Nail—Nickel-Plated ¾” Post

TACNA6021

#210 Nail—Nickel-Plated ½” Post

TACNA6022

#210 Nail—Nickel-Plated ¾” Post

TACNA6026

#210 Nail—White ¾” Post

TACNA6024

#210 Nail—Black ¾” Post

TACNA6031

#1515A Nail—Antique ½” Post

TACNA6032

#1515A Nail—Antique ¾” Post

TACNA6034

#1515A Nail—Nickel-Plated ½” Post

TACNA6037

#1533 Nail—Antique ½” Post

Q R S

Round Ox Nail—Pewter ⅞” Post

TACNA5924

Round Ox Nail—Brass ⅞” Post

TACNA5922

Round Ox Nail—Black ⅞” Post

OX NAILS—¾” NAIL HEAD T U V W

TACNA5921

Square Ox Nail—Pewter ⅞” Post

TACNA5920

Square Ox Nail—Black ⅞” Post

TACNA5919

Square Ox Nail—Copper ⅞” Post

TACNA5918

Square Ox Nail—Brass ⅞” Post Price Breaks: Bag (10) | Box (5 Bags) |

TACNA6008

Unthreaded Nail—Steel ⅞” Post

Case (10 Bags)

NAIL STRIPS

Price Breaks: Bag (1,000) | Box (5 Bags) |

The Continuous Nail Strip will simulate a row of evenly-spaced #9 nails without all the measuring, time and nails. Speeds up upholstering operations and cuts costs 50–80%. Provides accurate spacing for a uniform and professional appearance. Hole every forth cap for a real nail to anchor the strip and allow you to secure it around curves or other shapes. Plain 7/16” head to be used with our #9 Nails (#TACNA6041, #TACNA6045, and #TACNA6046).

Case (10 Bags)

4 TRI SQUARE—⅝” NAIL HEAD Natural—¾” Post

TACNA5923

Case (10 Bags)

Threaded Nail—Steel ⅞” Post

Old Copper—¾” Post

Round Ox Nail—Brass ⅝” Post

Price Breaks: Bag (10) | Box (5 Bags) |

TACNA6009

TACNA6014

Round Ox Nail—Black ½” Post

TACNA5917

OX NAILS—⅝” NAIL HEAD

PANEL NAIL— ¾” NAIL HEAD

TACNA6016

TACNA5925

Case (10 Bags)

L M

Round Ox Nail—Pewter ½” Post

Price Breaks: Bag (10) | Box (5 Bags) |

Price Breaks: Bag (1,000) | Box (5 Bags) |

K -

TACNA5926

X Y

Price Breaks: Bag (10) | Box (5 Bags) | Case (10 Bags)

TACNA6013

Nickel Nail Strip—With ¾” Post Nails

TACNA6012

French Natural Nail Strip—With ¾” Post Nails Price Breaks: Roll (50 yd) | Box (5 Rolls) | Case (10 Rolls)

134 | marine - awning - upholstery supplies

DARK NATURAL—⅝” POST

TACNA6006

French Natural— 1” Head Size

TACNA6020

French Natural—⅞”Head Size

TACNA6010

French Natural— ¾” Head Size

TACNA6002

French Natural—⅝”Head Size

TACNA6000

French Natural—7/16” Head Size

H I J

TACNA5913

Dark Natural—1” Head Size

TACNA5910

Dark Natural—⅞” Head Size

TACNA5916

Dark Natural—¾” Head Size Price Breaks: Bag (250) | Box (5 Bags) | Case (10 Bags)

Price Breaks: Bag (250) | Box (5 bags) |

TACNA5908

Case (10 Bags)

Dark Natural—⅝” Head Size Price Breaks: Bag (500) | Box (5 Bags) | Case (10 Bags)

JEWELLED NAILS—⅝” POST F G M N O P Q R

FRENCH NATURAL—⅝” POST A B C D E

TACNA5932

Small Square—Nickel ⅜” Head Size

TACNA5933

Large Square—Nickel 9/16” Head Size

TACNA5930

Small Rounded Black—Brass ⅜” Head Size

TACNA5931

Large Rounded Black—Brass ½” Head Size

TACNA5934

Small Rounded—Brass ⅜” Head Size

TACNA5935

Large Rounded—Brass ½” Head Size

TACNA5936

Small Rounded—Nickel ⅜” Head Size

TACNA5937

Large Rounded—Nickel ½” Head Size

TACNA5906

Dark Natural—7/16” Head Size Price Breaks: Bag (1000) | Box (5 Bags) | Case (10 Bags)

Price Breaks: Bag (10) | Box (5 Bags) | Case (10 Bags)

TACKS & TACKING STRIPS METAL TACKTITE TACK STRIP

For extra hold, serrated teeth have been punched through this 10oz. metal strip. They give the ultimate grip in the wood frame once set. 24” and 27” lengths minimize the need to cut the product.

S S S

TACST8329

24” Metal Tacktite Tack Strip

TACST8331

27” Metal Tacktite Tack Strip

TACST8332

30” Metal Tacktite Tack Strip Price Breaks: Bag (100) | Box (5 Bags) | Case (10 Bags)

CARDBOARD TACKING STRIP

Use as an edge stiffener and tack strip when blind tacking covers to a frame. Can be easily torn by hand and will accept a degree of curve without buckling. In a 5 lb bundle, there are ~350 pieces.

TACST8349

½” Cardboard Tack Strip (L38”) Price Breaks: Bundle (5 lb) | Box (5 Bundles) | Case (10 Bundles)

FIBER TACKING STRIP COIL

½” fi ber tacking strip in a continuous coil of 535’ for the production line. Tough enough for most uses but can be torn to length by hand for the fastest application of cover fabrics.

TACST8351

½” Continuous Tack Strip (535’ Coil) Price Breaks: Each | Box (5 ea) | Case (10 ea)

CURVE EASE STRIP

The ideal solution for attaching a cover to diffi cult curved areas. Eliminates time consuming hand sewing, blind stitching, decorative nails and gimp tacks. Sturdy pliable metal provides ample strength for shaping into any curve for any style. Sharp metal prongs in a series of two or three to grip fabrics or plastics. 3 Prongs are closely spaced to eliminate unwanted scalloping of the fabric.

V -

TACUP8339

Curve Ease Tacking Strip

TACUP8341

Heavy Duty Curve Ease Strip Price Breaks: Roll (100’) | Box (5 Rolls) | Case (25 Rolls)

U S

marine - awning - upholstery supplies | 135

™

Design + Performance and Legendary Performance Fabrics are trademarks and Sunbrella is a registered trademark of Glen Raven, Inc. ™ ®

L EG E N DA R Y PE R F O R M A N C E FA B R I C S SU N B E L L A .COsupplies M 136 | Rupholstery

FA D E PR O O F / E A S Y C A R E / B L E AC H C L E A N A B L E

™

BUTTON SIZING INFO

buttons & snaps

The numbers used to size the upholstery buttons (e.g. 22, 30, 36, 45) are based on a scale of 40 units to the inch, for example a #30 button represents 30 out of 40, or ¾” in diameter before covering. Using this scale, the common sizes roughly translate into: #22 = ⁹/₁₆”

#30 = ¾”

#36 = ⁷/₈”

#45 = 1¹/₈”

BUTTONS All the button machines listed function by crimping the shell around the button back, over a wide range of material thickness and weights. This can lead to the need for some correction of pressure or possibly a set of dies made for a different thickness of material. If you are not able to resolve your problems with the information provided here, please feel free to consult our Customer Service Center for further information.

NO TE: There are many types of buttons and machines that are available on a special order basis. If you do not see the item you need here, please contact our Customer Service Center or your sales representative for more information.

COMMON PROBLEMS

SOLUTIONS

Material does not wrap cleanly around shell to form button.

Check alignment of button dies, adjust stop pins on swivel base. Center the dies to ensure the buttons are completely crimped.

Shell is dented or vinyl covering is creased

Die may be for lighter material or stroke pressure may be too high.

Shell not crimped, back of button is not inside shell.

Stroke pressure may be too light. Ensure dies are aligned and try increasing pressure.

Vinyl material tears or cuts, fabrics cut.

Sign shell being too hard use softer shells. Can also try warming vinyl before crimping, lubricate with silicone, or apply light oil to bottom die (if using vinyl). Also check dies for burrs or nicks.

Shell not crimped and back pushed up completely inside.

Material is too light for the die. Try using a double layer of material or with a lining.

Back of button collapses or buckles. Back not far enough into shell, shell is crushed.

Material is too heavy for the die.

The shell is loose and coming off of the button back.

Material is too light for the die. Try using thicker fabric or adding a lining.

BUTTON SHELLS

RUST RESISTANT SHELLS

Price Breaks: Bag (144) | Box (5 Bags) | Case (25 Bags)

Soft shells for use with various styles of backs. The soft shell is the industry standard for the widest range of applications. Harder shells have a tendency to cut some types of vinyls and fabrics. Order the shells and backs you need for the complete set.

A B C D

BUTUP2002

#22 Button Shell

BUTUP2012

#30 Button Shell

BUTUP2028

#36 Button Shell

BUTUP2038

#45 Button Shell

Zinc plated soft button shells for use in marine and outdoor furniture, will not rust or cause streaking. All metal backs are zinc plated, standard shells are unplated but do have a treatment to resist corrosion. For extra protection, zinc plating is recommended.

E F

BUTUP2076

#22 Rust Resistant Button Shell

BUTUP2078

#30 Rust Resistant Button Shell

upholstery supplies | 137

2 PRONG BACKS

Two prongs with chiseled ends for pushing through fill provides the attaching mechanism for this button back. Fast and economical, requiring no special skills for installation. Excess prong length can be removed with pliers or side cutters if need be. Ideal for use with solid backed jobs. Can be used on backed materials using the prong button washer, see part #BUTUP2021. This unit is sold by the gross without the shell.

Price Breaks: Bag (144) | Box (5 Bags) | Case (25 Bags)

A B C K L

BUTUP2094

#22 1½”

BUTUP2011

#22 2”

BUTUP2100

#22 2½”

BUTUP2096

#30 1½”

BUTUP2013

#30 2”

M P Q R

BUTUP2102

#30 2½”

BUTUP2098

#36 1½”

BUTUP2015

#36 2”

BUTUP2104

#36 2½”

PRONG BUTTON WASHER

Use this washer to give a solid location of a prong style button and minimize the chance of pull-through. Can be used to give extra support to tufting clasps. Strongly recommended with any of the prong button molds.

BUTUP2021

Prong Button Washer

Price Breaks: Bag (144) | Box (5 Bags) | Case (25 Bags)

An easy to use washer, can be threaded onto pre-tied strings or tufted through the center normally. Will not corrode or rust and is silent when in contact with metal or wood components. 1¹/₈” in diameter.

BUTUP2108

TUFTING WASHER

Plastic Tufting Washer

Price Breaks: Bag (144) | Box (5 Bags) | Case (25 Bags) V

WIRE EYE BACKS

A sturdy closed loop wire eye for attaching the button used in tufting and other button applications. Will withstand an 80lb (36.3 kg) pull. Can be tied, used with clasps from a tufting needle or otherwise attached. Has the most common and versatile back. These are sold without the shells. Order the shells listed on p.188.

F G N O

BUTUP2001

#22 Wire Eye Back

BUTUP2003

#30 Wire Eye Back

BUTUP2005

#36 Wire Eye Back

BUTUP2006

#45 Wire Eye Back

Price Breaks: Bag (144) | Box (5 Bags) | Case (25 Bags)

LOOP EYE BACKS

The #44 small wire eye back has a smaller eye to be used against delicate materials to minimize piercing and runs. Zinc plated for rust resistance.

H I J

BUTUP2080

#22—44 Small Loop Eye Back

BUTUP2082

#30—44 Small Loop Eye Back

BUTUP2084

#36—44 Small Loop Eye Back

Price Breaks: Bag (144) | Box (5 Bags) | Case (25 Bags) 138 | marine - awning - upholstery supplies

THREADED NAIL BACKS

Threaded nail back buttons for use in applications using the spring washer listed below. Using this combination will ensure positive placement of the button, even in wood. It prevents pulling out as the wood ages and movement of the button occurs, loosening the nail back. Available in 4 different sizes listed. Matching shells are sold separately, see p.188.

S T U V

BUTUP2041

#22 ” Threaded Nail

BUTUP2051

#22 1½” Threaded Nail

BUTUP2043

#30 ⅞” Threaded Nail

BUTUP2045

#36 ¾” Threaded Nail

Price Breaks: Bag (144) | Box (5 Bags) | Case (25 Bags)

SPRING WASHERS

This washer allows for a better location of nail back buttons and minimizes the chance of pull-through. The nail cannot pull back through once gripped by the teeth of the washer. ¹⁵/₁₆” diameter.

BUTUP2067

15/16” Spring Washers

Price Breaks: Bag (144) | Box (5 Bags) | Case (25 Bags)

DURA SNAP RINGS

High impact nylon rings that work with upholstery soft shells to create a covered button that fits over any standard Dura Snap fastener. This product is available in two sizes and is a versatile option in finishing and trimming applications in automotive and marine.

B C

BUTUP2036

#30 Dura Snap Rings

BUTUP2030

#36 Dura Snap Rings

Price Breaks: Bag (144) | Box (5 Bags) | Case (25 Bags)

PIVOT BACK AND TACKS

Special two part back can be installed from the back of a surface and gives a pivoting action. Ideal when a button is required on only one side of a cushion. Can be used in tailoring skirts. Easily snapped together with hand pressure but will not pull apart.

BUTUP2037

NYLON HOOK BACK

Nylon hook backs can streamline and speed up tufting operations with the patented dual locking hook.

K L M N

#30 Pivot Back with ½” Tack

Price Breaks: Bag (144) | Box (5 Bags) | Case (25 Bags)

BUTUP2086

#22 Nylon Hook Back

BUTUP2088

#30 Nylon Hook Back

BUTUP2090

#36 Nylon Hook Back

BUTUP2092

#45 Nylon Hook Back

Price Breaks: Bag (144) | Box (5 Bags) | Case (25 Bags)

DURA SNAP: NICKEL-PLATED BRASS

A heavy-duty button-style fastener. Socket construction assures a firm grip which is maintained throughout use. Used in automotive, industrial and marine trades.

DURA SNAP SOCKET

DURA SNAP STUD

Standard socket for use with all Dura Snap Caps.

FASDB4003

For use with Dura Snap Posts (#4007 or #3995), or with #6 Head Screw.

Dura Snap Socket

Price Breaks: Bag (100) | Box (5 Bags) | Case (10 Bags)

FASDB3995

Dura Snap Post—Long

FASDB4007

Dura Snap Post—Standard

DURA SNAP CAPS

Use with socket #4003. Diameter of cap is 9/16”.

Price Breaks: Bag (100) | Box (5 Bags) | Case (10 Bags)

Use with socket #3997. Diameter of cap is ½”.

H I J

FASBB3992

Baby Dura Snap Cap—Black Brass

FASBB3996

Baby Dura Snap Cap—Nickel Brass

FASBB3999

Baby Dura Snap Post—Nickel Brass

Price Breaks: Bag (100) | Box (5 Bags) | Case (10 Bags)

FASDB4001

Dura Snap Standard Cap

Price Breaks:Bag (100) | Box (5 Bags) | Case (10 Bags)

BABY DURA SNAP: NICKEL-PLATED BRASS BABY DURA SNAP CAPS & POST

Dura Snap Stud

Price Breaks: Bag (100) | Box (5 Bags) | Case (10 Bags)

DURA SNAP POSTS F G

FASDB4004

R R

BABY DURA SNAP SOCKET Q

FASBB3997

Baby Dura Snap Socket—Nickel Brass

Price Breaks: Bag (100) | Box (5 Bags) | Case (10 Bags)

BABY DURA SNAP STUD R

FASBB3998

Baby Dura Snap Stud—Nickel Brass

Price Breaks: Bag (100) | Box (5 Bags) | Case (10 Bags) marine - awning - upholstery supplies | 139

140 | upholstery supplies

cleaners, protectants, & adhesives FOAM TO: Fabric

Aerosol Spray

Part #

74 Spray

ADHAE1021

76 Spray

ADHAE1031

80 Supertrim

ADHAE1041

470 Feather-Spray

ADHAE1011

JEF Bond 88

ADHAE1118

JEF Bond 99

ADHAE1119

74 Spray

ADHAE1021

76 Spray

ADHAE1031

476 Spray

ADHAE1132

JEF Bond 88

ADHAE1118

74 Spray

ADHAE1021

metal, plastic) 76 Spray

ADHAE1031

Foam:

Surfaces (wood,

470 Feather-Spray

ADHAE1011

476 Spray

ADHAE1132

JEF Bond 88

ADHAE1118

JEF Bond 99

ADHAE1119

FABRIC & UPHOLSTERY VINYL TO:

Fabric

Surfaces (wood,

Aerosol Spray 76 Spray

ADHAE1031

470 Feather-Spray

ADHAE1011

476 Spray

ADHAE1132

JEF Bond 99

ADHAE1119

76 Spray

ADHAE1031

metal, plastic) 470 Feather-Spray

INDUSTRIAL PVC TO:

PVC Surfaces (wood, metal, plastic)

Part #

ADHAE1011

476 Spray

ADHAE1132

JEF Bond 99

ADHAE1119

80 Supertrim

ADHAE1041

Aerosol Spray

Part #

80 Supertrim

ADHAE1041

80 Supertrim

ADHAE1041

Aerosol Spray

Part #

Carpet to Surfaces: 80 Supertrim

ADHAE1041

JEF Bond 99

ADHAE1119

Rubber, Leather and 80 Supertrim Self to Surfaces

ADHAE1041

TIPS ON ALL ADHESIVES Many two surface adhesives like contact cement allow a tack time but once the pieces are touched together, there is no chance of shifting or adjusting them. For larger areas, once the contact cement has been applied, place wax paper in overlapping sheets over the entire surface. Then position the piece to be bonded. It can be moved around a bit on the wax paper sheets. When properly aligned remove one sheet of the wax paper at a time. Whenever possible work from the center out. When all the wax paper has

been removed, apply whatever bonding pressure is recommended with the particular adhesive. Hot melt adhesives can cool prior to bonding large surfaces. If possible, pre-heat the surface itself using a hot air heat gun. This will provide a longer working time for successful adhesion. NO TE: Use proper judgment when using this method. Preheating may damage material being used. Never use a hot air heat gun to speed drying time of adhesive product: many adhesives are flammable.

marine - awning - upholstery supplies | 141

Aerosols & Protectants Applications Chart The following is a quick reference to help select the right product for the right job. The products listed are the manufacturers’ recommendations. See the full product descriptions throughout the catalogue for more information. Note: Some of the products perform more than one function (i.e. clean, polish, protect).

SURFACE PREPARATION

Product

Part #

Upholstery & Trim Vinyls

Vinyl Prep

AERCL9646

Hard and Semi-Hard Plastics

Sand Free

AERCL9648

Unsandable Metal/Fiberglass

Sand Free

AERCL9648

Unsandable Textured Surface

Sand Free

AERCL9648

COLOR CHANGE

Product

Part #

Upholstery Vinyls, Leather

SEM Vinyl Coat

See p.147

Auto Trim Carpet Sections

SEM Vinyl Coat

See p.147

Hard and Semi-Hard Plastics

SEM Vinyl Coat

See p.147

PROTECTANT

Product

Part #

Awnings (Sunbrella Acrylic)

303 Fabric Guard

See p.154

Color Coated Vinyls

SEM Vinyl Coat Clear

See p.147

Vinyls, Hard and Semi-Hard Plastics

Stamoid Vinyl Protectant

CLEST7094

Upholstery Fabrics (most)

303® Aerospace Protectant

See p.154

303 Fabric Guard

See p.154

Canvak

AERPR7199

Canvas

303® Fabric Guard

See p.154

Carpet

303 Fabric Guard

See p.154

Fiberglass

Metal Polish

CLEIO7109

Multi-Use

Aqua-tite Green

AERPR7166

Iosso Repellent

AERPR7103

Metal Polish

CLEIO7109

Sewn Seams

Iosso Seam Sealer

AERPR7106

Plastic Windows

Klear-to-Sea

CLEPL7168

IMAR Strataglass Protective Polish

CLEST7091

ADHESIVES: AEROSOLS

74 FOAM AND FABRIC ADHESIVE

476 SPRAY ADHESIVE

Permanently bonds foam and a wide range of fabrics to wood, rigid plastic or themselves. Ideal for foam backed fabrics such as display fabrics or headliners. Easily controlled spray pattern. Works very well on both urethane and latex foams and delivers a soft glue line. High solids, high coverage rates. Dries tack free and odor free.

ADHAE1021

Quick tacking and fast curing to ensure a strong and permanent bond. The unique product formulation and adjustable 3-way valve work together to provide optimum spray control for any application. Engineered to minimize wasteful soak-in. Adjustable nozzle eliminates overspray and gives smooth, even coverage. This new formula eliminates all ozone depleting substances and chlorinated solvents. It is safer to use and better for the environment.

74 Foam Fabric Adhesive Can Size: 17.25 oz. (489 g)

Price Breaks: Each | Box (12 ea)

ADHAE1132

Can Size: 13.12 oz. (375 g)

76 SPRAY ADHESIVE

Price Breaks: Each | Box (12 ea)

Non-misting adhesive. Features a unique lace-like spray pattern to allow you to vary spray width and rate, giving you the control to spray to the edge without going over. All purpose adhesive for upholstering and trimming/fitting. Not recommended for Styrofoam.

ADHAE1031

JEF BOND 88

Effective and economical alternative to higher priced products. Designed to bond urethane foams and fabrics to metals, supported vinyls, wood, paper and leather. It has a unique lace spay pattern offering low soak in for a soft pliable bond. It has a fan spray tip for controlled placement of the glue. This product offers a fast tack while being economical for the user. For best results, surfaces must be clean and dry and temperatures above 18Â°C (65Â°F).

76 Spray Adhesive Can Size: 16.2 oz. (460 g) Price Breaks: Each | Box (12 ea)

470 FEATHER-SPRAY

Provides a strong tack and builds strength quickly. It is an all purpose feather spray adhesive, excellent for bonding to multiple surfaces. An efficient and economical solution for your bonding needs.

ADHAE1011

476 Spray Adhesive

ADHAE1118

JEF Bond Spray Adhesive Can Size: 12 oz. (340 g) Price Breaks: Each | Box (12 ea) | Case (60 ea)

470 Feather-Spray Can Size: 13.12 oz. (375 g) Price Breaks: Each | Box (12 ea)

E A

TIPS 76 SPRAY ADHESIVE: Allow up to 10 minutes join time with single surface applications, and up to 60 minutes when applied to both surfaces. 80 Supertrim Adhesive: Faster drying than traditional contact cements, with a tack range up to 30 minutes.

marine - awning - upholstery supplies | 143

ADHESIVE APPLICATION CHART The following is a quick reference to help select the right product for the right job. The products listed are the manufacturers’ recommendations. See the full product descriptions throughout the catalogue for more information. Note: Some of the products perform more than one function (i.e. clean, polish, protect).

FOAM TO:

Product

Part #

Foam

JEF Bond 99

1119

Fabric

JEF Bond 99

1119

Other JEF Bond 99 Surfaces

1119

VINYL TO: Fabric

Product

Part #

JEF Bond 99

1119

Wood, Metal, JEF Bond 99 Plastic

1119

OUTDOOR/MARINE CARPET TO: Wood, Metal, Plastic

RUBBER AND LEATHER TO:

Product

Part #

80 Supertrim Adhesive

1041

Product

Part #

Rubber, Leather, Wood, 80 Supertrim Adhesive Metal, Plastic

INDUSTRIAL PVC TO:

Product

1041

Part #

PVC 80 Supertrim

1041

HH-66

See pg. 144

Wood, Metal, 80 Supertrim Plastic

1041

HH-66

See pg. 144

TRANSPORTATION OF DANGEROUS GOODS Some adhesives fall under the Transportation of Dangerous Goods Act. While this does not prohibit the shipping of these items, there are charges incurred by various carriers in order to cover the expense of the administrative and special handling requirements of the act. These items will have a Dangerous Goods Handling Fee attached to them. This fee will vary from carrier to carrier; the Customer Service Center can inform you at the time you place your order of the amount of surcharge, if applicable.

ADHESIVES: VINYLS VINYL ADHESIVES—HH-66 VINYL CEMENT

Specialist in PVC tarpaulin materials. This product features exceptional bond strength. Brushes smooth and dries fast. Ready in minutes.

Waterproof, good resistance to weather and temperature extremes, chemicals, oils, fuels and grease. Can be used for fabricating, repairing, sealing stitches/seams, etc. Remains flexible. A superior quality vinyl adhesive that really works.

A B

ADHBU1166

HH-66 Adhesive—8 oz. (237 ml)

ADHBU1164

HH-66 Adhesive—4 oz. (118 ml) C

Price Breaks: Each | Case (12 ea)

ADHBU1181

HH-66 Thinner—1 gal. (3.8 L) Price Breaks: Pail | Case (6 pails)

144 | marine - awning - upholstery supplies

ADHESIVES: TRIM TRIM ADHESIVES A

ADHAE1041

80 Supertrim Adhesive—18oz. (510 g) Spray adhesive from 3M for rubber and vinyl is a highstrength neoprene contact adhesive. Excellent heat resistance, maintaining strength at temperatures up to 93°C (200°F). For full applications chart, see p.141. Not recommended for polyethylene or polypropylene. Faster drying than traditional contact cements, with a tack range up to 30 minutes. It will not break down with heat or water, so it is ideal for heavy-weight headliners, hood silencer pads and vinyl tops. Contains no ozone-depleting ingredients.

Price Breaks: Each | Case (12 ea)

ADHAE1119

JEF Bond 99 Trim Adhesive—12 oz. (340 g) JEF Bond 99’s unique lace spray pattern offers low soak-in for a better, soft, pliable bond. Its fan spray tip allows for controlled placement of the glue. This product is fast-tacking and offers higher temperature resistance than most pressure-sensitive adhesives. For full applications chart, see p.141. Not recommended for non-backed vinyl fabric. Do not use on plasticized vinyl or copper. Complete directions are listed on the can.

Price Breaks: Each | Case (12 ea)

marine - awning - upholstery supplies | 145

ADHESIVES: BULK FOAM TO: Fabric

Foam

Surfaces (wood,

Aerosol Spray

Part #

Fastbond

ADHBU1122

Helmiprene

ADHBU1140

JEF Bond 2000

ADHBU1145

Fastbond

ADHBU1122

Helmiprene

ADHBU1140

JEF Bond 2000

ADHBU1145

Fastbond

ADHBU1122

metal, plastic) Helmiprene JEF Bond 2000

FABRIC & UPHOLSTERY VINYL TO:

Fabric Surfaces (wood, metal, plastic)

Bulk - Liquid 504 Latex

ADHBU1110

504 Latex

ADHBU1110

Bulk - Liquid

ADHBU1140

Gimps to Wood or 504 Latex Fabric Glue Sticks

ADHBU1145

Part #

Part # ADHBU1110 ADHBU1153

TRANSPORTATION OF DANGEROUS GOODS ACT Some of the bulk adhesives fall under the Transportation of Dangerous Goods Act. While this does not prohibit the shipping of these items, there are charges incurred by various carriers in order to cover the expense of the administrative and special handling requirements of the act. These items will have a Dangerous Goods Handling Fee attached to them. This fee will vary from carrier to carrier; the Customer Service Center can inform you at the time you place your order of the amount of surcharge, if it is applicable.

LATEX ADHESIVE*

A primary application of cementing fabrics to almost any other material, wood or metal. Firmly retains decorative scroll gimps in complex patterns and shapes. The squeeze tube container design allows careful placement of adhesive only where required. Water resistant.

ADHBU1110

504 Latex Adhesive Bottle Size: 17 oz. (500 ml) Price Breaks: Each | Box (12 ea) * Available in 1 gallon (4.5 L) jug on special order.

B A

FASTBOND™ FOAM ADHESIVE 100

3M Fastbond Foam Adhesive 100 is a one-part, water-dispersed, fast setting adhesive. This neoprene-based product bonds many porous substrates to porous or non-porous substrates with minimal drying time. Adheres to many types of fl exible polyurethane foam, latex foam fabric, polyester fiberfi ll, wood, plywood, particleboard and many plastic and metal surfaces.

ADHBU1122

Fastbond™ Foam Adhesive 100—5 Gal. (18.9L) Price Break: Pail | 5 pails | 10 pails

PRODUCT KNOWLEDGE ON 3M™ FASTBOND™ FOAM ADHESIVE 100 Fast tacking to help speed component assembly. Holds seams and curves within 15 seconds. 20 minute open time for repositioning after initial tack and to meet various assembly process requirements. Spray multiple components at one time for efficient assembly. Better value due to exceptionally high coverage. Long lasting 3M™ Fastbond™ gives yields up to 1000 ft2/ gallon. One gallon (3.8 L) provides the same coverages as 3–4 gallons (11.4–15.1 L) of solvent adhesive. Only 10 psi of pressure is needed for spraying, allowing for a thinner coat of adhesive. NOTE: This product is not freeze-thaw stable. Winter shipping presents a freezing hazard. Best storage temperature is between 15–27°C (60–80°F). Only stainless steel equipment is recommended, anything else will be prone to rusting.

146 | marine - awning - upholstery supplies

AEROSOL FINISHES: MOHAWK SPRAY STAINS

AERST7194

Satin Black

AERST7221

Red Mahogany

Specially formulated for a professional finish. Unfinished and finished wooden arms, legs, scuffed and rubbed through areas can be finished or refinished with ease. This product is economical, easily applied and dries quickly.

AERST7178

Dark American Walnut

AERST7195

Gloss White

Size: 13 oz. (365 g)

AERST7188

Cherry

AERST7181

Med. Brown Walnut

Price Breaks: Each | Case (12)

AERST7185

Brown Mahogany

AERST7197

Raw Umber

AERST7189

Flat Black

AERST7191

Gloss Black

AERST7161

Clear Satin

AERST7184

Clear Flat

AERST7160

Clear Gloss

FINISHING SPRAY

For sealing and finishing wood stains. Can Size: 13 oz. (365 g)

AERST7183

Medium Mahogany

AERST7193

Burnt Umber

AERST7179

Extra Dark Walnut

AERST7180

Dark Mahogany

Price Breaks: Each | Case (12)

SAND SEALER

Fills in and levels surface scratches, burn-in repairs and smooths fresh-padded repairs. Fast drying, easy sanding, high solids for rapid build up. Seals in stains prior to final top coat of finish for faster build up. AERST7162

Sanding Sealer

BLUSH ERASER

Humid or cold weather can cause a finish to turn white or “blush.” This aerosol spray will eliminate the “blushing” without changing the existing sheen of the lacquer top coat. Spray over the blushing finish and watch the white fade away. AERST7174

Blush Eraser Can Size: 13 oz. (365 g) Price Breaks: Each | Case (12)

Can Size: 13 oz. (365 g) Price Breaks: Each | Case (12)

VINYL COAT SEM COLOR COAT

SEM Color Coat is a solvent-based, elastomeric product formulated for aerosol application to renew or change the color of any vinyl, since it is a coating, not a dye. Meant to be used with SEM’s Sand Free plastic preparation product (#AERCL9648, p.148). Finish with SEM’s Vinyl Clear Coat Finishes for long-lasting durability.

Price Breaks: Each (12 oz. or 340 g) | Box (6 ea)

AERVI9658

25 Titan Metallic

AERVI9680

12 Santa Fe

AERVI9636

Silver Metallic

AERVI9604

06 Burgundy

AERVI9597

Gloss Black

AERVI9611

11 Firethorn Red

AERVI9689

45 Gloss White

AERVI9622

00 Phantom White

AERVI9599

Satin Black

AERVI9662

27 Napa Red

AERVI9673

60 Sailcloth White

AERVI9616

18 Warm Grey

AERVI9600

01 Landau Black

AERVI9606

09 Light Buckskin

AERVI9663

31 White

AERVI9682

39 Medium Gray

AERVI9640

16 Presidio

AERVI9678

64 Pacific Blue

AERVI9614

17 Camel

AERVI9601

36 Portola Red

AERVI9668

30 Graphite

AERVI9610

10 Super White

SEM VINYL FINISHES W

AERVI9654

Low Luster Clear

AERVI9656

High Gloss Clear

AERVI9679

01 Satin Gloss Clear

marine - awning - upholstery supplies | 147

SEM PRE-COLOR TREATMENTS A

AERCL9646

SEM Vinyl Prep—15.5 oz. (439 g) Ensures full adhesion of the SEM Color Coat line. Cleans the vinyl surface of all traces of wax and grease. Also creates a slight softening of the vinyl film to ensure that the Color Coat gets a good “tooth.” Rinse with water and allow to dry. Price Breaks: Each | Box (6 ea)

AERCL9648

SEM Sand Free—13 oz. (369 g) Sand Free is a blend of rich solvents that promote adhesion on plastic parts. It also eliminates sanding on hard-to-reach areas (e.g. door jams, under hoods, trunk, etc.). For best results, wash area first with soap and water. Then apply Sand Free directly to the surface to be painted. Price Breaks: Each | Box (6 ea)

TIPS FOR USING SEM SAND FREE Apply a light “dry” coat of Sand Free before painting. Avoid heavy applications as they will cause runs or sags. Do not allow Sand Free to dry completely before application of color coats. If Sand Free has completely evaporated, the pores of the substrate will be closed, which will result in a loss of adhesion. Follow the Sand Free layer with a coat of Color Coat or paint while Sand Free is still wet. After the first color or paint coat is dry, continue with normal painting procedures.

LUBRICANTS LUBRICANTS & SILICONES

An economical, all-purpose lubricant that stops squeaking, sticking, binding and slows corrosion. Use on any surface, such as metal, glass, rubber, plastic, painted finishes and fabrics. Non-staining and non-toxic. Can be used on food product equipment, sewing and cutting equipment to reduce drag. Helps fight rust on dies, rubber molds and precision equipment. Can be used to ease cover placement on foam cushions.

E F

Price Breaks: Each | Box (24 ea) | Case (60 ea)

AERSI7175

JEF Spray Silicone—14 oz. (400 g)

SILICONE—SLUYTER GRIP SLIP

A multipurpose lubricant and foam release that will not interfere with post-finishing operations. Maintain adequate ventilation in work area. Store in a cool dry place away from excess heat.

Price Breaks: Each | Box (12 ea)

AERSI7182

Grip Slip Paintable Silicone—14 oz. (400 g)

SILICONES—SLUYTER SUPER SLIP

A widely-used lubricant for sewing, cushion stuffing and cutting tables. Use on foams and paddings, inside covers for ease of placing cushions, on needles, feed plates and table surfaces. Use on blades, tables and dies for cutting. Invisible product leaves no trace on fabrics. Also invaluable as a general lubricant for joints, hinges, sliders, blades, etc. Can be used to waterproof electronics and ignition systems on automobiles. Anywhere friction is causing problems, silicone can be used to reduce it.

AERSI7171

Super Slip Silicone—14 oz. (397 g) Price Breaks: Each | Box (24 ea) | Case (60 ea)

148 | marine - awning - upholstery supplies

IOSSO® E-Z SNAP® LUBRICANT

E-Z Snap lubricates, waterproofs, protects and reduces friction on snaps, zippers, hinges and hardware. This is a non-staining, non-solvent nonsilicone, non-toxic formula. An easy-to-place gel that will not run. Place one drop in the head of the snap, then close and open a few times. Place a few drops down the center of a zipper. Work the zipper a few times to distribute the lubricant. If removal is necessary, use the Iosso® Safe-T-Solve (#7113, p.121) and wash as usual.

AERCL7108

Iosso® E-Z Snap® Lubricant—1.5oz (42.5g) Price Breaks: Each | Case (24 ea)

CLEANERS

MARINE WINDOW

This environmentally safe product eliminates the necessity for multiple cleaners. It safely cleans and protects glass and plastics. It is anti-static and anti-fog, fills in minor scratches and imperfections, protects from salt spray damage and cleans with no streaks or smudging. Use on mirrors, glass, plastics, clear vinyls, Plexiglas, and Lexan.

CLEPL7168

G D

IMAR STAMOID CLEANER

Gently but thoroughly cleans Stamoid and other marine vinyls. Frequent use is recommended, particularly in areas of environmental pollution. Application of Stamoid Marine Vinyl Protective Spray (#7094) between cleaning will ensure the vinyl’s like-new appearance.

CLEST7096

#603 Stamoid Vinyl Cleaner—16oz. (473ml) Price Breaks: Each | Box (6 ea) | Case (12 ea)

Klear-to-Sea—16 oz. (473 ml) Price Breaks: Each | Box (6 ea) | Case (12 ea)

IMAR STAMOID PROTECTIVE CREAM

303 ® MULTI-SURFACE CLEANER

Ultimate cleaning power with no residue. Safely brightens and rejuvenates surfaces. Removes oils, grease, ink, liquids and much more! Safe for all water-safe materials.

CLEAC7202

303® Multi-Surface Cleaner—32oz. (950ml) Price Breaks: Each | Box (6 ea) | Case (12 ea)

IMAR STRATAGLASS CLEANER AND POLISH

Both the Strataglass Protective Cleaner (#CLEST7090) and Protective Polish (#CLEST7091) are formulated to clean, shine and protect Strataglass and the Strataglass scratch-resistant protective coating. Using the Protective Cleaner frequently between polishing will rejuvenate the protective qualities of the Protective Polish.

CLEST7090

Strataglass Protective Cleaner—16 oz. (473 ml) Special UV inhibitors extend the life of Strataglass by minimizing the deteriorating effects of sunlight. Safe to use daily. Price Breaks: Each | Box (6 ea) | Case (12 ea)

CLEST7091

Cleans, shines and protects marine vinyl. A polymer-based formula designed to protect Stamoid and other vinyl in marine environments, while ensuring the retention of like-new suppleness and luster. With UV protection, static resistance and life-extending plasticizers, this proprietary formulation causes molecular bonding which creates a nearly-invincible protective barrier. Recommended usage ever 2–3 months.

CLEST7092

#601 Stamoid Vinyl Protective Cream—16 oz. (473 ml) Price Breaks: Each | Box (6 ea) | Case (12 ea)

IMAR STAMOID VINYL PROTECTIVE SPRAY

Cleans, shines and protects Stamoid Marine vinyl and works equally well on similar vinyl products. UV protection, coupled with the rejuvenation effects of included plasticizers, helps defeat age-induced brittleness and assures a longer product life. Enhances the protective qualities of Stamoid Marine Protective Cream (#CLEST7092).

CLEST7094

#602 Stamoid Vinyl Protective Spray—16 oz. (473 ml) Price Breaks: Each | Box (6 ea) | Case (12 ea)

Strataglass Protective Polish—16oz. (473 ml) Strataglass Protective Polish is recommended for use every 2–3 months. In areas of high fallout, use ever 4–6 weeks. Price Breaks: Each | Box (6 ea) | Case (12 ea)

marine - awning - upholstery supplies | 149

PROTECTANTS

D A

C B

FABRIGARD™—SLUYTER

Water and stain repellent, specifi cally developed for protecting fabric fi bers from stains, water, smoke, dirt and clinging odors. Used on all types of carpets, upholstery and linens.

AERPR7167

FabriGuard™—11 oz. (300 g) Price Breaks: Each | Box (12 ea)

SCOTCHGARD™

Scotchguard™ is a world famous protectant from 3M. It is the easy-touse odor free protectant that causes spills and liquids to blot up before they can turn into stains. 100% free of CFC’s and ozone depleting chemicals, will not change the look, feel or breatheability of fabric. Versatile, invisible protection for new or freshly cleaned upholstery.

AERPR7177

Scotchgard™—10 oz. (283 g) Price Breaks: Each | Box (6 ea)

303 ® FABRIC GUARD

Professional grade water repellency technology. Manufacturerapproved and tested. Resists soiling and helps to impede mildew formation. Protects all indoor and outdoor fabrics, carpet and upholstery. Can be used on all natural/synthetic fi ber, solution-dyed acrylic, carpeting, upholstery, patio furniture and auto interiors.

B C

AERPR7157

AERPR7158

LEATHER CARE—VINYL & LEATHER CONDITIONER

Sluyter’s Leather Care safely cleans and restores lustre to vinyl and leather fi nishes. The foaming action of this non-solvent based formulation penetrates and eliminates dirt and grime effectively, and leaves a lustrous protective fi lm on applied surfaces.

303® Fabric Guard™—16 oz. (473 ml) Price Breaks: Each | Box (6 ea)

Price Breaks: Each | Box (6 ea) | Case (12 ea)

303® Fabric Guard™—1 Gal. (3.79 L) Price Breaks: Each | Box (4 ea) | Case (12 ea)

AERPR7081

Leather-Care Vinyl and Leather Conditioner—14oz. (396ml)

SCOTCHGARD™ TIPS This special formula for furniture fabrics covers 16–28 ft 2 of heavy weight fabrics and 30–40 ft 2 of light weight fabrics per can. Some shiny surface fabrics, such as nylon may require lighter applications. Use on natural and synthetic fibres. Not recommended for silk, wool, velvet, leather, vinyl, suede or carpets.

303 FABRIC GUARD—THE SUNBRELLA SPECIALIST

Exceeding Expectations Since 1980

World’s most powerful and longest lasting fabric protector in a ready-to-use formula. Lasts up to 3 years. Protects new and cleaned fabric from water, dirt and grease to keep indoor and outdoor fabrics looking new. Sunbrella® recommends this fluorocarbon treatment for reproofing over silicone base products.

150 | marine - awning - upholstery supplies

Will not change feel, color or breathability. Non-toxic and odorless when dry. One bottle will protect up to 40ft2 of lightweight fabric. Not recommended for plastic, vinyl, fiberglass or imitation suede.

CRYPTON ® CARE: CLEANERS & PROTECTANTS FABRIC REFRESHER

The Fabric Freshener is a professional strength, ready-to-use product that removes odors on fabrics. It is a neutral quaternary disinfectant on non-porous surfaces and is engineered to safely clean and leave upholstery and any room smelling fresh and clean. Price Breaks: Each | Box (6 ea) | Case (12 ea)

CLEFA7069

Crypton® Care Deodorizing Mildew Resistant Fabric Refresher—32 oz. (946 ml)

CRYPTON CARE STAIN REMOVERS ®

A professional strength, ready-to-use spot cleaner that is built to remove tough stains like blood, grass, food and beverage stains. Apply this Crypton ® Care upholstery cleaner to the spot and lightly agitate. Blot up the solution with a clean, dry towel. Finally, rinse free with water.

LEATHER & VINYL—PROTECTOR & RESTORER

These products are specially formulated to safely clean treated leather and vinyl with natural degreasers. After cleaning, restorer is designed to replenish natural oils. Wipe on the restorer with a clean, dry cloth to instantly provide beauty and luster. Protector and Restorer sold together. Price Breaks: Each | Box (6 ea) | Case (12 ea)

CLEFA7070

CLEFA7073

Crypton® Care Leather & Vinyl Cleaner and Restorer—32 oz. (946 ml)

CRYPTON ® UPHOLSTERY STAIN REMOVAL KIT Price Breaks: Each | Box (6 ea) | Case (12 ea)

Price Breaks: Each | Box (6 ea) | Case (12 ea)

CLEFA7082

CLEFA7083

Crypton® Upholstery Stain Removal Kit

Crypton® Care Ink/Grease/Oil Stain Remover—24 oz. (710 ml) Crypton® Care Food/Beverage/Protein Stain Remover—24 oz. (710 ml)

C B

FABRIGUARD KNOWLEDGE & TIPS FabriGuard can be used on rain wear, clothing, canvas, shoes, cushions, tablecloths, upholstered furniture, automobile seat and trim, carpeting, suede, velvet and leather. It penetrates the material, surrounds the fibres, protecting it from stains and clinging odors. Spray overlapping sweeps 6–8” from fabric, let dry overnight. Test for water beading with a few drops. If water soaks in, reapply FabriGard. Coverage depends on the weight and absorbency of material being treated.

marine - awning - upholstery supplies | 151

™

Design + Performance is a trademark and Sunbrella is a registered trademark of Glen Raven, Inc. ®

Good business is built on trust, reliability and respect. Sunbrella delivers the ®

best performing marine fabrics, responsive customer support and the industry’s leading warranty. So your customers never question your commitment.

152 | upholstery supplies

SU N B R E L L A .CO M

WATER REPELLENT FINISH AQUA-TITE ® GREEN WATER REPELLENT

Aqua-Tite ® is a premium grade dual-action water and stain repellent. Eco-friendly green and clean technology product. Lower levels of VOCs (Volatile Organic Compounds) than current regulations. Use on awnings, boat covers, canvas, tarpaulins, outdoor furnishings and any synthetic or natural fi ber fabric (acrylic, cotton, nylon, polypropylene, polyester, leather and cotton blends).

One gallon of this product covers 500–700 ft 2, depending on absorbency of fabric. Water drops just “bead and roll off” AquaTite ® treated products. Aqua-Tite ® provides outstanding protection against aqueous-based stains such as soda and grape juice. It also resists dirt and oil-based stains such as animal droppings, motor oil and lubricants while enhancing the tone of the fabric. Aqua-Tite ® has very good durability to outdoor weathering. Aqua-Tite® Green Water Repellent—32 oz. (946 ml) A AERPR7166 Price Breaks: Each | Box (12 ea)

AERPR7165

Aqua-Tite® Green Water Repellent—1 gal. (3.8 L) Price Breaks: Each | Box (6 ea) | Case (12 ea)

ENDUREPEL™ – LONG LASTING PROTECTION Endurepel™ is Ennis Fabrics’ exclusive range of performance fi nishes, that are applied to woven fabrics and PU textiles, with applications across a wide range of markets. The protective film forms an invisible, stain-resistant coating around the textile fibers or on top of the PU skin. Endurepel makes furniture easier to clean and features anti-microbial and anti-bacterial properties. Shop our extensive range of Endurepel™ finished products; Endurepel™ Fundamentals, Stability II, Stability III, Premier, and all other future collections at ennisfabrics.com.

EASY CLEANABILITY | REPELS LIQUID | STAIN RESISTANT marine - awning - upholstery supplies | 153

303 ® PROTECTANTS 303 ® AEROSPACE PROTECTANT

303 ® Aerospace Protectant provides the ultimate sun-blocking technology that keeps items looking new and lasting longer. It protects vinyl, synthetic/natural rubber, plastic, painted surfaces, tonneau covers, fi nished leather, gelcoat fi berglass, RV awnings, EPDM, pressedpolished sheet, engine hoses, boat seats and fenders, door and trunk seals, infl atable boats, all-weather wicker, and patio furniture frames.

C D

AERPR7303

303® Aerospace Protectant—16 oz. (473 ml)

AERPR7302

303® Aerospace Protectant—32 oz. (946 ml)

AERPR7304

Price Breaks: Each | Case (6 ea)

303® FABRIC GUARD

303® Aerospace Protectant — 1 Pail = 1 gal. (3.8 L) Price Break: Pail | Box (4 Pails) | Case (12 Pails)

AERPR7157

AERPR7158

303® Fabric Guard™—16 oz. (473 ml) Price Breaks: Each | Case (6 ea) 303® Fabric Guard™—1 Pail = 1 gal. (3.8 L) Price Breaks: Pail | Box (4 pails) | Case (12 pails)

IOSSO® PROTECTANTS: WATER REPELLENT Iosso ® Water Repellent is effective on all fabrics. It protects fabric from water, soils, oils, bird droppings and environmental pollutants. It resists mildew and stains and increases weatherability. It will not change the color, feel or breathability of the fabric. Recommended for use on awnings, canopies, tents, patio furniture cushions, umbrellas, spa covers, tarps, boat covers, bimini tops, hunting fabrics, camping gear, leather synthetics and vinyls. Solution is ready-to-use or concentrated in a nonsolvent and non-silicone formula.

IOSSO ® WATER REPELLENT F

AERPR7105

Iosso® Water Repellent Concentrate—1 Pail = 1 gal. (3.8 L) One gallon of concentrate makes 5 gallons of mixed solution for total coverage of 780ft 2. Price Break: Pail | Box (4 pails) | Case (12 pails)

AERPR7104

Iosso® Water Repellent Ready-to-Use—1 Pail = 1 gal. (3.8 L) Price Break: Pail | Box (4 pails) | Case (12 pails)

AERPR7103

Iosso® Water Repellent—32oz. (990 ml) Price Breaks: Each | Case (6 ea)

154 | marine - awning - upholstery supplies

SEAM SEALER Ideal for boat covers, awnings, tents, backpacks and almost any other situation where a water-tight seam is required. Seam Sealer will not change the look or feel of your fabric. For best results, use with cotton, cotton-blends, polyester and synthetic woven fabrics. While Seam Sealer may be used on vinyl-coated or laminated fabrics, the water repellency will vary.

IOSSO ® SEAM SEALER A

AERPR7107

Iosso® Seam Sealer—1 Pail = 1 gal. (3.8 L) Price Break: Pail | Box (4 Pails) | Case (12 Pails)

AERPR7106

Iosso® Seam Sealer—4oz. (118 ml) Price Breaks: Each | Case (12)

IOSSO® CLEANERS: MILDEW STAIN REMOVER

Clean mold, mildew, dirt and algae stains from virtually every boat surface. Just add water to the biodegradable powder and soak the solution into the soiled areas. Can be used on vinyl, plastic, canvas, carpeting, wood, fiberglass, painted surfaces, sails and accessories. Please Note: 12 oz. (340 g) jar makes 3 gallon (11.4 L) of solution. 65oz (1.84 kg pail makes 16 gallons (60.6 L) of solution.

IOSSO ® MILDEW STAIN REMOVER C

CLEIO7101

CLEIO7100

Iosso® Mildew Stain Remover Concentrate—Pail = 65 oz. (1.84 kg) Price Break: Pail | Box (4 Pails) | Case (8 Pails) Iosso® Mildew Stain Remover Concentrate—12 oz. (340 g) Price Breaks: Each | Case (6 ea)

METAL POLISH A quick and easy application that leaves a brilliant, shiny protective coating. Can be used on brass, copper, chrome, stainless steel, aluminum, magnesium, silver, gold, porcelain, fiberglass, Plexiglas, hard plastics and painted surfaces.

IOSSO ® METAL POLISH E

CLEIO7109

Iosso® Metal Polish—3 oz. (85 g) Price Breaks: Each | Case (12 ea)

156 | marine - awning - upholstery supplies

The Trusted Leader in Coated Fabrics

Beautiful. Durable. Antibacterial. Stain-resistant.

888-646-2542 | CS@Nauga.com | www.naugahyde.com

orders an 1-800-333

fax: 1-205-985

AU TO | M A RINE

e-mail: sales@spr

url: www.sprad

Made exclusively for Spradling Internation

S P R AD L I N G V I N Y L. C OM 158 | upholstery supplies

GENERAL CARE & CLEANING CODES MSWD Mild soap and water. Dry immediately with a soft, dry cloth S Clean fabrics with Pure Solvents (Petroleum Distillate-Based Products) W Clean fabrics with water-based cleaning agents or water based foam WC Wash With Care WS Clean fabrics with water-based cleaning agents only do not use solvent cleaners X Clean fabrics with vacuum or brushing only

CRYPTON PRODUCTS: FABRICATION, CARE & CLEANING While the performance features of Crypton Fabric make it easy to clean, it is not self-cleaning. Use the simple instructions below to clean. Spot cleaning 1. Blot any excess liquid; wipe away excess mess with a dry, clean towel. 2. Mix together a simple soap and water solution. We recommend mixing 1/4 teaspoon enzyme laundry or dish detergent, like Tide ®, Cheer ® or Dawn ®, with 1 cup warm water. 3. Apply the solution and agitate with a soft bristle brush. Make sure to brush lightly and work from the outside of the stain inward so as not to spread the stain. Rinse your sponge or brush frequently. 4. Blot with a clean towel and rinse. Repeat if necessary. 5. And remember, soap attracts dirt so make sure to rinse thoroughly. 6. Allow fabric to air dry. Crypton Cleaners, for stubborn stains Using our 25 years of expertise in the science of stain, moisture and odor resistance, Crypton has created a line of strong, environmentally conscious, effective cleaners and care products for upholstery. While most stains will clean with a simple soap-and-water solution, you may prefer to use Crypton’s ready-to-use cleaners which are water-based and designed to easily break down tough stains. Visit www.crypton.com to purchase Crypton Cleaners. Extraction cleaning, for medium, ground-in stains and overall yearly maintenance For overall cleaning, we recommend periodically extracting upholstered surfaces using hot water extraction. Please note that no fabric is indestructible. Stains such as permanent marker, lipstick, nail polish, etc. may not be completely removable.

upholstery supplies | 159

SUNBRELLA® PRODUCTS: FABRICATION, CARE & CLEANING Sunbrella ® is made from 100% Sunbrella ® acrylic fibre which gives it a color brightness that is unsurpassed. Sunbrella fabrics have a 10 year limited warranty for shade and marine fabric and 5 year limited warranty for furniture fabrics, guaranteed for a period of 5 years against loss of color or strength from normal exposure conditions including sunlight, mildew, rot and atmospheric chemicals.

CARE & CLEANING

One of the best ways to keep Sunbrella ® fabrics looking good and to delay deep or vigorous cleaning is to properly maintain the fabrics. This can be accomplished by simply brushing off dirt before it becomes embedded in the fabrics, wiping up spills as soon as they occur or spot cleaning soon after stains occur. Wh en cleaning Sunbrella ® fabrics, it is important to observe the following: • A lways use a mild soap such as Ivory Snow, Dreft or Woolite. • Water should be cold to lukewarm. • Rinse thoroughly to remove all soap residue. • Air dry only. Never apply heat to Sunbrella ® fabrics.

GENERAL OR LIGHT CLEANING

To clean Sunbrella ® while still on an awning frame, follow these simple steps:

1. Brush off loose dirt. 2. Hose down. 3. Prepare a cleaning solution of water and mild soap such as Ivory Snow, Dreft or Woolite (no detergents). 4. Use a soft bristle brush to clean. 5. Allow cleaning solution to soak into the fabric. 6. Rinse thoroughly until all soap residue is removed. 7. Air dry.

May not require re-treatment depending on the age of the fabric. If stubborn stains persist, you can use a diluted chlorine bleach/soap mixture for spot cleaning of mildew, roof run-off or other similar stains (see our Stain Chart for specific recommendations: http://cdn.glenraven.net/sunbrella/_pdf/en_us/stain-chart.pdf).

HEAVY CLEANING FOR STUBBORN STAINS AND MILDEW

Sunbrella ® fabric does not promote mildew growth, however, mildew may grow on dirt and other foreign substances that are not removed from the fabric. To clean mildew, or other stubborn stains:

1. Make a solution of 8 oz. (1 cup) of chlorine bleach, 2 oz. (¼ cup) of mild soap and/or detergent, 1 gallon of water. 2. Clean with soft bristle brush. 3. Allow mixture to soak into fabric for up to 15 minutes. 4. Rinse thoroughly until all soap residue is removed. 5. Air dry.

Repeat if necessary. Re-treatment of fabric for water and stain resistance will be necessary. Remember to protect the area around your Sunbrella ® if using a bleach solution. Carpet or other fabrics that are not Sunbrella ® may have an adverse reaction to the bleach.

WASHING MACHINE

RE-TREATING THE FABRIC APPLYING 303 ® FABRIC GUARD

If an awning is suitable in size for a washing machine, these steps should be followed:

1. Use mild soap and/or detergent. For heavier stains add 1 cup of bleach to wash. 2. Wash and rinse in cold water. 3. Air dry. Never apply heat to Sunbrella ®. Re-treatment for water and stain resistance will be necessary after machine washing. As part of the finishing process, Sunbrella ® fabrics are treated with a fluorocarbon finish, which enhances water repellency. This finish is designed to last for several years, but must be replenished after a thorough cleaning. Based on test results, Glen Raven recommends 303 Fabric Guard™ as the preferred re-treatment product for Sunbrella ® fabrics. Fabrics should be re-treated after thorough cleaning or after five years of use. 303 ® should be applied to Sunbrella ® fabrics after each thorough cleaning, which typically re m oves the original finish and reduces the fabric’s water repellency.

1. Clean Sunbrella ® fabric, using one of the cleaning methods. 2. Allow Sunbrella ® to completely air dry. 3. Apply a thin, even coat of 303 ® in a well ventilated area and allow fabric to dry completely. 4. Apply a second thin, even coating of 303 ®. (Two light coatings are more effective in restoring fabric water resistance than a single heavy coating. A 15oz. bottle provides coverage of up to 50 ft2 of fabric.)

PROFESSIONAL AWNING CLEANERS

HELPFUL HINTS

You may have access to professional awning cleaning firms. In evaluating the services of a professional firm, you should inquire about a firm’s experience in working with Sunbrella ® fabrics and knowledge of cleaning and re-treatment requirements. DO NOT dry clean Sunbrella ® fabrics. Protect the area around the Sunbrella ® fabric when using a bleach solution—bleach may discolor non-Sunbrella fabrics. Always rinse Sunbrella ® thoroughly to completely remove bleach. Sunbrella ® air dries very quickly. Machine drying is not necessary. If fabric has some wrinkling, use an iron, if necessary, but only on the synthetic setting. As some irons exceed the recommended temperature on the synthetic setting, test a small inconspicuous area before ironing entire piece. DO NOT use a steamer or iron set to steam setting. Use of bleach and/or advanced age of the fabric application may impact the deterioration of the sewing thread and other non-Sunbrella components.

160 | upholstery supplies

CUTTING

Do not tear fabric. Cut with scissors or a knife. If a fused edge is desired, hot wire or hot blade cutting instruments may be used. Proper ventilation should be used when cutting with a hot blade instrument. Under ordinary conditions, Sunbrella ® will not shrink. (It is recommended that an awning/canopy be undercut approximately 0.5–1.0% both in length and width of the awning)

HEAT SEALING

SEWING

Sunbrella ® can be heat sealed, A radio-frequency heat sealing machine equipped with a thermo-heated bar is recommended for best results. A layer of Teflon should be attached to the bar to prevent scorching of the fabric. Due to variations in equipment and physical properties of Sunbrella ® (color) it may be necessary to experiment with specific temperature settings and dwell times. It is recommended that the manufacturer of the heat sealing equipment used be consulted in order to determine the best procedure to follow with a particular machine. • A double needle machine equipped with a puller is recommended. Needle gauge should be wide, if possible ¾”. Use of chain stitch is preferable in seaming the widths of cloth. • A lock stitch with a walking foot is recommended for hemming. • For both seaming and hemming the top thread should be polyester size F(16) or FF(12). Light to medium tension is recommended on both top and bottom thread. • Use size F(16) thread for the looper thread on chain stitch machines. • Lock stitch machines should use the same size bobbin thread as on top. • Use size 22 needle with size FF thread on lock stitch machines. • For chain stitch machines, when using size FF thread, the needle size should be 060. For thread size F, the needle size should be 054. Note: It is always advisable to use the smallest size needle with which the machine will stitch properly. For best results, needles should be inspected and changed frequently. • Use of acrylic braid fringe is recommended. Centerfold or flat woven can also be used. • To minimize puckering when seaming, tension should be maintained both in front of and behind the needle. • If needle hole leakage is a problem, an acrylic seam sealer is recommended.

INSTALLATION OF FABRICATION TIPS

• It is recommended no rope pull-ups be used, but if necessary the pulleys should be offset two of three inches so the ropes wipe the fabric rather than concentrate their wear in one line. • Installations should be made in such a manner as to avoid flapping or rubbing the fabric against walls, posts, shrubbery, etc. • There should be no sharp or rough spots in the framework. Reinforcements should be used on parts of the fabric that will come in direct contact with the framework. This will reduce the amount of wear to the fabric and minimize the possibility of leakage. • Rafters should be no more than 36” (92 cm) apart and lacing bands should be used. • A double front bard should be used on canopy type installations. • Avoid flat or nearly flat installations. A minimal pitch of 1’ of drop per 3’ of projection is recommended. If less than optimal pitch exists: increase the number of rafters, install drain grommets (weepers) and use a double front bar to insure maximum tension. • Installations that have underliners should have drain grommets. • Use large enough pipe in framework to ensure a stable installation. • In marine applications, the same general rules apply. A reinforcement should be used in areas where abrasion is likely to occur. Do not piece covers on top of installations. This can result in abrasion and deterioration. For boat covers that span large areas, a mooring pole is recommended to maintain adequate tension and drainage.

upholstery supplies | 161

Super Clear Vinyl UV Inhibitors ● Low Distor�on ● Low Haze ● Easy Release ● Heat Resistant ● Cold Impact

terms & conditions

INDUSTRY STANDARDS:

Seam Allowance & Stitch Density STANDARD PERFORMANCE SPECIFICATIONS FOR UPHOLSTERY FABRICS—PLAIN, TUFTED OR FLOCKED ASTM D3597-02-D434 is a test method published by the American Society of Testing and Materials (ASTM). It indicates the standard performance specification of woven upholstery fabrics. There are specifications within this test method that indicate the industry standard for the sewing of woven upholstery fabrics. It requires the sewing of a seam using a minimum of seven and a maximum of eight stitches per inch using a seam allowance not less than ½”. One can expect seam slippage issues when an upholstery fabric is sewn with a stitch density of less than 7 stitches per inch and seam allowances of less than ½”, so please ensure you always follow the industry standard to avoid problems with seam slippage.

SPECIFICATION GUIDELINES FOR CONTRACT UPHOLSTERY AND DRAPERY TEXTILES Here are some of the performance guidelines for contract textiles (commercial applications), as per the not-for-profit trade association, the Association for Contract Textiles (ACT). These guidelines are meant to help assist you when selecting an upholstery fabric for a commercial project, although product requirements will vary for each commercial project.

FLAMMABILITY California Technical Bulletin 117-2013 (Pass) CROCKING AATCC 8 (Upholstery) and 116 (Drapery) Dry Crocking: Grade 4 minimum Wet Crocking: Grade 3 minimum

COLORFASTNESS TO LIGHT AATCC 16 E or H—Grade 4 minimum at 40 hours PILLING ASTM D3511-03—Class 3 minimum BREAKING STRENGTH ASTM D5034-95 (2001) (Grab Test)—50lb minimum in warp and weft SEAM SLIPPAGE ASTM D3597-02-D434-95—25lb minimum in warp and weft ABRASION FOR WOVEN High Traffic/Public Spaces: UPHOLSTERY FABRICS • ASTM D4157

Low Traffic/Private Spaces:

• ASTM D4157 (Wyzenbeek)—15,000 double rubs

(Wyzenbeek)—50,000 double rubs

ABRASION FOR COATED Heavy duty end use applications include the following: hotel rooms/suites, conference UPHOLSTERY FABRICS rooms and dining area usage. ASTM D4157-02 (Wyzenbeek)—30,000 Double rubs For facilities that are in use for 24 hours per day, the abrasion resistance requirement for upholstered furniture may be higher than the requirement for heavy duty contract upholstery.

164 | terms & conditions

TERMS & CONDITIONS* TERMS

Payment terms are net 30 days from the date of the invoice. Shipments in Canada are F.O.B., Toronto, or Vancouver. Shipments in the U.S. are F.O.B. Indianapolis.

OVERDUE ACCOUNTS A 1.5% service charge per month (18% per annum) will be charged on overdue accounts.

ORDERING

BACK ORDERS HOLD STOCK POLICY

When placing an order, please provide the following information: pattern name, color number and shipping instructions. If exact color match is required, please request a cutting of present stock or send a cutting to be matched. If matching a previous order, please quote the order number. If it is unavailable, send a cutting of the fabric for matching. Please note that dye lots may vary. Back ordered items will be shipped as soon as available. Reservations placed on fabric orders will be honored for 48 hours with the following exceptions:

AN ORDER IS ELIGIBLE FOR A 5-DAY HOLD IF: • Fabric ordered requires dye lot matching • When customer makes a sale to their client but must wait to verify the exact yardage for a more accurate order

• When customers do not have space to take all inventory at once • Customer is quoting a project but must verify exact details from the customer (e.g. yards, color and pricing)

• When waiting for freight quotes

AN ORDER IS ELIGIBLE FOR A 10-DAY HOLD IF: • Customer has requested to see fabric cuts before approval of an order

RETURNS

Arrangements must be made prior to return shipments. Please see the Returned Goods and Claims Policies. Please read our Quality Control Standards and Guidelines carefully. Fabric may not be returned for credit once it has been cut or marked. Inspect yardage for flaws, length, quality and that it is the correct pattern and color before cutting. To ensure prompt credits on approved returns, please provide the following: invoice or packing slip number, pattern name, color number, yardage shipped and the reason for return. Refused shipments or cancellations after orders have been cut are subject to a 15% restocking charge. Cuts under 5 yards are not returnable. Returns will not be accepted on goods older than 90 days from the date of purchase. Adhesives are not accepted after 30 days due to shelf life. Supply items sold in pre-packaged lots will not be accepted in less than the complete lot. The cutting of a fabric indicates acceptance. Fabric may not be returned for credit once it has been cut or marked.

LOST GOODS

Customers must advise Ennis Fabrics within 90 days of a shipping date that goods are lost in shipping and that a claim is required. We cannot honor any freight claims past this point.

SHOWROOM SAMPLES

A deposit of twenty dollars ($20.00) per sample and a deposit of one hundred dollars ($100.00) per complete sample book will be collected at the time a customer completes a “Sample Loan Out Sheet.” Unless otherwise stated, all samples are expected to be returned to our showroom within 2 weeks, at which time your deposit will be returned to you. If samples are not returned within 4 weeks the deposit will be forfeited.

ENNIS FABRICS 2-YEAR FABRIC WARRANTY

Ennis Fabrics fabrics will be repaired or replaced if they fail to give normal wear for two years from the date of delivery. This warranty expressly does not cover: • Cuts

• Burns

• Damage caused by improper applications

• Stains

• Pet damage

• Damage caused by improper installations

• Pilling

• Soiling

• Damage caused by unreasonable use

• Fading caused by sunlight (unless product is specified UV resistant) Claims will not be honored when covers have been removed for cleaning. This warranty does not apply to fabrics treated with fluorocarbon finishes. If the identical fabric is not available, Ennis Fabrics will provide an equivalent fabric.

3RD PARTY PROCESSING

Ennis Fabrics may send goods to the laminator, quiltor, slitter or anywhere else the customer asks us to ship the goods for further processing. However, Ennis Fabrics is not responsible for goods that we did not directly make arrangements for.

* This information is offered for general guidance only. It is accurate to the best of our knowledge and it is not intended to relieve the user from their responsibility to investigate and understand other pertinent sources of information and to comply with all laws and procedures applicable to the safe handling and use of these materials.

terms & conditions | 165

COLOR MATCHING CHANGE:

Evaluating Color Difference of Change in Fabrics The Greyscale for Evaluating Color Difference or Change in Fabrics is used as the industry standard of judgment. It is published by the American Association of Textile Chemists and Colorist (ASTM 2616-12, AATCC 8, AATCC 16), and is used by all testing laboratories and most major mills. The Greyscale measures color change on a scale of 1 to 5. There are a total of 9 potential values that can be assigned to a fabric sample being tested for color change (1, 1/2, 2, 2/3, 3, 3/4, 4, 4/5, 5). The number 1 represents the greatest difference and the number 5 indicates that there has been no color change. Using the Greyscale measurement, Ennis Fabrics has established a standard of acceptance as a 3/4 or greater rating on the Greyscale for decorative fabrics, a 3/4 or greater rating for apparel, recreational and industrial fabrics. Dye lots below 3 would be rejected for all industries.

HOW THE GREYSCALE TEST WORKS The fabric to be tested is placed against the accepted original fabric color standard. A special grey paper, supplied by the AATCC, is placed equally over the two fabrics. This allows a neutral viewing background so that a fair visual judgment can be made of the grade value to be assigned. Viewing is performed in a certified lightbox under D65 lighting.

HOW THE GREYSCALE TEST IS IMPLEMENTED BY ENNIS FABRICS Ennis Fabrics has always had a high standard of quality assurance for the products we distribute. We work closely with our suppliers from the conception of a product, through it’s development and continually throughout it’s life cycle at the company. Every dye lot of goods is compared to a color standard for acceptance or rejection based on the “greyscale.” If the goods are graded below 3/4 on the greyscale, the dye lot is rejected and the process has to start again. Unfortunately, the rejection of a dye lot can delay delivery of goods anywhere from 2–6 weeks. However, this process assures us that we are providing our customers with quality goods each and every time.

CLEANING CODES MSWD Mild soap and water. Dry immediately with a soft, dry cloth S Clean fabrics with Pure Solvents (Petroleum Distillate-Based Products) W Clean fabrics with water-based cleaning agents or water based foam WC Wash With Care WS Clean fabrics with water-based cleaning agents only do not use solvent cleaners X Clean fabrics with vacuum or brushing only

166 | terms & conditions

ROLL TAG FLAW INFORMATION Each cut of fabric is accompanied by a tag describing the item ordered and the yardage shipped. These tags also contain information regarding flaws, the date and time of the order, the packing slip number, etc. Please read these tags thoroughly. Whenever the Quantity Ordered and the Quantity Shipped differ, there will be a mark denoting whether the cause was a flaw, an allowance or a given fabric situation. Given indicates that there was a small amount of yardage left on the roll and was forwarded to the customer at no charge. Flawed indicates that there were imperfections within the yardage (as outlined in Quality Control Standards), therefore extra fabric has been allowed for them. Break Piece Allowance indicates that you have been allowed extra fabric due to a break in the roll. This is when an order for fabric is fulfilled with a break in the roll. The extra allowance is done to compensate for the fabric being on multiple pieces. This order method is only done pending approval from the customer. Description and Tag for / Comments will also help to identify the goods. Be sure to check these before cutting the material.

RETURNED GOODS This section covers the Ennis Fabrics policies concerning returns and claims for fabrics and supplies. When a mistake has been made by Ennis Fabrics the goods may be returned at no charge to the customer. In this case, a returned goods authorization is required and may be obtained by the customer through our Customer Experience Center. Fabric may not be returned once it has been cut by the customer. In the course of discussing the nature of the complaint, it is often to the advantage of all concerned if an agreement can be reached for the customer to retain the goods at a discounted price to save on administrative return costs and freight. Please call for an authorization before returning goods. Due to freight costs, we cannot accept returns on cuts of fabric less than 5 linear yards, unless the problem was caused by Ennis Fabrics, such as the shipment of incorrect goods. Any goods not accompanied by a returned goods authorization number will automatically be assessed freight charges and restocking fees. The restocking fee is 15% on products returned for reasons other than an error by Ennis Fabrics. This covers the administrative costs of receiving and processing the transaction, as well as the inspection of the fabric prior to going into stock. These procedures plus the accounting and other administrative functions are expensive in that they are quite time consuming. These charges will be deducted from the credit that the return will generate. Returns will not be accepted on goods older than 90 days from the date of purchase. Adhesives are not accepted after 30 days due to shelf life. Supply items sold in pre-packaged lots will not be accepted in less than the complete lot. The cutting of a fabric indicates acceptance. Fabric may not be returned for credit once it has been cut or marked. Ennis Fabrics is a customer service oriented company. Every effort is made to correct any mistake we have made. Wherever possible, we will work with our customers to minimize the negative effects of a mistake.

terms & conditions | 167

WARRANTY CLAIMS Warranty periods vary by manufacturer and product. If you have a question or concern regarding the warranty on a purchase or an existing product in use, please contact your sales representative or our Customer Service Center. All warranty claims are handled on an individual basis. To initiate a claim, contact your sales representative to get a claims form filled out and submitted. Due to the wide range of manufacturers and suppliers there is no standard for claims.

WARRANTY LIMITATIONS WHAT CONSTITUTES AN AFTER-TREATMENT? AND WHY DOES ENNIS FABRICS REFUSE TO WARRANT AGAINST A FABRIC THAT HAS GONE THROUGH AN AFTER-TREATMENT? After treatments, or “fabric protection plans” are sold at most retail stores in North America. The chemicals are, in most instances, applied on location by hand. If not done properly, there could be over-saturation (causing fiber breakdown or discoloration), or key spots missed (i.e. coating the cushion top but not on the side borders), which could result in seam fatigue. Chemicals applied to upholstery fabric have a tendency to breakdown the fibers (primarily) filament yarns. Synthetic filament yarns make the fabric beautiful with a variety of twists, textures and wraps. After-treatment chemicals, such as Guardsman or Scotchgaurd, have a propensity to breakdown these fibers over time. In addition, the chemicals can erode the applied fabric backing, be it latex or acrylic. After-treatment chemicals have improved over the years becoming less toxic and less harmful to the environment. As a result, they have extended the life of the fibers over the previous compounds used but there is still degradation. The process is just prolonged. Consequently, it is impossible to determine whether a fabric’s defect or breakdown is the result of manufacturer error or because of an after treatment procedure. Therefore, neither Ennis Fabrics nor our fabric manufacturers will warrant against a fabric that has been after-treated. WHAT IS “PILLING” AND WHY IS IT NOT WARRANTED BY ENNIS FABRICS? As a result of normal wear and use, upholstered fabrics will begin to form little balls, or “pills,” of excess fabric on the surface. This is called pilling, a common characteristic of many upholstered fabrics. Pilling is not considered a defect by Ennis Fabrics because the fabric is not actually deteriorating. Over time, when all excess fibers have been released from the fabric, the pilling will stop. To restore the look of the material, we recommend occasionally “shaving” the product’s surface with a furniture or sweater shaver.

168 | terms & conditions

American & Efird Canada, Inc.

As one of the world’s foremost manufacturers of sewing threads and industrial yarns, A&E’s global presence extends from Asia to Europe to the Americas. It is not simply the scope of our international operations that makes A&E a world-class company. That distinction comes from our dedication to providing our customers with the finest products and services, at the highest quality, delivered anywhere. A&E asserts its century-old commitment to its customers, producing high quality goods by embracing contemporary quality principles and practices. These principles have produced an environment that stimulates individual empowerment and initiative. Such a culture enables us to be a product innovator, a creator of consistent and reliable high quality products, and a company that delivers our comprehensive product line to customers right on time. Visit our sites: www.amefird.ca & www.amefird.com

WE’RE IN ALL THE PLACES YOU NEED US TO BE.

indices

numerical index 1000

1718 74

2104 138

2244 87

1719 74

2108 138

2245 87

2000

2121 93

2248 82

2133 93

2250 87

2000 84

1041 141, 145

2135 93

2251 87

2001 138

1118 141, 143

2141 93

2253 86

2002 137

1119 141, 145

2143 93

2254 86

2003 138

1132 141, 143

2145 93

2259 86

2005 138

1110 146

2147 93

2260 86

2006 138

1122 146

2151 93

2262 86

2011 138

1140 146

2153 93

2265 86

2012 137

1145 146

2155 93

2267 85

2013 138

1164 144

2201 82

2270 86

2015 138

1166 144

2202 82

2274 85

2021 138

1181 144

2205 82

2275 85

2028 137

1151 100

2206 82

2276 85

2030 139

1153 100

2210 119

2277 85

2036 139

1158 103

2211 119

2278 83

2037 139

1159 103

2213 119

2279 84

2038 137

1160 103

2214 119

2280 84

2041 138

1161 103

2215 119

2282 84

2043 138

1162 103

2216 119

2283 83

2045 138

1163 103

2219 40

2284 84

2051 138

1165 103

2221 83

2285 84

2067 139

1170 103

2222 83

2286 84

2072 55

1172 103

2224 83

2287 84

2074 55

1174 103

2225 82

2290 84

2076 137

1175 103

2226 82

2291 84

2078 137

1700 74

2227 83

2294 84

2080 138

1701 74

2228 82

2295 84

2082 138

1702 90

2229 82

2296 86

2084 138

1703 74

2230 82

2297 86

2086 139

1704 74

2232 82

2302 85

2088 139

1706 74

2233 82

2304 85

2090 139

1707 74

2235 82

2305 85

2092 139

1708 74

2236 82

2307 85

2094 138

1709 74

2237 87

2320 85

2096 138

1710 74

2238 87

2325 85

2098 138

1713 74

2239 87

2360 64

2100 138

1716 90

2240 82

2361 64

2102 138

2241 87

2364 64

1011 141, 143 1021 141, 143 1031 141, 143

1717 90

numerical index | 171

2366 64

2572 78

2667 69

2769 73

2368 64

2573 69

2668 69

2771 65

2370 64

2574 69

2670 73

2772 78

2372 64

2575 78

2671 73

2773 65

2378 64

2575 87

2680 73

2774 65

2380 64

2576 71

2681 73

2775 76

2404 64

2577 71

2683 73

2776 78

2406 64

2578 71

2685 71

2777 65

2410 64

2579 66

2687 70

2778 75

2420 64

2580 72

2688 70

2779 75

2422 64

2581 70

2689 70

2780 76

2424 64

2582 70

2691 73

2781 65

2425 64

2583 70

2692 70

2785 76

2427 64

2584 70

2693 70

2786 75

2450 73

2585 70

2694 69

2787 75

2451 73

2586 70

2695 71

2788 75

2452 73

2587 70

2696 69

2789 75

2453 73

2588 70

2697 69

2790 76

2454 73

2590 72

2698 69

2795 76

2460 55

2591 76

2699 69

2797 75

2462 77

2600 72

2700 72

2798 75

2500 72

2605 71

2701 72

2799 75

2510 72

2610 72

2702 70

2800 76

2520 72

2611 73

2703 70

2801 76

2525 71

2612 73

2704 69

2802 76

2530 72

2613 73

2705 66, 72

2803 76

2535 78

2614 73

2706 66, 72

2804 75

2540 72

2620 72

2708 66, 72

2805 65

2541 72

2625 71

2709 72

2810 96

2545 71

2630 73

2710 72

2815 96

2546 71

2640 73

2711 72

2817 96

2547 71

2650 72

2712 72

2830 96

2550 72

2651 72

2713 71

2835 96

2560 72

2652 73

2715 71

2837 96

2561 73

2653 73

2720 70

2839 96

2562 69

2654 73

2721 69

2840 102

2563 69

2655 73

2722 121

2841 102

2564 69

2657 73

2723 121

2845 102

2565 69

2659 71

2740 78

2846 102

2566 69

2660 72

2761 77

2850 68

2567 69

2661 72

2763 77

2851 68

2568 69

2663 70

2764 77

2854 68

2569 69

2664 70

2766 72

2855 68

2570 72

2665 69

2767 72

2858 68

2571 69

2666 70

2768 73

2859 68

172 | numerical index

2862 68

3229 105

4012 53

4082 52

2863 68

3249 105

4013 54

4084 52

2870 68

3890 86

4014 53

4086 52

2871 68

3892 86

4015 53

4088 52

2874 68

3900 86

4016 90

4090 54

2875 68

3901 86

4017 54

4092 54

2878 68

3902 86

4018 54

4094 54

2879 68

3903 86

4019 54

4095 50

2882 68

3904 86

4020 51

4096 54

2885 68

3905 86

4021 51

4097 50

2886 68

3906 86

4022 89

4098 50

2888 68

3907 86

4023 89

4099 50

2892 68

3910 86

4024 89

4121 89

2900 68

3935 90

4025 89

4122 89

2901 68

3960 50

4026 92

4123 89

2904 68

3964 50

4027 89

4124 89

2905 68

3968 50

4028 89

4125 89

2908 70

3976 50

4029 89

4200 128

3000

3992 139

4030 91

4205 128

3992 51

4031 78

4208 128

3001 105

3995 139

4032 89

4241 43

3003 105

3995 50

4033 78

4243 43

3004 105

3996 139

4034 89

4246 43

3005 105

3996 51

4036 92

4249 43

3007 105

3997 139

4038 89

4253 43

3008 105

3997 51

4050 53

4254 43

3109 53

3998 139

4052 53

4256 43

3111 90

3998 51

4054 53

4258 43

3113 90

3999 139

4056 53

4336 97

3115 90

3999 51

4058 53

4338 97

4000

4059 54

4341 97

3120 55

4060 52

4342 97

3121 55

4000 50

4062 52

4365 40

3122 55

4001 139

4064 52

4371 40

3123 55

4001 50

4066 52

4499 40

3124 55

4002 50

4068 52

4500 40

3125 55

4003 139

4069 54

4501 40

3126 55

4003 50

4070 52

4502 40

3127 55

4004 139

4072 52

4503 113

3162 97

4004 50

4073 52

4738 113

3163 97

4007 139

4074 52

4739 113

3168 97

4007 50

4076 52

4740 113

3170 97

4008 50

4077 52

4741 113

3171 97

4010 53

4078 52

4742 113

3219 105

4011 54

4080 52

4743 113

3117 90

numerical index | 173

4746 113

4931 114

4985 113

5049 81

4747 113

4932 114

4989 113

5052 92

4748 113

4934 114

4998 113

5054 92

4749 113

4935 114

4999 113

5055 91

4751 113

4936 114

4752 116

4937 114

5000

5056 92

4754 113

4938 114

5002 118

5058 92

4939 114

5004 117

5059 91

4940 117

5008 117

5060 92

4942 114

5009 117

5075 81

4943 117

5010 117

5101 103

4761 113

4944 117

5011 81

5151 101

4762 113

4945 117

5012 81

5154 101

4765 113

4946 114

5013 81

5313 103

4766 116

4947 114

5014 81

5317 103

4948 117

5015 81

5906 135

4950 114

5016 81

5908 135

4952 114

5017 81

5910 135

4953 113

5019 91

5913 135

4773 113

4954 113

5020 91

5916 135

4774 113

4955 113

5021 91

5917 134

4775 113

4956 113

5022 91

5918 134

4776 113

4957 113

5023 91

5919 134

4958 113

5024 91

5920 134

4959 113

5025 91

5921 134

4960 113

5026 91

5922 134

4961 113

5027 91

5923 134

4786 116

4962 113

5028 91

5924 134

4788 116

4963 113

5029 91

5925 134

4792 117

4964 113

5030 92

5926 134

4890 102

4965 113

5031 91

5930 135

4966 113

5032 91

5931 135

4968 113

5033 91

5932 135

4970 113

5034 91

5933 135

4971 113

5037 91

5934 135

4902 115

4972 113

5038 91

5935 135

4903 115

4973 113

5039 81

5936 135

4904 115

4974 113

5040 81

5937 135

4905 115

4976 113

5041 81

5999 104

4906 115

4977 113

5042 81

4907 115

4978 114

5043 81

6000

4908 115

4979 113

5045 81

6000 135

4926 114

4980 113

5046 81

6002 135

4927 114

4981 113

5047 81

6003 127, 129

4930 114

4982 113

5048 81

6006 135

4755 113 4757 113 4758 113 4760 113

4767 113 4770 116 4771 113 4772 116

4777 113 4778 113 4779 113 4784 116

4892 102 4895 102 4897 102 4901 115

174 | numerical index

5057 92

6008 134

6147 91

6679 120

7027 95

6009 127

6149 91

6680 120

7030 95

6009 129

6155 91

6683 120

7031 95

6009 134

6157 91

6685 120

7032 95

6010 135

6159 91

6690 120

7033 95

6012 134

6201 106

6692 120

7034 94

6013 134

6204 106

6695 119

7035 94

6014 134

6205 106

6701 119

7036 94

6016 134

6207 106

6704 119

7037 94

6020 135

6208 106

6705 119

7038 94

6021 134

6214 106

6788 87

7069 151

6022 134

6215 106

6790 87

7070 151

6024 134

6217 106

6795 88

7073 151

6026 134

6218 106

6797 88

7081 150

6031 134

6223 106

6798 87

7082 151

6032 134

6225 106

6799 88

7083 151

6034 134

6226 106

6800 87

7090 149

6037 134

6227 106

6802 88

7091 149

6041 134

6228 106

6803 88

7092 149

6045 134

6233 106

6805 88

7094 149

6046 134

6234 106

6806 88

7096 149

6047 134

6235 106

6810 87

7100 156

6048 134

6236 106

6820 87

7101 156

6049 134

6245 106

6822 87

7103 154

6050 134

6246 106

6825 84

7104 154

6061 81

6247 106

6830 84

7105 154

6062 81

6251 105

6835 84

7106 156

6064 81

6255 105

6840 84

7107 156

6065 81

6257 105

6841 83

7108 148

6066 81

6258 105

6845 83

7109 156

6070 55

6259 105

6075 81

6261 106

7000

7157 150, 154

6262 106

7001 94

7160 147

6500 130

7002 94

7161 147

6510 130

7003 94

7162 147

6082 81

6514 130

7004 94

7165 153

6083 81

6520 130

7007 94

7166 153

6113 81

6601 106

7013 94

7167 150

6115 81

6606 106

7014 94

7168 149

6608 105

7020 95

7171 148

6609 105

7021 95

7174 147

6673 118

7022 95

7175 148

6674 118

7023 94

7177 150

6127 81

6675 118

7025 95

7178 147

6145 91

6676 118

7026 95

7179 147

6076 81 6080 81 6081 81

6117 81 6120 91 6123 81 6125 81

7158 150, 154

7180 147 numerical index | 175

7181 147

7841 121

8058 92

8884 127, 129

7182 148

7843 121

8061 132

8980 49

7183 147

7844 121

8106 112

8981 49

7184 147

7845 121

8107 112

8982 49

7185 147

7903 130

8121 120

8983 49

7188 147

7904 130

8122 120

8984 49

7189 147

7905 130

8125 114, 120

8985 49

7191 147

7907 130

8210 104

8986 49

7193 147

7985 125

8261 40

8987 49

7194 147

7987 125

8265 40

8992 49

7195 147

7990 125

8267 40

8993 49

7197 147

7991 125

8329 135

8994 49

7992 125

8331 135

8995 49 8996 49

7211 98

8000

8332 135 8339 135

8997 49

7214 98

8002 131

8341 135

8998 49

7216 98

8003 131

8349 135

8999 49

7217 98

8004 131

8351 135

7221 147

8005 131

8362 66

9000

7225 99

8006 131

8364 67

9000 49

7230 99

8011 104

8365 67

9001 49

7237 98

8012 104

8367 67

9002 49

7239 98

8013 130

8368 66

9003 49

7244 98

8014 97

8372 66

9004 49

7260 98

8015 104

8373 67

9005 49

7261 98

8016 104

8374 67

9006 127, 129

7283 131

8017 104

8376 66

9006 49

7284 131

8018 104

8378 100

9007 49

7285 131

8019 104

8380 100

9008 49

7287 131

8020 104

8382 100

9009 49, 127, 129

7288 131

8022 132

8388 100

9010 49

7289 131

8023 132

8392 100

9011 49

7302 154

8024 132

8400 128

9012 49

7303 154

8026 130

8403 112

9013 49

7304 154

8034 99

8404 112

9014 49

7579 128

8038 92

8416 107

9015 49

7700 87

8041 99

8417 107

9016 49

7800 121

8042 99

8418 107

9017 49

7801 121

8045 99

8419 107

9018 49

7806 121

8046 99

8420 101

9019 49

7810 121

8047 99

8435 126

9021 78

7811 121

8048 99

8440 92

9022 78, 91

7820 121

8049 99

8450 101

9024 49

7821 121

8051 92

8504 112

9025 49

7840 121

8052 92

8505 112

9026 49

7202 149 7210 98

176 | numerical index

9027 49

9111 44

9601 147

9734 42

9028 49

9113 44

9604 147

9735 42

9029 49

9114 44

9606 147

9736 42

9030 49

9120 45

9610 147

9737 42

9031 49

9121 44

9611 147

9738 42

9032 49

9122 44

9614 147

9739 127

9034 49

9123 44

9616 147

9749 127

9038 49

9124 44

9622 147

9750 127

9039 49

9125 44

9636 147

9752 127

9044 49

9126 44

9640 147

9762 127

9045 49

9127 44

9646 148

9766 42

9048 49

9128 44

9648 148

9767 42

9049 49

9129 44

9654 147

9768 42

9052 44

9130 44

9656 147

9769 42

9053 44

9131 44

9658 147

9770 42

9054 44

9132 44

9662 147

9771 42

9055 44

9133 44

9663 147

9780 42

9056 44

9134 44

9668 147

9781 42

9057 44

9135 44

9673 147

9782 42

9058 44

9136 44

9678 147

9791 42

9059 44

9142 44

9679 147

9792 42

9060 44

9143 44

9680 147

9793 42

9061 44

9420 65

9682 147

9794 42

9062 44

9421 65

9686 43

9797 42

9063 44

9422 65

9689 147

9813 96

9064 45

9423 65

9696 43

9814 96

9065 45

9424 65

9699 43

9816 96

9066 45

9425 65

9701 41

9821 42

9067 45

9426 65

9702 41

9825 127

9068 45

9450 59

9703 41

9827 127

9070 48

9451 59

9704 41

9830 127

9071 48

9452 59

9706 41

9831 41

9080 48

9453 59

9707 41

9832 41

9081 48

9454 59

9708 41

9834 126

9082 48

9455 59

9709 43

9836 126

9083 48

9470 59

9710 43

9838 126

9090 48

9471 59

9712 43

9840 118

9091 48

9472 59

9714 43

9841 118

9092 48

9473 59

9715 43

9842 118

9093 48

9474 59

9716 42

9844 42

9106 48

9475 59

9717 42

9845 118

9107 48

9550 41

9718 42

9846 42

9108 44

9597 147

9719 126

9849 126

9109 44

9599 147

9720 42

9850 42

9110 44

9600 147

9733 42

9851 42

numerical index | 177

9852 42

9909 56

9955 59

10000 56

9853 42

9910 56

9956 59

10001 56

9855 42

9911 62

9957 59

10003 56

9856 42

9912 56

9958 59

10004 56

9857 42

9913 62

9959 59

10005 59

9858 42

9914 56

9960 59

10006 59

9859 42

9915 62

9961 59

10007 59

9860 42

9916 62

9962 59

10008 59

9861 42

9917 56

9963 59

10009 59

9862 42

9918 62

9964 59

10010 59

9863 42

9919 62

9965 61

10011 59

9864 42

9921 62

9966 61

10012 59

9865 42

9922 62

9967 59

10013 59

9866 42

9923 62

9968 59

10014 59

9867 42

9924 62

9969 59

10015 59

9868 42

9925 62

9970 56

10016 59

9869 42

9926 62

9971 56

10017 59

9870 42

9927 62

9972 61

10018 59

9872 43

9928 62

9974 61

10019 59

9874 42

9929 56

9975 60

10020 59

9875 43

9930 60

9976 61

10021 59

9876 96

9931 62

9977 59

10022 59

9877 96

9932 62

9978 59

10023 59

9878 42

9933 62

9979 59

10024 59

9879 56

9934 62

9980 60

10025 59

9880 56

9935 60

9981 59

10026 59

9885 56

9936 60

9982 60

10027 59

9886 56

9937 60

9983 59

10028 59

9887 56

9938 60

9984 60

10029 59

9888 56

9939 61

9985 59

10030 59

9889 56

9940 61

9986 59

10031 59

9890 56

9941 61

9987 59

10032 59

9891 56

9942 61

9988 59

10033 59

9892 42

9943 61

9989 59

10034 59

9893 42

9944 61

9990 60

10035 59

9894 42

9945 61

9991 59

10036 59

9895 42

9946 61

9992 59

10037 59

9897 126

9947 61

9993 59

10038 59

9898 42

9948 61

9994 59

10039 59

9899 42

9949 61

9995 59

10040 59

9900 42

9950 59

9996 59

10041 59

9903 42

9951 59

9997 59

10042 59

9904 42

9952 59

9998 59

10043 59

9905 42

9953 59 9954 59

10,000

10044 59

9906 56

178 | numerical index

10045 59

10046 59

10092 59

11030 56

11412 58

10047 59

10093 59

11031 59

11420 58

10048 59

10094 59

11042 73

11432 58

10049 59

10095 59

11043 69

11448 58

10050 59

10096 59

11060 67

11500 56

10051 59

10097 59

11061 67

11501 56

10052 59

10098 59

11062 67

11502 56

10053 59

10099 59

11063 67

11609 56

10054 59

10120 60

11064 67

11610 56

10055 59

10121 60

11065 67

11612 56

10056 59

10122 60

11066 67

11613 56

10057 59

10166 58

11067 67

11660 56

10058 59

10168 58

11072 101

11670 56

10059 59

10170 58

11120 123

11682 56

10060 59

10172 58

11121 123

11800 114

10061 59

10309 116

11122 123

10062 59

10310 116

11123 124

12,000

10063 59

10311 116

11130 123

12011 113

10064 59

10312 116

11131 123

12012 113

10065 59

10313 116

11132 123

12013 113

10066 59

10314 116

11133 123

12014 113

10068 59

11,000

11135 123

13,000

10069 59

11001 51

11143 123

10070 59

11003 51

11150 123

10071 59

11007 51

11153 124

10072 59

11009 51

11156 124

10073 59

11010 104, 131

11157 124

10074 59

11011 51

11158 123

10075 61

11012 52

11159 124

10076 61

11013 61

11160 123

10078 61

11014 64

11161 117

10079 61

11015 64

11162 124

10080 61

11016 56

11163 117

10081 61

11017 56

11190 119

10082 60

11018 56

11194 119

10083 60

11019 56

11231 66

10084 60

11020 56

11300 58

10085 60

11021 56

11301 58

10086 59

11023 75

11302 58

10087 59

11025 56

11306 58

10088 59

11026 56

11308 58

10089 59

11027 56

11310 58

10090 59

11028 56

11312 58

10091 59

11029 56

11400 58

10067 59

11141 123

13000 53 13001 53 13002 53 13003 43 13042 44 13043 44 13044 44 13045 44 13078 44 13079 44 13080 44 13081 44 13125 41 13126 41 13127 41 13128 41 13129 41 13130 41 13131 41 13200 44 13201 44 13202 44

numerical index | 179

13203 44

134086 110

135553 110

138416 107

50,000

134099 110

135557 110

138417 107

134117 110

135561 110

138418 107

50820 91

134129 110

135631 110

147254 98

92,000

134136 110

135634 110

147255 98

134140 110

135670 110

147256 98

134144 110

136030 110

147257 98

134170 110

136048 110

147258 98

134177 110

136081 110

147278 98

134212 110

136099 110

147279 98

134215 110

136111 110

147280 98

134230 110

136135 110

147282 98

134252 110

136139 110

156033 110

134257 110

136179 110

156037 110

134297 110

136184 110

163114 110

134370 110

136188 110

163120 110

134444 110

136195 110

163233 110

134466 110

136220 110

167007 110

134609 110

136241 110

167011 110

134664 110

136245 110

167015 110

134794 110

136279 110

167021 110

134811 110

136289 110

167025 110

134913 110

136341 110

167028 110

134974 110

136343 110

167029 110

135000 110

136731 110

167034 110

135020 110

136911 110

167037 110

135048 110

136999 110

167047 110

135100 110

138,000

167048 110

135103 110

138201 108

167053 110

135210 110

138203 108

167054 110

135312 110

138204 108

167057 110

135385 110

138205 108

167058 110

135417 110

138207 108

167059 110

135434 110

138208 108

167060 110

135472 110

138214 108

167061 110

135477 110

138215 108

167063 110

135486 110

138216 108

167067 110

135495 110

138218 108

167069 110

135497 110

138220 108

167071 110

135500 110

138222 108

167073 110

135516 110

138223 108

167074 110

135520 110

138224 108

167075 110

135538 110

138229 108

135551 110

138231 108

92201 108 92202 108 92203 108 92204 108 92205 108 92206 108 92207 108 92208 108 92209 108 92212 108 92213 108 92214 108 92215 108 92216 108 92217 108 92218 108 92219 108 92220 108 92221 108 92222 108 92223 108 92224 108 92225 108 92227 108 92229 108 92230 108 92231 108 92232 108 92234 108 92235 108 92236 108 92255 108

130,000 130001 110 130004 70 134050 110 134067 110 134072 110 134081 110 180 | numerical index

135070 110

167050 110

248,000

248430 112

503038 115

9066507 109

248431 112

503039 115

9066508 109

248439 112

503040 115

9066509 109

248441 112

503041 115

9066510 109

278432 112

503042 115

9066511 109

278433 112

503045 115

9066512 109

278434 112

503046 115

9066513 109

278436 112

503090 115

9066517 109

278437 112

503091 115

9066518 109

296003 126

503092 115

9066519 109

296601 126

503093 115

9220116 107, 108

296604 126

503094 115

9222416 107, 108

296608 126

503096 115

9222916 107, 108

296630 126

503097 115

296631 126 296633 126

922,000

13,560,000

296637 126

922011 107

13566501 109

922012 107

13566502 109

922241 107

13566503 109

408445 112

922242 107

13566504 109

408446 112

922916 107, 108

13566506 109

458443 112

1,208,000

13566507 109

458444 112

1208421 112

13566509 109

503,000

1208422 112

13566510 109

1208423 112

13566511 109

503009 115

1208424 112

13566512 109

503016 115

1208425 112

13566513 109

503020 115

1208426 112

13566517 109

503021 115

1208427 112

13566518 109

503022 115

1208428 112

13566519 109

503023 115

1208429 112

13820116 108

503024 115 503025 115

1,382,000

503026 115

1382011 107

503027 115

1382012 107

503028 115

1382241 107

503029 115

1382242 107

503030 115

9,066,000

408,000 458442 112

503032 115 503033 115 503034 115 503035 115 503036 115 503037 115

13566500 109

13566508 109

9066500 109 9066501 109 9066502 109 9066503 109 9066504 109 9066506 109 numerical index | 181

alphanumerical index A ADHAE1011 141 ADHAE1011 143 ADHAE1021 141 ADHAE1021 143 ADHAE1031 141 ADHAE1031 143 ADHAE1041 141 ADHAE1041 145 ADHAE1118 141 ADHAE1118 143 ADHAE1119 141 ADHAE1119 145 ADHAE1132 141 ADHAE1132 143 ADHBU1110 146 ADHBU1122 146 ADHBU1140 146 ADHBU1145 146 ADHBU1164 144 ADHBU1166 144 ADHBU1181 144 ADHMI1153 100 AERCL7108 148 AERCL9646 148 AERCL9648 148 AERPR7081 150 AERPR7103 154 AERPR7104 154 AERPR7105 154 AERPR7106 156 AERPR7107 156 AERPR7157 154 AERPR7157 150 AERPR7158 154 AERPR7158 150 AERPR7165 153 AERPR7166 153 AERPR7167 150 AERPR7177 150 AERPR7302 154 182 | alphanumerical index

AERPR7303 154

AERVI9668 147

BAGDR3903 86

AERPR7304 154

AERVI9673 147

BAGDR3904 86

AERSI7171 148

AERVI9678 147

BAGDR3905 86

AERSI7175 148

AERVI9679 147

BAGDR3906 86

AERSI7182 148

AERVI9680 147

BAGDR3907 86

AERST7160 147

AERVI9682 147

BAGDR3910 86

AERST7161 147

AERVI9689 147

BAGHO2237 87

AERST7162 147

BAGHO2238 87

AERST7174 147

AERST7178 147

BAGBU2201 82

BAGHO2241 87

AERST7179 147

BAGBU2202 82

BAGHO2244 87

AERST7180 147

BAGBU2205 82

BAGHO2245 87

AERST7181 147

BAGBU2206 82

BAGHO2250 87

AERST7183 147

BAGBU2221 83

BAGHO2251 87

AERST7184 147

BAGBU2222 83

BAGHO2722 121

AERST7185 147

BAGBU2224 83

BAGHO2723 121

AERST7188 147

BAGBU2225 82

BAGHO6788 87

AERST7189 147

BAGBU2226 82

BAGHO6790 87

AERST7191 147

BAGBU2227 83

BAGHO6795 88

AERST7193 147

BAGBU2228 82

BAGHO6797 88

AERST7194 147

BAGBU2229 82

BAGHO6798 87

AERST7195 147

BAGBU2230 82

BAGHO6799 88

AERST7197 147

BAGBU2232 82

BAGHO6800 87

AERST7221 147

BAGBU2233 82

BAGHO6802 88

AERVI9597 147

BAGBU2235 82

BAGHO6803 88

AERVI9599 147

BAGBU2236 82

BAGHO6805 88

AERVI9600 147

BAGBU2240 82

BAGHO6806 88

AERVI9601 147

BAGBU2248 82

BAGHO6810 87

AERVI9604 147

BAGBU2278 83

BAGHO6820 87

AERVI9606 147

BAGBU2283 83

BAGHO6822 87

AERVI9610 147

BAGDR2253 86

BAGLO2267 85

AERVI9611 147

BAGDR2254 86

BAGLO2274 85

AERVI9614 147

BAGDR2259 86

BAGLO2275 85

AERVI9616 147

BAGDR2260 86

BAGLO2276 85

AERVI9622 147

BAGDR2262 86

BAGLO2277 85

AERVI9636 147

BAGDR2265 86

BAGMI2325 85

AERVI9640 147

BAGDR2270 86

BAGOR2296 86

AERVI9654 147

BAGDR3890 86

BAGOR2297 86

AERVI9656 147

BAGDR3892 86

BAGPA2302 85

AERVI9658 147

BAGDR3900 86

BAGPA2304 85

AERVI9662 147

BAGDR3901 86

BAGSL2279 84

AERVI9663 147

BAGDR3902 86

BAGSL2280 84

BAGHO2239 87

BAGSL2282 84

BINST10314 116

BINSUTRI4775 113

BINVI5009 117

BAGSL2284 84

BINSUNBB4742 113

BINSUTRI4776 113

BINVI5010 117

BAGSL2285 84

BINSUNBB4746 113

BINSUTRI4777 113

BINWI5002 118

BAGSL2286 84

BINSUNBB4747 113

BINSUTRI4778 113

BRASU503009 115

BAGSL2287 84

BINSUNBB4748 113

BINSUTRI4779 113

BRASU503016 115

BAGSL2290 84

BINSUNBB4749 113

BINSUTRI4960 113

BRASU503020 115

BAGSL2291 84

BINSUNBB4754 113

BINSUTRI4974 113

BRASU503021 115

BAGSL2294 84

BINSUNBB4755 113

BINSUTRI4979 113

BRASU503022 115

BAGSL2295 84

BINSUNBB4758 113

BINSUTRI4980 113

BRASU503023 115

BAGSL6825 84

BINSUNBP4757 113

BINSUTRI4981 113

BRASU503024 115

BAGSL6830 84

BINSUTR4738 113

BINSUTRI4982 113

BRASU503025 115

BAGSL6835 84

BINSUTR4739 113

BINSUTRI4985 113

BRASU503026 115

BAGSL6840 84

BINSUTR4740 113

BINSUTRI4989 113

BRASU503027 115

BAGSU6841 83

BINSUTR4741 113

BINSUTRI4998 113

BRASU503028 115

BAGSU6845 83

BINSUTR4743 113

BINSUTRI4999 113

BRASU503029 115

BAGTR2305 85

BINSUTR4751 113

BINSUTRI12011 113

BRASU503030 115

BAGTR2307 85

BINSUTR4954 113

BINSUTRI12014 113

BRASU503032 115

BAGTR2320 85

BINSUTR4956 113

BINSUTRP4953 113

BRASU503033 115

BASVA9686 43

BINSUTR4957 113

BINSUTRP4955 113

BRASU503034 115

BASVA9696 43

BINSUTR4958 113

BINTG4901 115

BRASU503035 115

BINCE4926 114

BINSUTR4959 113

BINTG4902 115

BRASU503036 115

BINCE4927 114

BINSUTR4961 113

BINTG4903 115

BRASU503037 115

BINCE4930 114

BINSUTR4962 113

BINTG4904 115

BRASU503038 115

BINCE4931 114

BINSUTR4963 113

BINTG4905 115

BRASU503039 115

BINCE4932 114

BINSUTR4964 113

BINTG4906 115

BRASU503040 115

BINCE4934 114

BINSUTR4965 113

BINTG4908 115

BRASU503041 115

BINCE4935 114

BINSUTR4966 113

BINTGP4907 115

BRASU503042 115

BINCE4936 114

BINSUTR4968 113

BINTO4752 116

BRASU503045 115

BINCE4937 114

BINSUTR4970 113

BINTO4766 116

BRASU503046 115

BINCE4938 114

BINSUTR4971 113

BINTO4770 116

BRASU503090 115

BINCE4939 114

BINSUTR4972 113

BINTO4772 116

BRASU503091 115

BINCE4942 114

BINSUTR4973 113

BINTO4784 116

BRASU503092 115

BINCE4946 114

BINSUTR4976 113

BINTO4786 116

BRASU503093 115

BINCE4947 114

BINSUTR4977 113

BINTO4788 116

BRASU503094 115

BINCE4950 114

BINSUTR12013 113

BINTW9840 118

BRASU503096 115

BINCE4952 114

BINSUTRA12012 113

BINTW9841 118

BRASU503097 115

BINCE4978 114

BINSUTRI4503 113

BINTW9842 118

BUTCU2151 93

BINFE4792 117

BINSUTRI4760 113

BINTW9845 118

BUTCU2153 93

BINGR11161 117

BINSUTRI4761 113

BINVI4940 117

BUTCU2155 93

BINGR11163 117

BINSUTRI4762 113

BINVI4943 117

BUTD2133 93

BINST10309 116

BINSUTRI4765 113

BINVI4944 117

BUTD2135 93

BINST10310 116

BINSUTRI4767 113

BINVI4945 117

BUTD2143 93

BINST10311 116

BINSUTRI4771 113

BINVI4948 117

BUTD2145 93

BINST10312 116

BINSUTRI4773 113

BINVI5004 117

BUTD2147 93

BINST10313 116

BINSUTRI4774 113

BINVI5008 117

BUTDI2141 93

alphanumerical index | 183

BUTMI2121 93

CLEFA7082 151

CORTW8121 120

FASDB3995 139

BUTUP2001 138

CLEFA7083 151

CORTW8122 120

FASDB4000 50

BUTUP2002 137

CLEIO7100 156

CORTW8125 120

FASDB4001 50

BUTUP2003 138

CLEIO7101 156

CORTW8125 114

FASDB4001 139

BUTUP2005 138

CLEIO7109 156

FASDB4002 50

BUTUP2006 138

CLEPL7168 149

BUTUP2011 138

CLEST7090 149

ELAKN4241 43

FASDB4003 139

CLEST7091 149

ELAKN4243 43

FASDB4004 50

CLEST7092 149

ELAKN4246 43

FASDB4004 139

CLEST7094 149

ELAKN4249 43

FASDB4007 50

CLEST7096 149

ELAWO4253 43

FASDB4007 139

CORAW6701 119

ELAWO4254 43

FASDB4020 51

CORAW6704 119

ELAWO4256 43

FASDB4021 51

BUTUP2036 139

CORAW6705 119

ELAWO4258 43

FASDO4060 52

BUTUP2037 139

CORDR6695 119

FASDO4062 52

BUTUP2038 137

CORDR11190 119

BUTUP2041 138

CORDR11194 119

BUTUP2043 138

CORLO2210 119

BUTUP2045 138

CORLO2211 119

BUTUP2051 138

CORLO2213 119

BUTUP2067 139

CORLO2214 119

BUTUP2072 55

CORLO2215 119

BUTUP2074 55

CORLO2216 119

BUTUP2076 137

CORRO6673 118

BUTUP2078 137

CORRO6674 118

BUTUP2080 138

CORRO6675 118

BUTUP2082 138

CORRO6676 118

BUTUP2084 138

CORSH6679 120

BUTUP2086 139

CORSH6680 120

BUTUP2088 139

CORSH6683 120

BUTUP2090 139

CORSH6685 120

BUTUP2092 139

CORSH6690 120

BUTUP2094 138

CORSH6692 120

BUTUP2096 138

CORSH7800 121

BUTUP2098 138

CORSH7801 121

BUTUP2100 138

CORSH7806 121

BUTUP2102 138

CORSH7810 121

BUTUP2104 138

CORSH7811 121

BUTUP2108 138

CORSH7820 121

CORSH7821 121

CLEAC7202 149

CORSH7841 121

BUTUP2012 137 BUTUP2013 138 BUTUP2015 138 BUTUP2021 138 BUTUP2028 137 BUTUP2030 139

CLEFA7069 151 CLEFA7070 151 CLEFA7073 151

184 | alphanumerical index

CORSH7840 121 CORSH7843 121 CORSH7844 121 CORSH7845 121

FASBB3992 51 FASBB3992 139 FASBB3996 51 FASBB3996 139 FASBB3997 51 FASBB3997 139 FASBB3998 51 FASBB3998 139 FASBB3999 51 FASBB3999 139 FASCO3109 53 FASCO3120 55 FASCO3121 55 FASCO3122 55 FASCO3123 55 FASCO3124 55 FASCO3125 55 FASCO3126 55 FASCO3127 55 FASCO4050 53 FASCO4052 53 FASCO4054 53 FASCO4056 53 FASCO4058 53 FASDB3960 50 FASDB3964 50 FASDB3968 50 FASDB3976 50 FASDB3995 50

FASDB4003 50

FASDO4064 52 FASDO4066 52 FASDO4068 52 FASDO4070 52 FASDO4072 52 FASDO4073 52 FASDO4074 52 FASDO4076 52 FASDO4077 52 FASDO4078 52 FASDO4080 52 FASDO4082 52 FASDO4084 52 FASDO4086 52 FASDO4088 52 FASDS4008 50 FASDS4010 53 FASDS4012 53 FASDS4014 53 FASDS4015 53 FASDS11001 51 FASDS11003 51 FASDS11007 51 FASDS11009 51 FASDS11011 51 FASGY11012 52 FASIN2460 55 FASIN6070 55 FASLI4011 54 FASLI4013 54

FASLI4017 54

FITAL2422 64

FITCH2525 71

FITST2578 71

FASLI4018 54

FITAL2424 64

FITCH2545 71

FITST2581 70

FASLI4019 54

FITAL2425 64

FITCH2546 71

FITST2582 70

FASLI4059 54

FITAL2427 64

FITCH2547 71

FITST2583 70

FASLI4069 54

FITAW2771 65

FITCH2605 71

FITST2584 70

FASPU4090 54

FITAW2773 65

FITCH2625 71

FITST2585 70

FASPU4092 54

FITAW2774 65

FITCH2659 71

FITST2586 70

FASPU4094 54

FITAW2777 65

FITCH2685 71

FITST2587 70

FASPU4096 54

FITAW2781 65

FITCH2695 71

FITST2588 70

FASSA6500 130

FITAW9420 65

FITCH2713 71

FITST2663 70

FASSA6510 130

FITAW9421 65

FITCH2715 71

FITST2664 70

FASSA6514 130

FITAW9422 65

FITCL2450 73

FITST2665 69

FASSA6520 130

FITAW9423 65

FITCL2451 73

FITST2666 70

FASST1700 74

FITAW9424 65

FITCL2452 73

FITST2667 69

FASST1701 74

FITAW9425 65

FITCL2453 73

FITST2668 69

FASST1703 74

FITAW9426 65

FITCL2454 73

FITST2687 70

FASST1704 74

FITAW11014 64

FITCL2591 76

FITST2688 70

FASST1706 74

FITAW11015 64

FITHI2772 78

FITST2689 70

FASST1707 74

FITBL2510 72

FITHI2776 78

FITST2692 70

FASST1708 74

FITBL2520 72

FITHO7700 87

FITST2693 70

FASST1709 74

FITBL2541 72

FITKI2462 77

FITST2694 69

FASST1710 74

FITBL2570 72

FITKI2761 77

FITST2696 69

FASST1713 74

FITBL2580 72

FITKI2763 77

FITST2697 69

FASST1718 74

FITBL2600 72

FITKI2764 77

FITST2698 69

FASST1719 74

FITBL2612 73

FITMI2000 84

FITST2699 69

FASST4095 50

FITBL2614 73

FITMI2740 78

FITST2702 70

FASST4097 50

FITBL2620 72

FITMI2778 75

FITST2703 70

FASST4098 50

FITBL2640 73

FITMI2779 75

FITST2704 69

FASST4099 50

FITBL2651 72

FITST2535 78

FITST2720 70

FASST13000 53

FITBL2652 73

FITST2562 69

FITST2721 69

FASST13001 53

FITBL2654 73

FITST2563 69

FITST2850 68

FASST13002 53

FITBL2657 73

FITST2564 69

FITST2851 68

FITAL2360 64

FITBL2661 72

FITST2565 69

FITST2854 68

FITAL2361 64

FITBL2671 73

FITST2566 69

FITST2855 68

FITAL2364 64

FITBL2681 73

FITST2567 69

FITST2858 68

FITAL2366 64

FITBL2683 73

FITST2568 69

FITST2859 68

FITAL2368 64

FITBL2691 73

FITST2569 69

FITST2862 68

FITAL2370 64

FITBL2701 72

FITST2571 69

FITST2863 68

FITAL2372 64

FITBL2705 66, 72

FITST2572 78

FITST2870 68

FITAL2378 64

FITBL2708 66, 72

FITST2573 69

FITST2871 68

FITAL2380 64

FITBL2711 72

FITST2574 69

FITST2874 68

FITAL2404 64

FITBL2712 72

FITST2575 87

FITST2875 68

FITAL2406 64

FITBL2766 72

FITST2575 78

FITST2878 68

FITAL2410 64

FITBL2767 72

FITST2576 71

FITST2879 68

FITAL2420 64

FITBL2769 73

FITST2577 71

FITST2882 68

alphanumerical index | 185

FITST2885 68

FITWE2787 75

GROOS5012 81

NEEST6226 106

FITST2886 68

FITWE2788 75

GROOS5013 81

NEEST6227 106

FITST2888 68

FITWE2789 75

GROOS5014 81

NEEST6228 106

FITST2892 68

FITWH2500 72

GROOS5015 81

NEEST6233 106

FITST2900 68

FITWH2530 72

GROOS5016 81

NEEST6234 106

FITST2901 68

FITWH2540 72

GROOS5017 81

NEEST6235 106

FITST2904 68

FITWH2550 72

GROOS5039 81

NEEST6236 106

FITST2905 68

FITWH2560 72

GROOS5040 81

NEEST6245 106

FITST2908 70

FITWH2561 73

GROOS6061 81

NEEST6246 106

FITST11043 69

FITWH2590 72

GROOS6062 81

NEEST6247 106

FITST11060 67

FITWH2610 72

GROOS6064 81

NEETU6261 106

FITST11061 67

FITWH2611 73

GROOS6065 81

NEETU6262 106

FITST11062 67

FITWH2613 73

GROOS6066 81

FITST11063 67

FITWH2630 73

GROOS6075 81

FITST11064 67

FITWH2650 72

GROOS6076 81

PADFI8261 40

FITST11065 67

FITWH2653 73

GROOS6080 81

PADFI8265 40

FITST11066 67

FITWH2655 73

GROOS6081 81

PADFI8267 40

FITST11067 67

FITWH2660 72

GROOS6082 81

PATCA3219 105

FITST130004 70

FITWH2670 73

GROOS6083 81

PATCA3229 105

FITTE2775 76

FITWH2680 73

GROSP5041 81

PATCA3249 105

FITTE2780 76

FITWH2700 72

GROSP5042 81

PATCH3001 105

FITTE2785 76

FITWH2706 66, 72

GROSP5043 81

PATCH3003 105

FITTE2790 76

FITWH2709 72

GROSP5045 81

PATCH3005 105

FITTE2795 76

FITWH2710 72

GROSP5046 81

PATCH3007 105

FITTE2800 76

FITWH2768 73

GROSP5047 81

PATCH3008 105

FITTE2801 76

FITWH11042 73

GROSP5048 81

PATPE3004 105

FITTE2802 76

FOACC4499 40

GROSP5049 81

PATPI6251 105

FITTE2803 76

FOACC4500 40

FITTU2579 66

FOACC4501 40

FITTU8362 66

FOACC4502 40

LINBU2219 40

PATPI6258 105

FITTU8364 67

FOARE4365 40

PATPI6259 105

FITTU8365 67

FOARE4371 40

FITTU8367 67

FRADO4031 78

NEECU6201 106

PATRU6609 105

FITTU8368 66

FRADO4033 78

FITTU8372 66 FITTU8373 67

FITTU8374 67

NEECU6204 106

PATPI6255 105 PATPI6257 105

PATRU6608 105

NEECU6205 106

NEECU6207 106

SHEQI7021 95

GROCR6113 81

NEECU6208 106

SHEQI7022 95

FITTU8376 66

GROCR6115 81

NEECU6214 106

SHEQI7023 94

FITTU11231 66

GROCR6117 81

NEECU6215 106

SHEST7001 94

FITVE2797 75

GROCR6123 81

NEECU6217 106

SHEST7002 94

FITVE2798 75

GROCR6125 81

NEECU6218 106

SHEST7003 94

FITVE2799 75

GROCR6127 81

NEERE6601 106

SHEST7004 94

FITVE2804 75

GROMI5075 81

NEEREE6606 106

SHEST7007 94

FITVE11023 75

GROMI9021 78

NEEST6223 106

SHEST7013 94

FITWE2786 75

GROOS5011 81

NEEST6225 106

SHEST7014 94

186 | alphanumerical index

SHEST7020 95

TACNA5931 135

TAPRE11120 123

THR69134811 110

SHEST7025 95

TACNA5932 135

TAPRE11121 123

THR69134913 110

SHEST7026 95

TACNA5933 135

TAPRE11122 123

THR69134974 110

SHEST7027 95

TACNA5934 135

TAPRE11123 124

THR69135000 110

SHEST7030 95

TACNA5935 135

TAPRE11130 123

THR69135020 110

SHEST7031 95

TACNA5936 135

TAPRE11131 123

THR69135048 110

SHEST7032 95

TACNA5937 135

TAPRE11132 123

THR69135070 110

SHEST7033 95

TACNA6000 135

TAPRE11133 123

THR69135100 110

SHEST7034 94

TACNA6002 135

TAPRE11135 123

THR69135103 110

SHEST7035 94

TACNA6006 135

TAPRE11141 123

THR69135210 110

SHEST7036 94

TACNA6008 134

TAPRE11143 123

THR69135312 110

SHEST7037 94

TACNA6009 134

TAPRE11150 123

THR69135385 110

SHEST7038 94

TACNA6010 135

TAPRE11153 124

THR69135417 110

STA147254 98

TACNA6012 134

TAPRE11156 124

THR69135434 110

STA147255 98

TACNA6013 134

TAPRE11157 124

THR69135472 110

STA147256 98

TACNA6014 134

TAPRE11158 123

THR69135477 110

STA147257 98

TACNA6016 134

TAPRE11159 124

THR69135486 110

STA147258 98

TACNA6020 135

TAPRE11160 123

THR69135495 110

STA147278 98

TACNA6021 134

TAPRE11162 124

THR69135497 110

STA147279 98

TACNA6022 134

THR69130001 110

THR69135500 110

STA147280 98

TACNA6024 134

THR69134050 110

THR69135516 110

STA147282 98

TACNA6026 134

THR69134067 110

THR69135520 110

STADU7237 98

TACNA6031 134

THR69134072 110

THR69135538 110

STADU7239 98

TACNA6032 134

THR69134081 110

THR69135551 110

STADU7244 98

TACNA6034 134

THR69134086 110

THR69135553 110

STAST7260 98

TACNA6037 134

THR69134099 110

THR69135557 110

STAST7261 98

TACNA6041 134

THR69134117 110

THR69135561 110

TACNA6045 134

THR69134129 110

THR69135631 110

TACNA6046 134

THR69134136 110

THR69135634 110

TACNA5906 135

TACNA6047 134

THR69134140 110

THR69135670 110

TACNA5908 135

TACNA6048 134

THR69134144 110

THR69136030 110

TACNA5910 135

TACNA6049 134

THR69134170 110

THR69136048 110

TACNA5913 135

TACNA6050 134

THR69134177 110

THR69136081 110

TACNA5916 135

TACST8329 135

THR69134212 110

THR69136099 110

TACNA5917 134

TACST8331 135

THR69134215 110

THR69136111 110

TACNA5918 134

TACST8332 135

THR69134230 110

THR69136135 110

TACNA5919 134

TACST8349 135

THR69134252 110

THR69136139 110

TACNA5920 134

TACST8351 135

THR69134257 110

THR69136179 110

TACNA5921 134

TACUP8339 135

THR69134297 110

THR69136184 110

TACNA5922 134

TACUP8341 135

THR69134370 110

THR69136188 110

TACNA5923 134

TAPETR7991 125

THR69134444 110

THR69136195 110

TACNA5924 134

TAPETR7992 125

THR69134466 110

THR69136220 110

TACNA5925 134

TAPMI7985 125

THR69134609 110

THR69136241 110

TACNA5926 134

TAPMI7987 125

THR69134664 110

THR69136245 110

TACNA5930 135

TAPMI7990 125

THR69134794 110

THR69136279 110

alphanumerical index | 187

THR69136289 110

THRDC1208427 112

THRSU92229 108

THRSUS9066509 109

THR69136341 110

THRDC1208428 112

THRSU92230 108

THRSUS9066510 109

THR69136343 110

THRDC1208429 112

THRSU92231 108

THRSUS9066511 109

THR69136731 110

THRHA8504 112

THRSU92232 108

THRSUS9066512 109

THR69136911 110

THRHA8505 112

THRSU92234 108

THRSUS9066513 109

THR69136999 110

THRMO8106 112

THRSU92235 108

THRSUS9066517 109

THR69156033 110

THRMO8107 112

THRSU92236 108

THRSUS9066518 109

THR69156037 110

THRNY8403 112

THRSU92255 108

THRSUS9066519 109

THR69163114 110

THRNY8404 112

THRSU138201 108

THRSUS13566500 109

THR69163120 110

THRPC248439 112

THRSU138203 108

THRSUS13566501 109

THR69163233 110

THRPC248441 112

THRSU138204 108

THRSUS13566502 109

THR69167007 110

THRPC408445 112

THRSU138205 108

THRSUS13566503 109

THR69167011 110

THRPC408446 112

THRSU138207 108

THRSUS13566504 109

THR69167015 110

THRPS278432 112

THRSU138208 108

THRSUS13566506 109

THR69167021 110

THRPS278433 112

THRSU138214 108

THRSUS13566507 109

THR69167025 110

THRPS278434 112

THRSU138215 108

THRSUS13566508 109

THR69167028 110

THRPS278436 112

THRSU138216 108

THRSUS13566509 109

THR69167029 110

THRPS278437 112

THRSU138218 108

THRSUS13566510 109

THR69167034 110

THRPS458442 112

THRSU138220 108

THRSUS13566511 109

THR69167037 110

THRPS458443 112

THRSU138222 108

THRSUS13566512 109

THR69167047 110

THRPS458444 112

THRSU138223 108

THRSUS13566513 109

THR69167048 110

THRSU92201 108

THRSU138224 108

THRSUS13566517 109

THR69167050 110

THRSU92202 108

THRSU138229 108

THRSUS13566518 109

THR69167053 110

THRSU92203 108

THRSU138231 108

THRSUS13566519 109

THR69167054 110

THRSU92204 108

THRSU922011 107

THRTE8416 107

THR69167057 110

THRSU92205 108

THRSU922012 107

THRTE8417 107

THR69167058 110

THRSU92206 108

THRSU922241 107

THRTE8418 107

THR69167059 110

THRSU92207 108

THRSU922242 107

THRTE8419 107

THR69167060 110

THRSU92208 108

THRSU922916 107, 108

THRTE138416 107

THR69167061 110

THRSU92209 108

THRSU1382011 107

THRTE138417 107

THR69167063 110

THRSU92212 108

THRSU1382012 107

THRTE138418 107

THR69167067 110

THRSU92213 108

THRSU1382241 107

TIEHO13003 43

THR69167069 110

THRSU92214 108

THRSU1382242 107

TOOAU8420 101

THR69167071 110

THRSU92215 108

THRSU9220116 107, 108

TOOAU8450 101

THR69167073 110

THRSU92216 108

THRSU9222416 107, 108

TOOCR6145 91

THR69167074 110

THRSU92217 108

THRSU9222916 107, 108

TOOCR6147 91

THR69167075 110

THRSU92218 108

THRSU13820116 108

TOOCR6149 91

THRDC248430 112

THRSU92219 108

THRSUS9066500 109

TOOCR6155 91

THRDC248431 112

THRSU92220 108

THRSUS9066501 109

TOOCR6157 91

THRDC1208421 112

THRSU92221 108

THRSUS9066502 109

TOOCR6159 91

THRDC1208422 112

THRSU92222 108

THRSUS9066503 109

TOOCU2810 96

THRDC1208423 112

THRSU92223 108

THRSUS9066504 109

TOOCU2815 96

THRDC1208424 112

THRSU92224 108

THRSUS9066506 109

TOOCU2817 96

THRDC1208425 112

THRSU92225 108

THRSUS9066507 109

TOOCU2830 96

THRDC1208426 112

THRSU92227 108

THRSUS9066508 109

TOOCU2835 96

188 | alphanumerical index

TOOCU2837 96

TOOFO4895 102

TOOOS5027 91

TOOTA7230 99

TOOCU2839 96

TOOFO4897 102

TOOOS5028 91

TOOTA8034 99

TOOCU3162 97

TOOGR6120 91

TOOOS5029 91

TOOTA8041 99

TOOCU3163 97

TOOGR9022 91

TOOOS5031 91

TOOTA8042 99

TOOCU3168 97

TOOGR9022 78

TOOOS5032 91

TOOTA8045 99

TOOCU3170 97

TOOGR50820 91

TOOOS5033 91

TOOTA8046 99

TOOCU3171 97

TOOGU5151 101

TOOOS5034 91

TOOTA8047 99

TOOCU4336 97

TOOGU5154 101

TOOOS5037 91

TOOTA8048 99

TOOCU4338 97

TOOHA5101 103

TOOOS5038 91

TOOTA8049 99

TOOCU4341 97

TOOHA8210 104

TOOOS5055 91

TOOTU8378 100

TOOCU4342 97

TOOHO8002 131

TOOOS5059 91

TOOTU8380 100

TOOCU8014 97

TOOHO8003 131

TOOPU8011 104

TOOTU8382 100

TOOCU9813 96

TOOHO8004 131

TOOPU8012 104

TOOTU8388 100

TOOCU9814 96

TOOHO8005 131

TOOPU8015 104

TOOTU8392 100

TOOCU9816 96

TOOHO8006 131

TOOPU8016 104

TOOTU11072 101

TOOCU9876 96

TOOKI8061 132

TOOPU8017 104

TOOWB8022 132

TOOCU9877 96

TOOKN8038 92

TOOPU8018 104

TOOWB8023 132

TOOFA1702 90

TOOKN8051 92

TOOPU8019 104

TOOWB8024 132

TOOFA1716 90

TOOKN8052 92

TOOPU8020 104

TOOWE2840 102

TOOFA1717 90

TOOKN8058 92

TOOQU3935 90

TOOWE2841 102

TOOFA3111 90

TOOKN8440 92

TOOSI7903 130

TOOWE2845 102

TOOFA3113 90

TOOMA5313 103

TOOSI7904 130

TOOWE2846 102

TOOFA3115 90

TOOMA5317 103

TOOSI7905 130

TOOZI11010 104, 131

TOOFA3117 90

TOOMI1151 100

TOOSI7907 130

TRIED2805 65

TOOFA4016 90

TOOMI1158 103

TOOSI8013 130

TRIED4200 128

TOOFA4022 89

TOOMI1159 103

TOOSI8026 130

TRIED4205 128

TOOFA4023 89

TOOMI1160 103

TOOSP5030 92

TRIED4208 128

TOOFA4024 89

TOOMI1161 103

TOOSP5052 92

TRIEZ296003 126

TOOFA4025 89

TOOMI1162 103

TOOSP5054 92

TRIEZ296601 126

TOOFA4026 92

TOOMI1163 103

TOOSP5056 92

TRIEZ296604 126

TOOFA4027 89

TOOMI1165 103

TOOSP5057 92

TRIEZ296608 126

TOOFA4028 89

TOOMI1170 103

TOOSP5058 92

TRIEZ296630 126

TOOFA4029 89

TOOMI1172 103

TOOSP5060 92

TRIEZ296631 126

TOOFA4030 91

TOOMI1174 103

TOOST7283 131

TRIEZ296633 126

TOOFA4032 89

TOOMI1175 103

TOOST7284 131

TRIEZ296637 126

TOOFA4034 89

TOOMI5999 104

TOOST7285 131

TRIHYMID1 127

TOOFA4036 92

TOOMI11800 114

TOOST7287 131

TRIHYMID3 127

TOOFA4038 89

TOOOS5019 91

TOOST7288 131

TRIHYMID6 127

TOOFA4121 89

TOOOS5020 91

TOOST7289 131

TRIHYMID8 127

TOOFA4122 89

TOOOS5021 91

TOOTA7210 98

TRIHYMID17 127

TOOFA4123 89

TOOOS5022 91

TOOTA7211 98

TRIHYMID33 127

TOOFA4124 89

TOOOS5023 91

TOOTA7214 98

TRIHYMID34 127

TOOFA4125 89

TOOOS5024 91

TOOTA7216 98

TRIHYMID61 127

TOOFO4890 102

TOOOS5025 91

TOOTA7217 98

TRIHYMID66 127

TOOFO4892 102

TOOOS5026 91

TOOTA7225 99

TRIHYMID67 127

alphanumerical index | 189

TRIHYMID84 127

TRIWEMID87 129

VELPS9120 45

VELSE9024 49

TRIHYMID87 127

TRIWEMID97 129

VELPS9121 44

VELSE9025 49

TRIHYMID97 127

TRIWEMID98 129

VELPS9122 44

VELSE9026 49

TRIHYMID98 127

TRIWEMID99 129

VELPS9123 44

VELSE9027 49

TRIHYMID99 127

TRIWEMID222 129

VELPS9124 44

VELSE9028 49

TRIHYMID222 127

TRIWEMID333 129

VELPS9125 44

VELSE9029 49

TRIHYMID333 127

TRIWEMID649 129

VELPS9126 44

VELSE9030 49

TRIHYMID649 127

TRIWEMID696 129

VELPS9127 44

VELSE9031 49

TRIHYMID696 127

TRIWEMID805 129

VELPS9128 44

VELSE9032 49

TRIHYMID805 127

TRIWEMID905 129

VELSE8980 49

VELSE9034 49

TRIHYMID905 127

TRIWEMID969 129

VELSE8981 49

VELSE9038 49

TRIHYMID969 127

TRIWEMID6003 129

VELSE8982 49

VELSE9039 49

TRIHYMID6003 127

TRIWEMID6009 129

VELSE8983 49

VELSE9044 49

TRIHYMID6009 127

TRIWEMID8884 129

VELSE8984 49

VELSE9045 49

TRIHYMID8884 127

TRIWEMID9006 129

VELSE8985 49

VELSE9048 49

TRIHYMID9006 127

TRIWEMID9009 129

VELSE8986 49

VELSE9049 49

TRIHYMID9009 127

VELSE8987 49

VELSE9052 44

TRIMI8400 128

VELSE8992 49

VELSE9053 44

TRIWE7579 128

VELAL9068 45

VELSE8993 49

VELSE9054 44

TRIWE8435 126

VELPO13042 44

VELSE8994 49

VELSE9055 44

TRIWE9719 126

VELPO13043 44

VELSE8995 49

VELSE9056 44

TRIWE9739 127

VELPO13044 44

VELSE8996 49

VELSE9057 44

TRIWE9749 127

VELPO13045 44

VELSE8997 49

VELSE9058 44

TRIWE9750 127

VELPO13200 44

VELSE8998 49

VELSE9059 44

TRIWE9752 127

VELPO13201 44

VELSE8999 49

VELSE9060 44

TRIWE9762 127

VELPO13202 44

VELSE9000 49

VELSE9061 44

TRIWE9825 127

VELPO13203 44

VELSE9001 49

VELSE9062 44

TRIWE9827 127

VELPS9070 48

VELSE9002 49

VELSE9063 44

TRIWE9830 127

VELPS9071 48

VELSE9003 49

VELSE9129 44

TRIWE9834 126

VELPS9080 48

VELSE9004 49

VELSE9130 44

TRIWE9836 126

VELPS9081 48

VELSE9005 49

VELSE9131 44

TRIWE9838 126

VELPS9082 48

VELSE9006 49

VELSE9132 44

TRIWE9849 126

VELPS9083 48

VELSE9007 49

VELSE9133 44

TRIWE9897 126

VELPS9090 48

VELSE9008 49

VELSE9134 44

TRIWEMID1 129

VELPS9091 48

VELSE9009 49

VELSE9135 44

TRIWEMID3 129

VELPS9092 48

VELSE9010 49

VELSE9136 44

TRIWEMID6 129

VELPS9093 48

VELSE9011 49

VELSE9142 44

TRIWEMID8 129

VELPS9106 48

VELSE9012 49

VELSE9143 44

TRIWEMID17 129

VELPS9107 48

VELSE9013 49

VELSE13078 44

TRIWEMID33 129

VELPS9108 44

VELSE9014 49

VELSE13079 44

TRIWEMID34 129

VELPS9109 44

VELSE9015 49

VELSE13080 44

TRIWEMID61 129

VELPS9110 44

VELSE9016 49

VELSE13081 44

TRIWEMID66 129

VELPS9111 44

VELSE9017 49

VELST9064 45

TRIWEMID67 129

VELPS9113 44

VELSE9018 49

VELST9065 45

TRIWEMID84 129

VELPS9114 44

VELSE9019 49

VELST9066 45

190 | alphanumerical index

VELST9067 45

WEBPP9769 42

ZIPAL9916 62

ZIPCF11500 56

WEBPP9770 42

ZIPAL9918 62

ZIPCF11501 56

WEBPP9771 42

ZIPAL9919 62

ZIPCF11502 56

WEBCO9550 41

WEBPP9780 42

ZIPAL9921 62

ZIPCF11609 56

WEBCO9831 41

WEBPP9781 42

ZIPAL9922 62

ZIPCF11610 56

WEBCO9832 41

WEBPP9852 42

ZIPAL9923 62

ZIPCF11612 56

WEBFU9710 43

WEBPP9853 42

ZIPAL9924 62

ZIPCF11613 56

WEBFU9712 43

WEBPP9855 42

ZIPAL9931 62

ZIPDC11400 58

WEBFU9714 43

WEBPP9856 42

ZIPBR9911 62

ZIPDC11412 58

WEBFU9715 43

WEBPP9857 42

ZIPBR9915 62

ZIPDC11420 58

WEBJU9709 43

WEBPP9858 42

ZIPBR9925 62

ZIPDC11432 58

WEBNY9782 42

WEBPP9859 42

ZIPBR9926 62

ZIPDF11300 58

WEBNY9791 42

WEBPP9860 42

ZIPBR9927 62

ZIPDF11301 58

WEBNY9792 42

WEBPP9861 42

ZIPBR9928 62

ZIPDF11302 58

WEBNY9793 42

WEBPP9862 42

ZIPBR9932 62

ZIPDF11306 58

WEBNY9794 42

WEBPP9863 42

ZIPBR9933 62

ZIPDF11308 58

WEBNY9797 42

WEBPP9864 42

ZIPBR9934 62

ZIPDF11310 58

WEBNY9821 42

WEBPP9865 42

ZIPCC9879 56

ZIPDF11312 58

WEBNY9844 42

WEBPP9866 42

ZIPCC9880 56

ZIPDF11448 58

WEBNY9846 42

WEBPP9867 42

ZIPCC9885 56

ZIPEZ11016 56

WEBNY9850 42

WEBPP9868 42

ZIPCC9886 56

ZIPEZ11017 56

WEBNY9851 42

WEBPP9869 42

ZIPCC9887 56

ZIPEZ11018 56

WEBNY9892 42

WEBPP9870 42

ZIPCC9888 56

ZIPEZ11019 56

WEBPO9701 41

WEBPP9874 42

ZIPCC9889 56

ZIPEZ11020 56

WEBPO9702 41

WEBPP9878 42

ZIPCC9890 56

ZIPEZ11021 56

WEBPO9703 41

WEBPP9893 42

ZIPCC9891 56

ZIPEZ11025 56

WEBPO9704 41

WEBPP9894 42

ZIPCC9906 56

ZIPEZ11026 56

WEBPO9706 41

WEBPP9895 42

ZIPCC9909 56

ZIPEZ11027 56

WEBPO9707 41

WEBPP9898 42

ZIPCC9910 56

ZIPEZ11028 56

WEBPO9708 41

WEBPP9899 42

ZIPCC9912 56

ZIPEZ11029 56

WEBPO13130 41

WEBPP9900 42

ZIPCC9914 56

ZIPEZ11030 56

WEBPO13131 41

WEBPP9903 42

ZIPCC9917 56

ZIPJE10166 58

WEBPP9716 42

WEBPP9904 42

ZIPCC9929 56

ZIPJE10168 58

WEBPP9717 42

WEBPP9905 42

ZIPCC9970 56

ZIPJE10170 58

WEBPP9718 42

WEBPR9699 43

ZIPCC9971 56

ZIPJE10172 58

WEBPP9720 42

WEBSE9872 43

ZIPCC10000 56

ZIPST11013 61

WEBPP9733 42

WEBSE9875 43

ZIPCC10001 56

ZIPVC9930 60

WEBPP9734 42

WEBSU13125 41

ZIPCC10003 56

ZIPVC9935 60

WEBPP9735 42

WEBSU13126 41

ZIPCC10004 56

ZIPVC9936 60

WEBPP9736 42

WEBSU13127 41

ZIPCC10120 60

ZIPVC9937 60

WEBPP9737 42

WEBSU13128 41

ZIPCC10121 60

ZIPVC9938 60

WEBPP9738 42

WEBSU13129 41

ZIPCC10122 60

ZIPVC9939 61

ZIPCC11660 56

ZIPVC9940 61

WEBPP9767 42

ZIPCC11670 56

ZIPVC9941 61

WEBPP9768 42

ZIPAL9913 62

ZIPCC11682 56

ZIPVC9942 61

WEBPP9766 42

alphanumerical index | 191

ZIPVC9943 61

ZIPVF9956 59

ZIPVF10020 59

ZIPVF10065 59

ZIPVC9944 61

ZIPVF9957 59

ZIPVF10021 59

ZIPVF10066 59

ZIPVC9945 61

ZIPVF9958 59

ZIPVF10022 59

ZIPVF10067 59

ZIPVC9946 61

ZIPVF9959 59

ZIPVF10023 59

ZIPVF10068 59

ZIPVC9947 61

ZIPVF9960 59

ZIPVF10024 59

ZIPVF10069 59

ZIPVC9948 61

ZIPVF9961 59

ZIPVF10025 59

ZIPVF10070 59

ZIPVC9949 61

ZIPVF9962 59

ZIPVF10026 59

ZIPVF10071 59

ZIPVC9965 61

ZIPVF9963 59

ZIPVF10027 59

ZIPVF10072 59

ZIPVC9966 61

ZIPVF9964 59

ZIPVF10028 59

ZIPVF10073 59

ZIPVC9972 61

ZIPVF9967 59

ZIPVF10029 59

ZIPVF10074 59

ZIPVC9974 61

ZIPVF9968 59

ZIPVF10030 59

ZIPVF10086 59

ZIPVC9975 60

ZIPVF9969 59

ZIPVF10031 59

ZIPVF10087 59

ZIPVC9976 61

ZIPVF9977 59

ZIPVF10032 59

ZIPVF10088 59

ZIPVC9980 60

ZIPVF9978 59

ZIPVF10033 59

ZIPVF10089 59

ZIPVC9982 60

ZIPVF9979 59

ZIPVF10034 59

ZIPVF10090 59

ZIPVC9984 60

ZIPVF9981 59

ZIPVF10035 59

ZIPVF10091 59

ZIPVC9990 60

ZIPVF9983 59

ZIPVF10036 59

ZIPVF10092 59

ZIPVC10075 61

ZIPVF9985 59

ZIPVF10037 59

ZIPVF10093 59

ZIPVC10076 61

ZIPVF9986 59

ZIPVF10038 59

ZIPVF10094 59

ZIPVC10078 61

ZIPVF9987 59

ZIPVF10039 59

ZIPVF10095 59

ZIPVC10079 61

ZIPVF9988 59

ZIPVF10040 59

ZIPVF10096 59

ZIPVC10080 61

ZIPVF9989 59

ZIPVF10041 59

ZIPVF10097 59

ZIPVC10081 61

ZIPVF9991 59

ZIPVF10042 59

ZIPVF10098 59

ZIPVC10082 60

ZIPVF9992 59

ZIPVF10043 59

ZIPVF10099 59

ZIPVC10083 60

ZIPVF9993 59

ZIPVF10044 59

ZIPVF11031 59

ZIPVC10084 60

ZIPVF9994 59

ZIPVF10045 59

ZIPVC10085 60

ZIPVF9995 59

ZIPVF10046 59

ZIPVF9450 59

ZIPVF9996 59

ZIPVF10047 59

ZIPVF9451 59

ZIPVF9997 59

ZIPVF10048 59

ZIPVF9452 59

ZIPVF9998 59

ZIPVF10049 59

ZIPVF9453 59

ZIPVF10005 59

ZIPVF10050 59

ZIPVF9454 59

ZIPVF10006 59

ZIPVF10051 59

ZIPVF9455 59

ZIPVF10007 59

ZIPVF10052 59

ZIPVF9470 59

ZIPVF10008 59

ZIPVF10053 59

ZIPVF9471 59

ZIPVF10009 59

ZIPVF10054 59

ZIPVF9472 59

ZIPVF10010 59

ZIPVF10055 59

ZIPVF9473 59

ZIPVF10011 59

ZIPVF10056 59

ZIPVF9474 59

ZIPVF10012 59

ZIPVF10057 59

ZIPVF9475 59

ZIPVF10013 59

ZIPVF10058 59

ZIPVF9950 59

ZIPVF10014 59

ZIPVF10059 59

ZIPVF9951 59

ZIPVF10015 59

ZIPVF10060 59

ZIPVF9952 59

ZIPVF10016 59

ZIPVF10061 59

ZIPVF9953 59

ZIPVF10017 59

ZIPVF10062 59

ZIPVF9954 59

ZIPVF10018 59

ZIPVF10063 59

ZIPVF9955 59

ZIPVF10019 59

ZIPVF10064 59

192 | alphanumerical index

alphabetical index A ADHESIVES 141 ADHESIVES - AEROSOLES 143 ADHESIVES - BULK 146 ADHESIVES - TRIM 145 ADHESIVES - VINYLS 144 ADHESIVE SPRAY GUN 103 AEROSOL FINISHES - MOHAWK 147 ALFA-LOK 45 ALUMINUM TUBING 66 AWNING FITTINGS - ALUMINUM 64 AWNING HARDWARE 64

B BAG ACCESSORIES 82 - 88 BENDING TOOLS 100 BINDING - AUTOMOTIVE - TOPLINE 116 BINDING - DOUBLE FOLD- TOP GUN 116 BINDING - FELT - SOLARGUARD 117 BINDING - FOLDER 102 BINDING - MARINE - TOPLINE 116 BINDING - NYLON - GROSGRAIN 117 BINDING - POLYESTER TWILL 118 BINDING - SUNBRELLA 113 BINDING - SUNBRELLA - BRAID 115 BINDING - TWO-FOLD - STAMOID 116 BINDING - VINYL 117 BINDING - WIRE ON 118 BOAT SEAT HINGES 78 BOAT - TOP FITTINGS - DELRIN 72 BOAT - TOP FITTINGS - STAINLESS STEEL 68 BOAT TOP FRAME KITS 77 BOAT VENTING 75 BRAID - SUNBRELLA 115 BUCKLES 82 BUTTONS 137 BUTTONS - SHELLS 137

C CANVAS - FABRIC 19 CARDBOARD 105

CHALK - TAILORS 105 CLEANERS 141, 149 CLEAR PLASTIC 12 CLOSED CELL FOAM 40 COATED PVC 10 OZ. 11 COATED PVC 14 OZ. 11 COATED PVC 18 OZ. 10 COCKPIT POLES 76 COMMON SENSE FASTENERS 53 CORD - AWNING 119 CORD - DRAWSTRING 119 CORD - SHOCK - HOOKS 121 CORD - SHOCK - NYLON 120 CORD - SHOCK - POLYPROPYLENE 120 CORD LOCKS 119 CORDAGE - TWINE 120 CRYPTON CARE 151 CUTTER AND DIE SETS - BUTTONS 93 CUTTERS - COMMON SENSE 90 CUTTERS - COMPACT & PRODUCTION 97 CUTTERS - FOAM 97 CUTTERS - HOT KNIFE 96 CUTTERS - LIFT-A-DOT 90 CUTTERS - ROUND KNIFE 97 CUTTERS - WIRE 97

D D-RING 86 DECKING 40 DECORATIVE NAILS 134 DIE-CAST FITTINGS - CHROME 71 DOT - LIFT THE DOT 54 DOT - PULL THE DOT 54 DOT COMMON SENSE - METAL 53 DOT DURABLE - NICKEL PLATED BRASS 52 DOT DURABLE - STAINLESS STEEL 53 DOWEL PINS 78 DRILLING TOOLS 101 DURA SNAP - BABY - NICKEL PLATED BRASS 51, 139 DURA SNAP - NICKEL PLATED BRASS 50, 139 DURA SNAP - NICKEL PLATED STEEL 51

CHALK - SANIGENE 105

alphabetical index | 193

E EDGEROLL 128 ELASTIC - KNIT 43 ELASTIC - WOVEN 43 E-Z LACE SUPREME 126

F FASTENER TOOLS 89 FASTENERS 50 FASTENERS - DOT COMMON SENSE - METAL 53 FASTENERS - DOT DURABLE - NICKEL PLATED BRASS 52 FASTENERS - DOT DURABLE - STAINLESS STEEL 53 FASTENERS - DURA SNAP - BABY - NICKEL PLATED BRASS 51, 139 FASTENERS - DURA SNAP - NICKEL PLATED BRASS 50, 139 FASTENERS - DURA SNAP - NICKEL PLATED STEEL 51 FASTENERS - LIFT THE DOT 54 FASTENERS - NYLON 55 FASTENERS - PULL THE DOT 54

HINGES - ALUMINUM 78 HINGES - BOAT 78 HOLE PUNCH TOOLS 104 HOOK AND LOOP 44 HOOK AND LOOP - PRESSURE SENSITIVE - 3M 48 HOOK AND LOOP - PRESSURE SENSITIVE - JEF 48 HOOK AND LOOP - SEW-ON - JEF 49 HOOKS AND CLASP - SURCINGLE 83 HOT AIR HEAT GUNS 101 HOT KNIFE 96 HYDEM GRIMP - MIDSHIP 127

I-K INDUSTRIAL BAG HARDWARE 82 JAW SLIDE 66 KNIVES 92

L LAP BELT - NON-RETRACTABLE 43

FASTENERS - STAYPUT 74

LIFT THE DOT 54

FELT 40

LOW TEMP VINYLS 54

FITTINGS - AWNING 64

LUBRICANTS 148

FITTINGS - DIE-CAST - CHROME 71 FITTINGS - GEMINI - STAINLESS STEEL 69 FITTINGS - MARINE 68

M MALLETS 103

FOAM - CLOSED CELL 40

MARINE FITTINGS 68

MARINE HARDWARE 66-78

GEMINI FITTINGS - STAINLESS STEEL 67

MARKER - WASH OUT 105

GIMP 126 - 127, 129

MESH - FABRIC 14

GIMP - MIDSHIP 127

MESH - SCREENING HEAVY MESH 14

GLUE 141

MOORING POLES 62

GLUE - AEROSOLES 143 GLUE - BULK 146 GLUE - TRIM 145

MARINE VINYLS 8

N-O NAIL STRIPS 134

GLUE - VINYLS 144

NAILS 134

GLUE GUNS 100

NAILS - DECORATIVE 134

GORE TENARA - THREAD 107

NAILS - TACKS 135

GROMMET TOOLS 91

NEEDLES 105

GROMMETS 80

NEEDLES - HAND SEWING 106

GROMMETS - VENTS 78

NEEDLES - TUFTING 106

NON-RETRACTABLE LAP BELT 43

HAMMERS 103 HAND SEWING 112 HANGER 130 HEAD PINS 105

194 | alphabetical index

NYLON - FABRIC 16

P-Q PACKING PRODUCTS 125 PADDING 40

PENCIL - WASH OUT 105

SLIDE - BAG 82

PINS - PLASTIC 105

SNAP HOOKS 87

PLASTIC - CLEAR 12

SNAPS 50

PLIERS - HOG RING 131

SPONGE ROD 128

PLIERS - ZIPPER 131

SPRAY GUN 103

POLE FITTINGS 76

SPRING TOOLS 130

POLYESTER - FABRIC 15

SPRING TOOLS - NO SAG 130

PROTECTANT - 303 154

STAINLESS STEEL FITTINGS 69

PROTECTANT - IOSSO 154

STAPLE GUNS 98

PROTECTANTS 141, 150

STAPLE REMOVERS 99

PU - UPHOLSTERY FARBIC 33

STAPLES 98

PULL THE DOT 54

STAYPUT 74

PVC - MARINE/AWNING/INDUSTRIAL FABRIC 11

STEAMERS 131

PVC - UPHOLSTERY FABRIC 36

SUNBRELLA - FABRIC 20

PVC WELDER TOOLS 102

SUNGUARD - THREAD 108

SUNSTOP - THREAD 109

RAIL - AWNING 65 RAIL FITTINGS - STAINLESS STEEL 68

REFLECTIVE TAPE 123 - 124

TACKERS 98

ROLL PLASTIC 12

TACKING STRIPS 135

ROPE - AWNING 119

TACKS 135

ROPE - DRAWSTRING 119

TAPE 122

ROPE - POLYPROPYLENE 118

TAPE - CARTON SEALING 125

ROPE - TWINE 120

TAPE - SCOTCHLITE 123

ROPE TIE-DOWN RATCHET 43

TAPE - TRANSFER 125

RULERS 105

TARP 10

TENT POLES 62

SAMPLE BOOK - HANDLE 130

THREAD - D-CORE 112

SAMPLE BOOK - RING 130

THREAD - GORE TENARA 107

SCISSORS 94

THREAD - MONOFILAMENT 112

SCOTCHLITE 122 - 124

THREAD - 69 NYLON 110

SCREWSTUDS 54

THREAD - PERMA CORE 112

SEAM SEALER 156

THREAD - POLYESTER 107

SEAM TAPE 123

THREAD - SUNGUARD 108

SEAT BELT - WEBBING 43

THREAD - SUNSTOP 109

SEM COLOR COAT 147

THREAD STAND 114

SHEARS - KAI 94

TIE-DOWN WEBBING 43

SHEARS - MUNDIAL 94

TOOLS 89

SHEARS - QUICK CLIPS 95

TOP FITTINGS - DELRIN 72

SHEARS - WISS 95

TOP FITTINGS - STAINLESS STEEL 69

SHOCK CORD - HOOKS 121

TRACK ALUMINUM 78

SHOCK CORD - NYLON 120

TREATED COTTON CANVAS 19

SHOCK CORD - POLYPROPYLENE 120

TRIM - SNAP ON 128

SILICONE 148

TRIMMING 126

SKEWERS 105

TRIMMING TOOLS 101

SUPPORT POLES 62

THREAD 105

alphabetical index | 195

TRUCK TARP REINFORCMENTS

WELT - AWNING

TUBING 66

WELT - MARINE 75

TUBING - ALUMINUM 66

WELT - MIDSHIP 129

TUBING - STAINLESS STEEL

WINDSHIELD CLIPS

TUFTING TWINE - NYLON 114

YARK STICK

TURN FASTENERS

TWIST PINS 105

105

ZIPPER TOOL 104

ZIPPERS

UNTREATED COTTON CANVAS UPHOLSTERY FABRICS

26 - 37

ZIPPERS - ALUMINUM - YYK

ZIPPERS - BRASS - YYK 62

UPHOLSTERY REPAIR KIT 132

ZIPPERS - COIL - JEF ZIP 56

ZIPPERS - DELRIN - JEF ZIP 58

VELCRO - ALFA-LOK 45

ZIPPERS - STOP PLIERS 131

VELCRO - FR 44

ZIPPERS - VISION FINSIHED - YYK 59

VELCRO - POLYESTER 44

ZIPPERS - VISION UNFINSIHED - YYK 60

ZIPPERS - METAL - YYK 62

VELCRO - PRESSURE SENSITIVE 44 VELCRO - SEW ON 44 VELSTICK - DISPLAY DOTS

VELSTICK - HOOK AND LOOP 45 VENTING - MARINE

VINYL - ENNIS 1974 9 VINYL COAT

147

VINYL - MARINE

VINYL - UPHOLSTERY

33 - 37

W-Y WATER REPELLENT FINISH

153

WEBBING 41 WEBBING BUCKLES - DELRIN 82 WEBBING BUCKLES - METAL 83 WEBBING - CONNECTORS 85 WEBBING - COTTON 42 WEBBING - D-RINGS

WEBBING - FURNITURE 43 WEBBING - LOOPS

WEBBING - NYLON

WEBBING - POLYESTER

WEBBING - POLYESTER TIE-DOWN 41 WEBBING - POLYPROPYLENE 42 WEBBING - SEAT BELT 43 WEBBING - SLIDES

WEBBING - SNAP HOOKS 87 WEBBING - SUNBRELLA 41 WEBBING SNAP HOOKS 87 WEBBING TOOLS 132 WELT 126

Ship2Shore

Perfect for Boats, Cars, and Everything Else

UPHOLSTERY THAT OUTPERFORMS ON LAND OR AT SEA!

800-243-2472 | CS@ENDURATEX.COM | ENDURATEX.COM

0120

BC38
