Balustrades assembly instructions - Alba Magic - en
THE ACCESSORIES ARRIVE ALREADY ASSEMBLED! TOP PART
How to mount the ALBA MAGIC system
How to mount the ALBA MAGIC system
FASCIA MOUNTING INSTALLATION
Threaded rod in stainless steel M14
• Hole Ø 16 mm
• Clean the hole
• Fill the hole approximately up to 50% with VBOND chemical resin or similar (not included in our supply)
• Insert the M14 rod
• Leave 115 mm out of the support
1. Insert the bushing on the rod
2a. Screw the upper accessory onto the rod as far as it will go and incorporate bushing 1
BOTTOM
System with shock absorber
1. Insert the bushing on the rod
2a. Screw the lower accessory onto the rod as far as it will go and incorporate bushing 1
2. Screw until leaving 5 mm
3. Insert the cylinder onto the rod and onto the notches of the 2
4. Insert cylinder 4 onto cylinder 3
BOTTOM
2. Screw until there is a gap of 5 mm
3. Insert the cylinder onto the rod as far as it will go and onto the notches of the 2
4. Insert cylinder 4 onto cylinder 3
4a ADJUSTMENT SYSTEM
REGULAR FLOOR SIMULATION:
MINIMUM ADJUSTMENT
Example without protrusion
How to mount the ALBA MAGIC
system
Glass assembly
All vertical plumb or horizontal alignment adjustments are made with the glass plate mounted.
Go to notes 4.a and 4.b for adjustments
Use an adjustable face spanner wrench (not supplied by Faraone)
MAXIMUM ADJUSTMENT
Example with protrusion of 30 mm
Note: depth adjustment of 15 mm
DEPTH
ADJUSTMENT
Use a special wrench on the internal bushing.
The Alba Magic system allows you to align the bosses to the millimetre both vertically (therefore between the upper and lower accessory) and horizontally (as shown below). With a variation range that goes from a minimum of 50 mm to a maximum of 65 mm between floor and glass.
IRREGULAR FLOOR SIMULATION:
GLASS HOLE
How to mount the ALBA MAGIC system
SIMULATION TO ALIGN THE HEIGHTS OF THE GLASS
EXAMPLE OF ADJUSTMENT
Note: eccentric adjustment +/- 4 mm
GLASS HOLE
ECCENTRIC ADJUSTMENT
Use a special wrench on the external bushing.
Use an adjustable face spanner wrench (not supplied by Faraone)
As regards the adjustment between the accessory and the glass, it is necessary to act on the eccentric bushing that is present inside the boss. This particular elliptical accessory allows alignment to the millimetre, both in height and in width, so as to perfectly centre the hole in the glass.
ATTENTION:
5a. Screw the upper accessory onto the rod until the glass is tightened
5b. Screw the lower accessory until the glass is tightened
Insert the other accessories
How to mount the ALBA MAGIC system
6. Screw and tighten by hand and put silicone points for gluing the cap 7.
6b. Snap-mounted cap and glued on silicone points for safety.
ALTERNATIVE INSTALLATION ON THE INSIDE OF A LOW WALL
NB: invert the position of the shock absorbers for internal fixings on low wall
How to mount the ALBA MAGIC system
ASSEMBLY EXAMPLE FASCIA MOUNTING
FRONT SHOCK ABSORBERS
ASSEMBLY EXAMPLE ON THE INSIDE OF A LOW WALL
REAR SHOCK ABSORBERS
NB: invert the position of the shock absorbers for internal fixings
EXPLODED VIEW. THE COMPONENTS ARRIVE ALREADY ASSEMBLED.
