DYNA-CORER

FAST AND DISCRETE MICRO-CORING FOR YEAR-ROUND AERATION

Aeration is vital for healthy turf; reducing compaction and allowing air, water and nutrients to reach the root zone. However, hollow coring can be slow and labour intensive; it disrupts play and disturbs the playing surface.

The innovative Dyna-Corers enable you to aerate your greens throughout the season with their micro-coring process.

The micro tines of the Dyna-Corers remove thousands of tiny core plugs, producing small neat holes, closely spaced for minimal disturbance to the playing surface.

Coring depth can be precisely adjusted down to a maximum of 25mm. A range of interchangeable tine options include cross tines for decompacting hard areas, needle tines, and slitting blades. Quickly fitted to your triplex, the Dyna-Corers have a working width of 1.5 metres. Their rapid action enables you to micro-core a green in minutes, minimising disruption to play.

The integral core-scraper effectively sweeps the plugs to the edge of the green for removal. Then just a quick blow or brush and your green is ready for play.

Micro tines effectively remove thousands of tiny core plugs

Interchangeable tine options:

Hollow: 11mm or 9.5mm.

Solid: 5mm or 9.5mm.

Cross for de-compacting hard areas.

Slicing blades for continuous or interrupted slits

• Minimal surface disturbance –no disruption to play

• Working width of 1.5 meters to micro-core a whole course in just a few hours

• Coring depth can be precisely adjusted down to 25mm

• Prevents surface sealing to enable air and water to reach the root zone

• Regularly remove thatch all year round, even in dry weather

• Quickly attach to your triplex for discrete coring

“

One of those pieces of equipment that comes available every few years and is “Wow!” and it changes the way you maintain your greens.”

0113 267 7000 info@greentek.uk.com

Can be fitted with spiking blades or slicing blades which give a continuous slit

Power Spiking To Relieve Compacted Surfaces Perfectly Clean Greens In Minimum Time

When golf greens become hard in summer drought conditions, even sarel rollers struggle to penetrate deep enough to enable air, water, and wetting agents to penetrate the root zone.

Dyna-Spikers are the solution. Using a powered, vibratory action, their spiking or slicing blades are driven through even the hardest surfaces and deep into the root zone.

Adjustable to a maximum depth of 35mm and fitted to your triplex in minutes, the 1.5 metre working width means you can get superior aeration across all your greens and tees in only a few hours.

That’s fast and effective aeration and the minimum of disruption to playing surfaces. No need to close the greens, and surfaces are immediately playable.

“ Nothing else penetrates as deep without using a tractor mounted implement.”

• Penetrates when even sarel rollers can struggle to work

• Use year round and leave immediately playable surfaces

• 1.5 metre working width allows superior aeration of greens and tees in only a few hours

• Control the depth of spike down to 35mm

• Fitted to your triplex in minutes

• Star spike or slice to get the aeration you want

When you want to disperse worm-casts and collect other loose debris from greens, tees, surrounds and approaches, Dyna-Brushes are in a league of their own.

The reverse-drive gearbox rotates the brushes the opposite way to the direction of travel, effectively flicking-up aeration cores, as well as stubborn debris like leaves or pine needles, collecting them all in the dedicated collection boxes.

The contra-rotating brushing action also stands the sward up before mowing to give a much cleaner cut.

Fitted in minutes to your triplex, the three DynaBrush units cover a width of 1.5 metres which means you can brush at the same speed as you would mow, covering a green in minutes and the whole course in a few hours.

Dyna-Brushes deliver a whole new level of finesse to your greens presentation.

• Excellent for greens, tees surrounds and approaches

• Sweeps up mini-cores and stubborn debris like leaves and pine needles, leaving an immediately playable surface

• Contra-rotating action stands up the grass sward for a cleaner cut when mowing

• Fitted to your triplex in minutes

“ Very impressed with the Dyna Brush - it worked wonders, standing up the grass and cleaning out the sward.”

“ They collected the Dyna-Corer’s cores, even though they were very wet - amazing!”
