PREVENTIVE MAINTENANCE PROGRAM

Mp7 And Mp8 Engine Maintenance

MEDIUM HIGHWAY USAGE

Total Fuel Consumption Less than 39 L/km (Greater than 6.0 MPG)

HEAVY HIGHWAY USAGE

Total Fuel Consumption Less than 50 L/km (Greater than 4.7 MPG)

Mp7 And Mp8 Engine Maintenance

MEDIUM HIGHWAY USAGE

Total Fuel Consumption

Less than 39 L/km (Greater than 6.0 MPG)

HEAVY HIGHWAY USAGE

Total Fuel Consumption Less than 50 L/km (Greater than 4.7 MPG)

Oil and Filter Change (includes fuel filters)

Note: If idle time is greater than 25% of total vehicle usage, use the next lower drain interval.

56 000 km/ 35,000 miles

40 000 km/ 25,000 miles

Oil and Filter Change (includes fuel filters)

Note: If idle time is greater than 25% of total vehicle usage, use the next lower drain interval.

56 000 km/ 35,000 miles

40 000 km/ 25,000 miles

Air FilterAt maximum restriction as indicated on gauge, or 12 months, whichever occurs first

Coolant Conditioner (used with traditional coolants requiring Supplemental Coolant Additive [SCA])

Coolant Filter (used with extended-life coolants which do not require SCA)

80 000 km/50,000 miles

(the coolant conditioner may be changed at each oil and filter change interval)

240 000 km/150,000 miles* or 12 months*

Air FilterAt maximum restriction as indicated on gauge, or 12 months, whichever occurs first

Coolant Conditioner (used with traditional coolants requiring Supplemental Coolant Additive [SCA])

Coolant Filter (used with extended-life coolants which do not require SCA)

80 000 km/50,000 miles (the coolant conditioner may be changed at each oil and filter change interval)

240 000 km/150,000 miles* or 12 months*

CoolantTraditional — (fully formulated) 500 000 km/ 300,000 miles* or 24 months*

Extended-Life — 1 000 000 km/600,000 miles* or 48 months*

CoolantTraditional — (fully formulated) 500 000 km/ 300,000 miles* or 24 months*

Extended-Life — 1 000 000 km/600,000 miles* or 48 months*

Valve Lash and Unit Injector Pre-Load Check and Adjustment

Belts (Fan and Accessory)

Ash Cleaning (Catalyzed Diesel Particulate Filter [DPF])

Aftertreatment Hydrocarbon Injector (AHI) Service

*Whichever occurs first.

Initial — 200 000 km/125,000 miles* or 12 months*

Regular — 400 000 km/250,000 miles* or 24 months*

500 000 km/300,000 miles* or maximum of 36 months*

400 000 km/250,000 miles* or 4,500 hours*

240 000 km/150,000 miles* or 4,500 hours*

Valve Lash and Unit Injector Pre-Load Check and Adjustment

Belts (Fan and Accessory)

Ash Cleaning (Catalyzed Diesel Particulate Filter [DPF])

Aftertreatment Hydrocarbon Injector (AHI) Service

*Whichever occurs first.

Initial — 200 000 km/125,000 miles* or 12 months*

Regular — 400 000 km/250,000 miles* or 24 months*

500 000 km/300,000 miles* or maximum of 36 months*

400 000 km/250,000 miles* or 4,500 hours*

240 000 km/150,000 miles* or 4,500 hours*

Preventive Maintenance Program

Preventive Maintenance Program

Certain chassis vocations may require more frequent service intervals. When developing a maintenance program, review chassis operating conditions and adjust the service intervals as required. At each maintenance and lubrication interval, look at the condition of chassis lubrication points, condition of components, etc., and adjust your service intervals accordingly. Using a lubricant analysis program performed by a reputable laboratory is the most effective method of determining lubricant change intervals. Alter the maintenance program to meet your needs, but never exceed MACK recommended intervals.

Certain chassis vocations may require more frequent service intervals. When developing a maintenance program, review chassis operating conditions and adjust the service intervals as required. At each maintenance and lubrication interval, look at the condition of chassis lubrication points, condition of components, etc., and adjust your service intervals accordingly. Using a lubricant analysis program performed by a reputable laboratory is the most effective method of determining lubricant change intervals. Alter the maintenance program to meet your needs, but never exceed MACK recommended intervals.

Preventive Maintenance Program

Preventive Maintenance Program

Oil and Filter Change (includes fuel filters)

Note: If idle time is greater than 25% of total vehicle usage, use the next lower drain interval.

SEVERE VOCATIONAL USAGE

Total Fuel Consumption Less than 64 MPG (Greater than 3.7 MPG)

24 000 km/15,000 miles*, 450 hours* or 6 months maximum*

VERY SEVERE VOCATIONAL USAGE

Total Fuel Consumption Less than 120 L/km (Greater than 2.0 MPG)

16 000 km/10,000 miles*, 300 hours* or 6 months maximum*

Air FilterAt maximum restriction as indicated on gauge, or 12 months, whichever occurs first

Coolant Conditioner (used with traditional coolants requiring Supplemental Coolant Additive [SCA])

Coolant Filter (used with extended-life coolants which do not require SCA)

80 000 km/50,000 miles* or 6 months*

Oil and Filter Change (includes fuel filters)

Note: If idle time is greater than 25% of total vehicle usage, use the next lower drain interval.

SEVERE VOCATIONAL USAGE

Total Fuel Consumption Less than 64 MPG (Greater than 3.7 MPG)

24 000 km/15,000 miles*, 450 hours* or 6 months maximum*

VERY SEVERE VOCATIONAL USAGE

Total Fuel Consumption Less than 120 L/km (Greater than 2.0 MPG)

16 000 km/10,000 miles*, 300 hours* or 6 months maximum*

Air FilterAt maximum restriction as indicated on gauge, or 12 months, whichever occurs first

Coolant Conditioner (used with traditional coolants requiring Supplemental Coolant Additive [SCA])

80 000 km/50,000 miles* or 6 months*

240 000 km/150,000 miles* or 12 months*

Coolant Filter (used with extended-life coolants which do not require SCA)

240 000 km/150,000 miles* or 12 months*

CoolantTraditional — (fully formulated) 500 000 km/ 300,000 miles* or 24 months*

Extended-Life — 1 000 000 km/600,000 miles* or 48 months*

CoolantTraditional — (fully formulated) 500 000 km/ 300,000 miles* or 24 months*

Extended-Life — 1 000 000 km/600,000 miles* or 48 months*

MP7

Preventive Maintenance Program

MP7

Valve Lash and Unit Injector Pre-Load Check and Adjustment

Belts (Fan and Accessory)

Ash Cleaning (Catalyzed and Non-Catalyzed Diesel Particulate Filter [DPF])

Aftertreatment

Hydrocarbon Injector (AHI) cleaning (catalyzed only)

Electrode and Injection Nozzle Service (non-catalyzed DPF only)

*Whichever occurs first.

SEVERE VOCATIONAL USAGE

Total Fuel Consumption Less than 64 MPG (Greater than 3.7 MPG)

VERY SEVERE VOCATIONAL USAGE

Total Fuel Consumption Less than 120 L/km (Greater than 2.0 MPG)

Initial — 200 000 km/125,000 miles* or 12 months* Regular — 400 000 km/250,000 miles* or 24 months*

240 000 km/150,000 miles* or maximum of 12 months*

400 000 km/250,000 miles* or 4,500 hours*

Valve Lash and Unit Injector Pre-Load Check and Adjustment

Belts (Fan and Accessory)

Ash Cleaning (Catalyzed and Non-Catalyzed Diesel Particulate Filter [DPF])

SEVERE VOCATIONAL USAGE

Total Fuel Consumption Less than 64 MPG (Greater than 3.7 MPG)

VERY SEVERE VOCATIONAL USAGE

Total Fuel Consumption Less than 120 L/km (Greater than 2.0 MPG)

Initial — 200 000 km/125,000 miles* or 12 months* Regular — 400 000 km/250,000 miles* or 24 months*

240 000 km/150,000 miles* or maximum of 12 months*

400 000 km/250,000 miles* or 4,500 hours*

240 000 km/150,000 miles* or 4,500 hours*

Aftertreatment Hydrocarbon Injector (AHI) cleaning (catalyzed only)

240 000 km/150,000 miles* or 4,500 hours*

161 000 km/100,000 miles* or 2,400 hours*

Electrode and Injection Nozzle Service (non-catalyzed DPF only)

*Whichever occurs first.

161 000 km/100,000 miles* or 2,400 hours*

Preventive Maintenance Program

Preventive Maintenance Program

CHASSIS MAINTENANCE AND LUBRICATION

SEVERE VOCATIONAL USAGE Total Fuel Consumption Less than 64 L/km (Greater than 3.7 MPG)

VERY SEVERE VOCATIONAL USAGE Total Fuel Consumption Less than 120 L/km (Greater than 2.0 MPG)

CHASSIS MAINTENANCE AND LUBRICATION

SEVERE VOCATIONAL USAGE

Total Fuel Consumption Less than 64 L/km (Greater than 3.7 MPG)

A Inspection12 000 km/ 7,500 miles* or 225 hours*

B Inspection24 000 km/ 15,000 miles* or 450 hours*

C Inspection48 000 km/ 30,000 miles* or 900 hours*

D Inspection96 000 km/ 60,000 miles* or 1,800 hours*

VERY SEVERE VOCATIONAL USAGE Total Fuel Consumption Less than 120 L/km (Greater than 2.0 MPG)

000 km/ 5,000 miles* or 150 hours*

000 km/ 10,000 miles* or 300 hours*

000 km/ 20,000 miles* or 600 hours*

*Whichever occurs first.

*Whichever occurs first.

Notes Table

Preventive Maintenance Program

Preventive Maintenance Program

Notes Table

Note 1:Lubricate the clutch release bearing at each recommended chassis lubrication interval (refer to the interval charts on pages 17 through 20).

Lubricate the driveshaft (Spicer and ArvinMeritor™) at the following intervals:

Spicer Life™ SPL-170 and SPL-250 Driveshaft — U-Joint Lubrication

Highway Usage: Every 161 000 km (100,000 miles) or 6 months*

Vocational Usage:

—Severe Vocational Usage: 32 000 km (20,000 miles) or 180 days*

—Very Severe Vocational Usage: 375 hours or 90 days*

* Whichever occurs first.

Note 1:Lubricate the clutch release bearing at each recommended chassis lubrication interval (refer to the interval charts on pages 17 through 20).

Lubricate the driveshaft (Spicer and ArvinMeritor™) at the following intervals:

Spicer Life™ SPL-170 and SPL-250 Driveshaft — U-Joint Lubrication

Highway Usage: Every 161 000 km (100,000 miles) or 6 months*

Vocational Usage:

—Severe Vocational Usage: 32 000 km (20,000 miles) or 180 days*

—Very Severe Vocational Usage: 375 hours or 90 days*

* Whichever occurs first.

Preventive Maintenance Program

Spicer Life™ SPL-170XL and SPL-250XL Driveshaft — U-Joint Lubrication

Spicer Life™ XL series driveshafts are equipped with “extended-lubrication” U-joints. These U-joints are easily identified by the blue plastic cover in the center of the U-joint cross where the grease fitting is usually located. The XL U-joints must be lubricated initially at the following intervals:

Highway Chassis: 560 000 km (350,000 miles) or 3 years*

Vocational Chassis (includes city driving and on/off highway: 161 000 km (100,000 miles) or 1 year*

* Whichever occurs first.

Following the initial lubrication outlined above, Spicer Life™ XL series U-joints must be lubricated at the following intervals:

Highway Chassis: 161 000 km (100,000 miles) or 6 months*

Vocational Chassis:

—Severe Service: 32 000 km (20,000 miles) or 180 days*

—Extra Severe Service: 375 hours or 90 days*

* Whichever occurs first.

The slip-joints used with Spicer Life™ driveshafts are “Lubed for Life,” and protected by a bellows. Lubrication of these slip-joints is not required and the bellows must not be disturbed.

ArvinMeritor™ RPL20 and RPL25 Permalube™ Series Driveshafts

The U-joints and slip joints on the RPL20 and RPL25 series driveshafts are permanently lubricated and sealed. Lubrication at regular intervals is not required during the life of the driveshaft.

Preventive Maintenance Program

Spicer Life™ SPL-170XL and SPL-250XL Driveshaft — U-Joint Lubrication

Spicer Life™ XL series driveshafts are equipped with “extended-lubrication” U-joints. These U-joints are easily identified by the blue plastic cover in the center of the U-joint cross where the grease fitting is usually located. The XL U-joints must be lubricated initially at the following intervals:

Highway Chassis: 560 000 km (350,000 miles) or 3 years*

Vocational Chassis (includes city driving and on/off highway: 161 000 km (100,000 miles) or 1 year*

* Whichever occurs first.

Following the initial lubrication outlined above, Spicer Life™ XL series U-joints must be lubricated at the following intervals:

Highway Chassis: 161 000 km (100,000 miles) or 6 months*

Vocational Chassis:

—Severe Service: 32 000 km (20,000 miles) or 180 days*

—Extra Severe Service: 375 hours or 90 days*

* Whichever occurs first.

The slip-joints used with Spicer Life™ driveshafts are “Lubed for Life,” and protected by a bellows. Lubrication of these slip-joints is not required and the bellows must not be disturbed.

ArvinMeritor™ RPL20 and RPL25 Permalube™ Series Driveshafts

The U-joints and slip joints on the RPL20 and RPL25 series driveshafts are permanently lubricated and sealed. Lubrication at regular intervals is not required during the life of the driveshaft.

Preventive Maintenance Program

ArvinMeritor™ 92N Permalube™ Wing-Style Driveshafts

The U-joints used on the 92N Permalube™ Wing-Style Driveshafts are permanently lubricated and sealed. Lubrication at regular intervals is not required during the life of the driveshaft. The slip joints, however, must be lubricated at each specified chassis lubrication interval. Refer to the preventive maintenance schedules found on pages 17 and 20.

Note 2:An extended service drain interval of 804 600 km (500,000 miles) or 3 years, whichever occurs first, for Highway type operations is permissible for MACK geared drivetrain components (Transmissions and Carriers) IF MACK-specific GO-J PLUS Gear Lubricant is used. For Vocational operations, an extended drain interval of 128 800 km (80,000 miles), 1 year or 1,200 hours, whichever occurs first, is permissible if GO-J PLUS Gear Lubricant is used. An SAE 40 or 50 grade transmission oil, TO-A PLUS, is also available for use in all MACK transmissions. Extended drain intervals for transmissions using TO-A PLUS are 804 600 km (500,000 miles) or 3 years, whichever occurs first, for Highway operations, and 128 800 km (80,000 miles), 1 year or 1,200 hours, whichever occurs first, for Vocational operations.

If a MACK axle and/or transmission were initially filled with GO-J PLUS gear lubricant and later “topped-off” with greater than 1-1/2 quarts of GO-J specification gear lubricant, the drain interval is reduced to the GO-J limits (2 years or 402 300 km [250,000 miles]).

ArvinMeritor™ 92N Permalube™ Wing-Style Driveshafts

The U-joints used on the 92N Permalube™ Wing-Style Driveshafts are permanently lubricated and sealed. Lubrication at regular intervals is not required during the life of the driveshaft. The slip joints, however, must be lubricated at each specified chassis lubrication interval. Refer to the preventive maintenance schedules found on pages 17 and 20.

Note 2:An extended service drain interval of 804 600 km (500,000 miles) or 3 years, whichever occurs first, for Highway type operations is permissible for MACK geared drivetrain components (Transmissions and Carriers) IF MACK-specific GO-J PLUS Gear Lubricant is used. For Vocational operations, an extended drain interval of 128 800 km (80,000 miles), 1 year or 1,200 hours, whichever occurs first, is permissible if GO-J PLUS Gear Lubricant is used. An SAE 40 or 50 grade transmission oil, TO-A PLUS, is also available for use in all MACK transmissions. Extended drain intervals for transmissions using TO-A PLUS are 804 600 km (500,000 miles) or 3 years, whichever occurs first, for Highway operations, and 128 800 km (80,000 miles), 1 year or 1,200 hours, whichever occurs first, for Vocational operations.

If a MACK axle and/or transmission were initially filled with GO-J PLUS gear lubricant and later “topped-off” with greater than 1-1/2 quarts of GO-J specification gear lubricant, the drain interval is reduced to the GO-J limits (2 years or 402 300 km [250,000 miles]).
