FRCPath 2 teaching H&N 2023

FRCPath Part 2 Surgical Course

Head & Neck Pathology

Eranga Nissanka-Jayasuriya Consultant Head & Neck Pathologist William Harvey Hospital, Ashford, Kent

Marking Scheme 3.5

3.0

2.5

2.0 1.5 1.0

Case 1

Case 1

26-year-old, Female, Parotid tumour

PART 2 SURGICAL COURSE - HEAD AND NECK PATHOLOGY PREETHA CHENGOT

??

Case 1- Salient points • Circumscribed salivary tumour, infiltrative periphery • Papillary cystic, microcystic patterns, hobnailing • Solid sheets of large polygonal cells with granular eosinophilic cytoplasm and vesicular nuclei • Secretory material –colloid-like eosinophilic secretions • Occasional mitotic figures

• Work up? PAS, DPAS, • CK7, S100, DOG1, Mammoglobin

Case 1 Diagnosis

Secretory carcinoma

Discussion Differential diagnoses • Acinic cell carcinoma • Secretory carcinoma (previously called MASC) • MEC • 90% -ETV6::NTRK3 fusion -chromosomal rearrangement, t(12;15) (p13;q25) • ETV6::RET, ETV6::MET, ETV6::MAML3 • ETV6 translocation-negative secretory carcinoma.

• Similar to Acinic cell carcinoma • But S100+, Mammoglobin+, DOG1-

Mammaglobin

S100

GATA3

ETV6 FISH

WHO 5th ed Essential and desirable diagnostic criteria • Essential: single cell type with vacuolated colloid-like secretory material; no zymogen cytoplasmic granules; IHC positivity for S100 protein, SOX10, and mammaglobin; lack of IHC staining for p40 and/or p63 • Desirable: ETV6 or RET rearrangement demonstrated by FISH, RNA sequencing, or PCR • Low grade • Lymph node metastases are reported in as many as 25% of cases

Case 2 56-year-old, Male Dysphagia And Lump In Pharynx

56-year-old, Male Dysphagia And Lump In Pharynx.

Case 2- Salient points • Multicystic and solid • Epidermoid, clear cells and mucous cells • Low grade- predominantly cystic • Work up? ABPAS, DPAS • CK7, P63 • Molecular: translocation at t(11;19)(q21;p13) expressing CRTC1::MAML2 fusion gene • DD-papillary cystadenoma, mucous retention cyst

??

Case 2 Diagnosis

Mucoepidermoid carcinoma, low grade

MEC Grading

commonest grading system: https://www.ncbi.nlm.nih.gov/pubmed/1544111 -Intracystic component <20% -Neural invasion -Necrosis -Mitoses >4/10 hpf -Ananplasia Other grading systems: https://www.ncbi.nlm.nih.gov/pubmed/9529011, https://www.ncbi.nlm.nih.gov/pubmed/11420454, https://www.ncbi.nlm.nih.gov/pubmed/25040772

Selected Geneticalterations Alterations in in Salivary Glandtumours Tumors Selected genetic salivary Tumor

Alteration

% cases

Acinic cell carcinoma

NR4A3 fusions HTN3-MSANTD3 fusion

95% 5%

Adenoid cystic carcinoma

MYB-NFIB MYBL1-NFIB MYB activation/amplification

~80%

Basal cell adenoma/ Basal cell carcinoma

CTNNB1 or CYLD mutation

40-80% (adenoma) 5-30% (carcinoma)

Clear cell carcinoma

EWSR1-ATF1

~80-90%

Epithelial-Myoepithelial Carcinoma

PLAG1 or HMGA2 fusions HRAS mutations

~50%

Low-grade intraductal carcinoma

NCOA4-RET

~50%

Mucoepidermoid carcinoma

CRTC1-MAML2 CRTC3-MAML2

~70-80%

Pleomorphic adenoma and carcinoma expleomorphic adenoma

PLAG1 or HMGA2 fusions

~60-90%

Polymorphous adenocarcinoma

ARID1A-PRKD1 DDX3X-PRKD1 Other PRKD2 and PRKD3 fusions

~20-50%

Salivary duct carcinoma

TP53, HRAS, PIK3CA, PTEN mutations ERBB2 amplification PLAG1 or HMGA2 fusions

90-100%

Secretory carcinoma

ETV6-NTRK3 ETV6-RET ETV6-MET

100%

Case 3

21-year-old, Female, Lump In Floor Of Mouth.

Case 3- Salient points • Pseudocyst lined by compressed rim of foamy macrophages • No epithelial lining • Associated with atrophic minor salivary glands

??

Case 3 Diagnosis

Mucous extravasation cyst (extravasation mucocoele)

HN4

Case 4

• Female 40 years Firm nodule dorsum of tongue. Present for months. Case type Oral.

Specimen: Tongue.

Macroscopic description: Mucosa 15 x 12 mm with firm tissue to depth of 9 mm.

Immunohistochemistry: None.

Case 4- Salient points • Nodular mucosa with circumscribed tumour with infiltrative periphery • Large cells with eosinophilic granular cytoplasm • Is surface epithelium normal?

??

Case 4 Diagnosis

Granular cell tumour

Case 5 16-year-old, Female, Cyst Associated With Unerupted Lower Wisdom Tooth.

Case 5- Salient points • Non-specific thin squamous epithelial lined cyst • No keratinisation, basal palisading • Largely uninflamed fibrous cyst wall

• Location + histology

??

Case 5 Diagnosis

Dentigerous cyst

Common odontogenic cysts & tumours • Dentigerous cyst • Radicular cyst • Odontogenic keratocyst • Orthokeratinised odontogenic cyst • Ameloblastoma • Radiology is a must- Location, relationship to tooth and nature of radiolucency can give diagnostic cluses

Case 6 28-year-old, Male Nasal Polyp.

??

Salient points • Laminated mucin • Degenerate eosinophils • Charcot-Leyden crystals • Fungal hyphae (usually fungal ball)

Case 6 Diagnosis

Allergic fungal rhinosinusitis

Case 7 62-year-old, Female Block From Maxillectomy Specimen.

Case 7- Salient points • SCC • Is lymphoid tissue normal- small monotonous sheets, no follicles • Work up- IHC

??

Case 7 Diagnosis

Squamous cell carcinoma and Lowgrade small cell lymphoma (Grade 1 follicular type NHL)

Case 8 • Male 14 years

Spontaneous swelling of the lower lip and mucosa generally. Unresponsive to antivirals. No other relevant medical history.

Specimen: Left buccal mucosa.

Macroscopic description: punch biopsy 4x3x3mm.

Immunohistochemistry: D/PAS negative.

??

Case 8 Diagnosis

Oral granulomatous inflammation likely orofacial granulomatosis

• Cobblestone cheek swelling and lip swelling • Children, young adults

• Associated with sarcoidosis and Crohn’s disease (could be the presenting feature before GI symptoms start)

Case 9

38-year-old Female, Cyst Associated With Unerupted Wisdom Tooth.

??

Case 9 Diagnosis

Odontogenic keratocyst

Salient points •Basal cell palisading •Corrugated parakeratosis •Focal inflammation –loss of above and “non-specific” features •Consistent loss of PTCH tumour suppressor gene- GorlinGoltz syndrome •Tendency for recurrence

Case 10 66-year-old Excision Of Tumour Tongue / Floor Of Mouth.

??

Case 10 Diagnosis

Mucosal melanoma

• • • • • • • •

80% of head and neck MM- nasal cavity, septum, maxillary sinus In the oral cavity-maxillary gingiva and palate Flat pigmented lesions Tumour cells are polymorphic Lentiginous/pagetoid growth pattern All head and neck mucosal MM are T3–4 and stage III-IV T3 Tumour limited to the epithelium and/or submucosa (mucosal disease) T4a Tumour invades deep soft tissue, cartilage, bone, or overlying skin

• Oral pigmented patches DD • • • •

Melanotic macule Smokers melanosis Amalgam tattoo Naevi

Case 11

Numbness Of Face (Distribution Of Infraorbital Nerve) Biopsy From Infratemporal Fossa.

??

Case 11 Diagnosis

Amyloidosis

Salient points • Deposition of hyalinised eosinophilic material in stroma •Congo red +++ •Consider type •? Assoc with plasma cell dyscrasia –Kappa and lambda check plasma cells at edge of lesion •Systemic investigations for AL ? Myeloma, H&N AL commonest •AA / hereditary

Case 12

55-year-old, Male Lump In Parotid.

??

Case 12 Diagnosis

Acinic cell carcinoma

Notes • Lymphoid stroma • ACC • MEC • Prognostic factor- better prognostic indicator • ACC can undergo HG transformation

Case 13 • Female 24 years Lesion left forehead with a 6-8 week history of recurrent headaches. ? cause.

Specimen: Skull.

Macroscopic description: Disc of bone covered on one surface by elevated soft tissue. Cut sections reveal a central bone cavity filled with granular material.

-

??

Case 13 Diagnosis

Langerhans cell histiocytosis

• Langerhans cell histiocytosis (LCH) is a clonal neoplastic proliferation of myeloid dendritic cells expressing LC phenotype • Single system/ multisystem involvement • cranial and facial bones, skin, gingiva, or cervical lymph nodes • intra-osseous ill-defined unilocular radiolucency with gingival involvement and tooth mobility.

• >99% survival for unifocal disease LCH cell clusters are diagnostic, but caution is needed in lymph nodes because paracortical dendritic/LCs are indistinguishable from sinus-based LCH cells.

Case 14

42-year-old, Female Lump In Neck.

??

Case 14 Diagnosis

Carotid body tumour

• Well differentiated non-epithelial neoplasms derived from paraganglion cells of the autonomic nervous system.

• Hereditary predisposition- 40% • Hereditary paraglanglioma syndrome • Germline mutation in SDHD (47%), SDHB (30%), SDHC (16%) • 3-4% risk of metastasis DDThyroid- medullary carcinoma Laryngeal neuroendocrine tumours Parathyroid tumours

HN15 60-year-old, Male Epistaxis, Numbness Of Cheek And Proptosis.

??

Case 15 Diagnosis

Sinonasal undifferentiated carcinoma (SNUC)

Sinonasal round blue cell tumours broad variants •Epithelial •Mesenchymal •Neuroectodermal •Haematolymphoid

pancytokeratin p63 (or p40) synaptophysin chromogranin S100 desmin CD45 CD99

Epithelial • non-keratinizing squamous cell carcinoma (NKSqCC) • non-keratinizing nasopharyngeal carcinoma (NKNPC) • basaloid squamous cell carcinoma (BSqCC) • NUT midline carcinoma (NMC) • lymphoepithelial carcinoma (LEC) • adenoid cystic carcinoma (solid pattern) (AdCC) • small cell carcinoma, neuroendocrine type (SmCCNET) • HPV related multiphenotypic sinonasal squamous cell carcinoma • SMARCB1/SMARCA4- deficient CA • sinonasal undifferentiated carcinoma (SNUC)

Neuroectodermal • Olfactory neuroblastoma (ONB) • Ewing sarcoma/peripheral primitive neuroectodermal tumour (ES/pPNET) • Malignant mucosal melanoma (MM) Haematolymphoid • Extranodal NK/T-cell lymphoma (NK/TCL); • Diffuse large B-cell lymphoma (DLBCL) and other B- and T-cell lymphomas; • Extramedullary myeloid sarcoma (myeloid sarcoma; MS) • Plasmacytoma Mesenchymal • Rhabdomyosarcoma (RMS) • Synovial sarcoma (SS) • Mesenchymal chondrosarcoma • Also metastases from other sites should be considered

Case 16 16-year-old, Male Epistaxis, Biopsy Of Mass, Upper Part Of Nasal Cavity.

??

Case 16 Diagnosis

Nasopharyngeal angiofibroma

• Puberty onset • Essential and desirable diagnostic criteria • Essential: male patient; posterior nasal cavity/nasopharynx location; numerous vessel types and sizes, some with muscular walls; stromal stellate fibroblasts with variably collagenized stroma • Desirable: ß-catenin and androgen receptor + in stromal cells

Case 17 71-year-old, Female Large Cystic Lesion Posterior Mandible.

??

Case 17 Diagnosis

Ameloblastoma

Case 18

28-year-old, Female Palatal Swelling.

??

Case 18 Diagnosis

Polymorphous adenocarcinoma (PLGA)

Case 19 Male 64 years, Left parotid gland mass.

??

Case 19 Diagnosis

Extranodal marginal zone lymphoma (MALT)

• H&N 2nd most common site after GI tract • Small lymphocytes and marginal zone cells • Monocytoid cells with abundant pale cytoplasm are sometimes present • Remnants of reactive follicles are common, sometimes with follicular colonization. Wellformed lymphoepithelial lesions

• Positive for CD20, CD22, PAX5), usually IgM, occasionally IgG or IgA, and rarely IgD, CD43 or TBX21 (T-bet) • Negative for CD5, CD10, BCL6, CD23, cyclin D1, SOX11, and EBV • Immunoglobulin light chain monotypia of B cells or plasma cells

Case 20 34-year-old, Male Nasal Tumour

.

??

Case 20 Diagnosis

NUT midline carcinoma

More common in young adults Foci of abrupt keratinization Pancytokeratin+, p63+, p40+, NUT1+ t(15;19); BRD4-NUT gene fusion

Case 21

Cyst From Apex Of Non-Vital Incisor Tooth

??

Case 21 Diagnosis

Radicular cyst

Case 22

19-year-old, Female Lymph Node Post Auricular Area.

Salient points Classic Triad • Reactive follicular hyperplasia, • Perifollicular / interfollicular epithelioid histiocytes -granulomas • Aggregates of monocytoid B cells.

??

Case 22 Diagnosis

Toxoplasmosis lymphadenitis

Case 23

22-year-old Female. Lymph Node From Neck.

??

Case 23 Diagnosis

Kikuchi Fujimoto disease (Kikuchi

histiocytic necrotizing lymphadenitis)

• Self-limiting, unknown etiology • Young adults of Asian origin • Histologic patterns: proliferative, necrotizing, and xanthomatous.

• DD- infectious lymphadenitis, autoimmune lymphadenopathy (primarily systemic lupus erythematosus), and lymphoma • Histomorphologic diagnosis • The histiocytes + lysozyme, myeloperoxidase, CD68, CD163, and CD4.

• The lymphocytes CD3-positive T cells demonstrating a predominance of CD8 compared with CD4, very few CD20positive B cells. Plasmacytoid dendritic cells - CD123+

Case 24 55-year-old, Male Parotid Swelling

??

Case 24 Diagnosis

Pleomorphic adenoma with ossification and atypia

Case 25 79-year-old, Male Parotid Swelling.

??

Case 25 Diagnosis

Warthin tumour with Small lymphocytic lymphoma

Case 26 46-year-old, Female Lump On Gum

.

•v

??

Case 26 Diagnosis

Peripheral ameloblastoma

Case 27 • Female 74 years 18 year history of submandibular swelling that has recently increased in size.

Specimen: submandibular gland.

??

Case 27 Diagnosis

In-situ carcinoma ex pleomorphic adenoma

Case 28 39-year-old, Male White Patch Buccal Mucosa, Smoker.

??

Case 28 Diagnosis

Lichenoid mucositis –lichen planus or lichenoid reaction

Case 29 57-year-old, Male White Patch Buccal Mucosa, Smoker.

??

Case 29 Diagnosis

Chronic hyperplastic candidosis

HN30 45-year-old M, Previous Multiple Excisions Of Nasal Tumour, Further Resection.

??

Case 30 Diagnosis

Squamous cell carcinoma arising in sinonasal inverted papilloma

Case 31 • Female 56 years

Slow growing lesion left neck from dorsal root C3. ? Nerve. Left posterior triangle. Present 20 years. Case type Combined.

Specimen: Neck.

Macroscopic description: Five bosselated nodules of soft tissue collectively measuring 55 x 45 x 15 mm.

Immunohistochemistry: S100 positive.

??

Case 31 Diagnosis

Ancient schwannoma

Case 32 • Male 58 years

Leukoplakia present 3/12.

Specimen: Incisional biopsy right side of tongue.

Macroscopic description: Mucosa 11 x5 x3mm.

Immunohistochemistry: none.

•

??

Case 32 Diagnosis

HPV related Oral intraepithelial neoplasia (Koilocytic dysplasia)
