THE AVIATION EDITION
HISTORY OF NEW YORK’S BIG 3 P.12
HALMAR AVATION ROUND-UP P.16
Issue No 4 • Fall/Winter 2017
INNOVATION: 3D CONCRETE PRINTING P.24
HIWAY | 1
ABOUT
HIWAY FROM THE EDITOR According to businessinsider. com, the world currently views US airports as substandard, with antiquated facilities, poor design and inconvenient connecting terminals. The 2015 Skytrax survey of the world’s best airports highlights this further, as not one airport in the states made the top 25 in the survey. To further highlight the dire state of airport infrastructure, Vice President Joe Biden has likened New York LaGuardia Airport to what one might find in “some third world country”. Though US airports might be considered third-world, compared with many of the new sleeker, more passenger friendly facilities overseas, now we’re seeing first world planning here in the states. It is blatantly untrue that US airports are falling down, but rather are rising to new heights and setting new standards for the rest of the world. Under this shift, the North America region now ranks as one of the top three regions in the world for the highest investment for capital improvement projects. These projects include new and upgraded terminals, runways and taxiways, lighting and passenger amenities. As Halmar passes it 55th year of operation this issue takes a look back at the multitude of airport work we have done in the Northeast region from cargo buildings and terminals to runways, taxiways and parking structures! Halmar is uniquely placed to be in integral part of the expansion and rebuilding of our airports. We hope you enjoy the issue! Sincerely, Kim Begonja Editor
© 2017 | 2 HIWAY
04 12 16 18 24 27 28 32 34
CURRENT PROJECT UPDATES
Curious about the latest word on any of our current projects? Check the “Current Project Updates” section out and see what’s developing.
HISTORY OF NEW YORK’S BIG 3
A yesteryear look at LaGuardia, JFK and Newark’s birth .
HALMAR AVATION ROUND-UP
Proud of our past projects and accomplishments.
LAGUARDIA AIRPORT
What’s next for the little airport that could.
INNOVATION: 3D CONCRETE PRINTING
Hi-Way introduces you to an old material reinvented with the use of technology.
HALMAR EQUIPMENT
WELCOME TO THE AVIATION EDITION OF HI-WAY, THE HALMAR NEWSLETTER! DEAR EMPLOYEES On behalf of the executive team and our marketing department, we are pleased to publish the fourth issue of Hi-Way, Halmar’s employee newsletter. This fourth issue is focused on Aviation. Halmar’s Aviation projects past and present - and Aviation projects of the future, projects that Halmar will aggressively pursue going forward. We focus on nearly a decade of work Halmar performed at JFK in the nineties and the beginning of the new millennium. How we played a major role in the JFK Redevelopment Program, working on three of the major passenger terminals, one of the major runways, a host of taxiways, roads, bridges, parking garages, toll plazas, and a U.S. customs facility and a large perishables warehouse facility, both on the airport. (See airport map on Page 16-17). Halmar’s major role in the JFK redevelopment was a significant factor in Halmar’s growth in revenue and reputation, and helped put Halmar on the national stage.
Operator Awareness Program to meet new emissions requirements.
Halmar also performd work at Newark Airport, building a monorail station, and currently is still performing work at LaGuardia infrastructure, as part of the LaGuardia Airport Redevelopment Project.
HALMAR AIRPORT PORTFOLIO
Looking to the future, there is major airport work planned at Newark Liberty Airport, Stewart International Airport and Long Island McArthur Airport. We look forward to leveraging our successful airport track record to capture a share of these upcoming opportunities.
More than two decades of continued success building and being part of NYC’s aviation industry.
HALMAR SOCIAL
The culture inside the Halmar family...Halloween costumes, new borns & that Halmar-swag?
HALMAR SPORTS
Just completing its second year as a Halmar Race team, our drivers and their dedicated crew have put Halmar Racing on the map.
And since much of the airport work on the horizon will be at New York area r airports, we thought you would enjoy a a nostalgic look back at the history of the 3 big airports in the New York area beginning on page 12. We hope you enjoy this issue’s focus on Aviation, along with all the regular columns including Current Project Updates, Halmars’ Social Page and Sports Page, and the Innovation column, for a look at the future of concrete forming that is here today – 3D printing! We’d like to thank all of you for your interest in Hi-Way and the positive feedback. We hope you enjoy this and other forthcoming issues, each one an individual building block in the great construct that is our history... and our future. This is HI-Way. Sincerely, Chris Larsen & Paul Atkins HIWAY | 3
ABOUT
HIWAY FROM THE EDITOR According to businessinsider. com, the world currently views US airports as substandard, with antiquated facilities, poor design and inconvenient connecting terminals. The 2015 Skytrax survey of the world’s best airports highlights this further, as not one airport in the states made the top 25 in the survey. To further highlight the dire state of airport infrastructure, Vice President Joe Biden has likened New York LaGuardia Airport to what one might find in “some third world country”. Though US airports might be considered third-world, compared with many of the new sleeker, more passenger friendly facilities overseas, now we’re seeing first world planning here in the states. It is blatantly untrue that US airports are falling down, but rather are rising to new heights and setting new standards for the rest of the world. Under this shift, the North America region now ranks as one of the top three regions in the world for the highest investment for capital improvement projects. These projects include new and upgraded terminals, runways and taxiways, lighting and passenger amenities. As Halmar passes it 55th year of operation this issue takes a look back at the multitude of airport work we have done in the Northeast region from cargo buildings and terminals to runways, taxiways and parking structures! Halmar is uniquely placed to be in integral part of the expansion and rebuilding of our airports. We hope you enjoy the issue! Sincerely, Kim Begonja Editor
© 2017 | 2 HIWAY
04 12 16 18 24 27 28 32 34
CURRENT PROJECT UPDATES
Curious about the latest word on any of our current projects? Check the “Current Project Updates” section out and see what’s developing.
HISTORY OF NEW YORK’S BIG 3
A yesteryear look at LaGuardia, JFK and Newark’s birth .
HALMAR AVATION ROUND-UP
Proud of our past projects and accomplishments.
LAGUARDIA AIRPORT
What’s next for the little airport that could.
INNOVATION: 3D CONCRETE PRINTING
Hi-Way introduces you to an old material reinvented with the use of technology.
HALMAR EQUIPMENT
WELCOME TO THE AVIATION EDITION OF HI-WAY, THE HALMAR NEWSLETTER! DEAR EMPLOYEES On behalf of the executive team and our marketing department, we are pleased to publish the fourth issue of Hi-Way, Halmar’s employee newsletter. This fourth issue is focused on Aviation. Halmar’s Aviation projects past and present - and Aviation projects of the future, projects that Halmar will aggressively pursue going forward. We focus on nearly a decade of work Halmar performed at JFK in the nineties and the beginning of the new millennium. How we played a major role in the JFK Redevelopment Program, working on three of the major passenger terminals, one of the major runways, a host of taxiways, roads, bridges, parking garages, toll plazas, and a U.S. customs facility and a large perishables warehouse facility, both on the airport. (See airport map on Page 16-17). Halmar’s major role in the JFK redevelopment was a significant factor in Halmar’s growth in revenue and reputation, and helped put Halmar on the national stage.
Operator Awareness Program to meet new emissions requirements.
Halmar also performd work at Newark Airport, building a monorail station, and currently is still performing work at LaGuardia infrastructure, as part of the LaGuardia Airport Redevelopment Project.
HALMAR AIRPORT PORTFOLIO
Looking to the future, there is major airport work planned at Newark Liberty Airport, Stewart International Airport and Long Island McArthur Airport. We look forward to leveraging our successful airport track record to capture a share of these upcoming opportunities.
More than two decades of continued success building and being part of NYC’s aviation industry.
HALMAR SOCIAL
The culture inside the Halmar family...Halloween costumes, new borns & that Halmar-swag?
HALMAR SPORTS
Just completing its second year as a Halmar Race team, our drivers and their dedicated crew have put Halmar Racing on the map.
And since much of the airport work on the horizon will be at New York area r airports, we thought you would enjoy a a nostalgic look back at the history of the 3 big airports in the New York area beginning on page 12. We hope you enjoy this issue’s focus on Aviation, along with all the regular columns including Current Project Updates, Halmars’ Social Page and Sports Page, and the Innovation column, for a look at the future of concrete forming that is here today – 3D printing! We’d like to thank all of you for your interest in Hi-Way and the positive feedback. We hope you enjoy this and other forthcoming issues, each one an individual building block in the great construct that is our history... and our future. This is HI-Way. Sincerely, Chris Larsen & Paul Atkins HIWAY | 3
PROJECT UPDATES
The latest goings-on at your site from your Project Managers
Mill Basin
Project Manager: John Cinguina
Concouse-Pitkin Yard Project Project Manager: Gustavo Urrea
The Shop Repair at Pitkin Yard and Power Upgrade at The Concourse shop is a 18 month project that has it’s challenges due the fact that is a project with two Job sites (Pitkin in Brooklyn and Concourse in the Bronx). Additionally The work also has to be performed while keeping both barns active since these barns are 24/7 all year round. The work has been completed and we are currently working on additional work orders that were added to the project and also commissioning the equipment and systems that were installed. The following is the scope of the work performed: Pitkin Yard (Brooklyn): • Remove and Install two New Trolley and Stinger systems • Provide Steel supports for DC Power Stinger Systems • Install a 2-TON double girder bridge overhead Crane with four lift hoists • Install a New Roofing system for the entire Shop • Install a Hand Rail System around the entire perimeter of the roof • Install 10 New Roof Mounted Exhaust Fans • Provide 10 steel Supports for new Exhaust Fans Concourse Yard (Bronx): • Install New Switch Gear • Remove and Install New Trolley and Stinger Systems • Provide Steel Supports for DC Power Stinger Systems • Remove and replace Multiple Tracks at Both Ends of the Shop • Install Underground Duct Banks and Manholes across and along the tracks for DC Positive and Negative Cables • Install New Negative equalizers at North End and South End of the Shop • Build New DC distribution room & Fire alarm room
HIWAY | 4
Mill Basin Bridge is progressing ahead to meet our first major traffic switch and the opening of the westbound bridge by July 4 2017. Presently structural concrete is 85 percent complete and will be wrapping up in mid-January. Structural steel is presently 50 percent complete. Work approaching Jamaica Bay has started and will continue through the winter. Concrete pavement is 50 percent complete on the south approach. Drainage is 45 percent complete on the north approach and will continue through the winter Spring 2017 will be active with the pouring of the remaining bridge decks and concrete pavement. Subcontractors will include Atlas concrete for curbs and barrier, Tonnage for rebar, Safety Marking for striping, and Royal Guard for guide rail.
HIWAY | 5
PROJECT UPDATES
The latest goings-on at your site from your Project Managers
Mill Basin
Project Manager: John Cinguina
Concouse-Pitkin Yard Project Project Manager: Gustavo Urrea
The Shop Repair at Pitkin Yard and Power Upgrade at The Concourse shop is a 18 month project that has it’s challenges due the fact that is a project with two Job sites (Pitkin in Brooklyn and Concourse in the Bronx). Additionally The work also has to be performed while keeping both barns active since these barns are 24/7 all year round. The work has been completed and we are currently working on additional work orders that were added to the project and also commissioning the equipment and systems that were installed. The following is the scope of the work performed: Pitkin Yard (Brooklyn): • Remove and Install two New Trolley and Stinger systems • Provide Steel supports for DC Power Stinger Systems • Install a 2-TON double girder bridge overhead Crane with four lift hoists • Install a New Roofing system for the entire Shop • Install a Hand Rail System around the entire perimeter of the roof • Install 10 New Roof Mounted Exhaust Fans • Provide 10 steel Supports for new Exhaust Fans Concourse Yard (Bronx): • Install New Switch Gear • Remove and Install New Trolley and Stinger Systems • Provide Steel Supports for DC Power Stinger Systems • Remove and replace Multiple Tracks at Both Ends of the Shop • Install Underground Duct Banks and Manholes across and along the tracks for DC Positive and Negative Cables • Install New Negative equalizers at North End and South End of the Shop • Build New DC distribution room & Fire alarm room
HIWAY | 4
Mill Basin Bridge is progressing ahead to meet our first major traffic switch and the opening of the westbound bridge by July 4 2017. Presently structural concrete is 85 percent complete and will be wrapping up in mid-January. Structural steel is presently 50 percent complete. Work approaching Jamaica Bay has started and will continue through the winter. Concrete pavement is 50 percent complete on the south approach. Drainage is 45 percent complete on the north approach and will continue through the winter Spring 2017 will be active with the pouring of the remaining bridge decks and concrete pavement. Subcontractors will include Atlas concrete for curbs and barrier, Tonnage for rebar, Safety Marking for striping, and Royal Guard for guide rail.
HIWAY | 5
PROJECT UPDATES
Contiued...
LaGuardia Airport
Project Manager: Matt Keefe
Bundled Bridges
Project Manager: Matthew Katkochin
Bridges for Route 199 (Town of Milan), Route 82 (Wappingers), Route 55 (Lagrange), Route 22 (Hillsdale) and Route 9H (Greenport) have all been completed and re-opened to traffic. The Route 82 Union Vale bridge is still under construction. At 82 Union Vale the abutments have been poured, precast tensioned and grouted. Deck form work and drainage work is continuing as allowed by the winter months. The bridge is scheduled to be reopened in early May.
HIWAY | 6
Halmar still retains a presence at LaGuardia. Currently, we are constructing the East Field Lighting Vault (Work Order 102) and Fiber Connection from the East Field Lighting Vault to Bldg 30, EES, and ATCT (Work Order 104). Both are part of the LGA Capital Infrastructure Program Contract 124.223.
HIWAY | 7
PROJECT UPDATES
Contiued...
LaGuardia Airport
Project Manager: Matt Keefe
Bundled Bridges
Project Manager: Matthew Katkochin
Bridges for Route 199 (Town of Milan), Route 82 (Wappingers), Route 55 (Lagrange), Route 22 (Hillsdale) and Route 9H (Greenport) have all been completed and re-opened to traffic. The Route 82 Union Vale bridge is still under construction. At 82 Union Vale the abutments have been poured, precast tensioned and grouted. Deck form work and drainage work is continuing as allowed by the winter months. The bridge is scheduled to be reopened in early May.
HIWAY | 6
Halmar still retains a presence at LaGuardia. Currently, we are constructing the East Field Lighting Vault (Work Order 102) and Fiber Connection from the East Field Lighting Vault to Bldg 30, EES, and ATCT (Work Order 104). Both are part of the LGA Capital Infrastructure Program Contract 124.223.
HIWAY | 7
PROJECT UPDATES
Contiued...
PATH Harrison Station Replacement Project Manager: Terrence O’Connell
One Vanderbuilt
Project Manager: Anthony Manganiello & James Ku
One Vanderbilt is a new project that we’re working on with a private developer, SL Green Realty. The project is part of the $200M infrastructure modifications and off-site transit improvements for the new One Vanderbilt skyscraper that will be NYC’s 2nd tallest building, located next to Grand Central Terminal, to be completed by year 2020. The off-site transit improvements include a 2-Phase project for MTA New York City Transit Authority. Halmar’s work for Phase 1 of the project is to rehabilitate an existing decommissioned pedestrian tunnel, the Mobil Passageway located under 42nd Street, and create a new subway entrance at 42nd Street and Lexington Avenue to connect with the Grand Central
HIWAY | 8
Terminal mezzanine for pedestrian access. Also in Phase 1 of the project is to construct the P-10 Stair that is a new 7’-6” metal staircase that connects the Grand Central Mezzanine to the southbound 4, 5, 6 subway platform. This P-10 Stair requires opening up the basement level of the 125 Park Avenue Pershing Building, located at Park Avenue and 42nd Street, including concrete and steel demolition, structural excavation, and new concrete construction. Halmar’s Phase 1 work started in October 2016 and is slated to be complete by July 30, 2017. We are currently working on the demolition in the 125 Park Avenue Pershing Building basement and structural excavation for the new P-10 Stair.
Approximately 60% of the overall project has been negotiated to date – East Station Houses and Platforms. The Port Authority has not yet decided how they will proceed with the West Station Houses. The Northeast Station House and Platform structure is completed and awaiting curtain wall, which is scheduled for this Summer 2017. Electrical/HVAC roughing and finish work is ongoing. The Northeast station house is scheduled to be commissioned April 2018, pending PA issuance of several design changes. The Ben Harjay building demolition at the southeast quadrant has been completed and is currently being used as a laydown area. The Southeast Station House platform caisson and soldier pile installation began in September 2016 and is scheduled to be completed in March 2018. The SE platform/canopy will be installed after completion, followed by the station house minipiles/foundation. The Southeast structural steel work is scheduled to be completed by December 2017 and commissioned December 2018, pending PA issuance of several design changes.
HIWAY | 9
PROJECT UPDATES
Contiued...
PATH Harrison Station Replacement Project Manager: Terrence O’Connell
One Vanderbuilt
Project Manager: Anthony Manganiello & James Ku
One Vanderbilt is a new project that we’re working on with a private developer, SL Green Realty. The project is part of the $200M infrastructure modifications and off-site transit improvements for the new One Vanderbilt skyscraper that will be NYC’s 2nd tallest building, located next to Grand Central Terminal, to be completed by year 2020. The off-site transit improvements include a 2-Phase project for MTA New York City Transit Authority. Halmar’s work for Phase 1 of the project is to rehabilitate an existing decommissioned pedestrian tunnel, the Mobil Passageway located under 42nd Street, and create a new subway entrance at 42nd Street and Lexington Avenue to connect with the Grand Central
HIWAY | 8
Terminal mezzanine for pedestrian access. Also in Phase 1 of the project is to construct the P-10 Stair that is a new 7’-6” metal staircase that connects the Grand Central Mezzanine to the southbound 4, 5, 6 subway platform. This P-10 Stair requires opening up the basement level of the 125 Park Avenue Pershing Building, located at Park Avenue and 42nd Street, including concrete and steel demolition, structural excavation, and new concrete construction. Halmar’s Phase 1 work started in October 2016 and is slated to be complete by July 30, 2017. We are currently working on the demolition in the 125 Park Avenue Pershing Building basement and structural excavation for the new P-10 Stair.
Approximately 60% of the overall project has been negotiated to date – East Station Houses and Platforms. The Port Authority has not yet decided how they will proceed with the West Station Houses. The Northeast Station House and Platform structure is completed and awaiting curtain wall, which is scheduled for this Summer 2017. Electrical/HVAC roughing and finish work is ongoing. The Northeast station house is scheduled to be commissioned April 2018, pending PA issuance of several design changes. The Ben Harjay building demolition at the southeast quadrant has been completed and is currently being used as a laydown area. The Southeast Station House platform caisson and soldier pile installation began in September 2016 and is scheduled to be completed in March 2018. The SE platform/canopy will be installed after completion, followed by the station house minipiles/foundation. The Southeast structural steel work is scheduled to be completed by December 2017 and commissioned December 2018, pending PA issuance of several design changes.
HIWAY | 9
Bronx Whitestone Bridge Project Manager: John O’Connor
Route 9W over Popolopen Creek Project Manager: Brendan McLaughlin
Awarded December 2015, The Bronx Whitestone Bridge project includes the removal of tuned mass damper as well as the removal of cross over platform for service to TMD. The contract also includes repairs and cable wedging and Inspection between bands and also at bands after removal and three suspender replacement including testing of cable wires and suspender ropes. We are currently finishing up suspender replacements on the East cable North Bound. Teams are in the process of steel removal of wind fairing trusses at mid span and prep work for removal of Tuned Mass Dampers has begun.
HIWAY | 10
In the fall of this year our crews completed all steel replacement, SLO, bearings, painting, deck repairs, concrete work, asphalt paving, railing, landscaping, and punch-list. Over the duration of the project, Halmar crews faced many challenges and unforeseen conditions which were acknowledged by NYSDOT and required 3 extensions to the original contract completion date. As of November 30, 2016 the Popolopen Bridge project is 100% complete.
HIWAY | 11
Bronx Whitestone Bridge Project Manager: John O’Connor
Route 9W over Popolopen Creek Project Manager: Brendan McLaughlin
Awarded December 2015, The Bronx Whitestone Bridge project includes the removal of tuned mass damper as well as the removal of cross over platform for service to TMD. The contract also includes repairs and cable wedging and Inspection between bands and also at bands after removal and three suspender replacement including testing of cable wires and suspender ropes. We are currently finishing up suspender replacements on the East cable North Bound. Teams are in the process of steel removal of wind fairing trusses at mid span and prep work for removal of Tuned Mass Dampers has begun.
HIWAY | 10
In the fall of this year our crews completed all steel replacement, SLO, bearings, painting, deck repairs, concrete work, asphalt paving, railing, landscaping, and punch-list. Over the duration of the project, Halmar crews faced many challenges and unforeseen conditions which were acknowledged by NYSDOT and required 3 extensions to the original contract completion date. As of November 30, 2016 the Popolopen Bridge project is 100% complete.
HIWAY | 11
HISTORY OF NEW YORK’S BIG LAGUARDIA-LGA Opened in 1939, LaGuardia Airport was built on the site of the old Gala Amusement Park at a cost of $40 million. The airport sits on 680 acres, has two 7,000 ft main runways and four terminal buildings
HIWAY | 12
that house up to 72 aircraft gates. Today, LaGuardia Airport’s 4 terminals handle millions of passengers, millions of tons of cargo and is an important economic engine for the New York-New Jersey region.
HIWAY | 13
HISTORY OF NEW YORK’S BIG LAGUARDIA-LGA Opened in 1939, LaGuardia Airport was built on the site of the old Gala Amusement Park at a cost of $40 million. The airport sits on 680 acres, has two 7,000 ft main runways and four terminal buildings
HIWAY | 12
that house up to 72 aircraft gates. Today, LaGuardia Airport’s 4 terminals handle millions of passengers, millions of tons of cargo and is an important economic engine for the New York-New Jersey region.
HIWAY | 13
JOHN F. KENNEDY-JFK Initial plans were for a modest 1,000-acre airport, but by the time construction was complete Idlewild Airport had grown to five times that size. Commercial flights began in July 1948. Today, JFK is the nation’s leading international gateway, • American Airlines • Cargo Buildings 77 & 75 • Perishables
with more than 80 airlines operating from its gates. JFK has six operating airline terminals, surrounded by a dual ring of peripheral taxiways. More than 125 aircraft gates serve the terminals. • British • Terminal 4 • Runways, taxiways
NEWARK-EWR Opening in 1928, it is the nation’s oldest airfield and home to the nation’s first commercial airline terminal. The airport was built on 68 acres of marshland by the City of Newark and quickly became the world’s busiest commercial airport. In fact,
HIWAY | 14
in 1935, Amelia Earhart led the dedication of this landmark terminal building. Newark Liberty has three major terminals: A, B and C. • Newark, NEC Granite Halmar Project
HIWAY | 15
JOHN F. KENNEDY-JFK Initial plans were for a modest 1,000-acre airport, but by the time construction was complete Idlewild Airport had grown to five times that size. Commercial flights began in July 1948. Today, JFK is the nation’s leading international gateway, • American Airlines • Cargo Buildings 77 & 75 • Perishables
with more than 80 airlines operating from its gates. JFK has six operating airline terminals, surrounded by a dual ring of peripheral taxiways. More than 125 aircraft gates serve the terminals. • British • Terminal 4 • Runways, taxiways
NEWARK-EWR Opening in 1928, it is the nation’s oldest airfield and home to the nation’s first commercial airline terminal. The airport was built on 68 acres of marshland by the City of Newark and quickly became the world’s busiest commercial airport. In fact,
HIWAY | 14
in 1935, Amelia Earhart led the dedication of this landmark terminal building. Newark Liberty has three major terminals: A, B and C. • Newark, NEC Granite Halmar Project
HIWAY | 15
HALMAR AVATION ROUND-UP
JOHN F. KENNEDY AIRPORT
Halmar’s aviation projects are punctuated by a decade of work at JFK that spanned most of the1990’s and continued well into the new Millennium. These contracts included a wide range of landside and airside projects on terminals and facilities throughout the airport. Some of these included: JFK Main Runway 13L/31R JFK International Arrivals Terminal 4: • Landside: Construction of terminal roadways, bridges, multi-level parking garage • Airside: aprons and hardstands FK British Airways Terminal 7: • Landside: Civil structural on the terminal, all roads and bridges, 850-car multi-level parking garage, light rail station • Airside: Hardstands for the Concorde American Airlines Terminal 8: • Landside: Civil structural work on the terminal, all roads and bridges and multi-level parking garage • Airside: Aprons and hardstands Building 75 at JFK – Perishables Warehoue Building 77 Multi-Tenant Cargo Facility
HALMAR WORK AT OTHER AIRPORTS Other aviation work include the light rail station at Newark Liberty Airport as well as site work and utilities on the current LaGuardia Redevelopment project.
HIWAY | 16
HIWAY | 17
HALMAR AVATION ROUND-UP
JOHN F. KENNEDY AIRPORT
Halmar’s aviation projects are punctuated by a decade of work at JFK that spanned most of the1990’s and continued well into the new Millennium. These contracts included a wide range of landside and airside projects on terminals and facilities throughout the airport. Some of these included: JFK Main Runway 13L/31R JFK International Arrivals Terminal 4: • Landside: Construction of terminal roadways, bridges, multi-level parking garage • Airside: aprons and hardstands FK British Airways Terminal 7: • Landside: Civil structural on the terminal, all roads and bridges, 850-car multi-level parking garage, light rail station • Airside: Hardstands for the Concorde American Airlines Terminal 8: • Landside: Civil structural work on the terminal, all roads and bridges and multi-level parking garage • Airside: Aprons and hardstands Building 75 at JFK – Perishables Warehoue Building 77 Multi-Tenant Cargo Facility
HALMAR WORK AT OTHER AIRPORTS Other aviation work include the light rail station at Newark Liberty Airport as well as site work and utilities on the current LaGuardia Redevelopment project.
HIWAY | 16
HIWAY | 17
About LaGuardia source: www.laguardia.com
In 2015, LaGuardia handled 28.4 million passengers. The airport also employs 11,000 people and generates more than $15.6 billion to the economy.
LaGuardia Airport Conveniently located eight miles from midtown Manhattan in the borough of Queens, New York, LaGuardia Airport serves millions of people each year. Since 1947, the Port Authority of New York and New Jersey has operated LaGuardia under a lease with New York City. The airport sits on 680 acres, has two 7,000 ft main runways and four terminal buildings that house up to 72 aircraft gates.
Our History Opened in 1939, LaGuardia Airport was built on the site of the old Gala Amusement Park at a cost of $40 million. Once called the Overseas Terminal, and then the Marine Air Terminal, Terminal A was the original airport terminal building, serving international flights throughout the 1940s. In 1995, the terminal was designated a historic landmark. Terminal B, also know as the Central Terminal Building, opened in 1964 followed by Terminals C and D in 1983 and 1992. Today, LaGuardia Airport handles millions of passengers, millions of tons of cargo and is an important economic engine for the New York-New Jersey region. Our Future At just eight miles from midtown Manhattan, LaGuardia Airport is a central, accessible transportation hub for millions of people and goods.
HIWAY | 18
As demand for air travel continues, an extensive redevelopment program is coming to LaGuardia to create world-class airport facilities for passengers and airlines alike. Some of the major improvements include replacing Terminal B, adding more taxiways and passenger walkways to reduce connection delays and enhancing food and retail offerings. To learn more about what’s in store, visit our redevelopment section. Redevelopment A New Airport for New York Governor Andrew M. Cuomo is heralding a new era for LaGuardia Airport. The Governor’s vision is to transform LaGuardia into a world-class transportation hub; to build an airport that is worthy of the State of New York and one that New Yorkers deserve. The comprehensive redesign of LaGuardia
HIWAY | 19
About LaGuardia source: www.laguardia.com
In 2015, LaGuardia handled 28.4 million passengers. The airport also employs 11,000 people and generates more than $15.6 billion to the economy.
LaGuardia Airport Conveniently located eight miles from midtown Manhattan in the borough of Queens, New York, LaGuardia Airport serves millions of people each year. Since 1947, the Port Authority of New York and New Jersey has operated LaGuardia under a lease with New York City. The airport sits on 680 acres, has two 7,000 ft main runways and four terminal buildings that house up to 72 aircraft gates.
Our History Opened in 1939, LaGuardia Airport was built on the site of the old Gala Amusement Park at a cost of $40 million. Once called the Overseas Terminal, and then the Marine Air Terminal, Terminal A was the original airport terminal building, serving international flights throughout the 1940s. In 1995, the terminal was designated a historic landmark. Terminal B, also know as the Central Terminal Building, opened in 1964 followed by Terminals C and D in 1983 and 1992. Today, LaGuardia Airport handles millions of passengers, millions of tons of cargo and is an important economic engine for the New York-New Jersey region. Our Future At just eight miles from midtown Manhattan, LaGuardia Airport is a central, accessible transportation hub for millions of people and goods.
HIWAY | 18
As demand for air travel continues, an extensive redevelopment program is coming to LaGuardia to create world-class airport facilities for passengers and airlines alike. Some of the major improvements include replacing Terminal B, adding more taxiways and passenger walkways to reduce connection delays and enhancing food and retail offerings. To learn more about what’s in store, visit our redevelopment section. Redevelopment A New Airport for New York Governor Andrew M. Cuomo is heralding a new era for LaGuardia Airport. The Governor’s vision is to transform LaGuardia into a world-class transportation hub; to build an airport that is worthy of the State of New York and one that New Yorkers deserve. The comprehensive redesign of LaGuardia
HIWAY | 19
Airport involves transforming LaGuardia into a unified airport with a main terminal, better transportation access with a future air train, more taxiways and best-in-class passenger amenities. “Our plan will fundamentally transform LaGuardia – replacing what is now an outdated and poorly designed complex with the world-class airport New York has always deserved.” Governor Andrew M. Cuomo Construction of the new unified terminal – Terminal B – is expected to be a $4 billion project creating 8,000 direct jobs and 10,000 indirect jobs. LaGuardia Gateway Partners – a consortium company of airport experts – will design, build, manage and maintain LaGuardia’s Terminal B under a 35-year lease agreement with the Port Authority of New York and New Jersey.
From the desk of Governor Andrew M. Cuomo https://www.governor.ny.gov/news/governor-cuomo-unveils-vision-transformative-redesign-laguardia-airport First Half of New Unified Terminal Structure – a $4 Billion Construction Project – to Break Ground in First Part of 2016 Via New Public Private Partnership Negotiated by Port Authority Delta Air Lines Expected to Redevelop Its Terminals – Comprising Second Half of New Unified Terminal Structure – On Parallel
HIWAY | 20
Track with Port Authority Project New Layout Designed to Reduce LaGuardia’s Current Plague of Aircraft Ground Congestion and Gate Delays, and Set Stage for World-Class Passenger Experience Governor Cuomo was joined recently by Vice President Joe Biden to unveil the vision for the comprehensive redesign of LaGuardia Airport. The airport will be transformed into a single, structurally unified main terminal with expanded transportation access, significantly increased taxiway space and best-in-class passenger amenities. Construction on the first half of the new unified terminal, expected to be a $4 billion project that creates 8,000 direct jobs and 10,000 indirect jobs, will be managed by LaGuardia Gateway Partners, a new public private partnership chosen by the Port Authority of New York and New Jersey to build the project Construction on the first half will begin upon final approval from the Board of Directors of the Port Authority of New York and New Jersey. That approval is expected in the first part of 2016; the majority of this first half of the project is expected to open to passengers in 2019, with full completion scheduled for approximately 18 months later. The second half of the new unified terminal is expected to be redeveloped by Delta Air Lines, which has indicated strong support for the new vision, and anticipates beginning the redevelopment of its terminals on a parallel track with the LaGuardia Gateway Partners project to complete the new unified airport. “New York had an aggressive, can-do approach to big infrastructure in the past – and today, we’re moving forward with that attitude once again,” said Governor Cuomo. “We are transforming LaGuardia into a globally-renowned, 21st century airport that is worthy of the city and state of New York. It’s the perfect metaphor for what we can achieve with the ambition and optimism and energy that made this the Empire State
in the first place, and I want to thank our many partners for joining us to build the airport that New York deserves.”. Video of a presentation that details the redesign, led by Dan Tishman, CEO of Tishman Construction Company and Chair of the Governor’s Airport Master Plan Advisory Panel, can be viewed here. Dan Tishman said, “On behalf of the advisory panel, I want to thank the port authority and the port chairman for working with us so professionally, and I want to thank the Governor for his leadership and support. For me, this has been an engaging and rewarding experience. This is our vision – this is Governor Cuomo’s vision – this is reimagining New York.” The recommendation for a single, unified terminal is included in a sweeping LaGuardia redesign, developed by the Governor’s Airport Master Plan Advisory Panel, and released today. The report, which can be viewed here, presents the Panel’s recommendations, which will enable LaGuardia to meet the demands of the 21st century. SINGLE, UNIFIED TERMINAL wLaGuardia’s current terminal layout, comprised of multiple, fragmented terminals (photo here), will be replaced by one main, architecturally unified terminal. This will be accomplished by demolishing the existing Terminal B building, which is operated by the Port Authority, and replacing it with a larger structure, located closer to the Grand Central Parkway, which will include new terminal space and a new Central Arrivals and Departures Hall, and will link to Delta’s Terminals C and D. This represents the western half of the new structurally unified terminal. The eastern half of the new unified terminal will be constructed on a parallel track by Delta Air Lines redeveloping its existing Terminals closer to the Grand Central Parkway
and connecting them to the new Central Arrivals and Departures Hall. Delta Air Lines is strongly supportive of this plan, and will move forward with the Panel’s recommendations in parallel with the construction schedule for the new space and Central Hall. TERMINAL LOCATION & ISLAND-GATES To utilize LaGuardia’s geographic footprint more efficiently, the new terminal facility will be built closer to the Grand Central Parkway. The redesigned facility will also utilize an island-gate system, in which passengers access their gates via raised pedestrian bridges, high enough for aircraft to taxi underneath, which connect back to the main terminal. A rendering of the island-gate system can be viewed here. Together, the relocated terminals and island-gate system will create nearly two miles of new taxiway space. This allows for a more efficient circulation of aircraft and reduced taxi-in and taxi-out times, which will yield shorter and fewer gate delays – a dramatic difference from today’s LaGuardia. In addition, this change will produce overall reduction in carbon emissions from idling aircraft. EXPANDING TRANSPORTATION ACCESS As part of his 2015 Opportunity Agenda,
Governor Cuomo proposed creating an AirTrain option that directly connects LaGuardia to the New York City subway and Long Island Rail Road at Mets-Willets Point Station. The panel supports the Governor’s call for this AirTrain option, and the new LaGuardia’s unified terminal will be designed to incorporate a future AirTrain terminal. The Panel recommends that the airport once again be made accessible by ferry service. The panel also calls for an enhanced road configuration to improve passenger access and reduce traffic on local streets in the airport’s vicinity, including the Grand Central Parkway. The interior of the new unified terminal will also be intuitive for passengers to easily navigate, and will facilitate efficient movement throughout the airport. A transit option to move passengers more quickly within the airport is recommended by the Panel, such as a tram or monorail, to be included as construction moves forward. This transit option would also better integrate the Marine Air Terminal (Terminal A) with the rest of the airport housed in the new unified terminal. IMPROVING PASSENGER EXPERIENCE Taking into account the realities of post9/11 air travel, the Panel recommends that the new unified facility contain additional
space for security check-in, which will help diminish wait times for passengers as they pass through mandatory TSA screening. The facility – both in its individual terminals and the central hall – will also be built with significant height and openness in order to allow for a superior passenger experience, clearer signage, greater use of natural light and overall aesthetic improvements. The central hall will also be designed with space for best-in-class passenger amenities in retail, dining, and business and conference center capabilities, as well as the option to include a 200-room boutique hotel option convenient for travelers. INCREASING STORM RESILIENCY During Superstorm Sandy, approximately 100 million gallons of saltwater flooded the airport and shut it down for two days, impacting 250,000 passengers and causing an estimated economic loss to the region of roughly $108 million. With this in mind, the Panel recommends elevating critical infrastructure in order to keep the airport operational during a flood event and better prepare the airport for similar extreme weather events. SUPPORTING SURROUNDING COMMUNITIES The redesign of LaGuardia is vital to transforming the airport into a 21st century facility and maintaining economic compet-
HIWAY | 21
Airport involves transforming LaGuardia into a unified airport with a main terminal, better transportation access with a future air train, more taxiways and best-in-class passenger amenities. “Our plan will fundamentally transform LaGuardia – replacing what is now an outdated and poorly designed complex with the world-class airport New York has always deserved.” Governor Andrew M. Cuomo Construction of the new unified terminal – Terminal B – is expected to be a $4 billion project creating 8,000 direct jobs and 10,000 indirect jobs. LaGuardia Gateway Partners – a consortium company of airport experts – will design, build, manage and maintain LaGuardia’s Terminal B under a 35-year lease agreement with the Port Authority of New York and New Jersey.
From the desk of Governor Andrew M. Cuomo https://www.governor.ny.gov/news/governor-cuomo-unveils-vision-transformative-redesign-laguardia-airport First Half of New Unified Terminal Structure – a $4 Billion Construction Project – to Break Ground in First Part of 2016 Via New Public Private Partnership Negotiated by Port Authority Delta Air Lines Expected to Redevelop Its Terminals – Comprising Second Half of New Unified Terminal Structure – On Parallel
HIWAY | 20
Track with Port Authority Project New Layout Designed to Reduce LaGuardia’s Current Plague of Aircraft Ground Congestion and Gate Delays, and Set Stage for World-Class Passenger Experience Governor Cuomo was joined recently by Vice President Joe Biden to unveil the vision for the comprehensive redesign of LaGuardia Airport. The airport will be transformed into a single, structurally unified main terminal with expanded transportation access, significantly increased taxiway space and best-in-class passenger amenities. Construction on the first half of the new unified terminal, expected to be a $4 billion project that creates 8,000 direct jobs and 10,000 indirect jobs, will be managed by LaGuardia Gateway Partners, a new public private partnership chosen by the Port Authority of New York and New Jersey to build the project Construction on the first half will begin upon final approval from the Board of Directors of the Port Authority of New York and New Jersey. That approval is expected in the first part of 2016; the majority of this first half of the project is expected to open to passengers in 2019, with full completion scheduled for approximately 18 months later. The second half of the new unified terminal is expected to be redeveloped by Delta Air Lines, which has indicated strong support for the new vision, and anticipates beginning the redevelopment of its terminals on a parallel track with the LaGuardia Gateway Partners project to complete the new unified airport. “New York had an aggressive, can-do approach to big infrastructure in the past – and today, we’re moving forward with that attitude once again,” said Governor Cuomo. “We are transforming LaGuardia into a globally-renowned, 21st century airport that is worthy of the city and state of New York. It’s the perfect metaphor for what we can achieve with the ambition and optimism and energy that made this the Empire State
in the first place, and I want to thank our many partners for joining us to build the airport that New York deserves.”. Video of a presentation that details the redesign, led by Dan Tishman, CEO of Tishman Construction Company and Chair of the Governor’s Airport Master Plan Advisory Panel, can be viewed here. Dan Tishman said, “On behalf of the advisory panel, I want to thank the port authority and the port chairman for working with us so professionally, and I want to thank the Governor for his leadership and support. For me, this has been an engaging and rewarding experience. This is our vision – this is Governor Cuomo’s vision – this is reimagining New York.” The recommendation for a single, unified terminal is included in a sweeping LaGuardia redesign, developed by the Governor’s Airport Master Plan Advisory Panel, and released today. The report, which can be viewed here, presents the Panel’s recommendations, which will enable LaGuardia to meet the demands of the 21st century. SINGLE, UNIFIED TERMINAL wLaGuardia’s current terminal layout, comprised of multiple, fragmented terminals (photo here), will be replaced by one main, architecturally unified terminal. This will be accomplished by demolishing the existing Terminal B building, which is operated by the Port Authority, and replacing it with a larger structure, located closer to the Grand Central Parkway, which will include new terminal space and a new Central Arrivals and Departures Hall, and will link to Delta’s Terminals C and D. This represents the western half of the new structurally unified terminal. The eastern half of the new unified terminal will be constructed on a parallel track by Delta Air Lines redeveloping its existing Terminals closer to the Grand Central Parkway
and connecting them to the new Central Arrivals and Departures Hall. Delta Air Lines is strongly supportive of this plan, and will move forward with the Panel’s recommendations in parallel with the construction schedule for the new space and Central Hall. TERMINAL LOCATION & ISLAND-GATES To utilize LaGuardia’s geographic footprint more efficiently, the new terminal facility will be built closer to the Grand Central Parkway. The redesigned facility will also utilize an island-gate system, in which passengers access their gates via raised pedestrian bridges, high enough for aircraft to taxi underneath, which connect back to the main terminal. A rendering of the island-gate system can be viewed here. Together, the relocated terminals and island-gate system will create nearly two miles of new taxiway space. This allows for a more efficient circulation of aircraft and reduced taxi-in and taxi-out times, which will yield shorter and fewer gate delays – a dramatic difference from today’s LaGuardia. In addition, this change will produce overall reduction in carbon emissions from idling aircraft. EXPANDING TRANSPORTATION ACCESS As part of his 2015 Opportunity Agenda,
Governor Cuomo proposed creating an AirTrain option that directly connects LaGuardia to the New York City subway and Long Island Rail Road at Mets-Willets Point Station. The panel supports the Governor’s call for this AirTrain option, and the new LaGuardia’s unified terminal will be designed to incorporate a future AirTrain terminal. The Panel recommends that the airport once again be made accessible by ferry service. The panel also calls for an enhanced road configuration to improve passenger access and reduce traffic on local streets in the airport’s vicinity, including the Grand Central Parkway. The interior of the new unified terminal will also be intuitive for passengers to easily navigate, and will facilitate efficient movement throughout the airport. A transit option to move passengers more quickly within the airport is recommended by the Panel, such as a tram or monorail, to be included as construction moves forward. This transit option would also better integrate the Marine Air Terminal (Terminal A) with the rest of the airport housed in the new unified terminal. IMPROVING PASSENGER EXPERIENCE Taking into account the realities of post9/11 air travel, the Panel recommends that the new unified facility contain additional
space for security check-in, which will help diminish wait times for passengers as they pass through mandatory TSA screening. The facility – both in its individual terminals and the central hall – will also be built with significant height and openness in order to allow for a superior passenger experience, clearer signage, greater use of natural light and overall aesthetic improvements. The central hall will also be designed with space for best-in-class passenger amenities in retail, dining, and business and conference center capabilities, as well as the option to include a 200-room boutique hotel option convenient for travelers. INCREASING STORM RESILIENCY During Superstorm Sandy, approximately 100 million gallons of saltwater flooded the airport and shut it down for two days, impacting 250,000 passengers and causing an estimated economic loss to the region of roughly $108 million. With this in mind, the Panel recommends elevating critical infrastructure in order to keep the airport operational during a flood event and better prepare the airport for similar extreme weather events. SUPPORTING SURROUNDING COMMUNITIES The redesign of LaGuardia is vital to transforming the airport into a 21st century facility and maintaining economic compet-
HIWAY | 21
Future rendering of LaGuardia Airport’s main terminal, northern Queens, NY itiveness throughout the region – but it is also important for the airport to be a good neighbor to its surrounding communities. Currently, the neighborhoods in the immediate vicinity of LaGuardia experience significant automobile traffic on local roads and the Grand Central Parkway from passengers either parking outside of the airport’s ground or from motorists waiting to pick up passengers from the airport as they arrive. Under the new design plan, the Panel recommends increasing parking options on-site and identifying a location for a cell phone waiting area in order to reduce congestion on local streets. Additionally, the Panel also recommends a new rental car facility be created to concentrate the ten car rental companies that currently serve LaGuardia from multiple dispersed locations, further reducing congestion. The Panel has recommended that the Port Authority will ensure that the project’s employment reflects a broad spectrum of the communities in the region, and should recognize Governor Cuomo’s goal of 30 percent MWBE participation. It will also build on the Port Authority’s longstanding commitment to supporting Airport Concession Disadvantaged Business Enterprises (ADCBE). Currently, LaGuardia contributes more than $16 billion in economic activity to the region
HIWAY | 22
Future rendering of LaGuardia Airport’s redevelopment, northern Queens, NY history while returning it to public use. We want to thank Governor Cuomo for his leadership in supporting our long-held belief that the TWA terminal can viably be restored and re-opened.”
JFK south Queens, NY redevelopment annually, generating about 121,000 total jobs and $5.9 billion in annual wages
UPDATE ON FUTURE WORK AT JFK, STEWART AND REPUBLIC AIRPORTS RFP to be issued for Master Planner for JFK Redesign In addition to the redesign plan for LaGuardia Airport, Governor Cuomo also provided an update on the status of efforts to revolutionize and modernize JFK, Republic and Stewart Airports. JFK International Airport – JFK is one of the few international airports without an on-air-
TWA flight center hotel port hotel. Governor Cuomo announced today the construction of a new state-ofthe-art hotel at JFK in the historic TWA Flight Center, which was designed by world-renowned architect Eero Saarinen. The hotel will include 505 guestrooms, 40,000 square feet of conference, event, and meeting space, and a 10,000 square foot observation deck. The hotel will also be LEED certified. The redevelopment of JFK’s TWA Flight Center Hotel will move forward under a public-private partnership between MCR Development, JetBlue and the Port Authority of New York and New Jersey. The $265 million construction project, which is expected to break ground next year, will generate
3,700 jobs, and is expected to open in 2018. “The TWA Flight Center Hotel will celebrate and preserve Eero Saarinen’s masterpiece, returning the landmark to its original glory and reopening it to the public,” said Tyler Morse, CEO of MCR Development, the New York-based developer responsible for the TWA Flight Center redevelopment plan. “The TWA Flight Center Hotel will be an economic engine and a world-class airport hotel, creating approximately 3,700 construction and permanent jobs, 505 new hotel rooms, and 40,000 square feet of meeting space at JFK. Whether staying the night or simply exploring, international visitors and New Yorkers alike will be able to experience
the magic of the Jet Age in this extraordinary mid-century icon. We are proud to play a part in Governor Cuomo’s effort to revitalize New York’s airports for generations to come, and we look forward to working with all of the carriers at JFK to realize this vision.” “We are thrilled the TWA Flight Center will come alive again,” said Rich Smyth, Vice President of Corporate Real Estate, JetBlue. “Saarinen’s aviation icon sits at the front door of our flagship T5 terminal, offering exciting collaboration opportunities that will benefit our customers and crewmembers. As New York’s Hometown Airline, we are proud to be a minority investor in MCR’s plan, which celebrates the landmark’s rich
The Governor also announced today plans to move forward to develop a full master plan for future development at JFK airport. The Governor has directed the Advisory Panel to report back in the next twelve months with its recommendations for an implementable master plan for the development of a 21st century JKF International Airport. Within the next 60 days, the Panel will work with the Port Authority to issue an RFP to retain a master planning firm to advise the Governor, the Panel, and the Port Authority on the future development of the airport. New RFIs for Republic & Stewart – Empire State Development has issued new RFIs with a primary focus on enhancing the regional economic activity at both Republic and Stewart International airports. Specific sites have been identified for future development, and ESD will guide the development of these sites via a new real estate broker: Newmark Knight Grubb Frank.
HIWAY | 23
Future rendering of LaGuardia Airport’s main terminal, northern Queens, NY itiveness throughout the region – but it is also important for the airport to be a good neighbor to its surrounding communities. Currently, the neighborhoods in the immediate vicinity of LaGuardia experience significant automobile traffic on local roads and the Grand Central Parkway from passengers either parking outside of the airport’s ground or from motorists waiting to pick up passengers from the airport as they arrive. Under the new design plan, the Panel recommends increasing parking options on-site and identifying a location for a cell phone waiting area in order to reduce congestion on local streets. Additionally, the Panel also recommends a new rental car facility be created to concentrate the ten car rental companies that currently serve LaGuardia from multiple dispersed locations, further reducing congestion. The Panel has recommended that the Port Authority will ensure that the project’s employment reflects a broad spectrum of the communities in the region, and should recognize Governor Cuomo’s goal of 30 percent MWBE participation. It will also build on the Port Authority’s longstanding commitment to supporting Airport Concession Disadvantaged Business Enterprises (ADCBE). Currently, LaGuardia contributes more than $16 billion in economic activity to the region
HIWAY | 22
Future rendering of LaGuardia Airport’s redevelopment, northern Queens, NY history while returning it to public use. We want to thank Governor Cuomo for his leadership in supporting our long-held belief that the TWA terminal can viably be restored and re-opened.”
JFK south Queens, NY redevelopment annually, generating about 121,000 total jobs and $5.9 billion in annual wages
UPDATE ON FUTURE WORK AT JFK, STEWART AND REPUBLIC AIRPORTS RFP to be issued for Master Planner for JFK Redesign In addition to the redesign plan for LaGuardia Airport, Governor Cuomo also provided an update on the status of efforts to revolutionize and modernize JFK, Republic and Stewart Airports. JFK International Airport – JFK is one of the few international airports without an on-air-
TWA flight center hotel port hotel. Governor Cuomo announced today the construction of a new state-ofthe-art hotel at JFK in the historic TWA Flight Center, which was designed by world-renowned architect Eero Saarinen. The hotel will include 505 guestrooms, 40,000 square feet of conference, event, and meeting space, and a 10,000 square foot observation deck. The hotel will also be LEED certified. The redevelopment of JFK’s TWA Flight Center Hotel will move forward under a public-private partnership between MCR Development, JetBlue and the Port Authority of New York and New Jersey. The $265 million construction project, which is expected to break ground next year, will generate
3,700 jobs, and is expected to open in 2018. “The TWA Flight Center Hotel will celebrate and preserve Eero Saarinen’s masterpiece, returning the landmark to its original glory and reopening it to the public,” said Tyler Morse, CEO of MCR Development, the New York-based developer responsible for the TWA Flight Center redevelopment plan. “The TWA Flight Center Hotel will be an economic engine and a world-class airport hotel, creating approximately 3,700 construction and permanent jobs, 505 new hotel rooms, and 40,000 square feet of meeting space at JFK. Whether staying the night or simply exploring, international visitors and New Yorkers alike will be able to experience
the magic of the Jet Age in this extraordinary mid-century icon. We are proud to play a part in Governor Cuomo’s effort to revitalize New York’s airports for generations to come, and we look forward to working with all of the carriers at JFK to realize this vision.” “We are thrilled the TWA Flight Center will come alive again,” said Rich Smyth, Vice President of Corporate Real Estate, JetBlue. “Saarinen’s aviation icon sits at the front door of our flagship T5 terminal, offering exciting collaboration opportunities that will benefit our customers and crewmembers. As New York’s Hometown Airline, we are proud to be a minority investor in MCR’s plan, which celebrates the landmark’s rich
The Governor also announced today plans to move forward to develop a full master plan for future development at JFK airport. The Governor has directed the Advisory Panel to report back in the next twelve months with its recommendations for an implementable master plan for the development of a 21st century JKF International Airport. Within the next 60 days, the Panel will work with the Port Authority to issue an RFP to retain a master planning firm to advise the Governor, the Panel, and the Port Authority on the future development of the airport. New RFIs for Republic & Stewart – Empire State Development has issued new RFIs with a primary focus on enhancing the regional economic activity at both Republic and Stewart International airports. Specific sites have been identified for future development, and ESD will guide the development of these sites via a new real estate broker: Newmark Knight Grubb Frank.
HIWAY | 23
Innovations in Construction Technology 3D Concrete printing
The world’s first 3D-printed hotel suite is located in the Philippines. Sources: https://3dprint.com/137655/3d-printing-concrete-expand-2021/ and https://futurism.com/hotel-3d-printed-sand-volcanic-ash/ Photo Credit: Rudenko HIWAY | Anthony 24
Construction is one of the main areas 3D printing has been projected to impact substantially, all along. It also tends to be the example of choice for critics asking what happened to all those lofty architectural plans that have yet to be seen on the ground. There aren’t 3D printers in every home yet, and few of us are living in 3D printed homes or working in 3D printed office buildings despite some far-out concepts, as well as compelling international models actually coming to fruition. So is this thing really on or what?
will transform construction with a material that’s undoubtedly familiar to us all. The question isn’t whether concrete 3D printing will begin to play a large role in the construction industry, but just when and how much. Due to the benefits offered, one would imagine many in the business are scrambling to know more and figure out how they can take advantage of the new technology as it offers major savings on the bottom line, greater speed and accuracy, and will be attractive to consumers looking to buy more affordable real estate in the future.
While other sectors such as automotive, aerospace, and medical are showing huge strides, in the construction arena we’ve The study focused on what the future seen slower progress, but it’s definitely been market size is for this technology and mathere, even if just in baby steps, and much terials in construction, along with the true of these have involved building a foundation potential for growth as they examined the of impact that begins following: with the tools and mate•Product type rials. They are definitely The study shows that •Concrete type emerging, from 3D print•Software many construction ers that can make bricks •End-use companies are to drones that function •Regions as self-sustained mini and will be using construction factories. The time period they While some of this is still concrete 3D printing, examined, from 2015fantastical, the progress 2021, allows for a look and that it has also is undeniably quite subat how construction will been growing in stantial—and we see nupropel the growth of 3D direct accordance merous large delta style printing, beginning with 3D printers emerging too with the industry studying vendors and for construction, even their revenues. overall, around the playing a part in some amazing projects which “The bottom-up proceworld. may just be one-offs dure was employed to so far, but they do also arrive at the overall size answer the question with a resounding “yes, of the global 3D concrete printing market 3D printing in construction is so on.” from the revenue of the key players,” states Research and Markets. Materials, of course, are at the crux of this conversation. Perhaps we have the plans They assessed market size and then moved and the tools and are ready to erect buildon to dividing it into different segments and ings galore—but with what? Why, concrete, subsegments, further studied and verified of course. And just how this is and will be with numerous, comprehensive interviews done is the major focus of a recent study with the higher-ups in many companies, to by Research and Markets as they look at include CEOs and executives. the what, when, and where for concrete 3D printing in 3D Concrete Printing Mar“These data triangulation and market ket By Product Type, by Concrete Type, by breakdown procedures were employed to Software, by End-Use Sector & by Region – complete the overall market engineering Forecast to 2021. process and arrive at the exact statistics for all segments and subsegments,” states the Research and Markets, a research and Research and Markets team. analysis company that offers resources to companies and investors around the world, Following are some of the 3D concrete is offering their take on how 3D printing printer manufacturers, architects, contrac-
tors, and vendors they see making up the ecosystem: •DUS Architects (The Netherlands) •Skanska (Sweden) •Fosters + Partners (U.K.) •WinSun Global (China) •Sika (Europe) •LafargeHolcim (Europe) •Balfour Beatty (U.K.) •Carilliom Plc (U.K.) The study shows that many construction companies are and will be using concrete 3D printing, and that it has also been growing in direct accordance with the industry overall, around the world. As industrialization increases, along with further urbanization, this leads to expanded building of a wide range of structures around the world. The research divides the 3D concrete printing market into the following submarkets: Product Type: •Walls •Floors and roofs •Panels and lintels •Others (staircases and paving slabs) By concrete type: •Ready-mix concrete •Precast concrete •Shotcrete •High-density concrete •Others (lightweight concrete, limecrete, and stamped concrete) By Software: •Design •Inspection •Printing By End-Use Sector: •Architectural construction •Industrial construction •Domestic construction •Residential •Commercial •Others (sports, education, and healthcare) By Region: •North America •Europe •Asia-Pacific •RoW (UAE and other countries in RoW) The Research and Markets team believes that as the global economy continues to recover, further demand can be expected HIWAY | 25
Innovations in Construction Technology 3D Concrete printing
The world’s first 3D-printed hotel suite is located in the Philippines. Sources: https://3dprint.com/137655/3d-printing-concrete-expand-2021/ and https://futurism.com/hotel-3d-printed-sand-volcanic-ash/ Photo Credit: Rudenko HIWAY | Anthony 24
Construction is one of the main areas 3D printing has been projected to impact substantially, all along. It also tends to be the example of choice for critics asking what happened to all those lofty architectural plans that have yet to be seen on the ground. There aren’t 3D printers in every home yet, and few of us are living in 3D printed homes or working in 3D printed office buildings despite some far-out concepts, as well as compelling international models actually coming to fruition. So is this thing really on or what?
will transform construction with a material that’s undoubtedly familiar to us all. The question isn’t whether concrete 3D printing will begin to play a large role in the construction industry, but just when and how much. Due to the benefits offered, one would imagine many in the business are scrambling to know more and figure out how they can take advantage of the new technology as it offers major savings on the bottom line, greater speed and accuracy, and will be attractive to consumers looking to buy more affordable real estate in the future.
While other sectors such as automotive, aerospace, and medical are showing huge strides, in the construction arena we’ve The study focused on what the future seen slower progress, but it’s definitely been market size is for this technology and mathere, even if just in baby steps, and much terials in construction, along with the true of these have involved building a foundation potential for growth as they examined the of impact that begins following: with the tools and mate•Product type rials. They are definitely The study shows that •Concrete type emerging, from 3D print•Software many construction ers that can make bricks •End-use companies are to drones that function •Regions as self-sustained mini and will be using construction factories. The time period they While some of this is still concrete 3D printing, examined, from 2015fantastical, the progress 2021, allows for a look and that it has also is undeniably quite subat how construction will been growing in stantial—and we see nupropel the growth of 3D direct accordance merous large delta style printing, beginning with 3D printers emerging too with the industry studying vendors and for construction, even their revenues. overall, around the playing a part in some amazing projects which “The bottom-up proceworld. may just be one-offs dure was employed to so far, but they do also arrive at the overall size answer the question with a resounding “yes, of the global 3D concrete printing market 3D printing in construction is so on.” from the revenue of the key players,” states Research and Markets. Materials, of course, are at the crux of this conversation. Perhaps we have the plans They assessed market size and then moved and the tools and are ready to erect buildon to dividing it into different segments and ings galore—but with what? Why, concrete, subsegments, further studied and verified of course. And just how this is and will be with numerous, comprehensive interviews done is the major focus of a recent study with the higher-ups in many companies, to by Research and Markets as they look at include CEOs and executives. the what, when, and where for concrete 3D printing in 3D Concrete Printing Mar“These data triangulation and market ket By Product Type, by Concrete Type, by breakdown procedures were employed to Software, by End-Use Sector & by Region – complete the overall market engineering Forecast to 2021. process and arrive at the exact statistics for all segments and subsegments,” states the Research and Markets, a research and Research and Markets team. analysis company that offers resources to companies and investors around the world, Following are some of the 3D concrete is offering their take on how 3D printing printer manufacturers, architects, contrac-
tors, and vendors they see making up the ecosystem: •DUS Architects (The Netherlands) •Skanska (Sweden) •Fosters + Partners (U.K.) •WinSun Global (China) •Sika (Europe) •LafargeHolcim (Europe) •Balfour Beatty (U.K.) •Carilliom Plc (U.K.) The study shows that many construction companies are and will be using concrete 3D printing, and that it has also been growing in direct accordance with the industry overall, around the world. As industrialization increases, along with further urbanization, this leads to expanded building of a wide range of structures around the world. The research divides the 3D concrete printing market into the following submarkets: Product Type: •Walls •Floors and roofs •Panels and lintels •Others (staircases and paving slabs) By concrete type: •Ready-mix concrete •Precast concrete •Shotcrete •High-density concrete •Others (lightweight concrete, limecrete, and stamped concrete) By Software: •Design •Inspection •Printing By End-Use Sector: •Architectural construction •Industrial construction •Domestic construction •Residential •Commercial •Others (sports, education, and healthcare) By Region: •North America •Europe •Asia-Pacific •RoW (UAE and other countries in RoW) The Research and Markets team believes that as the global economy continues to recover, further demand can be expected HIWAY | 25
HALMAR EQUIPMENT FROM THE YARD
Accordning to a NY Times article published on August 17th, 2016 “The Obama administration on Tuesday issued aggressive new emissions standards for heavy-duty trucks. The rules are expected to achieve better fuel efficiency and a bigger cut in pollution than the version that was first proposed last year. Officials said the new standards would require up to a 25 percent reduction in carbon emissions for big tractor-trailers over the next 10 years, and somewhat smaller improvements for delivery trucks, school buses and other large vehicles. Over all, administration officials said the new rules would cut 1.1 billion metric tons of carbon emissions through 2027 and represent a global benchmark for reducing vehicle-exhaust pollutants linked to climate change. The carbon-reduction target is 10 percent more than when the rules were proposed last year, and was made tougher after a public comment period.” (http://www.nytimes.com/2016/08/17/business/ energy-environment/epa-truck-emission-sta dards.html?_r=1)
for 3D printing and specifically that with concrete, leading to a market projected to be worth $56.4 million by 2021. Leading the pack will be Asia Pacific. The research company sees this region as growing the fastest, offering the biggest demand, and being open to the use of the technology and materials. High incomes with disposable cash will obviously propel 3D printing with concrete in construction along. Not surprisingly, China is expected to be the fastest growing country for the use of 3D printing with concrete from a global perspective,
HIWAY | 26
with all the elements in place: government interest and encouragement, standardization efforts, growing need, developing technologies, and, of course, an awareness of the new tools, materials and all the benefits that can be found in using them. Obvious obstacles to be considered are that of the amount of investment capital this technology can require—not to mention research and development—along with understanding how to use the hardware and put automation techniques into motion.
The study was meant to answer questions for stakeholders and potential investors, allowing them to understand which markets should be focused on for ‘prioritizing efforts and investments.’ The target audience for the reports includes raw materials suppliers, 3D concrete printing manufacturers, equipment manufacturers, real-estate agents, consulting firms, and more. For more information on this study, see Research and Markets. Discuss further in the 3D Concrete Printing Industry forum over at 3DPB.com.
As new emission requirements come into play within our industry, it is now critical to either add Diesel Exhaust Fluid (DEF) or Regenerate the Diesel Particulate Filter (DPF). We are finding that a great many of our operators and even superintendents do not understand or are not even aware of having to do so with the
newer machines. In order to get a get acclimated with this change in our industry we would like to implement and ‘Operator Awareness’ or vendor led instructional demonstration on the importance of and procedure to comply to these requirements in an effort to eliminate potential and unnecessary downtime. Acronyms Defined (Courtesy of Wikipedia): A diesel particulate filter (or DPF) is a device designed to remove diesel particulate matter or soot from the exhaust gas of a diesel engine. Wallflow diesel particulate filters usually remove 85% or more of the soot, and under certain conditions can attain soot removal efficiencies approaching 100%. Some filters are single-use, intended for disposal and replacement once full of accumulated ash. Diesel Exhaust Fluid (DEF), is a solution made from 67.5% purified water and 32.5 percent automotive-grade urea that serves as a carrying agent for the ammonia needed to reduce nitrogen oxide (NOx) emissions from diesel engines. When DEF is injected into the engine exhaust gas, downstream of the DPF, it will be rapidly hydrolyzed producing the oxidizing ammonia needed by the SCR catalyst to complete NOx emissions reductions. DEF begins to freeze at 12 degrees Fahrenheit (-11 degrees Celsius), manufacturers are incorporating a heating system to prevent this.
SMALL TOOL TRACKING Small tool tracking is an issue on any jobsite in the construction industry. It is a challenge that will be met with aggressive measure to ensure more control in the future. We will be looking into updating our tracking/ maintenance systems for small tools in the coming year. We are currently looking into various GPS and RFID tracking systems to help simplify and regulate small equipment purchases between projects.
HIWAY | 27
HALMAR EQUIPMENT FROM THE YARD
Accordning to a NY Times article published on August 17th, 2016 “The Obama administration on Tuesday issued aggressive new emissions standards for heavy-duty trucks. The rules are expected to achieve better fuel efficiency and a bigger cut in pollution than the version that was first proposed last year. Officials said the new standards would require up to a 25 percent reduction in carbon emissions for big tractor-trailers over the next 10 years, and somewhat smaller improvements for delivery trucks, school buses and other large vehicles. Over all, administration officials said the new rules would cut 1.1 billion metric tons of carbon emissions through 2027 and represent a global benchmark for reducing vehicle-exhaust pollutants linked to climate change. The carbon-reduction target is 10 percent more than when the rules were proposed last year, and was made tougher after a public comment period.” (http://www.nytimes.com/2016/08/17/business/ energy-environment/epa-truck-emission-sta dards.html?_r=1)
for 3D printing and specifically that with concrete, leading to a market projected to be worth $56.4 million by 2021. Leading the pack will be Asia Pacific. The research company sees this region as growing the fastest, offering the biggest demand, and being open to the use of the technology and materials. High incomes with disposable cash will obviously propel 3D printing with concrete in construction along. Not surprisingly, China is expected to be the fastest growing country for the use of 3D printing with concrete from a global perspective,
HIWAY | 26
with all the elements in place: government interest and encouragement, standardization efforts, growing need, developing technologies, and, of course, an awareness of the new tools, materials and all the benefits that can be found in using them. Obvious obstacles to be considered are that of the amount of investment capital this technology can require—not to mention research and development—along with understanding how to use the hardware and put automation techniques into motion.
The study was meant to answer questions for stakeholders and potential investors, allowing them to understand which markets should be focused on for ‘prioritizing efforts and investments.’ The target audience for the reports includes raw materials suppliers, 3D concrete printing manufacturers, equipment manufacturers, real-estate agents, consulting firms, and more. For more information on this study, see Research and Markets. Discuss further in the 3D Concrete Printing Industry forum over at 3DPB.com.
As new emission requirements come into play within our industry, it is now critical to either add Diesel Exhaust Fluid (DEF) or Regenerate the Diesel Particulate Filter (DPF). We are finding that a great many of our operators and even superintendents do not understand or are not even aware of having to do so with the
newer machines. In order to get a get acclimated with this change in our industry we would like to implement and ‘Operator Awareness’ or vendor led instructional demonstration on the importance of and procedure to comply to these requirements in an effort to eliminate potential and unnecessary downtime. Acronyms Defined (Courtesy of Wikipedia): A diesel particulate filter (or DPF) is a device designed to remove diesel particulate matter or soot from the exhaust gas of a diesel engine. Wallflow diesel particulate filters usually remove 85% or more of the soot, and under certain conditions can attain soot removal efficiencies approaching 100%. Some filters are single-use, intended for disposal and replacement once full of accumulated ash. Diesel Exhaust Fluid (DEF), is a solution made from 67.5% purified water and 32.5 percent automotive-grade urea that serves as a carrying agent for the ammonia needed to reduce nitrogen oxide (NOx) emissions from diesel engines. When DEF is injected into the engine exhaust gas, downstream of the DPF, it will be rapidly hydrolyzed producing the oxidizing ammonia needed by the SCR catalyst to complete NOx emissions reductions. DEF begins to freeze at 12 degrees Fahrenheit (-11 degrees Celsius), manufacturers are incorporating a heating system to prevent this.
SMALL TOOL TRACKING Small tool tracking is an issue on any jobsite in the construction industry. It is a challenge that will be met with aggressive measure to ensure more control in the future. We will be looking into updating our tracking/ maintenance systems for small tools in the coming year. We are currently looking into various GPS and RFID tracking systems to help simplify and regulate small equipment purchases between projects.
HIWAY | 27
AIRPORT PORTFOLIO
Past and Current Project involving airports.
JFK Runway 13/33
JFK American Airlines Terminal 8
JFK British Airways Terminal 7 Ramp
JFK British Airways Terminal 7
JFK British Airways Terminal 7 Light Rail Station
LaGuardia Airport
LaGuardia Airport Redevelopment
HIWAY | 28
Newark Airport Monorail/Light Rail Station
JFK Terminal 7
HIWAY | 29
AIRPORT PORTFOLIO
Past and Current Project involving airports.
JFK Runway 13/33
JFK American Airlines Terminal 8
JFK British Airways Terminal 7 Ramp
JFK British Airways Terminal 7
JFK British Airways Terminal 7 Light Rail Station
LaGuardia Airport
LaGuardia Airport Redevelopment
HIWAY | 28
Newark Airport Monorail/Light Rail Station
JFK Terminal 7
HIWAY | 29
JFK American Airlines Terminal 8 Hardstands
JFK British Airways Terminal 7 Hardstands
JFK International Arrivals Terminal 4
JFK Perishables Warehouse
JFK American Airlines Terminal 8 Ramp
JFK American Airlines Terminal 8
LaGuardia Airport Redevelopment
JFK Perishables Warehouse
JFK Terminal 7 Parking Garage
JFK American Airlines Terminal 8 Hardstands
HIWAY | 30
JFK Terminal 4 Parking Garage JFK International Arrivals Terminal 4
HIWAY | 31
JFK American Airlines Terminal 8 Hardstands
JFK British Airways Terminal 7 Hardstands
JFK International Arrivals Terminal 4
JFK Perishables Warehouse
JFK American Airlines Terminal 8 Ramp
JFK American Airlines Terminal 8
LaGuardia Airport Redevelopment
JFK Perishables Warehouse
JFK Terminal 7 Parking Garage
JFK American Airlines Terminal 8 Hardstands
HIWAY | 30
JFK Terminal 4 Parking Garage JFK International Arrivals Terminal 4
HIWAY | 31
HALMAR SOCIAL HALLOWEENFUN
NEWHIRES • • • •
Alberto Tedeschi Shea Ferguson Patrick Quarry Michael Sullivan
• • • • •
INTERNS Iam Power David Verdis Christina Gonzales Kade Stacy Alexandra Sims
NEWARRIVALS
Jackson Patrick Martin, born 12:55 AM 10/13/16. Mom and baby Kevin and Katelyn Martin are doing great.
HALMARSWAG
WHERE IN THE WORLD IS...HALMAR? We know you’ve got it, now it’s time to flaunt it! We want your best swag photos, it may even earn you more swag. Rules: Keep it clean, be safe, and we don’t want swag photos from Interpol, so no law breaking please...that’s bad publicity. SO WEAR IT PROUD! Send all photo via email to Kim Begonja at kbegonja@halmarinternational.com with your name and location(s). Left to right: Lorraine, Michelle, Sharon, Kristan, Tiffany, Heroshne, Lubia, Jamie, Rebecca and Richard.
SEPARATED AT BIRTH Lubia Donis
Kim Begonja
George Lopez Actor
HIWAY | 32
Raul Arguello
Stephen Colbert Entertainer
Jesse Jameson
Bill Rode
Matt Vanagas
Nick Vanier HIWAY | 33
HALMAR SOCIAL HALLOWEENFUN
NEWHIRES • • • •
Alberto Tedeschi Shea Ferguson Patrick Quarry Michael Sullivan
• • • • •
INTERNS Iam Power David Verdis Christina Gonzales Kade Stacy Alexandra Sims
NEWARRIVALS
Jackson Patrick Martin, born 12:55 AM 10/13/16. Mom and baby Kevin and Katelyn Martin are doing great.
HALMARSWAG
WHERE IN THE WORLD IS...HALMAR? We know you’ve got it, now it’s time to flaunt it! We want your best swag photos, it may even earn you more swag. Rules: Keep it clean, be safe, and we don’t want swag photos from Interpol, so no law breaking please...that’s bad publicity. SO WEAR IT PROUD! Send all photo via email to Kim Begonja at kbegonja@halmarinternational.com with your name and location(s). Left to right: Lorraine, Michelle, Sharon, Kristan, Tiffany, Heroshne, Lubia, Jamie, Rebecca and Richard.
SEPARATED AT BIRTH Lubia Donis
Kim Begonja
George Lopez Actor
HIWAY | 32
Raul Arguello
Stephen Colbert Entertainer
Jesse Jameson
Bill Rode
Matt Vanagas
Nick Vanier HIWAY | 33
HALMAR SPORTS
Halmar’s invovement in community and the tri-state area.
Halmar Racing Just completing its second year as a Halmar Race team, our drivers and their dedicated crew have put Halmar Racing on the map in a big way catapulting to the top team in the northeast with a 59 top 10 finishing record and an Eastern States win for Steward Friesen. In addition to our home track Orange County Speedway, the team has done their laps at places like Accord, Susquehanna and Bridgeport Speedways.
For the third straight year (fifth time in the last seven years), Stewart Friesen won the big-block modified race at Super DIRT Week at Oswego Speedway beating tight competition in Brett Hearn. Friesen has also finished in the top 20 is three of the 5 Nascar Camping World series races he has raced!
Stewart Friesen - 44
HIWAY | 34
HIWAY | 35
HALMAR SPORTS
Halmar’s invovement in community and the tri-state area.
Halmar Racing Just completing its second year as a Halmar Race team, our drivers and their dedicated crew have put Halmar Racing on the map in a big way catapulting to the top team in the northeast with a 59 top 10 finishing record and an Eastern States win for Steward Friesen. In addition to our home track Orange County Speedway, the team has done their laps at places like Accord, Susquehanna and Bridgeport Speedways.
For the third straight year (fifth time in the last seven years), Stewart Friesen won the big-block modified race at Super DIRT Week at Oswego Speedway beating tight competition in Brett Hearn. Friesen has also finished in the top 20 is three of the 5 Nascar Camping World series races he has raced!
Stewart Friesen - 44
HIWAY | 34
HIWAY | 35
HIWAY | 36
HALMAR INTERNATIONAL LLC 421 East Route 59 • Nanuet, NY 10954 TEL: 845-735-3511 • www.halmarinternational.com
