FEEDOUT WAGON
RX178 V2
FEEDOUT WAGON
CHASSIS ASSY RX178 V2
H00001201P H00001079 H00000949
H00005266
H00005980
H00001203P
FEEDOUT WAGON
CHASSIS ASSY RX178 V2
FEEDOUT WAGON
CHASSIS ASSY RX178 V2
HUSTLER© FEEDOUT WAGON
CROSS FLOOR CHAIN ASSEMBLY RX V2 -1
FEEDOUT WAGON
PUSHER
H00001703
H00001705
H00001271
C
FEEDOUT WAGON
ELEVATOR CATCHING
DETAIL B
DETAIL D
FEEDOUT WAGON
ELEVATOR CATCHING
H00006359
5105021
H00005915P
9009139
H00001901P
5005803
9009260
H00001528
H00001271
5105021 9009113
H00006359
DETAIL E
H00001705
H00001703 5203956 9009174
H00001705 9009113
H00001508
H00005903P
9009159
9009035
9009124 9009540
H00005902P
5200765
9009259
9009301
DETAIL F
FEEDOUT WAGON
H00000248
ELEVATOR CATCHING
HUSTLER© COMBI
ELEVATOR CHAIN ASSEMBLY -1
DO NOT SCALE PRINT, REMOVE ALL BURRS AND BREAK ALL SHARP EDGES ALL DIMENSIONS ARE IN MILLIMETERS UNLESS OTHERWISE SPECIFIED
CONTAINED IN THIS DRAWING IS PROPRIETARY TO HUSTLER AND SHALL NOT BE REPRODUCED OR DISCLOSED IN WHOLE OR IN PART OR USED FOR ANY DESIGN OR MANUFACTURE EXCEPT WHEN SUCH USER POSSESSES DIRECT WRITTEN AUTHORISATION FROM HUSTLER
DO NOT FIT BAR AT JOINER ENSURE JOINER CLIPS ON ON THE INSIDE
FEEDOUT WAGON
ELEVATOR FLAPS RX V2
ELEVATOR CURVE TOP ASSEMBLY
FEEDOUT WAGON
ELEVATOR CURVE TOP ASSEMBLY
FEEDOUT WAGON
A
FEEDOUT WAGON
ELEVATOR CURVE TOP ASSEMBLY
DETAIL D
C
FEEDOUT WAGON
ELEVATOR CURVE TOP ASSEMBLY
DETAIL E
DETAIL F
FEEDOUT WAGON
H00000280
DRAWBAR WAGON HD
DRAWBAR WAGON HD
FEEDOUT WAGON
H00004111
FRONT FENCE RX V2 ASSEMBLY
FEEDOUT WAGON
SIDE GUARD RX178
S11111121
COMBI RX WAGON NZ ROAD VIS KIT
FEEDOUT WAGON
FEEDOUT WAGON
FEEDOUT WAGON
SIDE ASSY LH RX178 V2
SCALE 1 : 10 9009113 9009302
DETAIL A
DETAIL C
SCALE 1 : 15
9009026
H00001267
DETAIL B
SCALE 1 : 10
H00001198
WAGON LADDER
WAGON LADDER
DETAIL C SCALE 3 : 10 9009302
H00001517
H00003634
DETAIL B SCALE 3 : 10
PUSHER RAM ASSY RX178
COMBI RX178
