BRAKES

SE C T IO N 0

GENERAL INFORMATION AND LUBRICATION

CONTENTS OF THIS SECTION

G e n e ra l I n f o r m a t i o n.................................................................. 0-1 L u b ric a tio n .................................................................................... 0-5

GENERAL IN F O R M A T IO N

INDEX

Model Line U p ............................................................... 0-1 Truck Model D e s ig n a tio n ............................................. 0-1 Vehicle Identification N u m b e r and R ating P la te.... 0-1 E ngine N u m b e r ............................................................... 0-2 U n it and Serial N u m b e r L ocatio n s........................... 0-2 Service Parts Identification P la te ................................. 0-3 Keys and L ocks............................................................... 0-3 E m ergency S t a r t i n g ........................................................ 0-3 T o w in g ............................................................................... 0-4

MODEL LINE UP T he 10 through 35 Series truck model line-up for 1974 consists o f the models shown in the Charts in this section.

Truck Model Designation A five digit n um ber preceded by a letter is used to designate truck models. F o r example, vehicle C 10703 would be: Conventional C, 4900 lbs.-6800 lbs. GVW 1, 42 in. -47 in. Cab-to-Axle dim ension 07, Chassis cab 03, as listed below.

First Letter - Chassis C - C onventional (Conventional Cab, Suburban) G - Light D uty Forw ard Control K - Four-W heel Drive P - Forw ard Control

First Number-GVW Range

1 - 4500-7150 lbs. 2 - 5500-8200 lbs. 3 - 6200-14000 lbs.

Second and Third Numbers- Cab-To-Axle Dimension

05 - 30-35 in. 07 - 42-47 in. 08 - 48-53 in. 09 - 54-59 in. 10 - 60-65 in. 14 - 84-89 in.

Fourth and Fifth Numbers-Body Styles Pickup boxes, tailgate and drop glass, van bodies, and trim are options. 03 - Cab 05 - Van (windowless) 06 - S ub u rb an and V an (with windows) 14 - U tility 32 - M otor Home Chassis 42 - Forw ard Control Chassis 63 - F our-D oor Crew C ab

VEHICLE IDENTIFICATION NUMBER AND RATING PLATE A com bination vehicle identification n um ber and ratin g plate used on all models (fig. 1) is located on the left door p illar o f CK models. On Forw ard C ontrol models (except P30 M otor Home Chassis) it is attached to the dash and toe panel. The vehicle identification nu m b er stam ped on the plate decodes into the in fo rm a tio n shown in Figure 2.
