FIGURE 2-16. GENERATOR INSTALLATION 110 VOLT (DEUTZ) (OPTIONAL
ITEM PART NUMBER QTY
DESCRIPTION
0251880 Ref GENERATOR INSTALLATION - 110 VOLT (DEUTZ) 1 4843410 1 Bracket, Mounting - Generator 3 2460011 1 Generator Assembly with Control Box 3 3580134 1 Pulley 3 7012558 1 Generator Assembly Only 3 7020108 4 Brush 3 7020109 4 Holder, Brush 3 7012513 4 Caps, Brush Holder 3 7012514 1 Fan 3 7020193 1 Cord, Power 3 7026199 1 Armature 3 7020110 1 End Bell, Front 3 7020111 1 End Bell, Rear 3 7020190 2 Bearing 3 7003657 1 Control Box Assembly Ref Note: Replacement 110V Control Box comes with 2 std
Receptacles p/n 4460190. Optional Industrial Twist Lock Receptacles p/n 4460027 must be ordered separately.
3 2420203 1 Voltmeter 3 4360542 1 Breaker, Circuit 3 4460190 2 Receptacle 3 2920162 1 Lamp 3 7020191 1 Switch, Toggle 3 3520028 1 Plug, Hole 4 3251476 1 Nametag - Generator On/Off 5 1060515 1 Cable, Electrical - 12/4 (was p/n 1060012) 7 4460023 1 Terminal, Connector 8 2860012 1 Key, Woodruff 9 0100011 AR Loctite 10 4751500 1 Flatwasher 5/16in 11 4761500 2 Lockwasher 5/16in 12 0361815 1 Arm, Adjustment 13 0701414 1 Bolt, Metric 14mm x 30mm 14 0701012 2 Bolt, Metric 10mm x 25mm 15 0480059 1 V-Belt 16 3580158 1 Pulley 18 0681510 2 Bolt 5/16in-18NC x 1 1/4in 19 3311501 1 Nut 5/16in-18NC 20 0901584 1 Bracket, Mounting - Control Box 21 4300068 2 Stud (Welded on Part) 22 4751400 4 Flatwasher 1/4in 23 4761400 6 Lockwasher 1/4in 24 3311401 4 Nut 1/4in-20NC 25 0641406 2 Bolt 1/4in-20NC x 3/4in 26 4812000 2 Flatwasher, Metric 10mm 27 2180730 1 Fitting, Adapter (Prior to October 1, 1992 Only) 28 2180749 1 Fitting, 45 29 2180537 1 Fitting, Nipple (Prior to SN 23307) 29 2180730 1 Fitting, Adapter (SN 23307 to Present) 30 2180360 1 Fitting, Tee (Prior to SN 23307)
REV
9
ITEM PART NUMBER QTY
DESCRIPTION
31 2200261 1 Fitting, Coupling (Prior to SN 23307) 32 4360037 1 Switch, Oil Pressure 33 0681610 2 Bolt 3/8in-16NC x 1 1/4in 34 4761600 2 Lockwasher 3/8in 35 4751600 2 Flatwasher 3/8in
