Drainage Solutions for
Civil Engineering, Garden & Landscaping
Jaybro is an Exclusive Distributor of MEA in Australia & New Zealand
Welcome to MEA Water Management, a leading manufacturer and supplier of drainage systems & solutions for rainwater treatment and infiltration. We are a division of the MEA Group, and we have been working in close cooperation with professional planners and builders for over 130 years. The wealth of experience and practical knowledge gained over the years is the key of our success and a cornerstone in the quality of the service and products that we deliver to our partners and customers worldwide.
MEA is China’s number one and the world’s number two in the market of polymer concrete drainage channels. The product portfolio comprises ultralight drainage channels made from glass-fibre reinforced composite (GRP), polymer concrete channels in various versions for loading classes ranging from A 15 to F 900 and aesthetic stainless steel channels. We are a supplier for numerous prestigious projects in the world, including the Formula One racetrack in Bahrain, the Expo 2010 in Shanghai, and several airports. Jaybro is the exclusive Australian Distributor of the MEA range - drainage products.
CHANNEL COVERS 5
Stainless Steel Heelguard
Plastic Composite Slotted
Galvanised Heelguard
Ductile Longitudinal Heelguard
Ductile Iron Slotted
Ductile Iron Hi-Flow
MEA DRAIN
MEA DRAIN
Our MEADRAIN channel product portfolio has been designed to provide a maximum of flexibility in using rainwater drainage channel for loading classes up to E 600. Our universal drainage channel made of polymer concrete covers all possible application fields, from landscaping to industrial areas with maximum traffic and charges.
The MEADRAIN drainage channels are available with edges made of galvanised and stainless steel as well as of ductile iron, providing a solution for every type of project. The system is available in 4 different widths (100, 150, 200 and 300 mm) and various heights (from flat to high capacity channels).
Features
• Loading Class E 600
• Lateral ribs for more stability and optimal anchorage in the concrete bed
• Matching covers with longitudinal shift protection
• With CLIPFIX grating locking mechanism
• With or without fall
• Widths: 100, 150, 200 and 300 mm
Shallow Channel
Edge protection available in Stainless Steel, Galvanised or Cast Iron
Pre-sloped & Stepped Options available
MEARIN PLUS & EXPERT 9
MEARIN PLUS & EXPERT
Glass-fibre-reinforced composite is a real all-rounder in the area of drainage. The high quality material with an extremely low weight is suitable for installation up to loading class E 600. The complete MEARIN product range has been adapted to fit to our universal CLIPFIX grating fixing mechanism.
The MEARIN PLUS product family has widened its range with the new MEARIN PLUS F flat channels. Available in 3 widths (100, 150 and 200 mm) with loading class up to D 400, the MEARIN PLUS F has been specially designed for areas where construction heights are crucial such as in car parks for instance.
Features
• Lightweight: Easier & more economical in handling on construction sites and reduced transport costs
• Highly stable (up to class E 600)
Drainage channel body made of glass-fibre-reinforced composite for a high temperature resistance and dimensional stability
• Clear widths: 100, 150, 200 and 300 mm
• Sustainable: 100% recyclable
• Design: Large selection of grates
Edge design made of glass-fibre-reinforced composite or glavanised steel
Drainage channel body made of glass-fibre-reinforced composite for a high temperature resistance and dimensional stability
MEAFLUID
MEAFLUID 11
MEAFLUID
MEAFLUID fluid redefines the boundaries in the use and installation of channels thanks to the versatility of possibilities in which this system can be used for drainage purposes.
MEAFLUID is particularly adapted for being used in gardens, front yards and green spaces, offering high water drainage levels coupled with extra long living qualities. MEAFLUID is ideal for all who are searching for a professional quality drainage solution coupled to an easy-to-handle and fast-to-mount product at a fair price.
Features
• Extremely sturdy thanks to the GRP material
• Widths: 100 and 150 mm
• Exceptional value for money
• Easy to install
• Very light and extremely stable
• Small range of compatible accessories available
Particularly stable design
Large choice of channel covers are available
Smooth surface / optimised water flow
MEA APPLICATION AREAS 12
HARBOURS AND CONTAINER TERMINALS
PARKING LOTS AND GREEN AREAS
UNDERGROUND GARAGES AND PARKING DECKS
TRAM AND RAIL SOLUTIONS
AIRPORTS (AIRSIDE)
MEA APPLICATION AREAS 13
DRAINAGE OF INNER CITIES AND PARKS
INFRASTRUCTURE AND TRAFFIC
GREEN ROOFS, TERRACES AND FACADES
GAS STATIONS
