6 minute read
Fischer
FINANCE
Available* FARMSHOP
DIRECT IMPORTS
SAVE 20% WITH 2022 INDENTS
Rotary Tedders 4 - 12 metre available
TECHNICAL DETAILS P4 - 471 P4 - 531 P6 - 651 P6 - 771
Working width [m / ft] 4,70 / 15’5” 5,30 / 17’5” 7,00 / 21’4” 7,70 / 25’3” Transport width / height [m / ft] 3,00 / 2,50 // 9’8’’ / 8’2’’ 3,00 / 2,70 // 9’8’’ / 8’1’’ 3,00 / 3,60 // 9’8’’ / 11’8” 2,95 / 4,00 // 9’7’’ / 13’2’’
Number of rotors [pcs.] 4 6 Necessary hydraulic couplers 1 x single acting 1 x double acting Working capacity [ha/h / ac/h] ~ 5,60 / 13,85 ~ 6,30 / 15,55 ~ 7,80 / 19,30 ~9,20 / 23
Number of arms [pcs.] 6
Rotor diameter [cm / ft] 162 / 5’4” 172 / 5’8” 160 / 5’3’’ 172 / 5’8” RPM 540 3-point hitch cat. II
Power demand [HP] from 30 from 40 from 50 from 60
Tires (with inner tubes) 16 x 6,5-8 Weight [kg / lbs] 665 / 1470 680 / 1500 915 / 2020 945 / 2080 PTO shaft tractor - tedder: with friction clutch
RRP (EX GST) $19,500.00 $22,220.00 $29,400.00 $31,800.00 INDENT (EX GST) $16,250.00 $18,580.00 $24,500.00 $26,500.00
SCAN THE CODE TO SEE IT IN ACTION
Single Rotor Rake Z-470
TECHNICAL DETAILS Z - 470
Working width [m / ft] 4,70 / 15’5”
Windrow width [m / ft] Transport width [m / ft] 3,80 / 12’8” Transport width without arms [m / ft] 2,30 / 7’7”
Working capacity [ha/h / ac/h] ~ 5,60 / 14,00 Number of arms [pcs.] 13
Rotor diameter with arms [m / ft] 3,80 / 12’8”
Number of tines [pcs./arm] 4 RPM* 3-point hitch cat. II Power demand [HP] from 50 Tires (with inner tubes) Weight [kg / lbs] 820 / 1810 PTO shaft
SCAN THE CODE TO SEE IT IN ACTION
Double Rotor Rake Z2-840
TECHNICAL DETAILS Z 2 - 840
Working width [m / ft] 7,60 – 8,40 / 24’11’’-27’7’’ Windrow width [m / ft] 1,20 - 2,00 / 3’11’’-6’7’’ Transport width / height [m / ft] 3,00 / 3,75 // 9’8”/ 12’3’’
Working capacity [ha/h / ac/h] ~ 9,00 / 22,00
Number of arms per rotor [pcs.] 11 Number of dismountable arms per 4 rotor for transport pcs.] RPM* 540 Power demand [HP] from 80
Tires (with inner tubes) 16 x 6,5 - 8 / 340/55-16 Weight [kg / lbs] 2330 / 5130
SCAN THE CODE TO SEE IT IN ACTION
Basket Rake TWIST 600 RAKE AND BALE - SAVE TIME
TWIST 600 is a center delivery rake designed for a fast, efficient and clean raking of forage.
It can be mounted to the front or rear of the tractor. With front mounting, you can simultaneously rake and work, e.g. with a baler. The rake consists of two working systems driven by tractor’s hydraulics using hydraulic motors. The machine does not need the tractor’s PTO shaft for operation. The rake has low weight in comparison to its extensive working width.
TECHNICAL DETAILS
TWIST 600
Working width [m / ft] Windrow width [m / ft] 6,00 / 19’ 9’’ 1,30 / 4’ 4’’
Transport width [m / ft] 2,35 / 7’7’’
Transport height [m / ft] 3,50 / 11’5” Necessary hydraulic couplers 2 x double acting Working capacity [ha/h / ac/h] 6,00 / 15,00
Working drums [pcs.] 2 Raking bar [pcs.] 5
Number of tines [pcs.] 18 Tires (with inner tubes) [pcs.] 15x6,5 Drive type Hydraulic
Pump capacity [l/min] 30 / 7
Nominal pressure [bar / MPa] 160 / 16 Weight [kg / lbs] 770 / 1700
RRP (EX GST) $37,000.00 RRP (EX GST) $31,000.00
SCAN THE CODE TO SEE IT IN ACTION
FINANCE
Available* FARMSHOP
DIRECT IMPORTS
SAVE 20% WITH 2022 INDENTS
Fischer GL4 Fix rear mounting with HYDRAULIC PRECISION SENSOR both sides on swing arms.
A E B A
Mod.
C
Outer dimensions
D B
Cutting width HP KG A B C D E A B RRP INDENT
GL/4 45 95-175 Special
4 8 30 - 80 538 97 148 115 27 180 95 175 $32,000.00 $25,600.00 GL/4 50 120-205 4 8 30 - 80 578 122 125 115 27 205 120 200 $33,000.00 $26,400.00 GL/4 50 130-215 4 8 30 - 80 589 132 130 115 27 220 130 215 $34,000.00 $27,200.00 GL/4 50 140-225 4 8 30 - 80 639 147 155 115 27 231 144 227 $34,500.00 $27,600.00 GL/4 60 140-245 4 8 30 - 80 658 152 168 115 27 247 149 243 $35,000.00 $28,000.00 GL/4 60 160-260 4 8 30 - 80 697 170 173 115 27 268 165 263 $35,400.00 $28,520.00 GL/4 60 180-280 4 8 40 - 80 737 182 183 115 27 284 178 279 $35,900.00 $28,950.00 GL/4 60 200-300 4 8 50 - 80 774 202 190 115 27 308 198 303 $39,000.00 $31,200.00 GL/4 60 220-320 4 8 50 - 80 831 223 203 115 27 327 217 322 $42,000.00 $33,600.00 GL/4 70 220-340 4 8 50 - 80 850 223 211 115 27 343 217 338 $42,500.00 $34,100.00
SCAN THE CODE TO SEE IT IN ACTION
Fischer SL Mower The one-sided Fischer SL is one of the most versatile mowers in our range.
Mod.
D F
C E
A
B
A
B
Outer dimensions
Cutting width fix mob. HP KG A B C D E F A B RRP INDENT
SL3/180-230 3 3 2 40 - 90 663 198 148 93 30 239 204 192 234 $33,000.00 $26,400.00 SL3/200-250 3 3 2 40 - 90 696 215 123 93 30 260 210 209 254 $34,000.00 $27,300.00 SL3/230-280 3 3 2 40 - 90 759 245 159 93 30 293 217 239 287 $35,000.00 $28,000.00 SL3/250-300 3 3 2 40 - 90 801 258 163 93 30 309 221 252 302 $36,500.00 $29,200.00
SCAN THE CODE TO SEE IT IN ACTION
Fischer BV2 Mower Fischer BV2 Expandable Deck Mower.
A
Mod.
C
D B
Outer dimensions
Cutting width HP KG A B C D E Min. Max. RRP INDENT
BV2 160-230 2 4 40 - 100 595 165 170 101 22 226 162 223 $25,000.00 $20,000.00 BV2 170-245 special 2 4 40 - 100 563 178 165 101 22 248 173 243 $26,000.00 $20,800.00 BV2 190-260 2 4 40 - 100 702 192 189 101 22 262 189 259 $27,000.00 $21,600.00 BV2 220-300 2 4 40 - 100 818 223 210 101 22 203 220 299 $28,000.00 $22,400.00 BV2 250-340 2 4 40 - 100 915 250 225 101 22 340 245 333 $29,000.00 $23,200.00 BV3-180-260 3 6 40 - 100 665 183 149 105 24 262 178 258 $30,000.00 $24,400.00 BV3-195-290 3 6 40 - 100 746 204 149 107 24 293 198 286 $31,000.00 $24,800.00 BV3-250-360 3 6 40 - 100 940 253 183 105 24 365 250 362 $32,000.00 $25,600.00 More model configurations available on request.
