HH Audio Commercial Audio Catalogue 2026

CO MMME E DIO C OM RR C ICAILA L A UAU DIO 2002 2 2 65

1

Contents COMMERCIAL 2025 Looking for our other catalogues?

Scan or Click Here Professional

Portable

1

2

Aptur APT-C4 | 4-Inch Passive Ceiling Loudspeaker APT-C6 | 6.5-Inch Passive Ceiling Loudspeaker APT-C8 | 8-Inch Passive Ceiling Loudspeaker APT-C8S | 8-Inch Passive Ceiling Subwoofer APT-P6 | 6.5-Inch Passive Pendant Loudspeaker APT-CL63 | 6 x 2.75-Inch Passive Column Array Loudspeaker APT-CL103 | 10 x 2.75-Inch Passive Column Array Loudspeaker APT-W8S | 8-Inch Passive Surface Mount Subwoofer

4

4 5 6

CL16J | 4 x 4-Inch Passive Column Array Loudspeaker

H8 | 8-Inch Passive High-Performance Loudspeaker H10 | 10-Inch Passive High-Performance Loudspeaker H12 | 12-Inch Passive High-Performance Loudspeaker H15 | 15-Inch Passive High-Performance Loudspeaker

35 36 37 38

7 8 9 10

5

CL Series CL32J | 8 x 4-Inch Passive Column Array Loudspeaker CL32 | 8 x 4-Inch Passive Column Array Loudspeaker

3

3

Royal Series

13 14 15

Tessen Install TNi-C4 | 4-Inch Passive Ceiling Loudspeaker TNi-C6 | 6.5-Inch Passive Ceiling Loudspeaker TNi-C8 | 8-Inch Passive Ceiling Loudspeaker TNi-WX3 | 3.25-Inch Passive Wall Mount Loudspeaker TNi-WX5 | 5.75-Inch Passive Wall Mount Loudspeaker TNi-WX6 | 6.25-Inch Passive Wall Mount Loudspeaker TNi-W4 | 4-Inch Passive Wall Mount Loudspeaker TNi-W6 | 6-Inch Passive Wall Mount Loudspeaker TNi-W8 | 8-Inch Passive Wall Mount Loudspeaker

19 20

TNi-W8PRO | 8-Inch Passive Full-Range Loudspeaker TNi-W10PRO | 10-Inch Passive Full-Range Loudspeaker TNi-W12PRO | 12-Inch Passive Full-Range Loudspeaker TNi-W15PRO | 15-Inch Passive Full-Range Loudspeaker

29 30 31 32

Prince Series PS5 | 5-Inch Passive High-Performance Loudspeaker PS6 | 6-Inch Passive High-Performance Loudspeaker PS8 | 8-Inch Passive High-Performance Loudspeaker PS10 | 10-Inch Passive High-Performance Loudspeaker PS12 | 12-Inch Passive High-Performance Loudspeaker PS15 | 15-Inch Passive High-Performance Loudspeaker

6

SP Series

7

MZ-Series

SP26 | Digital Speaker Management System SP48 | Digital Speaker Management System

41 42 43 44 45 46

49 50

21 23 24 25 26 27 28

MZ-140DX | Multi-Zone Amplifier MZ-140D | Multi-Zone Amplifier MZ-140Q | Multi-Zone Amplifier MZ-280Q | Multi-Zone Amplifier MZ-64P | Multi-Zone Preamplifier MZ-C2 | Zone Wall Controller

53 54 55 56 57 58

Aptur Aptur: an elegant range of precisely engineered installation loudspeakers designed to integrate into any environment seamlessly.

APT-C - Timbre balanced 2-way ceiling-mounted loudspeakers available in three sizes (4-Inch, 6.5-Inch, and 8-Inch). APT-C ceiling speakers can be combined to provide uniform coverage and exceptionally detailed audio making them well-suited to a vast range of applications from hospitality settings to corporate environments.

APT-C8S - An 8-Inch ceiling-mounted subwoofer supporting other elements of the Aptur range by extending the low-end frequency response of the overall system, thus providing a rich, full-range sonic experience.

APT-P - An elegant 2-way 6.5-Inch pendant loudspeaker extending the potential applications of the Aptur range to environments with cavernous high ceilings bringing sound closer to the listener, or spaces without a cavity space beyond the ceiling to mount a traditional ceiling speaker.

APT-CL - Sleek column array loudspeakers designed with an emphasis on clarity and directivity, enabling intelligible audio to be distributed directly to listeners even in acoustically challenging spaces.

APT-W8S - Echoing the low-frequency acoustic benefits of the APT-C8S, this surface mountable 8-Inch subwoofer provides low-end frequency extension with its direct radiating design. The APT-W8S can be discretely installed in a multitude of environments. Working alongside other products in the range this slim profile subwoofer immerses listeners in a deep and rich soundscape.

Retail

1

Cafes

Restaurants

Museums

Conference Spaces

Houses of Worship

Lecture Halls

Public Transport Stations

Scan Here to view on the HH Audio Website

2

APT-C4

4-Inch Passive Ceiling Loudspeaker Key Featu res • • • • • • •

4-Inch coaxial Celestion driver designed for HH Aptur range Acoustic baffle/waveguide designed in collaboration with Celestion Lo-Z & 100v/70v operation via multi-tap transformer Reversible dog ear mounts for thicker ceilings Magnetic edge-to-edge grille with removable HH logo Powder coated steel back can with eyelet for safety tether Optional black grille available

Applications

System Type Driver

2-way Coaxial Ceiling Loudspeaker Celestion 4-Inch Coaxial Driver with 1.25-Inch LF VC and 0.75-Inch HF VC

Dispersion Main Construction Material

110° ABS/Steel

100v Power Options

24W, 12W, 6W

Finish

White ABS/Powdercoated Steel Back Can

70v Power Options

24W, 12W, 6W, 3W

Grille

White Fine Mesh Perforated Steel with Powdercoated Finish

Nominal System Impedance Power Rating Recommended Amplifier

8 Ohms

Mounting Mechanism

75W AES, 150W Continuous, 300W Peak

Minimum Tile Thickness

4 reversible dog-ear mounts, safety tether eyelet 3mm

MZ-140D, MZ-140Q, MZ-280Q

Maximium Tile Thickness

65mm

Sensitivity 1W/1m

87dB

Cutout Diameter

213mm

Maximum SPL (1m)

105dB SPL, 111dB SPL (Peak)

Outer Diameter

248mm

Frequency Response

90Hz-20kHz

Max Depth

180.5mm

Input / Link Connector

4-pin Euroblock +/- +/-

3

Optional Accessories

APT-TB4 - Tile bridge for APT-C4, APT-CG4-BK - Black Grille for APT-C4

APT-C6

6.5-Inch Passive Ceiling Loudspeaker Key Featu res • • • • • • •

6.5-Inch coaxial Celestion driver designed for HH Aptur range Acoustic baffle/waveguide designed in collaboration with Celestion Lo-Z & 100v/70v operation via muli-tap transformer Reversible dog ear mounts for thicker ceilings Magnetic edge-to-edge grille with removable HH logo Powder coated steel back can with eyelet for safety tether Optional black grille available

Applications

System Type Driver

2-way Coaxial Ceiling Loudspeaker Celestion 6.5-Inch Coaxial Driver with 1.5-Inch LF VC and 1-Inch HF VC

Dispersion Main Construction Material

120° ABS/Steel

100v Power Options

60W, 30W, 15W

Finish

White ABS/Powdercoated Steel Back Can

70v Power Options

60W, 30W, 15W, 7.5W

Grille

White Fine Mesh Perforated Steel with Powdercoated Finish

Nominal System Impedance Power Rating Recommended Amplifier

4 reversible dog-ear mounts, safety tether eyelet

8 Ohms

Mounting Mechanism

120W AES, 240W Continuous, 480W Peak

Minimum Tile Thickness

3mm

MZ-140D, MZ-140Q, MZ-280Q

Maximium Tile Thickness

65mm

Sensitivity 1W/1m

90dB

Cutout Diameter

273mm

Maximum SPL (1m)

110dB SPL, 116dB SPL (Peak)

Outer Diameter

308mm

Frequency Response

70Hz-20kHz

Max Depth

197.5mm

Input / Link Connector

4-pin Euroblock +/- +/-

Optional Accessories

APT-TB6 - Tile bridge for APT-C6, APT-CG6-BK - Black Grille for APT-C6 4

APT-C8

8-Inch Passive Ceiling Loudspeaker Key Featu res • • • • • •

8-Inch coaxial Celestion driver designed for HH Aptur range Lo-Z & 100v/70v operation via multi-tap transformer Reversible dog ear mounts for thicker ceilings Magnetic edge-to-edge grille with removable HH logo Powder coated steel back can with eyelet for safety tether Optional black grille available

Applications

System Type Driver

2-way Coaxial Ceiling Loudspeaker Celestion 8-Inch Coaxial Driver with 1.5-Inch LF VC and 1-Inch HF VC

Dispersion Main Construction Material

120° ABS/Steel

100v Power Options

60W, 30W, 15W

Finish

White ABS/Powdercoated Steel Back Can

70v Power Options

60W, 30W, 15W

Grille

White Fine Mesh Perforated Steel with Powdercoated Finish

Nominal System Impedance Power Rating Recommended Amplifier

8 Ohms

Mounting Mechanism

4 reversible dog-ear mounts, safety tether eyelet

120W AES, 240W Continuous, 480W Peak

Minimum Tile Thickness

3mm

MZ-140D, MZ-140Q, MZ-280Q

Maximium Tile Thickness

65mm 298mm 333mm

Sensitivity 1W/1m

92dB

Cutout Diameter

Maximum SPL (1m)

112 dB SPL, 118dB SPL (Peak)

Outer Diameter

Frequency Response

60Hz-20kHz

Input / Link Connector

4-pin Euroblock +/- +/-

5

Max Depth

Optional Accessories

207.5mm APT-TB8 - Tile bridge for APT-C8(S), APT-CG8-BK - Black Grille for APT-C8(S)

APT-C8S

8-Inch Passive Ceiling Subwoofer Key Featu res • • • • • •

8-Inch HH-Designed Low-Frequency Driver Integrated multi-tap transformer for Lo-Z & 100V/70V operation Powder coated steel backcan with integrated eyelet for safety tether Magnetic edge-to-edge grille with removable HH logo Optional black grille available

Applications

System Type Driver

Ceiling Mount Subwoofer

Main Construction Material

ABS/Steel

8-Inch HH-Designed Low-Frequency Driver

Finish

White ABS/Powdercoated Steel Back Can

100v Power Options

100W, 50W, 25W, 13W

Grille

White Fine Mesh Perforated Steel with Powdercoated Finish

70v Power Options

100W, 50W, 25W, 13W, 6W

Mounting Mechanism

8 Ohms

Minimum Tile Thickness

3mm

100W AES, 200W Continuous, 400W Peak

Maximium Tile Thickness

65mm

Nominal System Impedance Power Rating

4 reversible dog-ear mounts, safety tether eyelet

MZ-140D, MZ-140Q, MZ-280Q

Cutout Diameter

298mm

Sensitivity 1W/1m

89dB

Outer Diameter

333mm

Maximum SPL (1m)

109 dB SPL, 115dB SPL (Peak)

Max Depth

207.5mm

Recommended Amplifier

Frequency Response

40Hz-200Hz

Input / Link Connector

4-pin Euroblock +/- +/-

Optional Accessories

APT-TB8 - Tile bridge for APT-C8(S), APT-CG8-BK - Black Grille for APT-C8(S)

6

APT-P6

6.5-Inch Passive Pendant Loudspeaker Key Features • • • • • •

6.5-Inch coaxial Celestion driver designed for HH Aptur range Acoustic baffle/waveguide designed in collaboration with Celestion Lo-Z & 100v/70v operation via multi-tap transformer Magnetic edge-to-edge grille with removable HH logo Suspension kit included Available in Black and White

Applications

System Type Driver

2-way Coaxial Pendant Loudspeaker Celestion 6.5-Inch Coaxial Driver with 1.5-Inch LF VC and 1-Inch HF VC

100v Power Options

60W, 30W, 15W

70v Power Options

60W, 30W, 15W, 7.5W

Nominal System Impedance Power Rating Recommended Amplifier

8 Ohms 120W AES, 240W Continuous, 480W Peak MZ-140D, MZ-140Q, MZ-280Q

Sensitivity 1W/1m

90dB

Maximum SPL (1m)

110dB SPL, 116dB SPL (Peak)

Frequency Response

70Hz-20kHz

7

Input / Link Connector

4-pin Euroblock +/- +/-

Dispersion

120°

Main Construction Material

ABS

Finish

Black/White ABS

Grille

Black/White Fine Mesh Perforated Steel with Powdercoated Finish

Mounting Bracket Mounting Suspension Points Outer Diameter Max Depth

Optional wall mounting bracket Integrated eyelet for suspended mounting via carabiner 308mm 305mm

APT-CL63

6 x 2.75-Inch Passive Column Array Loudspeaker Key Features • • • • • •

6 x Celestion 2.75” Neodymium full-range drivers Sleek tapered design Powder coated aluminium cabinet Multi-tap transformer for LoZ & 100v/70v applications Simple installation via included pan/tilt bracket and low profile wall bracket Available in Black or White

Applications

System Type Driver 100v Power Options 70v Power Options Nominal System Impedance

Power Rating Recommended Amplifier

Sensitivity 1W/1m Maximum SPL (1m)

Full-Range Column Array Loudspeaker 6 x Celestion Full-Range Neodymium Drivers

Frequency Response

160Hz-20,000Hz

Input / Link Connector

4-pin Euroblock +/- +/-

100W, 50W, 25W, 13W 100W, 50W, 25W, 13W, 6W 8 Ohms 120W AES, 240W Continuous, 480W Peak

Dispersion Main Construction Material

MZ-140D, MZ-140Q, MZ-280Q 91dB 111dB SPL, 117dB SPL (Peak)

Finish Grille Mounting Bracket Mounting Points Unit Dimensions (HWD)

Horizontal - 120° | Vertical - 12° Aluminium, MDF with ABS End Cap Powdercoat (Black/White) Black/White White Fine Mesh Perforated Steel with Powdercoated Finish Pan/Tilt bracket 6 mounting points for included bracket 466mm x 100mm x 150mm 8

APT-CL103

10 x 2.75-Inch Passive Column Array Loudspeaker Key Featu res • • • • • •

10 x Celestion 2.75” Neodymium full-range drivers Sleek tapered design Powder coated aluminium cabinet Multi-tap transformer for LoZ & 100v/70v applications Simple installation via included pan/tilt bracket and low profile wall bracket Available in Black or White

Applications

System Type Driver 100v Power Options 70v Power Options Nominal System Impedance

Power Rating

Full-Range Column Array Loudspeaker

Frequency Response

160Hz-20,000Hz

10 x Celestion Full-Range Neodymium Drivers 100W, 50W, 25W, 13W 100W, 50W, 25W, 13W, 6W

Input / Link Connector Dispersion

Mounting Bracket

4-pin Euroblock +/- +/Horizontal - 120° | Vertical - 10° Aluminium, MDF with ABS End Cap Powdercoat (Black/White) Black/White White Fine Mesh Perforated Steel with Powdercoated Finish Pan/Tilt bracket

Mounting Points

6 mounting points for included bracket

16 Ohms 200W AES, 400W Continuous, 800W Peak

Recommended Amplifier

MZ-140D, MZ-140Q, MZ-280Q

Sensitivity 1W/1m

93dB 116dB SPL, 800W dB SPL (Peak)

Maximum SPL (1m) 9

Main Construction Material Finish Grille

Unit Dimensions (HWD)

758mm x 100mm x 150mm

APT-W8S

8-Inch Passive Surface Mount Subwoofer Key Features • • • • • •

8-Inch HH-Designed Low-Frequency Driver Integrated multi-tap transformer for Lo-Z &100V/70V operation Wall bracket included for simple installation in either portrait or horizontal orientation Slim profile to aid discrete integration Rubber feet for freestanding installation Available in Black or White

Applications

System Type Driver

Surface Mount Subwoofer 8-Inch HH-Designed Low-Frequency Driver

100v Power Options

100W, 50W, 25W, 13W

70v Power Options

100W, 50W, 25W, 13W, 6W

Nominal System Impedance Power Rating Recommended Amplifier

8 Ohms 100W AES, 200W Continuous, 400W Peak MZ-140D, MZ-140Q, MZ-280Q

Sensitivity 1W/1m

89dB

Maximum SPL (1m)

109 dB SPL, 115dB SPL (Peak)

Frequency Response

40Hz-200Hz

Input / Link Connector Main Construction Material

4-pin Euroblock +/- +/Plywood

Finish

Black/White Paint

Grille

Black/White Fine Mesh Perforated Steel with Powdercoated Finish

Mounting Bracket

Steel surface mount bracket included

Dimensions (HWD)

With Feet - 327mm x 520mm x 175mm Without Feet - 320mm x 520mm x 168mm

Wall Clearance with Bracket

10mm

10

CL Series The CL Series passive column array speakers place cutting-edge acoustic technology in a sleek and unobtrusive enclosure. Designed to provide a high degree of pattern control in acoustically challenging environments, the CL series delivers precise and consistent sound throughout some of the most problematic spaces where hard reverberant surfaces and cavernous architecture can impact the clarity of the sound being heard. This makes the CL Series perfect for houses of worship and large auditoriums where speech intelligibility is paramount.

The CL Series speakers are available in multiple configurations of high-quality 4-Inch mid-frequency and 3/4-Inch high-frequency drivers. The CL16J (4 x 4-Inch) and CL32J (8 x 4-Inch) both use asymmetrical projection to reduce the requirement for tilting the speaker on installation and optimise the coverage angle when installed at a static height. The CL32 (8 x 4-Inch) can be combined with either the CL32J or CL16J when a larger column system is required. CL Series column array speakers are all housed in a robust plywood enclosure and finished with scratch/wear-resistant paint.

Houses of Worship

11

Museums

Public Transport Stations

Conference Spaces

Lecture Halls

Live Sound Reinforcement

Scan Here to view on the HH Audio Website

12

CL16J

4 x 4-Inch Passive Column Array Loudspeaker Key Featu res • • • • • • •

4 x 4-Inch mid-frequency drivers, 12 x 0.75-Inch high-frequency drivers 127dB Max SPL (Peak) Frequency Response of 80Hz - 20kHz (±3dB) 100° (H) x 40° (V) dispersion angle Asymmetric vertical projection Robust wooden enclosure with a wear-resistant finish Available in Black or White

Applications

Frequency Response

80Hz - 20kHz (±3dB) 60Hz - 25kHz (-10dB)

Finish

Scratch-resistant and wear-resistant paint finish (White or Black option)

Coverage Angle

Horizontal 100° (-6dB) Vertical 40° (-6dB)

Grille

Hexagonal mesh perforated steel with acoustic foam backing

Power Rating

200W RMS, 400W Program, 800W Peak

Fittings

Connection parts, threaded pole-mount socket, mounting points

Max SPL

121dB Continuous, 127dB Peak

Sensitivity

98dB

Nominal Impedance MF Driver

8Ω 4 x 4-Inch mid-frequency drivers

HF Driver

12 x 0.75-Inch high-frequency drivers

Cabinet

Plywood

13

Mounting Bracket Connectors

2 x M8 mounting points for standard CL16J-FLB Removable locking connector with screw terminals.

Pin Connectors

+/-

Unit Dimensions

475 x 140 x 185mm

Unit weight

7.3kg

CL32J

8 x 4-Inch Passive Column Array Loudspeaker Key Featu res • • • • • •

8 x 4-Inch mid-frequency drivers, 24 x 0.75-Inch high-frequency drivers 130dB Max SPL (Peak) Frequency Response of 70Hz - 20kHz(±3dB) 100° (H) x 35° (V) dispersion angle Asymmetric vertical projection Robust wooden enclosure with a wear-resistant finish

Applications

Frequency Response

70Hz - 20kHz (±3dB) 53Hz - 23kHz (-10dB)

Finish

Scratch-resistant and wear-resistant paint finish (White or Black option)

Coverage Angle

Horizontal 100° (-6dB) Vertical 35° (-6dB), +10°/-25° (-7.5° offset)

Grille

Hexagonal mesh perforated steel with acoustic foam backing

Power Rating

400W RMS, 800W Program, 1600W Peak

Fittings

Connection parts, threaded pole-mount socket, mounting points

Max SPL Sensitivity Nominal Impedance

127dB Continuous, 130dB Peak 101dB 4Ω

MF Driver

8 x 4-Inch mid-frequency driver

HF Driver

24 x 0.75-Inch high-frequency driver

Cabinet

Plywood

Mounting Bracket Connectors

2 x M8 mounting points for standard CL32J-FLB Removable locking connector with screw terminals.

Pin Connectors

+/-

Unit Dimensions

903 x 140 x 185mm

Unit weight

13.5kg 14

CL32

8 x 4-Inch Passive Column Array Loudspeaker Key Features • • • • •

8 x 4-Inch mid-frequency drivers, 24 x 0.75-Inch highfrequency drivers 130dB Max SPL (Peak) Frequency Response of 70Hz - 20kHz(±3dB) 100° (H) x 35° (V) dispersion angle Robust wooden enclosure with a wear-resistant finish

Applications

Frequency Response

70Hz - 20kHz (±3dB) 53Hz - 23kHz (-10dB)

Finish

Scratch-resistant and wear-resistant paint finish (White or Black)

Coverage Angle

Horizontal 100° (-6dB) Vertical 35° (-6dB)

Grille

Hexagonal mesh perforated steel with acoustic foam backing

Power Rating

400W RMS, 800W Program, 1600W Peak

Fittings

Connection parts, threaded pole-mount socket, mounting points

Max SPL

127dB Continuous, 130dB Peak

Sensitivity

101dB

Mounting Bracket Connectors

2 x M8 mounting points for standard CL32-FLB Removable locking connector with screw terminals.

4Ω

Pin Connectors

+/-

MF Driver

8 x 4-Inch mid-frequency driver

Unit Dimensions

878 x 140 x 185mm

HF Driver

24 x 0.75-Inch high-frequency driver

Cabinet

Plywood

Nominal Impedance

15

Unit weight

14.1kg

Model

CL16J

CL32J

CL32

Frequency Response

80Hz - 20kHz (±3dB) 60Hz - 25kHz (-10dB)

70Hz - 20kHz (±3dB) 53Hz - 23kHz (-10dB)

70Hz - 20kHz (±3dB) 53Hz - 23kHz (-10dB)

Coverage Angle

Horizontal 100° (-6dB) Vertical 40° (-6dB)

Horizontal 100° (-6dB) Vertical 35° (-6dB), +10°/-25° (-7.5° offset)

Horizontal 100° (-6dB) Vertical 35° (-6dB)

Power Rating

200W RMS, 400W Program, 800W Peak

400W RMS, 800W Program, 1600W Peak

400W RMS, 800W Program, 1600W Peak

Max SPL

121dB Continuous, 127dB Peak

127dB Continuous, 130dB Peak

127dB Continuous, 130dB Peak

Sensitivity

98dB

101dB

101dB

Nominal Impedance

8Ω

4Ω

4Ω

MF Driver

4 x 4-Inch mid-frequency drivers

8 x 4-Inch mid-frequency drivers

8 x 4-Inch mid-frequency drivers

HF Driver

12 x 0.75-Inch high-frequency drivers

24 x 0.75-Inch high-frequency drivers

24 x 0.75-Inch high-frequency drivers

Cabinet

Plywood

Plywood

Plywood

Finish

Scratch-resistant and wear-resistant paint finish (White or Black option)

Scratch-resistant and wear-resistant paint finish (White or Black option)

Scratch-resistant and wear-resistant paint finish (White or Black option)

Grille

Hexagonal mesh perforated steel with acoustic foam backing

Hexagonal mesh perforated steel with acoustic foam backing

Hexagonal mesh perforated steel with acoustic foam backing

Fittings

Connection parts, threaded polemount socket, mounting points

Connection parts, threaded polemount socket, mounting points

Connection parts, threaded polemount socket, mounting points

Mounting Bracket

2 x M8 mounting points for standard CL16J-FLB

2 x M8 mounting points for standard CL32J-FLB

2 x M8 mounting points for standard CL32J-FLB

Connectors

Removable locking connector with screw terminals.

Removable locking connector with screw terminals.

Removable locking connector with screw terminals.

Pin Connectors

+/-

+/-

+/-

Unit Dimensions

475 x 140 x 185mm

903 x 140 x 185mm

878 x 140 x 185mm

4.9kg (10.8lbs)

13.5kg (29.8lbs)

14.1kg (31lbs)

Unit weight

16

Tessen Install The Tessen Install range houses three sub-ranges that cater to a wide array of applications, with models to suit different power requirements and aesthetics. The Tessen install range is divided into the following categories: TNi-C: Ceiling-mounted loudspeakers that provide reliable performance paired with quick and easy installation. These models are available in 4-Inch, 6.5-Inch, and 8-Inch variants, offering flexibility for a range of applications such as retail stores, hospitality venues, and educational environments.

TNi-W: A range of wall-mounted loudspeakers offering reliable performance and simple installation for hospitality venues, retail stores, educational environments, and corporate spaces. Each TNi-W model is available in black and white, features adjustable power settings, the ability to connect to 70/100V or 8 Ohm lines, and includes a TNi-BRK1 bracket, which allows the installer to switch between horizontal and vertical mounting.

TNi-WX: Designed for demanding conditions, this IP65-rated surface mount range features UV-resistant ABS cabinets and weatherproof aluminium grilles. Available in three sizes and two colours, these units include internal line transformers for 70/100V or Lo-Z operation and come complete with a pan & tilt wall bracket for secure installation in outdoor or highmoisture environments.

TNi-WPRO: Built for more demanding applications where a higher SPL is needed, the TNi-WPRO loudspeakers are available in four sizes: 8-Inch, 10-Inch, 12-Inch, and 15-Inch. Each model features a HH-designed low-frequency driver paired with a Celestion high-frequency compression driver. The custom-designed rotatable waveguide makes the TNi-WPRO series even more versatile, allowing for vertical or horizontal orientation with a 90° x 60° dispersion angle. All models are housed in a robust wooden enclosure and are available in both black and white hard-wearing finishes. The TNi-WPRO is suitable for a wide array of applications, including bars, clubs, live sound reinforcement, restaurants, corporate spaces, houses of worship, leisure centres, and retail spaces.

Cafes

17

Bars

Restaurants

Retail

Museums

Wedding Venues

Educational Spaces

Conference Spaces

Live Sound Reinforcement

Scan Here to view on the HH Audio Website

18

TNi-C4

4-Inch Passive Ceiling Loudspeaker Key Features

• • • • • • •

4-Inch HH-designed coaxial LF driver & 1.5-Inch neodymium HF driver 100V power options: 30W, 15W, 6W 70V power options: 15W, 7.5W, 3W Low Impedance Power Rating 180W Peak, 45W AES Max SPL 111 dB Frequency response 85Hz – 20KHz 130° conical dispersion angle

Applications

LF Driver

4-Inch HH-designed coaxial LF driver

Input Connector

Push Spring Connectors

HF Driver

1.5-Inch Neodymium HF driver

Nominal Coverage

130° Conical

Max SPL

111 dB SPL

Outside Diameter

204mm, 8-Inch

Sensitivity 1W/1m2

88 dB SPL

Depth

156mm, 6.1-Inch

Low Impedance

8Ω

Cutout

180mm, 7.1-Inch

System Power Rating

45W AES, 180W Peak

Grip Range

Recommended Amplifier

80-160W @ 8 Ohms

Main Construction Material

ABS Plastic

Frequency Response

85Hz - 20kHz (-10dB) 100Hz - 16kHz (-3dB)

Mounting Points

3x Dog Ear Brackets

Transformer Power Taps

100V - 30W, 15W, 6W 70V - 15W, 7.5W, 3W

19

Unit weight

4-20mm

1.4kg, 3.1lbs

TNi-C6

6.5-Inch Passive Ceiling Loudspeaker Key Featu res • • • • • • •

6.5-Inch HH-designed coaxial LF driver with 1.5-Inch neodymium HF driver 100V power options: 40W, 20W, 10W 70V power options: 20W, 10W, 5W Low Impedance Power Rating 220W Peak, 55W AES Max SPL 113 dB Frequency response 75Hz – 20KHz 120° conical dispersion angle

Applications

LF Driver

6.5-Inch HH-designed coaxial LF driver

Input Connector

Push Spring Connectors

HF Driver

1.5-Inch Neodymium HF driver

Nominal Coverage

120° Conical

Max SPL

113 dB SPL

Outside Diameter

Sensitivity 1W/1m2

Depth

Low Impedance

90 dB SPL 8Ω

System Power Rating

55W AES, 220W Peak

Grip Range

Recommended Amplifier

100-200W @ 8 Ohms

Main Construction Material

ABS Plastic

Frequency Response

75Hz - 20kHz (-10dB) 85Hz - 16kHz (-3dB)

Mounting Points

4x Dog Ear Brackets

Transformer Power Taps

100V - 40W, 20W, 10W 70V - 20W, 10W, W5

Unit weight

Cutout

260mm, 10.2-Inch 176mm, 6.9-Inch-Inch 235mm, 9.3-Inch-Inch 4-20mm

2.1kg, 4.6 lbs

20

TNi-C8

8-Inch Passive Ceiling Loudspeaker Key Featu res

• • • • • • •

8-Inch HH-designed coaxial LF driver & 1.5-Inch neodymium HF driver 100V power options: 40W, 20W, 10W 70V power options: 20W, 10W, 5W Low Impedance Power Rating 260W Peak, 65W AES Max SPL 115 dB Frequency response 65Hz – 20KHz 100° conical dispersion angle

Applications

Input Connector

Push Spring Connectors

HF Driver

8-Inch HH-designed coaxial LF driver 1.5-Inch Neodymium HF driver

Nominal Coverage

100° Conical

Max SPL

115 dB SPL

Outside Diameter

300mm, 8-Inch

Sensitivity 1W/1m2

91 dB SPL

Depth

195mm, 6.1-Inch

Low Impedance

8Ω

System Power Rating Recommended Amplifier

Cutout

275mm, 7.1-Inch

65W AES, 260W Peak

Frequency Response

65Hz - 20kHz (-10dB) 80Hz - 16kHz (-3dB)

Transformer Power Taps

100V - 40W, 20W, 10W 70V - 20W, 10W, 5W

LF Driver

21

100-200W @ 8 Ohms

Grip Range

4-20mm

Main Construction Material

ABS Plastic

Mounting Points

4x Dog Ear Brackets

Unit weight

2.6kg, 5.7lbs

NEW FOR 2026

TNI-WX INDOOR AND OUTDOOR SURFACE MOUNT LOUDSPEAKER

IP65 22

TNi-WX3

3.5-Inch Passive Wall Mount Loudspeaker Key Featu res • • • • • •

6.5-inch low-frequency driver. 1-inch high-frequency driver Power handling: 60W RMS Sensitivity (1W/1m): 89dB IP65 weather-resistant design Compact lightweight design for simple and discreet installation Accessories: Cable gland panel, pan & tilt wall bracket

Applications

LF Driver

6.5-Inch LF driver

Frequency Response

90Hz - 20kHz (-10dB)

HF Driver

0.5-Inch HF driver

Input/Link Connector

4-Pin Euroblock

Power Options

100V - 7.5W, 5W, 3.75W, 2.5W 70V - 15W, 10W, 7.5W, 5W

Nominal System Impedance

8 Ohm

Power Rating

30W RMS, 120W Peak

Recommended Amplifier

MZ-140DX, MZ-140D, MZ-140Q or equivalent 70W – 140W @ 8 ohms amplifier

Sensitivity 1W/1m2

83 dB SPL

Max SPL 1m3

23

97dB, 103dB (Peak)

Dispersion Angle IP Rating Mounting Bracket Rear Panel Main Construction Material Unit Weight Unit Dimensions

Horizontal - 120° | Vertical - 70° IP65 Pan/Tilt wall bracket included Cable gland panel for outdoor use ABS Plastic 1.7Kg, 3.7 lbs 191 x 120 x 125mm, 7.5" x 4.7" x 4.9"

TNi-WX5

5.25-Inch Passive Wall Mount Loudspeaker Key Featu res • • • • • • •

5.25-inch low-frequency driver 0.75-inch high-frequency driver Power handling: 50W RMS Sensitivity (1W/1m): 87 dB IP65 weather-resistant design Compact lightweight design for simple and discreet installation Accessories: Cable gland panel, pan & tilt wall bracket

Applications

LF Driver

5.25-Inch LF driver

Frequency Response

75Hz - 20kHZ

HF Driver

0.75-Inch HF driver

Input/Link Connector

4-Pin Euroblock

Power Options

100V - 7.5W, 5W, 3.75W, 2.5W 70V - 15W, 10W, 7.5W, 5W

Nominal System Impedance

8 Ohm

Power Rating

50W RMS

Recommended Amplifier

MZ-140DX, MZ-140D, MZ-140Q or equivalent 70W – 140W @ 8 ohms amplifier

Sensitivity 1W/1m2

87 dB SPL

Max SPL 1m

3

103dB

Dispersion Angle IP Rating Mounting Bracket Rear Panel Main Construction Material Unit Weight Unit Dimensions

Horizontal - 120° | Vertical - 100° IP65 Pan/Tilt wall bracket included Cable gland panel for outdoor use ABS Plastic 2.4Kg, (5.3 lbs) 256 x 166 x 163mm, (10.1" x 6.5" x 6.4") 24

TNi-WX6

6.5-Inch Passive Wall Mount Loudspeaker Key Featu res • • • • • • •

6.5-inch low-frequency driver 1-inch high-frequency driver Power handling: 50W RMS Sensitivity (1W/1m): 87 dB IP65 weather-resistant design Compact lightweight design for simple and discreet installation Accessories: Cable gland panel, pan & tilt wall bracket

Applications

LF Driver

6.5-Inch LF driver

Frequency Response

60Hz - 20kHZ

HF Driver

1-Inch HF driver

Input/Link Connecter

4-Pin Euroblock

Power Options

100V - 30W, 15W 7.5W, 3.75W 70V - 60W, 30W, 15W, 7.5W

Nominal System Impedance

8 Ohm

Power Rating

60W RMS

Recommended Amplifier Sensitivity 1W/1m2 Max SPL 1m

3

25

Dispersion Angle IP Rating Mounting Bracket Rear Panel Main Construction Material

106 dB SPL 106dB

Unit Weight Unit Dimensions

Horizontal - 120° | Vertical - 140° IP65 Pan/Tilt wall bracket included Cable gland panel for outdoor use ABS Plastic 3.85Kg, (8.5 lbs) 329 x 210 x 206mm, (13" x 8.3" x 8.1")

TNi-W4

4-Inch Passive Wall Mount Loudspeaker Key Featu res • • • • • • • • •

HH-designed 4-Inch LF driver & 1-Inch dome HF driver 100V power options 30W, 15W, 6W, 3W 70V power options 15W, 7.5W, 3W, 1.5W Low Impedance Power Rating 180W Peak, 45W AES Max SPL 110 dB Frequency response 80Hz – 20KHz 90° x 80° dispersion angle Adjustable steel wall bracket included Available in white and black

Applications

LF Driver

4-Inch HH-Designed LF driver

HF Driver

1-Inch Dome HF driver

Frequency Response

Power Options

100V - 30W, 15W, 6W, 3W 70V - 15W, 7.5W, 3W, 1.5W

Input/Link Connecter

Nominal System Impedance

8 Ohm

Power Rating

45W AES, 13OW Peak

Recommended Amplifier

80-160W @ 8 Ohm

Sensitivity 1W/1m2

88 dB SPL

Max SPL 1m3

111 dB SPL 80Hz - 20kHz (-10dB) 125Hz - 18kHz (- 3dB) Euroblock & M4 Terminals

Dispersion Angle

Horizontal - 90° | Vertical - 80°

Main Construction Material

ABS Plastic

Mounting Bracket

Adjustable Steel Bracket Included

Unit Weight Unit Dimensions

2.8kg, 6.2 lbs 295 x 145 x 222mm, 11.6-Inch x 5.7-Inch x 8.7-Inch

26

TNi-W6

6-Inch Passive Wall Mount Loudspeaker Key Features

• • • • • • • • •

HH designed 6.5-Inch LF driver & 1-Inch dome HF driver 100V power options: 40W, 20W, 10W, 5W 70V power options: 20W, 10W, 5W, 2.5W Low Impedance Power Rating 220W Peak, 55W AES Max SPL 113 dB Frequency response 65Hz – 20KHz 90° x 80° dispersion angle Adjustable steel wall bracket included Available in white and black

Applications

6.5-Inch HH-designed LF driver

LF Driver

Max SPL 1m3

113 dB SPL

HF Driver

1-Inch Dome HF driver

Frequency Response

Power Options

100V - 40W, 20W, 10W, 5W 70V - 20W, 10W, 5W, 2.5W

65Hz - 20kHz (-10dB) 80Hz - 18kHz (- 3dB)

Input/Link Connecter

Euroblock & M4 Terminals

Nominal System Impedance

8 Ohm

Power Rating

55W AES, 220W Peak

Recommended Amplifier

100-200W @ 8 Ohm

Sensitivity 1W/1m

2

27

90 dB SPL

Dispersion Angle

Horizontal - 90° | Vertical - 80°

Main Construction Material

ABS Plastic

Mounting Bracket

Adjustable Steel Bracket Included

Unit Weight Unit Dimensions

3.5kg, 7.7 lbs 330 x 196 x 281mm, 13-Inch x 7.7-Inch x 11.1-Inch

TNi-W8 8-Inch Passive Wall Mount Loudspeaker Key Featu res • • • • • • • • •

HH-Designed 8-Inch LF driver & 1-Inch HF driver 100V power options: 40W, 20W, 10W, 5W 70V power options: 20W, 10W, 5W, 2.5W Low Impedance Power Rating 260W Peak, 65W AES Max SPL 114 dB Frequency response 55Hz – 20KHz 90° x 80° dispersion angle Adjustable steel wall bracket included Available in white and black

Applications

LF Driver

8-Inch HH-designed LF driver

Max SPL 1m3

115 dB SPL

1-Inch Dome HF driver

Frequency Response

55Hz - 20kHz (-10dB) 75Hz - 18kHz (- 3dB)

Power Options

100V - 40W, 20W, 10W, 5W 70V - 20W, 10W, 5W, 2.5W

Input/Link Connecter

Euroblock & M4 Terminals

Nominal System Impedance

8 Ohm

Power Rating

65W AES, 260W Peak

Recommended Amplifier

100-200W @ 8 Ohm

Sensitivity 1W/1m2

91 dB SPL

HF Driver

Dispersion Angle

Horizontal - 90° | Vertical - 80°

Main Construction Material

ABS Plastic

Mounting Bracket

Adjustable Steel Bracket Included

Unit Weight Unit Dimensions

4.2Kg, 9.3 lbs 390 x 240 x 319mm, 15.4-Inch x 9.4-Inch x 12.6-Inch 28

TNi-W8PRO

8-Inch Full-Range Passive Loudspeaker Key Features • • • • • • • • • •

8-Inch HH-designed high performance LF driver 1-Inch Celestion CDX1-1070 HF driver Custom designed rotatable waveguide for vertical or horizontal orientation 90° x 60° Dispersion angle Frequency response: 62 Hz – 20 kHz (-10 dB) 124 dB Max SPL (Peak) Robust wooden enclosure Hard-wearing spatter finish Rotatable logo Available in white and black

Applications

LF Driver

8-Inch HH Designed High Performance LF Driver, 2.0-Inch Voice Coil

HF Driver

1.0-Inch Celestion CDX1-1070

Nominal System Impedance

8 Ohm

Power Rating

200W AES, 400W Continuous, 800W Peak

Recommended Amplifier

HH M-Series M-750D or equivalent with 400-800W @ 8 Ohms

Sensitivity

93 dB SPL

Max SPL 1m2

116 dB SPL, 122 dB SPL (Peak)

Frequency Response

62 - 20kHz (-10dB) 72 - 18kHz (-3dB)

29

Input/Link Connector Dispersion Angle Crossover Frequency

Euroblock Connector and M4 Barrier Strip Terminal (7.62mm Pitch) Horizontal - 90° | Vertical - 60° 2.2KHz

Main Construction Material

Robust all wood construction (15mm plywood)

Mounting Bracket

4x M8 mounting points for optional TNi-BRK30

Mounting Suspension Points

7x M10 Penn-Elcom fly points (3 on top face, 2 on side face, 1 on rear, 1 on bottom

Unit Dimensions

474 x 270 x 257mm, 18.7-Inch x 10.6-Inch x 10.1-Inch

Unit weight

9.9Kg, 21.8 lbs

TNi-W10PRO

10-Inch Full-Range Passive Loudspeaker Key Features

• • • • • • • • • •

10-Inch HH-designed high performance LF driver 1.4-Inch Celestion CDX1-1445 HF driver Custom designed rotatable waveguide for vertical or horizontal orientation 90° x 60° Dispersion angle Frequency response: 56 Hz – 20 kHz (-10 dB) 126 dB Max SPL (Peak) Robust wooden enclosure Hard-wearing spatter finish Rotatable logo Available in white and black

Applications

LF Driver

10-Inch HH Designed High Performance LF Driver, 2.0Inch Voice Coil

HF Driver

1.4-Inch Celestion CDX1-1445

Nominal System Impedance

8 Ohm

Power Rating

250W AES, 500W Continuous, 1000W Peak

Recommended Amplifier

HH M-Series M-750D or M-1500D or equivalent with 500-1000W @ 8 Ohms

Input/Link Connector Dispersion Angle Crossover Frequency Main Construction Material

Euroblock Connector and M4 Barrier Strip Terminal (7.62mm Pitch) Horizontal - 90° | Vertical - 60° 2.2KHz Robust all wood construction (15mm plywood)

Mounting Bracket

4x M8 mounting points for optional TNi-BRK30

95 dB SPL

Mounting Suspension Points

7x M10 Penn-Elcom fly points (3 on top face, 2 on side face, 1 on rear, 1 on bottom

Max SPL 1m

119 dB SPL, 125 dB SPL (Peak)

Unit Dimensions

524 x 308 x 297mm, 20.6-Inch x 12.1-Inch x 11.7-Inch

Frequency Response

56 - 20kHz (-10dB) 66 - 18kHz (-3dB)

Sensitivity 2

Unit weight

13.2Kg, 29.1 lbs 30

TNi-W12PRO

12-Inch Full-Range Passive Loudspeaker Key Features

• • • • • • • • •

12-Inch HH-designed high performance LF driver, 1.4-Inch Celestion CDX1-1445 HF driver Custom designed rotatable waveguide for vertical or horizontal orientation 90° x 60° Dispersion angle Frequency response: 50 Hz -20 kHz (-10 dB) 128 dB Max SPL (Peak) Robust wooden enclosure Hard-wearing spatter finish Rotatable logo Available in white and black

Applications

LF Driver HF Driver

12-Inch HH-Designed High Performance LF Driver, 2.5-Inch Voice Coil 1.4-Inch Celestion CDX1-1445

Nominal System Impedance

8 Ohm

Power Rating

300W AES, 600W Continuous, 1200W Peak

Recommended Amplifier

HH M-Series M-750D or M-1500D or equivalent with 600-1200W @ 8 Ohms

Sensitivity

97 dB SPL

Max SPL 1m2

122 dB SPL, 128 dB SPL (Peak)

Frequency Response

50 - 20kHz (-10dB) 60 - 18kHz (-3dB)

31

Input/Link Connector Dispersion Angle Crossover Frequency

Euroblock Connector and M4 Barrier Strip Terminal (7.62mm Pitch) Horizontal - 90° | Vertical - 60° 2.2KHz

Main Construction Material

Robust all wood construction (15mm plywood)

Mounting Bracket

4x M8 mounting points for optional TNi-BRK30

Mounting Suspension Points

7x M10 Penn-Elcom fly points (3 on top face, 2 on side face, 1 on rear, 1 on bottom

Unit Dimensions

575 x 345 x 337mm, 22.6-Inch x 13.6-Inch x 13.3-Inch

Unit weight

16.2kg, 35.7 lbs

TNi-W15PRO

15-Inch Full-Range Passive Loudspeaker Key Featu res • • • • • • • • •

15-Inch HH-designed high performance LF driver, 1.75-Inch Celestion CDX1-1742 HF driver Custom designed rotatable waveguide for vertical or horizontal orientation 90° x 60° Dispersion angle Frequency Response: 41 Hz – 20 kHz (-10 dB) 131 dB Max SPL (Peak) Robust wooden enclosure Hard-wearing spatter finish Rotatable logo Available in white and black

Applications

LF Driver

15-Inch HH Designed High Performance LF Driver, 3.0-Inch Voice Coil

HF Driver

1.75-Inch Celestion CDX1-1742

Nominal System Impedance

8 Ohm

Power Rating

450W AES, 900W Continuous, 1800W Peak

Recommended Amplifier

HH M-Series M1500D or equivalent with 6001200W @ 8 Ohms

Sensitivity

98 dB SPL

Max SPL 1m2

125 dB SPL, 131 dB SPL (Peak)

Frequency Response

41 - 20kHz (-10dB) 51 - 18kHz (-3dB)

Input/Link Connector Dispersion Angle Crossover Frequency

Euroblock Connector and M4 Barrier Strip Terminal (7.62mm Pitch) Horizontal - 90° | Vertical - 60° 2.0KHz

Main Construction Material

Robust all wood construction (15mm plywood)

Mounting Bracket

4x M8 mounting points for optional TNi-BRK30

Mounting Suspension Points

7x M10 Penn-Elcom fly points (3 on top face, 2 on side face, 1 on rear, 1 on bottom

Unit Dimensions

665 x 430 x 400mm, 26.2-Inch x 16.9-Inch x 15.7-Inch

Unit weight

22.4Kg, 49.4 lbs 32

Royal Series Royal Series represents the pinnacle of audio engineering and performance from HH Audio. A range of products finely crafted to offer reliable and scalable live sound systems for the most demanding applications. This extensive series includes line array systems, subwoofer enclosures, and point source loudspeakers, designed to cater to a wide array of professional audio applications.

For this commercial catalogue, we are spotlighting the point source loudspeakers for their versatility beyond live sound. Featuring advanced carbon fiber and Kevlar components, Royal Series point source loudspeakers achieve exceptional transient response and distortion-free audio, even under high-power conditions. With flexible mounting options, rotatable horns, and robust enclosures, finished in durable black polyurea, Royal is built to excel.

Houses of Worship

33

Conference Spaces

Lecture Halls

Live Sound Reinforcement

Restaurants

Cafés

Clubs

Scan Here to view on the HH Audio Website

34

H8

8-In ch Point Source Loudspeaker Key Features •

1 x 8-Inch low-frequency driver, 1 x 1.4-Inch highfrequency compression driver

•

128dB Max SPL (Peak)

•

Rotatable horn with 90° (H) x 70° (V) coverage angles

•

Frequency Response of 60Hz - 18Hz (±3dB)

•

Robust wooden enclosure finished with black polyurea paint

Applications

Frequency Response

60Hz - 18kHz (±3dB) 50Hz - 20kHz (-10dB)

Coverage Angle

Horizontal 90° Vertical 70°

Power Rating

300W Continuous, 1200W Peak

Max SPL Nominal Impedance

122dB Continuous, 128dB Peak 97dB (1W@1m) 8Ω

LF Driver

1 x 8-Inch low-frequency driver

HF Driver

1 x 1.4-Inch high-frequency compression driver

Cabinet

Plywood

Sensitivity

35

Finish

Hard-wearing black polyurea paint

Grille

Hexagonal mesh black perforated steel with acoustic foam backing

Fittings Mounting Points Connectors Pin Connectors Unit Dimensions Unit weight

Pole-mount socket, M8 mounting points.

10 x M8 (2 on top, 4 on sides, 2 on rear, 2 on base).

2 x Speakon NL4 Input +/Link 1+/- and 2+/460 x 265 x 250mm 12kg

H10

10-Inch Point Source Loudspeaker Key Features •

1 x 10-Inch low-frequency driver, 1 x 1.4-Inch highfrequency compression driver

•

130dB Max SPL (Peak)

•

Rotatable horn with 90° (H) x 70° (V) coverage angles

•

Frequency Response of 58Hz - 18Hz (±3dB)

•

Robust wooden enclosure finished with black polyurea paint

Applications

Frequency Response

58Hz - 18kHz (±3dB) 48Hz - 20kHz (-10dB)

Coverage Angle

Horizontal 90° Vertical 70°

Power Rating

400W Continuous, 1600W Peak

Max SPL

124dB Continuous, 130dB Peak

Sensitivity

98dB (1W@1m) 8Ω

Nominal Impedance LF Driver

1 x 10-Inch low-frequency driver

HF Driver

1 x 1.4-Inch high-frequency compression driver

Cabinet

Plywood

Finish

Hard-wearing black polyurea paint

Grille

Hexagonal mesh black perforated steel with acoustic foam backing

Fittings

1 x Top handle, dual pole-mount sockets (0° and -10°), M8 mounting points.

Mounting Points Connectors Pin Connectors Unit Dimensions Unit weight

16 x M8 (3 on top, 8 on sides, 2 on rear, 3 on base) 2 x Speakon NL4 Input +/Link 1+/- and 2+/530 x 330 x 300mm 15kg 36

H12

12-In ch Point Source Loud speaker Key Features

•

1 x 12-Inch low-frequency driver, 1 x 3-Inch high-frequency compression driver

•

132dB Max SPL (Peak)

•

Rotatable horn with 90° (H) x 60° (V) coverage angles

•

Frequency Response of 42Hz - 18Hz (±3dB)

•

Robust wooden enclosure finished with black polyurea paint

Applications

Frequency Response

42Hz - 18kHz (±3dB) 31Hz - 20kHz (-10dB)

Finish

Hard-wearing black polyurea paint

Grille

Hexagonal mesh black perforated steel with acoustic foam backing 2 x Side handles, dual pole-mount socket (0° and -10°), M8 mounting points

Coverage Angle

Horizontal 90° Vertical 60°

Power Rating

500W Continuous, 2000W Peak

Fittings

Max SPL

126dB Continuous, 132dB Peak 99dB (1W@1m) 8Ω

Mounting Points Connectors

LF Driver

1 x 12-Inch low-frequency driver

Unit Dimensions

HF Driver

1 x 3-Inch high-frequency compression driver

Cabinet

Plywood

Sensitivity Nominal Impedance

37

Pin Connectors

Unit weight

12 x M8 (3 on top, 4 on sides, 2 on rear, 3 on base) 2 x Speakon NL4 Input +/Link 1+/- and 2+/670 x 405 x 385mm 23kg

H15 15-In ch Point Source Loudspeaker Key Features •

1 x 15-Inch low-frequency driver, 1 x 3-Inch high-frequency compression driver

•

133dB Max SPL (Peak)

•

Rotatable horn with 90° (H) x 60° (V) coverage angles

•

Frequency Response of 40Hz - 18Hz (±3dB)

•

Robust wooden enclosure finished with black polyurea paint

Applications

Frequency Response

40Hz - 18kHz (±3dB) 28Hz - 20kHz (-10dB)

Finish

Hard-wearing black polyurea paint

Coverage Angle

Horizontal 90° Vertical 60°

Grille

Hexagonal mesh black perforated steel with acoustic foam backing

Power Rating

650W Continuous, 2600W Peak

Fittings

2 x Side handles, dual pole-mount socket (0° and -10°), mounting points

Max SPL Sensitivity

129dB Continuous, 133dB Peak 101dB (1W@1m) 8Ω

Mounting Points

Nominal Impedance LF Driver

1 x 15-Inch low-frequency driver

HF Driver

1 x 3-Inch high-frequency compression driver

Cabinet

Plywood

Connectors Pin Connectors Unit Dimensions Unit weight

12 x M8 (3 on top, 4 on sides, 2 on rear, 3 on base).

2 x Speakon NL4 Input +/Link 1+/- and 2+/720 x 440 x 400mm 30kg 38

Prince Series The Prince Series is a comprehensive range of passive loudspeakers designed to deliver exceptional audio clarity and coverage. While the full series consists of line array, point source, and subwoofer enclosures, this catalogue focuses on the point source products specifcally for their relevance to commerical applications.

While PS point source loudspeakers are optimised to work in harmony with Prince Series line array and sub enclosure products the use cases of these high SPL point source boxes span much further. Suited to a wide range of applications including cafes, restaurants, and bars plus environments requiring a higher SPL such as bars, wedding venues, houses of worship, and large conference spaces.

Cafés

39

Restaurants

Bars

Wedding Venues

Houses of Worship

Conference Spaces

Live Sound Reinforcement

Scan Here to view on the HH Audio Website

40

PS5

5-Inch Point Source Loudspeaker Key Features

•

1 x 5-Inch low-frequency driver

•

1 x 0.75-Inch high-frequency driver

•

122dB Max SPL (Peak)

•

Frequency Response of 90Hz - 20kHz (±3dB)

•

90° (H) x 60° (V) dispersion angle

•

Robust wooden enclosure with a wear-resistant finish

•

Mounting bracket included

Applications

Frequency Response

90Hz–20kHz (±3dB) 85Hz–22kHz (-10d)

Finish

Black Paint

Coverage Angle

Horizontal 90° Vertical 60°

Grille

Hexagonal mesh black perforated steel with acoustic foam backing

Power Rating

150W Continuous, 600W Peak

Fittings

-

Max SPL

116dB Continuous, 122dB Peak 93dB (1W@1m)

Mounting Points

8Ω

Pin Connectors

Sensitivity Nominal Impedance LF Driver

1 x 5-Inch low-frequency driver

HF Driver

1 x 0.75-Inch high-frequency compression driver

Cabinet

Plywood

41

Connectors

Unit Dimensions (HWD) Unit weight

8 x M8 2 x Speakon NL4 Input +/Link 1+/- and 2+/184×150×180mm 3.1kg

PS6

6-Inch Point Source Loudspeaker Key Featu res •

1 x 6.5-Inch low-frequency driver

•

1 x 2-Inch high-frequency driver

•

122dB Max SPL (Peak)

•

Frequency Response of 90Hz - 20kHz (±3dB)

•

90° (H) x 60° (V) dispersion angle

•

Robust wooden enclosure with a wear-resistant finish

Applications

90Hz–20kHz (±3dB) 85Hz–22kHz (-10d)

Finish

Black Paint

Coverage Angle

Horizontal 90° Vertical 60°

Grille

Hexagonal mesh black perforated steel with acoustic foam backing

Power Rating

150W Continuous, 600W Peak

Fittings

-

Max SPL

116dB Continuous, 122dB Peak 93dB (1W@1m)

Mounting Points

8Ω

Pin Connectors

Frequency Response

Sensitivity Nominal Impedance LF Driver

1 × 6.5-Inch low-frequency driver

HF Driver

1 x 2-Inch high-frequency compression driver

Cabinet

Plywood

Connectors

Unit Dimensions (HWD) Unit weight

8 x M8 2 x Speakon NL4 Input +/Link 1+/- and 2+/395×220×200mm 8kg 42

PS8

8-Inch Point Source Loudspeaker Key Features •

1 x 8” low-frequency driver

•

1 x 2” high-frequency driver.

•

126dB Max SPL (Peak).

•

Frequency Response of 85Hz - 20kHz (±3dB).

•

90° (H) x 60° (V) dispersion angle.

•

Robust wooden enclosure with a wear-resistant finish.

Applications

85Hz–20kHz(±3dB) 70Hz–22kHz (-10dB)

Finish

Hard-wearing black polyurea paint

Coverage Angle

Horizontal 90° Vertical 60°

Grille

Hexagonal mesh black perforated steel with acoustic foam backing

Power Rating

200W Continuous, 800W Peak

Fittings

Pole-mount socket, M8 mounting points

Max SPL

Mounting Points

Nominal Impedance

120dB Continuous, 126dB Peak 95dB (1W@1m) 8Ω

LF Driver

1 x 8-Inch low-frequency driver

HF Driver

1 x 2-Inch high-frequency compression driver

Cabinet

Plywood

Frequency Response

Sensitivity

43

Connectors Pin Connectors Unit Dimensions Unit weight

8 x M8 2 x Speakon NL4 Input +/Link 1+/- and 2+/440×260×240mm 10kg

PS10

10-Inch Point Source Loud speaker Key Features •

1 x 10” low-frequency driver

•

1 x 1.4” high-frequency driver.

•

127dB Max SPL (Peak).

•

Frequency Response of 70Hz - 18kHz (±3dB).

•

90° (H) x 60° (V) dispersion angle.

•

Robust wooden enclosure with a wear-resistant finish.

Applications

42Hz - 18kHz (±3dB) 31Hz - 20kHz (-10dB)

Finish

Hard-wearing black polyurea paint

Coverage Angle

Horizontal 90° Vertical 60°

Grille

Hexagonal mesh black perforated steel with acoustic foam backing

Power Rating

300W Continuous, 1200W Peak

Fittings

Pole-mount socket, M8 Mounting points

Max SPL

Mounting Points

Sensitivity Nominal Impedance

121dB Continuous, 127dB Peak 96dB (1W@1m) 8Ω

LF Driver

1 x 10-Inch low-frequency driver

HF Driver

1 x 1.4-Inch high-frequency compression driver

Cabinet

Plywood

Frequency Response

Connectors Pin Connectors Unit Dimensions Unit weight

14 x M8 2 x Speakon NL4 Input +/Link 1+/- and 2+/515×320×280mm 15kg

44

PS12

12-Inch Point Source Loudspeaker Key Featu res

•

1 x 12-Inch low-frequency driver

•

1 x 3-Inch high-frequency compression driver

•

132dB Max SPL (Peak)

•

Rotatable horn with 90° (H) x 60° (V) coverage angles

•

Frequency Response of 42Hz - 18Hz (±3dB)

•

Robust wooden enclosure finished with black polyurea paint

Applications

Frequency Response Coverage Angle

50Hz–18kHz(±3dB) 40Hz–20kHz (-10dB)

Finish

Hard-wearing black polyurea paint

Horizontal 90° Vertical 60°

Grille

Hexagonal mesh black perforated steel with acoustic foam backing

Fittings

2 x Side handles, Dual pole-mount socket (0° and -10°), M8 Mounting points

Power Rating

400W Continuous, 1600W Peak

Max SPL Nominal Impedance

125dB Continuous, 131dB Peak 99dB (1W@1m) 8Ω

LF Driver

1 x 12-Inch low-frequency driver

Pin Connectors

HF Driver

1 x 3-Inch high-frequency compression driver

Unit Dimensions

Cabinet

Plywood

Sensitivity

45

Mounting Points Connectors

Unit weight

14 x M8 2 x Speakon NL4 Input +/Link 1+/- and 2+/650×400×365mm 22.5kg

PS15

15-Inch Point Source Loud speaker Key Featu res

•

1 x 15” low-frequency driver

•

1 x 3” high-frequency driver.

•

133dB Max SPL (Peak).

•

Frequency Response of 45Hz - 18kHz (±3dB).

•

90° (H) x 60° (V) dispersion angle.

•

Robust wooden enclosure with a wear-resistant finish.

Applications

45Hz–18kHz(±3dB) 35Hz–18kHz (-10dB)

Finish

Hard-wearing black polyurea paint

Coverage Angle

Horizontal 90° Vertical 60°

Grille

Hexagonal mesh black perforated steel with acoustic foam backing

Power Rating

500W Continuous, 2000W Peak

Fittings

2 x Side handles, Pole-mount socket, Mounting points

Max SPL

Mounting Points

LF Driver

127dB Continuous, 133dB Peak 100dB (1W@1m) 8Ω 1 x 15-Inch low-frequency driver

HF Driver

1 x 3-Inch high-frequency compression driver

Cabinet

Plywood

Frequency Response

Sensitivity Nominal Impedance

Connectors Pin Connectors Unit Dimensions Unit weight

10 x M8 2 x Speakon NL4 Input +/Link 1+/- and 2+/710×430×380mm 30kg

46

SP Series The SP Series loudspeaker management systems are the perfect counterpart to any HH set up – Suitable to a wide array of applications such as live sound and public address. The SP series comes with expertly created audio presets for use with the TNA line array system for easy set up straight out of the box.

SP Series units feature intuitive front panel controls and an interactive LCD display for local setup, or a dedicated PC control interface for remote monitoring and configuration via USB or RS485.

Clubs

47

Bars

Theatres/ Ballrooms

Corporate AV Events

Houses of Worship

Live Sound Reinforcement

Scan Here to view on the HH Audio Website

48

SP26

Digital Speaker Management System Key Featu res • • • • • • •

High performance 2 input, 6 output loudspeaker processor High quality 24bit AD/DA audio converters and 96bit DSP processor precision Max input delay of 900ms and max output delay of 340ms USB port for simple programming and setup Linkable inputs and outputs for easy stereo configuration Switched mode power supply with 100-240V worldwide operation 1U rack height

Applications

from 20Hz up to 20kHz with 1Hz resolution steps

Inputs

2 Electronically Balanced XLR Inputs

Centre Frequency

Outputs

6 Electronically Balanced XLR Outputs

Filter Q/BW

Q from 0.4 up to 128

150 Ohms

Input Gain

From -12dB to +12dB by 0.1dBu resolution steps;

0.001% at 1kHz 0 dBu

Output Gain

From -12dB to +12dB by 0.1dBu resolution steps; Butterworth 6/12/18/24/36/48 dB per octave. Bessel 12/24 dB per octave. Linkwitz-Riley 12/24/36/48 dB per octave

Minimum Load THD%N S/N

>106dBA

Frequency Response

20Hz-20kHz; -0.5dBy at 20Hz and 20kHz

AD/DA Converters

24bit, 96kHz (48kHz on models pre-October 2023)

Presents

48 user presets (16 pre-loaded TNA examples, may be erased)

Other

Audio Ground Lift switch, USB/RS485 ground lift switch

Remote

RS485 in/out XLR connectors for remote monitoring

DSP Engine DSP Resolution Parametric Equalisation

DSP, 24bit (data) x 96 bit (coeff.)

24bit (data) x 24 bit (coeff.), 54 bit accregisters. 96 bit precision on intermediate processing data 11 filters per input,7 filters per output

Filter Type

Bell, Shelving

Filter Gain

From -12dBu up to +12dBu by 0.5dBu resolution steps

49

Crossover Section HPF/LPF Input Noise Gate

Threshold from -90dBu up to -60dBu. Attack time from 1ms up to 1000ms;Release time from 10ms up to 1000ms

Input RMS Compressor

Threshold from -14dBu up to +16dBu and Bypass. Ratio 2:1~100:1; Knee: 0% ~ 100%. Attack time from 5ms up to 200ms;Release time from 0.1 sec up to 3 sec

Output Peak Limiter

Threshold from -14dBu up to +16dBu and Bypass. Attack time from 5ms up to 200ms;Release time from 0.1 sec up to 3 sec.

900 ms 10.4us increment/decrement steps per input channel. 340 ms 10.4us increment/decrement steps per output channel

Delay AC Power

Universal voltage 100V-240V~ 50/60Hz, three pin IEC socket

AC Power Consumption

<30W

Unit dimensions (HWD)

44 x 482 x 225mm, 1.7-Inch x 19-Inch x 8.9-Inch

Unit weight

3.5Kg, 7.7 lbs

SP48

Digital Speaker Management System Key Featu res • • • • • • •

High performance 4 input, 8 output loudspeaker processor High quality 24bit AD/DA audio converters 96bit DSP processor precision Max input delay of 420ms and max output delay of 129ms USB port for simple programming and setup.

Linkable inputs and outputs for easy stereo configuration Switched mode power supply with 100-240V worldwide operation 1U rack height

Applications

Inputs

4 Electronically Balanced XLR Inputs

Filter Gain

Outputs

6 Electronically Balanced XLR Outputs

Centre Frequency

Minimum Load THD%N S/N

150 Ohms

Filter Q/BW

0.001% at 1kHz 0 dBu

Input Gain

From -18dB to +12dB by 0.1dBu resolution steps;

>106dBA 20Hz-20kHz; -0.5dBy at 20Hz and 20kHz

AD/DA Converters

24bit, 48kHz 24 User Presets

Output Gain Crossover Section HPF/ LPF Input Noise Gate

Other

Audio Ground Lift switch, USB/RS485 ground lift switch

Input RMS Compressor

Remote

USB remote control and RS485 in/out RJ45 connectors for control and monitoring of upto 32 units

Output Peak Limiter

DSP Engine DSP Resolution

from 20Hz up to 20kHz with 1Hz resolution steps Bell Q: 0.4~128, Shelving/HP/LP Q:0.1~5.1, BP/Notch/All Pass Q:4~104

Frequency Response Presents

From -15dBu up to +15dBu by 0.5dBu resolution steps

24bit DSP 24bit (data) x 24 bit (coeff.), 54 bit accregisters. 96 bit precision on intermediate processing data

Parametric Equalisation

30 filters per input,7 filters per output

Filter Type

Bell, Hi/Lo Shelving, HP/LP Bandpass, Notch, All Pass

Delay AC Power

From -18dB to +12dB by 0.1dBu resolution steps; Butterworth 6/12/18/24/36/48 dB per octave. Bessel 12/24 dB per octave. Linkwitz-Riley 12/24/36/48 dB per octave Threshold from -80dBu up to -50dBu. Attack time from 1ms up to 1000ms;Release time from 10ms up to 1000ms Threshold from -14dBu up to +16dBu and Bypass. Ratio 2:1~32:1; Knee: 0% ~ 100%. Makeup from -12dB to +12dB. Attack time from 5ms up to 200ms;Release time from 0.1 sec up to 3 sec Threshold from -14dBu up to +16dBu and Bypass. Attack time from 1ms up to 900ms;Release time from 0.1 sec up to 5 sec.

420ms per input channel. 129ms per output channel Universal voltage 100V-240V~ 50/60Hz, three pin IEC socket

AC Power Consumption

<30W

Unit dimensions (HWD)

44 x 482 x 229mm, 1.7-Inch x 19-Inch x 8.9-Inch

Unit weight

3.5Kg, 7.7 lbs

50

MZ-Series The HH MZ Series, is a range of high performance, commercial, multi-zone amplifiers, preamplifier, and zone wall controller. Offering class leading low noise performance, with ultra high power in a compact 1U enclosure.

The MZ wall controllers allow the installer to select which zones the volume control is assigned to, and has a handy quick illuminated mute option to avoid adjusting the volume control. Standard UK/EU or US sized wall plates are available in a choice of white, or satin black.

The MZ range is suitable for a wide variety of use cases such as Retail, Restaurants, Conferences, Bars, Houses of Worship and Fitness Centres, or indeed anywhere high quality multi zone amplification is required.

Cafés

51

Conference Spaces

Bars

Houses of Worship

Restaurants

Leisure Centres

Retail

Scan Here to view on the HH Audio Website

52

MZ-140DX

Multi-Zone Amplifier Key Features • • • • • • • • • • • • • •

2 Zone Amplifier with assignable speaker outputs 140 Watts RMS Power output per zone with full power sharing of up to 280W into channel 1 >106dB signal to noise <0.008% THD+N Ultra-reliable, High performance amp modules designed by PASCAL 70V/100V or Min 4 Ohm Impedance Speaker Outputs (Configurable per Output) USB-C compliant APP for EQ, Limiter and Installer Settings adjustment Compact 1U ½ rack size Wall or rack mountable Universal ~100-240V worldwide operation Configurable: Easy DIP switch configuration including panel lock Efficiency: Low energy consumption Class leading performance

A pplicat io n s

Input Channels

2 + USB-C Digital Input for Audio Streaming

Output Channels

2

Power Rating

2x 140W

Output Limiter

Yes

Frequency Response

20-20KHz ±0.1dBu (LoZ Mode) 80-20KHz ±0.1dBu (HiZ Mode)

EQ AC Power Power Consumption

Available on MZ Control App Universal AC 100-240V~ 50/60HZ 17W Idle, 150W Typical, 200W Max, 0.4W Standby

Standby Modes

Auto standby mode, with override.

Energy Star & ErP 1275/2008/EC Compliant.

44 x 265 x 345 mm, (1.7-Inch x 10.4-Inch x 13.6-Inch)

THD+N

< 0.008%

Unit Dimensions (HWD)

SNR (A-weighted)

>110dB

Net Weight

2.5Kg, 5.5 lbs

Accessories

Rack Mounting Kit included. 4x 3.5mm 3 way, 2x 3.5mm 5 way, 1x 5.08mm 6 way Euro Plugs included. Optional MZ-C2 Wall Controllers

Controls

53

Each amplifier output features master volume controls, Dual Function Signal Present/Clip Led. Rear panel includes front panel lock and zone amplifier mode options via dip switches

MZ-140D

Multi-Zone Amplifier Key Featu res • • • • • • • • • • • • •

2 Zone Amplifier with assignable speaker outputs 140 Watts RMS Power output per zone >106dB signal to noise <0.009% THD+N Euro block input and output connectors, dual mic inputs Ultra-reliable, High performance amp modules designed

by PASCAL Microphone priority for automatic ducking on speech and paging inputs for page microphones Independent Bass and Treble EQ adjustment per zone Universal ~100-240V worldwide operation Remote volume and source control capability Compact space saving 1U 19-Inch rack mountable design Switchable emergency input override Class leading performance

A pplicat io n s

Input Channels

5

Output Channels

2

Power Rating

2x 140W

Output Limiter

Yes

Controls EQ AC Power

Each amplifier output features master volume controls, Dual Function Signal Present/Clip Led. Rear panel includes front panel lock and zone amplifier mode options via dip switches Bass 250Hz Shelving Control, ±12dB per zone. Treble 2kHz Shelving Control, ±12dB per zone Universal AC 100-240V~ 50/60HZ

Frequency Response

20-20KHz ±0.1dBu (LoZ Mode) 80-20KHz ±0.1dBu (HiZ Mode)

Configurable Routing

Yes

Standby Modes

Auto standby mode, with override

Yes (Auto and Manual CH1/2)

Unit Dimensions (HWD)

44 x 483 x 417 mm, (1.7-Inch x 19-Inch x 16.4-Inch)

Priority Muting Fire System Integration

Yes

THD+N

< 0.008%

SNR (A-weighted)

>106dB

Power Consumption

25W Idle, 150W Typical, 200W Max, 0.5W Standby

Net Weight

3.9Kg, 8.6 lbs

Accessories

Rack Mounting Kit included. 4x 3.5mm 3 way, 2x 3.5mm 5 way, 1x 5.08mm 6 way Euro Plugs included. Optional MZ-C2 Wall Controllers 54

MZ-140Q

Multi-Zone Amplifier Key Featu res • • • • • • • • • • • • •

4 Zone Amplifier with assignable speaker outputs 140 Watts RMS Power output per zone >106dB signal to noise <0.009% THD+N Euro block input and output connectors, dual mic inputs Class leading performance Ultra-reliable, High performance amp modules designed

by PASCAL Microphone priority for automatic ducking on speech and paging inputs for page microphones Independent Bass and Treble EQ adjustment per zone Universal power supply for worldwide operation (100 – 240V~) Remote volume and source control capability Compact space saving 1U 19-Inch rack mountable design Switchable emergency input override

Applications

Input Channels

5

Output Channels

2

Power Rating

4x 140W

Output Limiter

Yes

Controls

Each amplifier output features master volume controls, Dual Function Signal Present/Clip Led. Rear panel includes front panel lock and zone amplifier mode options via dip switches

EQ

Bass 250Hz Shelving Control, ±12dB per zone. Treble 2kHz Shelving Control, ±12dB per zone

AC Power

Universal AC 100-240V~ 50/60HZ

Frequency Response

20-20KHz ±0.1dBu (LoZ Mode) 80-20KHz ±0.1dBu (HiZ Mode)

Configurable Routing

Yes

Standby Modes

Auto standby mode, with override

Yes (Auto and Manual CH1/2)

Unit Dimensions (HWD)

44 x 483 x 417 mm, (1.7-Inch x 19-Inch x 16.4-Inch)

Priority Muting Fire System Integration

Yes

THD+N

< 0.009%

SNR (A-weighted)

>106dB

55

Power Consumption

30W Idle, 300W Typical, 450W Max, 0.5W Standby

Net Weight

4.5Kg, 9.9 lbs

Accessories

Rack Mounting Kit included. 4x 3.5mm 3 way, 2x 3.5mm 5 way, 1x 5.08mm 6 way Euro Plugs included. Optional MZ-C2 Wall Controllers

MZ-280Q

Multi-Zone Amplifier Key Features • • • • • • • • • • • • •

4 Zone Amplifier with assignable speaker outputs 280 Watts RMS Power output per zone >106dB signal to noise <0.009% THD+N Euro block input and output connectors, dual mic inputs Class leading performance Ultra-reliable, High performance amp modules designed

by PASCAL Microphone priority for automatic ducking on speech and paging inputs for page microphones Independent Bass and Treble EQ adjustment per zone Universal power supply for worldwide operation (100 – 240V~) Remote volume and source control capability Compact space saving 1U 19-Inch rack mountable design Switchable emergency input override

Applications

Input Channels

5

Output Channels

4

Power Rating

4x 280W

Output Limiter

Yes

Controls

Each amplifier output features master volume controls, Dual Function Signal Present/ Clip Led. Rear panel includes front panel lock and zone amplifier mode options via dip switches

EQ

Bass 250Hz Shelving Control, ±12dB per zone. Treble 2kHz Shelving Control, ±12dB per zone

AC Power

Universal AC 100-240V~ 50/60HZ

Frequency Response

20-20KHz ±0.1dBu (LoZ Mode) 80-20KHz ±0.1dBu (HiZ Mode)

Configurable Routing

Yes

Standby Modes

Auto standby mode, with override

Yes (Auto and Manual CH1/2)

Unit Dimensions (HWD)

44 x 483 x 417 mm, (1.7-Inch x 19-Inch x 16.4-Inch)

Priority Muting Fire System Integration

Yes

THD+N

< 0.009%

SNR (A-weighted)

>106dB

Power Consumption

35W Idle, 300W Typical, 650W Max, 0.5W Standby

Net Weight

4.9Kg, 10.8 lbs

Accessories

Rack Mounting Kit included. 4x 3.5mm 3 way, 2x 3.5mm 5 way, 1x 5.08mm 6 way Euro Plugs included. Optional MZ-C2 Wall Controllers 56

MZ-64P

Multi-Zone Preamplifier Key Featu res

• • • • • • • • • • • •

4 Zone Distribution Pre-Amplifier 4 Line level outputs with +21dBv max output >110dB signal to noise <0.008% THD+N Euro block input and output connectors, dual mic inputs Class leading performance Microphone priority for automatic ducking on speech and paging inputs for page microphones Independent Bass and Treble EQ adjustment per zone Universal power supply for worldwide operation (100 – 240V~) Remote volume and source control capability Compact space saving 1U 19-Inch rack mountable design Switchable emergency input override

Applications

Input Channels

5

Output Channels

4

Power Rating

-

Output Limiter

Yes (0dBu/+4dBu/Off)

Frequency Response

20-20KHz ±0.1dBu

Configurable Routing

Yes

Priority Muting

Yes (Auto and Manual CH1/2)

Controls EQ AC Power Power Consumption Standby Modes Unit Dimensions (HWD)

Each amplifier output features master volume controls, Dual Function Signal Present/Clip Led. Rear panel includes front panel lock and zone amplifier mode options via dip switches Bass 250Hz Shelving Control, ±12dB per zone. Treble 2kHz Shelving Control, ±12dB per zone Universal AC 100-240V~ 50/60HZ Typical <8W, Maximum < 30W 44 x 483 x 198 mm (1.7-Inch-Inch x 19-Inch-Inch x 7.8-Inch-Inch )-Inch

Yes

Net Weight

2.3Kg, 5.1lbs

THD+N

< 0.009%

Accessories

SNR (A-weighted)

>110dB

Rack Mounting Kit included. 4x 3.5mm 3 way, 2x 3.5mm 5 way, 1x 5.08mm 6 way Euro Plugs included. Optional MZ-C2 Wall Controllers

Fire System Integration

57

MZ-C2

Zone Wall Controller Key Featu res •

Single or multiple zones can be selected for volume control with an illuminated mute button

•

A front mounted source selector control allows the user to select which input is routed to the active zone/s

•

Control and Power via Cat5e cable, with daisy chain link connectors

•

Standard UK/EU or US sized wall plates

•

Available in white or satin black

Applications

Colour

White or Black

Controls

Rotary volume control, rotary source select, mute switch, zone select DIP switch

Input Connectors

1 x RJ45 LAN Connector

Wiring Unit Dimensions Weight

Standard Cat5e shielded cable, in a daisy chain configuration EU - 86 x 86 x 44mm (3.4-Inch x 3.4-Inch x 1.7-Inch) US - 114 x 70 x 44mm (4.5-Inch x 2.8-Inch x1.7-Inch) 0.147kg (0.3lbs) 58

Product Catalogue

COMMERCIAL AUDIO 2025

Contact Us. For more information visit hhaudio.com/contact-us 59
