FIGURE 6-1. HYDRAULIC DIAGRAM - AXLE LOCKOUT

FIGURE 6-1. HYDRAULIC DIAGRAM - AXLE LOCKOUT

FIGURE 6-1. HYDRAULIC DIAGRAM - AXLE LOCKOUT

ITEM PART NUMBER QTY

DESCRIPTION

Ref HYDRAULIC DIAGRAM - AXLE LOCKOUT WITH SWIVEL 2791844 Ref 2m Wide Machines 2791978 Ref 1.75m Wide Machines 1 2220582 2 Fitting, Straight 2 Ref Hose Options: 2 2750899 1 2m Wide Machines 2 2751014 1 1.75m Wide Machines 3 2750900 1 Hose 4 222504 1 Fitting, Tee 5 Ref Fitting Options: 5 2220371 2 Straight - 2m Wide Machines 5 2751014 2 90 - 1.75m Wide Machines 6 Ref Hose Options: 6 2750990 2 2m Wide Machines 6 2751138 2 1.75m Wide Machines 8 Ref Fitting, Tee Options: 8 2220635 1 2m Wide Machines 8 2220490 1 1.75m Wide Machines 9 Ref Hose Options: 9 2751394 1 2m Wide Machines 9 2751014 1 1.75m Wide Machines 10 2220235 1 Fitting, Plug 11 2220466 3 Fitting, 90 12 2751394 1 Hose 13 Ref Hose Options: 13 Not Required 0 2m Wide Machines 13 2750785 1 1.75m Wide Machines 14 2220587 1 Fitting, Tee 15 2220414 2 Fitting, Straight 16 2220416 2 Fitting, 90 17 2751021 1 Hose 18 4640013 1 Valve, Shuttle 19 2750902 1 Hose 20 2220618 1 Fitting, Reducer 21 2220385 1 Fitting, Tee 22 2750910 1 Hose 23 2220619 1 Fitting, Reducer 24 2220385 1 Fitting, Tee 25 Ref Hose Options: 25 2750899 1 2m Wide Machines 25 2751412 1 1.75m Wide Machines 26 2220415 1 Fitting, Straight 0100020 AR Sealant

REV

D-5 B
