Finished Spindles & Balusters ENDLESS POSSIBILITIES FOR WOOD STAIRCASES

Finished Spindles & Balusters

Create and install stunning wood staircases that complement a range of interiors quickly and efficiently with ready-to-install powder coated spindles and innovative assembling solutions.

TimeLine® The TimeLine collection of ready‑to‑install powder coated spindles offers endless possibilities for railing design. Spindles are available in a variety of colors and finishes. Mix and match styles, colors and finishes to create unique and personalized railing designs.

Zipbolt™ Zipbolt’s award-winning design and patented gearing system offers wood fastening solutions with cost and time saving advantages for stairbuilders and woodworkers. Create strong, durable and invisible connections for the most common joints in stairs and railings.

geobezdan.com

1 800 663 6356

09/26

R E A DY TO I N S TA L L B A L U S T E R S

_deac/ m/monica tagram.co www.ins _deac ica on m @

New Arrivals The TimeLine® collection continues to evolve with thoughtfully designed, carefully curated additions.

Visit geobezdan.com/timeline

Geometric baluster TL02-30 and plain baluster TL12X-30

09/26

New styles. Install ready. Standout results. The latest TimeLine® geometric spindles bring mid‑century-inspired design to stair projects with clean lines, consistent finishes, and tested performance. Explore the collection starting on page 8. For modern stair builds, metal newel posts offer a sleek option for level and stair applications. Installation-ready, each post includes a handrail bracket, base plate, and cover flange. See page 22. Endless Possibilities with TimeLine®

Stay in the loop! #bezdanrailings

Horizontal Guard Rail Now Code-Compliant We’ve expanded our horizontal infill offering in 60" lengths, including a new rectangular style. See page 21.

Contents Features & Resources Colors and Finishes. . . . . . . . . . . . . . . . . . . . 4 Photo Gallery. . . . . . . . . . . . . . . . . . . . . . . . . 28 Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 Balusters

09/26

Plain Round Steel Balusters. . . . . . . . . . . . 17 Decorative Round Steel Balusters . . . . . . 18 Lengths for Horizontal Infill Horizontal Infill - Plain Steel Lengths. . . . 21 Compatible Components

Stainless Steel Balusters. . . . . . . . . . . . . . . . 6

Square Steel Newel Posts. . . . . . . . . . . . . . 22

Plain Square Steel Balusters . . . . . . . . . . . . 7

Baluster Collars. . . . . . . . . . . . . . . . . . . . . . . 23

Geometric Steel Balusters . . . . . . . . . . . . . . 8

Base Collars. . . . . . . . . . . . . . . . . . . . . . . . . . 24

Geometric Square Steel Balusters. . . . . . . 9

Handrail Brackets. . . . . . . . . . . . . . . . . . . . . 26

Decorative Square Steel Balusters. . . . . . 15

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . 27

geobezdan.com

1 800 663 6356

Colors and Finishes Stainless Steel Finishes Eye-catching finishes and colors that embody luxurious metals and infuse fresh style into décor.

Satin Stainless Cool and contemporary stainless steel with a satin finish. SS

Graphite Black A contemporary black enhanced with a reflective quality that adds interest and provides ultimate versatility. 33

Satin Bronze A beautiful, rich golden hue with a reflective quality that offers a playful yet elegant, warm finish. 77

High Performance Powder Coated Finishes Powder coating boasts a smooth, consistent finish and textured options to resist marring and chipping.

Designer White A versatile warm white with a smooth finish and a hint of gloss. 10

Pavestone

A warm and versatile grey with a smooth finish and a hint of gloss.

Satin Black An understated matte black finish with endless versatility.

Wrinkled Black A beautifully textured finish resistant to signs of wear and tear.

Burnt Penny A smooth finish with a hint of gloss enhanced by a rich, warm hue.

Midnight Copper A matte black finish accented with hand-painted copper edges.

Gun Metal Grey A cool and sophisticated grey with a smooth finish and a hint of gloss.

Color Chips Confidently select the right powder coated color option for your next project. Contact your authorized dealer for color chips.

Select compatible components available in these finishes: BS

Brushed Stainless* * not powder coated

We have made every effort to display colors accurately. Physical product(s) may vary slightly from images shown.

geobezdan.com

1 800 663 6356

09/26

Discover the TimeLine® Difference Quality Finishes. Unique Designs. Trusted Results. TimeLine® was designed to provide a product that designers, builders, installers, and homeowners can count on for consistent quality, strength, and durability that is easy to install and offers clients distinctive and aesthetically pleasing styles. We continue to deliver this exceptional quality with new, unique designs to broaden the offering for those looking beyond standard railings.

Geometric baluster TL68-1-30 and plain baluster TL12X-30

Safety and Quality TimeLine® spindles shown in this catalog have undergone independent load analysis and testing to meet: • Part 9 of the 2020/2025 National Building Code of Canada • Part 9 of the 2024 British Columbia Building Code • Part 9 of the 2024 Ontario Building Code Downloadable reports available at geobezdan.com/resource-library 09/26

Stainless Steel Balusters Multiple Sizes of Square, Rectangular and Round Tube

44"

SS 33

1/2"

5/8"

3/4"

TL12

TL58

TL34

Baluster Size

SS 1/2" x 1-1/2"

TL115

Part Number Tube

Style No.

Dimensions

Color

1/2"

TL12

5/8"

TL58

3/4"

TL34

1/2" x 1-1/2"

TL115

1/2"

TL15RD

5/8"

TL58RD

3/4"

TL34RD

1/2"

5/8"

3/4"

TL15RD

TL58RD

TL34RD

Options/Notes Suitable for use with the TimeLine Connector (TLC SS) or Spirol Pin SS. See page 27.

44" L

Suitable for use with the TimeLine Connector (TLC SS). See page 27.

geobezdan.com

1 800 663 6356

09/26

Plain Square Steel Balusters Multiple Sizes of Square and Rectangular Tube

44"

10 40 45

30 30

1/2"

5/8"

3/4"

TL12

TL12X

CC12

TL12A

TL34

TL10

Baluster Size

Part Number Tube

Style No.

TL12

Dimensions

Color 10

Options/Notes

3/4" L dowel top

Suitable for use with the TimeLine Connectors (TLC and TLC SS) or Spirol Pin. See page 27.

Anchor Plate

Includes two #8 Robertson screws in matching -30 Satin Black

1/2" -

CC12

TL12A

TL115

Inclusions

TL12X

1/2" x 1-1/2"

44" L 5/8"

50 3/4" L dowel top

3/4"

09/26

TL34

TL10

1/2" x 1-1/2"

TL115

geobezdan.com

1 800 663 6356

Not suitable for use with discs, TimeLine Connectors (TLC and TLC SS) or Spirol Pin.

Suitable for use with the TimeLine Connector (TLC SS). See page 27.

Geometric Steel Balusters 1/2" x 1/4" x 5/8" Rectangular Bar 1/2"

Round Dowel Top ø 1/2"

44"

Solid Rectangular Ends 5/8"

1/4"

1/4" 5/8"

Geometric baluster TL05-30

3-5/16"

TL05 NEW

Baluster

Part Number Style No.

Color

Dimensions

Inclusions

Options/Notes

44" L

3/4" L dowel top

The TL05 allows for flexibility in spacing between the vertical elements as it can be manually adjusted to accommodate a range of rise and run configurations.

N EW

Size

1/2" dowel top and 1/4" x 5/8" solid rectangular ends

TL05

Meet the Hashi “V” Spindle Inspired by fabricated-style railings and the refined elegance of chopsticks, the Hashi “V” spindle brings a modern architectural look to wood staircases. This unique TimeLine® style adds visual interest for customers looking to create a distinctive railing design.

geobezdan.com

1 800 663 6356

09/26

Geometric Square Steel Balusters 1/2" and 5/8" Square Tube 2"

2-3/4"

6" 9"

6" 11.5"

24"

20"

24"

20"

17" 11.5"

14"

15"

14"

15"

14"

30 50

1/2"

5/8"

1/2"

TL98-1

TL98-2

TL98A-1

TL09-1

TL99-1

TL96-1

TL96-2 NEW

Baluster Size

Part Number

Tube

Style No. TL98-1

Color -

Dimensions

Inclusions

Options/Notes Suitable for use with the TimeLine Connectors (TLC and TLC SS) or Spirol Pin. See page 27.

1/2" TL98-2

TL98A-1

5/8"

TL09-1

44" L -

TL99-1 1/2"

N EW

TL96-1

09/26

geobezdan.com

3/4" L dowel top

30 Suitable for use with the TimeLine Connectors (TLC and TLC SS) or Spirol Pin. See page 27.

TL96-2

1 800 663 6356

Geometric Square Steel Balusters 1/2" Square Tube 2"

6" 10"

1" 4.5"

18"

11"

24" 24"

11"

4.5"

21" 14"

14"

14" 12"

1/2"

TL88-2H

TL78-1

TL78-2

TL77-1

TL91-1

NEW

Baluster Size

Part Number

Tube

Style No.

Color

TL88-2H

TL78-1

Dimensions

Inclusions

46" L

40 44" L 3/4" L dowel top

TL78-2

N EW

1/2"

TL77-1

46" L -

TL91-1

Options/Notes

Suitable for use with the TimeLine Connectors (TLC and TLC SS) or Spirol Pin. See page 27. TL88-2H styles not suitable for use with discs or base collars.

30 44" L

Installation Accessories From spirol pins to TimeLine® connectors, choose the right accessory to support your spindle or baluster installation method. See page 27.

geobezdan.com

1 800 663 6356

09/26

Geometric Square Steel Balusters 1/2" Square Tube 2"

3-1/2"

5-1/2"

3-1/2"

14"

12"

5" 5" 24"

24"

7" 5"

12"

NEW

20"

30 NEW

NEW

14"

14" 11-1/2"

1/2”

TL68-1

TL68-2

TL47-2

TL66-1

TL20-1

TL20-2

NEW

Baluster

Part Number

Tube

Style No.

Color

Dimensions

Inclusions

Options/Notes

44" L

3/4" L dowel top

Suitable for use with the TimeLine Connectors (TLC and TLC SS) or Spirol Pin. See page 27.

N EW

Size

TL68-1

TL68-2

TL47-2

N EW

1/2"

09/26

geobezdan.com

TL66-1

TL20-1

TL20-2

1 800 663 6356

Geometric Square Steel Balusters 1/2" Square Tube 4"

2-1/4"

3-1/4"

2-13/16"

5" 8"

26"

10"

12-1/4" 15"

5-1/2"

11" 29"

24"

23-1/2" 20-3/4"

12"

10"

1/2"

TL03

TL38-1

TL38-2

TL120

TL18-1

TL28-1

TL17-1

NEW

Baluster

Part Number

Tube

Style No. N EW

Size

Color

Dimensions

Inclusions

Options/Notes

44" L

3/4" L dowel top

Suitable for use with the TimeLine Connectors (TLC and TLC SS) or Spirol Pin. See page 27.

TL03

TL38-1

1/2"

N EW

TL38-2

TL120

TL18-1

TL28-1

TL17-1

geobezdan.com

1 800 663 6356

09/26

Geometric Steel Balusters 1/2" Square Tube 3-3/4"

36"

30 Geometric baluster TL02-30 and plain baluster TL12X-30

1/2”

TL02 NEW

Baluster

Part Number

Tube

Style No.

Color

Dimensions

Inclusions

Options/Notes

44" L

3/4" L dowel top

Suitable for use with the TimeLine Connectors (TLC and TLC SS) or Spirol Pin. See page 27.

N EW

Size

1/2"

TL02

Meet the Diapason Spindle Inspired by the tuning fork — also known as a diapason — this two‑pronged design takes a cue from an instrument known for producing a pure, fixed pitch. The result? A design that keeps everything in tune.

09/26

geobezdan.com

1 800 663 6356

Geometric Square Steel Balusters 1/2" Square Tube 2-5/8"

4-3/8"

14"

16-1/2"

17"

1-3/4" 1-3/4" 4"

1-3/4"

6-3/4"

1-3/4" 2-1/2"

23"

22-1/4" 19"

1/2"

TL19-1

TL29-2

TL39-2

Baluster Size

Tube

Part Number Style No.

Color

Geometric balusters TL19-1-30, TL29-2-30, TL39-2-30 and plain baluster TL12X-30

Dimensions

Inclusions

Options/Notes

44" L

3/4" L dowel top

Suitable for use with the TimeLine Connectors (TLC and TLC SS) or Spirol Pin. See page 27.

TL19-1

1/2"

TL29-2

TL39-2

Installation Accessories From spirol pins to TimeLine® connectors, choose the right accessory to support your spindle or baluster installation method. See page 27.

geobezdan.com

1 800 663 6356

09/26

Decorative Square Steel Balusters 1/2" Square Tube 7"

4-1/2"

5-3/4" 10-3/4" 13-7/8"

15-1/4"

27"

13-1/2"

24-1/2"

8-5/16"

44"

23-3/4"

21-13/16"

19-3/4" 12-1/2"

13-3/4"

40 30

1/2”

TL200-4

TL13

TL122

TL101-1

TL101-2

TL102-1

Hammered Baluster Size

Part Number

Tube

Style No.

Color

TL200-4

TL13

TL122

Dimensions

60 44" L

TL101-1 30

Options/Notes Hammered detail not suitable for use with discs, base collars, TimeLine Connectors or Spirol Pin.

1/2"

Inclusions

3/4" L dowel top

Suitable for use with the TimeLine Connectors (TLC and TLC SS) or Spirol Pin. See page 27.

TL101-2

TL102-1

09/26

geobezdan.com

1 800 663 6356

Decorative Square Steel Balusters 1/2" Square Tube

17-1/8"

16-1/2"

17-1/16"

18"

1-3/4"

1-11/16"

18"

1-7/8"

25-1/8"

14-3/8"

23-13/16"

25-1/16" 17"

10-1/4"

17-3/8"

17"

1/2”

TL106-1

TL106-2

TL130-1

TL130-2

TL260-1

TL260-2

Baluster Size

Tube

Part Number Style No.

Color

Dimensions

Inclusions

Options/Notes

44" L

3/4" L dowel top

Suitable for use with the TimeLine Connectors (TLC and TLC SS) or Spirol Pin. See page 27.

TL106-1 -

TL106-2

TL130-1 1/2" TL130-2

TL260-1

TL260-2

geobezdan.com

1 800 663 6356

09/26

Plain Round Steel Balusters Multiple Sizes of Round Tube

44"

43"

46"

44"

30 30

40 45

1/2"

9/16"

5/8"

3/4"

TL15RD

TL261-4RD

TL58RDL

TL34RD

Baluster Size

Part Number

Tube

1/2"

9/16"

Style No.

TL15RD

TL261-4RD

Dimensions

Color 30

Options/Notes

Decorative baluster TL104-1RD-30 and plain baluster TL58RDL-30

44" L

43" L See compatible baluster and base collars on page 23 to page 25.

30 5/8"

TL58RDL

45 46" L

3/4"

09/26

geobezdan.com

TL34RD

1 800 663 6356

44" L

Decorative Round Steel Balusters 1/2" Round Tube

10-3/4" 13-7/8"

17-1/16"

1-7/8"

13-1/2"

5-1/2"

18"

14-1/4"

8-5/16" 13-1/2"

25-1/16"

23-1/2"

21-13/16"

19-3/4" 17"

16-1/4"

30 40 40

1/2"

TL130-1RD

TL130-2RD

TL101-1RD

TL101-2RD

TL102-1RD

TL103-1RD

Baluster Size

Tube

Part Number Style No.

Dimensions

Color

Inclusions

Options/Notes

TL130-1RD

TL130-2RD -

TL101-1RD 1/2"

44" L TL101-2RD

TL102-1RD

TL103-1RD

Create unique railing patterns by pairing these decorative styles with plain spindle TL15RD, shown on page 17.

geobezdan.com

1 800 663 6356

09/26

Decorative Round Steel Balusters 9/16" Round Tube

11-1/4"

10" 15-1/8"

17-1/2"

17"

13-1/2"

10"

5-3/4" 17"

25-1/2"

24-1/2"

22-1/8"

16" 19-1/4"

16"

9/16"

TL224-1RD

TL224-2RD

TL261-1RD

TL261-2RD

TL230-1RD

TL230-2RD

Hammered collars Baluster Size

Part Number

Tube

Style No.

Color

Dimensions

Inclusions

Options/Notes

TL224-1RD -

44" L

TL224-2RD

Create unique railing patterns by pairing these decorative styles with plain spindle TL261-4RD, shown on page 17.

TL261-1RD -

9/16"

TL261-2RD 43" L TL230-1RD TL230-2RD

09/26

geobezdan.com

1 800 663 6356

The decorative centres of the balusters feature a hammered collar, while the straight tube sections are smooth.

Decorative Round Steel Balusters 5/8" Round Tube

6-5/8" 10-15/16"

10-15/16"

22-1/8"

14-1/2"

21-11/16"

6-1/2"

23" 15-5/8" 10-15/16" 30

10-15/16"

5/8"

TL104-1RD

TL105-1RD

TL450RD

TL415RD

Baluster Size

Tube

Part Number Style No.

Decorative baluster TL450RD-60

Dimensions

Color

Options/Notes

TL104-1RD -

Create unique railing patterns by pairing these decorative styles with plain spindle TL58RDL, shown on page 17.

TL105-1RD 5/8"

44" L TL450RD

TL415RD

These balusters can be used together or combined with plain spindle TL58RDL, shown on page 17. Decorative center detail of baluster is made of smooth die cast aluminum. Straight tube sections are heavy gauge steel fastened mechanically on each end of center detail.

Installation Accessories From spirol pins to TimeLine® connectors, choose the right accessory to support your spindle or baluster installation method. See page 27.

geobezdan.com

1 800 663 6356

09/26

Horizontal Infill - Plain Steel Lengths Multiple Sizes of Square, Round and Rectangular Tube 60"

1/2"

TL612 30

60"

1/2"

TL615RD 30

60"

5/8"

TL658RD 30

60"

1/2"x 1-1/2"

TL6115 30

NEW

Stainless Steel Alternative Bezdan Stainless cross tube in ø 5/8" x 19.84' alloy 304 offers a durable, modern stainless steel option for horizontal railings. Bezdan Stainless - Part #8030

Baluster Size

Part Number Tube

Style No.

Color

Dimensions

Options/Notes

60" L

44" - 46" balusters in round, square and rectangular forms can also be used to create a horizontal style railing.

TL612 1/2" TL615RD TL658RD N EW

5/8"

1/2" x 1-1/2"

TL6115

More Choice for Railing Design Horizontal guard infill is code compliant in Canada. Learn what the National Building Code changes mean for your next project. geobezdan.com/nbc

09/26

geobezdan.com

1 800 663 6356

Square Steel Newel Posts 1-9/16" Square Tube

Level

Corner

34-3/8"

35" to 38-3/8"

34-3/8"

Stair

30 5/16"

Base plate with cover flange

5/16"

1-9/16"

TL900

TL905

NEW

TL910 TL920 TL930

Metal newel post TL920-30, geometric baluster TL99-1-30 and plain baluster TL12X-30

NEW Baluster

Part Number

Tube

N EW N EW N EW

N EW

1-9/16"

Post Placement

Dimensions

TL900

Level

34-3/8" H Base plate 3-15/16"

TL905

Corner

34-3/8" H Base plate 3-15/16"

Front of Tread

35" H Base plate 3-15/16"

TL920

Middle of Tread

36-5/8" H Base plate 3-15/16"

TL930

Back of Tread

38-3/8" H Base plate 3-15/16"

Style No. N EW

Size

TL910

Color

Options/Notes

Newel posts include handrail bracket, base plate, and cover flange. Three height options support tread placement to meet 36" height requirements. Fasteners not included.

geobezdan.com

1 800 663 6356

09/26

Baluster Collars Dress Up Plain Balusters W

1/2”

5/8”

5/8"

10-75

BC-01

10-06

BC-01A

ML123

ML116

Tube Size Guide Steel tube balusters are available in a variety of sizes to suit design preferences and reduce the number of balusters required per tread. Imagery displays spindles from smallest to largest for easy comparison. 1/2"

9/16"

5/8"

3/4"

Baluster Size

1/2"

5/8"

Part Number

Tube

Style No.

Color

1/2" x 1-1/2"

Material

Width

7.5"

1-7/8"

1-9/16"

1-3/4"

1-5/32"

BC-01A

1-15/16"

1-11/16"

ML123

2-1/2"

1-3/16"

Steel

BC-01

10-06 -

5/8"

Dimensions Length

10-75

1/2"

3/4"

Options/Notes Secure at top or bottom of plain baluster. Recessed set screw on one side.

Recessed set screw on 2 sides.

Diecast aluminum

Recessed set screw on 1 side. ML116

09/26

geobezdan.com

1 800 663 6356

Zinc alloy

3/4"

1-3/16"

Base Collars Decorative Collars Color Matched to Balusters

30 30P 40 60

30 40

1/2”

5/8”

10-00

10-17

10-0A

10-17A

Lower Profile Base Collar Create a sleek and contemporary look with a base collar profile at 1/4" height for level (10‑30‑30) and slope (10‑32‑30) applications. Base collars 10-10-30 and 10-30-30

Baluster Size

Tube

Part Number Style No.

10-00

Color 30

30P

Material

1/2"

10-17

10-0A

10-17A

Dimensions

Application

Length

Width

1-5/16"

Level

1-5/16"

1-11/16"

40˚ Slope

1-7/16"

Level

1-7/16"

1-13/16"

40˚ Slope

Options/Notes

Diecast aluminum 30 finish is also available in ABS polymer (30P)

Recessed set screw on 1 side.

5/8"

geobezdan.com

1 800 663 6356

09/26

Base Collars Decorative Collars Color Matched to Balusters ø 1-1/2"

ø 1-3/4"

3/8"

Profile View

30 40

1/2”

1/2"

9/16"

5/8"

10-15

10-20

10-20D

10-20F

n 1-1/2"

n 1-5/16"

3/8"

Profile View

ø 1-3/4"

30 40 45

Profile View

1/2”

5/8”

10-10A

Baluster

1/2”

Style No. 10-15

Color -

Level

1/2”

10-30

Part Number

Tube

1/4"

Profile View

10-10

Size

1/4"

Sloped

10-32

Material

Application

Options/Notes

Stamped steel

Level

Base collars 10-30-30 and 10-32-30 feature a 1/4" height for a lower profile in level and slope applications.

1/2" 10-20

9/16"

10-20D

5/8"

10-20F

1/2"

10-10

5/8"

10-10A

1/2"

Level

Sloped

09/26

geobezdan.com

10-30

10-32

1 800 663 6356

30˚ – 50˚ Slope

Handrail Brackets Complement and Finish Every Detail Zinc Alloy L

H W

30 40 45

50 60 BS

30 40 45

30 BS

50 60 BS

Back Plate

BRACKET 2

BRACKET 3

BRACKET 7

BRACKET 8

BRACKET 9

Stainless Steel L

Back Plate

9710

9720

9750

9770

Removable back plate for horizontal or vertical mounting options

Part Number Style No.

Material

Color

BRACKET 2

BRACKET 3 BRACKET 7

†

Zinc alloy

BRACKET 8 BS

9710

9750 9770

Stainless steel with a satin finish.

L ø

3-3/8" 2-5/32"

L ø

3-3/8" 2-1/8"

L 3" H 1-9/16" W 1-9/16" L 3" H 1-9/16" W 2-5/16"

†

BRACKET 9

9720

Dimensions

Stainless Steel 304 for indoor use

L 2-15/16" ø 2-3/8" W 2-3/4"

L 2-15/16" H 1-9/16" W 2-3/4"

Applications

Flat, fixed saddle

Flat, adjustable saddle Flat, fixed saddle Flat, adjustable saddle

Options/Notes Includes three #2 Phillips screws for flat bottom handrail and wall mounting. Color matched. Includes five #2 Phillips screws for flat bottom handrail and wall mounting. Color matched. Includes three #2 Phillips screws for flat bottom handrail and wall mounting. Color matched. Includes four #2 Phillips screws for flat bottom handrail and wall mounting. Color matched.

Flat, fixed saddle Round, fixed saddle for ø 1-1/2" handrail

Fasteners not included.

Flat, fixed saddle Flat, adjustable saddle

† BS The brushed stainless finish is achieved through a nickel plating process

geobezdan.com

1 800 663 6356

09/26

Accessories Accessories to Suit Your Installation Method Discs Steel discs for level and sloped railings. Designed to cover mounting points and create a clean, finished look. Available in select colors. ø

30 40 45

1/2”

DISC 1

DISC 2

Spirol Pin L

The spirol pin adapts a square baluster for easy installation. The carbon steel construction provides superior strength compared to wood dowels.

1/2”

SPIROL PIN

SPIROL PIN SS

TimeLine® Connectors The TimeLine connectors adapt balusters for surface mount installation.

H 3/32" L

The TLC SS connector is a multiuse polymer fitting designed for rectangular and square hollow tube balusters to be secured to wood on level applications.

L, W

1/2”

TLC

TLC SS

Baluster Size

Part Number

Tube

Style No.

Color

Material

Dimensions

Steel

ø 1-3/8"

Includes two matte black #1 Robertson screws. Sloped

DISC 2

Steel tube balusters

SPIROL PIN High carbon steel

L 2"

SPIROL PIN SS

TLC Polymer TLC SS

Options/Notes

Level

DISC 1

1/2"

For Use With

Snug fit with powder coated balusters. Relaxed fit with stainless steel balusters.

Stainless steel balusters

L 1-3/32" W 1-3/32" H 1-3/32"

Flat surface mount

L 1-3/8"

SS and steel tube balusters

Wood screws not included.

Visit our YouTube channel to view suggested installation methods using these accessories.

09/26

geobezdan.com

1 800 663 6356

Photo Gallery Explore our gallery of installation photos and photo-realistic renderings for inspiration for your next project. Visit geobezdan.com/photo-gallery

Bring Your Ideas to Life Visualize a railing design in four easy steps using the TimeLine® Designer. This interactive tool allows you to mix and match with just a few clicks of the mouse. Explore different baluster options and create railing patterns that you can save and share. Visit thetimelinedesigner.com

Top: Geometric baluster TL68-1-30 and plain baluster TL12X-30 Bottom: Geometric baluster TL120-30 and plain baluster TL12X-30

09/26

Geometric baluster TL28-1-30 and plain baluster TL12X-30

eac a_d onic @m

ac/ _de nica /mo .com m ra g .insta www

Geometric baluster TL96-2-30 and plain baluster TL12X-30

09/26

Top Left: Plain baluster TL12X-30 Top RIght: Geometric baluster TL98-1-30 Bottom: Geometric baluster TL78-2-30, plain baluster TL12X-30 and base collar 10-10-30

Geometric baluster TL77-1-30 and plain baluster TL12X-30

09/26

Metal newel post TL920-30, geometric baluster TL99-1-30 and plain baluster TL12X-30

Top: Plain baluster TL115-30 Bottom Left: Decorative baluster TL122-40 and plain baluster TL12-40 Bottom Right: Metal newel post TL910-30 and plain baluster TL12X-30

09/26

@monic a_deac - www.in stagram .com/mon ica_deac /

09/26

Geometric baluster TL20-1-30 and plain baluster TL12X-30

Geometric baluster TL47-2-30 and plain baluster TL12X-30

09/26

Top Left: Horizontal length TL615RD-30 Top Right: Plain baluster TL12X-30 Bottom Left: Decorative balusters TL130-1-30, TL130-2-30, and plain baluster TL12X-30 Bottom Right: Geometric baluster TL38-1-30, TL38-2-30 and plain baluster TL12X-30

Index Search Catalog by Style Number Numeric

10-00. . . . . . . . . . . . . . . . 24 10-0A. . . . . . . . . . . . . . . . 24 10-06 . . . . . . . . . . . . . . . . 23 10-10. . . . . . . . . . . . . . . . . 25 10-10A . . . . . . . . . . . . . . . 25 10-15. . . . . . . . . . . . . . . . . 25 10-17. . . . . . . . . . . . . . . . . 24 10-17A. . . . . . . . . . . . . . . . 24 10-20 . . . . . . . . . . . . . . . . 25 10-20D. . . . . . . . . . . . . . . 25 10-20F. . . . . . . . . . . . . . . 25 10-30 . . . . . . . . . . . . . . . . 25 10-32. . . . . . . . . . . . . . . . . 25 9710 . . . . . . . . . . . . . . . . . 26 9720. . . . . . . . . . . . . . . . . 26 9750. . . . . . . . . . . . . . . . . 26 9770. . . . . . . . . . . . . . . . . 26

DISC 1. . . . . . . . . . . . . . . . 27 DISC 2 . . . . . . . . . . . . . . . 27

B BC-01. . . . . . . . . . . . . . . . 23 BC-01A. . . . . . . . . . . . . . . 23 BRACKET 2. . . . . . . . . . . 26 BRACKET 3. . . . . . . . . . . 26 BRACKET 7. . . . . . . . . . . 26 BRACKET 8. . . . . . . . . . . 26 BRACKET 9. . . . . . . . . . . 26

C CC12. . . . . . . . . . . . . . . . . . . 7

M ML116 . . . . . . . . . . . . . . . . 23 ML123. . . . . . . . . . . . . . . . 23

S SPIROL PIN. . . . . . . . . . . 27 SPIROL PIN SS. . . . . . . . 27

T TL02. . . . . . . . . . . . . . . . . . 13 TL03. . . . . . . . . . . . . . . . . . 12 TL05. . . . . . . . . . . . . . . . . . 8 TL09-1 . . . . . . . . . . . . . . . . 9 TL10. . . . . . . . . . . . . . . . . . . 7 TL12 . . . . . . . . . . . . . . . . 6, 7 TL12A. . . . . . . . . . . . . . . . . . 7 TL12X. . . . . . . . . . . . . . . . . . 7 TL13 . . . . . . . . . . . . . . . . . . 15 TL15RD. . . . . . . . . . . . . . 6, 17 TL17-1. . . . . . . . . . . . . . . . . 12 TL18-1. . . . . . . . . . . . . . . . . 12 TL19-1. . . . . . . . . . . . . . . . . 14 TL20-1 . . . . . . . . . . . . . . . . 11 TL20-2. . . . . . . . . . . . . . . . 11 TL28-1. . . . . . . . . . . . . . . . . 12 TL29-2. . . . . . . . . . . . . . . . 14

TL34. . . . . . . . . . . . . . . . 6, 7 TL34RD. . . . . . . . . . . . . 6, 17 TL38-1. . . . . . . . . . . . . . . . . 12 TL38-2. . . . . . . . . . . . . . . . 12 TL39-2. . . . . . . . . . . . . . . . 14 TL47-2. . . . . . . . . . . . . . . . 11 TL58. . . . . . . . . . . . . . . . . . 6 TL58RD. . . . . . . . . . . . . . . 6 TL58RDL. . . . . . . . . . . . . . 17 TL66-1 . . . . . . . . . . . . . . . . 11 TL68-1. . . . . . . . . . . . . . . . . 11 TL68-2. . . . . . . . . . . . . . . . 11 TL77-1. . . . . . . . . . . . . . . . . 10 TL78-1. . . . . . . . . . . . . . . . . 10 TL78-2. . . . . . . . . . . . . . . . 10 TL88-2H. . . . . . . . . . . . . . . 10 TL91-1. . . . . . . . . . . . . . . . . 10 TL96-1 . . . . . . . . . . . . . . . . 9 TL96-2. . . . . . . . . . . . . . . . 9 TL98-1. . . . . . . . . . . . . . . . . 9 TL98-2. . . . . . . . . . . . . . . . 9 TL98A-1. . . . . . . . . . . . . . . 9 TL99-1 . . . . . . . . . . . . . . . . 9 TL101-1. . . . . . . . . . . . . . . . 15 TL101-1RD . . . . . . . . . . . . . 18 TL101-2. . . . . . . . . . . . . . . . 15 TL101-2RD. . . . . . . . . . . . . 18 TL102-1. . . . . . . . . . . . . . . . 15 TL102-1RD. . . . . . . . . . . . . 18 TL103-1RD. . . . . . . . . . . . . 18 TL104-1RD. . . . . . . . . . . . 20 TL105-1RD. . . . . . . . . . . . 20

TL106-1. . . . . . . . . . . . . . . . 16 TL106-2. . . . . . . . . . . . . . . 16 TL115. . . . . . . . . . . . . . . . 6, 7 TL120. . . . . . . . . . . . . . . . . 12 TL122 . . . . . . . . . . . . . . . . . 15 TL130-1. . . . . . . . . . . . . . . . 16 TL130-1RD. . . . . . . . . . . . . 18 TL130-2 . . . . . . . . . . . . . . . 16 TL130-2RD . . . . . . . . . . . . 18 TL200-4. . . . . . . . . . . . . . 15 TL224-1RD. . . . . . . . . . . . . 19 TL224-2RD. . . . . . . . . . . . 19 TL230-1RD. . . . . . . . . . . . . 19 TL230-2RD. . . . . . . . . . . . 19 TL260-1. . . . . . . . . . . . . . . 16 TL260-2. . . . . . . . . . . . . . . 16 TL261-1RD. . . . . . . . . . . . . 19 TL261-2RD. . . . . . . . . . . . . 19 TL261-4RD. . . . . . . . . . . . . 17 TL415RD . . . . . . . . . . . . . 20 TL450RD. . . . . . . . . . . . . 20 TL612 . . . . . . . . . . . . . . . . . 21 TL615RD. . . . . . . . . . . . . . 21 TL658RD. . . . . . . . . . . . . . 21 TL900 . . . . . . . . . . . . . . . 22 TL905. . . . . . . . . . . . . . . . 22 TL910. . . . . . . . . . . . . . . . 22 TL920. . . . . . . . . . . . . . . . 22 TL930. . . . . . . . . . . . . . . . 22 TL6115. . . . . . . . . . . . . . . . . 21 TLC. . . . . . . . . . . . . . . . . . 27 TLC SS. . . . . . . . . . . . . . . 27

Search Part Number in Photos Numeric 10-10-30. . . . . . . . . . . . 24, 31 10-30-30. . . . . . . . . . . . . 24

T TL02-30. . . . . . . . . . . . . 2, 13 TL05-30. . . . . . . . . . . . . . . 8 TL12-40. . . . . . . . . . . . . . 34 TL12X-30. . . . . . . . . 2, 5, 13, . . . . . . . . . . . . . . . 22, 28, 29, . . . . . . . . . . . . . . . 30, 31, 32, . . . . . . . . . . . . . . . 33, 34, 35, . . . . . . . . . . . . . . . . . . .36, 37 TL19-1-30. . . . . . . . . . . . . . 14 TL20-1-30 . . . . . . . . . . . . 35 TL28-1-30 . . . . . . . . . . . . 29

TL29-2-30. . . . . . . . . . . . . 14 TL38-1-30 . . . . . . . . . . . . 37 TL38-2-30. . . . . . . . . . . . 37 TL39-2-30. . . . . . . . . . . . . 14 TL47-2-30. . . . . . . . . . . . 36 TL58RDL-30. . . . . . . . . . . 17 TL68-1-30 . . . . . . . . . . 5, 28 TL77-1-30. . . . . . . . . . . . . 32 TL78-2-30. . . . . . . . . . . . . 31 TL96-2-30. . . . . . . . . . . . 30 TL98-1-30 . . . . . . . . . . . . . 31 TL99-1-30 . . . . . . . . . 22, 33 TL104-1RD-30. . . . . . . . . . 17 TL115-30. . . . . . . . . . . . . . 34 TL120-30. . . . . . . . . . . . . 28 TL122-40. . . . . . . . . . . . . 34

TL130-1-30. . . . . . . . . . . . 37 TL130-2-30. . . . . . . . . . . 37 TL450RD-60. . . . . . . . . . 20 TL615RD-30 . . . . . . . . . . 37 TL920-30 . . . . . . . . . 22, 33

geobezdan.com

1 800 663 6356

09/26

Search Catalog by Color 10 Designer White 10-10-10. . . . . . . . . . . . . . 25 BRACKET 2-10. . . . . . . . 26 BRACKET 3-10. . . . . . . . 26 TL05-10. . . . . . . . . . . . . . . 8 TL12-10. . . . . . . . . . . . . . . . . 7 TL12A-10 . . . . . . . . . . . . . . . 7 TL68-1-10. . . . . . . . . . . . . . 11

30 Satin Black 10-00-30. . . . . . . . . . . . . 24 10-0A-30. . . . . . . . . . . . . 24 10-06-30. . . . . . . . . . . . . 23 10-10-30. . . . . . . . . . . . . . 25 10-10A-30 . . . . . . . . . . . . 25 10-15-30. . . . . . . . . . . . . . 25 10-17-30. . . . . . . . . . . . . . 24 10-17A-30. . . . . . . . . . . . . 24 10-20-30. . . . . . . . . . . . . 25 10-20D-30. . . . . . . . . . . . 25 10-20F-30. . . . . . . . . . . . 25 10-30-30. . . . . . . . . . . . . 25 10-32-30 . . . . . . . . . . . . . 25 10-75-30. . . . . . . . . . . . . . 23 BC-01-30. . . . . . . . . . . . . 23 BC-01A-30. . . . . . . . . . . . 23 BRACKET 2-30. . . . . . . . 26 BRACKET 3-30. . . . . . . . 26 BRACKET 7-30. . . . . . . . 26 BRACKET 8-30. . . . . . . . 26 BRACKET 9-30 . . . . . . . 26 CC12-30. . . . . . . . . . . . . . . . 7 DISC 1-30. . . . . . . . . . . . . 27 DISC 2-30. . . . . . . . . . . . 27 ML116-30. . . . . . . . . . . . . 23 ML123-30. . . . . . . . . . . . . 23 TL02-30. . . . . . . . . . . . . . . 13 TL03-30. . . . . . . . . . . . . . . 12 TL05-30. . . . . . . . . . . . . . . 8 TL09-1-30. . . . . . . . . . . . . 9 TL10-30. . . . . . . . . . . . . . . . 7 TL12A-30. . . . . . . . . . . . . . . 7 TL12X-30. . . . . . . . . . . . . . . 7 TL15RD-30 . . . . . . . . . . . . 17 TL17-1-30. . . . . . . . . . . . . . 12 TL18-1-30. . . . . . . . . . . . . . 12 TL19-1-30. . . . . . . . . . . . . . 14 TL20-1-30 . . . . . . . . . . . . . 11 TL20-2-30. . . . . . . . . . . . . 11 TL28-1-30 . . . . . . . . . . . . . 12 TL29-2-30. . . . . . . . . . . . . 14 TL34-30. . . . . . . . . . . . . . . . 7 TL34RD-30. . . . . . . . . . . . 17

09/26

geobezdan.com

TL38-1-30 . . . . . . . . . . . . . 12 TL38-2-30. . . . . . . . . . . . . 12 TL39-2-30. . . . . . . . . . . . . 14 TL47-2-30. . . . . . . . . . . . . 11 TL58RDL-30. . . . . . . . . . . 17 TL66-1-30 . . . . . . . . . . . . . 11 TL68-1-30 . . . . . . . . . . . . . 11 TL68-2-30. . . . . . . . . . . . . 11 TL77-1-30. . . . . . . . . . . . . . 10 TL78-1-30 . . . . . . . . . . . . . 10 TL78-2-30. . . . . . . . . . . . . 10 TL88-2H-30 . . . . . . . . . . . 10 TL91-1-30. . . . . . . . . . . . . . 10 TL96-1-30 . . . . . . . . . . . . . 9 TL96-2-30. . . . . . . . . . . . . 9 TL98-1-30 . . . . . . . . . . . . . 9 TL98-2-30. . . . . . . . . . . . . 9 TL98A-1-30. . . . . . . . . . . . 9 TL99-1-30 . . . . . . . . . . . . . 9 TL101-1-30. . . . . . . . . . . . . 15 TL101-2-30. . . . . . . . . . . . . 15 TL102-1-30. . . . . . . . . . . . . 15 TL102-1RD-30. . . . . . . . . . 18 TL104-1RD-30. . . . . . . . . 20 TL105-1RD-30. . . . . . . . . 20 TL115-30. . . . . . . . . . . . . . . . 7 TL120-30. . . . . . . . . . . . . . 12 TL130-1-30. . . . . . . . . . . . . 16 TL130-2-30. . . . . . . . . . . . 16 TL200-4-30 . . . . . . . . . . . 15 TL224-1RD-30. . . . . . . . . . 19 TL224-2RD-30. . . . . . . . . 19 TL261-1RD-30. . . . . . . . . . 19 TL261-2RD-30. . . . . . . . . 19 TL261-4RD-30 . . . . . . . . . 17 TL415RD-30 . . . . . . . . . . 20 TL450RD-30. . . . . . . . . . 20 TL612-30. . . . . . . . . . . . . . 21 TL615RD-30 . . . . . . . . . . . 21 TL658RD-30. . . . . . . . . . . 21 TL900-30. . . . . . . . . . . . 22 TL905-30 . . . . . . . . . . . . 22 TL910-30. . . . . . . . . . . . . 22 TL920-30 . . . . . . . . . . . . 22 TL930-30 . . . . . . . . . . . . 22 TL6115-30 . . . . . . . . . . . . . 21

30P Satin Black in ABS Polymer 10-00-30P. . . . . . . . . . . . 24

33 Graphite Black TL12-33 . . . . . . . . . . . . . . . 6 TL58RD-33. . . . . . . . . . . . 6

1 800 663 6356

40 Wrinkled Black

50 Pavestone

10-00-40. . . . . . . . . . . . . 24 10-10-40. . . . . . . . . . . . . . 25 10-17-40. . . . . . . . . . . . . . 24 10-20-40. . . . . . . . . . . . . 25 10-20D-40. . . . . . . . . . . . 25 10-20F-40. . . . . . . . . . . . 25 BRACKET 2-40 . . . . . . . 26 BRACKET 3-40 . . . . . . . 26 DISC 1-40. . . . . . . . . . . . . 27 DISC 2-40. . . . . . . . . . . . 27 TL12-40. . . . . . . . . . . . . . . . 7 TL13-40. . . . . . . . . . . . . . . 15 TL15RD-40 . . . . . . . . . . . . 17 TL58RDL-40. . . . . . . . . . . 17 TL68-1-40. . . . . . . . . . . . . 11 TL78-1-40 . . . . . . . . . . . . . 10 TL78-2-40. . . . . . . . . . . . . 10 TL88-2H-40 . . . . . . . . . . . 10 TL101-1RD-40. . . . . . . . . . 18 TL101-2RD-40. . . . . . . . . . 18 TL102-1-40. . . . . . . . . . . . 15 TL102-1RD-40. . . . . . . . . . 18 TL103-1RD-40. . . . . . . . . . 18 TL106-1-40 . . . . . . . . . . . . 16 TL106-2-40. . . . . . . . . . . . 16 TL115-40 . . . . . . . . . . . . . . . 7 TL122-40. . . . . . . . . . . . . . 15 TL130-1-40 . . . . . . . . . . . . 16 TL130-1RD-40. . . . . . . . . . 18 TL130-2-40. . . . . . . . . . . . 16 TL130-2RD-40. . . . . . . . . 18 TL230-1RD-40. . . . . . . . . 19 TL230-2RD-40. . . . . . . . . 19 TL260-1-40. . . . . . . . . . . . 16 TL260-2-40 . . . . . . . . . . . 16 TL261-1RD-40. . . . . . . . . . 19 TL261-2RD-40 . . . . . . . . . 19 TL261-4RD-40. . . . . . . . . 17

10-10-50. . . . . . . . . . . . . . 25 BRACKET 2-50. . . . . . . . 26 BRACKET 3-50. . . . . . . . 26 TL12-50 . . . . . . . . . . . . . . . . 7 TL12A-50. . . . . . . . . . . . . . . 7 TL15RD-50 . . . . . . . . . . . . 17 TL98-1-50 . . . . . . . . . . . . . 9

45 Gun Metal Grey 10-10-45. . . . . . . . . . . . . . 25 BRACKET 2-45. . . . . . . . 26 BRACKET 3-45. . . . . . . . 26 DISC 1-45. . . . . . . . . . . . . 27 DISC 2-45. . . . . . . . . . . . 27 TL12-45 . . . . . . . . . . . . . . . . 7 TL15RD-45. . . . . . . . . . . . . 17 TL58RDL-45. . . . . . . . . . . 17 TL68-1-45 . . . . . . . . . . . . . 11 TL261-4RD-45 . . . . . . . . . 17 TL415RD-45 . . . . . . . . . . 20

60 Burnt Penny 10-00-60. . . . . . . . . . . . . 24 BRACKET 2-60 . . . . . . . 26 BRACKET 3-60 . . . . . . . 26 TL12-60. . . . . . . . . . . . . . . . 7 TL15RD-60 . . . . . . . . . . . . 17 TL58RDL-60. . . . . . . . . . . 17 TL68-1-60 . . . . . . . . . . . . . 11 TL102-1RD-60. . . . . . . . . . 18 TL122-60. . . . . . . . . . . . . . 15 TL415RD-60. . . . . . . . . . 20 TL450RD-60. . . . . . . . . . 20

77 Satin Bronze TL12-77. . . . . . . . . . . . . . . . 6

80 Midnight Copper TL12X-80. . . . . . . . . . . . . . . 7

BS Brushed Stainless BRACKET 2-BS . . . . . . . 26 BRACKET 3-BS . . . . . . . 26 BRACKET 8-BS . . . . . . . 26 BRACKET 9-BS . . . . . . . 26

SS Satin Stainless TL12-SS . . . . . . . . . . . . . . . 6 TL15RD-SS. . . . . . . . . . . . . 6 TL34RD-SS. . . . . . . . . . . . 6 TL34-SS. . . . . . . . . . . . . . . 6 TL58RD-SS. . . . . . . . . . . . 6 TL58-SS. . . . . . . . . . . . . . . 6 TL115-SS. . . . . . . . . . . . . . . 6

Stainless Steel 9710 . . . . . . . . . . . . . . . . . 26 9720. . . . . . . . . . . . . . . . . 26 9750. . . . . . . . . . . . . . . . . 26 9770. . . . . . . . . . . . . . . . . 26

Bezdan Railing Solutions 1 800 663 6356 geobezdan.com info@geobezdan.com

To view the entire TimeLine® collection visit geobezdan.com/timeline

Distributed by

Product images shown in this catalog are for illustrative purposes only. Although we have made every effort to display colors accurately, the physical product(s) may vary slightly from the images shown. The TimeLine® name and logo are the property of Geo. Bezdan Sales Ltd.

BUILDING CODE IMPORTANT NOTICE Information contained in this catalog is not intended as a recommendation for use or installation of products. Building codes may vary by jurisdiction and compliance with regulation is the customer’s responsibility. Always consult your local building department or licensed engineer regarding code compliance before starting your project. V15 - 09/26

Front Cover: Geometric baluster TL03-30

Zipbolt™

MAKING LIFE EASIER Zipbolt saves time and money with innovative fasteners for the most common joints in wood stairs, railings, cabinetry and furniture. An award-winning design and patented universal tool gearing system creates strong, durable and invisible joints for handrails, fittings and newel posts quickly and efficiently and in less time than conventional connectors. Disassembly is also easily achieved.

Wood Fasteners

03/25

geobezdan.com

1 800 663 6356

Durable connections for the most common joints in wood stairs, railings, cabinetry and furniture. u Wood connectors

NEW! Clickable Content

n Finished Spindles & Balusters | Zipbolt™

WOOD FASTENERS | WOOD CONNECTORS ZB-11600 UT Maxi Mitre (8mm x 135mm)

B 2-23/64" (60mm)**

OVERVIEW w Provides a quick and easy solution for angle joints found in staircase designs and furniture construction w Offers flexibility of allowing any angle between 90˚ and 180˚ with the distinct advantage of allowing the shaft to pass through the back of the housing thereby providing travel and permitting the joint to be recut if necessary w Features two diecast housings and allows the installer adjustment to create a perfect joint. The open channel housing allows the housing to be placed over the shaft easily engaging the thread and positioning the housing at the right height

2-23/64" (60mm)**

ø 23/64" (9mm)

A ø 1" (25mm)

ø 5/16" (8mm)

INSTALLATION w Refer to ILLUSTRATION 6

** Note: The distance from edge of the material to the center of the 25mm diameter bore hole (A) is 60mm (B). Depending on the angle the material is cut and the depth of the bore hole, this actual distance will vary.

Part #

Material

Box Lot

Weight

ZB-11600

Zinc Plated Steel

0.14 lbs. each

ILLUSTRATION 1 Connector Installation w To view an installation video and product specifications, visit bezdanzipbolt.com

Minimum Bore Depth 51/64" (20mm)

Shaft Center 25/64” (10mm)

geobezdan.com

1 800 663 6356

03/25

NEW! Clickable Content

n Finished Spindles & Balusters | Zipbolt™

WOOD FASTENERS | WOOD CONNECTORS ZB-11700 UT Mini Mitre (6mm x 135mm)

B 2-23/64" (60mm)**

A ø 1" (25mm)

OVERVIEW w Provides a quick and easy solution for angle joints found in staircase designs and furniture construction w A smaller version of the ZB‑11600 UT Maxi Mitre with a 6mm shaft and slim housing w Offers flexibility of allowing any angle between 90˚ and 180˚ with the distinct advantage of allowing the shaft to pass through the back of the housing thereby providing travel and permitting the joint to be recut if necessary w Features two diecast housings and allows the installer adjustment to create a perfect joint. The open channel housing allows the housing to be placed over the shaft easily engaging the thread and positioning the housing at the right height

2-23/64" (60mm)**

ø 9/32" (7mm)

ø 15/64" (6mm)

Part #

Material

Box Lot

Weight

ZB-11700

Zinc Plated Steel

0.12 lbs. each

ILLUSTRATION 2 Connector Installation w To view an installation video and product specifications, visit bezdanzipbolt.com

Minimum Bore Depth 31/64" (12.5mm)

03/25

INSTALLATION w Refer to ILLUSTRATION 2

geobezdan.com

1 800 663 6356

Shaft Center 13/64" (5.5mm)

NEW! Clickable Content

n Finished Spindles & Balusters | Zipbolt™

WOOD FASTENERS | WOOD CONNECTORS ZB-10800 UT Mini (6mm x 100mm) OVERVIEW w Provides a fast and easy way of joining worktops, countertops and panels w Creates a join in a matter of seconds w A practical and innovative solution that saves time and money in assembling worktops, countertops and panels w The slim design is perfect for material as thin as 16mm or 5/8" INSTALLATION w Refer to ILLUSTRATION 3 1-21/32" – 1-59/64" (42 - 49mm)

ø 63/64" (25mm)

1-21/32" – 1-59/64" (42 - 49mm)

ø 15/64" (6mm)

Part #

Material

Box Lot

Weight

ZB-10800

Zinc Plated Steel

0.09 lbs. each

ILLUSTRATION 3 Connector Installation w To view an installation video and product specifications, visit bezdanzipbolt.com

Minimum Bore Depth 31/64" (12.5mm)

Shaft Center 13/64 (5.5mm)

geobezdan.com

1 800 663 6356

03/25
