FOG NOZZLES CLEANABLE NOZZLE WITH AISI 303 STEEL ANTI-DRIP SYSTEM FOR SLIP LOCK Ø6,35MM AND Ø9,6MM AISI 303 stainless steel new nozzle vs. classic brass nozzle

Code

Pack of

Flow rate Description factor AISI 303 stainless steel anti-drip nozzle, 15 UNC 10/24 thread, 0,15mm hole, complete with casing that acts as an adapter AISI 303 stainless steel anti-drip nozzle, 20 UNC 10/24 thread, 0,20mm hole, complete with casing that acts as an adapter AISI 303 stainless steel anti-drip nozzle, 30 UNC 10/24 thread, 0,30mm hole, complete with casing that acts as an adapter AISI 303 stainless steel anti-drip nozzle, 40 UNC 10/24 thread, 0,40mm hole, complete with casing that acts as an adapter AISI 303 stainless steel anti-drip nozzle, 50 UNC 10/24 thread, 0,50mm hole, complete with casing that acts as an adapter AISI 303 stainless steel anti-drip nozzle, 60 UNC 10/24 thread, 0,60mm hole, complete with casing that acts as an adapter AISI 303 stainless steel anti-drip nozzle, 70 UNC 10/24 thread, 0,70mm hole, complete with casing that acts as an adapter

IT.154C IT.204C IT.304C IT.404C IT.504C IT.604C IT.704C

100pcs 100pcs 100pcs 100pcs 100pcs 100pcs 100pcs

CLEANABLE NOZZLE WITH AISI 303 SS ANTI-DRIP SYSTEM FOR LINE WITH PRE-DRILLED Ø12MM PIPE How to install nozzles on a AISI 304 stainless steel pipe Code

IT.151C

Flow rate Description Pack of factor Nozzle made in AISI 303 stainless steel, with 15 100pcs anti-drip, threaded UNC 10/24, hole 0,15mm

IT.201C

20

Nozzle made in AISI 303 stainless steel, with 100pcs anti-drip, threaded UNC 10/24, hole 0,20mm

IT.301C

30

Nozzle made in AISI 303 stainless steel, with 100pcs anti-drip, threaded UNC 10/24, hole 0,30mm

IT.401C

40

Nozzle made in AISI 303 stainless steel, with 100pcs anti-drip, threaded UNC 10/24, hole 0,40mm

IT.501C

50

Nozzle made in AISI 303 stainless steel, with 100pcs anti-drip, threaded UNC 10/24, hole 0,50mm

IT.601C

60

Nozzle made in AISI 303 stainless steel, with 100pcs anti-drip, threaded UNC 10/24, hole 0,60mm

IT.701C

70

Nozzle made in AISI 303 stainless steel, with 100pcs anti-drip, threaded UNC 10/24, hole 0,70mm

FLOW RATE TABLE FOR AISI 303 STAINLESS STEEL NOZZLES Flow rate factor Nozzle

456

50bar

60bar

70bar

80bar

90bar

100bar

110bar

120bar

130bar

Pressure

15

0,043

0,047

0,050

0,058

0,064

0,068

0,070

0,072

0,075

LPM

20

0,063

0,071

0,075

0,081

0,085

0,091

0,093

0,097

0,102

LPM

30

0,091

0,102

0,105

0,116

0,122

0,132

0,140

0,146

0,150

LPM

40

0,128

0,142

0,150

0,159

0,169

0,185

0,190

0,197

0,209

LPM

50

0,160

0,180

0,190

0,195

0,209

0,228

0,235

0,240

0,250

LPM

60

0,180

0,196

0,210

0,228

0,241

0,255

0,275

0,285

0,300

LPM

70

0,209

0,228

0,240

0,256

0,274

0,294

0,305

0,315

0,330

LPM
