C E R T I F I C A T E
No. Z1A 117950 0006 Rev. 01
Holder of Certificate: Kusch+Co GmbH
Gundringhausen 5 59969 Hallenberg GERMANY
Certification Mark:
Product:
Tested according to:
Seating furniture for non-domestic use
DIN EN 16139:2014
DIN 4573:2021
AfPS GS 2019:01 PAK PPP 51063B:2022
With this certificate, in its capacity as a notified GS body, TÜV SÜD Product Service GmbH issues the GS Mark to the named certificate holder for the declared product with the named model designation in accordance with section 20 ProdSG (German Product Safety Act). The product meets the safety and health requirements of section 20 (3) ProdSG. The manufacturer is reminded of their obligations in accordance with section 24 ProdSG. The certification marks shown above can be affixed on the product. It is not permitted to alter the certification marks in any way. In addition, the certificate holder must not transfer the certificate to third parties. This certificate is valid until the listed date, unless it is cancelled earlier. All applicable requirements of the Testing, Certification, Validation and Verification Regulations of TÜV SÜD Group have to be complied. For details see: www.tuvsud.com/ps-cert
Test report no.: 713347938-1
Valid until: 2030-02-04
Date, 2025-02-07
( Jens Biesenack )
C E R T I F I C A T E
No. Z1A 117950 0006 Rev. 01
Model(s):
V-Care bench
- 2U / 3U / 4U
- PRM 2U / 3U / 4U
- 2U / 3U / 4U with external table
- PRM 2U / 3U / 4U with external table
- 1U / 2U / 3U with big table
- PRM 1U / 2U / 3U with big table
V-Care double-sided bench BBC
- 4U / 6U / 8U
- PRM 4U / 6U / 8U
- 4U / 6U / 8U with external table
- PRM 4U / 6U / 8U with external table
4U / 6U / 8U with big table
- PRM 4U / 6U / 8U with big table
Technical data:
The V-Care Bench series includes various models of benches for waiting areas. The benches consist of one or more polyurethane seat shells, mounted on a metal frame made of powder-coated steel.
The bench can optionally be fitted with armrests made of powder-coated aluminium. Variants are single-sided benches with seating for 1 to 4 people or double-sided benches with seating for 4, 6 or 8 people.
The seat shell can be designed as a standard seat or as a PRM seat for people with reduced mobility. The models with a PRM seat have a seat shell mounted at a higher seat height.
Seat height standard: 460 mm
Seat height PRM: 510 mm
V-Care bench 2U / 3U / 4U
Width: 1110 / 1680 / 2250 mm
Depth: 610 mm
Height: 820 mm
V-Care double-sided bench BBC 4U / 6U / 8U
Width: 1110 / 1680 / 2250 mm
Depth: 1290 mm
Height: 820 mm
The benches are optionally available with tables made of plastic laminate, which are attached to the outside of the bench as external tables or as big tables between two seat shells.
Table top width: 420 mm (big table) / 300 mm (external table)
Table top depth: 500 mm
Table top thickness: 13 mm
C E R T I F I C A T E
No. Z1A 117950 0006 Rev. 01
V-Care bench 2U / 3U / 4U with external table
Width: 1730 / 2300 / 2870 mm
Depth: 610 mm
Height: 820 mm
V-Care bench 1U / 2U / 3U with big table
Width: 1110 / 1680 / 2250 mm
Depth: 610 mm
Height: 820 mm
V-Care double-sided bench BBC 4U / 6U / 8U with external table
Width: 1730 / 2300 / 2870 mm
Depth: 1290 mm
Height: 820 mm
V-Care double-sided bench BBC 4U / 6U / 8U with big table
Width: 1110 / 1680 / 2250 mm
Depth: 1290 mm
Height: 820 mm
Production Facilities: 077947, 121393
