FIGURE 5-17. TELESCOPE CYLINDER ASSEMBLY - MAIN BOOM
ITEM PART NUMBER QTY
DESCRIPTION
1682415 Ref TELESCOPE CYLINDER ASSEMBLY - MAIN BOOM 1 1682416 1 Barrel Assembly 3 1120108 1 End Cap 3 0100035 AR Loctite #222 4 1681283 1 Head 5 Kit 1 Ring, Wear 6 Kit 1 Seal, Wiper 7 Kit 1 Seal, Rod 8 Kit 1 O-Ring 9 4564275 1 Spacer, Tube 9 3951603 2 Setscrew 3/8in-26NC x 3/8in 9 0100011 AR Loctite #242 10 3480092 1 Piston 11 3300282 1 Nut, Hex (February 1991 to Present) 11 0100011 AR Loctite #242 11 0100038 AR Primer, Locking 12 3900170 1 Setscrew 3/8in-16NC x 3/8in 13 Kit 1 O-Ring 14 Kit 2 Ring, Guidelock 15 Kit 2 Seal, Piston 16 1682039 1 Rod Assembly 17 2200201 1 Plug 1/8in 18 2200222 2 Plug 1/4in 18 0100020 AR Sealant, Pipe 19 0560810 1 Block, Support 20 0641628 1 Bolt 3/8in-16NC x 3 1/2in 21 0641632 1 Bolt 3/8in-16NC x 4in 22 4751600 4 Flatwasher 3/8in 23 3311601 2 Nut 3/8in-16NC 25 4640675 1 Valve, Dual Counterbalance (Not Field Repairable - Replace Complete Valve) 26 0641520 4 Bolt 5/16in-18NC x 2 1/2in 26 0100011 AR Loctite #242 2900396 Seal Kit (Includes Items 5, 6, 7, 8, 13, 14 & 15)
REV
B
