Technology Catalogue

CATEGORY

TECHNOLOGY SOLUTIONS

1

CONTENTS

03

AUDIO & VISUAL TECHNOLOGY

13

SECURITY SURVEILLANCE

26

SMART CONTROL

34

DATA & NETWORKING

39

SUSTAINABILITY - SOLAR & EV

ONKTXNR7100B 9.2- CHANNEL NE T WORK AV RECEIVER POWERED 3 ZONE

AUDIO & VISUAL TECHNOLOGY

New THX® Sound & Film-Like 8K Resolution

6.5'' WEATHERPROOF

OUTDOOR SPEAKER

• 2-Way sealed box • IP65 rated • Stainless steel/brass hardware • 1x 160mm LF, 1x 25mm HF drivers

Sold as Pair

KEFVENTURA6B (Black) KEFVENTURA6W (White)

Sold as Pair

ULTRA THIN

BEZEL ROUND

IN-CEILING SPEAKER • Uni-Q driver with 16mm aluminium dome tweeter • Magnetic grille • IP64 rated • Marine grade KEFCI160ER 6.5” In-Ceiling Speaker, 160mm KEFCI200ER 8” In-Ceiling Speaker, 200mm

10'' 300W SUBWOOFER • 1x 250mm driver • 24~140Hz, 111dB • RCA Phono sockets • Speaker level inputs

KEFKUBE10B

Proudly Distributed by

3

AUDIO & VISUAL TECHNOLOGY

EZY DATA ENCLOSURES Magnetic latch, hidden ventilation, designed to match the style of Ezywire Electrical Boards, provision for GPOs, Surface mounted sockets or unswitched socket

EZY DATA ENCLOSURE 355 X 725 X 90MM

4

EZY DATA ENCLOSURE 355 X 575 X 90MM

EZY DATA ENCLOSURE 355 X 275 X 90MM

IDEAL CODE

IDEAL CODE

IDEAL CODE

STLST8

STLST6

STLST2

The Domestic Prewire can be a contentious subject as everyone seems to have a point of view so here we will discuss a few of the principles and trade-offs involved and hopefully simplify the process a little for the installer.

The challenge is to accommodate all of the viewing habits the home owner has at present and then to also balance this against any future habits of, not only a growing family, but also any possible future owners of the home when the original family decide to move on.

Often the rush towards the finish line when building can make the prewire seem like a low priority but the reality is once the wall lining is on, any future considerations for AV become much more difficult. Anyone contemplating a wireless future should consider the likely age of any immediate or future occupants of the home as there is no substitute for copper in the wall for reliability and ease of use.

locations back to the AV source. It is recommended to avoid patch panels and faceplates when choosing CAT6 distribution, and cable directly between transmitter and receiver using brush plates (see 05MM-WP64). This is to avoid the loss associated with too many intersections leading to drop out and picture instability and this means wiring directly from the equipment area to a TV location rather than through the CAT6 hub.

Another reason to prewire with CAT6 is to give each TV location a hardwired connection to the internet for the online content available in smart TVs . This is to avoid REST OF HOUSE

RG6 We would recommend every current, or possible future, TV or Sky decoder location, be wired with 1 x RG6 each back to the distribution point (typically a recessed box in the garage or a nominated equipment area in the house). If modulation for distributing SKY around the home is being considered, then you also need a second RG6 to transmit the newly created Sky DVB-T channel back to the RG6 distribution point from that SKY decoder location.

In addition to this you also need to make the RG6 connections from the roof mounted Aerial or Satellite dish to feed the same distribution point. If you have both mounted on the roof then run a separate cable for each but if left with no choice you can combine the Satellite and Terrestrial signals into one cable with an outdoor diplexer.

TYPICAL SKY AND/OR FREEVIEW TERRESTRIAL RG6 WIRING DIAGRAM 13MM-R65P

AUDIO & VISUAL TECHNOLOGY

THE PREWIRE

HDMI DISTRIBUTION VIA CAT5/6 34MM-2K50-3

HDMI SOURCE

LOCAL TV

WIFI congestion and improve reliability and capacity as our connection speeds improve into the future.

If you intend to run HDMI leads to distribute an AV source to all TV locations, then you also need to consider running a CAT6 lead for returning the IR commands back to the source. Whilst there are kits available to run a remote control signal over an HDMI lead there is nothing that takes into account more than one location. These IR signals can be run through a patch panel and/or faceplates as the signal is very robust once captured into a copper connection.

10MM-DDA24

HDMI 02MM-MDU50

10MM-MT67

CAT6 Whole house distribution of an AV signal over CAT6 is now very popular due to the ease of the prewire and relatively inexpensive nature of the cable. It normally also has the advantage of returning the IR signal back to the AV source, (in the opposite direction the picture and sound are travelling) simplifying remote control from all

Prewiring with HDMI is normally a performance option when picture and sound performance are a priority.

HDMI also currently happens to be the most cost effective way into 4K capacity, as 4K extenders continue to be relatively expensive compared to their 1080p cousins and modulation has an upper limit of 1080p.

Whilst early, or low-cost, HDMI cables have a reputation for failing over 10m, Matchmaster’s current range of HDMI leads are fully tested and rated to work up to 20m with a 4K signal.

5

AUDIO & VISUAL TECHNOLOGY

Simply add an HDMI splitter to the AV source and match the outputs to the number of TV’s. If you have a request for more than one HDMI source, consider an HDMI Matrix switcher. These are designed to allow switching between HDMI sources from any connected TV, independently of what the other TV’s may be set to.

For the prewire, whether using an HDMI Splitter or Matrix Switcher, each TV location only needs one HDMI lead back to the equipment area.

ARC (AUDIO RETURN CHANNEL) 34MM-HDS4 CONNECTION DIAGRAM

ALL TV’S

HDMI SOURCE

Often overlooked in the prewire is consideration for transmitting the TV’s digital sound output back to an AV Amp or Soundbar location. As the drive towards thinner TV’s continues, TV manufacturers are struggling to keep sound quality advances on a par with an increasingly better picture performance. ARC is normally bundled with CEC code transfer and source on/off as well, which can be either an installer nightmare (if not handled well by the TV or HDMI source manufacturer), or a very helpful feature for the end user. Most HDMI cables have this feature as standard however it is rare to find a reliable extender that supports ARC, CEC, and IR all in one (see our 34MM-4K70-ARC).

If ARC over an HDMI lead or extender is not an option, consider installing an Optical Toslink lead back to the equipment area. Common to almost all TV’s, Soundbars and AV Amps, this connection doesn’t carry any remote control signals but does have the same ability to transmit digital audio as the ARC connection. (see 04MM-TOS1 to 04MM-TOS20).

If the install is complete and the wall lining is on, there is the option of transmitting the optical signal over yet another CAT5/6 cable using a Digital Audio Extender (see 34MM-DAE1).

34MM-4K70-ARC

HDMI Picture & Sound ARC, CEC and IR

6

EARC (ENHANCED AUDIO RETURN CHANNEL) eARc has the potential to reshape the prewire for home theatre. Claimed to much improve the connection and unpredictable sync ailments sometimes associated with standard ARC, this new format also increases capacity from 1Mbps to 37Mbps, which, unlike standard ARC, should allow all current sound formats to pass without the need of any further compression. Potentially this means all HDMI sources can be connected directly to the TV and an HDMI cable can be used to transmit the maximum bandwidth of the source’s audio signal intact to an eARC compatible Soundbar or AV Amp. Potentially we may even see cheaper AV amps without any video switching onboard coming onto the market as the TV becomes the HDMI hub. This also has the benefit of simplifying the user experience.

FUTURE PROOFING AND DAMAGE MITIGATION In an ideal world we would likely have floor to ceiling conduit installed to every current, or likely, TV position in a home. Given the constraints of budget, time, building regulations and the available options, what is realistic and achievable for future proofing, and for providing some options for when things do get damaged onsite.

With 4K sources being slow to mature in NZ, the market has been relatively happy to stick with 1080p for POSSIBLE eARC SETUP

domestic distribution in general. England and Australia have both had their mainstream Satellite Pay TV providers delivering 4K for some years so now might be the perfect time to start thinking about offering an option to increase that installation capacity to 4K. Damage on work sites is inevitable and HDMI leads, whilst delivering the highest quality picture and sound, have the greatest potential for damage due to the larger 19pin head shells and generally larger cable gauges when compared with CAT6 or RG6, so running a relatively cheap length of CAT6 with each installed HDMI lead is highly recommended. Damage to CAT6 or RG6 is less likely but common enough to warrant consideration as well but once equipment locations are known Matchmaster has the following recommendations as a guide:

HDMI DISTRIBUTION Each Active TV location: 1 x RG6 (Freeview) 1 x HDMI lead 3 x CAT6 (IR, Internet, and Damage/Future) Each possible future TV location: 1 x RG6 (Freeview) 2 x CAT6 (AV, Internet) Each Sky decoder location: 1 x RG6 CAT6 DISTRIBUTION Each Active TV location: 1 x RG6 (Freeview) 3 x CAT6 (AV, Internet, and Damage/Future) Each possible future TV location: 1 x RG6 (Freeview) 2 x CAT6 (AV, Internet)

points or household computers and printers etc.

4.

No provision has been made for hardwiring the internet to any AV sources or Amplifiers.

5. Please remember the CAT6 for AV, is run back to the equipment area, where as CAT6 for the internet, is run back to the CAT6 distribution point. This may or may not be the same area.

SUMMARY The prewire is remarkably similar across all three distribution methods and this is very convenient if a final decision on method of distribution, seating/TV positions, or number and type of AV sources, has been delayed. If the final details on equipment, seating, type of viewing etc are hard to come by, then with RG6 and CAT6 being relatively inexpensive, covering more than one option can be considered.

AUDIO & VISUAL TECHNOLOGY

(All wiring suggestions assume distribution of one AV source (typically Sky) to many TV’s and wall mounting all TV’s with no line of sight to any AV components)

At the end of the day the prewire will come down to taking an educated guess at the viewing habits of not only the current homeowners’ family but any future owners, and then incorporating as much future proofing and damage mitigation as budget and tolerance allow.

Remember cabling is never cheaper than when the wall lining is off.

Each Sky decoder location: 1 x RG6 MODULATION Each Active TV location: 1 x RG6 (Freeview/AV) 3 x CAT6 (IR, Internet, and Damage/Future) Each possible future TV location: 1 x RG6 (Freeview/AV) 2 x CAT6 (Internet, IR) Each Sky decoder location: 2 x RG6 PREWIRE NOTES: 1.

No provision in the prewire suggestions above has been made for ARC/eARC for either a Soundbar or an AV Amp

2. No consideration has been given for any speaker arrangements 3.

The suggestions made are concentrated on the AV needs of the home and no provision has been made for hardwiring the internet to the wider demands of the house eg CCTV, wireless access

7

AUDIO & VISUAL TECHNOLOGY

Households who have come away from a Sky subscription service, often switch to a mix of Freeview and online content to satisfy their viewing habits so today we thought a discussion of the 2 choices for free to air transmission currently available in New Zealand might be overdue.

Two transmission choices for Freeview are available in NZ, DVB-T (Terrestrial) and DVB-S (Satellite). The preferred choice is Terrestrial because that can deliver high definition (1080i), whereas Satellite can only deliver standard definition (576i). The reason we have 2 choices in NZ is Terrestrial cannot reach all New Zealanders and requires line of sight with a transmission tower. If you’re unlucky enough to live in a valley or dip, or are quite remote and surrounded by hills, then Satellite may be your only choice.

ANTENNA SELECTION GUIDE Approx. 6 years ago Matchmaster came up with an online guide to help installers choose the best transmission method for any address. Found on the Matchmaster homepage the ‘Antenna Selection Guide’ allows anyone to enter an address and get an aerial recommendation as well as a full set of installation specifications, a Google map of the various transmitter locations, and a topography diagram showing any hills interfering with line of sight. The nature of digital transmission means there is very little ‘signal wash’ over hills or trees, as there was with analog. This is where an experienced local aerial installer with a field strength meter, can make all the difference between getting Terrestrial to work and having to choose Satellite.

PHASED ARRAY Another technology advance that tipped the scales towards Terrestrial was the introduction of the ‘Phased Array’ aerial. This was a design geared towards the specific requirements of digital transmission. When Digital transmission was introduced in 2007, many home owners found their existing ‘Yagi’ aerials, previously installed to capture our analog signals, perfectly adequate for catching the new digital transmission.

These traditional analog aerials were designed to generate lots of power but in doing so, also generated lots of noise. A good digital TV picture however relies

8

VS.

AUDIO & VISUAL TECHNOLOGY

FREE TO AIR SIGNAL TRANSMISSION IN NZ TERRESTRIAL VS. SATELLITE

5G ON THE HORIZON With 5G on the horizon, numbers of cell towers are also set to increase, due to the shorter transmission lengths of so much more data capacity. As most installers will know 4G could be a big problem for a clean balanced terrestrial signal and Matchmaster will shortly be replacing its most popular antenna, the 02MM-MDU36, with an updated design with more 4G/5G filtering. As a TV’s DVB-T tuner can also see the same frequencies the cell towers use to connect your mobile to your service provider, we need to filter them out so as not to overwhelm the onboard TV terrestrial tuner. The new 02MM-MDU50 with 50db of filtering will take over from the 02MM-MDU36 early August with comparable pricing.

PHASED ARRAY

YAGI

AUDIO & VISUAL TECHNOLOGY

on a very clean, low noise aerial to capture the signal and low signal power can always be amplified later.

DVB-S SATELLITE TUNER The last point to note is the recent adoption of the DVB-S Satellite tuner to most new TV’s sold in NZ. Prior to this we saw just the DVB-T tuner onboard, with the possible addition of the analog tuner for older sets bought around the time of the digital transmission launch. If you are shifting house and need to look at Satellite for Freeview, and your TV predates the addition of the DVB-S tuner, then potentially you may have to add an external Satellite set top box and hook it up to the HDMI input on the existing TV. (Check the inputs on the rear of the TV to see whether it has twin tuners or not.)

9

AUDIO & VISUAL TECHNOLOGY

PREPARING FOR THE NEW SKY 4K SATELLITE BOX With Sky rumored to be close to releasing their long awaited 4K Satellite box, we thought it might be time to highlight some of the issues this might throw up in the light of older installed HDMI leads and Extenders.

With the exception of 4K Bluray, Apple TV 4K and a few others, the NZ market has largely been satisfied with 1080p distribution in the home and with the current Sky box limited to 1080i this was more than enough to transmit our most popular viewing source around a home or business.

Fast forward to the 3rd quarter of 2022 and we now have the option of choosing the next step up in viewing quality from Sky with the new 4K box. Details have yet to be confirmed but theoretically the idea of a hybrid Satellite/IP box will allow much greater flexibility for Sky when choosing which method to use for transmitting the various types of programming it may have. The issues prevalent with internet distribution of popular live sports events is well documented, with drop out and logging on issues fresh in the minds of World Cup Rugby fans…. these should be a thing of the past using Satellite.

So what can you expect when hooking up the new 4K decoder (or any 4K device) to your existing connection? Just how much of a jump is it to the new format and how do you know what you have in the wall will work? The easy way is to just connect it and see what happens. Whilst all HDMI devices have the ability to read the video capabilities of a monitor or TV via the ‘EDID’ signature, and adjust the HDMI output accordingly, none have the ability to measure the capacity of the connecting cable. TV specification has grown 30 fold since the first flat panel TVs started appearing, witness the 1 million pixels used by the first 720p plasma TVs versus the 33 million pixels used in the latest 8K TV’s, yet our most widely distributed broadcasting platform Sky, has remained at 1080i for many years. So the connecting HDMI cables were only being asked to do a small proportion of what was claimed on the box, allowing some bold claims on the packaging to go unchecked.

If you’ve made the swap to 4K and have no picture problems (picture instability/dropout or red/white ‘snow’) you should be in the clear. Digital generally works or it doesn’t, but if you have no picture, or are in the very narrow window of the symptoms above presenting themselves, then there are some options to try.

Almost all HDMI devices have some ability to adjust the various picture parameters manually and its these that can

10

have a dramatic effect on reducing the burden of data exiting the HDMI port.

The pursuit of higher frame rates from the standard 24fps for film and 30fps for video has been an attempt at a smoother, more lifelike motion. Especially important for sports fans and gamers, we are starting to see capabilities up to 120fps emerge from the likes of the PS5 and the latest Xbox. If your 4K device is setup from the box with 60Hz as its default, which includes most 4K Bluray players, then changing this to one of the lower frame rates will significantly lower the data burden with little effect on quality for most content.

Chroma Subsampling is a mechanism that reduces the colour (Chroma) information from

The push towards better colour reproduction has led to 10 and 12 Bit sampling and these are taking various shapes in the market with the most recognisable being HDR @ 10bit.

4K Bluray and a few online content providers have made the switch away from the traditional 8bit standard and are providing higher cost options for HDR and Dolby Vision (12Bit).

8 Bit sampling gives 256 variations of red, green, and blue giving 16,777,216 colours in total.

10 Bit sampling (HDR) gives us 1024 levels per colour and this allows a total of 1,073,741,824 possible colours.

12 Bit (Dolby Vision) sampling gives 68 billion colours As you step up from the industry standard of 8bit sampling, the picture performance can dramatically improve and while turning off HDR or Dolby Vision in the pursuit of a lower data burden would be a shame, it remains an option when all else has failed.

Whilst the bandwidth required for 4K HDMI certification has been set at 18Gbps by HDMI.org, if you turned on all the available features described above, the bandwidth needed climbs to 24Gbps. If we take our frame rate back to 24/30fps, reduce the Chroma Subsampling to 4:2:0 and don’t go any higher than 10bit sampling then we should get away with less than the 10.2Gbps standard set for HDMI1.4 (labelled ‘High Speed’). Unfortunately, not all HDMI cables live up to even this standard, despite the claims on the box, and as the standard SKY box has traditionally only needed a bandwidth closer to 2Gbps, the vast majority of connections remain untested.

If you still have access to the cable path, or the site is a new build or renovation, Matchmaster NZ has a range of true 18Gbps 4K HDMI leads up to 20m, please refer to https:// www.matchmaster.co.nz/ and search for ‘04MM-SL’ for under 6m, or ‘04MM-HDR’ for over 6m.

What to do if the connection fails despite reducing the bandwidth to the desired minimum? HDMI repeaters have been available for quite a few years but have managed to slip under the radar of most installers. The idea behind these is exactly the same as the chipset you will find in any modern longer HDMI lead’s TV head shell (giving it the acronym ‘Active’). Powered by the 5V rail inherent in any HDMI connection, the chips’

role is to re-equalise the signal or correct the errors, giving the lead greater capacity over a longer length. The success or otherwise of this depends on the how great the error rate is to begin with, so it is normally a case of plugging it in and seeing what happens with no guarantees. The upside is that with digital, the divide between a successful stable picture, and problems, is normally quite narrow, so small changes can make all the difference.

Matchmaster currently has the latest versions under review.

AUDIO & VISUAL TECHNOLOGY

a group of 8 pixels whilst leaving the black/white (Luma) information intact and there are 3 levels. The highest level of reduction is 4:2:0 which removes the original colour information from 6 of the 8 pixels…. on the face of it this looks to be fatal but actually only has a small impact on quality.

This is a common practice for video and can reduce the data burden by up to 50%.

If turning down the video enhancements and/or adding an HDMI repeater to the end of your lead still fails to deliver 4K, then the only option left is to look for alternatives to using the HDMI lead. The NZ AV market has long supported the concept of extending an HDMI picture using CAT5/6 ethernet cable, normally when distances start to creep over 10m.

These extenders have continued to develop and can now easily accommodate the 18Gbps standard set down by HDMI. org for 4K over a single run of CAT6.

If you happen to have a category ethernet cable in the wall then this presents an easy alternative to trying to get the older HDMI lead up to speed and has the advantage of also transferring your remote control signals back to the equipment area. If your cable is CAT5e, or an even older CAT5, then this may still work depending on the distance and quality of the installation…contact Matchmaster for advice.

To see the range of Matchmaster 18Gbps 4K Extenders see https://www.matchmaster.co.nz/ and search for ‘34MM-4K’.

11

AUDIO & VISUAL TECHNOLOGY

ANTENNA UHF 4G FILTERING PHASED ARRAY FEATURES AND BENEFITS:: • 4G/5G - 50dB Screened Filter • UHF Ch(28-51) • Weather protection on elements • New wider phase bars for balun access • Easy to assemble with vertical mounting option • X Elements - one piece for anti-corrosion

IDEAL CODE MTM02MDU50

SATELLITE DISH 65CM WITH LNB FEATURES AND BENEFITS: • Heavy gauge galvanized steel and a superior rolled edge for added strength and durability • Rolled edges for greater strength • Grey powder coating • Quality fittings • Easy to assemble

IDEAL CODE MTM13R65PK

DIPLEXER SAT/TERRESTRIAL OUTDOOR AUTO PWR BYPASS FEATURES AND BENEFITS: • Combines and filters satellite and terrestrial signals into one coaxial cable • Dixplexer can also be used in reverse to split satellite and terrestrial signal • ‘F’ type female connections • Supplied in outdoor housing for outdoor use • Auto voltage circuit for powering of LNB + Masthead amp if present

IDEAL CODE MTM09SD05

DIGITAL TERRESTRIAL PASS FILTER CH 25-48 Used to filter unwanted ‘Digital Killing’ interference from 4G/5G Cellphone and strong VHF frequencies in an Outdoor Housing

IDEAL CODE MTM9DTF01

12

by

R

6MP SURVEILLANCE

CAMERA KITS WITH ADVANCED HUMAN & VEHICLE DETECTION

Intelligent, Easy-to-Use & Cost Effective Kits Includes • 4x IPC-T261H-MU 6MP Turret PoE IP 2.8mm Fixed Lens Cameras • 4/8-Channel 1U PoE 4K NVR • 3TB HDD • Ethernet & HDMI Cable • Supports APP, Local & Remote Viewing Proudly Distributed by

SECURITY SURVEILLANCE

NEW

4-Channel Kit

8-Channel Kit

CDYIK4346THMMPC

CDYIK4386THMMPC

HILOOK 5MP SURVEILLANCE SYSTEM 8-CHANNEL HILOOK 6MP 8-Channel Surveillance Camera Kit with 3TB HDD. Includes 4x IPC-T261H-MU 6MP Turret PoE IP 2.8mm Fixed Lens Cameras, 1x 8-Channel 1U PoE 4K NVR, 1x 1m Ethernet Cable, 1x 2m HDMI Cable.

FEATURES AND BENEFITS: • One pack contains everything required for small monitoring scenarios • One 8-channel PoE NVR with decoding up to 1-ch@8MP • Four 5MP fixed turret network cameras with efficient H.265+ compression technology • Easy installation with Power over Ethernet (PoE) technology • HiLookVision for easy network management • 3TB pre-installed HDD

IDEAL CODE CDYIK4385THMMP

13

CATEGORY

NEW

BC1 Battery-Powered Wireless Camera Kit

Longer Lasting Battery BC1 Kit Options: 1 Base Station + 1/2/3 BC1 Cameras

14

1080p Video

12,900 mAh Rechargeable Lithium Battery

Color Night Vision

Accurate Human Motion Detection

Active Defense

Customizable Voice Alerts

Two-Way Talk

IP66 Dust and Water Protection

Supports 2.4 GHz Wi-Fi

H.265 Video Compression

Base Station Included (Supports MicroSD Cards up to 256 GB)

1 Base Station + 1 BC1 Camera

1 Base Station + 2 BC1 Camera

1 Base Station + 3 BC1 Camera

IDEAL CODE

IDEAL CODE

IDEAL CODE

EZVBC1B1

EZVBC1B2

EZVBC1B3

14 | TECHNOLOGY SOLUTIONS DISTRIBUTED BY

The EZVIZ LC1C is a security camera and outdoor floodlight in one product, meeting your need for both security and night-time illumination in the yard, driveway, and more. More active than just blasting a combined 2,000 lumens of brightness, the LC1C Camera monitors your surroundings with active defence and real-time motion notifications.

KEY FEATURES • Power Supply: Hardwired (100v - 240v) • Power Consumption: ≤35W • Ingress Protection Grade IP65 on camera • Product Dimensions: 268mm (H) x 186mm (W) x 185mm (D) Light Parameters • Lamp: 2 • LED: SMD LED • Brightness: 2000LM (+/-10%) • CRI80 • Color Temperature: 3000K • PIR Sensor Detection • Detection Distance: 10 meters (33 feet) • Detection Range: 270-degree

SECURITY SURVEILLANCE

2-IN-1 OUTDOOR SMART SECURITY CAMERA & LIGHT

Camera Parameters • Resolution: 1920 × 1080 • Field of View: Horizontal angle: 103°; Vertical angle: 57°; Diagonal angle: 121° • Night Vision: Up to 25 m (82 ft.)

Audio Parameters • Audio Input: Built-in Omni-direction microphone • Audio Output: Built-in loudspeaker • Audio Quality: Noise suppression

IDEAL CODE

COLOUR

EZVLC1CWHT

WHITE

EZVLC1CBLK

BLACK

MICRO SD MEMORY CARDS • 128GB Micro SD High-Speed Certified Flash Card with Adapter Class 10 • 256GB Micro SD High-Speed Certified Flash Card with Adapter Class 10

IDEAL CODE

CAPACITY

CDYSDMICRO128G

128GB

CDYSDMICRO256G

256GB

15

SECURITY SURVEILLANCE

4 CHANNEL & 8 CHANNEL NVR KIT FEATURES AND BENEFITS: • Support 8CH 6MP/5MP/4MP/3MP/1080P/ 960P/720P/960H/DI/CIF IP video input • H.265S/H.265+/H.265/H.264 • Intuitive and user-friendly Graphic User Interface ( GUI ), Windows style operation by mouse • Multi-mode recording: manual / timer / motion / sensor/ POS / AI recording • Playback : 8CH simultaneous playback • Search : time slice, time, event, tag, smart search • Support multiple VCA (Video Content Analytics) events, such as object abandoned/missing, region intrusion, tripwire, video exception, etc.

• Support POS information overlay on live view and playback • Express and flexible backup via USB, network and so on • Pentaplex : preview, record, playback, backup and remote access • DHCP, DDNS, PPPoE network protocol • Remote control via Web Client or CMS : preview, playback, backup, PTZ and configuration • 8 PoE network ports, support IPC direct connection to NVR; support PoE power supply • Dual stream technology for local storage with high definition, remote network transmission and remote surveillance with mobile device • Multi-user online simultaneously • Authorization management, log view and device status view • 1080P output, true high resolution display • Support NAT function and QRCode scanning by mobile phones • Powerful mobile surveillance by smart phones with iOS and Android OS

4 CHANNEL KIT INCLUDES: • 1 x 4 Channel NVR. • 4 x 2.8mm 5MP dome style AI cameras (TVT-D2.8POE-AI).

• 4 x CAT5e cable (20m LAN cable) • 1 x 2TB HDD (upgradable to 8TB) This kit is suitable for up to 4 IP cameras - This kit includes 4 x 5MP AI cameras and Interchangeable for any TVT POE camera.

IDEAL CODE TVT4CHNVRKITAI

8 CHANNEL KIT INCLUDES: • 1 x 8 Channel NVR. • 4 x 2.8mm 5MP dome style AI cameras (TVT-D2.8POE-AI).

• 4 x CAT5e cable (20m LAN cable) • 1 x 2TB HDD (upgradable to 8TB) This kit is suitable for up to 8 IP cameras - This kit includes 4 x 5MP AI cameras and Interchangeable for any TVT POE camera.

IDEAL CODE TVT8CHNVRKITAI

16

SECURITY SURVEILLANCE

NETATMO SMART INDOOR CAMERA Your Netatmo Indoor Camera protects your home and offers you peace of mind.

When it detects an intruder at your place, it alerts you immediately on your smartphone. Thanks to the camera's facial recognition technology and the 'pet detection' feature, it can distinguish between strangers, family members, and harmless movement. By customizing the notifications you want to receive, you won't be disturbed again for a false alarm! The Indoor Camera does not monitor your family - it spots intruders.

FEATURES & BENEFITS • Real time alerts in case of intrusion thanks to the facial recognition • Detection and distinction of stranger, family member, pet, or an harmless movement • Without fees: no hidden fees at Netatmo: video storage accessible at all time, free access to all functionalities, free app upgrades, and free live and stream videos.

• Life privacy respect: possibility of disabling notifications and video recordings of your family members • Secured, free and local storage on an included microSD card.

• Additional back up on via your personal Dropbox account or FTP server • Free download of videos • Infrared Night vision • x8 numeric zoom on the videos • Easy set up in few minutes • Alarms detection: receive a notification in case of fire or security alarm • Full HD quality 1080p • 130° field of view

IDEAL CODE NTTNSC01P

NETATMO SMART OUTDOOR CAMERA Your Netatmo Outdoor Camera protects your home and offers you peace of mind.

When it detects a person, a pet or vehicle it immediately sends a notification to your smartphone. Your Smart Camera sends you smart alerts because it can distinguish between people, animals, cars and harmless movement. Your data is 100% secured thanks to the local storage of your videos on an encrypted and included MicroSD card.

FEATURES & BENEFITS• Real time and precise alerts • Alert zones function: Up to 4 zones to select • Detection and distinction of people, car and animals • Customization of notifications on the app • Without fees: no hidden fees at Netatmo, video storage accessible at all time, free access to all functionalities, and free app upgrades.

• Free access to the videos via the application.

• Fully secured data: videos stored locally on an included microSD card. An option also allows you to send the recorded videos on your Dropbox account or in your personal server using FTP. • Integrated smart floodlight • Infrared night vision • Replace an existing light for easy installation • Free videos downloading • Through the app, you can give access to access to other persons.

• 100° field of view • 1080p Full HD video • Compatibility with Apple Homekit/Google Assistant IDEAL CODE NTTNOC01P2

17

CATEGORY

ONE APP,

Complete Home Control Introducing the new Classe 100 door entry system by Bticino, the specialists in video door entry systems.

Featuring a modern design, this video door entry system allows homeowners to answer calls using a smart device, whether they’re in a different room or on the other side of the globe.

The intuitive app allows homeowners to: • Remotely unlock front door of gates • Answer calls from their smart device • Monitor connected security cameras • Control connected lighting • Activate garden sprinklers • Review video messages in the event a call is missed • Call home directly from their smart phone to the Classe 100 internal unit This ready-to-install kit comprises of an internal hands-free 5” colour LCD screen with Wi-Fi connectivity, badge reader and power supply. The Classe 100 door entry system is also fully interoperable with Netatmo Smart cameras suitable for both indoor and outdoor environments adding greater security to the home.

The system’s external panel features an IP54/IK07 weather rating, 105 degree wide angle camera and illuminated name plate.

The Classe 100 door entry kit features a standard 2 wire installation making it easy to install and a great upgrade solution for outdated door entry systems. Recommended for single home dwellings to multi-residential applications of up to 22 apartments without a dedicated power supply.

From a trusted international brand, the Bticino intercom systems are the fastest and easiest to install as well as the most reliable, so you’ll save time on every job.

To find out more contact one of our BDMs by calling 0800 476 009 or by emailing projects@legrand.co.nz.

TRANSFORM ANY HOME INTO A CONNECTED HOME Classe 100 Wi-Fi – The Connected Door Entry System Whether the homeowner is at home or away on holidays, the Classe 100 Wi-Fi communicates with a smartphone or tablet to: • Answer door calls • Open the door / gate • Activate security cameras • Control lights or turn on garden sprinklers There are no installation complexities as the Classe 100 Wi-Fi is a standard 2-wire system, therefore perfect for retrofit or new build applications.

Keep your customers connected 24/7, wherever they are in the world.

18

THE GLOBAL SPECIALIST IN ELECTRICAL AND DIGITAL BUILDING INFRASTRUCTURES

www.legrand.co.nz

• Video kit Classe100 connected and Linea3000 external panel, Simplicity and modernity thanks to the built-in Wi-Fi connectivity.

• You can manage the main video door entry system functions directly from your smartphone, via the Door Entry CLASSE 100X App. • Call forwarding to smartphones, hands-free, Door lock release, Intercom, easy set up, wall mount or table top.

IDEAL CODE HPM364614

SECURITY SURVEILLANCE

VIDEO KIT CONNECTED DOOR ENTRY SYSTEM

INTERNAL UNIT VIDEO PANEL CONNECTED CLASSE 100 • CLASSE 100X16E is a connected video internal unit which combines simplicity and modernity thanks to the built-in Wi-Fi connectivity.

• Call forwarding to smartphones, 5 LCD colour display, Hands-free, Door lock release, Inductive loop function, Intercom, Staircase light activation, Easy setup, Wall mount or tabletop.

• HPM344652 - Wall mount or tabletop (with accessory 344692 - not provided), 1 Year Warranty

IDEAL CODE HPM344682 HPM344652

EXTERNAL UNIT LINEA 3000 VIDEO 2 WIRE METAL • Linea 3000 wall mounted 2-Wires video pushbutton.

• Can be configured both for 1 and 2 family house.

• High installation flexibility, Flush mounting installation, Horizontal and vertical wide viewing field.

• 1 Year Warranty

IDEAL CODE LEG343081

POWER SUPPLY 1200MA, 2 WIRE • Power supply 1200mA for 2 wire system with A/V Adapter, 6 Din rail modules.

• To be used in audio, video or mixed audio video systems.

• The output provides two power supplies in very low safety voltage, The device is electronically protected against overload and short circuit.

IDEAL CODE LEG346050

19

SECURITY SURVEILLANCE

SMART DOOR ENTRY WITH BUILT-IN ALEXA The Bticino Classe 300EOS with Netatmo is 2 WIRES / Wi-Fi video internal unit with Alexa built-in, 5 vertical LCD touch screen display and video door entry answering machine. It includes a physical key for door lock release and capacitive keys for the control of the main video door entry functions such as handsfree communication, entrance panel activation / camera scrolling and Favourite key that is customisable for the most frequently used actions. Easily interact with the builtin Alexa voice assistant, either using the dedicated capacitive keys or with your voice to activate several functions, such as the video door entry functions, smart home, scenarios and reminders etc.

FEATURES & BENEFITS • Download = the Home + Security app (available for Android and iOS), connect with the video internal unit • Control main video internal unit functions with the Home + Security app • Control Netatmo Security range within the one app, sold separately • Wall mounted installation using the supplied bracket • Connect via Wi-Fi or using RJ45 ethernet cable with the dedicated accessory (344844, sold separately) • 5 vertical touch screen display • Door release key function • 160-165cm recommended installation height • 4-50°C operating temperature • 1280x720 resolution • Possibility of Wi-Fi connection or via RJ45 ethernet cable using the dedicated accessory BT-344844 IDEAL CODE HPM344842

IP VIDEO DOOR STATION WITH 1 CALL BUTTON DoorBird is the smart solution for your house entrance.

Simply connect your DoorBird IP Video Door Station to your smartphone and talk to your visitor - anywhere you are.

KEY FEATURES:

• • • • • • •

Surface Mount Store Still Images of Visitors Motion Sensor with 4D Technology Geofencing for Automatic Door/Gate Opening Configurable Relay for Door/Gate Control Wifi, Bluetooth, Smartphone Compatible HDTV 1080p, dynamic Camera

IDEAL CODE ARHDBD1101V

20

SECURITY SURVEILLANCE

COLOUR VIDEO INTERCOM With an integrated video/keypad external gate station designed for New Zealand’s harsh weather conditions.

This is perfect for residential premises with the ability to add two gate stations to any one system.

KIT CONTENTS INCLUDE:

• 1 x 7” LCD Touch Panel Monitor with Memory Module (White Edition) • 1 x Video & Audio Keypad Gate Station (Silver Edition) • 1 x 15V 1.3A Switch Mode Power Supply in IP67 Case, 100 - 240VAC Input • 1 x Clean Contact 12V 1A Relay IDEAL CODE ARHCPTKITA8W

360° CEILING MOUNT DETECTOR KEY FEATURES:

• Highly Dense - Provides highly dense coverage with as many as 276 detection zones, eliminating dead spots • Zoom Function/Pattern Adjustment - The pattern angle can be variably adjusted. The special lens can be adjusted up and down by rotating the housing cover of the “Zoom” mechanism.

• Patented Multi-focus Lens - Creates zones with high vertical density for maximum detection sensitivity.

• RFI Protection - No alarm against field strength levels exceeding 30v/m for the range of 100MHz. to 1.2GHz. • Temperature Protection - No alarm in high, low and changing temperatures from -20° to +50°C(-4° to+122° F) • Noise Reduction Circuit • Selectable Pulse Count: 1,2,4.

• Selectable Sensitivity: High, Medium, Low. IDEAL CODE OTXSX360Z

PASSIVE INFRARED INDOOR DETECTOR The Highly accurate and reliable detection pattern of the CX-702 maintains its sensitivity throughout the entire detection area, even in high temperature or low contrast environments.

KEY FEATURES:

• For harsh environments • Temperature Compensation • Dual Purpose Lens / Detection Pattern Selection • Sealed Optics: Complete Shielding with Dual Structure • Spherical Lens Design

IDEAL CODE OTXCX702

21

SECURITY SURVEILLANCE

AX PRO KIT (433MHZ) •

IDEAL CODE HKVDSPWA96KITWB

Connects up to 96 wireless zones/outputs (including 48 PIRCAMs), 48 wireless keyfobs, 4 repeaters, 6 sounders, 8 tag readers & keypads.

KIT INCLUDES: • DS-PWA96-M-WB (AX PRO (433MHz)) • DS-PKF1-WB (Wireless Keyfob) • DS-PDP15P-EG2-WB (PIR) • DS-PDMC-EG2-WB (Magnetic Contact)

WIRELESS PIR-CAMERA DETECTOR • • • •

IDEAL CODE HKVDSPDPC12PEG2

• • •

Detection range: 12m / 85.9° Up to 30KG pet immunity SEC (Smart Environmental Control) - Advanced digital signal processing and 3D optics Polarizing IR lens design for more uniform night illumination and excellent night shots Large integrated memory buffer for image storage Fully remote configurable through App Multiple enrollment method and easy installation design

WIRELESS PHOTOELECTRIC SMOKE DETECTOR • •

High quality chamber with photoelectric sensor 10 years battery life

IDEAL CODE HKVDSPDSMKSWB

WIRELESS LED KEYPAD • • • • •

IDEAL CODE HKVDSPK1EWB

22

•

433 MHz two-way wireless communication AES-128 encryption Stay/away arming, disarming, alarm clearing for specified area or all areas LED indicates the programmed area One-Push fire alarm, panic alarm, and medical alarm. Silent/Audible alarm selectable. etc.

Output control

• • • • • •

433 MHz two-way wireless communication Configurable arming/disarming prompt sound and LED indicator 3 years battery life span (triggered every two weeks and alerting 90 s for each triggering) AES-128 encryption Front and rear panel tamper-proof 3 kinds of alarm sounds: fire alarm, panic alarm, and intrusion alarm

IDEAL CODE HKVDSPS1IWB

SECURITY SURVEILLANCE

WIRELESS INTERNAL SOUNDER

WIRELESS EXTERNAL SOUNDER • • • • • • •

433 MHz two-way wireless communication 3 years battery life span (triggered every two weeks and alerting 90 s for each triggering) AES-128 encryption Front and rear panel tamper-proof 3 kinds of alarm sounds: fire alarm, panic alarm, and intrusion alarm Buzzer Decibel: 110 dB Fully remote configurable through App

IDEAL CODE HKVDSPS1EWB

INFINITY ALARM KIT EC-BASE KIT & EC-LCD KEYPAD Compete Security system for both domestic and commercial premises with integrated alarm,access and automation features. Infinity series is completely modular, creating a versatile solution that saves excess hardware and labour in every installation. Supports 248 inputs, 32 outputs, 32 keypads, 32 partitions, 32 time schedules, 32 access levels, 2000 users & 10,000 events.

KIT INCLUDES: • EC security and control panel • EC-LCD full English keypad (vertical style) • OPT-FLX-S-ST sensor x 2 • DM12-7.5 SLA battery • PS209-R internal & EC-SIREN external sounders • EC-PLAS CAB enclosure with 16VAC 1.4A supply

IDEAL CODE ARHECKITLCDNC

23

SECURITY SURVEILLANCE

WIRELESS 433MHZ ACCESS KEYPAD This keypad is used to control your gate without the need for wiring. Up to 254 different codes can be used within the keypad.

IDEAL CODE ARHBBECODE

STAINLESS STEEL IP INTERCOM See your visitors, speak with them & open the door by smartphone or tablet from almost anywhere in the world. DoorGird combines innovative technology with exclusive design to keep you in touch with your home or business.

Thanks to the integrated high-end motion sensor you always know what happens in front of your home. The 180° infrared motion sensor (if desired} can set off an alarm without the visitor having rung the doorbell.

IDEAL CODE ARHDBD101S

COMPLETE SWING GATE 24V GATE SYSTEM Quality Italian made gate automation. 24V/DC dual swing gate automation kit with capacity to add battery back-up facility (sold separately). Suitable for gates up to 3m per leaf.

KIT INCLUDES:

2 x BOB3024E.ANZ 1 x Brainy 24 1 x Pupilla 2 x TO.GO2A 2 x B-BSR

IDEAL CODE ARHBBOB3024EP

24

SECURITY SURVEILLANCE

TRX TRANSCEIVER-PCB • NZ Designed & manufactured 2-Way wireless products. The transceiver is hard wired onto the ESL-2 control panel and allows full TRX 2-Way wireless communication between the TRX peripherals and ESL control board.

IDEAL CODE ARHTRXTRANSCEI

TRX PENDANT • Don’t get wet this winter by having to manually open your gate, use the TRX PENDANT 4 button remote to open you gate, garage door or arm/ disarm your alarm right from your fingertips

IDEAL CODE ARHTRXPENDANT

TRX PIR • Where cabling is an issue or you are undergoing renovations and running cables is too much of a hassle, use the wireless TRX PIR where no cabling is required.

IDEAL CODE ARHTRXPIR

AAP-TOUCH & AAP-EM

• Proximity egress button for access control applications with an operating voltage of 12 - 24V/ DC & 2 x clean contact N/O & N/C contacts rated to 2A @ 30V.

• Operating voltage of 12 - 24V/DC with fail safe 2 x clean N/O & N/C contacts rated to 2A @ 30V. Also includes optional green status flash, optional white or green backlight and activation lights.

IDEAL CODE ARHAAPTOUCH

IDEAL CODE ARHAAPEM

25

Put your customers in control with a PDL Wiser smart home

From blinds that close to keep the warmth in, a heat pump that clicks on before it cools down, and lights that dim as you drift off, a Wiser Smart Home can be easily adjusted to fit your customer’s lifestyle.

After it is installed by an approved Wiser installer, PDL Wiser is a flexible, automated smart home solution that lets the homeowner control their home with the intuitive Wiser by SE app, setting up their own automations and moments as they decide to add them over time.

pdl.co.nz/wiser-installer

PDL Wiser Smart Home components.

Wiser Smart Home Hub

Wiser IR Converter

The Wiser system communication interface. The hub allows you to control the home from a remote location.

Controls TVs, heat pumps and HiFi systems via the Wiser by SE app using infrared (IR) technology.

PDL501401

PDL501902

Wiser Table Stand for Hub

Wiser Iconic Switch, 2AX

Optional stand for placing the Wiser Hub on a table

Ideal for controlling LED lighting loads and exhaust fans. The small housing with integrated terminals allows quick installation into 6-gang plates and standard wall-boxes.

PDL5019020001

PDL356PB2MBTZ-VW

Wiser Micro Module Switch

Wiser Iconic Dimmer

Transforms a conventional push-button switch into a connected device you can control from the switch or through the Wiser by SE app.

Suitable for controlling a wide variety of loads.

The housing with integrated terminals allows quick installation into 3-gang plates and deep wall-boxes.

PDL5011WSZ

PDL354PBDMBTZ-VW

Wiser Micro Module Dimmer

Wiser Iconic Switch, 10AX

Transforms a conventional push-button switch into a connected device you can control and dim from the switch or through the Wiser by SE app.

Suitable for controlling a wide variety of loads.

The housing with integrated terminals allows quick installation into 3-gang plates and deep wall-boxes.

PDL5010WDZ

PDL356PB10MBTZVW

Wiser Micro Module Blind Controller

Wiser Iconic Twin Socket Grid, 10A

Transforms a conventional double push-button switch into a connected device you can control blinds from the switch or through the Wiser by SE app.

The Iconic Connected Socket has two independent 10 A rated socket outlets. The subtle Iconic status LED indicator can be customised using the Wiser by SE app. Skin code is PDL395CSC.

PDL5015WBZ

PDL395CSGZ

Wiser Window/Door Sensor

Wiser Iconic Switch, 2AX

Detects opened and closed windows and doors, and reports the status to the Wiser Hub. It consists of two separate parts: a sensor and magnet.

Ideal for controlling LED lighting loads and exhaust fans. The small housing with integrated terminals allows quick installation into 6-gang plates and standard wall-boxes.

PDL591011

PDL356PB2MBTW-VW W-VW

Wiser Motion Sensor

Wiser Iconic Dimmer mer

Detects movement and measures luminance in a room, and reports the status to the Wiser Hub.

Suitable for controlling a wide variety of loads.

The housing with integrated terminals allows quick installation into 3-gang plates and deep wall-boxes.

PDL595011

PDL354PBDMBTW-VW

Wiser Temperature/Humidity Sensor

Wiser Iconic Switch, 10AX

Helps to maintain a comfortable environment in the home by detecting changes in temperature and humidity and reporting climate data to the Wiser Hub.

Suitable for controlling a wide variety of loads.

The housing with integrated terminals allows quick installation into 3-gang plates and deep wall-boxes.

PDL593011

PDL356PB10MBTW-VW

Wiser Water Leakage Sensor

Wiser Iconic Twin Socket Grid, 10A

Detects the presence of water and alerts via an

The Iconic Connected Socket has two independent 10 A rated socket outlets. The subtle Iconic status LED indicator can be customised using the Wiser by SE app. Skin code is PDL395CSC.

connected to the Wiser Hub and detects water on event to the Wiser Hub.

PDL395CSG

PDL592011

Indoor IP Camera

Outdoor IP Camera

Provides day/night HD recording, with 340° panning, motion tracking/detection alerts, intercom and event or continuous recording. Simple control via the Wiser by SE App from anywhere. Use standalone or integrate into the Wiser smart home system and Automations.

With all the features of the Wiser Indoor IP Camera (excluding motion tracking and panning), the Outdoor

PDL723419

Zigbee connectivity

Bluetooth connectivity

pdl.co.nz/wiser-installer

camera position and IP56 protection, it can be PDL724419

Wi-Fi connectivity

MAKE IT SMART S I M P L I F Y D A I LY L I F E SCHEDULING

SCENARIOS

APP & VOICE

Introducing Excel Life Smart - a collection of smart wiring devices second to none.

Combining local design and engineering with world-class smart home technology by Netatmo, this collection of switches and powerpoints blends seamlessly with existing Excel Life installations with the added convenience of full home control using a wall switch, smart phone or voice via a digital assistant.

Enjoy convenience, security and greater energy efficiency without the need to replace existing lighting or appliances.

Smarter than your average switch!

ENERGY MANAGEMENT

EASY TO INSTALL

EXCEL LIFE DESIGN BASED ON 240V a.c. WIRING

INTEGRATED SMART TECHNOLOGY

FUTURE-PROOF TECHNOLOGY COMPATIBLE WITH ALL DIGITAL ASSISTANTS

DATA SAFETY

LEGRAND OWNED CLOUD

HIGH-LEVEL ENCRYPTION

“RELOCATE ME ANYWHERE”

2 GANG SWITCH EWN770/2WE

SINGLE GPO EWN787MB

WIRELESS SWITCH EWNWSW1MW

SMART CONTROL

WIRING A SMART HOME Advice for cable installers on the wiring requirements for access to telecommunications services (broadband and voice) INTRODUCTION Advances in technology mean it’s more important than ever to make sure the wiring and connections in homes are capable of delivering modern telecommunications, entertainment and building services.

It is based on the ‘Premises Wiring Cable Installers Guidelines for Telecommunication Services’, updated and approved by the NZ Telecommunications Forum (TCF) in 2021. The latest version of this Code can be accessed on the TCF’s website at: www.tcf.org.nz/ premwiring MINIMUM COMMUNICATION CABLING REQUIREMENTS Following are the minimum cable installation requirements we recommend for new homes and major renovations for which there is an opportunity to install new wiring: 1. Cabling must be ’star wired’. Telecommunications Ethernet cables need to be a minimum specification of Cat6 (UTP) or better if spans exceed 50m.

2. A star wiring box (home distributor) needs to be located at a ‘star point’ – to provide for the interconnection and distribution of cabling around the home, as well as for testing capability. It is the homeowner or builder’s responsibility to supply the home distributor, a patch panel, and patch cables.

3. The home distributor is usually installed in a wall cavity inside the home, somewhere easily accessible. If possible, it will be above the height of the External Termination Point (ETP) at about eye level (to minimise the risk of water entering the premises). Common locations for the home distributor are in an attached garage or a large cupboard or utility room.

4. The home distributor must be large enough to house devices such as an ONT, a router and an ethernet switch. Minimum dimensions of 350mm (W) x 700mm (H) x 80mm (D) are recommended, and made of non-metallic material as Wi-Fi capable equipment may be housed in here. It must also have integrated power sockets for devices. Two dual

30

power outlets as a minimum are recommended.

Ensure the door can be closed once power supply units are plugged in.

5. The door on the home distributor must be louvered so air can circulate and prevent the equipment from overheating.

6. A path from the ETP to the to the Home Distributor needs to be established. Ideally this is of plastic pipe – minimum of 20mm diameter and 300mm 90˚ bend up into the home distributor. Do not use an elbow bend. The ETP is important as it allows transition of external cable to internal rated cable. It also allows the customer’s service to be restored in the event of a fault or damage to the network in the street.

7. If the path from the ETP to the Home Distributor contains more than 3 bends, and/or is longer than 20m, then installing an internal Low Smoke Zero Halogen (LSZH) microduct or a recognised fibre optic cable (such as Prysmian Optic@t) is an acceptable alternative. These are available from your Local Fibre Company.

8. At the star wiring point, all Cat6 cables will ideally be terminated on keystone RJ45 type modular

Location of star wiring box (home distributor)

Best Practice Home Wiring

Star wiring box (Home Distributor)

Cladding

7/3.5mm Low Smoke Zero Halogen Microduct or Internal Fibre Cable

Building penetrations as per the building code

ETP Fibre Optic Cable

20mm conduit with swept bends 20mm conduit

Wall Underlay

Lateral Duct Lead in duct Minimum cover 450mm

90” pipe swept bend

Fibre Optic Cable 20mm conduit with swept bends Wall Underlay

WIRING FOR THE FUTURE Although Cat6 standard wiring is sufficient for meeting the bandwidth demands of existing telecommunications services, it is a good idea to prepare ahead for future upgrades and services. Installing pipe or microduct when building or renovating the home can be a good way of preparing a property for future options such fibre 90” pipe swept optic bend cabling.

SMART CONTROL

20mm conduit

sockets mounted in a patch panel. This will Lateral Duct allow for very simple patching to/from routers and easy replacement if any develop a fault. It is Lead in duct Minimum cover recommended that the installer provides a diagram 450mm to show the outlet and port positions to simplify future patching.

Minimum Home Best Practice Home Wiring

Kitchen Bedroom 2

Garage

Bedroom 3

Pipe between ETP & Home distributor hub

Ba

Wireless Access Point

Bath

Home distributor hub

Lounge

TV

Bedroom 1

ETP

Fibre path Porch

Service Lead Pipe

CAT6 Cables RJ45s

Minimum Home Wiring

CABLING THE

Best practice w Bedroom 2

Kitchen

• The home dist centrally withi

Garage

Bedroom 3 Pipe between ETP & Home distributor hub ETP

rvice Lead Pipe

Wireless Access Point

Bath

ETP

• Two Cat6 cabl star wiring po plus four to th

• Make sure cle cables and po Premises Wirin on the ‘segreg

Home distributor hub

Lounge

• Leave at least cable slack at TV

Bedroom 1

Fibre path Porch

CAT6 Cables

Service Lead Pipe

• If requested, C from the exter position to the

RJ45s

31

SMART CONTROL

m2

om 1

CABLING THE REST OF THE PREMISES Best practice when installing cabling: • The home distributor hub could also be placed centrally within the home i.e., within a cupboard.

• Two Cat6 cables should be fed from the star wiring point to each outlet position, plus four to the main Garage TV position. Kitchen Bedroom 3 • Make sure clearances between communication Pipe between cables and power cables areETPmaintained.

See the & Home ETP distributor hub Premises Wiring Code of Practice for more detail on Wireless Home (cable separation).

Access Point the ‘segregation of services’ distributor • Leave at least 300mm ofhub Cat6 cable slack at each Lounge outlet.

• If requested, Coax cables should be fed from the TV external aerial/satellite dish position to the main TV Service Lead Fibre path position.

Pipe Porch

• •

The minimum bend radius is exceeded; and/or Low quality components have been used

Smart TV Phone 1

2

3

4

5

6

7

8

9

1 0

1 1

1 2

1 3

1 4

1 5

1 6

1 7

1 8

1 9

2 0

2 1

2 2

2 3

2 4

Wi -Fi Access Point

Patch Panel Alarm

Computer Ethernet Switch

Phone Patch Cord

Ethernet Patch Cords

RGW/Modem

CAT6 Cables

Digital Media Player

ONT

When you’re considering whereRJ45s to install outlets or jackpoints, be sure to consider the following: • At least two RJ45 type jackpoints on the same Gaming Console faceplate (each with their own Cat6 cable) in each Fibre bedroom and normally occupied room.

• Two or more such outlets are recommended in the Note: The ONT is only required for fibre optic connections. room, study,where and to any Wi-Fi access When you’re considering install outlets OF THE PREMISES lounge, rumpus or jackpoints, be sure to consider the following: point position. alling cabling: • At least two RJ45 type jackpoints on the same • We recommend having one Wi-Fi Access Point for hub could also be placed CHECKLIST FOR WIRING A faceplate (each with their own Cat6 cable) in Home distributor generic example • The wiring is incorrectly terminated; me i.e., within a cupboard. every 100m2 area and in the house, androom. at least one each of bedroom normally occupied SMART HOME We strongly recommend only installing good • The communications cabling is too clos d be fed from the on each •floor if it is a multi-storied house. quality components such as patch cords and Two or more such outlets are recommended electrical cabling, lighting, or appliance ch outlet position, connectors, that beenyou independently 1. have Are familiar with the cabling • Avoid wetinareas suchrumpus as bathrooms and laundries. the lounge, room, study, and that can cause interference; TV position. certified and are from a recognised supplier. Low any Wi-Fi access point position.

• Include 20mm pipe or microduct routes from thequality components requirements The minimum necessary•for wiringbend a radius is exceeded; will affect the performance between communication • We recommend onefibre Wi-Fi Access Pointsuch ofas broadband and/or phone services. star wiring point to anyhaving future position, es are maintained. See the Low quality components have been use smart home available at:• www.tcf.org. for every 100m of area in the house, and at least of Practice for more detail We also recommend that newly installed cabling the main TV position and any room which may be one on each floor if it is a multi-storied house. services’ (cable separation). be tested and verified (by its installer) as being nz/premwiring used as a home office. capable of operating at the speed for which it is 2

of Cat6 tlet.

• Avoid wet areas such as bathrooms and laundries.

rated. Service performance will be affected where:

• Include 20mm pipe or microduct routes • Too much cable insulation is removed (no HOME DISTRIBUTOR GENERIC EXAMPLE from the star wiring point to any future fibre les should be fed more than 25mm), or there is excessive only installing good position, such as the main TV position andquality any al/satellite dish We strongly recommend untwisting of copper cable pairs (no more V position. room which may be used asand a home office. than 13mm), at termination points; components such as patch cords connectors,

that have been independently certified and are from a recognised supplier. Low quality components will affect the performance of broadband and/or phone services.

We also recommend that newly installed cabling be tested and verified (by its installer) as being capable of operating at the speed for which it is rated. Service performance will be affected where: • Too much cable insulation is removed (no more than 25mm), or there is excessive untwisting of copper cable pairs (no more than 13mm), at termination points; • The wiring is incorrectly terminated; • The communications cabling is too close to electrical cabling, lighting, or appliances that can cause interference; 32

2. Is the home distributor made of plastic and large enough and easily accessible?

3. Is Cat6 cabling being used?

4. Are there multiple outlets assigned in key living areas?

5. Have you tested and verified the installed cabling?

This article has come from NZ Telecommunications Forum (TCF). For more information visit the Premises Wiring page on the TCF website: http://www.tcf.org.nz/premwiring

Systems

"LCS³ offers even greater performance, scalability, and efficiency to networks. By adopting the new platform, you can achieve higher speeds with its high-category RJ45 connectors and copper solutions ranging from Category 5e to Category 8. The LCS3 fibre solutions are also more advanced, allowing data transmission speeds of up to 800 Gbps."

Legrand - Your multi-specialist partner for all your IT networks Rising volumes of data exchanged in buildings, increasing numbers of networks, the need for higher speeds and the density of equipment all make it necessary to have more reliable, secure, and high performance digital building infrastructures. This applies equally to local networks and data centres.

It’s in the development and design of structured cabling systems and solutions which has enabled the Legrand group to expand its offer and achieve the highest level of performance. Legrand cabling systems currently provide high-quality connectivity to more than 200 million devices, making the Legrand group a world leader in communication networks for data transmission.

LCS3 Digital Infrastructure - The Solution for all your data projects Legrand LCS3 is specially designed to meet these needs offering a modular cabling solution for copper and fibre structured cabling solutions. (See images) LCS3 patch panels are available in straight and angled versions. The modular patch panels enable the integration of both copper and fibre cassettes within the same 1U patch panel, enhancing the scalability of the LCS³ system. The Copper cassettes allow for up to 48 ports in a 1U patch panel, accommodating growing demands. By using Legrand LCS3 Solutions, the number of panels in a cabinet can be doubled, reducing installation costs.

Installers benefit from the Quick Fix System, featuring quick release sliding cassettes that make maintenance tasks much easier. This innovative system also allows for easy scalability, as often only the cassette needs to be replaced instead of the entire patch panel.

The toolless LCS3 connectors and cabling Solutions are PoE++ certified and an Applications Warranty can be applied for on completion of an install done to the correct installation standard.

LCS³ provides solutions tailored to the specific needs of users, system designers, and installers.

A 25-YEAR WARRANTY* LCS3 systems have guaranteed performance warranties for 25 years. This extended guarantee demonstrates Legrand’s commitment to the longevity of the solutions it offers. * Only available to the Certified Installer partners. T&Cs of 25 Year Warranty apply.

TRAINING The added value of Legrand solutions also lies in the support if offers. This can be seen in the extensive training available, especially concerning structured cabling and LCS3. Contact our Data & Technology National Sales Manager – Clinton Bell for Legrand LCS3 product training or to find out how to become a Certified Legrand Data Installer: clinton.bell@ideal.co.nz

CATEGORY

LCS³ Solutions by Legrand for all your IT Network

UPS TECHNOLOGY DIFFERENCES EXPLAINED LINE INTERACTIVE UPS

VS ONLINE UPS

Maintains the inverter in line and redirects the battery’s DC current path from the normal charging mode to supplying current when power is lost. There is a very short 6ms time delay when mains power is switched to the battery.

An Online UPS is designed to continue supplying power if a power loss occurs, that is to say the batteries will keep the power steady and unchanged, when power is restored mains will resume carrying the load and begin re-charging the batteries.

Designed for sensitive and critical equipment/devices as there is no transfer time during a failure.

Benefits • High-efficiency • Reasonable AVR voltage conditioning • Lower electricity consumption • Lower purchase price

Benefits • No time delay from DC to AC conversion • Best voltage regulation, indicating stable voltage quality • Highest protection against all power irregularities • Pure sine wave output

Limitations • Impractical over 5kVA • Equipment not protected against all forms of power irregularities • Common output is a square sine wave, rather than pure sine wave • Requires frequent battery use in areas of extreme voltage distortion

Limitations • Higher power dissipation • Higher purchase price

CDYUPSD650 (650VA/390W)

Line Interactive Defender Series UPS • • • • • • •

Smart LCD display Silent fanless design User replaceable batteries Buck & boost AVR for voltage stabilization Auto restart when AC returns USB cable with NetGuard® software Included Designed for home and office use

CDYUPSD1200 (1200VA/720W)

CDYUPSD1600 (1600VA/960W)

CDYUPSD2000 (2000VA/1200W)

CDYPSCE2000 (2000VA/1600W)

True Online Centurion Series UPS • • • • • • •

Informative LCD display Exceptional surge protection Advanced ECO mode for improved power efficiency External battery bank extension options for longer run time Optional network monitoring card purchased separately USB cable with NetGuard® software Included Designed for critical & expensive equipment devices

CDYPSCE1000 (21000VA/800W)

CDYPSCE3000 (2000VA/2400W)

DATA & NETWORKING

D-Series Swing Wall Mount Cabinets Supplied complete, no assembly required Removable Back mount supplied with left & right hinges 100mm back mount with cable entry rear, top & bottom Removable lockable side panels Reversible lockable safety glass front door Max loading: 60kg 6-Way PDU installed in models 12RU to 27RU Includes 1x Fixed Shelf and 10 x cage nuts Gloss Black Colour PRODUCT CODE

HEIGHT

DEPTH

PRODUCT CODE

HEIGHT

DEPTH

CDYRSFDS4450

4RU

450mm

CDYRSFDS18

18RU

550mm

CDYRSFDS6450

6RU

450mm

CDYRSFDS18600

18RU

600mm

CDYRSFDS6

6RU

550mm

CDYRSFDS24

24RU

550mm

CDYRSFDS9

9RU

550mm

CDYRSFDS24600

24RU

600mm

CDYRSFDS27600

27RU

600mm

CDYRSFDS12

12RU

550mm

CDYRSFDS12600

12RU

600mm

Recessed Wall Mount Network Enclosure Vented lid Dual GPO power and fibre knock outs on bottom panel Installs in 400mm centre studs Steel with durable white powder coating Comprehensive hole matrix for device mounting Includes installation accessories & earth kit Lockable, purchased separately PRODUCT CODE

TYPE

Home 28” & 42” Fibre to the sures clo En nt lia mp Co (FT TH)

CUT OUT OD

CDYHWS1404V2

14”

355 x 276 x 99mm

CDYHWS2004V2

20”

355 x 575 x 90mm

CDYHWS2804V2

28”

355 x 725 x 90mm

CDYHWS4204V2

42”

355 x 1067 x 90mm

35

DATA & NETWORKING

Beef up the Batch Wifi 3.2 GBPS ULTRA HIGH-SPEED WI-FI 6 MESH GIGABIT ROUTER DUAL-BAND 802.11AX​ FEATURES & BENEFITS • Wi-Fi 6 dual-band 802.11ax supporting speeds up to 3200 Mbps and up to 192 simultaneous users • MESH technology for seamless roaming between units • Simple setup and network management at your fingertips with the Reyee Router app • Eight antennas with eight signal amplifiers provide powerful ultra high-speed whole-home, building network coverage • Perfect for connecting home, office and public area smart Wi-Fi devices to the internet with built-in flexible parental controls • 1x WAN, 4x LAN (RJ45 10/100/1000Mbps)

IDEAL CODE RUJ57MMWR03

Get the Man Cave Wifi sorted PRE-CONFIGURED WIRELESS NETWORK BRIDGE FEATURES & BENEFITS • 5GHz single-band dual-stream chip with transmit power ≤250mW • One-click setup and management via the free cloud app • PTMP supported bridging (Example: one recorder, multiple cameras) • High durability: IP54 rating provides dust, water and heat protection for outdoor environments • Power supply redundancy support (12V and 24V) • Can be wall or pole mounted

RUJ57MMWB01

RUJ57MMWB02

IDEAL CODE

CAPACITY

RUJ57MMWB01

10DBI

RUJ57MMWB02

15DBI

Outdoor Wi-Fi Access Points RUJ57MMAP06

WI-FI 6 OUTDOOR OMNIDIRECTIONAL ACCESS POINT AX1800 802.11AX DUAL-BANDS 1.8 GBPS

Expand your outdoor Wi-Fi reception 300m in every direction with Matchmasters Wi-Fi 6 Outdoor Omnidirectional Access Point with 802.11ax Dual-bands and 1.8 Gbps

WI-FI 6 OUTDOOR CEILING/WALL ACCESS POINT AX1800 802.11AX DUAL-BANDS 1.8 GBPS RUJ57MMAP07

36

Expand your outdoor WiFi up to 500m in a single direction with Matchmasters Wifi 6 Outdoor Directional Ceiling/Wall Access Point with 802.11ax Dual-bands and 1.8 Gbps

IDEAL CODE RUJ57MMAP06

IDEAL CODE RUJ57MMAP07

HDMI & IR EXTENDER KIT

­

CDYLKV372EDID

HDMI EXTENDER KIT 1-IN-2-OUT

DATA & NETWORKING

HDMI EXTENDER KITS

CDYLKV712PRO

HDMI EXTENDER KIT 1-IN-4-OUT

CDYLKV714PRO

Distributed by

DYNAMIX 2-CHANNEL FLOOR CABLE PROTECT OR • Heavy Duty Includes Installation Lid • Max Load 10 Tons

IDEAL CODE

OUTER DIMS (L X W X H)

CHANNEL DIMS

WEIGHT

CDYFCP3CH1000

1000 x 300 x 50mm

30 x 35mm

8.5Kg

CDYFCP2CH1000

1000 x 250 x 50mm

32 x 32mm

6.5Kg

CDYCPFH3PC132

910 x 500 x 50mm

35 x 35mm

13Kg

37

DATA & NETWORKING

DYNAMIX USB-C 2.1A KEYSTONE CHARGING MECH • Input: 100-240V 50Hz • Output: 5VDC 2.1A • Includes Clipsal Adaptor

IDEAL CODE CDYAVUSBPC01

DYNAMIX USB-A 2.1A KEYSTONE CHARGING MECH • Power supply 1200mA for 2 wire system with A/V Adapter, 6 Din rail modules.

• To be used in audio, video or mixed audio video systems.

• The output provides two power supplies in very low safety voltage, The device is electronically protected against overload and short circuit.

IDEAL CODE CDYAVUSBPS01

DATAGUARD DUAL USB CHARGING MECH • 2x 2.4A USB-A Charging Ports • Input Voltage 5VDC • 240VAC • 50/60Hz

IDEAL CODE CDYFPUSB48A

DYNAMIX CAT6 BLACK UTP RIGHT ANGLED PATCH LEAD • PVC Molded with Strain Relief • RJ45 Unshielded Connector • 50μ Inch Gold Plate • Snag Proof.

38

IDEAL CODE

LENGTH

CDYPLKRAC60

0.5M

CDYPLKRAC61

1M

CDYPLKRAC61H

1.5M

CDYPLKRAC62

2M

SUSTAINABILTY

POWER SUPPLY • Smart Wallbox can be supplied either in single-phase or in three-phase • 220-240 V single-phase - 50/60 Hz • 380-415 V three-phase - 50/60 Hz POWER CONSUMPTION • Power consumption of each conditional input (limitationand deferred start): 5 mA 24 V DC MECHANICAL AND ENVIRONMENTAL • Ingress protection code: IP54 • Impact protection code: IK10 • Operating temperature: -30°C to +50°C • Storage temperature: -40°C to +80°C • Attached cable length: 4.5 m

• Interface with an external MID energy meter CONNECTIVITY • Wired Ethernet: 3 ports » Port 1: LAN » Port 2: 3G/4G » Port 3: connection to PC for commissioning » 3G/4G modem as an accessory » OCPP 1.5 or OCPP 1.6 interface COMMISSIONING • Parameters setting through a web server embedded in the charging station WARRANTY • 24 months for the entire EVlink range

SUSTINABILITY - SOLAR & EV

EVLINK SMART WALLBOX

ENERGY METERING • Integrated measuring of the apparent power

EVLINK PARKING POWER SUPPLY NETWORK • Earthing system: TT, TN-S, TN-C-S » IT (may require the addition of an isolating transformer for charging of certain vehicles) • Frequency: 50 Hz or 60 Hz • Socket outlet supply circuit (1 circuit per socket outlet): » 220/240 V 1P+N or » 380/415 V 3P+N • Control circuit voltage (for charging station): » 220/240 V 1P+N CHARGING MODES • Mode 3 with T2 socket outlet

• Communication between charging station and vehicle via charging cable as per IEC 61851 MECHANICAL AND ENVIRONMENTAL • Painted steel body, anti-corrosion treatment • Protection: IP54 (IEC 60529), IK10 (IEC 62262) • Operating temperature: -25°C to +40°C for Mode 2 / Mode 3 charging station • Operating temperature: -25°C to +50°C for Mode 3 only charging station WARRANTY • 24 months for the entire EVlink range

39

CATEGORY

40
