Surface Treatments

Super 1800-2 SprayJet

Vögele Pavers

Designed for pavement preservation surfacings like NovaChip Ultrathin bonded wearing courses. • Permits spraying of a tack coat and asphalt paving to take place in one pass, eliminating the tack coat truck from the paving train • Paver also can be used for conventional paving • Five precisely adjustable spray bars with a total of 20 selfsealing spray nozzles • SprayJet module incorporates high-precision control system • AB 500-2 Extending Screed permits paving widths of 16.4'

ForConstructionPros.com/10080116

MAXX Frictional Mastic Surface Treatment Applicators

Bergkamp Inc

Apply premixed frictional mastic surface treatments and premixed slurry seal over highways, roads, parking lots and airport runways. • Available in two models, the

MA20 and MA30 • Applies a material mix that is made to precise specification • Full-length ribbon mixer works to maintain the proper material consistency • Pavement treatment is applied with hydraulically operated, variable-width, low-pressure spray bar • 2,000- or 3,000-gal. steel material tank • In-cab controls • Easy-access mastic strainers protect pump and spray nozzles from clogging • Low-pressure system operates at less than 40 psi BIORESTOR In-Fra-Red Rejuvenator

BIO BASED SPRAY SYSTEMS, LLC

Adds back the oils lost from aging as well as those potentially lost during an infrared heating repair. •Testing has shown that penetration and viscosity values can be returned to those of like new asphalt binder • Without the addition of new oil, the repaired area can show cracking or significant ravel due to the increased brittleness of asphalt binder • Comparable test results have been achieved with BIORESTOR In-Fra-

Red used at only half of the petroleum rejuvenator rate

ForConstructionPros.com/11299286

MicroTekk Microsurfacing Treatment

Road Science

Combines a unique process and materials to increase a pavement’s durability and delay or mitigate cracking, extending the life of micro-surfacing layer. • Increased workability • Extended construction window • Less aggregate and water sensitivity • Short-term raveling resistance

ForConstructionPros.com/12130835

W 35 Ri Milling Machine

Wirtgen America

Designed for tight or restricted areas for the partial rehabilitation of pavement, milling around manhole covers, placing and removing road markings, or interior applications. 14" cutting width, expandable to 20", with a maximum 4" cutting depth. Three variably selectable milling drum speeds suit a wide range of applications. A 60-hp Deutz TCD 2.9 L4 Tier 4 Final engine.

ForConstructionPros.com/12228882

ArrTekk CRS Emulsifiers

Road Science

Delivers optimal emulsion viscosity characteristics which remain consistent across a wide range of asphalts for cost-effective chip sealing. • Uses cutting-edge chemistry to achieve desired chip seal emulsion viscosity across a broad range of asphalts • Emulsion producers benefit from increased versatility in asphalt selection which lowers costs, and reduced reprocessing • Forces chip seal emulsion to develop cohesive strength at least 50% sooner than alternatives

ForConstructionPros.com/21047877

RaynMaker Sealcoat Spray System

Rayner Equipment Systems, an Etnyre International Company

Rayner Equipment Systems introduces the RaynMaker, a specialty asphalt distributor. • Totally self-contained • Can be mounted on an available truck in minutes; requires no external hookups • Computerized spary rate controls • Full-sweep internal mixer • Wireless remote control with digital GPS inputs

ForConstructionPros.com/10093079

PASS QB

Western Emulsions Inc.

Unit is designed for fog seal applications. • Rejuvenates and seals to extend the life cycle of asphalt • Prevents weathering of the pavement surface • Scientifically formulated with cationic emulsifiers • Won't track or bleed when cured • Available and formulated for night-time work applications at lower ambient temperatures

ForConstructionPros.com/10160395

BrewerCote Pavement Sealer

The Brewer Company

• Refined tar sealer • Resistant to gas and oil • Colloid mill production assures consistent, homogeneous material • Dries to a deep black color

ForConstructionPros.com/10086661

Asphalt Distributor

Pavement Services Inc.

Has a one-touch, automatic, heated cleanout system that cleans the spraybar, pump and plumbing. • 400-gpm heated asphalt pump • Dual diesel-fired burners with auto-thermostat control and

Out Fire protection • Programmable computer system with redundant harness • 1,000- to 4,000-gal. tanks • 8- to 16-ft. telescoping spraybar • Single location strainer

Roadtec RX-700 Cold Planer

Astec Industries Inc.

Offers balanced weight distribution and can cut up to 14 in. deep. • Standard cut widths of 6 ft. 7 in., 7 ft. 2in., 8 ft. 2 in. and 10 ft. • Features a 60° front load-out conveyor swing • Dual control stations allow operation from either side • Automated Control of Elevation automates machine elevation • Keyway steering with crab, coordinated, rear or front only modes • 800-hp Caterpillar C18 six-cylinder, Tier 4 Final diesel engine

ForConstructionPros.com/21759539

BM 500/15-2 and BM 600/15-2 Milling Machines

BOMAG Americas Inc.

A reengineered vibration-isolated operator’s station featuring a suspension seat with optional heating and a 45° slewing angle for enhanced visibility. • Maximum milling widths of 19.7 and 23.6 in. • Four extra cutting tools, low vibration milling and smooth milled edges • 7-in. full graphic color display • Available in three- and four-wheel designs • Maximum milling speed for four-wheel configurations is increased by more than 25% for both models

ForConstructionPros.com/21121832

Loegering ST Series Stabilizing & Milling Attachments

ASV Holdings Inc.

Feature a unique drum design that allows both milling and stabilizing. • Suited for use on smaller, lower flow-rate loaders • Accurate milling to a depth of 9 in. • Independent level control on both sides of the attachment enable it to follow the contour of the pavement independent of the loader • Large mixing chamber provides optimal mixing of binders into cut pavement • Joystick controls allow full operator control at the touch of four buttons

ForConstructionPros.com/21174076

BS200 Tack Coat Sprayer/Hot Tack Distributor

Trade Industry Company AB (TICAB)

Can be mounted on a trailer or transported on a vehicle such as a pickup truck. • Honda GX-160 diesel aircooled engine • Built-in heating system with gas propane burner • Gear pump • Diesel cleaning system • Gear reducer • Safety bypass valve • Drum not included • Weight: 330 lb. without drum

ForConstructionPros.com/21118441
