COLOR-STREAM® TECHNOLOGY

COLOR-STREAM TECHNOLOGY FOR HIGH SPEED COMMUNICATION

AVANT-GARDE ENGINEERING

COLOR-STREAM® is the latest, futureproof GVA Lighting Technology and Product Platform. Based on a new method of delivering power/ controlling LEDs, COLOR-STREAM® combines extreme speed of communication, super-fine dimming, exceptional refresh rate, higher pixel resolution, in-field or remote control of power settings and firmware updates with extreme levels of system surge and thermal protections.

COLOR-STREAM® is the result of avant-garde engineering by GVA Lighting and provides lighting designers and electrical engineers exceptional performance and outstanding flexibility for the most challenging projects.

PRODUCTS PLATFORM INCLUDES THE FOLLOWING PRODUCTS: HL-GEN4 Series STR10 Series FL-GEN2 Series PIXEL-TW-GEN2 PDC-GEN5

SUPER-SPEED COMMUNICATION PROTOCOL Communication speed of 6.25Mbps 16X faster than DMX512

SUPPORTS ALL MAJOR COMMUNICATION PROTOCOLS COLOR-STREAM® products powered by Power-Data Connector PDC-GEN5 support all major input data protocols: ARTNET/sACN-RJ45, DMX-512A, DALI/DALI 2, 0~10V

CONTROL 64 DMX UNIVERSES CONTROLLED BY ONE PDC-GEN5 Power-Data Convertor PDC-GEN5 can control up to 64 DMX Universes or 32 Universes per channel

HIGH LINEAR CONTROLLABLE PIXEL RESOLUTION Down to 75 mm (3 in) for HL-GEN4 MONO Down to 150 mm (6 in) for HL-GEN4 RGBW/DWT Down to 100 mm (4 in) for STR10 MONO Down to 150 mm (6 in) for STR10 RGBW/DWT

MULTIPLE LUMINAIRE’S POWER CALIBRATIONS Luminaires can be re-calibrated in the field for different power outputs (e.g. 2W or 5W) without sacrifice in dimming resolution (up to 4,096 steps)

FINE DIMMING, LIQUID SMOOTH TRANSITIONS AND EFFECTS 16X SMOOTHER THAN DMX Up to 4,096 micro-steps of brightness resolution by 12-bit dimming

FLICKER - FREE DIMMING RANGE 40kHz equivalent dimming frequency guarantees flicker-free lighting for human eye and high-speed video cameras.

Flicker free dimming range from 100% to 0.2% with an absolute minimum dimming level of 0.02%

NO AUDIBLE NOISE No audible noise in full dimming range

CONFIGURABLE DIMMING CURVES Configurable exponential dimming curve matches the human eye’s perceived changes in brightness

100 METERS (328 FT) LONG LEADER / JUMPER CABLES COLOR-STREAM® supports very long leader and jumper cables without losing signal integrity or adding voltage drop (INFINITY® Technology)

CONNECTIVITY Freely combine MONO, DWT or RGBW luminaires in a single line Interconnectable product families HL-GEN4, STR10, FL-GEN2, PIXEL-TW-GEN2

EXTREME SYSTEM SURGE PROTECTION Extreme system surge protection of up to 20kV/10kA with a standard setting for 6kV/3kA for surge /lightning sensitive areas and applications

IMPROVED THERMAL PROTECTION Improved protection from overheating in extreme climates

INFINITY® GOES EVEN LONGER New Extended Single Lighting Circuit Lengths: Up to 684 meters (2,244 ft) of HL-GEN4 MONO luminaires Up to 600 meters (1,968 ft) of HL-GEN4 RGBW or HL-GEN4 DWT luminaires
