HYDRALADA MIDRAIL DROPGATE ISOLATION SWITCH
Chassis White Earth wires, A earth is provided from the Ignition switch in the platfrom. The other wire is connected to the engine.
Chassis Yellow wires 12v switch power is supplied from the ignition switch when in the ON position. With the Midrail access dropgate in the lowered position the switch is NC and power is supplied to the Start button and the chassis functions.
With the Midrail dropgate in the lowered position, NO Contacts breaks the earth circuit allowing the engine to run. When the dropgate is raised the switch earths the engine stopping the sparkplugs from firing.
When the access gate is Raised, the contacts break the cicuit and power is removed from the machine.
For fault finding this circuit can be disconnetected.
To Test - Jump the two pins on the yellow wire plug. This is for fault finding only.
NO
NC
Switch Midrail Engine Isolation.
DATE:
25/09/2024
VERSION: 1.0 TITLE:
