FIGURE 2-24. 2500W GENERATOR INSTALLATION - CATERPILLAR MACHINES (OPTIONAL
ITEM PART NUMBER QTY DESCRIPTION REV
Ref 2500W GENERATOR INSTALLATION 0273050 Ref 110V/60Hz Generator (Prior to SN 0300082708) B 0274084 Ref 110V/60Hz Generator (SN 0300082708 through 0300096000) A 0273051 Ref 220V/50HZ Generator (ANSI Export Only) B Ref Note: Aftermarket installation kit not available. Use items (2
thru 9 & 11 thru 23) for 110V Generator or (2 thru 9 & 11 thru 23) for 220V Generator.
1 0100011 AR Compound, Locking 2 0200742 1 Arm, Adjusting 3 Ref V-Belt Options: 3 0480122 1 110V 3 0480120 1 220V 4 0641508 1 Bolt 5/16in-18NC x 1in 5 0641610 1 Bolt 3/8in-16NC x 1-1/4in 6 0641772 1 Bolt 7/16in-14NC x 9in 7 0701217 3 Bolt, Metric 12mm x 45mm 8 0721008 2 Bolt #10-24NC x 1in 9 Ref Generator and Control Box Assembly Options: 9 2460032 1 110V/60Hz Assembly (Prior to SN 0300082708) 9 2460055 1 110V/60Hz Assembly (SN 0300082708 through 0300096000) 9 2460013 1 220V/50Hz Assembly 9A 7012558 1 Generator Only - 110V/60Hz 9A 1001100321 1 Generator Only - 220V/50Hz Ref Note: Replacement Generators come standard with p/n
3580134 pulley. This pulley may not be correct for all applications. Refer to pulley options below.
9A Ref Armature with Slip Rings Options: 9A 7026199 1 Armature with Slip Rings - 110V/60Hz 9A 70000123 1 Armature with Slip Rings - 220V/50Hz 9A 7012513 4 Cap, Brush Holder 9A 7020108 4 Brush 9A 7020109 4 Holder, Brush 9A 7012514 1 Fan 9A 7020110 1 Bell, Front 9A 7020111 1 Bell, Rear 9A 7020190 2 Bearing 9A 7020193 1 Cord, Power 9B 7003657 1 Box, Control - 110V/60Hz (Prior to SN 0300082708) 9B 7019680 1 Box, Control - 110V/60Hz (SN 0300082708 through
0300096000)
9B 70002235 1 Box, Control - 220V/50Hz 9B Ref Receptacle Options: 9B 4460190 1 Receptacle, Standard (110V Only) 9B 4460027 1 Receptacle, Twistlock (110V Only) 9B 70000124 1 Receptacle, Double (220V/50Hz Only) 9B 70000125 1 Receptacle, Single (220V/50Hz Only) 9B Ref Breaker, Circuit Options: 9B 4360542 1 Breaker 110V/60Hz 9B 70000126 1 Breaker 220V/50Hz 9B 3520028 1 Plug, Hole 9B 2920162 1 Lamp Assembly (Not Required on 2460055 Generator
ITEM PART NUMBER QTY DESCRIPTION
Assembly) 9B 7020191 1 Switch, Toggle (Not Required on 2460055 Generator Assembly) 9C Ref Voltmeter Options: 9C 2420203 1 Voltmeter - 110V 9C 7020192 1 Voltmeter - 220V 9D Ref Pulley Options: 9D 3580276 1 Pulley - 60Hz 9D 3580134 1 Pulley - 50Hz 9D 7027887 1 Key, Woodruff 10 2820031 1 Heat Shrink (Not Shown - Located at Platform) 11 3251102 1 Decal (Located at Platform) 12 3311005 2 Locknut #10-24NC 13 3311605 1 Locknut 3/8in-16NC 14 3311705 1 Locknut 7/16in-14NC 15 3520028 1 Plug, Hole 16 3580315 1 Pulley 17 3740080 1 Relay (Not Shown - Located Back Side of Engine Tray with Existing Relays) 18 4060802 1 Guard, Switch (Located at Platform) 19 4360336 1 Switch, Toggle - SPST (Located at Platform) 20 4460023 1 Connector, Strain Relief 21 4751000 8 Flatwasher #10 Regular 22 4751500 1 Flatwasher 5/16in Regular 23 4751600 6 Flatwasher 3/8in Regular
