Design Portfolio 2022 Eli Gilmore

PRODUCED BY AN AUTODESK STUDENT VERSION

134

134 3

1343

133

1344

NORTH

133

134

133

NEW ASPHALT DRIVE

134

WATERSHED #1

133

1338

WATERSHED #2

134

36 37 13

134

43 42

1337

8 7

133

134

1337

NORTH

133

1336

133

1335

13 41

1344

134

SIN

134

1345

134

1339

133

1344

133

1340

STRIP DRAIN TO BIORETENTION BASIN #1

40 13 134

13 40

1339

NEW ASPHALT PARKING LOT WITH NEW GRADING PLAN

1341

134

EN TIO

1340

NEW SCIENCE BUILDING FFE 1343.75

WATERSHED #3

RE T

1341

134

BIO

1342

PRODUCED BY AN AUTODESK STUDENT VERSION

NEW SCIENCE BUILDING FFE 1343.75 13

50'

PRODUCED BY AN AUTODESK STUDENT VERSION 1341

PRODUCED BY AN AUTODESK STUDENT VERSION

1339

NEW ASPHALT PARKING LOT WITH NEW GRADING PLAN

NEW ASPHALT DRIVE

XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX

PRODUCED BY AN AUTODESK STUDENT VERSION

DRAINS TO BIORETENTION BASIN #2

BIO

SIN

36 7 3 13

1338

1337

1336

1340

BIORETENTION BASIN #3

NORTH

STRIP DRAIN TO BIORETENTION BASIN #3

1335 1336

1337

1339

NEW PARKING LOT AREA PLAN

PRODUCED BY AN AUTODESK STUDENT VERSION

PROJECT DESCRIPTION: Stormwater run-off and bioretention basin grading plan for a theoretical science building.

SCALE: 1" = 50'-0" 0

25'

50'

NEW BUILDING AREA PLAN

PRODUCED BY AN AUTODESK STUDENT VERSION

PROJECT SUBTITLE: Grading practice

SCALE: 1" = 50'-0"

100'

PRODUCED BY AN AUTODESK STUDENT VERSION

Grading AutoCAD LA5771 // LANDSCAPE INFRASTRUCTURE 1 // S2021

SCALE: 1" = 100'-0"

OVERALL PLAN

25'

50'

Chilopsis linearis / Desert Willow

Cycas taitungensis / Sago Palm

Ginkgo biloba / Maidenhair Tree

Magnolia grandiflora / Southern Magnolia

Sciadopitys verticillata / Umbrella Pine

Achillea millefolium / Common Yarrow Agave havardiana / Havard's Century Plant Athyrium filix-femina / Lady in Red Lady Fern Athyrium niponicum / Japanese Painted Fern

Lavandula subnuda / Lavender

Polystichum acrostichoides/ Christmas Fern Sabal minor / Dwarf Palmetto

Yucca glauca / Soapweed

Equisetum scirpoides / Dwarf Horsetail

NM Museum of Natural History LA5772 // LANDSCAPE INFRASTRUCTURE 2 // F2021 PROJECT SUBTITLE: EVOLUTIONARY GARDEN PROJECT DESCRIPTION: In this project, I designed and created a planting plan for an outdoor exhibit showcasing the evolution of plants for the New Mexico Museum of Natural History in Albuquerque.

Eli Gilmore

MASTER PLAN 1/2" = 1'

PLANT_ SCHEDULE TREES

SHRUBS

CODE

QTY

BOTANICAL / COMMON NAME

CHI LIN

Chilopsis linearis / Desert Willow

CYC TAI

Cycas taitungensis / Sago Palm

WATER USE Low - Medium

120" min o.c.

SOIL TOLERANCES

SUN EXPOSURE

MATURE HEIGHT

MATURE WIDTH

SEASON OF BLOOM

6-9

Silt, Sand, Loam, Neutral, Alkaline, Well-drained, Dry, Moist

Part shade, Full sun

10 - 40' ht.

10 - 25' w.

Mid-spring, Late Spring, Early Summer, Mid-summer, Late Summer

7 - 10

Clay, Sand, Well-drained, Dry, Moist

Part shade, Full sun

HARDINESS ZONES

Chilopsis linearis / Desert Willow

Cycas taitungensis / Sago Palm

GIN BIL

Ginkgo biloba / Maidenhair Tree

Low - Medium

4-9

Rocky, Clay, Silt, Sand, Organic, Salty, Alkaline

Part shade, Full sun

40 - 65' ht.

25 - 40' w.

Non-blooming

MAG GRA

Magnolia grandiflora / Southern Magnolia

Medium - High

6 - 10

Sand, Loam, Acidic, Neutral, Moist

Part shade, Full sun

> 65' ht.

40 - 65' w.

Early Spring, Mid-spring, Late Spring, Early Summer, Mid-summer, Late Summer, Early Fall, Mid-fall

Ginkgo biloba / Maidenhair Tree

Medium

5-8

Silt, Sand, Organic, Acidic, Well-drained

Part shade, Full sun

15 - 25' ht.

15 - 25' w.

WATER USE

HARDINESS ZONES

SOIL TOLERANCES

SUN EXPOSURE

MATURE HEIGHT

MATURE WIDTH

SEASON OF BLOOM

Magnolia grandiflora / Southern Magnolia

SCI VER

Sciadopitys verticillata / Umbrella Pine

CODE

QTY

BOTANICAL / COMMON NAME

SPACING

ACH MIL

188

Achillea millefolium / Common Yarrow

36" o.c.

Low

3-9

Silt, Sand, Salty

Part shade, Full sun

6" - 36" ht.

1 - 3' w.

Early Summer, Mid-summer, Late Summer

AGA HAV

157

Agave havardiana / Havard's Century Plant

36" o.c.

Low

6 - 10

Rocky, Clay, Sand, Loam, Neutral, Alkaline, Well-drained

Part shade, Full sun

18" - 6' ht.

3 - 6' w.

Mid-spring, Late Spring

ATH LAD

Athyrium filix-femina 'Lady in Red' / Lady in Red Lady Fern

36" o.c.

Medium - High

2-8

Clay, Silt, Well-drained, Moist

Deep shade, Shade, Part shade

18 - 36" ht.

1 - 3' w.

ATH MCS

105

Athyrium niponicum / Japanese Painted Fern

24" o.c.

Medium

Clay, Silt, Well-drained, Moist

Deep shade, Shade, Part shade

6" - 36" ht.

1 - 3' w.

LAV SUB

285

Lavandula subnuda / Lavender

48" o.c.

Low

Clay, Sand, Well-drained, Dry, Moist

Part shade, Full sun

6" - 36" ht.

1 - 3' w.

POL ACR

118

Polystichum acrostichoides / Christmas Fern

24" o.c.

Medium

Silt, Sand, Well-drained, Moist

Deep shade, Shade, Part shade

6" - 36" ht.

1 - 3' w.

Non-blooming

Sabal minor / Dwarf Palmetto

72" o.c.

Medium

Mid-summer

4-9

7 - 10

Clay, Sand, Well-drained, Moist

3 - 1' ht.

3 - 6' w.

YUC GLA

213

Yucca glauca / Soapweed

24" o.c.

Very low - Low

4-5

Rocky, Silt, Sand

18 - 36" ht.

1 - 2' w.

CODE

QTY

BOTANICAL / COMMON NAME

SPACING

WATER USE

HARDINESS ZONES

SOIL TOLERANCES

SUN EXPOSURE

MATURE HEIGHT

MATURE WIDTH

EQU SCI

14,161

Equisetum scirpoides / Dwarf Horsetail

24" o.c.

High

5 - 11

Clay, Silt

Part shade

< - 18" ht.

SAB MIN

GROUND COVERS

SPACING

Shade, Part shade

Part shade, Full sun

Sciadopitys verticillata / Umbrella Pine

Achillea millefolium / Common Yarrow

SEASON OF BLOOM

Agave havardiana / Havard's Century Plant Athyrium filix-femina / Lady in Red Lady Fern Athyrium niponicum / Japanese Painted Fern

Lavandula subnuda / Lavender

Polystichum acrostichoides/ Christmas Fern

COVER 1/2 OF TRUNK WITH MOUNDED SOIL MIX DIG A HOLE THAT IS THE SAME DEPTH AND TWICE THE WIDTH OF ORIGINAL POT

50/50 PLANT MIX + SOIL

Sabal minor / Dwarf Palmetto

Yucca glauca / Soapweed

Equisetum scirpoides / Dwarf Horsetail

Eli Gilmore

FILL BOTTOM HALF OF HOLE WITH MIN. 1" DIAMETER GRAVEL

0.1

PLACE ON PLANT ON TOP OF GRAVEL THEN FILL TO ORIGINAL SOIL LINE WITH PLANT MIX

SABAL MINOR + SAGO PALM DETAIL NOT DRAWN TO SCALE

SAB MIN (46)

EQU SCI

Chilopsis linearis / Desert Willow

Cycas taitungensis / Sago Palm

Ginkgo biloba / Maidenhair Tree

Magnolia grandiflora / Southern Magnolia

Achillea millefolium / Common Yarrow

EQU SCI

ATH MCS (105)

Athyrium niponicum / Japanese Painted Fern

PERMIAN ZONE PLAN - SHRUBS 5/16" = 1'

Lavandula subnuda / Lavender

3.1

Polystichum acrostichoides/ Christmas Fern

Lavandula subnuda / Lavender

Sabal minor / Dwarf Palmetto

Eli Gilmore

2.2

CENOZOIC ZONE PLAN - SHRUBS

Lavandula subnuda / Lavender

5/16" = 1'

Polystichum acrostichoides/ Christmas Fern Sabal minor / Dwarf Palmetto

CYC TAI (13)

Yucca glauca / Soapweed

MAG GRA (4)

Equisetum scirpoides / Dwarf Horsetail

GIN BIL (3)

Eli Gilmore

CHI LIN (7)

PERMIAN ZONE PLANTING PLAN 5/8" = 1'-0"

Athyrium niponicum / Japanese Painted Fern

4.1

Yucca glauca / Soapweed

SCI VER (8)

Equisetum scirpoides / Dwarf Horsetail

CYC TAI (20)

Athyrium filix-femina / Lady in Red Lady Fern

Sabal minor / Dwarf Palmetto

Yucca glauca / Soapweed

SCI VER (8)

Achillea millefolium / Common Yarrow Agave havardiana / Havard's Century Plant

YUC GLA (213)

Athyrium niponicum / Japanese Painted Fern

Polystichum acrostichoides/ Christmas Fern

Ginkgo biloba / Maidenhair Tree

Magnolia grandiflora / Southern Magnolia

Sciadopitys verticillata / Umbrella Pine

AGA HAV (157)

Achillea millefolium / Common Yarrow Agave havardiana / Havard's Century Plant Athyrium filix-femina / Lady in Red Lady Fern

5/16" = 1'

Cycas taitungensis / Sago Palm

ACH MIL (188)

Magnolia grandiflora / Southern Magnolia

Sciadopitys verticillata / Umbrella Pine

MESOZOIC ZONE PLAN - SHRUBS

Chilopsis linearis / Desert Willow

LAV SUB (285)

Ginkgo biloba / Maidenhair Tree

ATH LAD (82)

Agave havardiana / Havard's Century Plant Athyrium filix-femina / Lady in Red Lady Fern

2.1

Cycas taitungensis / Sago Palm

POL ACR (118)

Sciadopitys verticillata / Umbrella Pine

EQU SCI

Chilopsis linearis / Desert Willow

SAB MIN (21)

PERMIAN ZONE PLAN - TREES

MESOZOIC ZONE PLANTING PLAN 5/8" = 1'-0"

3.1

5/16" = 1'

MESOZOIC ZONE PLAN - TREES

CENOZOIC ZONE PLANTING PLAN 5/8" = 1'

4.2

5/16" = 1'

CENOZOIC ZONE PLAN - TREES 5/16" = 1'

Landscape by Era

NM Museum of Natural History

Permian Era (470-230 mya.)

Mesozoic Era (165-145 mya.)

Cenozoic Era (144 mya. - NOW)

Chilopsis linearis / Desert Willow

Cycas taitungensis / Sago Palm

LA5772 // LANDSCAPE INFRASTRUCTURE 2 // F2021

Cycas taitungensis / Sago Palm

Ginkgo biloba / Maidenhair Tree

Remove nursery stake. If central leader needs to be straightened or held erect, it is acceptable to attach a 12" x 8' bamboo pole to the central leader and trunk.

Magnolia grandiflora / Southern Magnolia

Sciadopitys verticillata / Umbrella Pine

Achillea millefolium / Common Yarrow

32" long non - abrasive rubber ties.

Agave havardiana / Havard's Century Plant

Two (2) three inch lodge pole pine stakes. Install approximately 2" away from the edge of the root ball. Stake location shall not interfere with permanent branches.

Athyrium filix-femina / Lady in Red Lady Fern Athyrium niponicum / Japanese Painted Fern

XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX

Polystichum acrostichoides/ Christmas Fern

IF A TREE HAS THREE CODOMINANT STEMS. THE TWO THAT COMPETE WITH THE ONE IN THE CENTER SHOULD BE PRUNED TO SUPPRESS THEIR GROWTH.

0.3

CROWN CORRECTION DETAIL

TWO COMPETING STEMS WERE REDUCED SUBSTANTIALLY, IN THIS CASE REMOVING ABOUT 70% OF THEIR FOLIAGE USING REDUCTION CUTS.

Agave havardiana / Havard's Century Plant Athyrium filix-femina / Lady in Red Lady Fern Athyrium niponicum / Japanese Painted Fern

Lavandula subnuda / Lavender

Polystichum acrostichoides/ Christmas Fern

Sabal minor / Dwarf Palmetto

Yucca glauca / Soapweed

Equisetum scirpoides / Dwarf Horsetail

AFTER PRUNING, TREE HAS ONLY ONE DOMINANT STEM

NOTES: 1- TREE SHALL MEET CROWN OBSERVATION DETAIL FOLLOWING CORRECTION. 2- CHECK (CHI LIN), (GIN BIL), AND (MAG GRA) ANNUALLY FOR COMPETING STEMS.

2'-0"

PROJECT DESCRIPTION: The plantings fall into three eras and are placed according to when they evolved into the species they are today.

6'-0"

Lavandula subnuda / Lavender

PROJECT SUBTITLE: EVOLUTIONARY GARDEN

Ginkgo biloba / Maidenhair Tree

Magnolia grandiflora / Southern Magnolia

Sciadopitys verticillata / Umbrella Pine

Eli Gilmore

NOT DRAWN TO SCALE

0.2

TREE PLANTING DETAIL 1/2"=1'

The Granary Corridor Bikeway Opening the way to safety The Problem: Cyclist Safety

The Precedents:

The Site:

Cykelslagen by DISSING+WEITLING

Granary Corridor Bikeway LA8206 // MAKING URBAN LANDSCAPE SPACE // F2021

Pruszkow Bike Path by TPA Engineering

The Technion’s Entrance Gate by Schwartz Besnosoff Architects

The Problem: Missing Connections

PROJECT DESCRIPTION: For this project, I wanted to find a better way for pedestrians and bikers to get onto campus while avoiding traffic along University Ave. I took inspiration from the Cykelslagen in Denmark to create an elevated bike highway through the tree canopy along the BNSF railyard. It uses phosphor pavement that “charges” during the day to illuminate the path at night. The path also provides a much needed connection point from the west and from downtown.

Biking times fro Rapson Hall

Walking times from Rapson Hall

PROJECT SUBTITLE: MISSISSIPPI BIKEWAY

Nicollet Island

Como

Marcy Holmes

30 minutes 15 minutes

Downtown West

Downtown West Downtown East

Elliot Park

University of Minnesota

Down

20 minutes Elliot Park

Cedar Riverside

Ventura Village

Ventura Village Seward

Legend

Maxar

0.2 mi

Bike Path

Nicollet Island

Site Location University Of Minnesota, City of Minneapolis, Metropolitan Council, MetroGIS, Three Rivers Park District, Esri Canada, Esri, HERE, Garmin, SafeGraph, METI/NASA, USGS, EPA, NPS, USDA

The Solution: Granary Corridor Bikeway

E SE H AV 11 T

2ND ST SE

EAST R IVE R

10 TH AVE BRIDGE

11TH ST ENTRY

Section 1

RD TO UMN CAMPUS

TO STONE ARCH BRIDGE/ FATHER HENNEPIN BLUFF PARK

Bike Path Diagram 2” DIAMETER HANDRAIL

3’ RAILING

1”=8’

15 minutes

Section 2:

4’ BIKE LANE

2’ CORTEN PLANTER

6’ PEDESTRIAN LANE

16’ TOTAL

10 minutes Como

Marcy Holmes

ntown East

Circulation routes at 11th St connection

YIELD

Section 1:

N 1”=50’

UNIVERSITY AVE ENTRY AND RESTORED BRIDGE

io ct Se

10 TH AVE SE

UNIVERSITY AVE

11th St Entry Day + Night

University of Minnesota

Cedar Riverside

a e Seward

5 minutes

University Of Minnesota, City of Minneapolis, Metropolitan Council, MetroGIS, Three Rivers Park District, Esri Canada, Esri, HERE, Garmin, SafeGraph, METI/NASA, USGS, EPA, NPS, USDA

1” = 8’

1”=4’

Bell Museum LA5201 // MAKING LANDSCAPE SPACES AND TYPES // F2020 PROJECT SUBTITLE: GLACIERS PROJECT DESCRIPTION: In this project, we were tasked with creating a tree garden in the space next to the Bell Museum. I had been enamored by the effects of glacial activity after seeing the exhibit on glaciers in the Bell Museum XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX

Journey Through Time

Bell Museum Process LA5201 // MAKING LANDSCAPE SPACES AND TYPES // F2020 PROJECT SUBTITLE: GLACIERS PROJECT DESCRIPTION: To begin the process, I made a collage combining the empty site and components of glacial landsacpes. From there, I created a working clay model to assist in the development of the site. I had created a mission statement as well to explain the guiding principles

A tree garden is a living landscape that changes with time. This design tries to emphasize the change of the landscape through landforms reminiscent of the aftermath of ancient glaciers running through the site. The old growth coniferous trees on the hills contrasts the growing deciduous trees along the path. These deciduous trees are larger and more numerous to the north of the site, reflecting the slow movement of the theoretical glacier.

Bell Museum Experiential LA5201 // MAKING LANDSCAPE SPACES AND TYPES // F2020 PROJECT SUBTITLE: GLACIERS PROJECT DESCRIPTION: These diagrams were used to provide an experiential feeling to the landscape. XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX

Bell Museum Sections LA5201 // MAKING LANDSCAPE SPACES AND TYPES // F2020 PROJECT SUBTITLE: COLLABORATIVE EFFORT HYBRID PLANS PROJECT DESCRIPTION: Sections were used in this project to show the seasonality of the plantings, as well as to provide a human-level view of the site. XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX

Construction Documents LA5771 // LANDSCAPE INFRASTRUCTURE AND SYSTEMS 1 // F2020 PROJECT SUBTITLE: NORTHROP LAWN PROJECT DESCRIPTION: In this project, we were tasked with creating a small series of construction documents for the Northrop lawn. XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX

Street Acce

Parking

Welco me Center

Dro p- O

Deciduo

S e ati n g

C o n if ati n

e ro

Water Feature

Bio mes

Patio

S av a n n a h S e at i n g

Asp en Pa rk

Classroom

la n d

Seat ing

B l i n ds /

Bird watching Area

Vi e

in g

Bell Museum Extension LA3002 // INFORMANTS OF CREATING LANDSCAPE SPACE // S2020

SITE PLAN 1:100 SCALE

Patio/Gathering Space

Main Pathway

Parking

Marsh/Wetland

Trails

Open Water

Bird-Vewing Area

Prairie Savannah

Minnesota Biomes Center

/Ca

Cla

ssr oo

Central Pond

PROJECT SUBTITLE: MN BIOME CENTER PROJECT DESCRIPTION: In this project, we were tasked with designing an outdoor extension to the Bell Museum. My design utilizes the space to provide a learning experience about the biomes of Minnesota. XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX

Deciduous Forest

Bird viewing Area and Building

Coniferous Forest

Aspen Parkland

1/4 Scale

Bell Museum Extension

Co n

ife

ro u

sF or es

Section of prairie and pond

LA3002 // INFORMANTS OF CREATING LANDSCAPE SPACE // S2020 PROJECT SUBTITLE: MN BIOME CENTER PROJECT DESCRIPTION: In this project, we were tasked with designing an outdoor extension to the Bell Museum. My design utilizes the space to provide a learning experience about the biomes of Minnesota. XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX

Section of Coniferous trails

1/4 Scale

WW1 Memorial LA3001 // CREATING LANDSCAPE SPACE // F2019 PROJECT SUBTITLE: USING A METAPHOR TO CREATE LANDSCAPE SPACE PROJECT DESCRIPTION: For this project, I took Paul Nash’s We Are Making A New World and broke it down into a contour plan to portray a metaphor for the feeling of solemnity. The black to white gradient is meant to signify death and the final journey to a higher place. XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX

Bohemian Flats LA3001 // CREATING LANDSCAPE SPACE // F2019 PROJECT SUBTITLE: MISSISSIPPI DELTA PROJECT DESCRIPTION: In this project, we took were to redefine the space at Bohemian Flats Park. For this I took inspiration from the Mississippi river delta, reversing the process to give back to the river.

Bohemian Flats LA3001 // CREATING LANDSCAPE SPACE // F2019 PROJECT SUBTITLE: MISSISSIPPI DELTA PROJECT DESCRIPTION: The canals can fill with runoff from rains and melting snow, leading back into the river. When dry they can be used for better circulation. Around the park, the grasses and other plantings provide more spaces for seclusion or for gatherings. XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX

Fallout Shelter ARCH2281 // DESIGN FUNDAMENTALS II // S2019 PROJECT SUBTITLE: COLLABORATIVE EFFORT HYBRID PLANS PROJECT DESCRIPTION: We chose wood as our secondary materiel to provide a more natural juxtaposition to the primary material of concrete. We added turf and plant-life to areas of our model to simulate the feeling of trees and being outdoors, along with the natural sunlight that comes in from a shaft extending to the surface.

Professional Work GRIES ARCHITECTURAL GROUP// 2019 PROJECT SUBTITLE: WAREHOUSE PLANS PROJECT DESCRIPTION: These Revit drawings were part of a full set of plans for a warehouse I designed for my internship at Gries Architectural Firm in 2019. XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX
