Schumacher Easy Cut II Cutting Harvest System

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:13 Seite 1

The Schumacher Cut

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:13 Seite 2

THE ORIGINAL

www.schumacher-original.com

2

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:13 Seite 3

The SCHUMACHER Cut

Cutting system Easy Cut II

page 6 - 7

Mounting instruction

page 8 - 9

Kits Easy Cut II

page 10 - 11

Guard S4

page 12 - 15

MultiTool

page

17

Roller guide R1 R2

page

18

Wear plates

page

19

Section Pro Cut

page 20 - 21

Standard Comfort Premium

Check wear of the gap

page

16

Check section serrations

Sectional knife

page 22 - 23

Crop lifter ASK

page 24 -29

The Original

page

Types Mounting instruction

30

3

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:13 Seite 4

Schumacher - your partner for a smart cut!

Did you already know that a clean cut increases your harvest yields? Why is that possible? Cutting systems are prone to significant wear and therefore have to be checked frequently.

If you postpone the replacement of parts for too long, it can cost you time and money caused by the time needed for repairs on the fields or less acres harvested. Even a slower driving speed of the combine by only 0.3 km/h for an average of 1.000 acres (400 hectares) performance can cause losses of thousands of dollars. From 2010 on, we offer the latest cutting technology with Schumacher Easy Cut II products. In this brochure you can read how to replace parts, upgrade your existing Schumacher system or change over to the new Easy Cut II cutting system.

THE ORIGINAL 4

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:13 Seite 5

A smart cut!

Easy calculating: Easy deciding: Easy assembling:

The same price per foot (metre) for all combine types.

The same components for all combine types.

For mounting the system all you need is a standard set of tools.

A smart cut!

5

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:13 Seite 6

THE ORIGINAL Easy Cut II – 3 different versions.

Your harvesting success begins with a smart cut.

The standard version includes all established components for a good cut. You will benefit from the technical innovations offered by Easy Cut II. The roller guides can be mounted subsequently very easily without much time and effort.

All Schumacher products can be mounted with standard tools.

6

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:14 Seite 7

Cutting system Easy Cut II R1

▼

top guiding rollers (every 2 feet)

The top guiding roller. For a straight knife movement.

The advantage of a straight knife movement is an extended lifetime of knife and guards. We recommend using the top guiding rollers in combination with wear plates for all established cutting units and combine types.

R2

▼

R1

▼

top and bottom guiding rollers (alternating every foot)

“Twice the roll”. For wide cutter bars.

The additional advantage of the bottom guiding roller means less friction on the knife back and therefore less wear. We recommend using the bottom guiding roller for cutting widths starting at a minimum of 20 feet (6 metres). It is not recommended for all types of cutting units, please ask us if the premium version is suitable for your combine!

7

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:14 Seite 8

THE ORIGINAL

A

wear plate: arrow points ahead in driving direction

A A

20

A

m m

A A Or the cutting system starts with:

A A

R1 A

A

2 `=

R1

61 0

A

mm

A A

R1 A

A

R1 8

Top guiding roller: (every 2 feet) The first roller (top guided) is mounted right after the first wear plate.

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:14 Seite 9

Mounting instruction

A

A

R2 B

A R1

1`=

A B

R2 B

B

A

30 5m m

R1 A

20

m m

Attention: Turn the wear plate around and mount as a spacer bar: Arrow points backwards in mounting direction.

A

R1

Top and bottom guided roller are mounted alternating every foot.

The first roller (top guided) is mounted right after the first wear plate.

R1 A

R2

A

9

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:14 Seite 10

THE ORIGINAL

Schumacher Kits ready to mount.

You can find the most popular conversion kits for Claas John Deere Deutz-Fahr MF, Fendt Fiatagri-Laverda New Holland IHC www.schumacher-original.com

10

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:14 Seite 11

Knivdrivning Kits Easy Cut II

Example: Claas

Example: New Holland

Example: John Deere

11

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:14 Seite 12

THE ORIGINAL Efficient flow. More cut.

The new Schumacher double guard S4 easily leads more crop into the cutter bar. In order to make that possible, cutting edges have been reworked and the opening for the crops has been enlarged.

double guard

S4 since 2010

lowered and broadened bar

op cut timi tin zed ge dge

always with SCH logo

more room for improved flow of crops continuous bar

squared hole

Advantages of a Schumacher double guard High stability. Great protection from impacts.

Quality spring steel construction.

12

Double cutting edges for a balanced knife guidance.

Once mounted, no further adjustments will be necessary.

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:14 Seite 13

Guard S4 Type double guard

code-no.

production-code

ident-no.

code-no.

dimension -X- colour

ident-no.

2

12 mm

black

16500.01

4

14 mm

red

16501.01

7

17 mm

grey

16502.01

13

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:14 Seite 14

THE ORIGINAL Type triple guard

14

double first guard v/o

code-no.

dimension -X- colour

ident-no.

dimension -X- colour

ident-no.

2

12 mm

black

16503.01

12 mm

black

10701.01

4

14 mm

red

16504.01

14 mm

red

10702.01

7

17 mm

grey

16505.01

17 mm

grey

10703.01

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:14 Seite 15

Guard S4 Dimension -Xv/o

Please note: the mounting dimension determines the type of double guard (12/14/17 mm) and the thickness of the wear plate (4/5/6 mm).

dimension -X-

wear plate angle bar

Example angle bar

6 mm

+

7 mm

+

9 mm

+

wear plate 6 mm

=

5 mm

=

5 mm

=

dimension -X12 mm

14 mm 12 mm

example

John Deere

New Holland / Case / MF Laverda

!

Possible consequences of an incorrect mounting: Mounting of a 12 mm double guard on a dimension of 14 mm: The guard will be extended. The gap becomes too wide and the knife has too much room for movement.

!

Mounting of a 14 mm double guard on a dimension of 12 mm: The guard will be squeezed. The gap becomes too tight and the knife cannot move properly anymore.

!

15

!

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:14 Seite 16

THE ORIGINAL Wear of guards. Check the gap.

Guards should be checked regularly for wear. A new guard has a gap of 3.8 - 4.2 mm.

new guard, gap 3.8 – 4.2 mm

Replace now!

wear of the gap > 5.4 mm

A cutting gap of more than 5.4 mm causes “floating” of the knife. The rounded cutting edges cannot hold and cut the crops properly anymore. They will get pulled into the cutting gap.

!

Further checking for wear during the change of guards.

!

16

!

When changing the guards, simply check the wear plates as well. If the edges of the plates also show wear, the knife is unstable and so the new guards will be worn out quickly again.

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:15 Seite 17

Knivdrivning MultiTool Schumacher MultiTool as key ring.

The new handy Schumacher MultiTool is an ideal companion for all combine-operators:

1. Cutting Clearance Testing Tool You can immediately see the current wear of the guards.

4.0 – 5.4 mm

2. Hexagon | Wrench 10 mm | Screw Driver Helps you to open the side covers of the combine and header.

13 mm

8 mm

8 mm

3. Hint: integrated bottle opener

17

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:15 Seite 18

THE ORIGINAL Upgrade your existing Schumacher cutting system with roller guides.

If you own a Schumacher cutting system already, you can simply upgrade it with roller guides and gain the advantage of a great knife guidance. Choose your option of rollers along with the new shortened wear plates.

ident-no.

16330

The top guiding roller R1 holds the knife in a straight line, preventing the section from tipping downwards. This protects sections and guards from wear.

! ! !

R1 top guiding roller

ident-no.

In combination with the top guiding roller, the bottom guiding roller takes care of the knife guidance instead of the wear plates only. This means less friction, less vibration and less wear on the drive unit.

18

! ! !

R2 bottom guiding roller

15768

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:15 Seite 19

Roller guide R1 R2 |Knivdrivning Wear plates The new wear plate.

In the new shortened version applicable as either a wear plate or a spacer bar. mounting direction thickness ident-no.

A B C

A B C

dim ens ion

-X-

dim ens ion

dim ens ion -X-

thickness

dimension colour

ident-no.

5 mm

256 mm

10742.01

4 mm

6 mm 4 mm 5 mm

6 mm 4 mm 5 mm

6 mm

256 mm

grey khaki 10741.01

256 mm

black

180 mm 180 mm 180 mm 104 mm 104 mm 104 mm

blue

-X-

10743.01

grey khaki 17014.01 blue

black

17015.01

17016.01

grey khaki 17011.01 blue

black

17012.01 17013.01

19

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:15 Seite 20

THE ORIGINAL High quality Pro Cut sections for the Schumacher system.

Cleaning ridge for a clear cut.

! ! ! ! ! ! !

Different serrations of the sections for various harvesting conditions and crops.

Balanced cutting forces due to the alternated mounting of the sections (top and bottom cutting).

Cut-outs remove soil and other particles from the gap.

Pro Cut sections can be replaced easily.

The special Schumacher section-bolt with a splined shaft offers a safe, tight fit of the section on the knifeback.

section-bolt nut

set of bolts and nuts

packaging unit 50 pieces

20

ident-no.

10931.08

13961.06 15426.01

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:15 Seite 21

Section Pro Cut Section types for various conditions.

11 t pi

14 t pi

Easy Cut II knife assemblies can be supplied with fine or coarse sections as required.

fine coarse 14 tpi = 14 teeth per inch 11 tpi = 11 teeth per inch 25 teeth per length of section 19 teeth per length of section tpi indicates the number of teeth per inch (=25.4 mm)

type

ident-no.

coarse 11 tpi

10961.06

fine 14 tpi

packaging unit 25 pieces

Check frequently. Check section serrations for wear.

Teeth of section pointed

Teeth of section worn & rounded

10966.06

If the teeth are extremely pointed, the section will not cut cleanly.

The teeth will grab the stalk instead of cutting it and pull it into the cutting gap of the guard. This will increase knife load which demands increased power requirements.

If the teeth are rounded, the knife is blunt and the crops will not be cut properly anymore. This will cause increased power requirements as well.

!

! !! !! ! !

21

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:15 Seite 22

THE ORIGINAL Easy transport, storing, handling and mounting.

! !

! !

alter nat mou nted ely sectio ns

Easy handling of the knife sections Easy connection of the knife sections with the knife connector kit

A

Knife connector kit Easy and tight fit due to use of loctited bolts type fine section

A knife connector kit 10-hole

22

ident-no.

16831

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:15 Seite 23

Sectional knife All knives are packed & protected in a 2.60 m cardboard box.

All kn ive sa re pa cke d

in a

2.6 0m

car db oa rd bo x.

Schumacher sectional knives are packaged in a box measuring 2.60 m in length. That ensures reasonable freight costs and less possibility of damage during transit.

23

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:15 Seite 24

THE ORIGINAL The Schumacher crop lifter lasts longer.

I am strong.

I am grey.

I’ve got profile.

sliding curved

concave sliding skid

24

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:15 Seite 25

Crop lifter ASK The operational safety of your combine is the pre-condition for a high performance in harvest threshing. Every summer and with any kind of weather. Support the demands of your combine by using original Schumacher crop lifters.

standard crop lifter

ASK slim

file pro

sliding skid curved

mounting module with bend first rivet with more clearance height

25

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:15 Seite 26

THE ORIGINAL

Dimension -Zdimension -Z-

The dimension -Z- describes the distance between the end of the mounting module and the end of the sliding skid.

26

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:15 Seite 27

Crop lifter ASK Types ASK These crop lifters are available for all relevant combine types.

combine harvester

type

dimension -Z-

ident-no.

AGCO PowerFlow from 2007 (Fendt-MF-Laverda)

ASK-100

132.3 mm

16445.01

Deutz-Fahr (SDF)

ASK-100

132.3 mm

16445.01

John Deere series 800-900-600

ASK-100

132.3 mm

16445.01

Laverda from 2000

ASK-100

132.3 mm

16445.01

AGCO PowerFlow until 2007 (Dronningborg-Fendt-MF)

ASK-120

137.3 mm

16587.01

CASE 1030 Freeflow

ASK-120

137.3 mm

16587.01

CASE cutting unit 2030, 2040 and 2050, 3050

ASK-127

144.5 mm

16589.01

all CLAAS cutting units

ASK-121

143.0 mm

16588.01

Laverda/Fiatagri until 2000

ASK-120

137.3 mm

16587.01

New Holland cutting unit Standard + Varifeed

ASK-127

144.5 mm

16589.01

all headers using Schumacher system

all headers using forged guard system

coloured label with type number 27

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:15 Seite 28

THE ORIGINAL Your advantage in appliance The ASK reliably indicates when wear occurs.

!

From tip to mounting module, the sliding skid is concave shaped.

Concave shaped profile

! ! !

! ! !

Critical wear appears only in the middle of the sliding skid. The sides remain solid.

The crop lifter remains solid.

The ASK doesn’t wear out quickly.

!

The new bend at the mounting module offers more ground clearance for the first rivet. So wear will be reduced considerably.

New: Module with bend

Example of wear with a conventional crop lifter Crop lifters without bend are subject to wear more easily.

Wear of a mounting module of a crop lifter operated parallel to the ground.

28

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:15 Seite 29

Crop lifter ASK Crop lifter fitting with KM-3 and SM-4 fastener screw M 10 x 55

spool nut JD-2

KM-3

disc 25 x 10,5 x 4 nut M 10

ident-no. 10248

Đœ 10 Ń… 40

SM-4

SM-4

ident-no. 10255

The mounting kit modules KM-3 and SM-4 ensure a quick and firm mounting of the crop lifter.

Adjustable in height due to spring clip

3 positions

Set the crop lifter into the best position. 3 possible positions for the fixation of the spring clip allow an adjustment at the correct height.

CORRECT !

WRONG !

WRONG !

The crop lifter is operated parallel to the ground.

The crop lifter moves upwards and runs above the crops.

The crop lifter digs itself into the ground.

29

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:16 Seite 30

THE ORIGINAL Only The Original can achieve that!

Combine harvesters are high performance machines.

So the operational safety and impact power should be ensured by using quality parts only.

30

SCH logo on the mounting module

SCH logo on the section bolt

SCH logo on the section

SCH logo on the guard

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:16 Seite 31

SCHUMACHER. SCH – a strong brand Schumacher stands for 45 years of experience and presence on 5 continents. Original Schumacher products are used every day throughout the world.

So why don’t you start using it too?

Further information on www.schumacher-original.com

31

Easy Cut II Mini Australien 2011_Layout 1 12.10.11 17:16 Seite 34

www.schumacher-original.com

This brochure is available in:

Toowoomba 94 Buckland Street, Toowoomba, Qld 4350 Tel: 07 4636 91 50 Fax: 07 4636 91 70 www.gwtillage.com.au

Bendigo Unit 2 - 204 Strickland Road, East Bendigo, Vic 3550 Tel: 1800 087 871 Fax: 1800 087 971
