Terminal (settings, optional controls) 23
1. Program Overview 2012: Forage Harvester BiG X
Type Cutting Drum Composite belt main drive Engine Travelling gearsystem Fuel tank L / G Additional tank L / G
(Fuel or silage agent)
500
V-shaped/ 11° Ø 660 mm; 800 mm 28blades (20, 40blades) * 5 –groove MB OM 460 LA 12.8 l / R6 Poclain 960 / 253 250/ 66
700
V-shaped/ 11° Ø 660 mm; 800 mm 28 blades (20, 40, 48blades) * 7 –groove MAN D 2868 LE 16.16 l / V8 Poclain 960 / 253 330 / 87
850
V-shaped/ 11° Ø 660 mm; 800 mm 28 blades (20, 40, 48blades) * 8 –groove MAN D 2862 LE 24.24 l / V12 Bosch Rexroth 960 / 253 330 / 87
1100
V-shaped/ 11° Ø 660 mm; 800 mm 28 blades (20, 40, 48blades) * 8 –groove MAN D 2862 LE 24.24 l / V12 Bosch Rexroth 960 / 253 330 / 87
* optional
ICAN Computer Assistance Network:
AutoScan -maturity detection and automatic cutting length adjustment VariCollect -for independent adjustment of header and feed drive speeds SynchroSpeed -for automatic synchronisation of head speed and ground speed DataManager -machine data in ISO-XML format for further processing in many software applications
4
ServiceTraining 2012 advanced © KRONE Training Team, Spelle, Germany
1. Program Overview 2012: Forage Harvester BiG X
Performance Data-Overview
Principle of PowerSplit on BiG X 700/850/1100 R 6 engine with 12.8 l capacity (MB OM 460 LA)
BiG X 500
Continuous cutting output: 486 HP (ECE R24)
V 8 engine with 16.16 l capacity (MAN D 2868 LE)
BiGX 700
Continuous cutting output X-Power: 492 kW / 775 HP Continuous cutting output Eco Power: 374 kW / 509 HP
V 12 engine with 24.24 l capacity (MAN D 2862 LE)
BiG X 850
Continuous cutting output X Power: 607 kW / 825 HP Continuous cutting output Eco Power: 469 kW / 638 HP
BiG X 1100
Continuous cutting output X Power: 760 kW / 1,034 HP Continuous cutting output Eco Power: 469 kW / 638 HP
Eco Power –X Power
Eco Power is used to reduce fuel consumption when max performance is not required. When additional performance is required, on the BiG X 700, 850 and 1100, press the X Power button to activate full power mode. Power modes can be configured to automatically change (available on select engine models).
