FIGURE 2-24. GROUND CONTROL BOX INSTALLATION (GAS/DIESEL MACHINES
ITEM PART NUMBER QTY
DESCRIPTION
Ref GROUND CONTROL BOX ASSEMBLY 0860830 Ref Gas Machines Built (Prior to October 1994) 0860956 Ref Gas Machines Built (October 1994 to Present) 0860723 Ref Diesel Machines 1 Ref Lid Options: 1 3252044 1 Lid Used (Prior to May 1994) 1 3252383 1 Lid Used May (1994 to Present) 1 4420037 38 in/1m Strip, Rubber (Not Shown) 2 0750806 2 Screw, Self-Tapping #8 x 3/4in 3 4740120 2 Washer, Fiber 4 3300177 2 Nut, Tinnerman 5 3911412 3 Screw, Round Head 1/4in-20NC x 3/4in 6 4751400 3 Flatwasher 1/4in 7 4761400 3 Lockwasher 1/4in 8 3311401 3 Nut 1/4in-20NC 9 0860645 1 Box 10 0641405 4 Bolt 1/4in-20NC x 5/8in 11 4751400 4 Flatwasher 1/4in 12 4761400 4 Lockwasher 1/4in 13 3311401 4 Nut 1/4in-20NC 14 2420009 1 Hourmeter 15 2420129 1 Voltmeter 16 Ref Gage, Oil Pressure Options: 16 2420128 1 Gage, Oil Pressure (0-80 PSI) 16 2420111 1 Gage, Oil Pressure (0-100 PSI) 18 4360274 1 Switch, Push Button 18 3790015 1 O-Ring 19 3520028 1 Plug, Hole 20 4360284 1 Switch, Key (Master Switch) 20 7010698 1 Key, Replacement 20 4360267 1 Block, Contact - SPST - N.O. 20 4360281 3 Block, Contact - N.O. 21 4360199 1 Switch, Toggle (Ignition) 21 4360141 1 Guard, Switch 21 3790012 1 O-Ring 22 4360202 1 Switch, Toggle (Platform Rotate) 22 3790012 1 O-Ring 23 3520028 1 Plug, Hole 24 4360202 1 Switch, Toggle (Tower Lift) 24 3790012 1 O-Ring 25 4360202 1 Switch, Toggle (Main Lift) 25 3790012 1 O-Ring 26 4360202 1 Switch, Toggle (Swing) 26 3790012 1 O-Ring 27 4360202 1 Switch, Toggle (Tower Tele) 27 3790012 1 O-Ring 28 4360202 1 Switch, Toggle (Main Tele) 28 3790012 1 O-Ring 29 4360200 1 Switch, Toggle (Auxiliary Power) 29 3790012 1 O-Ring
REV
C
E
ITEM PART NUMBER QTY DESCRIPTION
30 3740049 15 Relay - SPDT 30 3311001 11 Nut #10-24NC 30 4761000 11 Lockwasher #10 30 4751000 11 Flatwasher #10 31 4360216 1 Switch, Circuit Breaker - 30 Amp 32 4360232 1 Switch, Circuit Breaker - 15 Amp 33 3640711 1 Rail (16 5/8in - 42cm Length) 33 3910606 2 Screw #6-32NC x 3/8in 33 4750600 2 Flatwasher #6 33 4760600 2 Lockwasher #6 33 3310601 2 Nut #6-32NC 34 4460299 2 Stop, Terminal 35 3740058 AR Relay - 4PDT 35 4120013 AR Base, Relay 35 3740063 AR Spring 36 4460300 2 Barrier, Terminal 37 4460298 45 Block, Terminal 38 4460301 1 Marker, Terminal 39 4460308 1 Bar, Buss (2 Position) 39 4460305 2 Screw 39 4460306 2 Washer 39 4460307 2 Sleeve 40 4460311 1 Bar, Buss 40 4460305 5 Screw 40 4460306 5 Washer 40 4460307 5 Sleeve 41 4460071 1 Connector, Strain Relief 41 0960238 1 Bushing 41 3300048 1 Nut, Conduit 42 4460051 3 Connector, Strain Relief 42 0960238 3 Bushing 42 3300048 3 Nut, Conduit 43 3740077 1 Relay, Bosch 43 3311001 1 Nut #10-24NC 43 4761000 1 Lockwasher #10 43 4751000 1 Flatwasher #10 44 Ref Connector, Strain Relief Options: 44 4460051 1 Connector, Strain Relief (Prior to SN 27513) 44 4460244 1 Connector, Strain Relief (SN 27513 to Present) 44 0960238 1 Bushing 44 3300048 1 Nut, Conduit 51 Ref Gage Options: 51 2420127 1 Gas Machines - Gage, Water Temperature 51 2420125 1 Diesel Machines - Gage, Oil Temperature 51 3990001 2 Diode - 3.5 Amp 52 Ref Breaker, Circuit Options: 52 3520026 1 Plug, Hole (Gas Machines) 52 4360212 1 Breaker, Circuit (Diesel Machines) 53 Ref Switch, Toggle Options: 53 3520026 1 Plug, Hole (Standard Gas and Diesel Machines) 53 4360201 1 Switch, Toggle (Dual Fuel Machines)
REV
ITEM PART NUMBER QTY DESCRIPTION
54 3311001 AR Nut #10-24NC 54 4761000 AR Lockwasher #10 54 4751000 AR Flatwasher #10 55 Ref Controller, Engine Options: 55 1600117 1 Gas Machines 55 Not Required 0 Diesel Machines 55 Ref Harness, Engine (Not Shown) 55 4921282 1 Gas Machines 55 Not Required 0 Diesel Machines 56 Ref Actuator, Adeco Throttle Options: 56 Not Required 0 Gas Machines 56 0060023 1 Actuator, Adeco Throttle (Diesel Machines) 56 7008829 1 PC Board 56 7008821 1 Motor 56 7008828 1 Cable Ref GROUND CONTROL BOX INSTALLATION 0253622 Ref Gas Machines with Bosch Alternator 0255153 Ref Gas Machines with Prestolite Alternator 0251837 Ref Diesel Machines 101 0641408 4 Bolt 1/4in-20NC x 1in 102 4751400 4 Flatwasher 1/4in 103 3311405 4 Locknut 1/4in-20NC Ref OPTIONAL PANEL LIGHTS INSTALLATION 201 2420024 1 Light, Panel (Optional)
