Concerning your safety – Maintenance work
3.9 Maintenance work
3.9.1 Preliminary remarks
Always carry out the prescribed maintenance work and maintenance measures on time in order to maintain the safety, operational readiness and long service life of the machine.
The machine must only be serviced by qualified personnel authorised by the operating company.
3.9.2 Working on the engine
Drain the engine oil at operating temperature – danger of scalding! Wipe off spilled oil, catch running out oil and dispose of environmentally.
When working on the air filter no dirt should fall into the air duct. Do not work on the hot exhaust - danger of burning!
Store used filters and other oil contaminated materials in a separate, specially marked container and dispose of environmentally.
3.9.3 Cleaning work
Do not perform cleaning work while the motor is running. Allow the engine to cool down before starting cleaning work. Do not use gasoline or other easily inflammable substances for cleaning.
3.9.4 Measures for longer shut-down periods
If the machine is taken out of operation for a longer period of time, various conditions must be met and maintenance work must be carried out both before and after shut-down ÄChapter 8.8.4 ‘Measures prior to extended shut-down period’ on page 90
It is not necessary to define a maximum storage period if these measures have been performed.
3.9.5 After maintenance work
Reassemble all guards and protections.
3.10 Repair
Concerning your safety – Repair
Identify a defect machine with a warning sign. Only operate the machine after it has been repaired. When replacing safety relevant components, only original spare parts must be used.
Repairs must only be performed by an expert/qualified person. When performing welding work on the machine you should cover the fuel tank with insulating material.
Concerning your safety – Signage
3.11 Signage
Keep stickers and signage in good and legible condition and comply with their meaning.
Replace damaged and illegible stickers or signage immediately.
Concerning your safety – Signage
Warning sticker - Follow operating instructions
Warning sticker - Starter rope
Instruction sticker - Wear ear defenders
Information sticker - Lifting point
Concerning your safety – Signage
Information sticker - Lashing point
Information sticker - Guaranteed sound capacity level
Information sticker - Filler opening for water
Information sticker Shut-down pin / throttle lever
Concerning your safety – Signage
Brief operating instructions
Instruction sticker - Observe operating instructions
Maintenance sticker
