Central terminal compartment UNIWRAP
Central terminal compartment UNIWRAP
Key to diagram: A22 UNIWRAP bale wrapper module A30-1 Bale wrapper terminal F 3 Fuse (15 Amperes) RS 232 Data link XD2 CAN bus socket (7 pin) X-X Socket XT-1 Terminal connector X30a UNIWRAP connection plug X30b Blind plug (for ROLLANT without UNIWRAP) X34 Hydraulic system connector X35 Sensor system connector X36 Hydraulic system connector X37 Sensor system connector
Connector mm Colour X-X E 0.5 rd X-X L 0.5 bk X-X H 0.5 gn-ye X-X - 0.5 vi X-X - 0.5 br-rd X-X + 0.5 bk-rd
