SINGLE PHASE ENERGY METER WITH THEFT DETECTION Shruti Mahant 1, Deepak Nishad2, Prabha Nishad 3, Sarita Sahu4 , Yuvraaj Suryawanshi ⁵, Prof. A.K. Jain⁶ 12345UG Student, Department of Electrical & Electronics Engineering, CEC Bilaspur, Chhattisgarh, India 6Professor , Department of Electrical & Electronics Engineering, CEC Bilaspur, Chhattisgarh, India

------------------------------------------------------------------------------***--------------------------------------------------------------------------------

ABSTRACT - One of the biggest issues facing power distribution firms is electricity theft, which causes large financial losses and power system instability. The “Single Phase Energy Meter with Theft Detection” technology that is being suggested is intended to detect unauthorized electricity use while also precisely measuring energy consumption. In order to continuously monitor electrical characteristics, this system integrates an Arduino board with current and voltage sensors using a microcontroller-based method. The system looks for any unusual discrepancy between the energy supplied and the load actually consumed, which could point to theft situations such illegal tapping or meter bypassing. In order to stop further abuse, the system disconnects the supply using a relay module and sends out realtime alerts via an LCD display and buzzer upon detection. The project's execution improves energy monitoring systems' dependability, efficiency, and security. It also lowers non-technical losses and encourages equitable use of electricity.

The suggested model is a useful addition to contemporary smart energy management systems since it is affordable, simple to use, and appropriate for both residential and small-scale business applications.

KEY WORDS: Arduino, Energy Meter, Theft Detection, Current Sensor, Voltage Sensor, Relay Module, Smart Monitoring, Power System

INTRODUCTION The efficient use and management of electrical energy is crucial in today's world since it is used in many commercial, industrial, and residential settings. However, electricity theft has become a major problem that impacts consumers as well as power distribution corporations by resulting in diminished system reliability, power imbalance, and financial losses. Conventional energy meters are not able to identify illegal use or tampering because their main purpose is to quantify consumption. The idea of a smart energy meter with theft detection has been presented to get around these restrictions. The goal of this project is to useArduino technology to design a single phase energy meter that is integrated with an advanced theft detection system. In order to find differences, the system continuously monitors electrical parameters and compares actual consumption with expected levels. The system enhances accuracy and guarantees prompt response to theft scenarios by integrating automation, real-time monitoring, and alert methods. Because of this, it is a workable way to improve energy distribution systems' efficiency and transparency. Additionally, the demand for electricity has increased dramatically due to the fast population development and growing reliance on electrical appliances, placing further strain on the current power generation and distribution networks. In such a situation, even a tiny percentage of electricity theft might eventually result in significant losses that have an impact on the power sector’s overall sustainability and efficiency. Authorities find it challenging to act quickly since traditional surveillance techniques are frequently labor-intensive, manual, and unable to identify theft in real time. This emphasizes how urgently an automated and intelligent system that can precisely assess energy consumption and quickly identify anomalies is needed.

METHODOLOGY Continuous monitoring, data collection, processing, and decision-making form the foundation of the suggested system's methodology. A voltage sensor linked in parallel and a current sensor connected in series with the load are used to monitor the system's initial single-phase AC power supply. The Arduino microcontroller receives the analog signals produced by these sensors' real-time electrical parameter measurements. After processing these signals, the Arduino uses the proper calculations to determine the power usage. The computed load consumption and the provided energy values that are stored in the system are then compared.The system detects a theft condition if the difference between these numbers is greater than a predetermined threshold. When theft is detected, the Arduino shows the warning message and real-time data on the LCD screen and sounds a buzzer to provide an aural notice. In order to stop additional unauthorized use, a relay module is simultaneously activatedtocutoffthepowerstime detection and prompt intervention are ensured by the continuous operation of the entire process. Reliable system performance is ensured by appropriate connections made with jumper wires and a steady power source.

© 2026, IRJET

|

Impact Factor value: 8.315

|

ISO 9001:2008 Certified Journal

|

Page 3451

International Research Journal of Engineering and Technology (IRJET)

e-ISSN: 2395-0056

Volume: 13 Issue: 04 | Apr 2026

p-ISSN: 2395-0072

www.irjet.net

BLOCK DIAGRAM

FIG.1 BLOCK DIAGRAM OF SINGLE PHASE ENERGY METER WITH THEFT DETECTION

MATERIALS 1. ARDUINO- A key component of contemporary embedded systems and electronics projects is Arduino, an open-

source microcontroller-based development platform, particularly in applications like a single phase energy meter with theft detection. It functions as the system's brain, processing inputs, carrying out preprogrammed commands, and regulating outputs in response to real-time data. Because of their simplicity, adaptability, and ease of programming with the Arduino IDE, Arduino boards—like the Arduino Uno—are based on microcontrollers like the ATmega328P. In order to identify any anomalies, Arduino gathers information from current and voltage sensors, examines electrical parameters, and contrasts the power supplied and used. Arduino activates output devices like relays, buzzers, and LCD displays to notify users and take appropriate action if a discrepancy is discovered, suggesting potential electricity theft.

It is very compatible with a wide range of sensors and modules because it accepts both analog and digital inputs.

Arduino is a crucial part in creating effective, dependable, and affordable smartenergy systems because of its capacity for automated control, real-time processing, and continuous monitoring.

FIG.2 ARDUINO

© 2026, IRJET

|

Impact Factor value: 8.315

|

ISO 9001:2008 Certified Journal

|

Page 3452

International Research Journal of Engineering and Technology (IRJET)

e-ISSN: 2395-0056

Volume: 13 Issue: 04 | Apr 2026

p-ISSN: 2395-0072

www.irjet.net

2. CURRENT SENSOR – An essential tool for tracking power use and identifying irregularities in energy use is a current sensor, which measures the flow of electric current in a circuit. The current sensor in a single phase energy meter with a theft detection system continuously detects the current flowing through the load and transforms it into a measurable electrical signal that the Arduino can read. Hall-effect sensors and shunt resistors are common current sensor types that offer precise, real-time measurements without interfering with the circuit. By comparing this information with the anticipated or supplied current, the sensor assists in figuring out how much current the connected load is actually using. Unauthorized tapping or theft may be indicated if there is a disparity, such as lower recorded consumption compared to supplied current. Depending on their design, current sensors can measure both AC and DC currents and are extremely sensitive and dependable. They play a crucial role in guaranteeing accurate energy monitoring, enhancing system effectiveness, and making it possible to identify illicit activity in the electrical network.

FIG.3 CURRENT SENSOR RELAY MODULE – Relay modules are electrically operated switches that enable safe control of high-power electrical equipment using low-power signals from microcontrollers such as Arduino. When theft or unusual behavior is detected, the relay module in a single phase energy meter with theft detection automatically cuts off the power supply. It operates by means of an electromagnetic device that, in response to a signal from the Arduino, opens or shuts the circuit.

The Arduino signals the relay to turn off the electricity supply to the suspected line or load when the system detects a discrepancy in energy use that suggests potential theft. Relay modules ensure safety and shield delicate components from harm by isolating high voltage power circuits from low voltage control circuits. They are extensively utilized in automation systems when automatic or remote switching is necessary since they are very dependable. By detecting theft and acting quickly to stop additional loss, the relay module increases the system’s efficacy.

3.

FIG.4 RELAY MODULE 4. BUZZER – A buzzer is an audio signaling device that sounds to notify users of a certain system status or occurrence.

When unusual or unauthorized electricity usage is detected, the buzzer in a theft detection energy meter acts as an instant warning system. The buzzer alerts users or authorities to possible theft when the Arduino detects a discrepancy between supplied and utilized power. Buzzers are simple to interface with microcontrollers and come in a variety of forms, including passive and active. They are incredibly efficient for real-time alert systems and use very little electricity. Even from a distance, the buzzer’s sound aids in swiftly attracting attention , ensuring that the problem is identified and dealt with right away. By offering both visual (LCD) and audio alarms, this increases the system’s security and makes the monitoring system more reliable and user-friendly.

© 2026, IRJET

|

Impact Factor value: 8.315

|

ISO 9001:2008 Certified Journal

|

Page 3453

International Research Journal of Engineering and Technology (IRJET)

e-ISSN: 2395-0056

Volume: 13 Issue: 04 | Apr 2026

p-ISSN: 2395-0072

www.irjet.net

FIG.5 BUZZER 5. JUMPER WIRES - Jumper wires are straightforward but crucial pieces that create electrical connections between various circuit components without the need for soldering. They are frequently utilized during the testing and prototyping phases of electronic projects, particularly when using development boards and breadboards like Arduino. To ensure appropriate signal and power flow throughout the system, jumper wires are used to link sensors, modules, and other components to the Arduino in the energy meter with theft detection system. Depending on the needs of the connection, these wires can be male-to-male, male-to-female, or female-to-female. They are perfect for rapidly creating and altering circuits since they are adaptable, reusable, and simple to work with. Despite their seemingly insignificant size, they play a critical role in preserving dependable and stable connections, which directly affects the system’s overall accuracy and performance.

FIG.6 JUMPER WIRES 6. LIQUID CRYSTAL DISPLAY– An LCD (Liquid

Crystal Display) screen is an output device that makes it simpler for users to keep an eye on system settings and status by displaying information in a visual format. Voltage, current, power consumption, and theft alarms are all displayed in real time on the LCD screen of a single phase energy meter with theft detection.Without the need for complicated equipment or software, it offers an intuitive interface that makes system operation simple to comprehend. A 16x2 LCD display, which can display 16 characters per line across two lines, is typically utilized. The LCD shows the processed data in a legible format after receiving it from the Arduino. Additionally, warning messages are displayed on the screen to assist users in taking prompt action in the event of any abnormal condition or identified theft. LCD panels are a crucial part in improving the system’s usability and efficacy because they are extremely dependable, energy-efficient, and simple to use.

FIG.7 LIQUID CRYSTAL DISPLAY © 2026, IRJET

|

Impact Factor value: 8.315

|

ISO 9001:2008 Certified Journal

|

Page 3454

International Research Journal of Engineering and Technology (IRJET)

e-ISSN: 2395-0056

Volume: 13 Issue: 04 | Apr 2026

p-ISSN: 2395-0072

8.WIFI

MODULE

www.irjet.net

(ESP8266MOD)-

TheESP8266MOD is an inexpensive, highly effective Wi-Fi module that is frequently used to facilitate wireless communication and internet connectivity in embedded systems and Internet of Things-based projects. Its foundation is the ESP8266 microcontroller, which has an integrated TCP/IP protocol stack that enables devices to connect straight to a Wi-Fi network without the need for other hardware. This module is perfect for clever applications like a single phase energy meter with theft detection because of its powerful capabilities and small size. Real-time data, including voltage, current power consumption, and theft status, can be wirelessly sent to distant servers, mobile apps, or cloud platforms for monitoring and analysis by including the ESP8266MOD into the system.

The ESP8266MOD uses serial communication (UART) to connect to microcontrollers such as Arduino and runs on a 3.3V power source. It offers versatility in implementation by supporting many modes of operation, such as access point mode (building its own network), station mode (connecting to an existing Wi-Fi network), and both together. The module in this project can be configured to send messages or warnings whenever electricity theft is discovered, allowing users or authorities to respond quickly even when they are far away. Additionally, it has the ability to send and preserve previous data, which can be used to analyze trends of energy consumption and spot suspect activity over time.

WORKING PRINCIPLE

FIG.8 WIFI MODULE (ESP8266MOD)

A single phase energy meter with theft detection operates by continuously measuring, comparing, and analyzing electrical parameters to find any discrepancy between energy delivered and consumed. A voltage sensor linked in parallel and a current sensor connected in series with the load are used to monitor the single-phase AC supply that powers the system. The voltage and current passing through the circuit are continuously measured by these sensors, which then translate the results into proportionate analog outputs. The Arduino microcontroller, which serves as the system’s central processing unit, receives these signals after that.

The Arduino uses the relationship between voltage and current to compute the power usage after reading the sensor data. It continuously contrasts the measured load consumption with the system-programmed expected or supplied energy values. The input supply and the load consumption stay balanced within a particular range under normal circumstances. However, the system identifies any notable divergence as a possible theft circumstance, such as when electricity is unlawfully drawn from the line or the meter is circumvented.

The Arduino starts responding as soon as it detects a mismatch. In order to show the current values and a warning message about potential theft, it transmits signals to the LCD panel. In order to ensure that the problem is promptly identified, a buzzer is simultaneously turned on to offer an auditory indication. In order to stop additional unlawful use of electricity, the Arduino also manages a relay module that can cut off the power supply to the impacted line or load.

The system is able to continuously monitor, identify, and react to any aberrant state because this entire process occurs in real-time. The system is dependable and effective for contemporary energy management applications because of the integration of sensor, processing, and control components, which guarantees precise energy measurement and efficient theft detection.

© 2026, IRJET

|

Impact Factor value: 8.315

|

ISO 9001:2008 Certified Journal

|

Page 3455

International Research Journal of Engineering and Technology (IRJET)

e-ISSN: 2395-0056

Volume: 13 Issue: 04 | Apr 2026

p-ISSN: 2395-0072

www.irjet.net

CIRCUIT DIAGRAM

FIG.9 CIRCUIT DIAGRAM OF SINGLE PHASE ENERGY METER WITH THEFT DETECTION RESULTS AND DISCUSSIONS The suggested approach was successfully put into practice and evaluated in a variety of scenarios to assess its effectiveness. The outcomes showed that the system’s real-time measurements of voltage, current, and power consumption are accurate. The system showed reliable readings and no false alarms when it was operating normally.

The system successfully identified the anomaly and activated the alarm mechanis ms when an imbalance between supplied and used energy was introduced to simulate a theft condition. The LCD showed real-time parameters and a theft warning message as soon as the buzzer went off. By successfully cutting off the power supply, the relay module stopped more energy loss. Under many conditions, the system demonstrated dependability, effectiveness, and responsiveness.

However, environmental variables and component limits caused some variances in sensor readings, which can be reduced with appropriate calibration and sophisticated components.

FIG.10 OUR MODEL ADVANTAGES AND APPLICATIONS Advantages: 1. Provides accurate measurement of electricity consumption in real time.

2. Effectively detects electricity theft by comparing supplied and consumed energy.

3. Reduces power losses and improves efficiency of the distribution system. © 2026, IRJET

|

Impact Factor value: 8.315

|

ISO 9001:2008 Certified Journal

|

Page 3456

4.

5.

6.

7.

8.

International Research Journal of Engineering and Technology (IRJET)

e-ISSN: 2395-0056

Volume: 13 Issue: 04 | Apr 2026

p-ISSN: 2395-0072

www.irjet.net

Relay module enables immediate disconnection of power supply during theft.

Minimizes human intervention through automation and continuous monitoring.

Cost-effective and easy to implement using simple electronic components.

Enhances reliability and transparency in energy usage.

Automatic alert system using buzzer and LCD display for quick notification.

Applications: 1.

2.

3.

4.

5.

6.

7.

8.

Used in homes to keep an eye on power consumption and deter theft.

Suitable for small businesses, such as stores and office .

Helps electricity boards identify and manage unauthorized power use.

It can be used for sophisticated energy management in smart grid systems.

Suitable for small-scale industrial settings to track load and identify irregularities.

When combined with IOT devices, it facilitates remote energy monitoring.

Beneficial in isolated and rural locations where electricity theft is more prevalent.

It can be used for equitable usage tracking in shared buildings, hostels, and residences.

CONCLUSION In conclusion, the project on a single phase energy meter with theft detection offers a workable and efficient solution to electricity theft, one of the main problems the power distribution industry faces. Using cutting-edge embedded technology, the system effectively combines the capabilities of precise energy measurement and intelligent monitoring. The system can continually monitor electrical parameters and detect any discrepancy between provided and consumed energy by integrating components like voltage and current sensors with an Arduino microcontroller. The system is very responsive and dependable because of this comparison-based method, which guarantees that even minute abnormalities can be found in real time.By clearly and promptly notifying users of any abnormal situation, alert mechanisms such an LCD display and buzzer improve userawareness. Additionally, the addition of a relay module adds a crucial control feature that enables the system to instantly cut off the power supply in the case that theft is detected, preventing additional energy loss.

In addition to lowering the requirement for manual inspection, this automation raises the monitoring process’s general efficacy and efficiency. The project is economically achievable while maintaining great performance thanks to the use of straightforward and affordable components.

Another significant aspect of this project is its flexibility and potential for future enhancement. The system can be easily upgraded by integrating communication technologies such as Wi-Fi or IoT modules like ESP8266, enabling remote monitoring, data logging, and real-time alerts through mobile or web applications. This opens the door for its application in smart grids and advanced energy management systems. Additionally, the project promotes responsible electricity usage among consumers by discouraging illegal practices and ensuring fair distribution of power.

All things considered, the single phase energy meter with theft detection shows how automation and embedded technologies may be successfully applied to solve practical issues. It helps to lower non-technical losses and increase the dependability of power systems in addition to improving the precision and transparency of energy usage. The project emphasizes the significance of implementing clever solutions for sustainable and effective energy management in the future and provides a solid basis for future innovation in smart metering technology.

REFRENCES [1] Arduino, “Arduino Official Documentation,” [Online]. Available: https://www.arduino.cc.

[Accessed: Apr. 2026].

[2] IEEE, “Electricity Theft Detection Techniques,” IEEE Xplore Digital Library, [Online].Available:https://ieeexplore.ieee.org. [Accessed: Apr. 2026].

[3] ScienceDirect, “Smart Energy Metering Systems and Applications,” [Online].

Available: https://www.sciencedirect.com. [Accessed: Apr. 2026].

[4] ResearchGate,“Design and Implementation of Smart Energy Meter,” [Online].Available: https://www.researchgate.net. [Accessed: Apr. 2026].

[5] Springer, Electric Power Theft Detection and Prevention Methods. Springer, 2019.

© 2026, IRJET

|

Impact Factor value: 8.315

|

ISO 9001:2008 Certified Journal

|

Page 3457

International Research Journal of Engineering and Technology (IRJET)

e-ISSN: 2395-0056

Volume: 13 Issue: 04 | Apr 2026

p-ISSN: 2395-0072

www.irjet.net

[6] H. G. R. Tan, C. H. Lee, and V. H. Mok, “Automatic power meter reading system using GSM network,” in Proc. IEEE Int. Conf., 2007.

[7] S. McLaughlin, D. Podkuiko, and P. McDaniel, “Energy theft in the advanced metering infrastructure,” IEEE Systems Journal, vol. 6, no. 3, pp. 1–9, 2012.

[8] National Instruments, “Basics of Voltage and Current Measurement,” [Online]. Available: https://www.ni.com.

[Accessed: Apr. 2026].

[9] Electronics Hub, “Energy Meter using Arduino and Current Sensor,” [Online]. Available: https://www.electronicshub.org. [Accessed: Apr. 2026].

[10] TutorialsPoint, “Arduino and Embedded Systems Tutorial,” [Online].

Available: https://www.tutorialspoint.com. [Accessed: Apr. 2026].

[11] GeeksforGeeks, “Basics of Sensors and Microcontrollers,” [Online].

Available: https://www.geeksforgeeks.org. [Accessed: Apr. 2026].

[12] A. I. Khandaker et al., “Design of smart energy meter with theft detection,” International Journal of Engineering Research, vol. 5, no. 4, pp. 234–239, 2018.

[13] All About Circuits, “Working of Current and Voltage Sensors,” [Online]. Available: https://www.allaboutcircuits.com. [Accessed: Apr. 2026].

[14] Microchip Technology, “ATmega328P Datasheet,” [Online].

Available: https://www.microchip.com. [Accessed: Apr. 2026].

[15] Google Scholar, “Research papers on energy meter and theft detection,” [Online]. Available: https://scholar.google.com. [Accessed: Apr. 2026].
